Frigidaire FAS184J2A1 User manual

PRODUCT NO.
BASE MODEL NO.
VOLTS
BTU-COOLING
FAS184J2A1 FAS184J2A 230 18000
P.O. Box 212378
Augusta, GA 30917
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
©2000 White Consolidated Industries, Inc.
ROOM AIR CONDITIONER
Model No.
FAS184J2A1
WIRING DIAGRAM # - 309343701
OWNERS GUIDE # - 309000825
Publication No.
000307
-EN/SERVICE /REP
345
5995339693

FAS184J2A1
CABINET FRONT AND WRAPPER
3/00 1

FAS184J2A1
1 309632704 Sleeve-Seal Assy Domestic
2 309632804 Grill & RR Rail ASM HDTC
7 309631104 Link-Vertical Louvers
8 309630804 Louver-Horizontal
9 309631004 Louver-Vertical HDTC
12 309631404 Filter-Molded BRCLN
17 309633205 FrontT ASM- HDTC
19 309341003 Plate-Dial
25 309321401 Door-Vent Actuator HDTC
26 309330404 Handle-Vent Barcelona
43 309630904 Frame-Front HDTC
70 309342401 Enclosure
78 309342604 Remote- control
*309633305 Louver assy-includes 7, 8 & 9
# = Functional Parts
* = Non-illustrated Parts
CABINET FRONT AND WRAPPER
POS. NO. PART NO. DESCRIPTION
3/00 2

FAS184J2A1
CONTROL PARTS
3/00 3

FAS184J2A1
7 309630403 Box-Control
10 309623601 Bulkhead
12 * 5304414108 Clip-thermister holder
13# 5303317228 Capacitor, 370V, 30+6 mfd
14 5303303691 Screw, truss head, 8-18AB x 0.38
15 5303303086 Strap-capacitor
17# 309343112 Cord-power 230v
70 # 309342401 Enclosure
71 # 309340503 Power board
72 # 309340701 Input board
74 5303301590 Screw, (2)
75 5304413781 Hardware, (4)
76 # 309111602 Transformer
*5304415035 Defrost-thermister
*5304408751 Harness-compressor wires
POS. NO. PART NO. DESCRIPTION
CONTROL PARTS
# = Functional Parts
* = Non-illustrated Parts
3/00 4

FAS184J2A1
AIR HANDLING PARTS
3/00 5

FAS184J2A1
1# 5303311048 Fan Blade, with clamp
2 3202975 Screw,10-16 x 0.72 square drive
3 309623201 Condenser Shroud - One Piece
4 3016696 Seal, housing-fan, upper
5 5303015311 Seal, housing-fan, lower
7 5303015427 Screw, truss head, 8-18AB x 0.47
8# 309630603 Motor-Fan 3SP 230/60 48Fr
10 309623401 Bulkhead-Aire Side HDTA/TC
11 309633001 Blower Whl & Clamp Assy - Plastic
13 309630301 Cover-Top HDTA/TC
15 309630101 Scroll-Evap Cool Only HDTA/TC
17 5308011040 Clamp-part of fan blade ass'y
20 309630201 Plate-Scroll HDTA/TC
# = Functional Parts
* = Non-illustrated Parts
AIR HANDLING PARTS
POS. NO. PART NO. DESCRIPTION
3/00 6

FAS184J2A1
COMPRESSOR PARTS
3/00 7

FAS184J2A1
1# 5304403268 Compressor
2 5303283877 Grommet-compressor,3
3 5308006948 Nut, compressor, 3
5 5303002069 Clamp-Cover
6 5303002068 Gasket-cover
7 5303002067 Cover,terminal
10 5303317601 Start Assist Kit, compressor
11# 309634101 Evap-Assy 2Row 19Fpi
12# 5303306719 Condenser
13 309623501 Tray-Evap
14 309632906 Base/Compressor-Stud Assy
16# 5303209546 Capillary Tube
16A * 5303209546 Capillary Tube
16B * 5303209546 Capillary Tube
17 5304416409 Drier-process tube
19 5303002664 Washer,compressor
# = Functional Parts
* = Non-illustrated Parts
COMPRESSOR PARTS
POS. NO. PART NO. DESCRIPTION
3/00 8

FAS184J2A1
1 5304407729 Seal-window
2 5303211056 Bracket
4 5304414928 Frame,LH
5 5304409250 Seal-top rail
6 5304414933 Retainer,accordian
7 5304414931 Support,RH
8 3001815 Bracket-support
9 3007756 Screw
10 3007759 Nut-bracket
11 5304414932 Support,LH
12 3017023 Nut, hex, 10-32, 2
13 5303281649 Screw,support
14 5304414929 Frame,RH
15 5304414930 Accordian
16 5304414116 Rail,top
17 3002803 Screw-wood
18 8012680 Screw
21 5303212504 Seal,bottom
24 3002801 Screw
*309313303 Kit-Mounting-HDSO
*5304409248 Hardware
*5304409249 Seal-shipping screw holes
WINDOW MOUNTING PARTS
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
3/00 9

FAS184J2A1
WIRING DIAGRAM
3/00 10
