tne Q4-v3 User manual
TNE-SCOOTER Q4-v3
FEATURES
TNE-SCOOTER Q4-v3
APPEARANCE & SIZE
www.tne-scooter.com www.tne-group.net
BRAKE HANDLE
SPEED DISPLAY
FRONT SUSPENSION
AIR HOLES
ANTI SLIP
STICKER
QUICK FOLDING
HANDLEBAR GRIP
BRAKE
LIGHT
REAR OIL
SUSPENSION
WARNING LIGHT BACK SIDE LIGHTS
FULLY
ENCLOSED
DRUM
BRAKE
MOTOR
STRONG
KICKSTAND
QUICK FOLDING
RELEASE
NO WELDING
STRUCTURE
HEAD
LIGHT
10 INCH
PNEUMATIC
TIRES
Max
height
120cm
Min
height
102cm
115cm
45cm
58cm
18.5cm
115cm
TNE-SCOOTER Q4-v3
FEATURES
TNE-SCOOTER Q4-v3
MAIN PARTS
FULLY ENCLOSED DRUM BRAKE MOTOR
LCD INTELLIGENT SPEED METER
QUICK FOLDING SYSTEM
REAR OIL SUSPENSION
& DRUM BRAKE
SCOOTER BRACKET
FRONT WHEEL & OIL SUSPENSION
HEIGHT ADJUSTABLE BAR
QUICK FOLDING SYSTEM
www.tne-scooter.com www.tne-group.net
WARNINGS & GENERAL INFORMATION
WARNINGS
The responsibility for E-SCOOTER maintenance is yours,
and will help reduce risk of injuries.
Therefore, read this manual and follow it’s instructions, they
will help you avoid risk.
GENERAL WARNING
● Alway follow the local lwas and regulations.
● Never ride your scooter in conditions of poor visibility.
● Do not do stunts, wheelies or jumps, they will increase your
Chances of injury and damage your E-SCOOTER.
● Never carry passengers.
PLEASE NOTICE
E-SCOOTER is not liable for incidental damages or consequential
damages due directly or indirectly to the use of this product.
IMPORTANT INFORMATION
This manual was written to help you understand the proper us
and maintenance of E-SCOOTER.
Also, it is important that your first ride with E-SCOOTER will be
in a remote location, without any obstacles.
It is important for you to understand your new E-SCOOTER; its
features and performance, so that you will enjoy the most from
your first and every ride.
E-SCOOTER needs a short period for all moving parts such
as hinges and brakes to adjust themselves into their correct
position.
www.tne-scooter.com www.tne-group.net
3
OPENING & FOLDING TNE-SCOOTER Q4-v3
FOLDING E-SCOOTER
● First, open the snap joint as shown is Fig.1;
● Second, Holding the Fig. 2, and then pull outward;
● Third, holding the handle bar Fig.3, pull outward;
● Finally, pull outward the T-type, and fold the handle.
● First, open the snap joint as shown is Fig.1;
● Second, Holding the Fig. 2, and then pull outward;
● Third, holding the handle bar Fig.3, pull outward;
● Finally, pull outward the T-type, and fold the handle.
OPENING E-SCOOTER
NOTICE
Before driving you must ensure that the folding part is
working well.
22
1
3
www.tne-scooter.com www.tne-group.net
22
1
OPERATION
BATTERY
● Do not operate motor while charging!
● Indicator lights in the throttle are intended only for general knowledge
(full / empty) and does not give a precise indication to the battery
status.
● Do not store E-SCOOTER for long terms (more than two months) with
fully charged battery.
● From time to time Discharge the battery by riding E-SCOOTER in the
red led light position until it slows down and stops.
● Is Broken
● Emits an unusual odor or excessive heat
● Presents any leakage
Avoid contact with substance oozing form the battery.
Keep the battery away form children and pets. Exposure to the battery
voltage can canse death or serious injury.
The use, storage or charging of the E-SCOOTER battery outside
specified limits.
may result in the annulment of the warryanty, battery damage, and
an ineffective battery charging.
DO NOT USE THE BATTERY IF THE BOARD:
CHARGING AND BATTERY
Your E-SCOOTER has an external charger. Connect the charging to
E-SCOOTER charging socket under the footboard, on the right side
at the rear.
Than connect the charge electric cable to an electrical outlet.
Charging Light Red - Battery charging.
Charging Light Green - Charging is complete.
Avoid long periods of time with an uncharged or fully charged battery.
To maximize your E-SCOOTER battery performance, fully charged it
for 9 hours,
once a moth, or after each use of twelve hours.
Unplug E-SCOOTER from the outlet before installing, removing the
battery or performing any maintenance. It is dangerous to work on
E-SCOOER when plugged in to an AC outlet. Electrical shock an cause
serious injury and damage the scooter.
Do not attempt to open the battery. Do not insert anything in the battery
and do not attempt to open it’s case with any tool. Inserting an object
any attempt to open the battery can cause electrical shock, injury, burns
or fire. Any attempt to open the battery case will damage it and cause
release of dangerous toxic substances.
Charge the battery only using tools approved by E-SCOOTER.
Remove the battery and carry E-SCOOTER according to all applicable
local and national requirements.
www.tne-scooter.com www.tne-group.net
OPERATION
DISPLAY
LCD TNE 881 Intelligent speed regulating handle instructions
Special for TNE-SCOOTER
Version Number: 20150930
Item No: TNE 881 - A
WARNINGS
Release speed control before braking!
2.1 Working Voltage: DC24V 36V (Setting of the meter)
48V (According to customers’ requires to customized)
2.2 Mode of connection:
1. Red Line (D+): Enter of the power’s plus
2. Black Line (GND): Power’sminus
3. Blue Line (DS): Controllerelectricdoorlock
4. Yellow Line (SC): Brakesignal
5. Green Line (RX): Received the communication
6. White Line (TX): Sendthecommunication
Working Voltage and Mode of Connection
www.tne-scooter.com www.tne-group.net
First, Introduce of Display Content
1 Function of Display
Speed display、Battery indicator、Problems prompt、Mileage、
Accumulative mileage
2 Function of Control and SettingPower switch control、Wheel diameter
setting、Automatic dormancy time setting、Backlight brightness setting、
startup mode、 drive mode is set、voltage grade setting、controllerset
current limiting values
3 Communication Protocol: UART
All The Content On The Display Screen(Opened In One Second)
Function
1.Voltage Status Grade POWER
2.Multi function display area
The total mileage of ODO, single mileage TRIP, residual mileage RM
(need batteryprotection board, software support), running time of TIME,
the fault code ERRO
3. The fault status display area ERRO, when ERRO symbols in the
flashing, short press ON/OFF key to adjust the display interface to the
interface ERRO interface under the corresponding figures represent the
specific content of the corresponding fault stateare as follows
ERRO 1:Motor fault
ERRO 2:Turn fault
ERRO 3:Controller failure
ERRO 4: Power brakes
ERRO 5:Under voltage protection
ERRO 6:Communication fault,
the instrument does not close to the output of the controller
ERRO 7:Communication fault,
the controller does not receive the instrument output
www.tne-scooter.com www.tne-group.net
Second, the key function introduction:
Short press + or - key to change speed state,press + key is used to
increase the maximum speed of the vehicle,press - key is used to r
educe the maximum speed of the vehicle,the default speed third gear,
the 1 slowest, 3 fastest。
Parameter numerical modification:
Access parameter is set to meet, transferred to want to adjust the
parameters, through the + key and - key to increase or reduce the
value of parameter, confirm the change after long press the + key
and - key to exit the parameter settings, shut down, restart that modify
the parameters to complete。
4、The turn adjusting motor speed, from top to bottom toggle, motor
speed increase;Loosen the turn speed to zero。
5、If the display have a light function,long press – key to open the light。
4 . Speed display area
Unit MPH, KM/H
Speed signal from the Holzer signal in the motor, the controller send
instrument,
(A single Holzer cycle time,单位: 1MS)
The instrument according to the wheel diameter and signal data(Holzer
also need to set the number of motor magnetic steel),Calculate the
actual speed
5. Parameter setting and definition
P01: The backlight brightness, 1 levels of the dark, the 3 level is the
brightest;
P02: Distance unit, 0:KM; 1:MILE;
P03: Voltage grade: 24V, 36V, 48V, default 36V;
P04: Sleep time:0, Don't sleep; Other figures for the sleep time,
Range: 1-60;Unit minutes;
P06: Wheel diameter:Unit,inch; Precision:0.1;
P07: Speed magnetic steel number: Range:1-100;
P09: Zero start, non-zero start up settings,0:Zero start;1:non-zero start;
P12: Starting torque: Range:0-5,0 The weakest, 5 The strongest;
P14: Controller for limiting value setting default 12A Range:1-20A;(Need
controller software support)
P15: Maximum speed set to slow gear vehicle, fast file does not work;
ODO: ODO reset (Long press – or + button for 5-6 seconds reset)
1、Shut down state, short press key to boot,short press the key,
interface switching between ODO, TRIP, RM, TM, ERRO;
2、The boot state,long press key to shut down;
3、Long press + and - key to enter the mode setting,
in the setting of interface, short press key to switch parameter;
Note: the part of the parameter is set, the shutdown restart to take effect.
PS: Because the company product upgrade products may display content
of the part you get will differ with the instructions, but will not affect your
normal use。
www.tne-scooter.com www.tne-group.net
SAFETY
WARNINGS
Certain countries or regions require safety devices or grea.It is
your responsibility to know the state laws, and follow them.
IMPORTANT INFORMATION
Riding, llike most sports, involves risks of injury and damage. By
choosing to ride E-SCOOTER the responsibility and all inherent
risk is on you. It is crucial that you know, understand and act
according to safety rules.
DO NOT USE THE BATTERY IF THE BOARD:
MECHANICAL SAFETY TESTS:
Air pressure in tires: 40psi to 50psi.
SAFETY GEAR
Helmet: most serious injuries that occur while riding are head injuries.
This could hace been prevented if a helmet had been worn.
You must wear a helmet while riding your E-SCOOTER. The helmet
must be worn according to its instructions.
Before using E-SCOOTER: Perform a visual inspection that all screws
and nuts are tight and in place. Note if anything looks amiss, or is
showing signs of wear. If you are unsure, bring your E-SCOOTER to
theauthorized distributor. Tires and wheels: check the tires for signs of
wear. To do this spin that the wheels are freely rotating from the brakes.
If not, take E-SCOOTER to the authorized distributor.
Before each ride, always check your brakes and mechanical funtion.
TIP
As you accelerate, lean forwards. As you brake, tilt your weight
backwards.
SAFETY GEAR
1. Knowing E-SCOOTER- Get to know E-SCOOTER before drving it.
Test your control over it. Make your turns slowly and cautiously, and
give yourself stopping distance.
2. Your driving capability- to gain control over your scooter, practice your
first ride on E-SCOOTER in an open space with on obstacles to disturb
you.
DRIVING TECHNIQUE:
Foot position- before riding put your foot as close as possilbe to the front
section of the scooter, and your other foot on the ground. Make sure that
your driving route is clear.
To start riding boost yourself forwards (as on non-motorized scooters)
with your foot that is on the ground.
Immediately after press the thumb throttle sownwards, tilt your body
forwards so you shouldn’t fall backwards during acceleration,
E-SCOOTER will be in motion.
Keep on foot behind the other, (it’s more comfortable to place one foot
forward and the other one turned backwards at 70-90, like on skate/
surfboard.) it will help you gain more stability.
www.tne-scooter.com www.tne-group.net
DRIVING TECHNIQUE
DRIVING TECHNIQUE
Turns- the turns on E-SCOOTER are done as on surf/ski/snowboard.
The handlebar should be in parallel to the body. Before turning look
at the approaching direction and make sure turing is safe.
Braking- Tilt your weight backwards so that the brake action will come
through the feets and not through the handlebar and steering system.
It is there is a dual concerm; forward turning over. (”Stopy”) and/or wear
and breaking of the handlebar and steering system.
TNE-SCOOTER DRUM BRAKE
INSTALLATION AND OPERATION
www.tne-scooter.com www.tne-group.net
NOTES:
1. The thin-headed screw is non-adjustable. Users are not
allowed to screw the thin head screw (see figure III) in case
of damaging then disc brake calipers.
When the brake performance began to decline, can adjust the brake
line regulation in order to achieve the required sensitivity, If the brake
line after adjustment, The braking performance is still poor, Or the
brake noise dealers need to find the product replacement brake pads.
This product is equipped with lithium battery can repeat charging at
least two years 800 times. When each time with electric range too
short, lithium batteries need to be replaced.
Check the listing
When the product can’t normal operation, please check the following
action has been completed:
When the product can’t normal operation, please check the following
action has been completed:
Need every dix months in folding hand clutch set using a small amount
of lubricating oil or lubricant to do maintenance.
2. After it has been frequently used for a long time or not used
for ta least one month, the disc brake must be checked whether
it works correctly, whether the wear of brake pads is within
normal range and the disc is worn de- formed or not (when the
deformation deflection exceeds 0.2mm, the disc must be
replaced).
3. The brake pads cannot be contaminated with oil. Or the brake
pads must be replaced to ensure the safety riding.
4. When users use the brake during riding, there may be the
slight noise caused by the friction of the brake pads and the disc.
It is normal and no need to worry about.
5. It is very important to completely understand the operation
of your bicycle’s brake system may results in a loss of con- trol,
or an accident which could lead to severe injury. Be sure to
learn the proper braking technique and operation of your bicycle
because each bicycle may handle differ- ently. This can be
done by consulting your professional bi- cycle dealer and the
bicycle’s user manual, and by prac- ticing your riding and braking
technique.
MAINTENANCE
LUBRICATION
TIRE
Note: do not use the WD40 (rust - proof oil) to lubrication product
parts, front and rear wheels don’t lubrication, if in doubt, consult your
dealer.
General troubleshooting
● The power supply has been opened.
● Display and surplus electricity power.
● Brake pull up has been let go.
● All sockets and connectors are clean and accurate link
www.tne-scooter.com www.tne-group.net
1. No-load Max speed: 60kph
2. With-load (60kg) Max speed: 48kph
3. Max distance: 40-120km
4. Max loading: 200kg
5. Battery: 48V lithium ion battery pack
6. Motor: 500W Rear hub Brushless motor
7. Charger: 220 /110V, 50 - 60Hz, or 240/100V, Customized
8. Throttle lever: Intelligent speed throttle
9. Controller: 25A Intelligent controller
10. Frame: 45# iron
11. Tyres: Thick 10 x 2.5 Wheel for 2 wheels
12. Suspension: F/R Oil Suspension
13. Rim: Aluminum alloy 6061-12
14. Folding system: Quicking folding system, 304 stainless
15. Brake system: Drum brake
16. Mudguard: 45# iron
17. Handlebar: Aluminum alloy 6061
18. Scooter board: Aluminum alloy 6061
19. Lights: Font LED light & 2 brake lights
20. Display: TNE 881-A intelligent LCD-Display
21. Charging time and life: 4-12 hours, > 500 times
22. G.W./N.W.: 18-22 kg
23. Handlebar heigh: 102~120 cm
24. Foldable size: 115*45*18.5 cm
25. open size: 115*120*18.5 cm
26. Carton size: 120*25*44.5 cm
27. Loading quantity:
20GP: 215 pcs
40GP: 430 pcs
40HQ: 523 pcs
PRODUCT SPECIFICATONS AND
PARAMETERS
SPECIFICATION
TNE-SCOOTER Q4-v3
www.tne-scooter.com www.tne-group.net
Dear user:
Thank you for your choose of our products, this is not only the
high trust of our company’s products, but also great trust and support
for our after-sales service guanrantee system, please fill out the warranty
card and confirm the registration, to help us improve the quality of the
product.
WARRANTY CARD
SPECIFICATION
User information
User name
Telephone
Address
Zip code
Purchase date
Model
Maintenance record
Sending
date
Maintenance
condition
Maintenance
result
Maintenance
person
Handing
date
User’s
signature
Provide services with concentrated attention to create perfect.
www.tne-scooter.com www.tne-group.net
GO
Tel: 4006-908-344
Email: info@tne-group.net
Http: //www.tne-scooter.com
www.tne-group.net
Table of contents
