OWNER'S MANUAL
Model: MPM3-12HRN1-BH9
Model: MPM3-14CRN1-B I 6
PORTABLE AIR CONDITIONER

CONTENTS
The rating data indicated on the energy label is based
on the testing condition of installing the un-extended
air exhaust duct without adaptor A & B (The duct and
the adaptor A & B are listed in the accessories chart
of the Instruction Manual).
NOTE
1
SAFETY PRECAUTIONS
Always do this ...................................................................................................................................3
Never do this .....................................................................................................................................3
Electrical information .........................................................................................................................3
Accessories .......................................................................................................................................4
Names of parts...................................................................................................................................5
Operation panel of the air conditioner ..............................................................................................6
Operating condition .........................................................................................................................10
Location ...........................................................................................................................................11
Window kit installation .....................................................................................................................11
Exhaust hose installation .................................................................................................................14
Water drainage ................................................................................................................................15
Care and maintenance ....................................................................................................................16
Troubleshooting ...............................................................................................................................17
CARE AND MAINTENANCE
TROUBLESHOOTING TIPS
OPERATING INSTRUCTIONS
INSTALLATION INSTRUCTIONS
IDENTIFICATION OF PARTS
Environmental concerns......................... .............................................................................................2

2

3
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation due to ignoring of instructions may cause harm or damage.
Your air conditioner should be used in such a way
that it is protected from moisture. e.g. condensation,
splashed water, etc. Do not place or store your air
conditioner where it can fall or be pulled into water
or any other liquid. Unplug immediately.
Always transport your air conditioner in a vertical
position and stand on a stable, level surface during
use.
Turn off the product when not in use.
Always contact a qualified person to carry out
repairs. If the supply cord is damaged it must be
repaired by a qualified repairer.
Keep an air path of at least 30cm all around the
unit from walls, furniture and curtains.
If the air conditioner is knocked over during use,
turn off the unit and unplug from the mains supply
immediately.
SAFETY PRECAUTIONS
!
Always do this
Do not operate your air conditioner in a wet room
such as a bathroom or laundry room.
Do not touch the unit with wet or damp hands or
when barefoot.
Do not press the buttons on the control panel with
anything other than your fingers.
Do not remove any fixed covers. Never use this
appliance if it is not working properly, or if it has
been dropped or damaged.
Never use the plug to start and stop the unit.
Always use the switch on the control panel.
Do not cover or obsturct the inlet or outlet grilles.
Do not use hazardous chemicals to clean or come
into contact with the unit. Do not use the unit in the
presence of inflammable substances or vapour such
as alcohol, insecticides, petrol,etc.
Do not allow children to operate the unit
unsupervised.
Do not use this product for functions other than
those described in this instruction manual.
Never do this
Energy Save
Use the unit in the recommended room size.
Locate the unit where furniture cannot obstruct the air flow.
Keep blinds/curtains closed during the sunniest part pf the day.
Keep the filters clean.
Keep doors and windows closed to keep cool air in and warm air out.
Be sure the electrical service is adequate for the model you have chosen. This information can be found
on the serial plate, which is located on the side of the cabinet and behind the grille.
Be sure the air conditioner is properly grounded. To minimize shock and fire hazards, proper grounding is
important. The power cord is equipped with a three-prong grounding plug for protection against shock
hazards.
Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you intend
to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualified
electrician install the proper receptacle.
Ensure the receptacle is accessible after the unit installation.
WARNING For your safety
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove
any prong from the power cord.
WARNING Electrical Infor mation

4
Accessories
Check all the accessories are included in the package and please refer to the installation instructions for
their usage.
PARTS : PARTS NAME :
Exhaust hose with adapter B(round mouth)
Wall Exhaust Adaptor A( )
Window Exhaust Adaptor B(flat mouth)
Expansion Plug and wooden screw( )
QUANTITY :
1 set
1 pc
1 pc
4/ pc
1 set
Window Slider Kit
Foam seal
3/pc
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
SWING
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
RESET LOCK
SET TEMPERATURE( C)
FOLLOW
ME LED
DISPLAY
ION
TURBO
Remote Controller
(For remote control models only)
1pc
Battery(For remote controller)
2/pc
IDENTIFICATION OF PARTS
Band (For bundling the power cord)
Drain Hose(For continuous drainage)
1 pc
1 pc
Suggested tools for window kit installation
1. Screwdriver(medium size Phillips)
2. Tape measure or ruler
3. Knife or scissors
4. Saw(In the event that the window kit needs to be cut down in size because the window is too
narrow for direct installation)
NOTE: Optional parts( ), some models without.

IDENTIFICATION OF PARTS
5
NAMES OF PARTS
Fig.1
Fig.2
Front
Rear
Operation Panel
Horizontal Louver Blade
(Lift it up during operation)
Signal receptor(optional)
Air intake (Air filter inside)
Carrying Handle
(both sides)
1
2
3
5
4
1
2
3
4
5
11
10
6
7
8
9
10
11
Air intake
Power cord outlet
Drain Outlet A (Used on
dehumidifying operation)
Drain Outlet B (Used on heating
operation)
Air Outlet
Air intake(Air filter inside)
9
6
7
8
NOTE: The illustrations are for
explanation purposes only. The
actual shape of the machine you
purchased may be slighted
different. The actual shape
should prevail.

6
OPERATING INSTRUCTIONS
TIMER ON TIMER OFF
MODE
LOW
FAN
SLEEP
FOLLOW ME
HI
MED
HEAT
FAN
DRY
COOL
AUTO
SWING
ION/
PLAS M A
Follow me
indicator light
(on some models)
Mode indicator
lights
Fan speed
indicator light
TURBO
1
23
4
56
78910
11
Before you begin, thoroughly familiarize yourself with the control panel and remote controller
and all its functions, then follow the symbol for the functions you desire.
The unit can be controlled by the unit control panel alone or with the remote controller .
Fig.3
NOTE: This manual does not include Remote Controller Operations, see the <<Remote
Controller Instruction>> packed with the unit for details.
OPERATION PANEL OF THE AIR CONDITIONER
1
2
3
Control the fan speed. Press to select the fan
speed in four steps-LOW, MED, HI or AUTO.
The fan speed indicator light illuminates under
different fan settings except AUTO.
TIMER button:
Used to initiate the start time/
stop time program , in
confuction with & buttons.
AUTO ON
AUTO OFF
Selects the appropriate operating
mode. Each time you press the button,
a mode is selected in a sequence that
goes from AUTO, COOL, DRY, FAN and
HEAT(For cooling & heating models only).
The Mode indicator lights illuminate under
the different mode settings Fig.4.
Used to adjust (increasing/decreasing)
temperature settings(1 C/2 F increments)
in a range of 17 C(62 F) to 30 C(88 F).
Under Auto-timer setting, press or hold
the Up or Down button to change the
Auto time by 0.5 hour increments, up to
10 hours, then at one hour increments up
to 24 hours.
Power switch on/off.
Fan Options:
COOL (4 speeds) Low-Med-Hi-Auto
DRY(1 speed) LOW
FAN (4 speeds) Low-Med-Hi-Auto
Low-Med-Hi-AutoHEAT(4 speeds)
AUTO (1 speeds) AUTO
SWING button:
Allows the top horizontal louver blades to
oscillate forward and backward to the
desired direction. Each press will change
the swing angle for 6 . If keeping pressing
the button without releasing for 2 more
seconds, the louver blades would oscillate
forward and backward automatically.
O
4
5
6
Temperature/Time Up/Down buttons
Fan speed button
Mode select button
Power button
NOTE: The control is capable of displaying
temperature in degrees Fahrenheit or degrees
Celsius. To convert from one to the other, press
and hold the Up and Down buttons at the same
time, for 3 seconds.
LED DISPLAY MODELS:
NOTE:The following illustration is for explanation purposes only. The actual shape of the control
panel of the unit you purchased may be slightly different. But the function are the same.

OPERATING INSTRUCTIONS
7
ION/PLASMA button(optional)
TURBO button
Used to set the strong fan speed, the set
temperature will reach in the shortest time.
This function is only availabe on COOL mode.
.
Press the this button, the anion generator/
Plasma Filter is energized and will help to
remove pollen and impurities from the air,
and trap them in the filter.
SLEEP button
Press this button, the selected temperature
will increase(cooling) or decrease(heating)
by 1 30 minutes.The temperature will
then increase(cooling) or decrease(heating)
by another after an additional 30
minutes. This new temperature will be
maintained for 7 hours before it returns
to the originally selected temperature. This
ends the Sleep mode and the unit will
continue to operate as originally program-
med. The Sleep mode program can be
cancelled at any time during operation by
again pressing the SLEEP button,or turning
off the unit, or pressing the MODE or FAN
button.
This feature is unavailabe under
FAN or DRY mode.
NOTE:
O O
O O
C/2 F
C/2 F
1
Shows the set temperature in C " " " " or F
and the Auto-timer settings.
Room temperature sensor error-
Unplug the unit and plug it back in. If
error repeats, call for service.
Evaporator temperature sensor error-
Unplug the unit and plug it back in. If
error repeats, call for service.
Conenser temperature sensor error-
Unplug the unit and plug it back in. If
error repeats, call for service.
Bottom tray is full - Remove the bottom
drain plug and drain off the water.
Error codes:
E1-
E2-
E3-
P1-
7
8
9
10
LED Display
11
To activate the Follow Me feature, point
the remote control towards the unit and
press the Follow Me button. T
If the unit does not receive the Follow
Me signal during any 7 minute interval,
the FOLLOW ME indicator light turns off
to indicate the mode has ended.
he remote
display is actual temperature at its
location. The remote control will send
this signal to the air conditioner every 3
minutes interval until press the Follow
Me button again.
This feature can be activated by
the remote control ONLY. The
remote control serves as a remote
thermostat allowing for the precise
temperature control at its location.
Follow me indicator light
(optional)
TIMER operation
When the air conditioner is on:
- Press the "TIMER " button will first activate
the Timer Off setting program. The TIMER
OFF indicator light illuminates and the
LED display window appears "0.0 " .
- Continue pressing or keep pressing the
"UP or DOWN " button to select the time
you need the unit to stop operation. If
press UP button, the time is programmed
as :0.0- 0.5-1.0-1.5-2.0-2.5-3.0-3.5-4.0-4.5
-5.0- 5.5-6.0-6.5-7.0-7.5-8.0-8.5-9.0-9.5-
10-11-12-13-14-15-16-17-18-19-20-21-22
-23-24-0.0. If press the DOWN button, the
time is programmed in reverse order.
- When the desired time is established,
wait for 5 seconds or press the TIMER
button again to register the time. The
setting temperature will immediately
revert back in the display window. And
the TIMER OFF indicator light remains
on indicating the program is set.
- If press the TIMER button once again,
the TIMER ON indicator light illuminates
and the LED display window appears
"0.0 ". You are ready to adjust the ON
Timer setting.

OPERATING INSTRUCTIONS
8
- Perform the same operations as above TIMER
OFF setting to set the TIMER ON time.
- The starting/stopping time is adjustable from
0.0 to 24.
When the air conditioner is off:
- Press the "TIMER" button will first activate the
TIMER ON setting program. Press the TIMER
button once again will activate the TIMER OFF
setting program.
- Perform the same operations as above TIMER
ON and TIMER OFF setting to set the starting/
stopping time.
IMPORTANT:
The time will be registered in 5 seconds period
(after pressing the UP/DOWN button), so you
should continue pressing the button until the
desired time is established. Otherwise you must
repeat the steps again.
When both start and stop time are set
simultaneously:
- Both the TIMER ON and TIMER OFF indicator
lights illuminate and remain on until the auto
starting/stopping time is achieved.
FAN SLEEP SWING
ON/OFF
ION/
PLASMA
TIMER
ON/OFF
DOWN
UP
MODE
LCD DISPLAY MODELS:
ON
OFF auto
LCD display
window
LCD display window :
auto
Timer on indicator
Timer off indicator
Auto operation indicator
Cooling operation indicator
Dry operation indicator
Heating operation indicator
Fan operation indicator
Fan speed indicator
(Low( )--Med( )--Hi( )--
Auto ))
(No display
Sleep operation
Turbo display
Anion display(on some models)
Auto swing display
Follow me indicator(on some models)
ON
OFF
TURBO
12
3 4 5
67 8 9
Fig.4
Shows the set temperature in C " " " " or F
and the error codes.
Room temperature sensor error-
Unplug the unit and plug it back in. If
error repeats, call for service.
Evaporator temperature sensor error-
Unplug the unit and plug it back in. If
error repeats, call for service.
Conenser temperature sensor error-
Unplug the unit and plug it back in. If
error repeats, call for service.
Bottom tray is full - Remove the bottom
drain plug and drain off the water.
Error codes:
-
-
-
-
Display
10
NOTE:The following illustration is for explanation purposes only. The actual shape of the control
panel of the unit you purchased may be slightly different. But the function are the same.

OPERATING INSTRUCTIONS
9
6
Press the FAN button to select the desired fan
speed:
LOW MED HI AUTO
Fan Options:
COOL (4 speeds) Low-Med-Hi-Auto
DRY(1 speed) LOW
FAN (4 speeds) Low-Med-Hi-Auto
Low-Med-Hi-AutoHEAT(4 speeds)
AUTO (1 speeds) AUTO
FAN button
(No display)
TURBO/PUMP button
Used to set the strong fan speed, the set
temperature will reach in the shortest time.
This function is only availabe on COOL mode.
SLEEP button
Press this button, the indicator displayed
and the selected temperature will increase
(cooling) or decrease(heating) by 1
in 30 minutes.The temperature will then
increase(cooling) or decrease(heating)
by another after an additional 30
minutes. This new temperature will be
maintained for 7 hours before it returns
to the originally selected temperature. This
ends the Sleep mode and the unit will
continue to operate as originally program-
med. The Sleep mode program can be
cancelled at any time during operation by
again pressing the SLEEP button,or turning
off the unit, or pressing the MODE or FAN
button.
This feature is unavailabe under
FAN or DRY mode.
NOTE:
O O
O O
C/2 F
C/2 F
1
7
8
9
SWING button:
Allows the top horizontal louver blades to
oscillate forward and backward to the desired
direction. Each press will change the swing
angle for 6 . If keeping pressing the button
without releasing for 2 more seconds, the
louver blades would oscillate forward and
backward automatically.
O
Button functions on Control Panel
1
2
Press the MODE button to select the
appropriate operating mode:
AUTO COOL DRY FAN HEAT
Power switch on/off.
MODE button
ON/OFF button
auto
HEAT mode is for cooling & heating models only.
3
TIMERON/OFF button:
Used to initiate the start time/
stop time program , in
confuction with & buttons.
AUTO ON
AUTO OFF
Used to adjust (increasing/decreasing)
temperature settings(1 C/2 F increments)
in a range of 17 C(62 F) to 30 C(88 F).
Under Auto-timer setting, press or hold
the Up or Down button to change the
Auto time by 0.5 hour increments, up to
10 hours, then at one hour increments up
to 24 hours.
4
Temperature/Time Up/Down buttons
NOTE: The control is capable of displaying
temperature in degrees Fahrenheit or degrees
Celsius. To convert from one to the other, press
and hold the Up and Down buttons at the same
time, for 3 seconds.
ION/PLASAM button(on some models)
Press this button, indicator displayed
indicating the anion generator/Plasma filter
is energized and will help to remove pollen
and impurities from the air, and trap them in
the filter.
5
10
To activate the Follow Me feature, point
the remote control towards the unit and
press the Follow Me button. T
If the unit does not receive the Follow Me
signal during any 7 minute interval, the
FOLLOW ME indicator disappeared to
indicate the mode has ended.
he remote
display is actual temperature at its location.
The remote control will send this signal to
the air conditioner every 3 minutes interval
until press the Follow Me button again.
This feature can be activated by the
remote control ONLY. The remote
control serves as a remote thermostat
allowing for the precise temperature
control at its location.
Follow me indicator( )(on some models)

OPERATING INSTRUCTIONS
When the air conditioner is on:
- Press the "TIMER ON/OFF " button will first
activate the Timer Off setting program. The
word OFF and the clock symbol begin to flash
and the LCD display window appears "0.0 " .
- Continue pressing or keep pressing the "UP or
DOWN " button to select the time you need the
unit to stop operation. If press UP button, the
time is programmed as :0.0- 0.5-1.0-1.5-2.0-2.5
-3.0-3.5-4.0-4.5 -5.0- 5.5-6.0-6.5-7.0-7.5-8.0-8.5
-9.0-9.5-10-11-12-13-14-15-16-17-18-19-20-21
-22-23-24-0.0. If press the DOWN button, the
time is programmed in reverse order.
TIMER operation
- When the desired time is established, wait 5
seconds or press the TIMER ON/OFF button
again to register the time. The word OFF
flashes and the clock symbol illuminates ,
indicating the OFF timer has been set.
- If press the TIMER ON/OFF button once again,
the word ON and clock symbol flash and the
LCD display window appears "0.0 ". You are
ready to adjust the ON Timer setting.
- Perform the same operations as above
TIMER OFF setting to set the TIMER ON time.
- The starting/stopping time is adjustable from
0.0 to 24.
When the air conditioner is off:
- Press the "TIMER ON/OFF" button will first
activate the TIMER ON setting program.
- Press the TIMER ON/OFF button again will
activate the TIMER OFF setting program.
- Perform the same operations as above
TIMER ON/OFF setting to set the starting/
stopping time.
IMPORTANT:
The time will be registered in 5 seconds period
(after pressing the UP/DOWN button), so you
should continue pressing the button until the
desired time is established. Otherwise you must
repeat the steps again.
When both start and stop time are set
simultaneously:
- If the TIMER ON TIMER OFF feature is set,
the word ON flashes, the word OFF and clock
symbol illuminate and remain on.
- If the TIMER OFF TIMER ON feature is set,
the word OFF flashes, the word ON and clock
symbol illuminate and remain on.
The air conditioner must be operated within the
temperature range indicated below:
Operating condition
MODE ROOM TEMPERATURE
COOL
Dehumidification
17 C ~35 C/62 F~ 95 F
O O O O
HEAT
13 C ~35 C/54 F~ 95 F
O O O O
5 C ~30 C/41 F~ 88 F
O O O O
10

INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Horizontal
window
Window Slider Kit
Minimum:67.5cm(2.22ft).
Maxmum:123cm(4.04ft).
Window Slider Kit
Minimum:67.5cm(2.22ft).
Maxmum:123cm(4.04ft).
Horizontal
window
Fig.6
Fig.7
Fig.5
Location
The air conditioner should be placed on a firm
foundation to minimize noise and virbration. For
safe and secure positioning, place the unit on a
smooth, level floor strong enough to support the unit.
The unit has casters to aid placement, but it should
only be rolled on smooth, flat surfaces. Use caution
when rolling on carpet surfaces. Do not attempt to
roll the unit over objects.
The unit must be placed within reach of a properly
rated grounded socket.
Never place any obstacles around the air inlet or
outlet of the unit.
Allow at least 30cm of space from the wall for
efficient air-conditioning.
Your window kit has been designed to fit most standard
Vertical and horizontal window applications,
However, it may be necessary for you to improvise/
modify some aspects of the installation procedures for
certain types of window. Please refer to Fig. 6& Fig.7 for
minimum and maximum window openings.
" " " "
Window kit Installation
If the window opening is less than the mentioned
minimum length of the window slider kit, cut that one
with holes in it short to fit for the window opening. Do
never cut out the hole in window slider kit.
Note:
30cm
30cm
11

INSTALLATION INSTRUCTIONS
Installation in a double-hung sash
windows
1. Cut the foam seal(adhesive type) to the proper
length and attach it to the window stool. Fig.8
2. Attach the window slider kit to the window stool.
Adjust the length of the window slider kit according
to the width of window, short the adjustable window
kit if the width of window is less than 27 inches.
Open the window sash and place the window slider
kit on the window stool. Fig.9
3. Cut the foam seal(adhesive type) to the proper
length and attach it on the top of the window. Show
as in Fig.10.
4. Close the window sash securely against the
window.
5. Cut the foam seal to an appropriate length and
sealing the open gap between the top window sash
and outer window sash. Show as in Fig.11.
Foam seal A
(adhesive type)
Window kit
Window stool
26.5 ~ 48
Foam seal
Fig.8
Fig.9
Fig.10
Fig.11
12
Window kit
Window stool

INSTALLATION INSTRUCTIONS
Installation in a sliding sash
windows
1. Cut the foam seal(adhesive type) to the proper
length and attach it to the window frame,Fig.12.
2. Attach the window slider kit to the window stool.
Adjust the length of the window slider kit according
to the width of window, short the adjustable window
kit if the width of window is less than 27 inches.
Open the window sash and place the window slider
kit on the window stool. See Fig.13.
3. Cut the foam seal(adhesive type) to the proper
length and attach it on the top of the window.
Show as in Fig.14.
4. Close the sliding sash securely against the window.
5. Cut the foam seal to an appropriate length and
sealing the open gap between the top window sash
and outer window sash. Show as in Fig.15.
Foam seal
Foam seal A
(adhesive type)
Window
panel
26.5 ~ 48
Fig.12
Fig.13
Fig.14
Fig.15
13

INSTALLATION INSTRUCTIONS
Exhaust hose installation:
The exhaust hose and adaptor must be installed or
removed in accordance with the usage mode.
COOL mode
FAN, HEAT or DEHUMIDIIFY
mode
Install
Remove
The duct can be compressed or extended
moderately according to the installation
requirement, but it is desirable to keep the
duct length to a minimum.
IMPORTANT:
DO NOT OVER BEND THE DUCT (SEE Fig.20)
Fig.18
Fig.16
Fig.17
Fig.20
(Not applicable to the units without adaptor A,
expansion plugs and wooden screws of Accessories )
1. Prepare a hole in the wall. Install the wall Exhaust
adaptor A onto the wall(outside) by using 4 expansion
plugs and wooden screws, be sure to fix thoroughly.
(See Fig.19)
2. Attach the Exhaust hose to wall Exhaust adaptor A.
The exhaust hose can be installed into the wall .
.
Fig.19
max 120CM
min 30CM
Adaptor A
Expansion plug
position
Adaptor
cap
Note:
Cover the hole using the adaptor cap when not in
use.
14
Adaptor B
Adaptor B
1. Install the window Exhaust adaptor B(flat mouth)
onto the exhaust hose as shown in Fig.16. Refer to
the previous pages for window kit installation.
2. Install the flexible Exhaust hose as depicted
in Fig.17 & 18.

CARE AND MAINTENANCE
Water drainage:
Fig.21
Fig.22
Drain outlet A
Attach a section of
drain hose onto the
connector inside.
15
Drain outlet B
- During Dehumidifying modes, remove the drain
plug A from the back of the unit(Fig.21), install
the drain connector(5/8 universal female mender)
with 3 4 hose(locally purchased).
-
Make sure the drain
outlet A is plugged.
- For the models without drain connector, just attach
the drain hose to the hole. Place the open end of
the hose directly over the drain area in your
basement floor.
During Heating mode, remove the drain plug B
from the back of the unit(Fig.21), install the drain
connector (5/8 universal female mender) with 3/4
hose(locally purchased).
Please refer to Fig.22.
-When the water level of the bottom tray reaches
a predetermined level,
and the unit
stop operation. Carefully move the unit to a drain
location, remove the bottom drain plug and let the
water drain away(Fig.24). Restart the machine
until the P1 symbol disappears. If the error
repeats, call for service.
" "
NOTE: When the relative humidity is less than
80%, the water drainage is not needed during
cooling operation. If performing above water
drainage during cooling operation, the cooling
efficiency will be reduced.
the unit beeps 8 times,
the digital display area shows P1 " "

CARE AND MAINTENANCE
2. Unit enclosure
- Use a lint-free cloth soaked with neutral detergent
to clean the unit enclosure. Finished by a dry clean
cloth.
3. Unit idle for a long time
Fig.24
- When you plan to leave this unit unused for a long
time, remove the bottom rubber plug from the back
hole and attach a section of the continuous drain
hose . All the water in the bottom tray would drain
outside through the drain hose.(See Fig.24)
- Keep the appliance running on FAN mode for half
a day in a warm room to dry the appliance inside
and prevent mold forming.
- Stop the appliance and unplug it, wrapped the cord
and bundle it with the tape. Remove the batteries
from the remote controller.
- Clean the air filter and reinstall it.
- Disconnect the exhaust hose, keep it safety, and
cover the window(wall) hole with the adaptor cap.
16
1. Air filter
- Clean the air filter at least once every two weeks to
prevent inferior fan operation because of dust.
-
Grasp the filter tab, pull the filter out then up .
Then remove the screw on the side air intake grille,
pull the filter out. See Fig.23.
-
Wash the air filter by immersing it gently in warm
water(about 40 C/104 F) with a neutral detergent.
Rinse the filter and dry it in a shady place.
-
Replace the air filters.
Replacement air filter are available through the
Customer Service Parts Department.
Never operate the unit without the air
filter in place as this may result in damage to the
unit.
Removal
Cleaning
Mounting
, , , ,
O O
CAUTION:
, ,
, ,
CARE AND MAINTENANCE
1)
2) Do not use gasoline, thinner or other chemicals to
clean the unit.
3) Do not wash the unit directly under a tap or using a
hose. It may cause electrical danger.
4) If the power cord is damaged, it should be repaired
by manufacture or its agency.
Be sure to unplug the unit before cleaning or
servicing.
IMPORTANT:
Filter tap
Fig.23
Air intake grille
Air filter

TROUBLESHOOTING TIPS
TROUBLE SHOOTING
1. Unit does not
Start when
Pressing on/off
Button
- Water full indicator blinks, water tank
is full.
Dump the water in the water tank.
TROUBLES
POSSIBLE CAUSES
SUGGEST REMEDIES
Reset the temperature.
Reset the temperature.
Make sure all the windows and
doors are closed.
Remove the heat sources if possible.
Connect the duct and make
sure it can function properly.
Decrease the set temperature.
Clean the air filter.
- Room temperature is higher than
the set temperature.(Heating mode)
- Room temperature is lower than
the set temperature.(Cooling mode)
- The windows or doors in the room
are not closed.
- There are heat sources inside the
room.
- Exhaust air duct is not connected or
blocked.
- Temperature setting is too high.
- Air filter is blocked by dust.
2. Not cool enough
Place the unit on a flat, level
ground if possible.
It is normal.
- The ground is not level or not flat
enough.
- The sound comes from the flowing
of the refrigerant inside the
air-conditioner.
4. Noisy or vibration
5. Gurgling sound
Switch on again after the unit
has cool down.
- The automatic over heat protection
function. When the temperature at
the air outlet exceed 70 C/158 F,
the device will stop.
O O
3. Power shut off at
Heating mode
6. Compressor does not work
and the digital display area
shows P1 ¡° ¡±
- The bottom tray is full
7. The cooling indicator light
flashes at 1Hz and the digital
display area shows E1 ¡° ¡±
- The room temperature Sensor is
off or short-circuit.
Contact service people
8. The FAN indicator light
flashes at 1Hz and the digital
display area shows E2 ¡° ¡±
- The Evaporator Temperature Sensor
is off or short-circuit.
9. The indicator
light flashes at 1Hz and the
digital display area shows
E3
Dehumidifying
¡° ¡±
- The Condenser Temperature Sensor
is off or short-circuit.
Contact service people
Contact service people
Rremove the bottom plug and drain
the collected water away. If it does
not work after restart, contact the
service people.
17
