SERVICE MANUAL (Basic Information)
FH1222 / CH1222
FH1822 / CH1822
SPLIT SYSTEM AIR CONDITIONER
8526481017500 REFERENCE NO. WM–700701
W
Indoor Unit Outdoor Unit
CH1222
CH1822
FH1222 / FH1822
092-290S/M(Basic)00.12.1310:25AMページA

092-290S/M(Basic)00.12.1310:25AMページi

ii WM–700701
SERVICE MANUAL
FH1222 / CH1222
FH1822 / CH1822
(Basic Information)
092-290S/M(Basic)00.12.1310:25AMページii

iii WM–700701
IMPORTANT!
Please Read Before Starting
This air conditioning system meets strict safety and operating
standards. As the installer or service person, it is an important
part of your job to install or service the system so it operates
safely and efficiently.
For safe installation and trouble-free operation, you must:
●Carefully read this instruction booklet before beginning
●Follow each installation or repair step exactly as shown
●Observe all local, state, and national electrical codes
●Pay close attention to all warning and caution notices
given in this manual
This symbol refers to a hazard or
unsafe practice which can result
in severe personal injury or
death.
This symbol refers to a hazard
or unsafe practice which can
result in personal injury or prod-
uct or property damage.
If Necessary, Get Help
These instructions are all you need for most installation
sites and maintenance conditions. If you require help for a
special problem, contact our sales/service outlet or your
certified dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for
improper installation or maintenance service, including
failure to follow the instructions in this document.
SPECIAL PRECAUTIONS
When Wiring
ELECTRICAL SHOCK CAN CAUSE SEVERE PER-
SONAL INJURY OR DEATH. ONLY A QUALIFIED,
EXPERIENCED ELECTRICIAN SHOULD
ATTEMPT TO WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and tub-
ing are completed or reconnected and checked.
• Highly dangerous electrical voltages are used in this sys-
tem. Carefully refer to the wiring diagram and these
instructions when wiring. Improper connections and inad-
equate grounding can cause accidental injury or death.
• Ground the unit following local electrical codes.
• Connect all wiring tightly. Loose wiring may cause over-
heating at connection points and a possible fire hazard.
When Transporting
Be careful when picking up and moving the indoor and out-
door units. Get a partner to help, and bend your knees when
lifting to reduce strain on your back. Sharp edges or thin
aluminum fins on the air conditioner can cut your fingers.
When Installing…
…In a Ceiling or Wall
Make sure the ceiling/wall is strong enough to hold the
unit’s weight. It may be necessary to construct a strong
wood or metal frame to provide added support.
…In a Room
Properly insulate any tubing run inside a room to prevent
“sweating” that can cause dripping and water damage to
walls and floors.
…In Moist or Uneven Locations
Use a raised concrete pad or concrete blocks to provide a
solid, level foundation for the outdoor unit. This prevents
water damage and abnormal vibration.
…In an Area with High Winds
Securely anchor the outdoor unit down with bolts and a
metal frame. Provide a suitable air baffle.
…In a Snowy Area (for Heat Pump-type Systems)
Install the outdoor unit on a raised platform that is higher
than drifting snow. Provide snow vents.
When Connecting Refrigerant Tubing
• Keep all tubing runs as short as possible.
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching surfaces of the
flare and union tubes before connecting them, then tighten
the nut with a torque wrench for a leak-free connection.
• Check carefully for leaks before starting the test run.
NOTE:
Depending on the system type, liquid and gas lines may be
either narrow or wide. Therefore, to avoid confusion the
refrigerant tubing for your particular model is specified as
either “narrow” or “wide” rather than as “liquid” or “gas.”
When Servicing
• Turn the power OFF at the main power box (mains)
before opening the unit to check or repair electrical parts
and wiring.
• Keep your fingers and clothing away from any moving
parts.
• Clean up the site after you finish, remembering to check
that no metal scraps or bits of wiring have been left
inside the unit being serviced.
WARNING:
CAUTION:
092-290S/M(Basic)00.12.1310:25AMページiii

iv WM–700701
Table of Contents
Page
1. OPERATING RANGE............................................................................................................................... 1
2. SPECIFICATIONS .................................................................................................................................... 2
Unit Specifications ....................................................................................................................................... 2
3. DIMENSIONAL DATA ............................................................................................................................. 4
4. COOLING CAPACITY............................................................................................................................. 6
5. HEATING CAPACITY.............................................................................................................................. 10
6. REFRIGERANT FLOW DIAGRAM ...................................................................................................... 14
7. ELECTRICAL DATA................................................................................................................................16
●Electrical Characteristics....................................................................................................................... 16
●Electric Wiring Diagram........................................................................................................................ 17
092-290S/M(Basic)00.12.1310:25AMページiv

1WM–700701
1. OPERATING RANGE
Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp.
Cooling Maximum 95°F DB / 71°F WB 115°F DB
Minimum 67°F DB / 57°F WB 67°F DB
Heating Maximum 80°F DB / 67°F WB 75°F DB / 65°F WB
Minimum — DB / — WB 17°F DB / 15°F WB
FH1222 / CH1222, FH1822 / CH1822
092-290S/M(Basic)00.12.1310:25AMページ1

2WM–700701
Model No. Indoor unit FH1222
Outdoor unit CH1222
Cooling Heating
Capacity BTU/h 11,400 / 11,200 12,500 / 12,200
kW 3.34 / 3.28 3.66 / 3.58
Air circulation (High) cu. ft./min. 350 / 340
Moisture removal (High) Pints/h 3.3 / 3.2
Phase, Frequency Hz Single, 60
Voltage rating V 230 / 208 230 / 208
Available voltage range V 187 to 253 187 to 253
Running amperes A 5.6 / 5.9 5.2 / 5.5
Power input W 1,210 / 1,180 1,190 / 1,140
Power factor % 94 / 96 99 / 99
Starting amperes A 32
S.E.E.R. (H.S.P.F.) BTU/Wh 10.0 / 10.0 (6.8 / 6.8)
Heater element kW — 3.0 / 2.45
Controls Microprocessor
Control unit Indoor unit
Temperature control IC thermostat
Timer ON/OFF, 12-hours
Fan speeds Indoor / Outdoor 3 and Auto / 1
Air deflector Horizontal / Vertical Manual / Manual
Air filter Washable, easy access
Compressor Rotary
Refrigerant amount charged at shipment lbs. (kg) R22: 2.96 (1.34)
Refrigerant control Capillary tube
Refrigerant tubing connections Flare type
Operation sound In-Hi / Me / Lo dB-A 37 / 34 / 31
Out-Hi dB-A 49
Max. allowable tubing length at shipment ft. (m) 33 (10)
Limit of tubing length ft. (m) 65 (20)
Limit of elevation difference ft. (m) Outdoor unit is higher than indoor unit: 23 (7)
between the 2 units Outdoor unit is lower than indoor unit: 23 (7)
Refrigerant tube o.d. Narrow tube in. (mm) 1/4 (6.35)
Wide tube in. (mm) 1/2 (12.7)
Refrigerant tube kit Optional
Accessories —
Indoor unit Outdoor unit
Height in. (mm) 26-25/32 (680) 20-7/8 (530)
Width in. (mm) 43-5/16 (1,100) 29-17/32 (750)
Depth in. (mm) 8-15/32 (215) 11-1/32 (280)
Net weight lbs. (kg) 66.1 (30.0) 92.6 (42.0)
Shipping volume cu. ft. (cu. m) 11.6 (0.33) 6.7 (0.19)
Shipping weight (Approx.) lbs. (kg) 90.4 (41.0) 99.2 (45.0)
PerformanceElectrical Rating
Features
Dimensions & Weight
2. SPECIFICATIONS
Unit Specifications
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Outside air temperature 95°F DB/75°F WB
Indoor unit entering air temperature 80°F DB/67°F WB
Heating: Outside air temperature 47°F DB/43°F WB
Indoor unit entering air temperature 70°F DB
092-290S/M(Basic)00.12.1310:26AMページ2

3WM–700701
Model No. Indoor unit FH1822
Outdoor unit CH1822
Cooling Heating
Capacity BTU/h 16,500 / 16,000 18,000 / 17,600
kW 4.84 / 4.69 5.27 / 5.16
Air circulation (High) cu. ft./min. 440 / 420
Moisture removal (High) Pints/h 5.3 / 5.2
Phase, Frequency Hz Single, 60
Voltage rating V 230 / 208 230 / 208
Available voltage range V 187 to 253 187 to 253
Running amperes A 8.0 / 8.6 8.0 / 8.6
Power input W 1,790 / 1,740 1,790 / 1,750
Power factor % 97 / 97 97 / 97
Starting amperes A 52
S.E.E.R. (H.S.P.F.) BTU/Wh 10.0 / 10.0 (6.8 / 6.8)
Heater element kW — 3.3 / 2.7
Controls Microprocessor
Control unit Indoor unit
Temperature control IC thermostat
Timer ON/OFF, 12-hours
Fan speeds Indoor / Outdoor 3 and Auto / 1
Air deflector Horizontal / Vertical Manual / Manual
Air filter Washable, easy access
Compressor Rotary
Refrigerant amount charged at shipment lbs. (kg) R22: 4.25 (1.93)
Refrigerant control Capillary tube
Refrigerant tubing connections Flare type
Operation sound In-Hi / Me / Lo dB-A 47 / 44 / 40
Out-Hi dB-A 55
Max. allowable tubing length at shipment ft. (m) 33 (10)
Limit of tubing length ft. (m) 65 (20)
Limit of elevation difference ft. (m) Outdoor unit is higher than indoor unit: 23 (7)
between the 2 units Outdoor unit is lower than indoor unit: 23 (7)
Refrigerant tube o.d. Narrow tube in. (mm) 1/4 (6.35)
Wide tube in. (mm) 5/8 (15.88)
Refrigerant tube kit Optional
Accessories —
Indoor unit Outdoor unit
Height in. (mm) 26-25/32 (680) 24-13/16 (630)
Width in. (mm) 43-5/16 (1,100) 32-11/16 (830)
Depth in. (mm) 8-15/32 (215) 12-13/32 (315)
Net weight lbs. (kg) 70.5 (32.0) 134.5 (61.0)
Shipping volume cu. ft. (cu. m) 11.7 (0.33) 10.3 (0.29)
Shipping weight (Approx.) lbs. (kg) 97.0 (44.0) 143.3 (65.0)
PerformanceElectrical Rating
Features
Dimensions & Weight
Unit Specifications (cont’d)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Outside air temperature 95°F DB/75°F WB
Indoor unit entering air temperature 80°F DB/67°F WB
Heating: Outside air temperature 47°F DB/43°F WB
Indoor unit entering air temperature 70°F DB
092-290S/M(Basic)00.12.1310:26AMページ3

4WM–700701
3. DIMENSIONAL DATA
Indoor Unit: FH1222, FH1822
Xxxxx
Xxxxxxxxxxxxx
xxxxxxxxxxxxx
xxxxxxxxxxxxx
Xxxxxxxxxxxxx
xxxxxxxxxxxxx
xxxxxxxxxxxxx
43-5/16
42-1/8
26-25/32
22-17/32 3-3/41/2
8-15/32
5-29/32
2-1/8
15/32
8-1/32
3/4 2-9/32
22-27/32
23-31/32
7-9/16
3-5/32 3-15/16
5-25/32
➀ Narrow tube
➁ Wide tube
Drain O.D. 23/32
Model No. FH1222 FH1822
➀Narrow tube in. 1/4 1/4
➁Wide tube in. 1/2 5/8
092-290S/M(Basic)00.12.1310:26AMページ4

5WM–700701
Outdoor Unit: CH1222
4 ×15/32 dia. hole
Air intake
Air discharge
23-15/16 2-3/8
29-17/32
Check port
2-1/4 1-3/16 9-27/32
20-7/8
21/32
3-23/32 2-3/8
1/4" narrow tubing
service valve
1/2" wide tubing
service valve
10-23/32
11-7/8
Air
intake
Outdoor Unit: CH1822
Check port
1/4" narrow tubing
service valve
5/8" wide tubing
service valve
2-3/8
3-3/4
11-7/32
1-3/162-1/432-11/16
3/4
24-13/16
Air discharge
Air
intake
Air intake
21-3/16 5-3/4
12-3/12
13-1/4
4 ×15/32 dia. hole
092-290S/M(Basic)00.12.1310:26AMページ5

6WM–700701
4. COOLING CAPACITY
230V
FH1222 / CH1222
TC: Total Cooling Capacity (BTU/H)
SHC: Sensible Heat Capacity (BTU/H)
kW: Compressor Input (kW)
Remarks: Rating conditions (* mark) are: Outdoor ambient temperature 95°F DB
Indoor unit entering air temperature 80°F DB/67°F WB
Rating Capacity: 11,400 BTU/H Air Flow Rate: 350 CFM
Evaporator Condenser
Ent. Temp. °F/(°C) Ambient Temp. °F/(°C)
WB DB 75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 11,290 10,770 10,260 9,680 8,890
kW 0.89 0.97 1.05 1.14 1.25
59 72 (22.2) SHC 8,900 8,650 8,410 8,140 7,790
(15.0) 76 (24.4) SHC 10,200 9,960 9,720 9,450 8,890
80 (26.7) SHC 11,290 10,770 10,260 9,680 8,890
84 (28.9) SHC 11,290 10,770 10,260 9,680 8,890
88 (31.1) SHC 11,290 10,770 10,260 9,680 8,890
TC 11,670 11,310 10,860 10,270 9,460
kW 0.89 0.98 1.07 1.16 1.28
63 72 (22.2) SHC 7,340 7,180 6,990 6,740 6,400
(17.2) 76 (24.4) SHC 8,650 8,490 8,300 8,040 7,700
80 (26.7) SHC 10,010 9,850 9,660 9,410 9,070
84 (28.9) SHC 11,320 11,160 10,860 10,270 9,460
88 (31.1) SHC 11,670 11,310 10,860 10,270 9,460
TC 11,990 11,800 *11,400 10,770 10,030
kW 0.90 0.99 1.08 1.18 1.31
67 72 (22.2) SHC 5,750 5,670 5,510 5,270 4,980
(19.4) 76 (24.4) SHC 7,060 6,980 6,820 6,570 6,290
80 (26.7) SHC 8,420 8,340 8,180 7,940 7,650
84 (28.9) SHC 9,720 9,650 9,490 9,240 8,960
88 (31.1) SHC 11,030 10,950 10,790 10,550 10,030
TC 12,370 12,160 11,860 11,320 10,660
kW 0.91 1.00 1.10 1.21 1.33
71 72 (22.2) SHC 4,110 4,040 3,930 3,730 3,500
(21.7) 76 (24.4) SHC 5,410 5,340 5,230 5,040 4,810
80 (26.7) SHC 6,780 6,700 6,590 6,400 6,170
84 (28.9) SHC 8,080 8,010 7,900 7,710 7,480
88 (31.1) SHC 9,390 9,310 9,200 9,010 8,780
TC 12,610 12,470 12,200 11,760 11,290
kW 0.93 1.02 1.11 1.24 1.37
75 76 (24.4) SHC 3,790 3,750 3,660 3,520 3,370
(23.9) 80 (26.7) SHC 5,160 5,110 5,020 4,880 4,730
84 (28.9) SHC 6,460 6,420 6,330 6,190 6,040
88 (31.1) SHC 7,770 7,720 7,630 7,490 7,340
092-290S/M(Basic)00.12.1310:26AMページ6

7WM–700701
208V
FH1222 / CH1222
TC: Total Cooling Capacity (BTU/H)
SHC: Sensible Heat Capacity (BTU/H)
kW: Compressor Input (kW)
Remarks: Rating conditions (* mark) are: Outside ambient temperature 95°F DB
Indoor unit entering air temperature 80°F DB/67°F WB
Rating Capacity: 11,200 BTU/H Air Flow Rate: 340 CFM
Evaporator Condenser
Ent. Temp. °F/(°C) Ambient Temp. °F/(°C)
WB DB 75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 11,090 10,580 10,080 9,510 8,740
kW 0.88 0.96 1.04 1.13 1.24
59 72 (22.2) SHC 8,710 8,470 8,240 7,970 7,620
(15.0) 76 (24.4) SHC 9,980 9,740 9,510 9,240 8,740
80 (26.7) SHC 11,090 10,580 10,080 9,510 8,740
84 (28.9) SHC 11,090 10,580 10,080 9,510 8,740
88 (31.1) SHC 11,090 10,580 10,080 9,510 8,740
TC 11,470 11,110 10,670 10,090 9,300
kW 0.89 0.97 1.06 1.15 1.27
63 72 (22.2) SHC 7,200 7,040 6,850 6,600 6,270
(17.2) 76 (24.4) SHC 8,470 8,310 8,120 7,870 7,540
80 (26.7) SHC 9,800 9,640 9,450 9,200 8,870
84 (28.9) SHC 11,070 10,910 10,670 10,090 9,300
88 (31.1) SHC 11,470 11,110 10,670 10,090 9,300
TC 11,780 11,590 *11,200 10,580 9,860
kW 0.89 0.98 1.07 1.17 1.29
67 72 (22.2) SHC 5,640 5,560 5,410 5,170 4,890
(19.4) 76 (24.4) SHC 6,910 6,840 6,680 6,440 6,160
80 (26.7) SHC 8,240 8,170 8,010 7,770 7,490
84 (28.9) SHC 9,520 9,440 9,280 9,040 8,760
88 (31.1) SHC 10,790 10,710 10,560 10,310 9,860
TC 12,150 11,950 11,650 11,120 10,470
kW 0.90 0.99 1.09 1.20 1.32
71 72 (22.2) SHC 4,040 3,960 3,860 3,670 3,440
(21.7) 76 (24.4) SHC 5,310 5,240 5,130 4,940 4,710
80 (26.7) SHC 6,640 6,570 6,460 6,270 6,040
84 (28.9) SHC 7,910 7,840 7,730 7,540 7,320
88 (31.1) SHC 9,190 9,110 9,000 8,820 8,590
TC 12,390 12,250 11,980 11,560 11,090
kW 0.92 1.01 1.10 1.23 1.35
75 76 (24.4) SHC 3,730 3,680 3,600 3,460 3,310
(23.9) 80 (26.7) SHC 5,060 5,010 4,930 4,790 4,640
84 (28.9) SHC 6,330 6,290 6,200 6,060 5,910
88 (31.1) SHC 7,600 7,560 7,470 7,330 7,180
092-290S/M(Basic)00.12.1310:26AMページ7

8WM–700701
230V
FH1822 / CH1822
TC: Total Cooling Capacity (BTU/H)
SHC: Sensible Heat Capacity (BTU/H)
kW: Compressor Input (kW)
Remarks: Rating conditions (* mark) are: Outside ambient temperature 95°F DB
Indoor unit entering air temperature 80°F DB/67°F WB
Rating Capacity: 16,500 BTU/H Air Flow Rate: 440 CFM
Evaporator Condenser
Ent. Temp. °F/(°C) Ambient Temp. °F/(°C)
WB DB 75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 16,340 15,590 14,850 14,010 12,870
kW 1.29 1.41 1.53 1.66 1.82
59 72 (22.2) SHC 11,990 11,620 11,250 10,840 10,300
(15.0) 76 (24.4) SHC 13,580 13,210 12,840 12,430 11,890
80 (26.7) SHC 15,250 14,870 14,510 14,010 12,870
84 (28.9) SHC 16,340 15,590 14,850 14,010 12,870
88 (31.1) SHC 16,340 15,590 14,850 14,010 12,870
TC 16,900 16,370 15,720 14,870 13,700
kW 1.30 1.43 1.55 1.69 1.86
63 72 (22.2) SHC 10,020 9,780 9,490 9,100 8,580
(17.2) 76 (24.4) SHC 11,620 11,370 11,080 10,690 10,170
80 (26.7) SHC 13,280 13,040 12,740 12,360 11,840
84 (28.9) SHC 14,870 14,630 14,330 13,950 13,430
88 (31.1) SHC 16,460 16,220 15,720 14,870 13,700
TC 17,360 17,080 *16,500 15,590 14,520
kW 1.31 1.44 1.57 1.71 1.90
67 72 (22.2) SHC 7,990 7,880 7,630 7,260 6,820
(19.4) 76 (24.4) SHC 9,590 9,470 9,230 8,850 8,420
80 (26.7) SHC 11,250 11,130 10,890 10,520 10,080
84 (28.9) SHC 12,840 12,720 12,480 12,110 11,670
88 (31.1) SHC 14,430 14,320 14,070 13,700 13,260
TC 17,900 17,610 17,160 16,380 15,430
kW 1.33 1.45 1.59 1.76 1.94
71 72 (22.2) SHC 5,910 5,790 5,630 5,330 4,980
(21.7) 76 (24.4) SHC 7,500 7,390 7,220 6,930 6,570
80 (26.7) SHC 9,160 9,050 8,880 8,590 8,240
84 (28.9) SHC 10,760 10,640 10,470 10,180 9,830
88 (31.1) SHC 12,350 12,230 12,060 11,770 11,420
TC 18,250 18,050 17,660 17,030 16,340
kW 1.35 1.48 1.62 1.80 1.99
75 76 (24.4) SHC 5,430 5,360 5,220 5,010 4,780
(23.9) 80 (26.7) SHC 7,090 7,020 6,890 6,670 6,440
84 (28.9) SHC 8,680 8,610 8,480 8,270 8,030
88 (31.1) SHC 10,270 10,210 10,070 9,860 9,630
092-290S/M(Basic)00.12.1310:26AMページ8

9WM–700701
208V
FH1822 / CH1822
TC: Total Cooling Capacity (BTU/H)
SHC: Sensible Heat Capacity (BTU/H)
kW: Compressor Input (kW)
Remarks: Rating conditions (* mark) are: Outside ambient temperature 95°F DB
Indoor unit entering air temperature 80°F DB/67°F WB
Rating Capacity: 16,000 BTU/H Air Flow Rate: 420 CFM
Evaporator Condenser
Ent. Temp. °F/(°C) Ambient Temp. °F/(°C)
WB DB 75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 15,840 15,120 14,400 13,580 12,480
kW 1.26 1.38 1.50 1.62 1.79
59 72 (22.2) SHC 11,600 11,240 10,880 10,480 9,960
(15.0) 76 (24.4) SHC 13,130 12,770 12,410 12,010 11,490
80 (26.7) SHC 14,730 14,370 14,010 13,580 12,480
84 (28.9) SHC 15,840 15,120 14,400 13,580 12,480
88 (31.1) SHC 15,840 15,120 14,400 13,580 12,480
TC 16,380 15,870 15,250 14,420 13,280
kW 1.28 1.40 1.52 1.66 1.82
63 72 (22.2) SHC 9,710 9,470 9,190 8,810 8,310
(17.2) 76 (24.4) SHC 11,240 11,000 10,720 10,340 9,840
80 (26.7) SHC 12,840 12,600 12,310 11,940 11,440
84 (28.9) SHC 14,370 14,130 13,840 13,470 12,970
88 (31.1) SHC 15,900 15,660 15,250 14,420 13,280
TC 16,830 16,560 *16,000 15,120 14,080
kW 1.29 1.41 1.54 1.68 1.86
67 72 (22.2) SHC 7,760 7,640 7,410 7,040 6,620
(19.4) 76 (24.4) SHC 9,290 9,170 8,930 8,570 8,150
80 (26.7) SHC 10,880 10,770 10,530 10,170 9,750
84 (28.9) SHC 12,410 12,300 12,060 11,700 11,280
88 (31.1) SHC 13,940 13,830 13,590 13,230 12,810
TC 17,360 17,070 16,640 15,890 14,960
kW 1.30 1.42 1.56 1.72 1.90
71 72 (22.2) SHC 5,750 5,640 5,470 5,190 4,850
(21.7) 76 (24.4) SHC 7,280 7,170 7,000 6,720 6,380
80 (26.7) SHC 8,880 8,770 8,600 8,320 7,980
84 (28.9) SHC 10,400 10,290 10,130 9,850 9,500
88 (31.1) SHC 11,930 11,820 11,660 11,380 11,030
TC 17,700 17,500 17,120 16,510 15,840
kW 1.32 1.45 1.59 1.76 1.95
75 76 (24.4) SHC 5,280 5,210 5,080 4,880 4,650
(23.9) 80 (26.7) SHC 6,880 6,810 6,680 6,480 6,250
84 (28.9) SHC 8,410 8,340 8,210 8,000 7,780
88 (31.1) SHC 9,940 9,870 9,740 9,530 9,310
092-290S/M(Basic)00.12.1310:26AMページ9

10 WM–700701
5. HEATING CAPACITY
FH1222 / CH1222
230V
Indoor Entering Air Temperature 70°F
Temperature of Air Entering Outdoor Coil
(°F DB at 75% RH)
Heating Capacity (BTU/h)
30,000
25,000
20,000
15,000
10,000
5,000
23
(–5)
32
(0)
41
(5)
50 59
(15)
68
(20)
75°F
(23.7°C)
47
(8.3)
17
(–8.3)
12,500
22,740
Heat-pump with back-up heater
Heat-pump capacity
092-290S/M(Basic)00.12.1310:26AMページ10

11 WM–700701
FH1222 / CH1222
208V
Indoor Entering Air Temperature 70°F
Temperature of Air Entering Outdoor Coil
(°F DB at 75% RH)
Heating Capacity (BTU/h)
30,000
25,000
20,000
15,000
10,000
5,000
23
(–5)
32
(0)
41
(5)
50 59
(15)
68
(20)
75°F
(23.7°C)
47
(8.3)
17
(–8.3)
12,200
20,560
Heat-pump with back-up heater
Heat-pump capacity
092-290S/M(Basic)00.12.1310:26AMページ11

12 WM–700701
FH1822 / CH1822
230V
Temperature of Air Entering Outdoor Coil
(°F DB at 75% RH)
Heating Capacity (BTU/h)
30,000
25,000
20,000
15,000
10,000
5,000
23
(–5)
32
(0)
41
(5)
50 59
(15)
68
(20)
75°F
(23.7°C)
47
(8.3)
17
(–8.3)
29,260
35,000
18,000
Indoor Entering Air Temperature 70°F
Heat-pump with back-up heater
Heat-pump capacity
092-290S/M(Basic)00.12.1310:26AMページ12

13 WM–700701
FH1822 / CH1822
208V
Temperature of Air Entering Outdoor Coil
(°F DB at 75% RH)
Heating Capacity (BTU/h)
30,000
25,000
20,000
15,000
10,000
5,000
23
(–5)
32
(0)
41
(5)
50 59
(15)
68
(20)
75°F
(23.7°C)
47
(8.3)
17
(–8.3)
26,810
35,000
17,600
Indoor Entering Air Temperature 70°F
Heat-pump with back-up heater
Heat-pump capacity
092-290S/M(Basic)00.12.1310:26AMページ13

14 WM–700701
Heat exchanger
Wide tube
Accumulator
Compressor
Wide tube
service
valve
DrierCheck
valve
Strainer
Capillary tube Capillary
Muffler
4-way
valve
Narrow tube
service
valve
O.D.
1/2"
(12.7 mm)
Narrow tube
O.D.
1/4"
(6.35 mm)
Heat exchanger
Check
port
( )
Indoor unit Outdoor unit
Heat exchanger
Wide tube
Accumulator
Compressor
Wide tube
service
valve
DrierCheck
valve
Strainer
Capillary tube
Capillary
Muffler
4-way
valve
Narrow tube
service
valve
O.D.
1/2"
(12.7 mm)
Narrow tube
O.D.
1/4"
(6.35 mm)
Heat exchanger
Check
port
( )
Indoor unit Outdoor unit
6. REFRIGERANT FLOW DIAGRAM
FH1222 / CH1222
Cooling Cycle
Heating Cycle
092-290S/M(Basic)00.12.1310:26AMページ14

15 WM–700701
Heat exchanger
Wide tube
Accumulator
Compressor
Wide tube
service
valve
DrierCheck
valve
Strainer
Capillary
Muffler
4-way
valve
Narrow tube
service
valve
O.D.
5/8"
(15.88 mm)
Narrow tube
O.D.
1/4"
(6.35 mm)
Heat exchanger
Check
port
( )
P
Discharge pressure
regulator
Capillary
Modulator
Indoor unit Outdoor unit
Heat exchanger
Wide tube
Accumulator
Compressor
Wide tube
service
valve
DrierCheck
valve
Strainer
Capillary
Muffler 4-way
valve
Narrow tube
service
valve
O.D.
5/8"
(15.88 mm)
Narrow tube
O.D.
1/4"
(6.35 mm)
Heat exchanger
Check
port
( )
P
Discharge pressure
regulator
Capillary
Modulator
Indoor unit Outdoor unit
FH1822 / CH1822
Cooling Cycle
Heating Cycle
092-290S/M(Basic)00.12.1310:26AMページ15
