TMG Alpha-15 User manual

LASER DEFENDER
Alpha-15
Operaon Manual
Facets Product Design & Development Ltd.
Taiwan Microwave Group
www.TMG-FACETS.com
WWW. TMGAMERICAS.COM
TMG, the TMG logo, and other TMG marks are owned by TMG and may be registered.
All other trademarks are properes of their respecve owners.

Content
Introducon ................................................................................................ 2
Installaon ................................................................................................... 4
Operaon .................................................................................................... 6
Warranty ..................................................................................................... 8
Appendix ..................................................................................................... 9
Introducon
Thank you for purchasing the TMG A-15, one of the most innovave and
sophiscated devices in its category today.
Please be sure to read this manual to familiarize yourself with the features and
operaon of this product. Enjoy the trip and drive safely.
TMG system is a class 1M laser product. Never look at the heads
closely while powered on! We recommend wearing Laser protected
eye wear, when tesng the jamming funcon with Laser guns.
Motorists are expected to exercise all cauon while using this
product, and to obey all applicable trac laws.
Check your State and local laws on usage. We encourage you to disable your
jamming funcon as soon as possible once you slow down. This can be done by the
RCV buon, front power buon, or the RCV tab on the app. Running in the “test
mode” is meant for laser jamming tesng only, and is in full me jamming mode,
and could result in suspicion that a LIDAR operator has been jammed. Auto-sleep
mode is default, and highly recommended with an Auto-kill feature to “Receive only
mode” aer 4 seconds.
CPU only takes 12V power sources; A 24V power source will damage
the product permanently, and will void your 2 year warranty.
Specicaons
Input .................................................................................. DC 12V
Laser Wavelength .............................................................. 905nm
Opcal Peak Power............................................................ Up to 75 W
Communicaon ................................................................. BT3.0/4.0 Compable
Operaon Temperature .................................................... -10°F~150°F / -25°C~70°C
Tool Requirements
•T-10 torque bit or allen wrench
• Cordless screw driver- mount the brackets
• Small screws- to mount the brackets
• Velcro or 3m tape to mount the CPU
•Tape measure- measure out the head seperaon
• Electrical tape - wrap up the head connectors and the wire to
feed through the rewall.
•Metal wire to feed the wires through the rewall. (Oponal)
2 3
Indent
Set Screw
Detent
Coupler
Detent on transponder lines up with indent on the
bracket. Posion is locked into place with the set screw.

CHAPTER 1: Installaon
Make sure the heads are posioned approximately the same height as the
license plate and separated by at least 24 to 30 inches from each other. Being
too close together can cause interference.
Use the included green bubble level tool to make sure the heads are
horizontally posioned, and are facing straight forward, and ensure all torque
screws are ght.
When using a third head, install the head in the center of both heads,
below the car’s emblem or directly above the license plate.
The CPU computer has a capability of having 8 heads total
with an oponal splier.
Make sure
transponders
are facing
straight forward.
Make sure the heads are
horizontally installed by using
the bubble level included in
the package.
Changing the Lens cover
Aer a year of use on the road, replace
the old lens cover with a new one. Use
a pin to pry open the old lens cover to
replace it.
Cables
Arrows on cable align for
proper t.
Oponal third head for maximum protecon.
BMW owners have the opon to install the heads vercally. However a third
horizontal head is required so you have two vercal outside heads and one center
horizontal head.
4 5
Controller is installed inside the cabin.
24” ~ 30”
a-15
UDT
AUTO/QUIETRCV
a-15
UDT
AUTO/QUIETRCV
a-15
UDT
AUTO/QUIETRCV
a-15
UDT
AUTO/QUIETRCV
24” ~ 30”
a-15
UDT
AUTO/QUIETRCV
a-15
UDT
AUTO/QUIETRCV

CHAPTER 2: Operaon
Adjusng Volume
Press the + and - side buons to adjust the volume. Press for 1 second to reach the
maximum or minimum volume level. (15 is the maximum).
Receive only Mode
Press the RCV buon to switch to receive only mode. This mode only receives Laser,
and does not jam. Pressing the RCV buon again will enable Auto sleep mode.
Auto/Quiet
Pressing one second enables Auto sleep mode, this stops jamming funcon aer
4 seconds. Auto sleep mode will take 1 minute to relay back to 4 second jamming
from RCV only mode. Use cauon for 1 minute because laser alerts will be muted
unl the CPU announces “Auto sleep mode o”. Press the SLP/RPT buon for 1
second to report police to the server. ”Test mode” is recommended only for tesng
the jamming capability.
The RDT port is for radar detector integraon, or other accessories. The side PWR
port can be used to power the unit with a 12v barrel connector 1.3 mm.
App operaon
1. Start the Laser defender App. Don’t set up BT connecon through the phone or
tablet operaon system. Press Start/On the buon on the app. (α-15 CPU needs
to be powered on and nearby for connecon).
2. Choose MAC address starng with “1E:03” for Android system, and “1E:04” for
iOS. Password is “1234” or “0000” It should take 15 seconds for seng up.
3. Now you can hide the app, and only keep the pop-up. It automacally
disconnects or re-connects to the α-15 CPU when you switch the α-15 CPU o or
on. To bring the interface back, press the pop-up.
4. CPU automacally reports to the server when it receives laser signals. If you keep
the interface on, you can manually report a few dierent types of spots. If you
manually report from the CPU (by long pressing SLP/RPT buon), it’s police spot.
Any report will be kept on the server for 3 hours.
5. Map view and instrucons are on the upper right corner.
Algorithm update (Must have Internet access)
1. Make sure your App is connected with the Bluetooth, otherwise go through step
1 and 2 in previous paragraph.
2. Press the UDT buon on the CPU (An audio voice will say “Algorithm update/
Open app and choose new algorithm and enable Bluetooth”).
3. Press the UDT buon tab on the App. (You may hear an audio voice, that says
“Start Transferring”).
4. Follow the instrucon on the screen.
5. Choose the newest algorithm version to download and choose to start
transferring.
6. When the le is nished, an audio voice will say “Update nished or aborted/
returning to defender mode”.
a-15
Power
Receive only
Algorithm update
For factory use only
System reset
Auto sleep/Report
Switches to determine heads 3 and 4 or rear.
TP (Terminal Ports 1-4 are connecons for Transponders)
(Heads 1 and 2 are always front.)
Align pins on the transponder cable
with the connecon port
AUTO/QUIETRCV UDT
RST
PWR TP1 TP2 TP3
RER
FRT
TP4 RDT
DTA PWR
1 2
ON
Power port (1.35 mm)
TP4 RDT
6 7

CHAPTER 4: Appendix
Protecon
Here is a collecon of laser/lidar guns we have tested. Our laser jammer works for
other similar ones. The coverage is increasing and we always keep our products
promptly updated.
CHAPTER 3: Two Year Limited Warranty
For a period of two years from the date of purchase by the consumer Facets will
repair or replace, at Facets discreon, defecve Facets products upon delivery to
Facets or an authorized Service agent. Facets products must include a proof of
purchase with the date it was rst purchased from an authorized dealer, such as a
copy of a sales receipt.
The customer must pay for shipping Facets products to an authorized Facets
Service Agent. If the product is proven to be under warranty, the return charge, to
the customer, will be at our expense.
This limited warranty does not apply:
To any product damaged by accident.
In the event of misuse or abuse of the product.
As a result of unauthorized alteraons or repairs.
If the serial number has been altered, defaced, or removed.
All implied warranes, including warranes of merchantability and tness for a
parcular purpose are limited in duraon to the length of this warranty.
Aenon
When tesng the system at any me, such as on a bench or
a temporary install, unwrap all cables. Tesng with the cables
wrapped up can cause a magnec eld, and the heads performance
may be compromised.
8 9
License Agreement
Facets products are made by Facets Product Design and Development Ltd in Taiwan. Facets and its licensors grant to
the purchaser a non-transferable, non-exclusive license to use the soware and data installed on Facets’ products and
the related documentaon solely for personal use only on such Facets products. The purchaser should not copy, reverse
engineer, translate, port, modify or make derivave works of the soware and data. The purchaser should not loan, rent,
disclose, publish, sell, assign, lease, sublicense, market or otherwise transfer the soware and data or use it in any manner
not expressly authorized by this agreement. By using this product, the purchaser agrees to be bound by the terms and
condions of this license agreement. Facets and its licensors shall retain all copyright, trade secret, patent and other
proprietary ownership rights in the soware and data. The soware and data is copyrighted and may not be copied, even if
modied or merged with other products. The purchaser shall not alter or remove any copyright noce or proprietary legend
contained in or on the soware and data. The purchaser may transfer all of his/her license rights in the soware, data, the
related documentaon and a copy of this License Agreement to another party, provided that the party reads and agrees to
accept the terms and condions of this License Agreement. The soware and data are provided to the purchaser “AS IS”.
Facets and its licensors make and you receive no warranty for the soware and data, whether express or implied, and all
warranes of merchantability and tness for any parcular purpose for the soware and data are expressly excluded. The
soware and data is complex. Facets and its licensors intend to provide their customers the most complete and accurate
informaon available at a reasonable cost from government and private data sources. However, all data sources have
limitaons and some have inaccuracies or are incomplete in some degree. As such, Facets and its licensors do not make any
warranty regarding the accuracy or completeness of data used by this product and shall not be liable to the user for any
incidental, consequenal, special, indirect or exemplary damages including any ne, civil or criminal penales arising from
the use of the product.

NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
