Titan TTT933CHN User manual

Cordless chainsaw
36V 35cm
Original Instructions_YAT_TITAN_MNL_36V Chain saw_BXIM220_TTT933CHN_GB-V01
TTT933CHN
CAUTION: Read the instructions before using the product.
EN

02
EN
These instructions are for your safety. Please read through them thoroughly
before use and retain them for future reference.
Safety information
Your product
Before you start
03
19
21
Getting started... 02
In more detail... 29
30
33
42
48
49
50
52
53
54
56
Product functions
Operation
Care and maintenance
Trouble shooting
Recycling and disposal
Guarantee
Customer Care and Technical Helpline
Availability of Spare Parts
Technical specications
Declaration of conformity
Let’s
get started...

TTT933CHN
03
Getting started...
EN
Safety warnings
General power tool safety warnings
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
Safety information

TTT933CHN
04
Getting started...
EN Safety information
tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
2. Use personal protective equipment. Always wear

TTT933CHN
05
Getting started...
EN
Safety information
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that
have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.
Power tool use and care

TTT933CHN
06
Getting started...
EN
1. Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
2. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
Safety information

TTT933CHN
07
Getting started...
EN
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
Battery tool use and care
1. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used
with another battery pack.
2. Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or a re.
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
5. Do not use battery pack or tool that is damaged
or modied. Damaged or modied batteries may
exhibit unpredictable behaviour resulting in re,
Safety information

TTT933CHN
08
Getting started...
EN
explosion or risk of injury.
6. Do not expose a battery pack or tool to re
or excessive temperature. Exposure to re or
temperature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instructions.
Charging improperly or at temperatures outside
the specied range may damage the battery and
increase the risk of re.
Service
1. Have your power tools serviced by a qualied
repair person using only identical replacement
parts. This will ensure that safety of the power tool is
maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
Safety instructions for chain saws
General chain saw safety warnings:
1. Keep all parts of the body away from the saw
chain when the chain saw is operating. Before
you start the chain saw, make sure the saw chain
is not contacting anything. A moment of inattention
while operating chain saws may cause entanglement
of your clothing or body with the saw chain.
2. Always hold the chain saw with your right hand
on the rear handle and your left hand on the front
handle. Holding the chain saw with a reversed hand
Safety information

TTT933CHN
09
Getting started...
EN
conguration increases the risk of personal injury and
should never be done.
3. Hold the chain saw by insulated gripping
surfaces only, because the saw chain may
contact hidden wiring. Saw chains contacting a
"live" wire may make exposed metal parts of the
power tool "live" and could give the operator an
electric shock.
4. Wear eye protection. Further protective
equipment for hearing, head, hands, legs and feet
is recommended. Adequate protective equipment
will reduce personal injury from ying debris or
accidental contact with the saw chain.
5. Do not operate a chain saw in a tree, on a
ladder, from a rooftop, or any unstable support.
Operation of a chain saw in this manner could result
in serious personal injury.
6. Always keep proper footing and operate the
chain saw only when standing on xed, secure
and level surface. Slippery or unstable surfaces
may cause a loss of balance or control of the chain
saw.
7. When cutting a limb that is under tension be alert
for spring back. When the tension in the wood
bres is released, the spring loaded limb may
strike the operator and/or throw the chain saw out of
control.
8. Use extreme caution when cutting brush and
saplings. The slender material may catch the saw
chain and be whipped toward you or pull you off
balance.
Safety information

TTT933CHN
10
Getting started...
EN
9. Carry the chain saw by the front handle with the
chain saw switched off and away from your body.
When transporting or storing the chain saw,
always t the guide bar cover. Proper handling of
the chain saw will reduce the likelihood of accidental
contact with the moving saw chain.
10. Follow instructions for lubricating, chain
tensioning and changing the bar and chain.
Improperly tensioned or lubricated chain may either
break or increase the chance for kickback.
11. Cut wood only. Do not use chain saw for
purposes not intended. For example: do not use
chain saw for cutting metal, plastic, masonry or
non-wood building materials. Use of the chain saw
for operations different than intended could result in
a hazardous situation.
12. Do not attempt to fell a tree until you have an
understanding of the risks and how to avoid
them. Serious injury could occur to the operator or
bystanders while felling a tree.
13. Follow all instructions when clearing jammed
material, storing or servicing the chain saw.
Make sure the switch is off and the battery pack
is removed. Unexpected actuation of the chain saw
while clearing jammed material or servicing may
result in serious personal injury.
14. Keep handles dry, clean, and free from oil and
grease. Greasy, oily handles are slippery causing
loss of control.
15. Pay attention to national and local regulations.
National and local regulations may restrict the use of
Safety information

TTT933CHN
11
Getting started...
EN
this product.
16. Only use replacement guide bars and saw chains
specied by the manufacturer or equivalent
replacements. Using non-approved cutting
attachments can result in personal injuries and
damage to property.
17. Before using the product and after any impact or
dropping, check for signs of wear or damage and
repair as necessary.
18. Never remove or modify any guard or safety
component. Ensure that guards and other safety
components necessary for machine operation are
in position, in good working condition and properly
maintained to avoid injuries.
19. Training of all operation is necessary for rst-time
and inexperienced operator.
20. Remove branches in section.
Causes and operator prevention of kickback
Kickback may occur when the nose or tip of the guide
bar touches an object, or when the wood closes in and
pinches the saw chain in the cut.
Tip contact in some cases may cause a sudden reverse
reaction, kicking the guide bar up and back towards the
operator.
Pinching the saw chain along the top of the guide
bar may push the guide bar rapidly back towards the
operator.
Either of these reactions may cause you to lose control
of the saw which could result in serious personal injury.
Do not rely exclusively upon the safety devices built into
Safety information

TTT933CHN
12
Getting started...
EN
your saw. As a product user, you should take several
steps to keep your cutting jobs free from accident or
injury.
Kickback is the result of tool misuse and/or incorrect
operating procedures or conditions and can be avoided
by taking proper precautions as given below:
1. Maintain a rm grip, with thumbs and ngers
encircling the chain saw handles, with both
hands on the saw and position your body and
arm to allow you to resist kickback forces.
Kickback forces can be controlled by the operator,
if proper precautions are taken. Do not let go of the
product.
2. Do not overreach and do not cut above shoulder
height. This helps prevent unintended tip contact
and enables better control of the chain saw in
unexpected situations.
3. Only use replacement guide bars and chains
specied by the manufacturer. Incorrect
replacement guide bars and saw chains may cause
chain breakage and/or kickback.
4. Follow the manufacturer’s sharpening and
maintenance instructions for the saw chain.
Decreasing the depth gauge height can lead to
increased kickback.
Additional safety warnings for battery pack
1. Battery pack needs to be charged before use.
Always refer to the charger’s instruction and charge
it properly.
2. Remove the battery pack from the product when
Safety information

TTT933CHN
13
Getting started...
EN
not in use.
3. Don’t maintain the battery pack on the charger
when not in use.
4. After extended periods of storage, it may be
necessary to charge and discharge the battery
pack several times to obtain the maximum
performance.
5. Longer life and better performance can be
obtained if the battery is charged when the air
temperature is between 18°C and 24°C. Do not
charge the battery in air temperature below 5°C
or above 40°C. This is important as it can prevent
serious damage to the battery.
6. Do not charge battery in a damp or wet location.
Following this rule will reduce the risk of electric
shock.
7. Do not disassemble the battery and avoid
mechanical damage to the battery. Risk of short
circuit and fumes may be emitted. Ensure fresh
air and seek medical assistance in the event of
discomfort.
8. When disposing of battery pack, keep the battery
pack of different electrochemical systems
separate from each other.
Vibration and noise reduction
To reduce the impact of noise and vibration
emission, limit the time of operation, use low-
vibration and low-noise operating modes as well as
wear personal protective equipment.
Take the following points into account to minimise the
Safety information

TTT933CHN
14
Getting started...
EN
vibration and noise exposure risks:
1. Only use the product as intended by its design and
these instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure
they are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
(HAVS) e.g. ngers going white; as well as specic
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear
protective gloves and keep your hands warm.
Emergency
Familiarise yourself with the use of this product
by means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage
to property.
2. Switch the product off and remove the battery
Safety information

TTT933CHN
15
Getting started...
EN
pack if there are malfunctions. Have the product
checked by a qualied professional and repaired, if
necessary, before you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and
design of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3. Danger of injury and property damage caused by
ying objects.
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Safety information

TTT933CHN
16
Getting started...
EN
Symbols
On the product, the rating label and within these instructions you will nd
among others the following symbols and abbreviations. Familiarise yourself
with them to reduce hazards like personal injuries and damage to property.
V Volt, (direct current voltage) mAh Milliampere per hour
/min or min-1 Per minute °C Degree Celsius
g Gram kg Kilogram
mm Millimetre m Metre
cm Centimetre m/s² Metres per second squared
dB(A) Decibel (A-rated) Lock / to tighten or secure.
Read the instruction manual.
Unlock / to loosen.
Note / Remark.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and
week of manufacturing (Wyy)
Wear hearing protection.
Wear eye protection.
Wear a dust mask.
Wear head protection, where there is a risk of falling objects.
Wear respiratory protection.
Wear protective gloves.
Wear protective, slip-resistant footwear.
Wear tight-tted protective clothes.
Use appropriate protection for foot-leg and hand-arm.
Switch the product off and remove battery pack before assembly,
cleaning, adjustments, maintenance, storage and transportation.
Safety information

TTT933CHN
17
Getting started...
EN
This product is of protection class III.
Do not expose the product to rain or wet conditions (moisture).
Keep hands away from moving cutting device!
Objects thrown by the product could hit the user or other
bystanders. Always ensure that other people and pets remain
at a safe distance from the product when it is in operation.
In general, children must not come near the area where the
product is.
Minimum distance is 10m.
Kickback! Tip contact may cause the guide bar to move
suddenly upward and backwards what may cause serious injury
to user.
Contact of the guide bar tip with any object should be avoided.
Always use the product with two hands. Do not use one handed
when operating the product.
Chain oil ll.
Correct direction of cutting-teeth.
Beware of chain saw kickback and
avoid contact with bar tip
Cutting of ngers or hand.
Guaranteed sound power level value in 102 dB.
WEEE symbol. Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling
advice.
Safety information

TTT933CHN
18
Getting started...
EN
Crossed out dust bin. Batteries and battery packs should not
be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or local store for
recycling advice.
Do not dispose of battery packs in rivers or immerse in water.
Do not dispose of battery packs in re. They will explode and
cause injury.
max.40oC
Do note expose battery packs to heat in excess of 40 ºC.
Do not charge or store the battery pack in temperatures below 5
°C (41 °F) and above 40 °C (104°F).
The product complies with the applicable European directives
and an evaluation method of conformity for these directives was
done.
UK Conformity Assessed.
Safety information

TTT933CHN
19
Getting started...
EN
Your product
Your product
23
21
123
97
9a
9b
10
11
12
13a 13 14 15
16
17
18
19
20
22c 22b
22
22a
6
5
4
8
1. Rear handle
2. Front handle
3. Front safeguard (chain brake lever)
4. Spiked bumper
5. Oiling port
6. Mounting bolt
7. Drive sprocket
8. Saw chain
9. Guide bar
a.Sprocket wheel
b.Lubrication hole
c.Turning wheel*
10. Chain tension wheel
11. Locking wheel
12. Chain saw cover
a.Spigot*
13. Oil tank cap
a.Hand ring
14. Lock-off button
15. On/off switch
16. Rear safeguard
17. Battery docking port
18. Air vents
19. Oil level window
20. Motor housing
a.Motor*

TTT933CHN
20
Getting started...
EN
21. Guide bar cover
22. Battery pack
a.Release button
b.Battery capacity indicators
c.Battery capacity button
23. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
Your product
