Tobi KB-1126 User manual

Distributed by:
Thane Direct Canada, Inc. Toronto ON,
www.thane.ca
Thane Direct UK Ltd. Admail ADM3996 London W1T 1ZU
www.thanedirect.co.uk
Wo r l d ’ s f i r s t u p r i g h t a n d p o r t a b l e
w r i n k l e r e m o v a l m a c h i n e
INSTRUCTION
MANUAL
Read this booklet thoroughly before using
and save it for future reference
INSTRU CTI ON
MANUAL
Model #KB-1126

I N S T R U C T I O N M A N U A L
Table of Contents
❖IMPORTANT SAFEGUARDS: 02
❖THE TOBI™ FEATURES 03
❖SPECIAL INSTRUCTIONS 04
Know your Tobi 04
Before your first use 06
❖ASSEMBLY INSTRUCTIONS 06
Assembling and mounting the Telescopic Pole 06
Attaching the hose 07
Attachments (Upholstery & Pet/lint hair attachment) 07
❖OPERATING INSTRUCTIONS 08
❖HOW TO STEAM 09
❖QUICK STORAGE 10
❖CLEANING AND LONG-TERM STORAGE 10
❖CLEANING MINERAL DEPOSITS 11
❖TOBI MAINTENANCE 12

I N S T R U C T I O N M A N U A L
02
I N S T R U C T I O N M A N U A L
03
IMPORTANT SAFEGUARDS:
When using your TOB
i™
, basic precautions should always be followed, including the following:
1. Read all instructions prior to usage.
2. To reduce the risk of contact with hot water and steam, always check TOB
i™
for steam
leaks. Make sure the steam nozzle is placed in its holder prior to switching on and
inspecting the base hose, handle and nozzle for leaks.
3. Do not use TOB
i™
outdoors.
4. Steam only in an up and down vertical motion (except when steaming bedding directly
on bed). Never use steamer in a horizontal position or tilt into a backward position, this
may result in water discharge.
5. Never force the plug into an outlet. Check that the main voltage corresponds to the
voltage indicated on the rating label, see specifications below:
TUV/UK 220-240V 50/60Hz 1500W with power cord current 15A.
6. Avoid contact with hot parts. Keep hands, hair, and clothing away from hot parts to
prevent burns.
7. To protect against fire, from electric shock and injury do not immerse TOB
i™
in water
or other liquids.
8. Tobi is not a toy. Close supervision is necessary when any appliance is used by or
near children.
9. Always disconnect from outlet when not in use and before cleaning. Allow it to cool
before putting on or taking off parts, and before cleaning the appliance.
10. Always disconnect Tobi from outlet when filling with water, emptying water tank, and
when not in use.
11. Do not operate any appliance with a damaged cord or plug. Stop use immediately if
TOB
i™
malfunctions, or has been damaged in any manner.
12. The use of accessory attachments that do not come with the TOB
i™
may result in fire,
electric shock or injury to persons.
13. Do not let cord hang over edge of table or counter, or touch hot surface. The power
cord should not be kinked or obstructed in any way.
14. Do not allow cord to touch hot surfaces. Let appliance cool completely before storing.
15. Always keep the steam nozzle elevated above water container. Do not lay hose on
the floor.
16. Do not operate TOB
i™
without properly filling the water container.
17. Always turn the switch to the “OFF” position before plugging in or unplugging
the unit.
18. Never pull the power cord to disconnect it from an outlet. Instead, grasp the plug to
remove it from the outlet.
19. Do not use TOB
i™
for other than intended use.
20. Never attempt to steam clothing while on body.
21. SAVE THESE INSTRUCTION.
HOUSEHOLD USE ONLY
The Tobi Features
❖Easy On/Off switch.
❖Easy grip handle.
❖30 second start up time.
❖30 minutes continuous steam.
❖Lightweight, flexible hose.
❖Shatterproof water tank.
❖Automatic shut-off. TOB
i ™
automatically
shuts off when water tank is empty.
❖Comfortable, easy-grip handle.
❖Height adjustable hanger pole.
❖Easy-roll casters for mobility.
❖Upholstery attachment.
❖Pet hair attachment.
❖Travel bag - store main unit, hose and carry
strap in this bag. The bag is not made for
the pole or Tobi's rollable base.

I N S T R U C T I O N M A N U A L
04
I N S T R U C T I O N M A N U A L
05
SPECIAL INSTRUCTIONS
1. To reduce the likelihood of a circuit overload, do not operate another
high-wattage appliance on the same circuit as Tobi.
2. If an extension cord is absolutely necessary, a 15 amps rated cord should be
used. Cords rated for less amperage may overheat. Care should be taken to
arrange the cord so that it cannot be inadvertently pulled or tripped over.
Know your TOB i™
1. Pole Top - The Pole Top is comprised of the Clothes Hanger Hook (1a) and Steam
Nozzle Holder (1b). The Clothes Hanger Hook allows you to steam garments right
on the hanger.
1a. The Clothes Hanger Hook allows you to steam clothing right on the hanger.
The groove in the Hanger Hook fits any hanger. Lightly click a hanger in the
groove to help the hanger stay in place while steaming.
2. Pole - The Pole with the Telescopic Pole (2a) with the Pole Extension (2b) /
connects the Pole top to the steamer and provides quick, compact storage of
the unit. The Telescopic Pole is comprised of Part 2A and Part 2B part
(SEE FIG.1).
3. Pole Base - The Pole Base ensures a stable mount for the Pole.
4. Steam Nozzle - The Steam Nozzle spreads the steam over a wide area providing
hot, penetrating steam.
5. Handle - The Handle is permanently attached to the Steam Nozzle. Use the
handle to safely direct the steam onto the desired fabric.
6. Steam Hose - The Hose directs the steam from the Main Unit to the Handle
and Steam Nozzle. Never pull, bend or wrap the hose, it will damage the hose
and result in steam leak. During the operation, do not touch the Steam Hose.
It gets very hot and can burn or scald your skin.
7. Hose Base - The Hose Base is a threaded plastic pipe for the attachment of
the Hose.
8. Power Cord - Connects the Main Unit to the power outlet.
9. Unit Base - When operating TOB i
™
, fix the Main Unit on the rollable base.
If you require TOB
i
™
to be portable, attach the carrying strap and press
Release Button (#18 ) and place Tobi on your shoulder.
10. Casters - There are four roll casters, allow for ease of movement.
11. Drain Switch - Drain the water in the Main Unit by turning the
Drain Switch to the “OPEN” position. Make sure you tighten securely to avoid
water leakage.
12. Lighted Switch - When plugging the power outlet, turn it to the “ON” position,
the light will be illuminated.
13. Main Unit - The water in the water tank will flow into the Main Unit.
14. Water Tank - Water Tank is removable from the Main Unit. Unscrew valve cap,
fill to the max line and place the tank back on to the Main Unit.
15. Shoulder Strap - When operating TOB
i
™
in portable mode, use the Shoulder
Strap for easy portability.
16. Upholstery Attachment - Upholstery Attachment is suitable for breathing new life
into sofa’s, cushions, chairs and drapes. Attach to Steam Nozzle.
17. Lint/Pet-hair remover - It is suitable for removing lint and stubborn pet hair
from your clothes and upholstery while refreshing them at the same time.
Attach to Steam Nozzle.
18. Release Button - Press the Release Button to take out the Main Unit to make
TOB i
™
portable.

Abb. 4
Abb. 2 Abb. 3
I N S T R U C T I O N M A N U A L
07
I N S T R U C T I O N M A N U A L
06
Before your first use:
1. 1. Remove any packaging and factory labeling from TOB
i
™
.
2. Assemble TOB
i
™
according to the assembly instruction section, then fill the
Water Tank with water at the max level, then operate TOB i
™
according to the
operation instructions.
Assembly Instructions
I. Assembling and mounting the Telescopic Pole. (SEE FIG.1)
1. Loosen the ridged knob of the pole by turning it counterclockwise. Insert the
Telescopic Pole (#2A ) into the Pole (#2). Tighten the ridged knob by turning
it clockwise.
2. Loosen the ridged knob of the Telescopic Pole (#2A) part by turning it counter
clockwise. Insert the Pole Extension (#2B) into the Telescopic Pole (#2A) part.
Tighten the ridged knob by turning it clockwise.
3. Screw the Pole Extension (#2B) onto the Telescopic Pole (#2A) by turning the
Pole Extension (#2B) clockwise.
4. Place the Pole Top (#1) on top of the Pole Extension (#2B) and turn it clock
wise until lock.
NOTE: The Telescopic Pole must be fully extended during operation of the TOB
i
™
to ensure a free flow of steam through the Hose.
Fig. 1
5. Loosen the Pole Base (#3) by turning it counterclockwise.
6. Insert the bottom of the Pole into the Pole Base (SEE FIG. 2) in such a way so
that the Clothes Hanger Hook faces the rear of the TOB i
™
. Pointing the Clothes
Hanger Hook towards the rear will ensure the stability of TOB
i ™
when garments
are hanging from the Clothes Hanger Hook.
7. Push the Pole down as far as possible.
8. Tighten the Pole Base by turning the ridged knob clockwise.
Fig. 2 Fig. 3
II. Attaching the hose
1. Screw the Hose onto the threaded
Hose Base by turning the fitting on
the end of the Hose clockwise (SEE FIG.3).
2. Hand-tighten only. Do not over-tighten.
3. Hang the steam Nozzle on the Steam Nozzle Holder.
CAUTION: To prevent steam from causing bodily injury or damage to surface,
always hang the Steam Nozzle on the Steam Nozzle Holder when not in use. Do
not lay the Hose on the floor as condensation may occur, causing unwanted
water droplets in the steam.
CAUTION: Pulling on the Hose with excessive force will damage the Hose, result-
ing in a steam leak.
III. Attachments (Upholstery & Pet/lint hair attachment)
1. Turn TOB
i
™
off, and wait until steam no longer emits from
the Steam Nozzle.
CAUTION: To avoid burns, do not try to install the
attachments while steam is coming from the Steam Nozzle.
2. Align the pegs along the back of the attachments with
the holes on the Steam Nozzle.
3. Push as shown in FIGURE 4 until the attachments is firmly in place.
Fig. 4

1. Unplug the Power Cord, and turn the
Lighted Switch to the “OFF” position.
2. Remove the Water Tank; turn it upside
down, and unscrew the Valve Cap
(SEE FIG.5)
3. Fill the Water Tank with cool water, and
replace the Valve Cap.
4. Place the Water Tank on the Main Unit
(SEE FIG.6). You should hear water flowing
into the Main Unit for a short time.
CAUTION: Do not operate TOB
i
™
with a dry
Water Tank. When operating, if you want to add water,
first turn the Lighted Switch to “OFF” position, before
removing the Water Tank to avoid burning yourself.
5. Plug TOB
i
™
into a grounded three-pronged outlet.
Warning: If a grounded three-pronged outlet is not
available, a 3-to-2 prong adapter can be used only
if the adapter itself is properly grounded.
6. Turn the Lighted Switch to “ON” position, the light
will be illuminated.
7. Steam should start flowing from the Steam Nozzle.
Wait for steam to heat sufficiently otherwise you will
create wet spots. Wait at least 30 seconds.
8. To steam a garment, place item of clothing on the hanger and steam directly on
the Hanger Hook.
Caution: Be careful when handling garments on the Clothes Hanger Hook.
Pulling on the garment with too much force may cause TOB i
™
to tip.
9. Grasp the handle, and place the Steam Nozzle at the top of the garment. Steam
will rise along the inside and outside of the fabric, removing wrinkles. Slowly
slide the Steam Nozzle vertically, from the top to the bottom of the garment.
You may also reverse this motion and steam from the bottom to the top.
Note: Do not allow kinks to form in the hose at any time.
I N S T R U C T I O N M A N U A L
09
I N S T R U C T I O N M A N U A L
08
Operating Instructions:
Fig. 5
10. Repeat steps 9 until the fabric is wrinkle free.
11. Curtains and draperies can be steamed while they are hanging. Press the
Release Button and use Shoulder Strap to put the Main Unit on the shoulder
for these items.
Note:
1. During steaming, make sure that the hose is fully extended to insure
a free flow of steam through it.
2. When removing the Main Unit from the Base, always use Shoulder Strap.
Assemble the Shoulder Strap on the Main Unit, by inserting the end of
the Shoulder Strap into the slot of the Main Unit. To remove the Shoulder
Strap press the round bump to release the Shoulder Strap.
12. When finished using TOB
i
™
, turn the Lighted Switch to the “OFF” position.
How to Steam
TOB
i
™
removes wrinkles from all your clothes five times faster than iron. It works
on virtually all fabrics, silk, denim, cotton, polyester and wool. PLEASE REFER TO
LABEL ON ITEM OF CLOTHING TO CHECK IF GARMENT CAN BE STEAMED.
SOME FABRICS LIKE LEATHER, SUEDE, VELVET MAY NOT BE SUITABLE FOR
STEAMING. IF YOU ARE NOT SURE THEN STEAM A SMALL PART OF THE
INSIDE OF THE GARMENT TO TEST THAT IT DOES NOT DAMAGE THE FABRIC
BEFORE STEAMING THE ENTIRE GARMENT OR FABRIC.
❖Some articles can be steamed better from the underside. This allows the
steam to relax the fibers of the material, thus removing the wrinkles.
❖Pants may be easily steamed by holding them by the cuff.
❖When steaming, touch material lightly with Steam Nozzle and move up and
down to remove wrinkles. It is important that Steam Nozzle makes contact with
the garment and/or fabric.
❖Always steam with hose in upright position so any condensation is free to flow
back into the steamer. If steaming in a low position near floor, frequently
extend Hose up and out to keep clear.
❖ TOB
i
™
helps to eliminate trips to the drycleaner by helping to reduce odors. It
will not remove stains from garments.
❖Convenient hanger/hook mechanism holds both the clothes and steam
head securely.
Fig. 6

I N S T R U C T I O N M A N U A L
11
I N S T R U C T I O N M A N U A L
10
❖Use TOB
i
™
directly on sheets while on the bed to smooth out and
remove wrinkles.
❖Use TOB
i
™
directly on mattresses and pillow cases to help
eliminate dust-mites.
❖Use TOB
i
™
directly on upholstery to help refresh and breathe new life into
sofas and chairs.
Quick Storage
1. Turn the Lighted Switch to “OFF”.
2. Unplug the Power Cord.
3. Wrap the Hose around the Telescopic Pole one time.
4. Hang the Steam Nozzle from the Steam Nozzle Holder.
5. Loosen the two ridged knobs on the Telescopic Pole by turning them
counterclockwise.
6. Push down on the Pole Top, the Telescopic Pole will collapse to a
compact height.
7. Roll TOB
i
™
to a convenient storage location.
Cleaning and Long-term Storage
We recommend you follow this procedure at least once per month. Use of distilled
or de-mineralized water will help to reduce the need for cleaning and prolong the
life of TOB
i
™
. However, you can use ordinary tap water as well.
1. Turn the Lighted Switch to “OFF”.
2. Unplug TOB
i
™
from the power outlet.
3. Wait for TOB
i ™
to cool completely.
4. Disassemble the Hose and the Telescopic Pole, and set them aside.
5. Carry the Main Unit to a sink or tub.
6. Remove and drain the Water Tank, rinse the Water Tank with fresh water,
and drain completely.
7. Drain the steamer by unscrewing the drain switch out and empty the contents
into the sink or tub. Tilt the unit towards the drain plug to facilitate removal of
the water. Then screw on the switch.
8. Flush the Main Unit by filling the Water Tank with fresh water and
draining completely.
9. Assemble the Telescopic Pole and Hose.
10. Follow steps 3-7 of the quick storage section.
Cleaning Mineral Deposits
One common problem with all steamers is mineral deposit caused by a high miner-
al content in many municipal water supplies. Mineral residue inside of the internal
pipes and heater can cause intermittent steaming or, in some cases, no steaming
at all.
Note: To reduce or eliminate the occurrence of mineral deposit, we recommend the
use of de-mineralized or distilled water in the Main Unit. However regular tap
water can also be used.
The section below can be used to reduce mineral deposit. If not using de-
mineralized or distilled water, we recommend you follow this procedure monthly.
1. Turn TOB
i
™
“OFF” and unplug the power cord.
2. Remove the Hose and Pole from the Main Unit.
3. Mix a solution of 50% vinegar and 50% water. Two cups of this solution will
be sufficient.
4. Slowly pour the solution into the Water Tank and replace the Valve Cap.
5. Place the Water Tank on the Main Unit. You should hear water flowing into the
Main Unit for a short time.
6. Allow it to stand for 40 minutes.
7. Drain the solution out from the Water Tank into a sink or tub.
8. Pour clean water in the Main Unit and drain. Repeat this step until the vinegar
odor dissipates.
9. Reassemble Tobi and operate normally.

I N S T R U C T I O N M A N U A L
12
TOBI™ Maintenance
Clean and rinse your Tobi regularly:
All steamers need to be cleaned and rinsed on occasion to remove mineral
deposits. If steam from the TOB
i
™
becomes intermitted or stops altogether please
refer to the section on cleaning of mineral deposits.
Never Use additives:
Additives such as salt, perfumes and dyes should never be added to the Water
Tank. These substances will corrode or clog internal parts.
Steam in a vertical, upright position:
Do not use your TOB
i
™
in horizontal position like an iron. Steam in a vertical up
and down motion. This will allow the condensation in the hose to flow back into
the Main Unit.
Do not pull Tobi by the power cord:
Pulling TOB
i
™
by the power cord may cause the internal wiring to become loose.
Never use your foot to turn Tobi ON/OFF:
Damage may occur to the power switch should you turn the unit off using excess
pressure with your foot.
Storing Tobi:
Before storing TOB
i
™
for an extended period (30 days or more), empty all water
from the Main Unit. Water becomes stale with time and may clog internal parts.
