Topcon X35 User manual

X35 CONSOLE
BOURGAULT SRC 6000 & 7000A/S
OPERATOR'S MANUAL
MONITOR VERSION: 4.01
REVISED NOVEMBER 2017
0252-90-75
Note:
Use this manual as well as the Topcon Operator's Manual, and the Bourgault Air Seeder Operator's Manual for
operational information.

X35 CONSOLE TABLE OF CONTENTS
0.3
TABLE OF CONTENTS LAST REVISION: November 2017
P/N 0252-90-75
Monitor Version: 4.01
Table of Contents ................................................................................................................................0.3
1 System Components ....................................................................................................................1.1
1.1 Introduction ............................................................................................................................1.2
1.1.1 Software Version .........................................................................................................1.2
1.2 X35 Console ..........................................................................................................................1.3
1.2.1 USB Wi-Fi Antenna ......................................................................................................1.3
1.3 Switchbox ..............................................................................................................................1.4
1.4 Harnesses .............................................................................................................................1.4
1.4.1 X35 Main Harness .......................................................................................................1.4
1.4.2 Power Extension Harness ...........................................................................................1.5
1.4.3 In-Cab SwitchBox Harness .........................................................................................1.6
1.4.4 Tractor ISOBUS Harness ............................................................................................1.6
1.5 Electronic Control Unit (ECU) ................................................................................................1.7
1.5.1 Master ECU (CM-40) ...................................................................................................1.7
1.5.2 I/O ECU (EM-24) (optional) .........................................................................................1.7
1.5.3 SL2140 Scale Link ECU ........................................................................................................1.8
1.5.4 SLC2810 Remote Display ...........................................................................................1.8
1.6 Speed Sensors ......................................................................................................................1.9
1.7 Case Drain Pressure Switch .....................................................................................................1.9
1.8 Low Bin Level Sensors ..........................................................................................................1.9
1.9 BHECU (Blocked Head Electronic Control Unit) .................................................................1.10
1.10 Granular Sectional Control harnesses .................................................................................1.10
1.11 Section Control Valve Proximity Sensor ..............................................................................1.10
2 Overview ......................................................................................................................................2.1
2.1 Starting the X35 Console ......................................................................................................2.2
2.1.1 Turning On ...................................................................................................................2.2
2.1.2 Shutting Down .............................................................................................................2.2
2.2 Console Toolbar .....................................................................................................................2.4
2.3 Understanding Main Screens ................................................................................................2.5
2.3.1 Operations Screen .......................................................................................................2.5
2.3.2 Manipulating Main Viewing Area .................................................................................2.6
2.4 Common Functions ...............................................................................................................2.7
2.5 Guidance/Coverage Map ......................................................................................................2.9
2.6 Seeder Controller ................................................................................................................2.12
2.6.1 Seeder Controller Mini-View Window ........................................................................2.13

X35 CONSOLE
TABLE OF CONTENTS
0.4
2.6.2 Seeder Controller Full Screen Mode .........................................................................2.14
2.6.3 Tank Tab/Panel Explained .........................................................................................2.16
2.6.3.1 Tank Parameters .................................................................................................2.18
2.6.4 Configuration Panel ...................................................................................................2.19
2.6.5 Area Counters Panel .................................................................................................2.20
2.7 Working With Global Home Screens ...................................................................................2.21
2.7.1 Saving a Global Home Screen ..................................................................................2.21
2.7.2 Overwriting Home Screen .........................................................................................2.21
2.7.3 Managing Screens .....................................................................................................2.21
2.7.4 Loading (Selecting) Global Home Screen .................................................................2.22
3 Setup ............................................................................................................................................3.1
3.1 Setup menu Explained ..........................................................................................................3.2
3.2 User .......................................................................................................................................3.4
3.2.1 Region .........................................................................................................................3.4
3.2.1.1 Language ..............................................................................................................3.4
3.2.1.2 Time/Date ..............................................................................................................3.5
3.2.1.3 Units ......................................................................................................................3.6
3.2.2 Lightbar ........................................................................................................................3.6
3.2.3 Environment ................................................................................................................3.7
3.2.4 Map ..............................................................................................................................3.8
3.2.5 Access Level ...............................................................................................................3.9
3.2.6 User Controls .............................................................................................................3.10
3.2.7 Remote Support ........................................................................................................3.11
4 System .........................................................................................................................................4.1
4.1 Features ................................................................................................................................4.2
4.1.1 Licenses ......................................................................................................................4.2
4.1.2 Console .......................................................................................................................4.2
4.1.3 Guidance .....................................................................................................................4.4
4.1.4 Implement ....................................................................................................................4.5
4.1.5 Xtend ...........................................................................................................................4.8
4.1.6 Wireless .......................................................................................................................4.9
4.1.7 Quick Start .................................................................................................................4.10
4.2 GPS .....................................................................................................................................4.12
4.2.1 Receiver ....................................................................................................................4.13
4.2.2 Output ........................................................................................................................4.14
4.2.3 Radar .........................................................................................................................4.15

X35 CONSOLE TABLE OF CONTENTS
0.5
4.3 Serial Ports ..........................................................................................................................4.16
4.4 Alarms .................................................................................................................................4.17
4.4.1 General Alarms ..........................................................................................................4.17
4.4.2 Seeder Alarms ...........................................................................................................4.19
4.5 Flag Points ..........................................................................................................................4.23
4.6 ISOBUS ...............................................................................................................................4.24
4.6.1 Task Controller Setup ................................................................................................4.24
4.6.2 Universal Terminal Setup ...........................................................................................4.25
4.7 Utilities .................................................................................................................................4.26
5 Vehicle .........................................................................................................................................5.1
5.1 Selecting an Existing Vehicle ................................................................................................5.2
5.2 Setting Up a New Vehicle ......................................................................................................5.3
5.3 Setting Up Vehicle Geometry ................................................................................................5.7
5.4 Steering .................................................................................................................................5.8
5.5 Antenna .................................................................................................................................5.8
6 Implement Setup ..........................................................................................................................6.1
6.1 Selecting an Existing Implement ...........................................................................................6.3
6.2 Creating a New Implement Profile .........................................................................................6.5
6.2.1 Creating a New Profile Based on Factory Templates ..................................................6.5
6.2.2 Create a Custom Implement Profile ..........................................................................6.11
6.3 ECU .....................................................................................................................................6.22
6.3.1 ECU Setup .................................................................................................................6.22
6.3.2 ECU Manage .............................................................................................................6.24
6.3.3 Add New ECUS .........................................................................................................6.27
6.3.4 ECU Upgrade ............................................................................................................6.27
6.4 Geometry .............................................................................................................................6.28
6.5 Section Control ....................................................................................................................6.31
6.5.1 Sections .....................................................................................................................6.31
6.5.2 Timing ........................................................................................................................6.34
6.5.3 Section Switch ...........................................................................................................6.36
6.6 Seeder .................................................................................................................................6.37
6.6.1 Granular Setup ..........................................................................................................6.37
6.6.1.1 Granular Tank Setup ...........................................................................................6.37
6.6.1.1.1 General Tank Setup ......................................................................................6.37
6.6.1.1.2 Individual Tank Setup ...................................................................................6.39

X35 CONSOLE
TABLE OF CONTENTS
0.6
6.6.1.2 Tank Grouping .....................................................................................................6.41
6.6.1.2.1 Selecting from Factory Groupings ................................................................6.41
6.6.1.2.2 Creating Custom Grouping ...........................................................................6.41
6.6.1.3 Drive Setup .........................................................................................................6.43
6.6.1.4 Control Setup ......................................................................................................6.45
6.6.2 NH3/Liquid Setup ......................................................................................................6.46
6.6.2.1 NH3/Liquid Tank Setup .......................................................................................6.46
6.6.2.1.1 General Tank Setup ......................................................................................6.46
6.6.2.1.2 Individual Tank Setup ...................................................................................6.46
6.6.2.2 Flow Settings ......................................................................................................6.48
6.6.2.3 Control Valve Settings .........................................................................................6.49
6.6.2.3.1 Proportional Valve Settings ..........................................................................6.50
6.6.2.3.2 Regulator Valve Settings ..............................................................................6.51
6.6.2.4 Pressure Settings ................................................................................................6.52
6.6.3 Fan Settings ..............................................................................................................6.53
6.6.4 Pumps Settings .........................................................................................................6.54
6.6.5 Drill Control ................................................................................................................6.55
6.6.5.1 Lift Master Settings .............................................................................................6.55
6.6.5.2 Pack Master Settings ..........................................................................................6.56
6.6.5.3 Control Settings ..................................................................................................6.57
6.6.6 Accessories ...............................................................................................................6.58
6.6.6.1 Sensor Setup ......................................................................................................6.58
6.6.6.2 Blocked Head Monitor .........................................................................................6.59
6.6.6.3 Granular Sections ...............................................................................................6.65
6.6.6.4 General Inputs ....................................................................................................6.65
6.6.6.5 Encoder ...............................................................................................................6.65
6.6.6.6 General Output ...................................................................................................6.66
6.6.6.7 Drill Fold Setup ...................................................................................................6.66
6.6.7 Weigh Scales ...................................................................................................................6.67
6.6.7.1 ECU ...........................................................................................................................6.67
6.6.7.2 Scales ........................................................................................................................6.68
6.6.7.3 Assignment ................................................................................................................6.69
6.6.7.4 Pressure Compensation ............................................................................................6.70
6.6.8 Speed Source ............................................................................................................6.71
6.6.9 Audio ................................................................................................................................6.73
6.7 Speed & Position .................................................................................................................6.74

X35 CONSOLE TABLE OF CONTENTS
0.7
6.8 Operator Inputs ...................................................................................................................6.75
6.8.1 Master Switch ............................................................................................................6.75
6.8.2 Keypad ......................................................................................................................6.76
6.8.2.1 In-Cab SwitchBox ...............................................................................................6.76
6.8.2.2 On Frame (calibration) SwitchBox ......................................................................6.79
6.6.2.2.1 Switchbox LED status: .................................................................................6.79
7 Product Setup ..............................................................................................................................7.1
7.1 Adding New Product ..............................................................................................................7.3
7.1.1 Adding a New Product Using a Manufacturer Template ..............................................7.5
7.1.2 Adding a Custom Product Without a Template ............................................................7.7
7.2 Modifying Product ..................................................................................................................7.9
7.3 Product Density ...................................................................................................................7.10
8 General Operations ......................................................................................................................8.1
8.1 Selecting the Product ............................................................................................................8.2
8.2 Filling the Tank .......................................................................................................................8.5
8.3 Determine Product Allocation ................................................................................................8.8
8.4 Calibration - Granular Air Seeder Tank ................................................................................8.12
8.4.1 Manual Entry of Calibration Factors ..........................................................................8.13
8.4.2 Stationary Calibration ................................................................................................8.14
8.4.2.1 7000 Series Air Seeders .....................................................................................8.15
8.4.2.2 6000 Series Air Seeders .....................................................................................8.19
8.4.3 Area Test ...................................................................................................................8.23
8.5 Calibration - NH3 Tank .......................................................................................................8.24
8.6 Calibration - Liquid Tank .....................................................................................................8.25
8.6.1 Flow Calibration .........................................................................................................8.27
8.7 Wheel Sensor Calibration ....................................................................................................8.28
8.8 Fan Settings ........................................................................................................................8.31
8.9 Checking Distribution Runs and ASC Valves ......................................................................8.32
8.9.1 A 7000 Series Air Seeder ..........................................................................................8.32
8.9.2 6000 Series Air Seeder ..............................................................................................8.33
8.10 Using Auto Section Control .................................................................................................8.34
8.11 Virtual Section Switches ......................................................................................................8.37
9 Starting a New Field/Job ..............................................................................................................9.1
9.1 Introduction ............................................................................................................................9.2
9.2 Field Menu .............................................................................................................................9.4
9.2.1 Selecting an Existing Field ..........................................................................................9.4

X35 CONSOLE
TABLE OF CONTENTS
0.8
9.2.2 Starting a New Field ....................................................................................................9.5
9.2.3 Unload Field ................................................................................................................9.5
9.2.4 Setting Flag Points ......................................................................................................9.6
9.2.4.1 Removing Or Changing Flag Points .....................................................................9.6
9.2.5 Field Boundary ............................................................................................................9.7
9.2.5.1 Recording a Boundary ..........................................................................................9.7
9.2.5.2 Manipulating Field Boundaries ..............................................................................9.9
9.2.6 Headland ...................................................................................................................9.10
9.2.7 Clear Field Boundary .................................................................................................9.12
9.2.8 Creating a Field Boundary From a Shapefile ............................................................9.12
9.2.9 Creating A Field Boundary From A Coverage Map ....................................................9.13
9.3 Job Menu .............................................................................................................................9.14
9.3.1 Selecting An Existing Job ..........................................................................................9.14
9.3.2 Creating a New Job ...................................................................................................9.15
9.3.3 Configure Job Regions ..............................................................................................9.16
9.3.4 Recording Job Information ........................................................................................9.17
9.3.5 Exporting Job Report .................................................................................................9.18
9.3.6 Clearing a Job ...........................................................................................................9.18
9.3.7 Variable Rate Control ................................................................................................9.19
10 Monitoring & Managing Files .....................................................................................................10.1
10.1 Viewing Information On The Dashboard .............................................................................10.2
10.1.1 Configuring the Dashboard ........................................................................................10.2
10.1.2 Dashboard Items .......................................................................................................10.3
10.2 Viewing Job Information ......................................................................................................10.7
10.3 GPS Details (Mini-View Window) ........................................................................................10.8
10.4 Viewing Diagnostics ............................................................................................................10.9
10.5 System information ............................................................................................................10.10
10.6 Inventory Manager ............................................................................................................10.11
11 Wiring Schematics .....................................................................................................................11.1
11.1 In-Cab Components ............................................................................................................11.2
11.1.1 With Simplified ISOBUS X35 Harness ......................................................................11.2
11.1.2 With ISO-Lite ISOBUS X35 Harness ................................................................................
11.2 Components on the Air Seeder Tank and Implement ..........................................................11.3
11.2.1 TBHD 6000 Series Air Seeders .................................................................................11.3
11.2.2 LDG 6000 Series Air Seeders ...................................................................................11.4
11.2.3 TBHD 7000 Series Air Seeders .................................................................................11.5

X35 CONSOLE TABLE OF CONTENTS
0.9
11.2.4 LDG 7000 Series Air Seeders ...................................................................................11.6
11.2.5 NH3/Liquid - Non Bourgault Systems with 6000/7000 Series AS .............................11.7
11.2.6 NH3/Liquid - Raven System - No ASC with 6000/7000 Series AS ...........................11.8
11.2.7 Liquid - Bourgault LFC with 6000/7000 Series AS ....................................................11.9
11.2.8 Auto Section Control ................................................................................................11.10
11.2.8.1 Systems with 6, 8 or 10 Port Primary Manifolds ...............................................11.10
11.2.9 Weigh System Wiring Schematic .............................................................................11.11
12 Troubleshooting .........................................................................................................................12.1
12.1 Start-up ................................................................................................................................12.2
12.2 Controls ...............................................................................................................................12.2
12.3 Operation .............................................................................................................................12.3
12.4 Alarms .................................................................................................................................12.5
12.5 Guidance .............................................................................................................................12.6
12.6 Weigh System .....................................................................................................................12.6
13 Optional Equipment ...................................................................................................................13.1
13.1 Implement Switch (Auto-Clutch) Feature .............................................................................13.2
13.2 X35 Drill Controll ..................................................................................................................13.3
13.2.1 Lift Master Feature ....................................................................................................13.4
13.2.2 Pack Master Feature .................................................................................................13.5
13.2.2.1 Pack Master Calibration ......................................................................................13.8
13.3 X35 Blockage Monitoring ..................................................................................................13.10
13.3.1 Mounting the Components ......................................................................................13.11
13.3.2 Blockage Monitoring with X35 Console ...................................................................13.13
13.4 Weigh System ...................................................................................................................13.15
13.4.1 Scale Link SL2140 in Universal Terminal ................................................................13.15
13.4.2 Remote Display SLC2810 .......................................................................................13.16
13.4.3 Saddle Tank Load Cells ...........................................................................................13.17
13.4.3.1 Scale Weight Difference ....................................................................................13.17
13.5 Xtend Feature ....................................................................................................................13.18
D Index ........................................................................................................................................... D.1

X35 CONSOLE
TABLE OF CONTENTS
0.10

X35 console System Components
1.1
1 System Components ....................................................................................................................1.1
1.1 Introduction ............................................................................................................................1.2
1.1.1 Software Version .........................................................................................................1.2
1.2 X35 Console ..........................................................................................................................1.3
1.2.1 USB Wi-Fi Antenna ......................................................................................................1.3
1.3 Switchbox ..............................................................................................................................1.4
1.4 Harnesses .............................................................................................................................1.4
1.4.1 X35 Main Harness .......................................................................................................1.4
1.4.2 Power Extension Harness ...........................................................................................1.5
1.4.3 In-Cab SwitchBox Harness .........................................................................................1.6
1.4.4 Tractor ISOBUS Harness ............................................................................................1.6
1.5 Electronic Control Unit (ECU) ................................................................................................1.7
1.5.1 Master ECU (CM-40) ...................................................................................................1.7
1.5.2 I/O ECU (EM-24) (optional) .........................................................................................1.7
1.5.3 SL2140 Scale Link ECU ........................................................................................................1.8
1.5.4 SLC2810 Remote Display ...........................................................................................1.8
1.6 Speed Sensors ......................................................................................................................1.9
1.7 Case Drain Pressure Switch .....................................................................................................1.9
1.8 Low Bin Level Sensors ..........................................................................................................1.9
1.9 BHECU (Blocked Head Electronic Control Unit) .................................................................1.10
1.10 Granular Sectional Control harnesses .................................................................................1.10
1.11 Section Control Valve Proximity Sensor ..............................................................................1.10
1 System Components

X35 consoleSystem Components
1.2
This manual is intended for use with the Bourgault
7000 A/S SRC (Seed Rate Control) with the X35
console.
The system is a powerful tool that will provide a
wide range of options to the operator.
Seed & Fertilizer Rate Controller
1. Control and monitoring of up to six product
applications including 5 granular, and NH3 or
liquid
2. Variable Rate
3. Weigh Scale Monitoring
Guidance System
1. Parallel and Contour guidance software standard
(Optional DGPS receivers required for operation)
2. Use any compatible DGPS
3. Save field maps ("where applied")
VRC/Maplink
1. Log “as applied” maps
2. Use prescription maps for variable rate
applications
Liquid/NH3 Control (Spray Rate Control)
1. Control up to 3 products
2. Liquid Control
3. Liquid Fertilizer
4. Use in a completely separate unit (sprayer,
liquid applicator, etc)
5. Adjustable audible and visual alarms
6. Bin Levels count down as product is used
Auto Steering (Topcon systems ONLY)
Important
Any reference to Auto Steering throughout the
manual is applicable only when the user's tractor
is configured with Topcon guidance equipment
(antenna, receiver, controller, etc.) and is included
as reference only. If your tractor is equipped with
non-Topcon guidance equipment, then the Auto
Steering will be a part of that system and the X35
console will be used for mapping purposes only.
Figure 1.1 - System Information Screen
Click here to
show System
Information
1.1 Introduction
Important
It is important that you do not change settings or
operate buttons on the X35 console with anyone
working on or around the seeding unit. Certain
functions of the console operate components on the
machine which can cause serious injury or death.
1.1.1 Software Version
The system can be upgraded as new features are
added. To check what version of the software is
installed, select the System Information button on
the left side of the screen, refer to Figure 1.1.
Check with the dealer if a new version is available
for update. Contact Bourgault Service for more
information.

X35 console System Components
1.3
Figure 1.2 - X35 Console
1.2 X35 Console
Figure 1.3 - X35 Console - Back View
CAN Ports
Power
Button
Ethernet
Port
USB
Port
1.2.1 USB Wi-Fi Antenna
Connects into USB port on X35 which can
generate a local hotspot or connect to the internet
through a hotspot. This can be used for remote
control of functions through a smartphone or tablet
or can be used for remote support.
The X35 console is a Linux based computer
system contained within an ABS housing. The
console has no internal moving parts and the
housing is designed to ensure long life in even the
toughest conditions.
The console has a 13.5" LCD touch screen display.
The back panel of the X35 console has a few
connection ports, refer to Figure 1.3.
1. Ttwo CAN ports which are used for harness
connections;
2. The ethernet port allows connection to the
internet and computer;
3. A USB port can be used to connect a
thumbdrive or any other Topcon supported
USB devices. Using a USB memory stick,
you can transfer files from your console to
the USB memory stick or import specific files
from USB memory to your console. There is
a 2nd USB port on the X35 harness to allow
hooking up multiple devices.
Figure 1.4 - USB Antena

X35 consoleSystem Components
1.4
1.4 Harnesses
Figure 1.6 - X35 Main Harness
Refer to Section 11 - Wiring Schematics for the
wiring harness layouts.
1.4.1 X35 Main Harness
Refer to Figure 1.6. This harness connects the
X35 console to a power source, ISOBUS, and GPS
signal.
Figure 1.5 - In-Cab Switchbox
1.3 Switchbox
The same switchbox is used in-cab and on the
frame of the air seeder.
The in-cab switchbox connects to a 9-pin AMP
connection in the tractor cab.
The on-frame switchbox is installed on the frame
to control the meters in calibration mode. It is
also used to run meters to check runs when the
unit is stationary.
1. will control up to 8 tanks;
2. alternate means of controlling the air seeder to
the console touch screen;
3. in-cab switchbox can be placed near tractor
controls for easy access;
4. functions include: master on/off, tank on/off
and customized features;
5. must be enabled through the X35 console.

X35 console System Components
1.5
1.4.2 Power Extension Harness
Power extension harness connects X35 console to
the power source. There are two power extension
harnesses available:
1. with the auxiliary connector to connect in the
cab (3151-69, refer to Figure 1.7).
2. with leads to connect to the battery and
switched power source (3151-68, refer to
Figure 1.8).
Figure 1.8 - Power Extension Harness (3151-68)
Figure 1.7 - Power Extension Harness (3151-69)

X35 consoleSystem Components
1.6
1.4.4 Tractor ISOBUS Harness
Tractor ISOBUS harness connects to battery
and tees into X35 harness. Implement plugs into
harness at back of tractor.
Figure 1.12 - Bourgault ISOBUS X35 Harness
(3151-78)
1.4.3 In-Cab SwitchBox Harness
Harnesses connect switchbox into ISOBUS on X35
harness. Also, use the switchbox power harness
(Figure 1.11) to power up the switchbox from the
X35 harness.
Figure 1.10- In-Cab Switchbox Harness (3132-41)
Figure 1.9- Switchbox ISOBUS Adapter
Harness (3132-42)
Connects to in-
Cab SwitchBox
Connects to 9- pin AMP
ISOBUS connection in
the tractor cab
Connects to the round
connector on the in-cab
switchbox harness
Connects to
switchbox extension
power harness
Tee into
ISOBUS
Figure 1.11 - Switchbox Power Extension Harness
(3132-76)
Connects to the
"switched Power"
Connector on X35
Harness
Connects to
SwitchBox ISOBUS
Adapter Harness

X35 console System Components
1.7
1.5 Electronic Control Unit (ECU)
Figure 1.13 - Master ECU (CM-40)
1.5.1 Master ECU (CM-40)
The Master ECU (Figure 1.13) is located on the
hopper panel of the air seeder. It is capable of:
1. controlling up to four tanks;
2. monitoring and transmitting signals from the
various air seeder sensors to the console for
display.
A second ECU (CM-40) will be installed if there
are more than 4 tanks used.
Refer to Section 11 - Wiring Schematics for the
wiring harness layouts.
1.5.2 I/O ECU (EM-24) (optional)
The I/O ECU (Figure 1.14) is located on the back
side of the same mount as the Master ECU. It is
capable of:
1. controlling the granular and NH3/liquid Auto
Section Control systems, up to 10 sections
each;
2. can be installed on the drill to control blocked
head sensors.
Figure 1.14 - I/O ECU (EM-24)

X35 consoleSystem Components
1.8
1.5.3 SL2140 Scale Link ECU
Integrates the Digi-Star weigh system into the X35
Apollo system so live weights can be monitored.
Setup can be accessed through the X35.
1.5.4 SLC2810 Remote Display
Displays the scale values and can control the scale
link setup.
Figure 1.15 - Scale Link ECU
Figure 1.16 - Weigh System Remote Display

X35 console System Components
1.9
Figure 1.18 - Case Drain Pressure Switch
Figure 1.17 - Speed Sensor
1.6 Speed Sensors
There are speed sensors in several locations on the
air seeder. These include fan speed, ground speed,
and metering auger speed. All of these sensors are
proximity style and send a signal to the ECU.
1. the fan speed sensor picks up from a target
bolt on the fan hub (one pulse per revolution).
2. the ground speed sensor is located on the rear
left wheel mount or drive. It picks up a signal
from a sprocket.
3. the metering auger sensors are on the
metering auger housing and pick up the signal
from a sprocket on the metering auger shaft
(32 pulses per revolution for 7000AS, and 16
pulses per revolution for 6000AS).
1.7 Case Drain Pressure Switch
A pressure switch (Figure 1.18) is installed in the
fan hydraulic motor case drain line. This controls
an alarm that will activate if the case drain
pressure is too high (greater than 65psi). High
case drain pressure may result in damage to the
hydraulic motor.
1.8 Low Bin Level Sensors
Each air seeder compartment contains a single bin
level sensor installed near the bottom. The sensor
will trigger an alarm when there is no product in
front of it.
The X35 provides a calculated (not actual) method
of reporting the product remaining in the tank.
This value is based on the metering auger output
in relation to the product amount entered at time
of fill. This value should be used as reference
only.
Figure 1.19 - Bin Level Sensor
BinSensor.tif

X35 consoleSystem Components
1.10
1.9 BHECU (Blocked Head
Electronic Control Unit)
A I/O ECU (EM-24) (Figure 1.20) and BH Sensor
(Figure 1.21) are available to use with the X35/
Bourgault SRC programs.
The I/O ECU is installed on the secondary manifold
stand and communicates with the BH sensor.
- the sensor is installed "in-line" on one tertiary
line per secondary manifold;
- there is a maximum of 20 BH sensors per unit.
The information from this BH sensor is then sent
back to the X35 monitor and is displayed on the
Bourgault SRC program. Refer to Section 13.3
- X35 Blockage Monitoring for more installation
information.
1.10 Granular Sectional Control
harnesses
There are 2 control harnesses that run from the I/O
ECU to control up to 10 sections on the unit. One
harness controls the section valves and the other
harness sends the section sensor feedback to the
ECU.
1.11 Section Control Valve Proximity
Sensor
Refer to Figure 1.22. A proximity sensor is used
to determine position of the section control valve.
The sensor provides an alarm on the monitor
when a valve should be open (for seeding), but is
partially or completely closed.
Figure 1.21 - Blocked Head Sensor
(DICKEY-john Style)
Figure 1.22 - Proximity Sensor
Proximity
Sensor
Figure 1.20 - I/O ECU (EM-24)
