Toa SR-F1B User manual

OPERATING INSTRUCTIONS
SR-F1B
SR-L1B
SPEAKER SYSTEM
SUPER WOOFER SYSTEM
Note: The SR-F1B comes with two nuts on the bottom side, which
are used only for mounting the SR-F1B to an optional
speaker stand. Never use these nuts for speaker suspension.
SR-F1B
Electronic-controlled system (bi-amplifier driven system) with the AC-F1 Electronic Control Unit.
High power capacity of 120 watts continuous pink noise for low frequency and 80 watts for high frequency.
High-efficiency 30 cm (12") woofer using a 20 cm (8") large magnet.
HFD-651 type high power driver with LE Series Constant Directivity(CD) Horn (60°horizontal by 40°vertical).
Fixing metals for suspension provided on top and bottom sides of the enclosure.
Provided an angle of 15° at both sides ofthe enclosureto prevent mutual interference in high frequency range.
SR-L1B
Electronic-controlled system with the AC-L1 Electronic Control Unit.
High power capacity of 300 watts continuous pink noise.
Ultra-linear, high power 38cm (15") woofer.
General Features
Neutrik NL4MPR input connector.
APITON plywood enclosurewith rugged FRP coating.
Removable punched metal front grill.
TOA Corporation
FEATURES
SR-F1B
SR-L1B

INPUT CONNECTOR
Each speaker employs the Neutrik NL4MPR connector for its input.
The table on the right shows the NL4MPR's contact arrangement.
The mated cable connector is the Neutrik NL4FC.
CONNECTION DIAGRAMS
Single System (SR-F1B)
* Woofer direction viewed from the front side.
Contact number SR-F1B SR-L1B
Combination System (SR-F1B and SR-L1B)
Mixer / preamplifier
Mixer/ preamplifier
Note: Refer to the "Electronic control unit's operating instructions" for the mode setting ofthe electronic control unit and
the level setting of power amplifier.
INSTALLATION
Mounting the SR-F1B on the SR-L1B
When one SR-F1B is mounted on the SR-L1B When two SR-F1Bs are mounted on the SR-L1B
Arrange so the front edges of the SR-F1B
and SR-L1B are aligned as shown in the figure.
SR-F1B
SR-L1B
SR-F1B
SR-F1B
SR-F1B
2
SB-L1B

Suspending the SR-F1B
Note: TheSR-L1B can notbe suspended.
Caution
The SR-F1B weighs approximately 37 kg. Confirm that the structure of installation place, and suspending wires or belts
are heavy-duty enough to support the total weight ofthe load before suspension. Secure to lock the fixing metals of the
suspending wire or belt to the speaker. TOA takes no responsibility for any accidents or injuries resulting from the fall
of the SR-F1B due to incorrect installation.
• As for the general suspending methods of the SR-F1 B, refer to the figures below.
Be sure to use two suspending wires or belts.
Fix them to the ceiling reinforcement
individually.
Even in case of oblique installation of the
speaker, be sure to use two suspending wires
or belts.
WARNING
Never suspend the speaker as shown in the figures below.
Never use a ringed one wire. Never suspend the speaker
with a single wire.
Never link more than three
speakers vertically.
Never suspend the speaker using
the speaker handles.
3
Fitting metal supplied with the SR-F1B
32202 Ring/Stud Pan Fitting (Aeroquip made)
To suspend the SR-F1B from its stud,
prepare the following applicable metal.
32326 Stud Fitting (Aeroquip made)
Suspending metal
Ring
Stud

SPECIFICATIONS
Enclosure
Speaker
Lowfrequency
Highfrequency
Ratedimpedance
Sensitivity
Frequencyresponse
Crossoverfrequency
Power
handlingLowfrequency
Highfrequency
Inputconnector
Enclosurematerial
Weight
Dimensions
Finish
SR-F1B
SR-L1B
Bassreflextype
One30cm(12")dia.conespeaker
CDhorn(60°horizontalby40°Vertical)
pluscompressiondriver
Lowfrequency: 8
Highfrequency:16
Lowfrequency: 98dB(1W/1m)
Highfrequency:110dB(1W/1m)
70Hz~20kHzatAC-F1'suse
1kHzatAC-F1'suse
Continuouspinknoise: 120WRMS( 1)
Continuousprogram: 360W
Continuouspinknoise:80WRMS( 2)
Continuousprogram:240W
Two38cm(15")dia.conespeakers
—
8X2
96dB(0.5Wx2/1m)
35 Hz~1 kHz
125HzatAC-L1'suse
Continuouspinknoise: 150W RMSx2(3)
Continuousprogram:450WRMSx2
—
NeutricNL4MPR
Apitonplywood(Thickness: 18mmor0.71*)
Approx.37kg(82Ib.)
390(W)X 619(H)X 364(D)mm
15.4(W)x 24.4(H)X 14.3(D)in.
Approx.79kg(174Ib.)
829(W)x 629(H)x 606(D)mm
32.6(W)x 24.8(H)x 23.9(D)in.
Enclosure: FRPcoatingingraycolor
Frontgrille: Black(painted)
Specificationsaresubjecttochangewithoutnotice.
StandardAccessories:Operatinginstructionsx 1
Mountinginstructionsx 1
(1)BandLimited(50to1,000Hz)PinkNoiseSignal(24hours)
(2)BandLimited(1,000to20,000Hz)PinkNoiseSignal(24hours)
(3)BandLimited(40to1,000Hz)PinkNoiseSignal(24hours)
CHARACTERISTICDIAGRAMS(1/3octavepinknoise)
SR-F1B(atAC-F1electroniccontrolunit'suse)
Frequencyresponse(1W/1m,at300Hz)Polarresponse(1W/4m)
HorizontalVertical
SR-L1B(atAC-L1electroniccontrolunit'suse)
Frequencyresponse(1W/1m,at100HzofcrossoverOUT)
Generalfrequencyresponse(1W/1m,at300HzoftheSR-F1B)
SR-L1B+AC-L1,SR-F1B+AC-F1AC-L1:CrossoverOUT
PrintedinJapan
133-01-381-60
TOACorporation
AC-L1mode
CrossoverOUT
CrossoverIN

SR-F1BSPEAKERFLYINGSYSTEM
ThisspeakerflyinghardwaresystemismanufacturedbyATMFLY-WARE™(ATMGROUP,Inc.)oftheUnitedStatesforuse
withTOA'sSR-F1Bspeaker.Theflyingsystemenablesvariousspeakerarrayconfigurationstobeconstructedquicklyand
safelywithoutspecialcomponents.
SYSTEMCOMPOSITION
Theflyingsystemiscomprisedoffivemaincomponents.
1.[AMFS-SRF1-THTrussModule]Allowableload275kg
ThetrussmoduleattachestoboththetopandbottomoftheSR-F1B
speaker.
<Note>Speakerfixingscrewsaresuppliedwiththetrussmodule.
2.[AMFS-1X2-30ConnectingBar]Allowableload278kg
Theconnectingbarisusedforhorizontalspeakerconnection.
3.[AMFS-1X2-SMEShackleMount]Allowableload225kg
Theshacklemountisusedtosetsuspensionpointsforverticalspeaker
suspension. (Multiple rows of speakers canbe suspended at different tilt
angles.)
4.[AMFS-1X2-SBStackingBracket]Allowableload194kg
Thestackingbracketisusedtosuspendmultiplerowsofspeakersina
straightverticalformatwithoutvarying array tilt angles.
5. [2.5QRPQuickReleasePin]Allowableload835kg
Thequickreleasepinhasa lockfunctionandisusedtoconnect
individualparts.
MOUNTINGTRUSSMODULE
Trussmodule Panfittingring
Hexagonbolt3/8"x41/2"
Caution
Neverusemounting
hardwareotherthan
supplied.
WARNING
EXAMPLEOFUSAGE
Thefollowinglimitationsmustbeobservedevenwhentheallowableload
requirementismet.
(1)A maximumoffourspeakerscanbesuspendedpershacklemount
(AMFS-1X2-SME)orstackingbracket(AMFS-1X2-SB).
Example1:A columnofeightspeakersconfiguredtwohighandfourwide
canbesuspendedfromtwoAMFS-1X2-SMEShackleMounts.
Example2:A columnoftenspeakersconfiguredtwohighandfivewide
wouldrequiresuspensionfroma minimumofthreeAMFS-1X2-
SMEShackleMounts.
(2)A maximumofthreerowsofspeakersusingthisflyinghardwaresystem
maybesuspendedintheverticalplane.
Confirmthefollowingpointsbeforeinstallation.
(1)Totalactualloadofeachcomponentmustbelowerthantheallowable
loadforthatcomponent.
(2)Allquickreleasepins(2.5QRP)mustbeinsertedintoothercomponents
tolockthemsecurely.
(3)Allcomponentsthatrelatetoarraysuspension(i.e.enclosures,individual
componentsoftheflyinghardwaresystem,clamps,connectors,and
suspensiondevices)mustbefreefromanydeformation,crackand
corrosion.
AMFS-1X2-SME
AMFS-1X2-SB
AMFS-1X2-SME
AMFS-1X2-30
AMFS-1X2-SME
AMFS-1X2-SME
2.5QRPAMFS-1x2-30
AMFS-SRF1-TH
2.5QRP
2.5QRP
2.5QRP
AMFS-1X2-30
2.5QRP
AMFS-SRFI-TH
AMFS-1X2-SB
2.5QRP
AMFS-SRFI-TH
AMFS-1X2-SB
2.5QRP
2.5QRP

SR-F1B SPEAKER STAND
This speaker stand is manufactured by König&Meyer GmbH(K&M) of Germany for use with TOA's SR-F1B speaker.
The speaker stand consists of two main sections:
Stand: Model 213
Bracket: Model 19582
USAGE (Refer to Fig. 1.)
Extending the Stand Legs.
1 . Loosen the tripod clamp screw and extend the tripod legs by
sliding the clamp ring down the length of the stand until the leg
stays are horizontal, then retighten the screw.
Mounting the Speaker.
2 . Attach the stand bracket to the base of the speaker using the
supplied mounting screws and washers. (Fig. 2).
3 . After ensuring that the bracket clamp screw is loose and not
protruding into the interior of the bracket, carefully place the
speaker on the stand by sliding the bracket over the end of the
stand.
4 . After positioning the speaker, tighten the bracket clamp screw.
Adjusting Stand Height.
5 . Loosen the height lock screw.
6 . Loosen the handle clamp screw, then fold out the crank handle
and retighten the screw.
7 . While holding down the lock button, adjust the speaker's height by
turning the crank handle. (Clockwise rotation raises the speaker.)
The handle cannot be turned without holding down the lock button.
After adjustment is completed, release the lock button and make sure
that the shaft is securely locked. (This can be checked by rotating the
handle slightly.)
8 . Retighten the height lock screw.
9 . Loosen the handle clamp screw, flip the handle back into its
foldaway position and retighten the handle clamp screw. Be sure
the handle is always folded up except when adjusting the height.
Removal After Use
10. After use, lower and detach the speaker, then collapse the stand
in the reverse order of the above procedure.
Speaker Mounting Screw Storage
After the stand bracket is detached from the speaker, the speaker
mounting screws can be inserted into the threaded holes of the stand
bracket for storage. (Fig. 3).
PRECAUTIONS
Only use the stand on flat, hard ground or floor surfaces.
Avoid installing the stand near narrow passages where passers by might trip over the tripod legs.
When using the stand outdoors, take care to avoid exposure to strong winds.
To reduce the chance of the stand toppling over, avoid extending the stand too high.
When there is potential for instability and the danger of a fall, be sure to secure the stand with guy wires or other
devices.
<Fig. 2>
<Fig. 1>
Speaker mounting screw
Plain washer
Threaded hole
<Fig. 3>
Plain washer-
Speaker mounting screw
Stand bracket
clamp screw
Height lock screw
Tripod clamp screw
Lock button
Handle clamp screw
Crank handle
Height adjuster
Tripod leg
Stay

SR-F1B

SR-F1B

TOA
SR-F1B
SR-L1B

2

3

133-01-380-50

SAFETY PRECAUTIONS
Follow this instruction manual to obtain the optimum
results before use.
We also recommend you keep this instruction manual
handy for future reference.
Note that this manual may include safety precautions not
applied to your products.
INSTRUCTION MANUAL
Symbols
Symbol of
caution actions
Caution
Symbol of
prohibited actions
Prohibition
WARNING
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Avoid installing or mounting the unit in unstable locations, such as on a rickety
table or a slanted surface. Doing so may result in the unit falling down and
causing personal injury and/or property damage.
Prohibition
Install the unit only in a location that can structurally support the weight of the
unit and the mounting bracket. Doing otherwise may result in the unit falling
down and causing personal injury and/or property damage.
Caution
CAUTION
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
Install the unit only in stable locations, and make appropriate arrangements to
prevent it from falling down or rolling cross the floor. If it falls down or moves,
this may cause personal injury and/or property damage.
Caution
When unpacking or moving a heavy unit, be sure to handle the unit with two or
more persons. Falling or dropping the unit may cause personal injury and/or
property damage.
Caution
Do not place heavy objects on the unit as this may cause it to fall or break which
may result in personal injury and/or property damage. In addition, the object
itself may fall off and cause injury and/or damage.
Do not stand or sit on, nor hang down from the unit as this may cause it to fall
down or drop, resulting in personal injury and/or property damage.
Do not operate the unit for an extended period of time with the sound distorting.
This is an indication of a malfunction, which in turn can cause heat to generate
and result in a fire.
Avoid placing the unit in a doorway or other high traffic area as people may trip
on the equipment and cords, or be injured by falling objects.
TOACorporation
Prohibition
Prohibition
Prohibition
Prohibition
133-21-296-50

TOA
* Please see the reverse side for English safety instructions.
