Thor Motor Coach Class A Gas User manual

Class A and C Motorhomes
Appliance and
Entertainment Guide
thormotorcoach.com

A
About This Guide
Thank you for choosing Thor Motor Coach (TMC). This Appliances and Entertainment System Guide is
intended to help you understand and operate these convenient devices of your new motorhome. It includes
information provided by your selling dealer during your new motorhome pre-delivery inspection (PDI), and
much more.
This guide is not intended for use as a service manual, nor is it model specific. Although some information is
specific to certain brands and models, it is of a general nature, and the illustrations and descriptions provided
may differ from the components installed in your motorhome.
Thor Motor Coach’s Continuing Commitment
Thor Motor Coach’s continuing commitment is to provide quality products and systems for it’s motorhome
customers. Appliance and entertainment devices, features, and options will constantly change as new and
improved devices become available.
Contact Us
You are extremely important to us, and you can be assured Thor Motor Coach and your selling dealer will
always strive to do everything possible to earn your trust and goodwill. Your selling dealer should be your first
source for information regarding any questions or concerns you may have about your motorhome.
You can also contact TMC Customer Care anytime you have a question about your motorhome or the
operation of any factory-installed appliance, equipment, or component.
By telephone, TMC Customer Care representatives are available Monday through Friday, 8:00 am to 5:00 pm
EST. If you call off-hours, leave a detailed message and a representative will contact you ASAP.
Contact to a TMC Customer Care representative is also available via direct email or email through the Thor
Motor Coach website. You can also send or fax written requests to the address and number listed below:
Thor Motor Coach (TMC) reserves the right to make changes in vehicles built and/or sold at any time without incurring any
obligations to make the same or similar changes on vehicles previously built and/or sold by TMC. Information in this systems guide is
subject to change without notice and represents information relevant at the time of publication. Nothing in this systems guide creates
any warranty, either expressed or implied. The only warranties offered by Thor Motor Coach are those set forth in the Thor Motor
Coach Limited Warranty and in the Thor Motor Coach Structural Limited Warranty, as applicable to the motorhome. Appliance
manufacturers may offer limited warranties on products installed in your Thor motorhome, subject to product registration. Product
registration is the responsibility of the motorhome owner.
Copyright Thor Motor Coach, Inc. © 02/2020
Thor Motor Coach
Attn: Customer Care
PO Box 1486
Elkhart IN 46515-1486
Phone: [phone] (24/7 assistance)
Fax: [phone]
Email: [e-mail]
Website: www.thormotorcoach.com

B
Appliance and Entertainment Component Suppliers:
Antennas
Over-the-Air Winegard Company: www.winegard.com
King Controls: www.kingconnect.com
Satellite, TV Winegard Company: www.winegard.com
Satellite, Radio River Park Inc: www.riverparkinc.com
WiFi Winegard Company: www.winegard.com
COAX Distribution Furrion: www.furrion.com
Cooktop
Atwood Atwood Mobile Products: www.askforatwood.com
Tru Induction Dehco/Cast Products: www.dehco.com
Dometic Dometic Corporation: www.dometic.com/en-us/us/
High Pointe Collins and Company: www.collins-n-co.com
Dishwasher Westland Sales: www.westlandsales.com
DVD/Blu-Ray Player RiverPark Inc: www.riverparkinc.com
ASA Electronics: www.asaelectronics.com
HDMI Distribution RiverPark Inc: www.riverparkinc.com
Microwave
Greystone Way Interglobal Network: www.wayinterglobal.com
High Pointe Collins and Company: www.collins-n-co.com
Whirlpool Whirlpool: www.whirlpool.com
Oven Atwood Mobile Products: www.askforatwood.com
Radio, Dash
Axxera MITO Corporation: www.mito-oem.com
Sony RiverPark Inc: www.riverparkinc.com
Radio, Wall Mount ASA Electronics: www.asaelectronics.com
Refrigerator
Dometic Dometic Corporation: www.dometic.com/en-us/us/
Norcold King Controls: www.kingconnect.com

C
Pummell Drive Mid-West Sales: www.midwestsales.org
Whirlpool Whirlpool: www.whirlpool.com
Soundbar
Connexx RiverPark Inc: www.riverparkinc.com
JBL RiverPark Inc: www.riverparkinc.com
ProScan MITO Corporation: www.mito-oem.com
Seiki MITO Corporation: www.mito-oem.com
Vizio MITO Corporation: www.mito-oem.com
Yamaha Quest Audio Video: www.questav.com
Televisions
Axxera MITO Corporation: www.mito-oem.com
GPX Mid-West Sales: www.midwestsales.org
Jensen ASA Electronics: www.asaelectronics.com
LG Quest Audio Video: www.questav.com
Sansui RiverPark Inc: www.riverparkinc.com
Seiki MITO Corporation: www.mito-oem.com
Sony RiverPark Inc: www.riverparkinc.com
Washer/Dryer Whirlpool: www.whirlpool.com
WiFi Extenders
Winegard Winegard Company: www.winegard.com
WiFi Ranger WiFi Ranger: www.wifiranger.com
Other Resources:
Thor Motor Coach Customer Care: 877-855-2867
Thor Motor Coach Customer Resources Web Site:
https://thormotorcoach.com/motorhome-owners-resources/
Thor Motor Coach YouTube Site: https://www.youtube.com/user/ThorMotorCoach

D
This page intentionally left blank

E
Table of Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Labels, Alerts, and Symbols . . . . . . . . . . 1
Requirements for Safe Energy Use . . . . . . . . . . 2
Propane Requirements . . . . . . . . . . . . . . . . . . . . 2
Propane Safety . . . . . . . . . . . . . . . . . . . . . . . . 2
Electrical Requirements . . . . . . . . . . . . . . . . . . . 3
Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . 4
Kitchen and Appliances . . . . . . . . . . . . . . . . . . . . 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Kitchen Made to Travel . . . . . . . . . . . . . . . . . . . . 5
Cabinets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Countertops . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Kitchen Sink and Faucet . . . . . . . . . . . . . . . . . . . 7
Exterior Kitchen Unit (optional) . . . . . . . . . . . . . . 7
Cooktops and Ovens . . . . . . . . . . . . . . . . . . . . . 8
Propane Gas Use . . . . . . . . . . . . . . . . . . . . . . 8
Gas Range and Oven Combination . . . . . . . . . 10
Gas Cooktops . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Induction Cooktops . . . . . . . . . . . . . . . . . . . . . 12
Microwave Oven . . . . . . . . . . . . . . . . . . . . . . . . 15
Microwave/Convection Oven . . . . . . . . . . . . 16
Kitchen Refrigerator . . . . . . . . . . . . . . . . . . . . . 18
Residential Refrigerator Operation . . . . . . . . 18
Gas/Electric Refrigerator Operation . . . . . . 19
Effects of High Altitude on Propane Gas
Operation . . . . . . . . . . . . . . . . . . . . . . . . . 23
Effects of Freezing Temperatures on
Refrigerator Operation . . . . . . . . . . . . . . . . . . 23
Care and Maintenance . . . . . . . . . . . . . . . . 23
Outside Kitchen Refrigerator (optional) . . . . . . 24
3-Way Kitchen Refrigerator (if equipped) . . . . 24
Optional Appliances . . . . . . . . . . . . . . . . . . . . . 25
Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Clothes Washers and Dryers . . . . . . . . . . . . . . 25
Entertainment Devices . . . . . . . . . . . . . . . . . . . 26
Televisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
A/V Switchboxes . . . . . . . . . . . . . . . . . . . . . . . . 27
Cable TV Hook-up . . . . . . . . . . . . . . . . . . . . . . 28
Home Theatre System (optional) . . . . . . . . . . . 28
Satellite TV Hook-up . . . . . . . . . . . . . . . . . . . . 29
DVD/Blu-Ray Player . . . . . . . . . . . . . . . . . . . . 30
Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Dash Radio . . . . . . . . . . . . . . . . . . . . . . . . . . 30
House Radios . . . . . . . . . . . . . . . . . . . . . . . . 31
WIFI Extenders (optional) . . . . . . . . . . . . . . . . 32
Winegard ConnecT 2.0+ . . . . . . . . . . . . . . . . 32
WiFi Ranger Sky 3 . . . . . . . . . . . . . . . . . . . . 33
Other Entertainment Devices . . . . . . . . . . . . . . 35

F
This page intentionally left blank

1
THOR MOTOR COACH | MADE TO FIT
SAFETY
Safety
Safety Labels, Alerts, and Symbols
Safety labels and decals are placed throughout the motorhome in locations where the potential for a
hazardous condition is present. Make sure that you and your traveling companions understand and follow all
safety instructions. Never remove safety labels and decals. If a safety label should become damaged, illegible,
or removed, it should be replaced as soon as possible. Contact Thor Motor Coach Customer Care for a
replacement.
Thor Motor Coach uses the following signal words to warn you of possible safety concerns and to provide
information to help prevent personal injury and/or damage to the motorhome:
NOTE: Provides helpful information on the topic being covered in the section.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death. This
symbol may be used in conjunction with the following signal words and with a color that
corresponds with the associated safety label.
Danger indicates an imminently hazardous situation that, if not avoided, will result in death or serious
injury. This alert information is limited to the most extreme situations.
Warning indicates a potentially hazardous situation that, if not avoided, may result in death or
serious injury.
Caution indicates a potentially hazardous situation that, if not avoided, may result in minor or
moderate injury. It may also be used to alert against unsafe practices.
A Notice indicates a potential situation that, if not avoided, may result in property damage or
damage to your motorhome.
WARNINGWARNING
DANGERDANGER
CAUTIONCAUTION
NOTICENOTICE

2CUSTOMER CARE | 877.855.2867
SAFETY
Requirements for Safe Energy Use
Since the appliances and entertainment devices installed in your motorhome require portions of the propane
and electrical system for proper operation, follow all safety-related messages concerning safe propane and
electrical system use.
Propane Requirements
In order to function properly, gas appliances will require a safe and reliable source of propane gas (LP). Your
motorhome is furnished with a propane system that is designed to deliver an ample supply of propane for the
water heater, furnace, and all factory-installed gas-fired appliances.
Propane gas pressures are factory set to 11 inches of water column. Do not adjust or bypass the gas regulator
or modify any component of the propane system. If you experience problems with your gas appliances or
any propane system component, promptly have a qualified propane service technician inspect the propane
system make all necessary repairs.
Propane Safety
Familiarize yourself and follow all propane gas safety procedures listed within this document, the TMC
Propane Gas System Guide, your Owner’s Manual, and the documentation associated with all gas and
electrical appliances of your motorhome.
IF YOU SMELL PROPANE GAS
1. Extinguish any open ames and all smoking materials.
2. Shut off the propane supply at the container valve(s) or propane supply connection.
3. Do not touch electrical switches.
4. Open doors and other ventilating openings.
5. Leave the area until the odor clears.
6. Have the propane system checked and leakage source corrected before using again.
Ignition of ammable vapors could lead to a re or explosion and result in death or serious injury.
DANGERDANGER
Turn OFF all pilot lights, appliances, and their igniters (see operating instructions) while the
motorhome is traveling or in motion, and before refueling the motorhome’s fuel tanks and/or
propane containers.
Can cause ignition of ammable vapors, which can lead to a re or explosion and result in death or
serious injury.
DANGERDANGER

3
THOR MOTOR COACH | MADE TO FIT
NOTE: For information regarding the safe operation of the propane system and its components, refer to the
Propane System Guide, available in the Owner’s Resource section of the TMC website:
www.thormotorcoach.com
NOTE: For information regarding the safe operation of the electrical system and its components, refer to the TMC
Electrical System Guide, available in the Owner’s Resource section of the TMC website:
www.thormotorcoach.com
SAFETY
Electrical Requirements
Most, if not all of the devices described in this guide require electricity for proper operation. Control circuits
and igniters of gas appliances require 12 volts DC, while entertainment components generally require 120
volts AC. For safe and reliable operation, your motorhome must be able to supply electrical energy to your
appliances and entertainment devices.
For 12 volt DC power, the main battery switch must be ON. Operating the generator or being connected to a
shore power source will supply 120 volts AC as needed.
Make sure the propane/carbon monoxide (LP/CO) detector and alarm is always kept in good
working order. Test this device regularly and immediately replace if it is not functioning properly.
The LP/CO detector operates on house 12 volts DC and is only operational when the main battery
switch is ON.
CAUTIONCAUTION
NOTICENOTICE
The electrical system of the motorhome must be in good working condition; being able to supply
both 12 volts DC and 120 volts AC, in order to operate the appliances and entertainment devices
installed in your motorhome.
NOTICENOTICE
It is possible to overload the electrical system if too many electrical appliances and entertainment
devices are operating at the same time, particularly if the electrical power is being supplied only by
the generator. Be familiar with the power demand (in watts) of the devices being operated and do
not exceed the power capacity (in watts) of the generator.

4CUSTOMER CARE | 877.855.2867
SAFETY
Electrical Safety
Familiarize yourself and follow all electrical system safety procedures listed within this document, the TMC
Electrical System Guide, your Owner’s Manual, and the documentation associated with all gas and electrical
appliances of your motorhome.
Use extreme caution when using metal tools near electrical system terminals, connections, and
components. Short circuits can occur when metal tools bridge between electrical terminals of
opposite polarity, causing sparks, possible equipment damage, potential of re, explosion, bodily
injury and/or electrocution.
DANGERDANGER
Safety precautions must always be observed when using any electrical device or working with
electrical wires and connections. Careless handling of electrical components can be fatal.
• Never touch or use electrical components or appliances while feet are bare, while hands are
wet, or while standing in water or on wet ground.
• Always remove jewelry and wear protective clothing and eye covering.
• Avoid creating sparks, which could ignite nearby ammable materials.
CAUTIONCAUTION
Whenever electrical system maintenance is required and before working on the electrical system of
the motorhome:
• Turn OFF the main battery switch
• Disconnect the shore line power cord
• Turn OFF the generator
• Disable the automatic generator start functionality
• Disconnect the negative 12 VDC auxiliary (house) battery terminal(s)
• Attach an electrical lockout device to the electrical service panel
Before disconnecting your house and/or chassis batteries, always make sure the main battery
switch is turned OFF, and the inverter/charger (if so equipped) is turned OFF.
WARNINGWARNING

5
THOR MOTOR COACH | MADE TO FIT
Kitchen and Appliances
Introduction
One of the first things you will notice when stepping into a roomy Thor
Motor Coach motorhome is its excellent appointments of appliances
and entertainment systems. Being able to take all the conveniences
of home with you while experiencing unique places and events is
what makes motorhome travel so compelling, enjoyable, and relaxing.
Whether you enjoy your morning coffee brewed over an open campfire,
prepared with your favorite electric coffee maker, or warmed with a
microwave oven, your TMC motorhome is well equipped for the task
and ‘Made to Fit’ your traveling lifestyle.
Within this guide is important safety and operational information that will
allow you to maximize the features and conveniences of the devices that
truly make your TMC motorhome, your ‘home on wheels.’
Kitchen Made to Travel
As in your own home, the kitchen of your TMC motorhome is often
the central location for many family activities. The appliances of your
motorhome have been carefully selected to provide you with maximized
food preparation conveniences, while ‘right-sizing’ the appliances to
proportionally fit the floorplan of your particular motorhome. Several
TMC floorplans take kitchen conveniences a step further by providing
an additional outdoor food preparation area, which enhances out-of-
doors family and other activities.
Your Thor motorhome is well appointed
with modern, convenient appliances
KITCHEN AND APPLIANCES
Do not store combustible materials in this area (kitchen and
cabinets). Failure to comply could result in re or personal
injury.
DANGERDANGER
Be cautious when opening cabinets after travel. Contents may
have shifted and could inadvertently fall out.
CAUTIONCAUTION
Cabinets
Not only is your mobile kitchen well appointed with appliances, it is
well equipped with generous cabinet storage for food, cooking utensils,
cleaning supplies, and portable appliances. Some cabinets feature
pull-out storage trays and shelf dividers. All have door catches that stay
TMC motorhomes feature home-like
kitchen appointments

6CUSTOMER CARE | 877.855.2867
closed while you’re underway. As a safety precaution, cabinet contents
can shift during travel. Please ensure that all cabinet doors are closed
and latched before traveling to prevent the contents from falling out,
causing possible injury or damage.
Drawers are designed to ensure that they do not open inadvertently
during travel. To open the drawers, pull out until catch releases. Some
cabinets have a wire-frame or wooden pull-out pantry. To extend this
pantry, remove the travel lock pin at the bottom track and pull the pantry
rack outward. To prepare for travel, push the pantry rack in and reinsert
the travel lock pin.
NOTICENOTICE
To clean the countertops of your motorhome:
A simple wipe with soapy water or disinfectant spray is usually
all that is needed to keep the surface clean and looking new.
Although the materials are durable, they can be damaged with
sharp and/or hot objects. Use cutting boards for slicing and
dicing and protective heat pads for hot pots and pans.
Countertops
Your mobile kitchen is designed with countertops that provide durable
food preparation surfaces. Countertops are made of laminate or solid-
surface materials similar to those found in your home. Both surface
types provide easy-care and low maintenance. Some kitchen floorplans
are supplied with additional folding countertops, which further increases
food preparation surface area, while conveniently stowing away when
not needed.
RANGE AND SINK COVERS
Thor motorhomes are well appointed
with spacious and durable countertops
KITCHEN AND APPLIANCES
Flip-up range covers provide additional
countertop space
Slide-out pantry rack
For your food preparation convenience, the kitchen sink may be
equipped with a solid cover, made of the same material as the
countertop. Additionally, several range models are supplied with a range
cover that provides additional counter space when needed.
When opened, the range cover acts as a grease and splash guard. To
raise the range cover, lift and push back until it snaps into place. To
return the cover to its counter flush position, lift straight up to disengage
the holding mechanism, and return it to the original position.
NOTE: For secure and safe travel, ensure all kitchen cabinet doors are closed and latched to prevent contents
from falling out during travel.

7
THOR MOTOR COACH | MADE TO FIT
NOTE: If hot water is desired,
the hot water heater must be on
and allowed adequate time to
heat the water. For water system
details, refer the TMC Water
System Guide.
Optional exterior kitchen
NOTE: As with the interior kitchen sink, do not put solid particles down
the drain of the exterior kitchen sink. Solid particles could clog the drain
pipes and the waste water holding tank.
When using the outdoor kitchen and cooking area:
• The vehicle must be level and stabilized.
• Do not violate manufacturers’ instructions on required
clearances for cooking appliances during use.
• Do not store cooking appliances until cool to the touch.
Can lead to a re and explosion and result in death or serious injury.
WARNINGWARNING
Kitchen Sink and Faucet
The stainless steel kitchen sink installed in your motorhome is much like
the one in your home. It may be a single or dual-bowl design and equipped
with a sink cover board which, when in place, increases countertop space.
Only waste water should be disposed of down the kitchen drain. Be sure
to always use the catch basket on the drain. Your motorhome kitchen
sink drain DOES NOT have a garbage disposal unit. Never put grease,
food, or other solids or semi-solids down the drains of your motorhome
because you may clog the drain and/or waste water holding tank.
The faucet and sinks installed in your motorhome operate just like those
in your home. As long as there is water system pressure, provided by
the on-demand pump or city source, hot and cold water is conveniently
available for washing and food preparation.
To operate the faucet, rotate the hot and cold handles for desired water flow
rate. To operate the sprayer, pull out on the head of the faucet. Press the
button on top to release the water. To reinsert the hose, gently guide it back
to the original position.
Exterior Kitchen Unit (optional)
Residential-quality kitchen fixtures
KITCHEN AND APPLIANCES
NOTICENOTICE
Only waste water should be disposed of down the drain. Always
use the sink drain strainer to capture food and other particles.
Never put grease, food, or other liquid or solid materials down
the drain because you may plug the drain pipes and holding
tank. Your motorhome’s kitchen sink is not equipped from the
factory with a garbage disposal.

8CUSTOMER CARE | 877.855.2867
Cooktops and Ovens
GENERAL SAFETY INSTRUCTIONS FOR PROPANE AND GAS-BURNER APPLIANCES
Propane Gas Use
Most RV cooktops, ranges, and refrigerators use propane (LP) gas or a combination of gas/electric to
operate. Some appliances may have electronic gas ignition, while others may require a pilot light to be lit
before operating.
KITCHEN AND APPLIANCES
When equipped, the exterior kitchen unit provides a convenient outdoor food preparation and clean-up
station. The outside kitchen unit is accessed by an exterior compartment door, usually located at the rear,
curb-side of the motorhome. Compared model-to-model, the kitchen unit may contain different features, but
all will have a sink, with hot and cold running water, a refrigerator, and a GFCI 120 volts alternating current
(AC) receptacle. Also located along the right-side rear, some motorhome models provide a convenient liquid
petroleum (LP) gas connection for a portable grill or other gas appliance.
Use caution whenever a LP gas appliance is connected and in-use. Inspect the gas supply hose for any
cracks or damage. Do not use if damaged in any way. Inspect the burners, they could have shifted out-of-
place during transport. Keep the appliance well away from the side of the motorhome or other flammable
materials. Always turn OFF the gas supply when appliance is not in use. Instruct children to stay clear of hot
devices and allow adequate time to cool before stowing away any cooking device or appliance.
PROPANE GAS IS HIGHLY VOLATILE AND EXTREMELY EXPLOSIVE. DO NOT USE MATCHES OR A
FLAME TO TEST FOR LEAKS. USE ONLY APPROVED PROPANE GAS LEAK TESTING SOLUTIONS
FOR LEAK DETECTION.
Unapproved solutions can damage copper tubing and brass ttings. Never attempt to adjust
propane gas regulators. Only qualied personnel should perform any maintenance or repair to the
propane gas system.
DANGERDANGER
DO NOT USE GAS APPLIANCES FOR COMFORT HEATING.
CAN LEAD TO CARBON MONOXIDE POISONING, WHICH CAN LEAD TO DEATH OR SERIOUS
INJURY.
DANGERDANGER
PREVENT ANY FLAMMABLE MATERIALS, SUCH AS CLOTHING, PAPER OR CLOTH TOWELS,
CURTAINS OR SHADES, ETC., FROM BECOMING CLOSE TO OPEN FLAME OR HOT SURFACES.
DANGERDANGER

9
THOR MOTOR COACH | MADE TO FIT
All control knobs must be turned to OFF when not in use. Fire and/or burning hazard may occur if
a burner is accidentally left ON.
DO NOT operate range or cooktop if it is damaged or not working properly.
In case of emergency or gas detection, know where the main LP gas shutoff valve is located and
know how to TURN OFF gas supply.
If any burner should extinguish (after initial lighting or due to accidental blow-out), turn all burner
knobs to OFF and WAIT 5 MINUTES before attempting to re-light burner.
DO NOT touch top burners, burner grates, or other areas near top burners during and after use. Do
not let clothing or other flammable materials contact top burners or areas near top burners until
they have had sufficient time to cool.
Be sure that glass cooking utensils are safe for use on the cooktop. Only certain kinds of glass
utensils are suitable for surface or top burner use without breaking due to the sudden changes in
temperature.
Never leave top burners unattended. A boil-over could result and cause smoking and greasy
spillovers that could ignite.
Turn pan handles inward, but not over other top burners. This reduces the chance of burns due to
bumping the pan.
DO NOT leave children alone or unattended in area where range or cooktop is in use. Never allow
anyone to sit, stand, or climb on any part of the range cooktop. They could be burned or injured.
DO NOT heat unopened containers. They could explode. The hot contents may cause burns and
container particles may cause injury.
Replace range cover only after burners and grate have sufficiently cooled.
DO NOT operate burners with control knob set to the LITE position. Damage to the ignition module
and burner electrodes may result.
Top burner flame size should be adjusted so it DOES NOT extend beyond the edge of the cooking
utensil.
WARNINGWARNING
Follow all safety instructions when using LP Gas appliances and the LP Gas system of your
motorhome. The risk of fire and/or explosion and bodily injury exists with improper use of LP gas
or any other flammable substances.
WARNINGWARNING
KITCHEN AND APPLIANCES

10 CUSTOMER CARE | 877.855.2867
Typical 3-Burner LP Gas Range and
Oven
Gas Range and Oven Combination
Similar to the illustration to the right, your motorhome may be equipped
with a two or three-burner range and oven combination. This unit
requires a pilot light to be lit in order to operate the oven. The oven
is designed this way in order to reduce the possibility of unintended
ignition.
TO LIGHT THE OVEN PILOT
• Ensure that the LP gas supply is ON at the LP tank.
• Turn the oven control knob to the PILOT position and push IN.
• Light the pilot with a lighter.
• Hold in the knob for at least 30 seconds until the pilot flame is well
established.
THE PILOT WILL NOT COME ON
• Check to determine if the main gas valve is turned ON.
• Is there LP gas in the tank?
• Check for blockage of the orifice, pilot assembly or pilot line.
• Check for kinks in the pilot gas line.
PILOT WILL NOT STAY ON
• Hold oven knob, in the pilot position, for up to 30 seconds.
• Check gas supply; ensure the main valve is ON and there is LP in the tank.
• Confirm that thermocouple is fully inserted into the thermocouple holder.
• Pilot flame out of position; pilot flame is not engulfing thermocouple. Pilot assembly needs to be adjusted
so that pilot flame is engulfing thermocouple.
NOTICENOTICE
Become familiar with all safety-related warnings and instructions whenever a propane appliance
or device is in use. Routinely, check for gas leaks. If gas is ever detected, either by smell or by an
alarm, know the safety and evacuation procedures.
Any gas leaks have the potential of causing explosion or re, resulting in severe injury or death.
Always have gas leaks repaired immediately by a qualied and certied technician.
Follow all propane-related warning labels afxed throughout your motorhome and included in the
manufacturer’s owner’s manual for each appliance. For further information on the Propane (LP) Gas
System of your motorhome, please refer the Propane Systems Guide, available on the Thor Motor
Coach website.
NOTE: The pilot gas line will
remain open as long as the
pilot is lit and the thermocouple
senses flame. If the pilot goes
out, the magnet will drop out and
shut off gas flow to the pilot.
KITCHEN AND APPLIANCES

11
THOR MOTOR COACH | MADE TO FIT
OVEN OPERATION
• After the pilot is lit, rotate the oven control knob counter-clockwise to the desired temperature setting or
to BROIL. The oven will pre-heat in approximately 15 minutes. For best results, always allow adequate
time for the oven to come to temperature.
• To extinguish the oven burner, rotate the oven control knob clockwise to PILOT/PUSH/HOLD position.
The oven burner will extinguish, but the pilot will remain lit.
USING THE BROILER
• Ensure the pilot is lit.
• Push and rotate the oven control knob to the BROIL position.
• Center the cookpan under the broiler flame. Move and turn food frequently for even browning and
cooking.
• When cooking is complete, rotate the oven control knob clockwise to PILOT/PUSH/HOLD position.
• For complete oven shut-down push in the oven control knob and rotate clockwise to the OFF position.
Pilot should extinguish. For safety, visually check to confirm that the pilot did, in fact, extinguish.
LIGHTING THE TOP BURNERS MANUALLY
1. All burner controls operate counter-clockwise and must be pressed
inward to turn ON or LITE position. Do not attempt to light more
than one burner at a time.
2. Immediately light the burner by holding a lit match or hand-held
spark igniter designed for this purpose, near the burner ports.
3. To extinguish the top burner flame, turn the appropriate burner knob
counterclockwise to OFF.
LIGHTING TOP BURNERS WITH SPARK IGNITERS
1. Turn the appropriate burner knob counterclockwise to ON or LITE.
Do not attempt to light more than one burner at a time.
2. Turn the SPARK knob clockwise one “click.” If the burner fails to
light, continue turning the SPARK knob clockwise until the burner
ignites.
3. To extinguish the top burner flame, turn the appropriate burner knob
clockwise to OFF.
LIGHTING TOP BURNERS WITH ELECTRONIC IGNITION
1. Turn the appropriate burner knob counterclockwise to ON or LITE. This will automatically activate the
ignition system, and all burners will begin to spark repeatedly. This is the “clicking” sound you will hear.
2. The burner will light within five seconds. Once the burner is lit, turn the knob counterclockwise to the
desired setting.
3. To extinguish the top burner flame, turn the appropriate burner knob clockwise to OFF.
4. If 12 volts DC power is not available to the ignition module for any reason, top burners may be lit
manually (see manual lighting instructions above).
KITCHEN AND APPLIANCES
NOTE: Cooktops and ovens
are a source of heat. On hot
days, heat from the range
and/or oven may cause the
cabin temperature to rise to
uncomfortable levels.
Gas burners

12 CUSTOMER CARE | 877.855.2867
Gas Cooktops
The kitchen of your motorhome may be equipped with a 2 or 3-burner
gas cooktop (similar to the illustration here), and instead of a gas oven,
your kitchen may be equipped with either a microwave or a combination
microwave/convection oven (see microwave oven section).
If so equipped, your gas cooktop operates similarly to the gas range
burners described previously. Please note all LP gas-related safety
instructions when using this or any gas appliance.
TO OPERATE THE GAS BURNERS
• Ensure that the LP gas supply valve at the tank is ON.
• Push in the burner control knob and rotate to the LITE position. The
electronic igniter should begin “clicking.”
• After burner ignites, rotate knob to adjust flame to the desired level.
TO TURN OFF GAS BURNER
• Rotate burner knob to the OFF position.
• Before traveling, turn OFF the LP gas supply valve at the tank.
Induction Cooktops
KITCHEN AND APPLIANCES
Typical 2-3 burner gas cooktop
NOTE: For complete operating
instructions and maintenance
details, please refer to the
manufacturer’s owner’s manual,
included with your TMC
Owner’s Packet.
IMPORTANT INDUCTION COOKTOP SAFETY INFORMATION:
• When the unit is on, do not touch outside the control panel, as the surface may contain residual
heat.
• Do not cook on a broken or damaged cooktop as spillovers may penetrate surface and create a
risk of electric shock.
• Allow sufcient space around cooking area when in use.
• Magnetic eld caution: Items that could be affected are Radios, televisions, credit cards,
cassette tapes, etc.
• Do not use with empty pans/pots.
• Do not place metal objects such as knives, forks, spoons, lids, cans or aluminum foil on
cooktop.
• The surface will remain hot for a time after use.
• Do not clean surface while still hot.
CAUTIONCAUTION
