Operator’s Safety and Service Manual

Grinder

TCG-10

It is the OWNER´S RESPONSABILITY to communicate information on the

SAFE USE and OPERATION of this machine to the operators.

27112013

www.discount-equipment.com

Discount-Equipment.com

Discount-Equipment.com is your online resource for commercial and industrial

quality parts and equipment sales.

Locations:

Florida (West Palm Beach): 561-964-4949

Outside Florida TOLL FREE: 877-690-3101

Need parts? Check out our website at www.discount-equipment.com

Can’t find what you need?

Click on this link: http://www.discount-equipment.com/category/5443-parts/ and fill out

the request form.

Please have the machine model and serial number available in order to help us get

you the correct parts. One of our experienced staff members will get back to you with

a quote for the right part that your machine needs.

We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mayco, Toro/Stone,

Diamond Products, Magnum, Airman, Mustang, Power Blanket, Nifty Lift, Atlas Copco,

Chicago Pneumatic, Allmand Brothers, Essick, Miller Spreader, Skyjack, Lull, Skytrak,

Tsurumi, Husquvarna/Target, Whiteman-Concrete/Mortar, Stow-Concrete/Mortar, Baldor,

Wacker, Sakai, Snorkel, Upright, Mi-T-M, Sullair, Neal, Basic, Dynapac, MBW, Weber,

Bartell, Bennar Newman, Haulotte, Ditch Runner, Blaw-Knox, Himoinsa, Best, Buddy,

Crown, Edco, Wyco, Bomag, Laymor, Terremite, Barreto, EZ Trench, Takeuchi, Basic, Bil-

Jax, Curtis, Gehl, Heli, Honda, ICS/PowerGrit, Puckett, Waldon, ASV, IHI, Partner, Imer,

Clipper, MMD, Koshin, Rice, Gorman Rupp, CH&E, Cat Pumps, Comet, General Pump,

Giant,AMida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,

Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, Small Line, Wanco, Yanmar

Discount-Equipment.com

TABLE OF CONTENTS

1.Serial Number Location.............................................. 3

2.Parts Ordering Procedure .......................................... 3

3.Assembling Instructions ............................................. 4

4.Safety Precautions ..................................................... 4

5.Safety Notice & Decals ............................................... 5

6.Before Operating........................................................ 9

7.Starting Engine ......................................................... 10

8.Operating Instructions ............................................. 11

9.Service Instructions.................................................. 14

10.Maintenance Schedule .......................................... 15

11.Replacements......................................................... 15

12.Torque Chart .......................................................... 16

Discount-Equipment.com

1. SERIAL NUMBER LOCATION

The model/serial number decal is located on the shroud assembly (black).

(Write model number)

(Write serial number)

The unit’s year of manufacture can be determined by the serial number. Contact your nearest

sales branch or for more information.

This Unit warranty is stated in this Operational and Safety manual on page 16. Failure to

return warranty registration card renders the warranty null and void.

An engine owner’s manual is also attached to every unit. Engine parts may order from any

authorized dealer. Refer to the engine owner´s manual lo learn about specifications and part

identification.

2. PARTS ORDERING PROCEDURE:

Parts are available worldwide and must be ordered through your local distributor. If you

can’t locate the distributor in your area refer to page 17 of this manual to locate the

nearest branch and contact numbers for assistance.

Grinders are intended for use in several applications. They are powered by four stroke

gas engines or electric motors and are available in different sizes and manufacturers.

This Operation manual contains only standard parts. Variations of these parts as well as other

special parts are not included. Contact your local distributor for assistance in identifying

parts not included in this manual.

ALWAYS HAVE READY:

1. Model and serial number of machine when ordering parts.

2. Model and serial number of engine when ordering engine parts.

3. Item part number(S), description, and quantity.

4. Company name, address, zip code, and purchase order number.

5. Preferred method of shipping.

Discount-Equipment.com

REMEMBER –You own the best. If repairs are needed, use

only purchased parts from authorized distributors.

3. ASSEMBLING INSTRUCTIONS

UNPACKING

1. Remove the unit and all components from its shipping crate. You will see:

Preassembled grinder

Grinders weight kit.

Carbide cutters or tungsten cutters (if they were purchased separately).

FINAL ASSEMBLING

Surface Grinders are shipped completely assembled with the exception of Grinders

weight kit and the grinding rocks.

Note: All installation hardware must be inserted into its respective location on the

equipment, see parts explosion for more details.

1. Using appropriated equipment, bring the unit to the ground from its shipping pallet.

Warning: failure to use proper lifting equipment could cause

the equipment to fall and cause serious injury.

4. SAFETY PRECAUTIONS

READ AND STUDY THE FOLLOWING SAFETY INFORMATION BEFORE ATTEMPTING TO OPERATE THIS

EQUIPMENT. IN ADDITION, ENSURE THAT EVERY INDIVIDUAL WHO OPERATES OR WORKS WITH

THIS EQUIPMENT IS FAMILIAR WITH THESE SAFETY PRECAUTIONS.

WARNING - LETHAL EXHAUST GAS!

An internal combustion engine discharges carbon monoxide, which is a poisonous and odorless

invisible gas. Death or serious illness may result if inhaled. Operate only in an area with good

ventilation, NEVER IN A CONFINED AREA!

WARNING - DANGEROUS FUELS!

Use extreme caution when storing, handling and using fuels - they are highly volatile and explosive in

the vapor state. Do not add fuel while engine is running. Stop and cool the engine before adding fuel.

DO NOT SMOKE WHEN REFUELING!

SAFETY GUARDS

It is the owner's responsibility to ensure ALL GUARDS AND SHIELDS are in place and in working order.

Discount-Equipment.com

IGNITION SYSTEMS

Breakerless magneto and batteries ignition systems CAN CAUSE SEVERE ELECTRICAL SHOCKS, avoid

contact with these components or their wiring.

SAFE DRESS

DO NOT WEAR loose clothing, rings, wristwatches, etc., near machinery.

NOISE PROTECTION

Wear O.S.H.A. specified hearing protection devices.

FOOT PROTECTION

Wear O.S.H.A. specified steel tip safety shoes.

HEAD PROTECTION

Wear O.S.H.A. specified safety helmets.

EYE PROTECTION

Wear O.S.H.A. specified eyes shields, safety glasses, and sweat bands.

DUST PROTECTION

Wear O.S.H.A. specified dust mask or respirator.

OPERATOR

Keep children and bystanders off and away from the equipment. Only trained Operators who fully

understand its safety operation must use this equipment.

For details on safety rules and regulations in the United States, contact your local Occupational Safety

and Health Administration (O.S.H.A.) office. Equipment operated in other countries must be operated

and serviced in accordance and compliance with any and all safety requirements of such country. The

publication of these safety precautions is done for your information does not by the publication of

these precautions, imply or in any way represent that these are the sum of all dangers present near

equipment. If you are operating a unit it is your responsibility to insure that such operation is

in full accordance with all applicable safety requirements and codes. All requirements of the United

States Federal Occupational Safety and Health Administration Act must be met when operated in

areas that are under the jurisdiction of that United States Department.

5. SAFETY NOTICE & DECALS

IMPORTANT NOTICE

The "SAFETY ALERT SYMBOL" is used to call attention to items or operations that may be

dangerous to those operating or working with this equipment. These symbols can be found

throughout the manual and on the unit itself. Please read these warnings and cautions carefully.

Discount-Equipment.com

READ SAFETY DECALS CAREFULLY

Carefully read and follow all safety decals. Keep them in good conditions. If they become

aged, replace as required. If repainting, REPLACE ALL decals. Decals are available from your

authorized Distributors. Decals are not shown to scale.

201155

201157

IMPORTANT NOTICE

The "SAFETY ALERT SYMBOL" is used to call attention to items or operations that may be

dangerous to those operating or working with this equipment. These symbols can be found

throughout the manual and on the unit itself. Please read these warnings and cautions carefully.

Discount-Equipment.com

READ SAFETY DECALS CAREFULLY

Carefully read and follow all safety decals. Keep them in good condition. If they become aged,

replace as required. If repainting, REPLACE ALL decals. Decals are available from your

authorized Distributors. Decals are not shown to scale.

201003 (x2)

201005

201026

201152

201005

201006

201001 BIG

201001 SMALL

290791

201004

201154

Discount-Equipment.com

SAFETY PRECAUTIONS

DANGER

EXPLOSION HAZARD

Never operate the machine in an

explosive atmosphere, near

combustible materials or where

ventilation does not clear exhaust

fumes.

! WARNING

BURN HAZARD

Never come into contact with the

engine or muffler when engine is

operating or shortly after it is turned

off. Serious burns may occur

! CAUTION

MOVING PARTS

Before starting the machine ensure

that all guards and safety devices

are in place and functioning

properly.

! CAUTION

MACHINE DAMAGE

Advance cutter depth in small

increments to avoid premature

wear or damage.

! ATTENTION

READ OWNERS MANUAL

Read and understand operator's

manual before using this machine.

Failure to follow operating

instructions could result in serious

injury or death.

Discount-Equipment.com

6. BEFORE OPERATING

REMEMBER! It is the owner´s responsibility to communicate information on the safe

use and proper operation of this unit to the operators.

Before operating, review SAFETY PRECAUTIONS listed on page 6 of this manual.

Familiarize yourself with the operation of the unit and confirm that all controls

function properly BEFORE starting engine.

Locate the killing switch and assure you know how to STOP the unit.

Make sure hands, feet, and clothing are at a safe distance from any moveable parts

prior to starting.

Shrouds and guards are provided to protect the operator or structures in close

proximity to rotating hot engine parts. It is the RESPONSABILITY OF THE OPERATOR to

see that they are properly in place. NEVER operate this equipment without a guard.

OIL LEVEL - Check the oil level in the engine. For more information see "Lubrication"

under the engine "Owner's Manual" the "Maintenance" section of this manual. All

Equipment come without oil, running an engine without lubrication may damage the

engine.

AIR CLEANER - Check to ensure elements are in good condition and properly installed.

Review every decal with the OPERATOR.

FUEL SUPPLY - Engines on equipment require an automotive grade of clean, fresh,

unleaded or regular gasoline. All equipment’s come without gasoline and oil.

FUEL FILTER - Check to ensure element is in good condition... Replace if it is clogged or

damaged.

LUBRICATION POINTS –Grease wheels, Drive Shaft and bushing daily.

SPARK PLUG (GAS UNIT) –Check and clean spark plugs regularly. A fouled, dirty or

carbonated spark plug may cause difficulties starting and poor engine performance.

Set spark plug gap to recommended clearance. Refer to engine manual.

POSITION –The only operating position for this grinder is at the rear of the equipment.

If the operator must leave this position the engine must be shut down.

SPECTATORS –Keep all personnel/spectators away from the Grinder while running.

This spinning equipment can throw segments and can cause injuries.

Discount-Equipment.com

7. STARTING ENGINE/AIR

GAS ENGINE

1. With the Grinder engine level in the ground check oil level and add oil and fuel

as required.

2. Pull the stop switch on the unit to its "Out" position.

3. Prior to starting engine, raise the cutter cage assembly using the hand knob

lever, so that cutters do not touch the ground surface, "IDLE" POSITION, and

secure the lever with the locking handle

4. Move the engine throttle control to the "FAST" position.

5. Choke the engine if necessary. (You may not need to choke a warm engine)

BEFORE STARTING ENGINE MAKE SURE ALL GUARDS ARE IN PLACE.

6. Pull the starter string.

7. After the engine starts, move the choke lever to the open position, move the

throttle level to the "IDLE" position and let the engine warm-up for one or two

minutes.

8. To stop the engine, make sure to let the engine idle before stopping by using

the crank lift handle to raise the grinder cutters height.

9. Push in the engine stop switch on the grinder.

10. Close the fuel valve.

ELECTRIC MOTOR

1. With the cage in maximum raised position, plug the motor into a suitable power

source.

2. Move the switch on the motor to the "ON" position.

3. It is recommended to let the motor idle before running and stopping by using

the crank lift handle to raise the grinder cutters height.

STOPPING PROCEDURE:

With machine in upright position, adjust the cutter cage to maximum height by

turning the height adjustment knob to its farthest position. (This ensures

clearance for the rotating cage.)

GASUNIT –Stop engine by depressing kill switch button located at top of handle.

ELECTRIC UNIT –Turn off switch on handle.

Discount-Equipment.com

STOP THE ENGINE OR ELECTRIC MOTOR BEFORE:

Adding fuel.

Leaving equipment unattended for any amount of time.

Making any repairs or adjustments to the unit.

Lifting/Transportation.

8. OPERATION INSTRUCTIONS

1. Before starting the engine, raise the front of the machine to a clear working surface.

2. Start the engine and allow it to reach operating speed. Position the grinder at a

starting point and back continuously, and do not force the machine into the work, the

engine or motor should not strain when grinding.

3. When wet grinding, water is required. Attach the water hose to the water hook-up

valve. Use the water valve to control flow.

4. For dry grinding, provide respiratory and dust control system.

5. For gasoline models, put the engine stop switch in the run position. Consult the

engine manufacturers operating manual and follow the directions to run/stop engine.

6. To stop the machine, stop forward motion. On gasoline models push the throttle to

idle. Turn ignition or power switch off and let the engine comes to a completely stop.

Tur off the water supply.

7. When maneuvering the grinder, tilt grinder back enough so it doesn’t strike the slab

surface. Damage to accessories may occur with inadvertent contact with the slab.

NEVER FORCE THE GRINDER INTO THE SURFACE TO A POINT WHERE THE

EQUIPMENT STARTS BOUNCING

8. If the power source fails, raise the grinder off of the floor. Disconnect power source,

inspect accessories for damage. Replace damage (or questionable) accessories before

re-staring the equipment.

9. When transporting the grinder, disconnect the power source before lifting or

removing any guard.

10.When hosting or lifting grinder, always inspect frame and attaching hardware for

damage before lifting. Use proper safer hoisting and lifting equipment to prevent

injuries.

Discount-Equipment.com

TYPICAL GRINDER APPLICATIONS

Leaving uneven joints.

Light grinding or concrete surfaces cleaning.

Remove mastics, thin-sets, high spots, epoxies and urethanes.

Trailed and stabilizers included.

Lightly texturized concrete surfaces.

Sidewalk Repairs.

Concrete Removal.

Floor Cleaning/Preparation.

Concrete texturized lines removal.

Creating non-slipping surfaces.

9. SERVICE INSTRUCTIONS

Never service or lubricate the unit engine while running.

After servicing the unit, restore and fasten all guards, shields, and covers to their

original positions.

Never drain oil into the ground, into open streams, or down sewage drains.

Keep air filter clean at all times. Wash away dust and debris using anon-oil based

cleaning solvent. Let the filter dry before re- installing.

WHEN LIFTING/LOWERING ALWAYS:

1. Set the machine in an upright position and adjust the cutter cage to maximum

height by turning the height adjustment knob to its farthest position. (This will

ensure clearance for the rotation cage.)

2. Stop the engine or electric motor.

3. REMOVE GRINDING ACCESORIES.

4. Lift the cutting guide to avoid any contact with the head.

5. Secure any other hardware on the machine.

6. Make sure you use appropriated lifting equipment to lift equipment.

7. Do not position yourself where you could possibly be pinched / caught between

the equipment and some other obstacle.

TOWING

1. Move Grinder on the jobsite by hand pushing. Do not tow the unit with another

vehicle. The grinder may be damage if towed.

Discount-Equipment.com

STORING

1. Drain fuel tank.

2. Clean drive shaft, threats. Coat parts with grease.

3. Lube all bearings

4. Empty water system

5. Clean all moving parts with WD-40 lubricant.

6. Lower unit completely.

7. Cover unit for protection.

ENGINE

See engine owner´s manual maintenance schedule.

LUBRICATION

1. Grease wheels, and knob lever daily. Use high quality gun grease.

2. Keep a coating of grease on the drive shaft and threads for easy installation or

removal and longer bushing life.

SPARK PLUG

1. Check and clean spark plugs regularly. A fouled, dirty or carbonized spark plug

causes hard starting and poor engine performance. Set spark plug gap to

recommended clearance. Refer to engine manual.

BELT TENSION

1. If there is excessive belt play, there will be a decrease in the grinding action,

which could cause cage and machine damage. The normal belt play should be

3/8” to 1/2” which is attained by depressing the top section of the belt at the

belt guard mounting bracket location. When adjusting the belt make sure that

the drive pulley is in alignment with cage pulley. Tighten all engine mount bolts,

adjust the two engine-stop bolts, and tighten lock nuts.

ACCESSORIES INSTALLATION/REMOVAL

1. To install and accessory there are several different types but all are installed in

the same manner, use a brass rod or similar mal-able material to drive the

wooden wedge into place as shown in the below illustrations, note on which

side of the accessory the wooden wedge is positioned (near center of disc).

Never mix worn or used accessories with new ones. It will caused vibration and

uneven work surface. Replace accessories in complete sets, never mix sets.

Discount-Equipment.com

2. To remove and accessory there are several different types but all are installed in

the same manner, use a wooden block as explained in the below illustration.

Never hammer directly on any accessory, damage to the self-adjusting system

will result and the accessory will have to be replaced.

Discount-Equipment.com

10. MAINTENANCE SCHEDULE

1. Check all hardware after the first 5 hours of use, the follow the maintenance schedule.

Maintenance

Services Intervals

After

every use

After 45

days or

50 hrs.

Every 3

months

100 hrs.

Every 6

months

200 hrs.

Every 9

months

300 hrs.

Every 12

months

400 hrs.

General Inspection:

Guards

Check

Warning stickers

Check

Wheels

Check operation

Test run

Check operation

Engine:

Engine oil

Check level

Change

Engine oil filter

Replace

Oil cooler

Clean

Cooling Fins

Clean

Air cleaner

Check - clean

Replace

Air Intake Line

Check

Replace

2 years

Fan Belt

Check tightness

Replace

500 hrs.

Valve clearance

Check-adjust

Fuel filter

Check & clean

Replace

Fuel Tank

Clean

500 hrs.

Engine wiring

Check

Cage:

Teeth: (see Individual Cage for

specifications)

Check wear

Change

Shaft: (see Individual Cage

for specifications)

Check wear

Change

11. REPLACEMENTS

Parts

Tolerance or Replacement Cycle

Engine Components

Refer to your engine manufacturer´s Owner´s

Manual

V-Belts

Replace if stretched to the point that the idler does

not work properly. Replace the V-belts if they are

cracked or torn.

Cutters

Replace if Cutters present any missing segments or

stress cracks.

Discount-Equipment.com

Hardware

Re-torque all bolts after the first eight hours of

operation and check hardware every 25 hours.

Replace any worn or damaged hardware as

needed. Replacement hardware should be grade 5

and zinc plated.

Safety Decals

Replace if they become aged, damaged or cannot

be easily read.

12. TORQUE CHART

Discount-Equipment.com
