Titan TTB426GDO User manual

POLE PRUNER 750W TTB426GDO
24month
Manufacturer's
Warranty
SAFETY AND OPERATING MANUAL
Original instructions

Congratulations on your purchase of a power tool from Titan Power
Tools (UK) Ltd. We want you to continue getting the best performance from
it so this handbook includes information on safety, handling and care. Please
retain this handbook in case you need to refer to any of the information in the
future.
Your power tool comes with a 24-month guarantee, so should it develop
a fault within this period contact your retailer.
GUARANTEE
This product carries a guarantee of 24 months. If your product develops a fault
within this period, you should, in the rst instance contact the retailer where the item was
purchased.
This guarantee specically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
For any enquiries relating to the guarantee please refer to your retailer.

POLE PRUNER 750W TTB426GDO
SAFETY INSTRUCTIONS
Warnings! Read this instruction carefully before operating this pruner.
Make sure that you are familiar with the controls and properly operate the
machine. Following this instructions, you can reduce the risk of re, electric shock
and personal injury.
GENERAL SAFETY INSTRUCTIONS
Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury! Save all warnings and
instructions for future reference. The term "garden power tool" in the warnings refers to
your mains-operated (corded) garden power tool or battery-operated (cordless) garden
power tool!
1. This garden power tool is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction
concerning use of the garden power tool by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the garden power
tool.
3. The garden power tool must be kept out of reach of children.
4. Store the instruction manual in a location accessible to all users of the garden power
tool and always include the instruction manual when passing it on to other users.
5. Instruct inexperienced persons on the safe use of this garden power tool using this
instruction manual.
Work area safety
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate garden power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Garden power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while operating a garden power tool.
Distractions can cause you to lose control.
Electrical safety
1. Garden power tool plugs must match the outlet. Never modify the plug
in any way. Do not use any adapter plugs with earthed (grounded) garden
power tools. Unmodied plugs and matching outlets will reduce risk of electric
shock.
2. Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
3. Do not expose garden power tools to rain or wet conditions. Water entering a
garden power tool will increase the risk of electric shock.
4. Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the garden power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of electric
shock.
5. When operating a garden power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.

6. If operating a garden power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces the risk
of electric shock.
Personal safety
1. Stay alert, watch what you are doing and use common sense when
operating a garden power tool. Do not use a garden power tool while you
are tired or under the inuence of drugs, alcohol or medication. A moment of
inattention while operating garden power tools may result in serious personal injury.
2. Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
3. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying garden power tools with your nger on the switch or energising garden
power tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before turning the garden power tool
on. A wrench or a key left attached to a rotating part of the garden power tool may
result in personal injury.
5. Do not overreach. Keep proper footing and balance at all times. This enables
better control of the garden power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
7. If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards.
Garden power tool use and care
1. Do not force the garden power tool. Use the correct garden power tool for
your application. The correct garden power tool will do the job better and safer at
the rate for which it was designed.
2. Do not use the garden power tool if the switch does not turn it on and off.
Any garden power tool that cannot be controlled with the switch is dangerous and
must be repaired.
3. Disconnect the plug from the power source and/or the battery pack from the
garden power tool before making any adjustments, changing accessories,
or storing garden power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
4. Store idle garden power tools out of the reach of children and do not allow
persons unfamiliar with the garden power tool or these instructions to
operate the garden power tool. Garden power tools are dangerous in the hands of
untrained users.
5. Maintain garden power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the garden
power tool’s operation. If damaged, have the garden power tool repaired
before use. Many accidents are caused by poorly maintained garden power tools.
6. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.

POLE PRUNER 750W TTB426GDO
7. Use the garden power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working conditions and the
work to be performed. Use of the garden power tool for operations different from
those intended could result in a hazardous situation.
PRUNER SAFETY INSTRUCTIONS
1. Interrupt your work when you feel tired or exhausted. Make regular breaks
to regenerate. A moment of inattention while operating the garden power tool may
result in serious personal injury.
2. Keep all parts of the body away from the saw chain. Do not remove cut
material or hold material to be cut when saw chain is moving. Make sure
the switch is off when clearing jammed material. A moment of inattention while
operating the garden power tool may result in serious personal injury.
3. Hold the garden power tool by insulated gripping surfaces only, because the
saw chain may contact hidden wiring or its own cord. Saw chains contacting a
"live" wire may make exposed metal parts of the garden power tool "live" and could
give the operator an electric shock.
4. Keep cable away from cutting area. During operation the cable may be hidden in
shrubs and can be accidentally cut by the blade.
5. Keep all parts of the body away from the saw chain when the garden power
tool is operating. Before you start the garden power tool, make sure the saw
chain is not contacting anything. A moment of inattention while operating garden
power tools may cause entanglement of your clothing or body with the saw chain.
6. Always hold the garden power tool with both hands on the handle and soft
grip. Holding the garden power tool with only one hand or on parts not intended for
that increases the risk of personal injury and should never be done.
7. Wear safety glasses and hearing protection. Further protective equipment
for head, hands, legs and feet is recommended. Adequate protective clothing
will reduce personal injury by ying debris or accidental contact with the saw chain.
8. Do not operate a garden power tool in a tree. Operation of a garden power tool
while up in a tree may result in personal injury.
9. Always keep proper footing and operate the garden power tool only when
standing on xed, secure and level surface. Slippery or unstable surfaces such
as ladders may cause a loss of balance or control of the garden power tool.
10. When cutting a limb that is under tension be alert for spring back. When the
tension in the wood bres is released the spring loaded limb may strike the operator
and/or throw the garden power tool out of control.
11. Use extreme caution when cutting brush and saplings. The slender material
may catch the saw chain and be whipped toward you or pull you off balance.
12. Carry the garden power tool by the soft grip with the garden power tool
switched off and away from your body. When transporting or storing the
garden power tool always t the guide bar cover. Proper handling of the garden
power tool will reduce the likelihood of accidental contact with the moving saw chain.
Service
Have your garden power tool serviced by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the garden power tool is
maintained.

13. Follow instructions for lubricating, chain tensioning and changing
accessories. Improperly tensioned or lubricated chain may either break or increase
the chance for kickback.
14. Keep handles dry, clean, and free from oil and grease. Greasy, oily handles are
slippery causing loss of control.
15. Cut wood only. Do not use garden power tool for purposes not intended. For
example: do not use garden power tool for cutting plastic, masonry or non-
wood building materials. Use of the garden power tool for operations different than
intended could result in a hazardous situation.
16. Pay attention to national and local regulations. National and local regulations
may restrict the use of this garden power tool.
Residual risks
Even if you are operating this garden power tool in accordance with the
provisions, residual risks will always still remain. The following dangers can
arise in connection with the structure and design of this garden power tool:
1. Health defects resulting from vibration emission if the garden power tool is being
used over longer period of time or not adequately managed and properly maintained.
2. Injuries and damage to property to due to broken accessories or hidden objects that
are suddenly dashed.
3. Injuries and damage to property to due to thrown and fallen objects.
Causes and operator prevention of kickback
1. Kickback may occur when the nose or tip of the guide bar touches an object, or when
the wood closes in and pinches the saw chain in the cut.
2. Tip contact in some cases may cause a sudden reverse reaction, kicking the guide bar
up and back towards the operator.
3. Pinching the saw chain along the top of the guide bar may push the guide bar rapidly
back towards the operator.
4. Either of these reactions may cause you to lose control of the saw which could result
in serious personal injury. Do not rely exclusively upon the safety devices built into
your saw. As a garden power tool user, you should take several steps to keep your
cutting jobs free from accident or injury.
5. Kickback is the result of tool misuse and/or incorrect operating procedures or
conditions and can be avoided by taking proper precautions as given below:
a). Maintain a rm grip, with thumbs and ngers encircling the garden
power tool handles, with both hands on the saw and position your body and
arm to allow you to resist kickback forces. Kickback forces can be controlled by
the operator, if proper precautions are taken. Do not let go of the garden power tool.
b). Do not overreach and do not cut above shoulder height. This helps
prevent unintended tip contact and enables better control of the garden power tool in
unexpected situations.
c). Only use replacement bars and chains specied by the manufacturer.
Incorrect replacement bars and chains may cause chain breakage and/or kickback.
d). Follow the manufacturer’s sharpening and maintenance instructions for
the saw chain. Decreasing the depth gauge height can lead to increased kickback.

POLE PRUNER 750W TTB426GDO
Emergency
1. Familiarise yourself with the use of this garden power tool by means of this
instruction manual. Memorise the safety directions and follow them to the
letter. This will help to prevent risks and hazards.
2. Always be alert when using this garden power tool, so that you can
recognise and handle risks early. Fast intervention can prevent serious injury and
damage to property.
3. Stop the engine and unplug from the mains if there are malfunctions. Have
the garden power tool checked by a qualied professional and repaired, if necessary,
before you put it into operation again.

VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help reduce
hand arm vibration syndrome injuries to power tool users. The directive requires power tool
manufacturers and suppliers to provide indicative vibration test results to enable users to make
informed decisions as to the period of time a power tool can be used safely on a daily basis and
the choice of tool. Further Advice can be found at www.hse.gov.uk
The declared vibration emission value should be used as a minimum level and should be used
with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difcult and the HSE website
has further information.
The declared vibration emission been measured in accordance with a standard listed test stated
above and may be used to compare one tool with another. The declared vibration emission value
may also be used in a preliminary assessment of exposure.
Helping to minimise your vibration exposure risk.
Maintain this tool in accordance with these instructions and keep well lubricated (where
appropriate).
Avoid using tools in temperatures of 10°C or less.
Plan your work schedule to spread any high vibration tool use across a number of days. Health
Surveillance.
Health Surveillance.
All employees should be part of an employer’s health surveillance scheme to help identity any
vibration related diseases at an early stage, prevent disease progression and help employees
stay in work.
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed.
WARNING! The vibration emission value during actual use of the power tool can differ
from the declared value depending on the ways in which the tool is used dependant on
the following examples and other variations on how the tool is used:
How the tool is used and the materials being ground or cut.
The tool being in good condition and well maintained.
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these instructions.
WARNING! identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off and when it is running idle in
addition to the trigger time). Note The use of other tools will reduce the users’ total working
period on this tool.
Vibration total values (triax vector sum) determined according to EN ISO 11680-1:
Vibration level for operation Vibration emission value ah = 2.681 m/s²
Uncertainty K = 1.5 m/s²

POLE PRUNER 750W TTB426GDO
SYMBOLS
Warning
Read the instruction manual
Double insulation
Compliance with relevant safety standards
0123
Wear eye protection
Wear ear protection
Wear helmet protection
Gloves with saw protection
Boots with saw protection, steel toecap and non-slip sole
Wear protective clothing
To avoid potential electric shock, do not use the unit in humid or wet conditions
Double insulation:
The tool is double insulated. This means that all the external metal parts are electrically insulated
from the mains power supply. This is done by placing insulation barriers between the electrical
and mechanical components making it unnecessary for the tool to be earthed.
Important note:
Be sure the supply is the same as the voltage given on the rating plate. The tool is tted with a
two-core cable and plug. Remove the mains plug from socket before carrying out any adjustment
or servicing.

Switch off! Remove plug from mains before cleaning or maintenance
Switch off! Remove plug from the mains immediately if the cable is damaged or cut.
Correct direction of cutting-teeth.
Always beware of the danger from overhead electric-power line, keep a safe
distance at least 10M from the power line.
Guaranteed sound power level
Waste electrical products should not be disposed of with household waste, please
recycle where facilities exist. Check with your local authority or retailer for recycling
advice.

POLE PRUNER 750W TTB426GDO
15
14
11
9
18
8
4
2
3
13
12
10
7
5
6
1
23
14
19
19a
15
24
21
17
20
22
16
1 Power cord
2 Handle
3 ON/OFF switch
4 Lock-off button
5 Soft grip
6 Pole
7 Locking sleeve for pole extension
8 Pole extension
9 Side cover
10 Cover insert

11 Hex screw
12 Oil tank
13 Oil tank cap
14 Guide bar
15 Saw chain
16 Tension screw
17 Spike bumper
18 Vents
19 Harness
19a Harness attachment
20 Sprocket
21 Rail
22 Tension pin
23 Guide bar protection cover
24 Multi tool
Rated voltage 230-240VAC 50Hz
Rated power 750W
No-load speed 6000/min
Chain speed 13.5m/s
Max. cutting length 180mm
Saw chain type OREGON, 91PJ033X, 8"
Chain pitch 3/8"
Number of chain links 33
Chain gauge 0.050"
Bar type OREGON, 552912, 8"
Oil tank capacity 60ml
Net Weight 3.6 kg
Cable length 3M
TECHNICAL DATA
NOISE AND VIBRATION DATA
Measured sound pressure level 90 dB(A), K=3 dB (A)
Measured sound power level 105.1 dB(A), K=2.35 dB (A)
Guaranteed sound power level 108 dB(A)
Vibration: 2.681 m/s², K=1.5m/s²

POLE PRUNER 750W TTB426GDO
The declared vibration value has been measured in accordance with a standard test method and
may be used for comparing one tool with another.
The declared vibration value may also be used in a preliminary assessment of exposure.
WARNING! The vibration emission value during actual use of the tool can differ from the
declared value depending on the ways in which the tool is used. Identify safety measures to
protect the operator that are based on an estimation of exposure in the actual conditions of use
(taking account of all parts of the operating cycle such as the times when the tool is switched off
and when it is running idle in addition to the trigger time).
The sound intensity level for the operator may exceed 85dB(A) and ear protection measures are
necessary.
ACCESSORIES
Harness 1PC
Saw chain 1PC
Multi tool 1PC

Cutter
1. ASSEMBLY INSTRUCTIONS
Your pole pruner requires installation of the guide bar, saw
chain, sprocket cover, adjustment of chain, and filling the oil
tank with lubricating oil before it is ready for operation. Do
not switch the pole pruner on until it is properly assembled.
Follow the operating instructions step-by-step and use the
pictures provided as a visual guide to easily assemble the
machine.
d). Use the screwdriver end of the multi tool (24, provided)
to turn the chain tension screw in a counter-clockwise
direction. The tension pin is moved toward the left. (See
Fig.3)
c). Spread the saw chain out with the cutting edges of the
chain pointing in the direction of rotation.
Slide the chain into the slot around the chain bar. Ensure
chain is installed in correct direction of
rotation. (See Fig.2)
1). CHAIN AND BAR ASSEMBLY
a). Use only a guide bar and saw chain according to the
technical data of the pole pruner.
b). Set the pole pruner on a suitable flat surface with the
cover facing upwards. Unscrew in counter-clockwise
direction the hex screw with Allen key (supplied) and then
remove the side cover and cover insert. (See Fig.1)
Fig. 1
Fig. 2
Fig. 3
OPERATION INSTRUCTIONS
WARNING! Read all instructions carefully. Do not
connect the pole pruner to mains supply
power before it is completely assembled. Always use glove
s during assembly.

POLE PRUNER 750W TTB426GDO
2). SAW CHAIN TENSIONING
Always check the saw chain tension before use, after
the first cuts and regularly during use, approx. every 5
cuts. Upon initial operation, new chains can lengthen
considerably. This is normal during the break-in period and
the interval between future adjustments will lengthen quickly.
e). Mount the guide bar and saw chain assembly over the
sprocket and align the slot in the guide bar with the rail.
Push the guide bar to the left towards the sprocket. Make
sure the tension pin is inserted into the lower hole (A) on the
guide bar. (See Fig.4)
f). Fit the side cover and cover insert back, tighten the screw
using the Allen key. (See Fig.5)
g). The saw chain is not yet tensioned. Tension the chain as
described under “SAW CHAIN TENSIONING”. After running
the chain saw for approx. 1 hour, adjust the chain tension.
Fig. 4
Fig. 5
WARNING! Unplug from power source before
adjusting saw chain tension.
WARNING! Cutting edges on saw chain are sharp.
Always wear protective gloves when handling chain.
WARNING! Always maintain proper chain tension.
A loose chain will increase the risk of kickback.
A loose chain may jump out of guide bar groove. This may
injure operator and damage the chain.
A loose chain will cause rapid wear to chain, chain bar, and
sprocket.
WARNING! Tensioning the chain too tightly will
overload the motor and cause damage, insufficient
tension can provoke chain derailing, whereas a correctly
tightened chain provides the best cutting characteristics and
prolonged work life. The chain life depends mainly upon
sufficient lubrication and correct tensioning.

Chain ‘tie straps’
a). Set the power tool on a suitable flat surface.
b). Use the screwdriver end of the multi tool to turn the chain
tension screw in a clockwise direction until the chain “tie
straps” are just touching the bottom edge of the guide bar.
The correct chain tension is reached when the chain can be
lifted by approx. 2-4 mm from the chain bar in the centre.
This should be done by using one hand to lift the chain
against the weight of the machine. (See Fig.6a & 6b)
B
The oil tank holds 60mI chain lubrication oil, enough to
lubricate the chain for 20-25 minutes of cutting.
The oil tank level can be checked by way of the oil level
gauge (B). Check oil level gauge prior to start-up and
regularly during operation. Refill oil when oil level is lower
than "MIN" marking. (See Fig.7)
a). Set pruner on any suitable surface with oil tank cap (13)
facing upward.
b). Clean area around the oil tank cap with cloth.
c). Add chain lubrication oil until reservoir is full. You can
use either SAE30 or SAE10.
d). Avoid dirt or debris entering oil tank, refit oil filler cap and
tighten.
Fig. 6a
Fig. 6b 3). CHAIN AND BAR LUBRICATION
WARNING! The pruner is not filled with oil. It is
essential to fill with oil before using.
Never operate the pruner without chain oil or an empty oil
tank, as this will result in extensive damage to the product.
WARNING! Never run the bar and chain without
lubrication oil. Running the saw dry or with too little oil
will decrease cutting efficiency, shorten chain saw life, and
cause rapid wear to the chain and bar from overheating.
Insufficient oil is evidenced by smoke or bar discoloration.
Adequate lubrication of the saw chain during cutting
operations is essential to minimize friction with the guide
bar. Your pruner is equipped with an automatic oiling
system. The oiling system automatically delivers the proper
amount of oil to the bar and chain.
Fig. 7

POLE PRUNER 750W TTB426GDO
a). Remove the nut and screw from the harness attachment
(19a).
b). Push the harness attachment onto the pole, between
handle and grip, with the holes facing upwards.
Secure the harness attachment with screw and nut.
c). Fit and adjust the length of the harness for easy
operation. (See Fig.8a & 8b, 8c)
The pole pruner can be connected to any socket (with
230-240V alternating current).
We recommend to always use the appliance via a Residual
Current Device (RCD) with a tripping current of max. 30mA.
1). Use only rubber-insulation-sheath extension cables
suitable for outdoor use. The recommended size of
extension cord is not lighter than 1.5mm2and a maximum of
10meters in length.
4). HARNESS
WARNING! The harness helps the operator
carry this pruner. Always attach the harness when
operating the pruner. Do not carry it only with your hands.
Fig. 8a
Fig. 8b
Fig. 8c
2. POWER CONNECTION
WARNING! Before operating the pruner, ensure
that the fastening elements are undamaged.
In order to prevent risk, always switch off the motor and pull
out the mains plug before starting this task.

2). Mains leads on pruner are particularly susceptible to
insulation damage. The causes of this include the following:
- Cut the cable by passing over it with the pruner.
- Damage through crushing if the mains lead is routed
under doors or windows.
- Cracks caused by ageing of the insulation sheath.
- Kinks caused by incorrect fastening or routing of the
mains lead.
3). Such damaged mains leads should not be used under
any circumstances as they may cause fatal injuries due to
their damaged insulation sheath.
4). Always check the plug and cable and make sure they are
in good condition before operation.
3. CABLE ROUTING
Always route the electric main cable away from the work
area to prevent it from coming into contact with the blade.
Plan your route before starting work. Start your work at the
nearest point to the electrical outlet, and work away from it.
This will keep the cable away from the pruner and avoid it
being accidentally cut. Keep the cable over your shoulder
for added safety.
For tension relief of the cable, form a loop of the end of the
extension cable and bring this through the opening at the
handle and insert it into the cable hook. (See Fig.9)
The cutting length of the pruner can be adjusted
continuously according to required cutting height.
1). Unscrew the locking sleeve in clockwise-direction and
extend the pole bar forward.
2). After adjusting required length, tighten the locking sleeve.
(See Fig.10)
Fig. 9
Fig. 10
4. CUTTING LENGTH ADJUSTMENT
WARNING! Always switch the motor off and pull the
mains plug from power supply before any adjustment.

POLE PRUNER 750W TTB426GDO
5. STARTING AND STOPPING
7. HANDLING
6. KICKBACK
1). STARTING
The pole pruner is fitted with a lock-off button feature. To
start the pruner, simply depress the lock-off button (4) then
fully press and hold the switch trigger (3). The lock-off button
can now be released.
NOTE: It is not necessary to maintain pressure on the lock-
off button once the switch trigger is squeezed and the motor
is running. The lock-off button is a safety device to avoid
accidental start-up of the device.
2). STOPPING
The pruner will automatically stop once the switch trigger is
released. The lock-off button will have to be depressed and
the switch trigger squeezed to restart the pruner motor. (See
Fig.11)
1). Always hold the pruner firmly with both hands using
the soft grip. Fully grip both handles at all times during
operation. Never operate this pruner using only one hand.
Always hold the pruner at an angle of max. 60° from the
horizontal level. Otherwise safe operation is not possible.
(See Fig.12a)
Kickback is the sudden backward/upward motion of the
pruner, occurring when the chain (at the tip of the guide bar)
comes in contact with a log or wood, or when the saw chain
becomes jammed.
When kickback occurs the pruner reacts unpredictably and
can cause severe injuries to the operator or bystanders.
Particular attention must be given when sawing sideward,
slanted or during lengthwise cuts, as the spiked bumper
usually cannot be applied.
To avoid kickback:
- Saw with guide bar at a flat angle
- Never work with a loose, overstretched or worn out chain
- Ensure chain is sharpened correctly
- Never saw above shoulder height
- Never work with the tip of the guide bar
- Always hold the chain saw firmly with both hands
- Always use a low kickback chain
- Apply the metal gripping teeth for leverage
- Ensure correct chain tension
Fig. 11
Fig. 12a

2). Never stand directly under the limb you are sawing.
Objects may fall different than expected. Always position
yourself out of the path of falling limps. Keep other persons
away from cutting end of garden power tool and at a safe
distance from the work area. Maintain a minimum distance
of 10 m to bystanders. Never stand on a ladder or other type
of unstable support while using the pruner. Insecure stand
could result in accidents. (See Fig.12b)
3). Ensure that the power cord is located to the rear, away
from the chain and wood and positioned in such a way that
it will not be caught on branches or the like during cutting.
4). Use the pruner only with secure footing. Hold the pruner
at the right-hand side of your body.
5). Do not operate the pruner with arms fully extended or
attempt to saw in areas which are difficult to reach.
6). Keep a firm, steady pressure on the pruner while
working. Do not try to force the pruner through the wood,
let the chain do the work; use the gripping teeth to apply
minimal leverage pressure.
7). Beware when reaching the end of the cut. The weight of
the pruner may change unexpectedly as it cuts free from the
wood. Accidents can occur to legs and feet. Always remove
the pruner from a wood cut while it is running.
Fig. 12b
Fig. 13
8. PRUNING
1). CUT THIN BRANCHES
Thin branches can be cut off with one single cut. To prevent
the branch from slivering and buckling the branch should be
cut off in several pieces. (See Fig.13)
