Thomas 135TA User manual

135TA/137/153
PUBLICATION NO. 52935
June 2005
Owner’s
and
Operator’s
Manual
Skid Steer Loader

THOMAS EQUIPMENT LIABILITY WARRANTY
THE WARRANTY IS THE ONLY OBLIGATION OF THOMAS OR A THOMAS
DEALER TO THE PURCHASER OR ANYONE ELSE CONCERNING A PRODUCT, IT’S
SERVICE, IT’S USE OR PERFORMANCE OR IT’S LOSS OF USE OR FAILURE TO
PERFORM. NEITHER THOMAS NOR ATHOMAS DEALER HAVE MADE AND
NEITHER WILL MAKE ANY OTHER EXPRESSED OR IMPLIED REPRESENTATION,
WARRANTY OR AGREEMENT CONCERNING A PRODUCT, NEITHER THOMAS NOR
ATHOMAS DEALER HAVE MADE OR WILL MAKE ANY REPRESENTATION,
WARRANTY OR AGREEMENT CONCERNING A PRODUCT’S MERCHANTABILITY
OR OTHER QUALITY, IT’S SUITABILITY FOR PURCHASER’S PURPOSE (EVEN IF A
PURCHASER HAS INFORMED THOMAS OR ATHOMAS DEALER OF THAT
PURPOSE), IT’S DURABILITY, PERFORMANCE OR OTHER CONDITION.
EVEN IF THOMAS OR A THOMAS DEALER WAS ADVISED OF THE
POSSIBILITY OF SUCH LOSS, NEITHER THOMAS NOR A THOMAS DEALER WILL BE
LIABLE TO PURCHASER OR ANYONE ELSE FOR ANY INDIRECT, INCIDENTAL
CONSEQUENTIAL, PUNITIVE, ECONOMIC, COMMERCIAL, OR SPECIAL LOSS
WHICH IN ANY WAY ASSOCIATED WITH A PRODUCT. THIS INCLUDES ANY LOSS OF
USE OR NON-PERFORMANCE OF A PRODUCT, ANY REPLACEMENT RENTAL OR
ACQUISITION COST, ANY LOSS OF REVENUE OR PROFITS, ANY FAILURE TO
REALIZE EXPECTED SAVINGS, ANY INTEREST COSTS, ANY IMPAIRMENT OF
OTHER GOODS, ANY INCONVENIENCE OR ANY LIABILITY OF THE PURCHASER TO
ANY OTHER PERSON.
PURCHASER MAY NOT ATTEMPT TO ENLARGE ITS RIGHTS UNDER THE
WARRANTY BY MAKING CLAIM, FOR INDEMNITY, FOR BREACH OF CONTRACT,
FOR BREACH OF COLLATERAL WARRANTY, FOR A TORT (INCLUDING
NEGLIGENCE, MISREPRESENTATION OR STRICT LIABILITY) OR BY CLAIMING
ANY OTHER CAUSE OF ACTION.
THE WARRANTY IS A CONDITION OF SALE OF THE PRODUCT TO THE
PURCHASER AND WILL THEREFORE APPLY EVEN IF THE PURCHASER ALLEGES
THAT THERE IS A TOTAL FAILURE OF THE PRODUCT.
N.B. Read and practice your Thomas operating and servicing instructions. Failure to do this may
void the warranty.
PUBLICATION NUMBER 52473
© Thomas Equipment Inc. 2005
Printed in Canada

INDEX
1. SAFETY PRECAUTIONS
2. CONTROLS
2. 1 Instrument Panel
2. 2 Seat and Seat Belt
2. 3 Seat Bar
2. 4 Parking Brake
2. 5 Throttle Controls
2. 6 Lift Arm Supports
2. 7 Steering Controls
2. 8 Foot Pedals
2. 9 Quick - Tach
2. 10 Electrical Panel
3. OPERATION
3. 1 Starting Instructions
3. 2 Operating Procedure
3. 3 Filling From a Pile
3. 4 Digging with a Bucket
3. 5 Leveling and Backfilling
3. 6 Auxiliary Hydraulics
3. 7 Lifting
3. 8 Towing
3. 9 Securing and Transporting
3. 10 Lowering Lift Arms
4. MAINTENANCE
4. 1 Preventive Maintenance Service Schedule
4. 2 Service Access
4. 3 Daily Service Checks
4. 4 50 Hour Service Check
4. 5 150 Hour Service Check
4. 6 Final Drive Maintenance
4. 7 Hydraulic / Hydrostatic System Maintenance
4. 8 Engine Maintenance
4. 9 Air Cleaner Maintenance
4. 10 Engine Cooling System
4. 11 Electrical System
4. 12 Tire Maintenance
4. 13 Trouble Shooting
4. 14 Hydraulic / Hydrostatic Circuit
4. 15 Special Tools
5. SPECIFICATIONS
5. 1 Loader Specifications
5. 2 Torque Specifications
5. 3 Decals
6. ATTACHMENTS AND BUCKETS
6. 1 Thomas Approved Buckets and Attachments

WARNING
This warning indicates
hazards or unsafe
practices which COULD
result in severe personal
injury or death.
This warning indicates an
immediate hazard which
WILL result in severe
personal injury or death.
DANGER
Instructions are necessary
before operating or
servicing this machine.
Read the operators manual
and service decals on the
loader. Follow warnings and
instructions in this manual
when making repairs,
adjustments or servicing.
Check for correct operation
after adjustments and
repairs.
IMPORTANT
This notice shows
important procedures
which must be followed
to prevent damage to the
loader or attachment.
IMPORTANT
This warning indicates
hazards or unsafe
practices which COULD
result in minor personal
injury or product or
property damage.
CAUTION
FOREWORD
This book has been written to give the Owner / Operator necessary operating,
servicing and preventative maintenance instructions on the loader.
Read this manual completely and know the loader before operating or servicing it.
Do not do any service procedures that are not in the Operator’s manual.
Only service personnel that have had training in the service of this loader can do these
service procedures.
Reference Information
Write the correct information for your loaders in the spaces below. Always use these
numbers when referring to your loader.
Model No.
Serial No.
Dealer Name
Address
Phone
Throughout this manual the terms DANGER, WARNING and CAUTION are used to
indicate the degree of hazard in terms of personal safety. These words will be used in
conjunction with the Safety - Alert symbol, a triangle with an exclamation mark.
Throughout this manual, the term IMPORTANT is used
* To indicate that instructions are necessary before operating or servicing the
loader.
* To show important procedures which must be followed to prevent damage to
the loader or attachment.

5
1. SAFETY PRECAUTIONS
The following precautions are suggested to help prevent accidents.
A careful operator is the best operator. Most accidents can be avoided by observing certain precautions. Read and take the
following precautions before operating this loader to help prevent accidents. Equipment should be operated only by those
who are responsible and instructed to do so.
1. Read this manual carefully before using the loader.
Working with unfamiliar equipment can lead to accidents.
2. Do not allow anyone to ride on the loader with the
operator.
3. Make sure the seat bar is installed and functioning at all
times.
4. Never run the engine in a closed building without
adequate ventilation, as the exhaust fumes can cause
death.
5. Always fasten the seat belt around your waist before
starting the engine. Never fasten the seat belt behind you.
6. Never attempt to start the engine while standing beside
the unit unless as specified in this manual or under
specific service and backhoe operation procedures. Start
the engine only while sitting in the operator’s seat with
the seat belt fastened around you. Always check to make
certain that the seat cushion is secured to the frame.
7 Keep the operator’s area free of debris.
8. Never enter or leave the loader while the engine is
running. Always lower the lift arms down against the
frame, drop the attachment down to contact the ground,
set the parking brake and shut off the engine prior to
leaving the loader.
9. If the unit is equipped with a cab enclosure kit always
close the door prior to operating the loader lift arms.
10. Do not operate the loader unless all safety equipment,
shields, seat belt, seat bar, hydraulic controls, parking
brake, operator guard, and lift arm supports are working
properly, as well as all safety and instruction decals are in
place.
OPERATING THE LOADER
1. Always drive the loader at speeds compatible with safety,
especially when operating over rough ground, crossing
ditches or when turning.
2. Avoid jerky turns, starts, stops, or reverses.
3. Use care when operating on steep grades to maintain
proper stability.
4. Do not turn the loader while the lift arms are in the
raised position.
5. Be careful when driving through door openings or under
overhead objects. Always make sure there is sufficient
clearance for the operator’s guard.
6. When travelling on public roads, know the local rules and
regulations and make sure your loader is equipped with
the proper safety equipment.
7. Always be sure of water, gas, sewage and electrical line
locations before you start to dig.
8. Watch out for overhead and underground high-voltage
electrical lines when operating the loader.
9. Always park the loader on level ground where possible. If
the loader is to be parked on an incline, always lower the
attachment so it contacts the ground, set the parking brake
and block the wheels.
10. Do not leave the loader when it is in motion.
11. Do not dismount from the loader and leave the loader lift
arms raised, unless following specific service procedures.
Always lower the lift arms down against the frame and
drop the attachment down to contact the ground.
12. Always be watchful of bystanders when operating the
loader.
13. Always carry the attachment low for maximum stability
and visibility.
14. Exercise extreme caution when operating the loader with
a raised attachment.
15. Never attempt to lift loads in excess of loader capacity.
16. Check that the foot pedals are locked before getting out of
the operator’s seat.
17. Keep both hands on the control levers while the loader is
in motion.
MAINTENANCE
1. Stop the engine before performing any service on the
loader.
2. Never refuel the loader while smoking or with the engine
hot or running.
3. Replace all missing, illegible or damaged safety and
warning decals. See Section 5.3 for list.
4. Do not modify or alter, or permit anyone to modify or
alter this loader or any of its components or any loader
function.
5. Do not bypass the safety system. Consult your Thomas
Equipment Dealer if your safety controls are
malfunctioning.
6. Do not make mechanical adjustments while the loader is
in motion or when the engine is running. However, if
minor engine adjustments must be made, securely block
the loader with the wheels clear of the ground, and use
extreme caution.
7. Do not attempt to repair or tighten hydraulic hoses when
the system is under pressure, when the engine is running
or when the lift arms are raised.
8. Do not get under the attachment or lift arms or reach
through the lift arms when they are raised.
9. Never attach the chains or ropes to the operator’s guard
for pulling purposes, as the loader can tip over.
10. Whenever servicing or replacing pins in cylinder ends,
buckets, etc., always use a brass drift and a hammer.
Failure to do so could result in injury from flying metal
fragments.
11. Cooling system operates under pressure which is
controlled by the radiator cap. It is dangerous to remove
the cap while system is hot. Always turn cap slowly to the
first stop and allow the pressure to escape before
removing the cap entirely.
12. Keep the operator and foot pedal areas free from debris.
13. For lifting and towing instructions, refer to Sections 3.7
and 3.8 of this manual.

To prevent personal
injury do not start the
engine unless you are in
the seat with the seat belt
fastened around you.
WARNING
To prevent personal
injury do not operate the
loader without lowering
the safety bar, fastening
the seat belt and keeping
feet on the control pedals
or cab floor.
WARNING
This engine is equipped
with glow plugs. Do not
use ether or any high
energy fuels to assist
starting.
IMPORTANT
C-359
6
1. SAFETY PRECAUTIONS
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked.
Then, unlatch the seat belt
and exit the loader. Do not
enter or exit with the engine
running unless as specified
in this manual or under
specific service and backhoe
operating procedures.
WARNING
START SAFELY
1. Sit in the operator’s seat and adjust it so you can operate
all of the controls properly.
2. Adjust the seat and fasten the seat belt. Cycle the
controls to make sure they are in the locked or neutral
position. Lower the seat bar.
3. Know the exact starting procedure for your machine.
See Section 3 for the manufacturer’s instructions for
starting.
PARK SAFELY
Select level ground whenever possible. If you must park
on a slope or incline, position the machine at right angles
to the slope. Lower the attachment to the ground, engage
the parking brake and block the wheels (C359).
C - 360

7
2. CONTROLS
2. 1 Instrument Panel
2. 2 Control Lever Handles
2. 3 Seat and Seat Belt
2. 4 Seat Bar
2. 5 Parking Brake
2. 6 Throttle Control
2. 7 Lift Arm Supports
2. 8 Steering Controls
2. 9 Auxiliary Controls
2. 10 Foot Pedals
2. 11 Hand Controls
2. 12 Quick-Tach
2. 13 Electrical Panel
2. CONTROLS

1. Fuel Gauge: The fuel gauge indicates the quantity of
fuel remaining in the fuel tank.
2. Ignition Switch: The ignition switch is a four (4)
position switch: ‘OFF’, ‘PRE-HEAT’, ‘RUN’ and
‘START’. Turn the key counter clockwise to engage
engine ‘PRE-HEAT’. Turn the key clockwise to the
‘START’ position, this engages the starter. The key will be
in the ‘RUN’ position when released. Turn the key to
‘OFF’ to shut off the engine and remove the key.
3. Hour Meter: The hour meter records the number of
engine operating hours and has a total of 9999.9 hours.
4. Left Signal Indicator Light: This light will illuminate
when the operator uses the optional left signal (not
available on all models).
5. Auxiliary Front Indicator Light: This light will
illuminate when the loader auxiliary hydraulic front switch
(not available on all models) is turned on.
6. Hi-Flow Hydraulics Indicator: This light will
illuminate when the loader hi-flow hydraulics (not
available on all models) are in use.
7. Work Lights Indicator: This light will illuminate
when the loader work lights are turned on. This will serve
as a reminder to turn them OFF when the loader is not in
use.
8. Right Signal Indicator Light: This light will
illuminate when the operator uses the optional right signal
(not available on all models).
9. Hydraulic Oil Temperature Indicator: This light will
illuminate when the oil temperature has exceeded
recommended levels. Shut off the engine immediately and
determine the cause.
10. Brake Indicator Light: The brake light will
illuminate when the parking brake is engaged.
11. Seat Belt Indicator Light: This light will illuminate
when the seat belt is unfastened.
12. Hydraulic Oil Pressure Indicator Light: This light
will illuminate when there is low hydraulic oil pressure. If
this light illuminates, shut off the engine and determine the
cause (not available on all models).
13. Rotary Beacon Indicator: This light will illuminate
when the optional rotary beacon (not available on all
models) is turned on.
14. Engine Oil Pressure Indicator: This light will
illuminate when the engine loses lubrication pressure. Shut
off the engine immediately and determine the cause.
15. Coolant Temperature Indicator Light: This light
will illuminate if there is a rise in engine temperature. If
this occurs, shut off the engine immediately and determine
the cause.
16. Alternator Indicator Light: This light will
illuminate when the alternator is not producing sufficient
current.
8
2. CONTROLS
2.1 INSTRUMENT PANEL
C3170 Fig. 2.1
To prevent personal
injury never add fuel to
the loader when the
engine is running or is
hot. NO SMOKING!
WARNING
4
To prevent personal
injury do not start the
engine unless you are in
the seat with the seat belt
fastened around you.
WARNING
This engine is equipped
with glow plugs. Do not
use ether or any high
energy fuels to assist
starting.
IMPORTANT
5678
910 11 12 13
14 15 16 17 18
19 24
1
2
3
20 21 22 23
25

9
17. Air Cleaner Indicator Light: This light will
illuminate when there is an obstruction in the intake or
when the air filter needs servicing. If this light illuminates,
stop the engine and service the cleaner (see section 4.9).
18. Pre-heat Indicator Light: This light will illuminate
when the ignition key is turned counter clockwise to
activate the engine glow plugs.
19. Dipped Beam Light Switch: This switch is a toggle
switch. Push up to turn the dipped beam lights on. These
lights are located on the front of the loader (not available
on all models).
20. Rotary Beacon Light Switch: This switch is a toggle
switch. Push up to turn the optional rotary beacon light on
(not available on all models).
21. Hazard Light Switch: This switch is a toggle switch.
Push up to turn the optional hazard light on (not available
on all models).
22. Work Light Switch: This switch is a toggle switch.
Push up to turn the optional work light on (not available
on all models). The light is located on the back of the
loader.
23. Auxiliary Hydraulics Front Switch: This switch is
a toggle switch. Push up to provide a continuous flow of
hydraulic oil to the quick couplers when using an
attachment (not available on all models).
24. Lift Arm Supports: For safety while performing
service or maintenance, the loader is equipped with a lift
arm support device. Refer to section 2.6 for details.
25. Hi-Flow Hydraulic Switch: This switch is a toggle
switch. Push up to turn the hi-flow hydraulics on (not
available on all models).
2.2 CONTROL LEVER HANDLES
1. Two Speed Switch (not available on all models):
This switch provides alternate switching. Press to activate
Hi-Speed function. Pressing and releasing the switch a
second time will return the loader to the Low-Speed
function. (Fig. 2.2A)
2. Horn Switch (not available on all models): This
switch is a momentary switch. Pressing and holding the
switch will activate the horn. Releasing the switch
deactivates the horn. (Fig. 2.2A)
3 & 4. Electric Solenoid Auxilliary Switch: This
switch is a momentary switch. Pressing and holding the
switch in position 3 provides hydraulic flow to the female
quick coupling. Pressing and holding the switch in position
4 provides hydraulic flow to the male quick coupling.
Releasing the switch returns it to neutral, stopping the
hydraulic flow. (Fig. 2.2A)
5. LH Directional Signal Switch (not available on
all models): This switch is a momentary switch. Pressing
and holding this switch will activate the LH turn signal.
Releasing the switch deactivates the LH turn signal. (Fig.
2.2B)
6. RH Directional Signal Switch (not available on
all models): This switch is a momentary switch. Pressing
and holding the switch will activate the RH turn signal.
(Fig. 2.2B)
7 & 8. Hi-Flow Hydraulic Switch (not available on all
models): This switch is a momentary switch. Pressing and
holding the switch in position 7 activates the hi-flow
hydraulics to the male quick coupling. Pressing and
holding the switch in position 8 activates the hi-flow
hydraulics to the female quick coupling. Releasing the
switch returns it to neutral and stops the hi-flowhydraulic
flow. (Fig. 2.2B)
Fully retract lift arm
support pins before
raising or lowering lift
arms.
IMPORTANT
2. CONTROLS
LH Control Handle RH Control Handle
1
3
2
4
5
6
8
7
C3015 Fig. 2.2A C3933 Fig. 2.2B

2. CONTROLS
2.3 SEAT AND SEAT BELT
The loader is equipped with a deluxe seat. The seat can be
adjusted forward or back for operator comfort. (Fig. 2.2A).
For your safety the loader is equipped with a seat belt.
Before starting the loader adjust and fasten the seat belt
(Fig. 2.2B) around you. The seat and seat belt also have
integrated safety lock switches whereby the operator must
be seated in the seat with the seat belt securely fastened
and seat bar lowered before the loader hydraulics can be
operated.
To prevent personal
injury do not start the
engine unless you are in
the seat with the seat belt
fastened around you.
WARNING
Fig. 2.2B
C2698
Fig. 2. 2A
C2699
Release
10

11
2. 4 SEAT BAR
For operator protection the loader is equipped with a seat
bar.
The loader must be started with the operator seated in the
loader and the seat bar in the up position. To raise the seat
bar, lift up on the bar (Fig. 2.3A). In the up position, the
seat bar activates the parking brake.
When down (Fig. 2.3B), the seat bar releases the park
brake and the hydraulic controls of the lift and tilt circuits.
Before exiting the loader always check the controls by
cycling them to ensure that they are in the neutral position.
2. CONTROLS
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked. Then,
unlatch the seat belt and exit
the loader. Do not enter or
exit with the engine running
unless as specified in this
manual or under specific
service and backhoe
operating procedures.
WARNING
C3775 Fig. 2. 3A
C3776 Fig. 2. 3B
Seat Bar Up
Seat Bar Down

12
2. 5 PARKING BRAKE
The loader is equipped with park brakes, located inside the
torque motor. The brakes are activated and de-activated
by the seat bar, via charge pressure. When the seat bar is
in the up position, the brake is activated (Fig. 2.4A). When
the seat bar is in the down position, the brake is off (Fig.
2.4B).
The loader has a parking brake indication light to warn that
the brake is engaged.
2. 6 THROTTLE CONTROL
The diesel engine throttle control is the lever located on
the left hand side of the loader next to the steering control
lever (Fig. 2.5). Engine start and stop are controlled
electrically by the ignition key.
Before shutting off the engine, return the throttle control to
idle position and allow the engine to cool at least 2
minutes.
Pushing the lever all the way forward increases the
engine speed to maximum high idle. Pulling the lever
back decreases the engine RPM.
The engine should always be operated at full speed and
the loader travel speed controlled with the steering
control levers (See Section 2.7).
2. 7 LIFT ARM SUPPORTS
For safety while performing regular service or
maintenance work the loader is equipped with lift arm
supports.
The lift arm supports, when extended, prevent the lift arms
from dropping if hydraulic pressure is relieved or the foot
control pedals are accidentally cycled.
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked.
Then, unlatch the seat belt
and exit the loader. Do not
enter or exit with the engine
running unless as specified
in this manual or under
specific service and backhoe
operating procedures.
WARNING
C870 Fig. 2.5
2. CONTROLS
C3775 Fig. 2.4A
C3776 Fig. 2.4B
Seat bar UP
(Parking Brake On)
Seat bar DOWN
(Parking Brake Off)

13
To operate the lift arm supports, first remove any bucket or
attachment from the quick - tach; raise the lift arms to full
height and shut OFF the engine. Push the two lift arm
support pin handles located directly in front of the operator
at the top of the operator compartment (Fig. 2.6A) outward
extending the lift arm locking pins (Fig. 2.6B). Slowly
lower the lift arms down onto the pins. To retract the
support pins, first lift the lift arms off of the pins before
retracting.
2. 8 STEERING CONTROLS
The two steering levers control speed, direction and
turning of the loader. The R.H. lever controls the wheels
on the R.H. side of the loader and the L.H. lever the L.H.
wheels. Loader speed is controlled by the amount each
lever is moved from centre or neutral position. (Fig. 2.7A)
The further away from neutral the faster the travel speed.
For maximum power and slow travel speed move the
control levers only a small amount.
To drive the loader forward in a straight line, move both
control levers forward the same amount (Fig. 2.7B).
To drive the loader in reverse in a straight line, move both
control levers back the same amount (Fig. 2.7B).
The loader is turned by moving one lever further forward
than the other. To turn right, move the left lever further
than the right lever. To turn left, move the right lever
further than the left lever (Fig. 2.7B).
For the loader to turn or “skid-steer” within its own length,
one lever is moved forward and the other back. This causes
the wheels on one side to turn forward and the wheels on
the other side to reverse turning the loader (Fig. 2.7B).
Fully retract the lift arm
supports before raising
or lowering lift arms.
IMPORTANT
2. CONTROLS
C - 694 Fig. 2. 6B
C3135 Fig. 2. 6A
C3938 Fig. 2.7A
C - 696 - 9 Fig. 2.7B
FORWARD REVERSE LEFT TURN RIGHT TURN
To avoid personal injury do
not start the engine unless
you are in the seat with the
seat belt fastened around
you, unless as specified in
this manual or under
specific service and backhoe
operating procedures.
WARNING

14
2. CONTROLS
C3793a Fig. 2.8B
C3015 Fig. 2.8A
C4086 Fig. 2.8C
2.9 ELECTRIC SOLENOID
AUXILIARY CONTROLS
Auxiliary hydraulics (solenoid operated - standard)
A switch located on the L.H. steering control lever (Fig. 2.8A)
is used to engage the loader’s auxiliary hydraulic circuit to
power attachments such as post hole augers, sweepers, etc.
Pressing and holding the switch in position 1 (fig. 2.8A)
provides hydraulic flow to the female quick connect coupling
located at the front of the lift arms (fig. 2.9C). Releasing the
switch returns the auxiliary hydraulic circuit to neutral,
stopping the hydraulic flow.
Pressing and holding the switch in position 2 (fig. 2.8A)
provides hydraulic flow to the male quick connect coupling
located at the front of the lift arms (fig. 2.8C). releasing the
switch returns the auxiliary hydraulic circuit to neutral,
stopping hydraulic flow.
For continuous flow to the auxiliary hydraulic circuit, a toggle
switch is located on the L.H. instrument panel (fig. 2.8B).
Placing the switch in the “ON” position provides continuous
hydraulic flow to the female quick connect coupling located
at the front of the lift arms (fig. 2.8C). To stop hydraulic flow
to the auxiliary hydraulic circuit, return the switch to the
“OFF” position (fig. 2.8B). When the switch on the
instrument panel is in the “ON” position, the switch located in
the L.H. control lever is not operable.
NOTE: See Section 2.2 for information on the control
handles.
AUXILIARY HYDRAULIC CONTROL
1
2
NEUTRAL
ROPS SIDE SEAT SIDE
TOGGLE
SWITCH
T avoid persinal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the controls to
ensure they are locked.
Then, unlatch the seat belt
and exit the loader. Do not
enter or exit with the engine
running unless as specified
in this manual or under
specific service and backhoe
operating procedures.
WARNING
Male Quick Coupling
Female Quick Coupling

15
2.10 FOOT CONTROLS
Operation of the lift cylinders and the bucket tilt cylinders
are controlled by the foot pedals (fig. 2.10) connected to a
hydraulic control valve. The hydraulic control valve is a
series type valve which allows simultaneoous use of both
the lift and bucket tilt circuits.
Lift – The L.H. pedal is the lift control (Fig. 2.10). To raise
the lift arms press on the heel (2) of the pedal. To lower the lift
arms press on the toe (1) of the pedal. Firm pressure on the toe
(1) of the pedal will lock the lift arms in float position. This
allows the bucket to follow the ground as the loader moves
backward.
Bucket Tilt – The R.H. pedal is the bucket tilt (dump)
control. Pressing on the toe (3) of the pedal will dump the
bucket. Pressing on the heel (4) of the pedal will roll the bucket
back.
2. 11 HAND CONTROLS
Hand controls to operate the loader’s lift arm and bucket
hydraulic system as well as the loader’s travel speed and
direction are available. Refer to previous section for
instructions on steering controls.
LIFT ARM AND BUCKET CONTROLS
The right hand lever controls the bucket tilt cylinders
(2.11). Moving the control lever to the right causes the
bucket to dump. Moving the lever to the left rolls the
bucket to the carry position.
Moving the left hand control lever (Fig. 2.11) to the left
will cause the lift cylinders to extend, raising the loader’s
lift arms. Moving the control lever to the right causes the
lift cylinder to retract, lowering the lift arms. Moving the
control lever to the extreme right will place the lift arms in
the float position. This allows the bucket to follow the
contour of the ground as the loader moves backward.
When the control levers are released they will
automatically return to the neutral position, stopping all
hydraulic movement and travel speed. Before exiting the
loader, lower the lift arms completely down to the frame
and ground the attachment. Then shut off the engine. Move
both levers to the left and right to ensure the hydraulic
controls are locked before you get out of the loader.
2. CONTROLS
To prevent personal
injury do not operate the
loader without lowering
the safety bar, fastening
the seat belt and keeping
feet on the control pedals
or the cab floor.
WARNING
To avoid personal injury,
lower the lift arms, shut
off the engine, raise the
seat bar and cycle the
hydraulics to ensure they
are locked. Then unlatch
the seat belt and exit the
loader. Do not enter or
exit with the engine
running unless as
specified in this manual
or under specific service
and backhoe operating
procedures.
WARNING
C - 669 Fig. 2.10
Return the auxiliary
hydraulic control to the
neutral position when not
in use.
IMPORTANT
Fig. 2.10
C3020

16
2.12 QUICK - TACH
The quick - tach, which is standard equipment, allows
changing from one attachment to another quickly without
having to remove bolt or pins.
To operate, (Fig. 2.11A), lift the locking lever (1) up to
completely retract the locking pins (2). Tilt the quick - tach
frame forward (Fig. 2.11B) with the bucket tilt cylinders and
drive into the attachment. Retract the bucket tilt cylinders
(Fig. 2.11C) which will line up the bottom of the attachment
with the quick - tach lock pins. Shut off the engine.
Push the locking lever (1) fully down (Fig. 2.11D) extending
the lock pins (Fig. 2.11E item 2) through the attachment and
securing the attachment.
Before operating the attachment check that the locking pins
are correctly engaged.
After hooking up the
attachment check to be
sure pins and locking
levers are correctly
engaged.
WARNING
C3967 C3964 Fig. 2.11B
Fig. 2.11A
C 3966 C 3968 Fig. 2.11E
1
1
2
Fig. 2.11D
1
2
1
C3965 Fig. 2.11C
1
1
1
1
2
1
2. CONTROLS

17
2.13 ELECTRICAL PANEL
The loader is equipped with a 12 volt, negative ground
electrical system. The fuse and relay panel are located in
the engine compartment on the engine cover. The panel
consists of the following:
1. Engine Pre-Heater Relay.
2. Starter Relay.
3. Fuse Panel.
FUSE PANEL (3)
4. Electric Fuel Solenoid Shutoff (15A)
5. Alternator Light (10A)
6. Electric Auxiliary (10A)
7. Spare
8. Spare
9. Valve Locks (10A)
10. Horn (Optional) (10A)
11. Spare
2. CONTROLS
Fig 2.12
C672
STARTER RELAY
PRE-HEATER RELAY
12
4
5
6
7
8
9
10
11
3

18
3. OPERATION
3. 1 Starting Instructions
1. Pre-Starting Inspection
2. Starting Procedure
3. Shut-Off Procedure
3. 2 Operating Procedures
3. 3 Filling From a Pile
3. 4 Digging With a Bucket
3. 5 Leveling and Backfilling
3. 6 Auxiliary Hydraulics
3. 7 Lifting
3. 8 Towing
3. 9 Securing and Transporting
3. 10 Lowering Lift Arms
3.11 Accumulator
3. OPERATION

19
3.1 STARTING INSTRUCTIONS
1. Pre-Starting Inspection
Before starting the loader complete the following
inspection:
(1) Check the hydraulic oil level, engine oil level, engine
coolant level and fuel supply.
(2) Check for fuel, oil and hydraulic leaks.
(3) Check lights, battery level and cables.
(4) Check tire pressure:
10.00 x 16.5 . . . . 40 - 45 PSI (276 - 310 kPa)
(5) Check wheel nut torque 100 - 110 ft. lbs. (136- 149
Nm).
(6) Lubricate all grease fittings.
(7) Check the condition and operation of all safety decals
and equipment – Ensure all shields and safety screens
are in place. If necessary repair or replace before
starting.
For complete daily servicing refer to section 4. 3.
2. Starting Procedure – Diesel
1. Ensure the seat bar is in the UP position and the
steering controls are centered and the foot pedals
locked.
2. Adjust and fasten the seat belt securely around you.
3. Place the throttle control in idle position.
4. Turn the ignition key counter clockwise to activate the
glow plugs. Hold approximately 15 seconds. Both the
alternator and engine oil pressure warning lights
should be on.
5. Turn the key clockwise to start position to engage the
starter. Do not crank the starter for more than 15
seconds. If the engine fails to start turn the key counter
clockwise and pre-heat again.
6. When the engine has started the engine oil pressure
and alternator warning lights should go out. If they
don’t, shut - off the engine immediately and determine
cause.
7. Allow the engine to warm up for five minutes before
operating. When ready to operate, lower the seat bar
and advance the throttle to full on position.
3. Shut-Off Procedure
(1) Park the loader on level ground. If it’s necessary to
park on a slope, position the machine at right angles to
the slope.
(2) Lower the lift arms and ground the attachment.
(3) Return the throttle control to idle position. If the
engine is hot allow it to idle until normal. At least 2
minutes.
(4) When the engine is cool, turn the ignition key to the
OFF position and remove the key.
(5) Never enter or exit the loader when the engine is
running.
(6) Raise the seat bar to apply the park brake. Turn the
ignition switch to the OFF position, unfasten the seat
belt, and ensure the hydraulic controls are locked by
rocking them.
This engine is equipped
with glow plugs. Do not
use ether or any high
energy fuels to assist
starting.
IMPORTANT
3. OPERATION
To avoid personal injury
do not start the engine
unless you are in the seat
with the seat belt
fastened around you,
unless as specified in this
manual or under specific
service and backhoe
operating procedures.
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulic
controls to ensure they are
locked. Then, unlatch the seat
belt and exit the loader. Do
not enter or exit with the
engine running unless as
specified in this manual or
under specific service and
backhoe operating
procedures.
WARNING
WARNING
To prevent personal
injury do not operate the
loader without lowering
the safety bar, fastening
the seat belt and keeping
feet on the control pedals
or cab floor.
WARNING

20
3. 2 OPERATING PROCEDURES
1. When learning to use the loader operate at a slow rate.
2. Take advantage of the efficient operation of the loader.
Keep the travel distance as short as possible. Keep the
work area small so the cycle time is short.
3. Keep the work area as level as possible.
4. Decrease cycle time by “skid” turning (See Section
2.7) rather than a go backward-go forward turn.
5. Fill the bucket to rated capacity. Turning is easier with
a full load than with a partial load. Keep the loaded
bucket close to the ground when transporting.
6. Tilt the bucket as you raise the lift arms or drive up a
slope. This will prevent material from falling off the
back of the bucket.
7. Do not drive across a slope. Always go up or down a
slope with the heavy end of the loader pointing up
towards the top of the slope.
3. 3 FILLING FROM A PILE
Push down on the toe of the lift arm pedal and lower the lift
arms completely down (Fig. 3.3A). Push the toe of the bucket
pedal and place the cutting edge of the bucket on the ground.
For hand control units, move the L.H. control lever towards
you and lower the lift arms completely down. Move the R.H.
control lever away from you (Fig. 3.3A) and place the cutting
edge of the bucket on the ground.
Drive the loader forward slowly. As the bucket begins to fill
push on the heel of the bucket pedal to raise the front of the
bucket (Fig. 3.3B) and push on the heel of the lift arm pedal
to raise the lift arms. When the bucket is full back away from
the pile. For hand control units, move the R.H. control lever
towards you to raise the front of the bucket, and move the
L.H. control lever away from you to raise the lift arms (Fig.
3.3B). When the bucket is full back away from the pile.
To dump the bucket (Fig. 3.3C) push down on the heel of the
lift arm pedal to raise the lift arms. Push down on the toe of
the bucket pedal small amounts as the lift arms are raising to
stop material from falling off the back of the bucket. When
the bucket is at the correct height for dumping, push on the toe
of the bucket pedal to empty the bucket.
For hand control units, move the L.H. control lever away
from you (Fig. 3.3C) to raise the lift arms. Move the R.H.
control lever away from you in small amounts as the lift arms
are raising to stop material from falling from the back of the
bucket. When the bucket is at the correct height for dumping,
move the R.H. lever away from you to empty the bucket.
* Hand controls not available on all machines.
Always let the engine
warm completely before
you begin operation each
day.
IMPORTANT
3. OPERATION
Fig. 3.3A
Fig. 3.3B
C706
Fig. 3.3C
C709
C707
LH
R H
LH
RH
C710
LH
RH
*
*
*
