Titan MNRSPRDRv2 User manual

MANURE SPREADER
MNRSPRDRv2
191396
Operator’s Manual
Read the Operator’s Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

2
GENERAL WARNING
GENERAL WARNINGS
READ and UNDERSTAND this manual completely before using the Manure Spreader.
Operators must read and understand all safety and warning information, operating
instructions, maintenance, and storage instructions before operating this equipment.
Failure to properly operate and maintain the manure spreader could result in serious
injury to the operator or bystanders.
OPERATION WARNINGS
•Never carry passengers.
•Do not sit or stand on the manure spreader.
•Do not allow children to play on, stand upon or climb on the manure spreader.
•Always inspect the manure spreader before use for missing or loose hardware.
•Replace or repair damaged or worn parts immediately.
•Always check and tighten hardware and assembled parts before operation.
•Avoid large holes and ditches when transporting loads. Be careful when operating on
steep grades (hills) as the manure spreader may tip over.
•Do not pull close to creeks, ditches, or public highways.
•Do not use the manure spreader in windy conditions.
•Always use caution when loading and unloading the manure spreader.
•Only tow the manure spreader using a lawn tractor, ATV or golf cart at a speed of no
greater than 5 mph for spreading. Crush and Cut Hazards
•Always keep hands and feet clear from moving parts while operating the manure
spreader.
•Always keep the work area clean and clear of debris.
•Always wear safety gear, eye protection, gloves and work boots while operating the
manure spreader.
CRUSH AND CUT HAZARDS
▪Always keep hands and feet clear from moving parts while operating the manure
spreader.
▪Always keep the work area clean and clear of debris.
▪Always wear safety gear, eye protection, gloves and work boots while operating the
manure spreader

3
WARNING
The warning, cautions, and instructions outlined in the instruction manual cannot cover
all possible conditions or situation that may occur. It must be understood by the
operator that common sense and caution are factors which cannot be built into this
product and must be supplied by the operator
PROP 65 WARNING
This product can expose you to chemicals including lead and lead compounds which are
known to the State of California to cause cancer and birth defect or other reproductive
harm. For more information go to www.P65Warnings.ca.gov
ASSEMBLY IS REQUIRED
This product requires assembly before use. See “Assembly” section for instructions. INSPECT
ALL COMPONENTS closely upon receipt to make sure no components are missing or damaged.
HAZARD SINGNAL WORD DEFINITIONS
This is the SAFETY ALERT SYMBOL. It is used to alert
you to potential personal injury hazards, obey all
safety messages that follow this symbol to avoid
possible injury.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result tin death or serious
injury.
WARNING indicated. A potentially hazardous
situation which, if not avoided, could result in death
or serious injury.
CAUTION indicated a potentially hazardous situation
which, if not avoided, may result in minor moderate
injury.
CAUTION used without the safety alert symbol
indicated a potentially hazardous situation which, if
not avoided, may result in minor moderate injury.

4
CONTROLS AND FEATURES IDENTIFICATION
Read this owner’s manual before operating the equipment. Familiarize yourself with the
location and function of all the controls and features. Please save this manual for future
reference.
1. Hopper
2. 2” Coupler
3. Spreading Drum
4. Spreading Engagement Lever
5. Agitator
6. Relief Panel
CAUTION
Read and follow all instruction for assembly and operation. Failure to properly assemble
this equipment could result in serious injury to the user or bystanders and/or cause
equipment damage.

5
ASSEMBLY INSTRUCTIONS
MANURE SPREADER COMPONENT PARTS AND ASSEMBLY
Before beginning to assemble the manure spreader, take all parts out of the shipping crate and
inspect components to ensure there are no missing pieces. Carefully follow assembly steps 1
through 2.
TOOLS REQUIRED
• 10mm, 13mm, 17mm, 19mm Wrenches
• Screwdriver
STEP 1: CONNECT SIDE PLATES
Connect right side plate (#17), left side plate (#22), rear plate (#16) and front plate (#58) using
step bolt M6x12 (#18) and nylon lock nut M6 (#19).

6
STEP 2: ATTACH PRESSING PLATE
Attach discharge plate (#24) to the hopper assembly using hex bolt M8x20 (#21), lock washer Ø8
(#39) and flat washer Ø8 (#27).
STEP 3: ATTACH THE DISCHARGE PLATE
Attach discharge plate (#24) to the hopper assembly using hex bolt M8x20 (#21), lock washer Ø8
(#39) and flat washer Ø8 (#27).

7
STEP 4: ATTACH THE AXLE WELDMENT
Put the axle weldment (#53) through the roller assembly (#54), then insert sleeve 14 (#50) and
rolling bearing (#51), then tighten the screw in the rolling bearing.
STEP 5: ATTACH ROLLER ASSEMBLY
Attach roller assembly to the hopper assembly using hex bolt M12x40 (#35), flat washer Ø12
(#4) and nylon lock nut M12 (#5). At the same time, insert about 5mm plates between the rollers
on both sides and the side plates of the hopper, and then move the roller as far as possible to
the hopper. Lock the bolt after visual inspection of each gap is reasonable. Finally, pull out the
plates inserted between the roller and the side plates.

8
STEP 6: ATTACH WHEELS
Attach sleeve (#50) and wheel (#46) to the wheel axle, then attach clutch assembly to the wheel
axle using hex bolt M8x60 (#60), clutch spring (#55), large flat washer Ø8 (#27) and nylon lock
nut M8 (#11). Turn the nylon lock nut M8 to adjust the spring tightness to the right position.
STEP 7: ADJUST THE DISCHARGE PLATE
Adjust the discharge plate assembly by moving it up and down to ensure that the gap between
the discharge plate and the roller is between 3-5mm. Tighten the bolt to lock the discharge plate
assembly.

9
STEP 8: ATTACH THE AGITATOR ASSEMBLY
Attach the agitator assembly to the hopper, place sleeve 5 (#36) on the hopper, then lock it with
hex bolt M8x20 (#21) and nylon lock nut M8 (#11). Ensure that the fixed plate can be easily
rotated.
4
STEP 9: ATTACH TOW BAR
Attach tow bar (#15) to the side plate using M8x16 carriage bolt (#20) and M8 nylon lock nut
(#11).

10
STEP 10: ATTACH COUPLER ASSEMBLY
Attach coupler assembly to the tow bar using M10x75 Hex Bolt (#12), Ø10 flat washer (#13) and
M10 nylon lock nut (#14).

11
ALTERNATIVE CONNECTION FOR THE TOW BAR
Unscrew the M12x70 hex bolt (#3), Ø12 flat washer (#4) and M12 nylon lock nut (#5), then
remove coupler (#1) and bushing (#2). Pull out the hitch pin (#8) and the R pin (#10) and insert
them into the front hole.

12
OPERATING INSTRUCTIONS
1. Attach the manure spreader to the vehicle using either the 2” ball coupler or the clevis
hitch.
2. Rotate the agitator so that the rubber wheels are resting on the manure spreader drum.
3. Fill the manure spreader with manure.
4. Drive the manure spreader to the desired spreading location.
5. Flip the spreading engagement lever to engage the spreading drum on either both wheels
or one wheel.
Engage only one wheel when making many turns while spreading. Engage the wheel opposite of
the way you will be turning. For example, if you are turning left, engage the right wheel. –
Engage both wheels for heavy loads of manure and straight-line spreading.
6. Spread the manure while maintaining safe driving speeds.
ADJUSTING THE MANURE SPREADER DISCHARGE RATE AND PATTERN.
•The spreader discharges manure from between the drum and discharge plate. The
spring force of the discharge plate against the drum breaks up the manure as the
spreader discharges the manure.
•Using the adjustment plate to change the size of the holes in the discharge plate allows
for further adjustment of the manure spread pattern and ability to control the discharge
rate.
•Loosening or tightening the bolts enclosed by the small compression springs on the
discharge plate adjusts the manure spreader discharge rate.
•Tightening the bolts compresses the springs making it more difficult for manure to pass
between the drum and discharge plate. Tighten the bolts to break up the manure into
fine pieces before being discharged.
•Overtightening the bolts may result in no manure being able to discharge.
oSuggestion: Tighten the compression springs bolts as far as possible while still
allowing manure to pass, then change the discharge opening by adjusting the
discharge adjustment plate.
oLoosen the bolts to allow larger pieces of manure to discharge from the spreader.

13
The manure spreader has an adjustment plate which changes the discharge hole sizes in the
discharge plate. Adjust the size of the discharge holes by loosening the threaded knobs on the
adjustment plate and sliding the plate to the desired opening.
MAINTENANCE AND STORAGE
WARNING
Improper maintenance and storage of the manure spreader may void the warranty.
MAINTENANCE
•After each use, carefully clean material out of the hopper.
•Rinse and dry the inside and outside of the manure spreader after each use.
•Prior to each use, inspect and verify that all hardware is tight.
•Before initial use, add grease to the two grease zerks on each side of the wheels.
•Check and periodically add grease to the wheels.
•After every use, spray out the hopper and the spreading drum. Cleaning the spreader will keep
debris and manure from clogging the spreading drum and damaging the spreader.
•Check the rubber guard after every use and replace as needed.
IMPORTANT:
When replacing parts be sure to only use parts that meet the manufacturer’s specifications.
Replacement parts that do not meet the manufacturer’s specifications may result in safety
hazards and/ or poor machine operation and may void the warranty.

14
STORAGE
•Never allow material to remain in the hopper for extended periods of time.
•Before storing, make sure the manure spreader is clean and dry.
•Store indoors or in a protected area during any severe weather and during winter
months.
•Store the unit upright to allow any water to drain.

15
PARTS DRAWING AND PARTS LIST

16

17
ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY
The use of any equipment, including this one, involves the potential risk of injury. Apart from any
warranty claim that might be presented for a claimed defect in material or workmanship of the product,
you accept and assume full responsibility for any and all injuries, damages (both economic and non-
economic), and losses of any type, which may occur, and you fully and forever release and discharge
Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,
demands, damages, rights of action, or causes of action, present or future, whether the same be known
or unknown, anticipated, or unanticipated, resulting from or arising out of the use of said equipment.
This equipment must be used with care by capable and competent individuals under supervision, if
necessary.
TITAN LIMITED WARRANTY: TERMS, EXCLUSIONS AND LIMITATIONS OF REMEDIES
This product comes with a one (1) year limited warranty that can be found at
www.palletforks.com/warranty.html. Please review the same for all details regarding the Titan Limited
Warranty.
THE TITAN LIMITED WARRANTY FOUND AT WWW.PALLETFORKS.COM/WARRANTY.HTML IS
EXCLUSIVE AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE, EACH
OF WHICH IS HEREBY DISCLAIMED.
