Tommy Bahama BAHAMA BREEZES User manual

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
Net Weight:
19.0 Lbs.
Part No. F40BP728900001 Form No. BP7289-1
READ AND SAVE THESE INSTRUCTIONS
TB344AP00
Antique Pewter
TB344BBR00
Brushed Brass
TB344CW00
Colonial White
TB344DBZ00
Distressed Bronze
BAHAMA BREEZES
Damp Location
Ceiling Fan Owner's Manual
Model Numbers
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 1

WARNING: To avoid fire, shock, and serious personal injury, follow these
instructions. Safety Instructions
1. Read your ownerÕs manual carefully and keep it for future reference.
2. Before servicing or cleaning unit, switch power off at service panel and lock
service panel disconnecting means to prevent power from being switched on
accidentally. When the service disconnecting means cannot be locked, securely
fasten a warning device, such as a tag, to the service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the
fan. Always turn off the power to the ceiling fan before servicing.
4. Do not put anything into the fan blades while they are turning.
5. Do not operate reversing switch until fan blades have come to a complete stop.
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned off at the fuse box before
wiring, and do not operate fan without blades.
2. The installation is to be in accordance with the National Electrical Code,
ANSI/NFPA 70-1999 and Local Codes. Use the National Electrical Code if Local
Codes do not exist. The ceiling fan must be grounded as a precaution against
possible electrical shock. Electrical installation should be made or approved by
a licensed electrician.
3. The outlet box and joist must be securely mounted and capable of reliably
supporting at least 50 pounds. Use only U.L. outlet boxes listed as ÒAcceptable
for Fan SupportÓ, and use the mounting screws provided with the outlet box.
Most outlet boxes commonly used for support of light fixtures are not accept-
able for fan support and may need to be replaced. Consult a qualified electri-
cian if in doubt.
4. The fan must be mounted with the fan blades at least 7 feet from the floor to
prevent accidental contact with the fan blades.
5. Follow the recommended instructions for the proper method of wiring your
ceiling fan. If you do not know enough about electrical wiring, have your fan
installed by a licensed electrician.
NOTE: This fan is suitable for use with solid-state speed controls.
WARNING: To avoid fire, shock or injury, do not use a Tommy Bahama or any
other brand of control not specifically approved for this fan.
WARNING: This product is designed to use only those parts supplied with this
product and/or any accessories designated specifically for use with this product by
Emerson Electric Co. Substitution of parts or accessories not designated for use
with this product by Emerson Electric Co. could result in personal injury or
property damage.
WARNING: To reduce the risk of personal injury, do not bend the blade flange
when installing the blade flanges, balancing the blades or cleaning the fan. Do not
insert foreign objects in between rotating fan blades.
!WARNING
DATE CODE:
The date code of this fan may be found on the box, stamped in ink on a white label.
You should record this data above and keep it in a safe place for future use.
2
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 2

3
THIS FAN IS SUITABLE FOR DAMP LOCATIONS SUCH AS
COVERED PORCHES, COVERED PATIOS, AND COVERED DECKS...
ANYWHERE THERE IS A ROOF OVERHEAD.
Tools Needed for Assembly
One Phillips head screwdriver
One wire stripper
One stepladder
One 5/32Ó hex wrench (supplied)
Four wire connectors (supplied)
Materials
Wiring, outlet box and box connec-
tors must be of type required by the
local code. The minimum wire would
be a 3-conductor (2-wire with
ground) of the following sizes:
This Manual Is Designed to Make it as Easy as Possible for You to
Assemble, Install, Operate and Maintain Your Ceiling Fan
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
Before assembling your ceiling fan,
refer to section on proper method of
wiring your fan (page 9). If you feel you
do not have enough wiring knowledge
or experience, have your fan installed
by a licensed electrician.
!WARNING
Unpacking Instructions
For your convenience, check-off boxes are provided next to each step. As each
step is completed, place a check mark in the box. This will insure that all
steps have been completed and will be helpful in finding your place should
you be interrupted.
Do not install or use fan if any part is
damaged or missing. Call Toll-Free:
1-800-654-3545
!WARNING
This product is designed to use only
those parts supplied with this product
and/or any accessories designated
specifically for use with this product by
Emerson Electric Co. Substitution of
parts or accessories not designated for
use with this product by Emerson
Electric Co. could result in personal
injury or property damage.
!WARNING
1. Open styrofoam unit containing
fan. Remove top half of styrofoam
unit. Remove parts and check to
see that you have received the fol-
lowing parts:
NOTE: If you are uncertain of part
description, refer to exploded view
illustration.
a. Fan motor and housing assembly
b. One ceiling cover
c. One motor cover
d. Five blade flanges
e. One hanger bracket
f. One hanger ball/downrod assembly
g. One switch housing cover
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 3

Your new ceiling fan will require a
grounded electrical supply line of
120 volts AC, 60 Hz, 15 amp circuit.
The outlet box must be securely
anchored and capable of withstand-
ing a load of at least 50 pounds.
4
To reduce the risk of fire, electric
shock, or personal injury, mount fan to
outlet box marked ÒAcceptable for Fan
SupportÓ, and use screws supplied with
outlet box. Most outlet boxes common-
ly used for support of light fixtures are
not acceptable for fan support and may
need to be replaced. Consult a qualified
electrician if in doubt.
!WARNING
h. One loose parts bag containing:
1. One 5/16-18 x 1/4Ó setscrew
2. One 5/32Ó hex wrench
3. Two 1Ó threaded studs
4. Two 1-1/4Ó threaded studs
5. Four knurled knobs
6. Four lockwashers
7. Four wire connectors
8. One hibiscus pendant
9. One bell pendant
10. Two couplings
11. One clevis pin/hairpin clip
assembly
CH
E
AG
D
F
B
Electrical Requirements
12. Eleven 10-32 x 3/4Ó oval head
screws
13. Twenty-one 10-32 x 5/16Ó
Phillips pan head screws
14. Twenty-one #10 flat washers
15. Two 8-32 x 3/8Ó pan head
screws
NOTE: Place the parts from the loose
parts bags in a small container to
keep them from being lost. If any
parts are missing, contact your local
retailer or catalog outlet for replace-
ment before proceeding.
If your fan is to replace an existing
ceiling light fixture, turn electricity
off at the main fuse or circuit break-
er box at this time and remove the
existing light fixture.
Turning off wall switch is not suffi-
cient. To avoid possible electrical
shock, be sure electricity is turned off
at the main fuse or circuit breaker box
before wiring. All wiring must be in
accordance with National and Local
codes and the ceiling fan must be prop-
erly grounded as a precaution against
possible electrical shock.
!WARNING
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 4

DOWNROD
CLEVIS
PIN
5/16-18" x 1/4"
SETSCREW
MOTOR
COUPLING
HAIRPIN
CLIP
5
IMPORTANT: If you are going to use
a Tommy Bahama remote control and
receiver to control your fan, perform
the instructions in this OwnerÕs
Manual in conjunction with the
instructions contained in the remote
control/receiver OwnerÕs Manual.
1. Remove the fan motor and housing
assembly from the styrofoam pack-
aging and position it so that the
top of the motor is facing you.
2. Remove the hanger ball from the
downrod by loosening the
setscrew in the hanger ball until
the ball falls freely down the down-
rod (Figure 1). Remove the pin
from the downrod, then remove
the hanger ball. Retain the pin and
hanger ball for reinstallation in
step 8.
3. Separate, untwist and unkink the
three motor leads. Route the
motor leads through the downrod
and seat the downrod in the motor
coupling (Figure 2).
PIN
HANGER
BALL
SETSCREW
DOWNROD
Figure 1
Figure 2
The Tommy Bahama TB344 Series
Ceiling Fan is designed to be operat-
ed from wall switch(es), or from a
Tommy Bahama remote control/
transmitter. There are no controls
supplied with the ceiling fan.
How to Assemble Your Ceiling Fan
4. Align the clevis pin holes in the
downrod with the holes in the
motor coupling. Install the clevis
pin and secure with the hairpin
clip (Figure 2). (Pin and clip are
supplied in loose parts bag.) The
clevis pin must go through the
holes in the motor coupling and
the holes in the downrod. Push the
straight leg of the hairpin clip
through the hole near the end of
the clevis pin until the curved por-
tion of the hairpin clip snaps
around the clevis pin. The hairpin
clip must be properly installed to
prevent the clevis pin from work-
ing loose. Pull on the downrod to
make sure the clevis pin is proper-
ly installed.
To avoid possible fire or shock, follow
all wiring instructions carefully.
Any electrical work not described in
these instructions should be done or
approved by a licensed electrician.
!WARNING IMPORTANT: Your ceiling fan and
optional Tommy Bahama remote con-
trol will not function properly, and
may be damaged, it used with any
wall dimmer switch or control other
than Tommy Bahama Wall Control,
Model No. TBSW02. Use only this
Tommy Bahama Wall Control or a
listed general use on/off wall switch.
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 5

6
5. Install the 5/16-18 x 1/4Ó setscrew
(supplied) in the motor coupling
(Figure 2). While pulling up on the
downrod, tighten the setscrew
using the 5/32Ó hex wrench
(supplied).
NOTE: The setscrew must be proper-
ly installed as described above, or fan
wobble could result.
6. Screw two 1Ó threaded studs (sup-
plied) into the motor (Figure 3).
Leave approximately 7/8Ó of the
stud extending above the motor.
Coil the wires and wire connectors
around the motor coupling then
slide the motor cover over the
downrod and rotate the cover until
the threaded studs protrude.
Install two lockwashers and
knurled knobs (supplied) to secure
the cover to the motor. All wires
and wire connectors must be
enclosed under the motor cover.
NOTE: Lightly snug the knurled
knobs and make sure the wires and
wire connectors are completely
inside the motor cover and not
pinched between the motor cover and
the motor.
7. Position the ceiling cover over the
downrod. Be sure the cover is ori-
ented correctly, with the large
opening at the top (Figure 4).
!WARNING
It is critical that the clevis pin in the
motor coupling is properly installed
and the setscrew securely tightened.
Failure to verify that the pin and
setscrew are properly installed (as
shown in Figure 2) could result in the
fan falling.
!WARNING
It is critical that the pin in the hanger
ball is properly installed and the
setscrew securely tightened. Failure to
verify that the pin and setscrew are
properly installed could result in the
fan falling.
8. Reinstall the hanger ball on the
downrod (Figure 4) as follows.
Route the motor leads through the
hanger ball and slide the hanger
ball over the downrod. Install the
pin through the holes at the top of
the downrod and slide the hanger
ball up the downrod, aligning the
ball so the pin in captured in the
groove in the top of the hanger
ball. Pull the hanger ball up tight
against the pin and securely tight-
en the setscrew in the hanger ball.
A loose setscrew could create fan
wobble.
1" THREADED
STUD (2)
MOTOR
COVER
KNURLED
KNOB (2)
LOCKWASHER
(2)
Figure 3
DOWNROD
HANGER
BALL CEILING
COVER
PIN
SETSCREW
Figure 4
9. The fan comes with blue, black
and white leads that are 80-inch-
es long. Before installing the fan,
measure up approximately 6 to 9-
inches above top of hanger
ball/downrod assembly. Cut off
excess leads and strip back insu-
lation 1/2-inch from end of leads.
10. Use four 10-32 x 5/16Ó Phillips
pan head screws (supplied) and
four #10 flat washers to secure
the fan blade to the blade flange
(Figure 5). Repeat this procedure
for the remaining four blades.
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 6

7
NOTE: Some fan blades are thicker
than others and require longer
screws. If a bag of screws and wash-
ers is supplied with the TB500 Series
Blades (purchased separately) you
are installing, use these screws in
place of the screws supplied with the
fan.
10-32 x 5/16"
PAN HEAD SCREWS (4)
#10 FLAT
WASHERS (4)
FAN BLADE
BLADE
FLANGE
Figure 5
10-32 x 3/4" OVAL
HEAD SCREWS (2)
SWITCH
HOUSING
BLADE
FLANGE
MOTOR HUB
Figure 6
11. Turn the fan motor and housing
assembly upside down in prepa-
ration for mounting the fan
blades assemblies.
12. Use the 10 round recessed holes
in the motor hub that are marked
with a Ò5Ó and install the five
blade assemblies in accordance
with steps 13 through 15. The
switch housing has a slot to allow
easy access when tightening the
flange screws.
13. Insert two 10-32 x 3/4Ó oval head
screws (supplied) into the
recessed holes in one of the blade
flanges.
14. Align two of the round recessed
holes in the motor hub with the
slot in the switch housing
(Figure 6). Position the blade
flange on the motor hub so that
the screws in the blade flange
align with the two round
To reduce the risk of personal injury,
do not bend the blade flanges when
installing the flanges, balancing the
blades, or cleaning the fan. Do not
insert foreign objects between rotating
fan blades.
!WARNING
recessed holes in the motor hub.
Loosely tighten the screws at this
time. Then install the four
remaining blade assemblies in
the same way.
15. Gently snug all flange screws to
the motor hub, working around
the hub in a clockwise sequence.
Next, securely tighten all flange
screws, again working in a clock-
wise sequence. Failure to follow
this procedure could result in fan
wobble. This completes the blade
installation.
16. Pass the end of the longest pull
chain through one of the bush-
ings in the switch housing cover
(Figure 7). Slip the pull chain
through the hole in the hibiscus
pendant (supplied). Then secure
the pendant by snapping the cou-
pling (supplied) onto the end of
the chain.
17. Pass the end of the shortest pull
chain through the other bushing
in the switch housing cover.
Secure the bell pendant (sup-
plied) to this chain in the same
manner as above.
COUPLING
HIBISCUS PENDANT
BUSHING
SWITCH
HOUSING
COVER
SPEED CONTROL SWITCH
PULL CHAIN
Figure 7
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 7

8
How to Hang
Your Ceiling Fan
CEILING
FLOOR
AT LEAST 7'
Figure 9
1. Securely attach the hanger brack-
et to the outlet box using the two
screws supplied with the outlet
box (Figure 10).
The fan must be hung with at least 7' of
clearance from floor to blades (Figure 9).
!WARNING
The outlet box and joist must be secure-
ly mounted and capable of supporting
at least 50 lbs. Use only a U.L. outlet
box listed as ÒAcceptable for Fan
SupportÓ.
!WARNING
Failure to seat tab in groove could
cause damage to electrical wires and
possible shock or fire hazard.
!WARNING
To avoid possible fire or shock, do not
pinch wires between the hanger
ball/downrod assembly and hanger
bracket.
!WARNING
To reduce the risk of fire, electric
shock, or personal injury, mount fan to
outlet box marked ÒAcceptable for Fan
SupportÓ, and use screws supplied with
outlet box. Most outlet boxes common-
ly used for support of light fixtures are
not acceptable for fan support and may
need to be replaced. Consult a qualified
electrician if in doubt.
!WARNING
Hanger bracket must seat firmly
against outlet box. If the outlet box is
recessed, remove wall board until
bracket contacts box. If bracket and/or
outlet box are not securely attached,
the fan could wobble or fall.
!WARNING
TWO SCREWS
SUPPLIED WITH
OUTLET BOX HANGER
BRACKET
TAB
OUTLET
BOX
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD
ASSEMBLY
NOTE: CEILING COVER,
SUPPLY WIRES AND
FAN WIRES OMITTED
FOR CLARITY.
THREADED
STUD (2)
Figure 11
2. Carefully lift the fan and seat the
hanger ball/downrod assembly on
the hanger bracket that was just
attached to the outlet box (Figure
11). Be sure the groove in the ball
is lined up with the tab on the
hanger bracket (Figure 10).
18. Position the switch housing cover
on the switch housing and secure
using two 8-32 x 3/8Ó pan head
screws (supplied) (Figure 8).
8-32 x 3/8" PAN HEAD
SCREWS (3)
SWITCH
HOUSING
COVER
Figure 8
Figure 10
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 8

9
2. If you are going to control your
fan using two wall switches, you
will need a three-wire (with
ground) conductor cable between
the ceiling and wall outlet boxes.
This will allow you to operate the
optional Tommy Bahama Light
Fixture (if installed) from one
switch and the ceiling fan from a
separate switch. Refer to Figure
12 and proceed as follows:
Check to see that all connections are
tight, including ground, and that no
bare wire is visible at the wire connec-
tors, except for the ground wire. Do not
operate fan until blades are in place.
Noise and fan damage could result.
!WARNING
Turning off wall switch is not suffi-
cient. To avoid possible electrical
shock, be sure electricity is turned off
at the main fuse or circuit breaker box
before wiring. All wiring must be in
accordance with National and Local
codes and the ceiling fan must be prop-
erly grounded as a precaution against
possible electrical shock.
!WARNING
How to Wire Your Ceiling Fan
If you feel that you do not have
enough electrical wiring knowledge
or experience, have your fan
installed by a licensed electrician.
1. If you are going to use a Tommy
Bahama Remote Control/Receiver
or Wall Control/ Receiver to oper-
ate your ceiling fan, wire your fan
in accordance with the Control/
Receiver OwnerÕs Manual. After
wiring, return to step 4.
a. Connect the green grounding
lead from the hanger ball and
the green grounding lead
from the hanger bracket to
the supply grounding conduc-
tor (this may be a bare wire
or wire with green colored
insulation). Securely connect
wires with a wire connector
(supplied).
b. Securely connect the fan
motor white wire to the sup-
ply white (neutral) wire using
a wire connector (supplied).
c. Securely connect the fan
motor black wire to the sup-
ply black (hot) wire using a
wire connector (supplied).
d. Securely connect the fan
motor blue wire to the supply
red (hot) wire using a wire
connector (supplied).
e. After connections have been
made, separate the white and
green wires from the black,
blue and red wires.
f. Carefully turn the wires
upward and insert them up
through the open side of the
hanger bracket and into the
outlet box. Push the green
and white wires into one side
of the outlet box; push the
black, blue and red wires into
the other side of the outlet
box.
CAUTION: To reduce the risk of elec-
trical shock, disconnect the electrical
supply circuit before installing the
fan and optional light kit and/or
remote control receiver.
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 9

10
3. If you are going to use a single
wall switch to control your
ceiling fan and optional Tommy
Bahama Light Fixture (if instal-
led) simultaneously, you will
need a standard two-wire (with
ground) conductor cable between
the ceiling and wall outlet boxes.
The fan speed can then be operat-
ed from the pull chain switch in
the switch housing; the optional
light fixture can be operated
from the light fixture switch.
Refer to Figure 13 and proceed
as follows:
Check to see that all connections are
tight, including ground, and that no
bare wire is visible at the wire connec-
tors, except for the ground wire. Do not
operate fan until blades are in place.
Noise and fan damage could result.
!WARNING
a. Connect the green grounding
lead from the hanger ball and
the green grounding lead
from the hanger bracket to
the supply grounding conduc-
tor (this may be a bare wire or
wire with green colored
insulation). Securely connect
wires with a wire connector
(supplied).
b. Securely connect the fan
motor white wire to the sup-
ply white (neutral) wire using
a wire connector (supplied).
c. Securely connect the fan
motor black wire and blue
wire to the supply black (hot)
wire using a wire connector
(supplied).
d. After connections have been
made, separate the white and
green wires from the black
and blue wires.
e. Carefully turn the wires
upward and insert them up
through the open side of the
hanger bracket and into the
outlet box. Push the green
and white wires into one side
of the outlet box; push the
black and blue wires into the
other side of the outlet box.
BLACK BLACK FAN WIRE
LISTED OUTLET BOX
GREEN WIRE
(GROUND)
FROM
HANGER
BRACKET WHITE
GREEN WIRE (GROUND)
FROM HANGER BALL
GROUND
WIRE BLUE
RED
LISTED WIRE CONNECTOR (4)
LIGHT
SWITCH
TO 120
VOLT
SUPPLY
GROUND
WHT.
FAN SWITCH
BLACK
(HOT)
GROUND
THREE-CONDUCTOR CABLE
(WITH GROUND) BETWEEN
CEILING AND WALL OUTLET
BOXES
GENERAL PURPOSE
ON-OFF WALL
SWITCHES
Figure 12
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 10

11
CEILING
COVER
1-1/4"
THREADED
STUD
LOCKWASHER (2)
KNURLED
KNOB (2)
Figure 14
4. Screw the two 1-1/4Ó threaded
studs (supplied) into the tapped
holes in the hanger bracket
(Figure 11).
5. Lift the ceiling cover up to the
threaded studs and turn until the
studs protrude through the holes
in the ceiling cover (Figure 14).
6. Secure the ceiling cover in place
by sliding lockwashers (supplied)
over the threaded studs and
installing the two knurled knobs
(supplied). (Figure 14.) Tighten
the knurled knobs securely until
the ceiling cover fits snugly
against the ceiling.
To avoid possible fire or shock, make
sure that the electrical wire are com-
pletely inside the outlet box and not
pinched between the ceiling cover and
the ceiling.
!WARNING
Using Your Ceiling Fan
1. Restore electrical power to the
outlet box by turning the electrici-
ty on at the main fuse or circuit
breaker box.
2. Check the operation of the fan by
gently pulling on the 4-position
speed control switch pull chain
(the longest chain). The operating
sequence is as follows:
THREE-SPEED
1st PullÑHIGH
2nd PullÑMedium
3rd PullÑLow
4th PullÑOFF
SPEED CONTROL
SWITCH PULL CHAIN
REVERSING SWITCH
PULL CHAIN
Figure 15
BLACK FAN WIRE
LISTED OUTLET BOX
GREEN WIRE
(GROUND)
FROM
HANGER
BRACKET WHITE
GREEN WIRE (GROUND)
FROM HANGER BALL
GROUND
WIRE BLUE
BLACK
LISTED WIRE CONNECTOR (3)
GENERAL
PURPOSE ON/OFF
WALL SWITCH
TO 120
VOLT
SUPPLY
GROUND
WHT.
BLACK
(HOT)
GROUND
TWO-CONDUCTOR CABLE
(WITH GROUND) BETWEEN
CEILING AND WALL OUTLET
BOXES
Figure 13
7. Your ceiling fan is now installed
and wired to be controlled by the
wall switches and/or remote
control.
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 11

12
Accessories
Attaching Light Kit
1. Ceiling Fan Light Kits (see store
or catalog).
2. Downrod Extension Kits (see store
or catalog).
3. Ceiling Fan Remote Controls (see
store or catalog).
The use of any other control not specif-
ically approved for this fan could result
in fire, shock and personal injury.
!WARNING
Do not use water when cleaning your
ceiling fan. It could damage the motor
or the blades and create the possibility
of an electrical shock.
!WARNING
To avoid possible electrical shock, be
sure electricity is turned off at the main
service box before wiring.
!WARNING
This product is designed to use only
those parts supplied with this product
and/or any accessories designated
specifically for use with this product by
Emerson Electric Co. Substitution of
parts or accessories not designated for
use with this product by Emerson
Electric Co. could result in personal
injury or property damage.
!WARNING
To install a Tommy Bahama accesso-
ry light kit, remove the two screws
securing the switch housing cover on
the switch housing. Remove the
threaded plug from the switch hous-
ing cover and install the light kit in
accordance with the Tommy Bahama
light kit OwnerÕs Manual.
Maintenance
IMPORTANT CARE INSTRUCTIONS
for your Ceiling Fan
Periodic cleaning of your new ceiling
fan is the only maintenance that is
needed.
When cleaning, use only a soft brush
or lint free cloth to avoid scratching
the finish.
Abrasive cleaning agents are not
required and should be avoided to
prevent damage to finish.
3. If airflow is desired in the opposite
direction, turn your fan off and
wait for the blades to stop turning,
then gently pull on the reversing
switch pull chain (the shortest
chain) and turn the fan on again
(Figure 15). The fan blades will
turn in the opposite direction and
reverse the airflow.
CAUTION: To reduce the risk of elec-
trical shock, disconnect the electrical
supply circuit before installing the
fan and optional light kit and/or
remote control receiver.
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 12

13
Trouble Shooting
TROUBLE PROBABLE CAUSE SUGGESTED REMEDY
1. Fan will not 1.Fuse or circuit breaker 1. Check main and branch
start. blown. circuit fuses or circuit
breakers.
2.Loose power line 2. Check line power connections
connections to the fan, or to fan and switch wire
loose switch wire connections in the switch
connections in the switch housing.
housing.
WARNING: Make sure
main power is turned off.
2. Fan sounds 1.Blades not attached to fan. 1. Attach blades to fan before
noisy. operating.
2.Screws securing fan blade 2. Check to make sure the
flanges to motor are loose. screws which attach the
blade flanges to the motor
are tight.
3.Wire connectors inside 3. Check to make sure wire
switch housing rattling. connectors in switch housing
are not rattling against each
other or against the interior
wall of the switch housing.
WARNING: Make sure main
power is turned off.
4.Screws holding blades to 4. Tighten screws securely.
flanges are loose.
5.Loose screws in motor 5. Check to make sure all
housing. screws in motor housing
are snug (not over-tight).
3. Fan wobbles 1.Setscrew in motor coupling 1. Raise coupling cover and
excessively. is not tightened securely. tighten setscrew securely.
2.Setscrew in the hanger ball/ 2. Tighten the setscrew in the
downrod assembly is loose. hanger ball/downrod
assembly.
3.Screws securing fan blade 3. Check to be sure screws
flanges to motor are loose. which attach the fan blade
flanges to the motor are
tight.
4.Fan blade flanges not 4. Check to be sure that the
seated properly. fan blade flanges seat firmly
and uniformly to the surface
of the motor. If flanges are
seated incorrectly, loosen
the flange screws and
retighten according to
Step 15 and Figure 6.
5.Hanger bracket and/or 5. Tighten the hanger bracket
ceiling outlet box is not screws to the outlet box,
securely fastened. and/or secure outlet box.
6.Fan blades out of balance. 6. Interchanging an adjacent
(side-by-side) blade pair can
redistribute the weight and
result in smoother operation.
Or use supplied balancing
kit to balance blades.
WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE
BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN.
!
!
!
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 13

14
Repair Parts
7
6
9
20
3
2
8
1
5
4
23
11
10
12
24
25 15
19
22
26
13
14
21
6
7
18
28
27
17
19 16
Before discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS,ALWAYS GIVE THE FOLLOWING INFORMATION:
• PART NUMBER
• NAME OF ITEM
• PART DESCRIPTION
• MODEL NUMBER
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone [phone].
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 14

15
Part Numbers
Key Model No. Model No. Model No. Model No.
No. Description TB344AP00 TB344BBR00 TB344CW00 TB344DBZ00
* Hanger Pack, Consisting of: 761655-42 761655-85 761655-40 761655-41
1 Hanger Bracket — — — —
2 Hanger Ball — — — —
3 Downrod — — — —
* Parts Bag, Containing: 762779 762779-2 762779-1 762779-2
4 Wire Connector (4) — — — —
5 Hex Wrench, 5/32” — — — —
6 Knurled Knob, 8-32 (4) — — — —
7 Lockwasher, #8 (4) — — — —
8 Threaded Stud, 1-1/4” (2) — — — —
9 Threaded Stud, 1” (2) — — — —
10 Hairpin Clip — — — —
11 Clevis Pin — — — —
12 Setscrew, 5/16-18 x 1/4” — — — —
13 Screw, Phillips Pan Head,
#10-32 x 5/16” (21) — — — —
14 Washer, Flat, #10 (21) — — — —
15 Screw, Oval Head,
#10-32 x 3/4” (11) — — — —
16 Screw, Pan Head,
#8-32 x 3/8” (2) — — — —
17 Pendant, Hibiscus — — — —
18 Pendant, Bell — — — —
19 Coupling (2) — — — —
20 Cover, Ceiling 762768-AP 762768-BBR 762768-CW 762768-DBZ
21 Cover, Motor 762769-AP 762769-BBR 762769-CW 762769-DBZ
22 Capacitor, Aux 10 uF 762243 762243 762243 762243
23 Motor 762508 762508 762508 762508
24 Hub, Motor 760601 760601 760601 760601
25 Flange Set, Blade
(full set for one fan) 762774-AP 762774-BBR 762774-CW 762774-DBZ
26 Housing, Switch 761991-AP 761991-BBR 761991-CW 761991-DBZ
27 Cover Assembly,
Switch Housing 762842-AP 762842-BBR 762842-CW 762842-DBZ
28 Harness Assembly,
Speed/Reverse 762778 762778 762778 762778
—Owner's Manual BP7289-1 BP7289-1 BP7289-1 BP7289-1
Repair Parts Listing
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 15

LIMITED WARRANTY
What The Warranty Covers:
This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in
workmanship and materials. You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
As it applies to the motor, this warranty will last for a lifetime of your ceiling fan. All other components and accessories are cov-
ered by this warranty for one year from the date you purchased your ceiling fan. ANY IMPLIED WARRANTY OF MER-
CHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS
ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson Electric Co. will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other accessory at
no charge to you. If repair of the motor or blades is not practical or possible within a reasonable time and no replacement can
be provided, Emerson Electric Co. will refund the actual purchase price of your fan. We will ship the repaired product or
replacement to you at no charge, but you are responsible for all costs oF removal, reinstallation and shipping of the
product to Emerson Electric Co.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE CEILING FAN TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR
RECEIPT OR OTHER PROOF OF PURCHASE. You can return the product to our factory or to your nearest authorized service
center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort
Products, Division of Emerson Electric Co., 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown
on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service
center. You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service
center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be
responsible for any such damage.
What Is Not Covered:
The glass globes and light bulbs of your ceiling fan are not covered by this warranty. This warranty also does not cover any
defects, malfunctions or failures caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your ceiling fan while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral
warranties apply, and no employee, agent, dealer or other person is authorized to give any warranties on behalf of Emerson
Electric Co.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND
EMERSON ELECTRIC CO. IS NOT RESPONSIBLE FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUEN-
TIAL DAMAGES. Incidental damages include but are not limited to such damages as loss of time and loss of use. Consequential
damages include but are not limited to the cost of repairing or replacing other property which was damaged if this product does
not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limita-
tion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
Part No. F40BP72890001 Printed in China 02/09 Form No. BP7289-1
8100 W. Florissant
St. Louis, MO 63136
1-800-823-4964
BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 16
