THUNDERPOLE T-800 User manual

T-800
MULTI STANDARD PROGRAMMABLE
27 MHz CB MOBILE TRANSCEIVER
OWNER’S MANUAL

Declaration of Conformity
THUNDERPOLE T-800
With the present declaration, we certify that the following products :
comply with all the technical regulations applicable to the above mentioned products in
accordance with the Radio Equipment Directive 2014/53/EU (RED) and 2011/65/EU (RoHS)
EC Certificate of Conformity
(to EC Directive 2014/53/EU, 2011/65/EU)
DECLARATION OF CONFORMITY
Type of product :
Mr. Alan Crumpton
(General Manager)
CB Transceiver
EN 62311:2008
EN 300 433 V2.1.1
EN 301 489-1 V2.2.0
EN 301 489-13 V1.2.1
EN 60950-1:2006+A11:2009+A1:2010
+A12:2011+A2:2013
THUNDERPOLE
1 Hartburn Close, Crow Lane Ind Est
Northampton, NN3 9UE, England
Tel. [phone]
E-mail : [email protected]
Alan Crumpton
Tel. [phone]
E-mail : [email protected]
Details of applied standards :
Manufacturer / Importer:
Contact Reference :
Northampton, 19/12/2018
NOTICE!
It is recommended to carefully read this owner’s manual before using the product. This will also help the user to
prevent using the radio in violation of the regulations valid in the country where the product is used, as well as to
avoid any possible interference with other services.

Index - Introduction - Contents of the box
Index - Introduction - Contents of the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Controls and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Frequency band selection / table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
NOTICE !
Before using this transceiver, please check it has been programmed on the correct frequency band
and operating mode allowed by the regulations valid in the country where the product is used. If not,
please change the frequency band(see page 6).
NOTE: This transceiver is factory pre-programmed on the UK frequency band (UK 40CH FM 4W).
Congratulations!
Congratulations for selecting and purchasing a quality THUNDERPOLE product.
This transceiver includes a number of advanced functions and systems, therefore it is important to carefully
read this owner’s manual before using the radio. With the correct use of this product in accordance with the
operating method described in this manual, the product will offer trouble free use for many years.
THUNDERPOLE is constantly engaged in developing and providing quality products meeting the customers
requirements, however any suggestions or comments on this product that might help us to improve quality are
warmly welcome.
The THUNDERPOLE T-800 is a CB transceiver using advanced hardware and software design, it includes a
special multi-standard programmable circuit, which allows you to program the frequency band and operating
mode in compliance with the regulations valid in the various European countries. Therefore this product can be
used in any country of the European Community.
The radio is delivered factory pre-programmed on the UK frequency band (UK 40CH FM 4W).
Contents of the box
Please check that all the following items are contained in the box :
• Main unit (transceiver)
• DC power cord with fuse holder and fuse
• Condenser microphone
• Car mounting bracket
• Car mounting bracket accessories (hardware,
knobs, etc.)
• Microphone bracket
• Owner’s manual
- 1 -

Controls and operation
Front Panel
1. Microphone Connector
Connect the microphone to this connector and turn the connector ring to lock it.
2. Up Button
This button allows you to change the operating channel upwards.
3. Down Button
This button allows you to change the operating channel downwards.
4. SQUELCH Control
The SQUELCH control allows you to silence the receiver by cutting out the background noise when no
signals are being received. Turn the knob clockwise until the background noise is cut. Turn the knob counter
clockwise (SQUELCH opening) in order to listen to the weakest signals.
5. RF GAIN knob
The receiver gain is adjustable with the RF GAIN knob. This control should be fully clockwise most of the
time, however in the case of very strong signals from local stations the receiver sensitivity can be reduced by
turning the knob anti-clockwise.
6. ON/OFF/VOLUME Control
Use this knob to switch radio ON and OFF, as well as to adjust the receiver volume to the desired level. To
adjust the receiver volume when no signals are being received on the operating channel, open the
SQUELCH and then adjust the receiver volume using the background noise as a reference.
- 2 -
ASQ

Controls and operation
7. AM / FM Selector (EU / UK Selector)
This switch allows you to select the operating mode AM or FM, in both TX and RX (if the selected frequency
band allows it), unless the radio is set to the UK frequency band - then this switch changes the operating band
from the UK 40 FM channels to the EU (CE) 40 FM channels.
8. CH9 / CH19 Selector
This 3-position switch allows you to select the emergency channels CH9 and CH19 in the programmed
frequency band. If the switch is set to its centre position, the radio will operate on the normal selected channel.
9. TX and ASQ LED
This two-colour indicator is red or green. When radio is in TX mode it is red, when ASQ (see page 4) is
activated it is green.
10. RX /TX Signal Meter
4-bar LED display to indicate the strength of the received signal, or the power of the outgoing signal.
11. DISPLAY
The bright digital LED display shows the channel number.
Rear Panel
12. ANTENNA Connector
Antenna connector. Refer to the section INSTALLATION OF THE ANTENNA (Page 5).
13. 13.8VDC POWER CORD
13.8VDC power cord input.
14. EXT (External Speaker) Jack
This jack is for connecting an external speaker (optional).
- 3 -

Controls and operation
Microphone
15. PTT (Push-to-Talk) Button
Transmitter button. Press the PTT button to transmit and release it to return to the receive mode.
16. Up Button
This button allows you to change the operating channel upwards.
17. ASQ Button
The ASQ function allows you to automatically silence the receiver, avoiding SQUELCH manual adjustment.
To enable the ASQ function, press this button once, to disable it press it a second time.
Note: When ASQ is enabled ASQ LED (9) will illuminate green.
18. Down Button
This button allows you to change the operating channel downwards.
19. MICROPHONE Plug
6-pin microphone connector with locking ring. Connect it to the microphone connector (1) on the front panel
of the radio.
- 4 -
15
16 17 18
19

Installation
Installation
Before installing the main unit in the vehicle, check and select the most convenient location, in order
that the radio will be easy to reach and comfortable to operate, without obstructing any of the vehi-
cles controls. Use the supplied bracket and hardware to install the radio. The car mounting bracket
can be installed over or below the radio and the radio may be inclined as desired(whether under
dashboard or truck cabin roof installation).
Installation of the Main Unit
Before connecting the radio to the vehicles electric system, make sure that radio is switched off,
with the OFF/VOLUME (6) knob completely turned counter clockwise at OFF position. The DC
power cable (13) of the radio is complete with a fuse holder with fuse located on the red positive (+)
wire. Connect the DC power cable to the vehicles electric system, with special attention to correct
polarity. Connect the red wire to the positive (+) pole and the black wire to the negative (-) pole of
the vehicles electric system. Make sure that the wires and terminals are rmly and stably connect-
ed, in order to prevent cables from disconnecting or causing short circuits.
Installation of the Antenna
A specic 27MHz CB antenna must be used. Please make sure to carefully install the antenna
mount on the vehicle with a good connection to ground. Before connecting the antenna to the radio,
it is necessary to check the correct operation of the antenna with low standing wave ratio (S.W.R.),
using an SWR meter. If not, the transmitter circuit of the radio could be damaged. The antenna
should be installed on the highest part of the vehicle, free from obstacles and as far away as pos-
sible from any source of electric or electromagnetic noise. The RF antenna coaxial cable must not
be damaged or pressed on its way between antenna and the radio. The correct operation of the
antenna and the low standing wave ratio (S.W.R.) must be checked periodically. Connect the RF
antenna coaxial cable to the antenna connector (12), located on the rear side of the radio.
Checking Operation of the Radio
Once the radio has been connected to the vehicles electric system and to the antenna, the correct
operation of the system may be checked. Please proceed as follows :
1) Check that the power cable is correctly connected.
2) Check that the RF antenna coaxial cable is correctly connected.
3) Connect the microphone to the connector (1), located on the front side of the radio.
4) Rotate the SQUELCH (4) knob counter clockwise.
5) Turn the radio on using the ON/OFF/VOL (6) knob and adjust the volume to the desired level.
6) Select the desired channel, using the channel selector buttons (2 and 3, or 16 and 18 on mic).
7) Rotate the SQUELCH (4) knob clockwise, to cut the background noise.
8) Press the PTT (15) key to transmit and release it to receive.
- 5 -

Frequency band selection / table
Frequency Band Table
8 programmable frequency bands are available, as per the below table :
FREQUENCY BAND
ID CODE
COUNTRY SPECIFICATIONS
(Channels, Operating Modes, TX Power)
E1 ITALY/SPAIN 40CH AM / FM 4W
I2 ITALY 36CH AM / FM 4W
-d GERMANY 80CH FM 4W - 12CH AM 1W
d2 GERMANY 40CH FM 4W - 12CH AM 1W
EU EUROPE/FRANCE 40CH FM 4W - 40CH AM 1W
CE CEPT 40CH AM / FM 4W
-U UK 40CH FM 4W UK FREQUENCIES
40CH FM 4W EU (CE) FREQUENCIES
PL POLAND 40CH AM / FM 4W POLISH FREQUENCIES
Frequency Band Selection / Programming
This Thunderpole T-800 CB radio must be programmed and exclusively used on a frequency band
allowed in the country where the product is used (see below). When radio is switched ON, the
current programmed frequency band code will be displayed for approx. 2 seconds. To program a
different frequency band, proceed as follows :
1) Turn OFF the radio.
2) Whilst pressing the PTT (15) and Down button on the microphone (18) together, turn on the
power using the ON/OFF/VOLUME Control (6).
3) Use the UP and Down buttons (2 & 3, or 16 &18) to select the band.
4) Turn the radio off and then on again, now the display will show the programmed band, and you
will be working on the band you selected.
UK/CE Channel Selection (Frequency Band “U”)
If the UK Frequency band has been selected, all 80 channels available for UK use can be accessed
by using the EU/UK (AM/FM) Switch (7). In EU/AM position the radio will operate on the European
(CE) 40 Channel band in FM mode, and when in UK/FM position the radio will operate on the UK 40
Channel band in FM mode.
Note: To access AM channels on the CE band follow instructions 1 to 4 above and choose CE band,
then swith the AM/FM switch to AM.
- 6 -

User information
Attention ! This radio has been pre-programmed on the UK frequency band (UK 40CH FM 4W)
which is for use in the UK only. For use in other countries, please refer to the frequency band table
on page 6.
User Information
in accordance with art. 13 of the Legislative Decree of 25th July 2005, no. 15 ”Implementation of
Directives 2002/95/EC, 2002/96/EC and 2003/108/EC, relative to reduction of the use of hazardous
substances in electrical and electronic equipment, in addition to waste disposal”.
The crossed bin symbol shown on the equipment indicates that at the end of its work-
ing life the product must be collected separately from other waste.
The user must therefore take the above equipment to the appropriate differentiated
collection centres for electronic and electro technical waste, or return it to the dealer
when purchasing a new appliance of equivalent type, in a ratio of one to one.
Appropriate differentiated waste collection for subsequent recycling, treatment and environment-
friendly disposal of the discarded equipment helps to prevent possible negative environmental and
health effects and encourages recycling of the component materials of the equipment.
Illegal disposal of the product by the user will be punished by application of the administrative nes
provided for by the legislative decree no. 22/1997 (article 50 and following of the legislative decree
no. 22/1997).
- 7 -
IMPORTANT !
Never attempt to open the cabinet of the transceiver. No user serviceable parts inside. Internal
modications or tampering may cause damage to the product, modifying its technical specications
will void all warranty rights.
If service or repair is required, please go to an authorised service centre or specialised technician.

Specications
General
Channels 40 AM / FM (refer to the frequency bands table at page 6)
Frequency range 27 MHz Citizen Band
Frequency control P.L.L.
Operatine temperature -10°/+55°C
DC input voltage 13.8Vdc ±15%
Size 115 (W) x 38 (H) x 150 (D) mm
Weight 800 gr.
Receiver
System Double conversion, CPU controlled super-heterodine
IF 1° 10.700 MHz / 2° 450 KHz
Sensitivity -120dBm for 12dB SINAD (FM)
-107dBm for 12dB SINAD (AM)
Audio output @10% THD 2.5W at 8 ohm
Audio distorsion <8% at 1 KHz
Image rejection 65dB
Adjacent channel 85dB
Signal/noise ratio 45dB
Current drain 220mA (stand-by)
Transmitter
System CPU controlled P.L.L. systhesizer
Maximum RF power 4W at 13.8Vdc
Modulation 85% to 90% (AM)
2KHz ±0.2 KHz (FM)
Impedance 50 ohm unbalanced
Current drain 2000mA (at no modulation)
- 8 -

Notes
