Toa SR-F1D User manual

OPERATING INSTRUCTIONS
SPEAKER SYSTEM
SUBWOOFER SYSTEM
SR-F1D
SR-L1B
SR-F1D SR-L1B
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.

2
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS ............................................................................... 3
2. GENERAL DESCRIPTION ............................................................................. 5
3. FEATURES .......................................................................................................... 5
4. INSTALLING THE SR-F1D ON THE SR-L1B ........................................... 5
5. FLYING (SR-F1D ONLY)
5.1. Direct Suspension Using the SR-F1D's Flying Hardware ................................. 6
5.2. Suspension Using Optional Flying Hardware
5.2.1. SR-F1D speaker flying hardware system ............................................... 7
5.2.2. Flying precautions ................................................................................... 8
5.2.3. Flying example ........................................................................................ 8
6. SPEAKER STAND FOR SR-F1D ................................................................. 9
7. INPUT CONNECTOR ...................................................................................... 10
8. CONNECTION DIAGRAMS
8.1. Single System (SR-F1D) .................................................................................. 10
8.2. Combination System (SR-F1D and SR-L1B) ................................................... 10
9. PROCESSOR SETTINGS .............................................................................. 11
9.1. Flat Phase Type ............................................................................................... 12
9.2. Minimum Delay Type ....................................................................................... 13
10. CHARACTERISTIC DIAGRAMS
10.1. SR-F1D + SR-L1B (when DP-0206 is used)
10.1.1. Flat phase type .................................................................................. 14
10.1.2. Minimum delay type ........................................................................... 14
10.2. SR-F1D (when DP-0206 is used) .................................................................. 15
11. DIMENSIONAL DIAGRAMS ......................................................................... 15
12. SPECIFICATIONS ............................................................................................ 16

3
When Installing the Unit
• Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down and causing personal injury and/or property
damage.
• Refer all installation work to the dealer from whom
the speaker was purchased. Installation for flying
requires extensive technical knowledge and
experience. The speaker may fall off if incorrectly
installed, resulting in possible personal injury.
• Flying Precautions
Be sure to follow the instructions below. Otherwise,
the suspension wires or belts may be off or snap
and the speaker may fall off, causing personal
injury.
· Check to confirm that the suspension wires and
belts are strong enough to withstand the speaker
load.
· The connectors of the suspension wires and belts
must be securely linked with those of the
speaker.
· All parts and components (such as enclosures,
metal pieces, and screws) must be free from any
deformation, crack, and corrosion.
· Be sure to use screws supplied with the optional
flying hardware when installing the speaker using
such hardware.
• Install the unit only in a location that can
structurally support the weight of the unit and the
mounting bracket. Doing otherwise may result in
the unit falling down and causing personal injury
and/or property damage.
• Owing to the unit's size and weight, be sure that at
least two persons are available to install the unit.
Failure to do so could result in personal injury.
• Do not use other methods than specified to mount
the bracket. Extreme force is applied to the unit
and the unit could fall off, possibly resulting in
personal injuries.
• Tighten each nut and bolt securely. Ensure that the
bracket has no loose joints after installation to
prevent accidents that could result in personal
injury.
• Use the specified mounting bracket in combination.
Doing otherwise may cause the unit or component
to fall off, resulting in personal injury.
• Cautions when using the speaker stand
Be sure to carefully observe the following
instructions. Ignoring them could result in the
speaker system toppling over or falling down,
possibly resulting in personal injury.
· Open the stand legs to their full extension.
· Do not extend or fold the tripod while the speaker
is mounted.
· Install the stand on a flat, hard surface.
· Avoid placing the speaker in a doorway or other
high-traffic area where people may trip over the
equipment or cords.
· In outdoor installations, take such measures as
securing speakers with safety wire to prevent
them from being toppled over due to strong wind,
etc.
1. SAFETY PRECAUTIONS
• Be sure to read the instructions in this section carefully before use.
• Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
• We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.
WARNING
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
WARNING
CAUTION

4
When Installing the Unit
• When unpacking or moving the unit, be sure to
handle it with two or more persons. Falling or
dropping the unit may cause personal injury and/or
property damage.
When the Unit is in Use
• Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
• Do not stand or sit on, nor hang down from the unit
as this may cause it to fall down or drop, resulting
in personal injury and/or property damage.
• Have the unit checked periodically by the shop
from where it was purchased. Failure to do so may
result in corrosion or damage to the unit or its
mounting bracket that could cause the unit to fall,
possibly causing personal injury.
CAUTION

5
2. GENERAL DESCRIPTION
Developed for the mobile sound reinforcement applications, TOA's SR-F1D and SR-L1B make up a speaker
and subwoofer system which features high power handling capability, high quality and durable construction.
3. FEATURES
• The SR-F1D can reproduce both low and high frequencies (bi-amp operation), while the SR-L1B clearly
reproduces super-low frequencies. Both systems are used in conjunction with the DP-0206 Digital
Processor.
• The SR-F1D reproduces low frequencies with excellent transient response thanks to its high-efficiency
30 cm woofer with large 20 cm diameter magnet.
• The SR-F1D's driver employs a titanium diaphragm and features high sound quality and high power handling
capability. Its constant directivity horn (60° horizontal x 40° vertical) has a smoothed cross-sectional area
and provides a uniform sound field and smooth sound quality.
• The SR-L1B's 38 cm woofer consists of a strong magnetic circuit employing a large 20 cm diameter magnet
and a 72 mm diameter long voice coil. This combination permits ultra-linearity down to super-low
frequencies while realizing high power handling capability.
• The enclosure is constructed of high-strength Apiton plywood. Since the outside surface is covered in FRP
(glass fiber-reinforced plastic), the speaker also features high durability to stand up to rough handling when
used on the road.
• NEUTRIK NL4MPR input connectors ensure quick and accurate system field installations.
• The SR-F1D features flying hardware (Aeroquip ring/stud pan fittings) installed on its top and bottom. The
bottom surface is also equipped with built-in nuts for mounting on an optional stand.
• Because the sides of the SR-F1D's enclosure are angled at 15°, when multiple speakers are arranged side-
by-side, they can be oriented in a radial array, which helps suppress mutual interference at high frequencies.
• When one SR-F1D is installed
on the SR-L1B
• When two SR-F1Ds are
installed on the SR-L1B
SR-F1D
SR-L1B
SR-F1D
SR-L1B
Align with the front surface
of the SR-L1B.
4. INSTALLING THE SR-F1D ON THE SR-L1B

6
5. FLYING (SR-F1D ONLY)
Two flying methods can be performed: 1) direct suspension using the SR-F1D's flying hardware (refer to the
figures below), and 2) suspension using optional flying hardware (refer to p. 7).
•Be sure to refer flying construction work to the dealer from whom the speaker was purchased.
•Avoid flying methods other than those described in this section.
Otherwise, the suspension wires or belts may be off or snap and the speaker may fall off, causing
personal injury.
Shown below are the general flying methods:
•Use the pan fitting rings attached to the speaker's top and/or bottom.
•Provide at least two suspension points on each speaker's top.
•The maximum number of speakers that can be suspended vertically
is three.
SR-F1D's flying hardware
WARNING
Do not suspend as illustrated below:
•Flying through only one
suspension point on the
top.
•Vertical suspension of 4 or
more speakers.
•Use of a single wire that
has formed a loop
•Flying through handles. •Flying using the nuts on
the bottom surface
5.1. Direct Suspension Using the SR-F1D's Flying Hardware

7
5.2. Suspension Using Optional Flying Hardware
5.2.1. SR-F1D speaker flying hardware system
The speaker flying hardware system is manufactured by ATM FLY-WARETM (ATM GROUP, Inc.) of the United
States for use with TOA's SR-F1D speaker. The flying system permits various speaker array configurations to
be constructed quickly and safely without using special components.
[System composition]
The flying system comprises 5 main components.
AMFS-SRF1-TH Truss Module
Allowable load 275 kg
The truss module attaches to both the top and
bottom of the SR-F1D speaker.
Note
Bolts, nuts, and other fixing hardware are included.
AMFS-1X2-30 Connecting Bar
Allowable load 278 kg
Used for horizontal speaker connection.
AMFS-1X2-SME Shackle Mount
Allowable load 225 kg
Used to set suspension points for vertical speaker
suspension. (Upper and lower speakers can be
suspended at different tilt angles.)
AMFS-1X2-SB Stacking Bracket
Allowable load 194 kg
Used to suspend multiple speakers connected close
to each other.
2.5QRP Quick Release Pin
Allowable load 835 kg
Has a lock function and connects individual parts
surely and quickly.
5
4
3
2
1
1
2
3
4
5
Hexagon bolt 3/8'' x 41/2''
Nut 3/8''
Spring washer 3/8''
Wedge
Truss module
Pan fitting ring
(at top and bottom of SR-F1D)
[Mounting truss module]
Use 2 pan fitting rings on the SR-F1D's top or bottom to
mount the truss module. Pass a hexagonal bolt*
through the module and pan fitting ring, then secure it
with a wedge*, spring washer*, and nut*.
* Supplied with the truss module
Be sure to use the supplied hardware when
mounting the truss module. The speaker may fall
off if other hardware is used, resulting in possible
personal injury.
WARNING

8
[Speaker array arranged in 2 speakers horizontal
x 3 rows vertical (6 speakers in total)]
[Speaker array assembly diagram]
1
2
3
4
5
[Hardware to be used]
Truss Module AMFS-SRF1-TH: 12
Connecting Bar AMFS-1X2-30: 6
Shackle Mount AMFS-1X2-SEM: 6
Stacking Bracket AMFS-1X2-SB: 4
Quick Release Pin 2.5QRP: 26
1
2
3
4
5
Note
For mounting truss module, refer to
the previous page.
5.2.2. Flying precautions
•Confirm the following points before installation.
1. Load on each flying hardware component does not exceed its allowable load.
2. All quick release pins (2.5QRP) are fully inserted into other components and locked.
3. All components used in suspension (i.e. enclosures, individual flying hardwares, clamps, connectors, and
suspension devices) are free from any deformation, crack and corrosion.
•The maximum number of speakers that can be suspended per shackle mount (AMFS-1X2-SME) or stacking
bracket (AMFS-1X2-SB) is four.
•Not more than three speakers are joined and suspended vertically.
5.2.3. Flying example

9
6. SPEAKER STAND FOR SR-F1D
The speaker stand manufactured by Köning & Meyer GMBH (K & M) of Germany is made available for use
with TOA's SR-F1D speaker.
The speaker stand consists of two main sections, which are sold separately.
Stand: Model 213
Bracket: Model 19582
Step 1. Extend the stand's legs.
Loosen the tripod fixing screw and open the tripod
legs outward so that the stays become level.
Then, tighten the fixing screw.
Height fixing screw
Tripod fixing screw
Tripod leg
Stay
Lock botton
Handle fixing screw
Height adjustment
handle
Plain washer
Plain washer
Treaded hole
Speaker mounting screw
Speaker mounting screw
Stand 213
SR-F1D
Stand bracket
19582
Storage of speaker mounting screws
1
2
3
4, 5
Bracket fixing
screw
Tip
To avoid the loss of the speaker mounting
screws, it is highly recommended that the
screws be inserted into the stand bracket
when putting away the stand.
Fully extend the stand's tripod legs and place
the stand on a stable surface. If the tripod is
not sufficiently extended, the stand could
topple over, possibly resulting in personal
injury.
WARNING
Step 4. Adjust the stand height.
4-1. Loosen the height fixing screw.
4-2. Loosen the handle fixing screw and raise the
handle, then retighten the handle screw.
4-3. While holding down the lock button, adjust the
speaker's height by turning the height adjustment
handle. (Clockwise rotation raises the speaker.)
Note
You cannot rotate the handle unless the lock button
is continuously pressed. To complete the height
adjustment, ensure that the shaft is locked when
the lock button is released. (This can be checked
by rotating the handle slightly.)
Step 5. Retighten the height fixing screw.
Note
Leave the handle folded back except when adjusting the
height.
Owing to the speaker's size and weight, be
sure that at least two persons are available to
install the speaker. Failure to do so could result
in personal injury.
WARNING
Step 2. Attach the stand bracket to the speaker using the
speaker mounting screws and plain washers.
Step 3. Loosen the bracket fixing screw, then place the
speaker on the stand.
After setting the speaker's orientation, retighten the
bracket fixing screw.

10
7. INPUT CONNECTOR
•Each speaker employes the NEUTRIK NL4MPR connector for its input. The mated cable connector is the
NEUTRICK NL4FC.
•Pins of the NEUTRIK connector are connected as shown in the table below.
* The "left" and the "right" are the positions of
woofer units as viewed from the front.
Pin number SR-F1D SR-L1B
1 + LOW + Left* +
1 –LOW –Left* –
2 + HIGH + Right* +
2 –HIGH –Right* –
8. CONNECTION DIAGRAMS
•It is recommended that TOA's IP-600D Power Amplifier be connected and used.
•The DP-0206 Digital Processor's compressor has been set based on a power amplifier gain of "20 dB."
When using the IP-600D amplifier, set the input volume control to the "–12 dB" position.
8.1. Single System (SR-F1D)
Mixer/Preamplifier
IN
HIGH
LOW
SR-F1D
Digital processor
DP-0206
Power amplifier
HIGH
LOW
SUB-LOW
SR-F1D
SR-L1B
Mixer/Preamplifier
IN
Digital processor
DP-0206
Power amplifier
Power amplifier
8.2. Combination System (SR-F1D and SR-L1B)
Right
SR-L1B
Left

11
9. PROCESSOR SETTINGS
Set the following parameters –for the DP-0206 Digital Processor. Perform settings for either the "flat
phase type" (p. 12) or "minimum delay type" (p. 13) depending on the application.
Note
Refer to the DP-0206 Software Instruction Manual for setting instructions.
10
1
12
3
4
8
9
10
5
6
7

12
PEQ
1 1.25 k –5.0 1.414
2 1.80 k –3.0 4.318
3 2.90 k –0.5 4.318
4 3.75 k –4.0 4.318
5 5.40 k –4.0 4.318
Freq. Gain Q
INPUT 1
OUTPUT 1
SR-L1B
SUB-LOW
X-over
Freq.Type
HPF
LPF 6 dB 29
QQ2
Gain Polarity Delay
8.5 Inverse 0.667
Filter
Type
1
2
LPF (6 dB)
Low Shelving
330
40 2.5
Freq. Gain Q
Comp.
Thresh
Ratio
Sync
Attack
Release
13
4 : 1
off
20
200
OUTPUT 2
SR-F1D
LOW
X-over
Freq.Type
12 dB BW
HPF
LPF
24 dB BS 700
20
QQ2
Gain Polarity Delay
0 Normal 0.5
Comp.
Thresh
Ratio
Sync
Attack
Release
10
2 : 1
off
10
100
Filter
Type
1 PEQ 95 –1.5 4.318
2 PEQ 462 –1.5 4.318
3 PEQ 1.80 k –12.0 9.889
4 PEQ 2.00 k –2.0 4.608
Freq. Gain Q
OUTPUT 3
SR-F1D
HIGH
X-over
Freq.Type
12 dB BW
HPF
LPF
900
QQ2
Gain Polarity Delay
–5.5 Inverse 0
Comp.
Thresh
Ratio
Sync
Attack
Release
15
4 : 1
off
10
100
1
2
3
4
5
6
7
8
9
10
Filter
Type
PEQ 13.6 k 7.5 1.414
All Pass 2.94 k 1.414
All Pass 3.87 k 1.119
All Pass 5.00 k 2.871
All Pass 6.90 k 4.608
All Pass 8.40 k 4.318
All Pass 9.95 k 5.764
All Pass 11.6 k 7.689
All Pass 13.1 k 9.889
All Pass 14.6 k 6.919
Freq. Gain Q
1
2
3
4
5
6
7
8
9
10
*
*
*
9.1. Flat Phase Type
•Phase characteristics for the driver's band are nearly flattened using all-pass filters (APF).
•Set parameters –for the DP-0206 as follows:
10
1
* The DP-0206 Digital Processor's compressor has been set based on a power amplifier gain of "20 dB."
When using the IP-600D amplifier, set the input volume control to the "–12 dB" position.
•In the above parameter setting, the polarity checker indication for each frequency band is as follows:
Polarity
SR-L1B Negative
SR-F1DLOW Positive
SR-F1DHIGH Positive

13
X-over
Freq.Type
HPF
LPF 6 dB 30
QQ2
Gain Polarity Delay
8.5 Inverse 0
Filter
Type
1
2
LPF (6 dB)
Low Shelving
330
40 2.5
Freq. Gain Q
Comp.
Thresh
Ratio
Sync
Attack
Release
13
4 : 1
off
20
200
INPUT 1 OUTPUT 1
SR-L1B
SUB-LOW
X-over
Freq.Type
HPF
LPF
24 dB BS 702
12 dB BW 20
QQ2
Gain Polarity Delay
0 Normal 0
Comp.
Thresh
Ratio
Sync
Attack
Release
10
2 : 1
off
10
100
OUTPUT 2
SR-F1D
LOW
Filter
Type
1
2
PEQ
PEQ
131
275 –2.0
Freq. Gain Q
–2.0 4.318
4.318
3
4
PEQ
PEQ
380
1.80 k –12.0
–3.0 8.651
9.889
5 PEQ 2.00 k –2.0 4.608
X-over
Freq.Type
HPF
LPF
QQ2
Gain Polarity Delay
–5.5 Normal 0
Comp.
Thresh
Ratio
Sync
Attack
Release
15
4 : 1
off
10
100
OUTPUT 3
SR-F1D
HIGH
12 dB BW 900
Filter
Type
1
2
High Shelving
PEQ
16.0 k
1.00 k –2.0 4.318
3 PEQ 1.40 k –5.0 1.414
4 PEQ 2.90 k –1.0 4.318
5 PEQ 3.75 k –4.0 4.318
6 PEQ 5.30 k –4.0 4.318
7 PEQ 13.2 k 7.5 2.016
8 PEQ 15.0 k 3.0 4.318
Freq. Gain
5.0
Q
2
3
4
5
6
7
8
9
10
*
*
*
9.2. Minimum Delay Type
•Designed to provide a minimum signal delay without using a delay function or APF for each frequency band.
•Set parameters –for the DP-0206 as follows:
10
2
* The DP-0206 Digital Processor's compressor has been set based on a power amplifier gain of "20 dB."
When using the IP-600D amplifier, set the input volume control to the "–12 dB" position.
•In the above parameter setting, the polarity checker indication for each frequency band is as follows:
Polarity
SR-L1B Negative
SR-F1DLOW Positive
SR-F1DHIGH Negative

14
110
[dB]
100
90
80
70
60
20 50 100 500 1 k 5 k 10 k 20 k
[Hz]
Frequency
SPL
SR-F1D + SR-L1B
SR-L1B
SR-F1D LOW
SR-F1D HIGH
[deg]
180
90
0
–90
–180
20 50 100 500
Frequency
1 k 5 k 10 k 20
k
[Hz]
Phase
110
[dB]
100
90
80
70
60
20 50 100 500 1 k 5 k 10 k 20 k
[Hz]
SR-F1D + SR-L1B
SR-L1B
SR-F1D LOW
SR-F1D HIGH
Frequency
SPL
[deg]
180
90
0
–90
–180
20 50 100 500 1 k 5 k 10 k 20
k
[Hz]
Frequency
Phase
10. CHARACTERISTIC DIAGRAMS
Note: Referenced to 200 Hz in the SR-F1D's LOW band, 1 W 1 m
10.1. SR-F1D + SR-L1B (when DP-0206 is used)
10.1.1. Flat phase type
10.1.2. Minimum delay type
Phase Characteristics
Frequency Characteristics
Frequency Characteristics
Phase Characteristics

15
0°
10
10
0
0
–10
–10
–20
–20
–30
–30
–40
–40
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
0°
10
10
0
0
–10
–10
–20
–20
–30
–30
–40
–40
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
HornWoofer
1,000 Hz
2,000 Hz
4,000 Hz
8,000 Hz
10.2. SR-F1D (when DP-0206 is used)
[Polar pattern]
Horizontal Vertical
11. DIMENSIONAL DIAGRAMS
2-M8 Nut (For mounting to an optional speaker stand)
120
390
221
829 606
224 619
629
364
[SR-F1D] [SR-L1B]
Unit: mm

12. SPECIFICATIONS
Enclosure Bass reflex type
Power Handling Continuous pink noise: 120 W (Low frequency)*1, 80 W (High frequency)*2
Capacity Continuous program: 360 W (Low frequency), 240 W (High frequency)
Rated Impedance Low frequency: 8 Ω, High frequency: 16 Ω
Sensitivity Low frequency: 98 dB (1 W, 1 m), High frequency: 110 dB (1 W, 1 m)
Frequency Response 70 –20,000 Hz at DP-0206's use
Crossover Frequency 1,000 Hz at DP-0206's use
Speaker Component Low frequency: One 30 cm dia. cone-type
High frequency: CD horn (60°horizontal by 40°vertical) plus compression driver
Input Connector NEUTRIK NL4MPR
Finish Enclosure: FRP coating, gray
Front grill: Black, paint
Dimensions 390 (w) x 619 (h) x 364 (d) mm
Weight 37 kg
Printed in Japan
133-01-431-60
[SR-F1D]
*1Band limited (50 –1,000 Hz) pink noise signal (24 hrs.)
*2Band limited (1,000 –20,000 Hz) pink noise signal (24 hrs.)
*3Band limited (40 –1,000 Hz) pink noise signal (24 hrs.)
Note: The design and specifications are subject to change without notice for improvement.
Enclosure Bass reflex type
Power Handling Continuous pink noise: 150 W x 2*3
Capacity Continuous program: 450 W x 2
Rated Impedance 8 Ωx 2
Sensitivity 96 dB (0.5 W x 2, 1 m)
Frequency Response 35 –1,000 Hz
Crossover Frequency 125 Hz at DP-0206's use
Speaker Component Two 30 cm dia. cone speakers
Input Connector NEUTRIK NL4MPR
Finish Enclosure: FRP coating, gray
Front grill: Black, paint
Dimensions 829 (w) x 629 (h) x 606 (d) mm
Weight 79 kg
[SR-L1B]
