LMT056DIDFWD-ABN
LCD Module User Manual
Prepared by:
Yang
Checked by: Approved by:
Date: 2012-08-01 Date: Date:
Rev.
Descriptions
Release Date
0.1 Preliminary new release 2012-08-01
0.2 Typing Correction on Terminal Function 2012-11-15

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX
TOPWAY displays
[email protected]
www.topwaydisplays.eu

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 2 of 14
Table of Content
1. Product Highlight...................................................................................................................3
2. Block Diagram........................................................................................................................3
3. Terminal Function (Input Terminal)......................................................................................4
4. Absolute Maximum Ratings..................................................................................................5
5. Electrical Characteristics......................................................................................................5
5.1 DC Characteristics.................................................................................................................................................5
6. AC Characteristics.................................................................................................................6
6.1 TFT Controller Timing Characteristics....................................................................................................................6
6.2 TFT Controller Reset Timing..................................................................................................................................7
7. Optical Characteristics..........................................................................................................8
8. Function Specifications.........................................................................................................9
8.1 TFT Controller Functions .......................................................................................................................................9
9. Precautions of using LCD Modules....................................................................................13
10. Appendix <Inspection items and criteria for appearance defect>...................................14

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 3 of 14
1. Product Highlight
Power Supply and logic level
- 5.0V supply
- 3.3V logic level(tolerate 5.0V input)
Display
- TFT LCD display
- 640 x 480 pixels
- 65536colors
- data refresh rate 20fps possible
Host Interface
- 8bit data, 1bit address, 8080mode
- fast command execution
Built-in Drawing Engine
- Hardware rotation of 0°,90°,180°,270°
- Hardware Display Mirroring
- Hardware Windowing
- Address auto increment
Backlight Control
- 256 level backlight brightness control
General Specification beat
Signal Interface : 8bit data, 1bit address
Display Technology : TFT active matrix
Display Mode : Transmissive / Normal White
Screen Size(Diagonal) : 5.6”
Outline Dimension : 155.2 x 109.0 x 15.4 (mm) (see attached drawing for details)
Active Area : 112.896 x 84.672 (mm)
Number of dots : 640 x 3 (RGB) x 480
Pixel Pitch : 0.0588 x 0.1764 (mm)
Pixel Configuration : RGB Stripe
Backlight : LED
Color Depth: 1677216(24bit)colors
Surface Treatment: Anti-Glare Treatment
Viewing Direction : 12 o’clock
Operating Temperature : -20 ~ +70°C
Storage Temperature : -30 ~ +80°C
2. Block Diagram
5.6”TFT Panel
Source Driver
Gate Driver
Backlight
Backlight
Driver
Power Circuit
TFT controller
SSD1963
VDD, VSS
D0~D
7
/RD, /WR, /CS, D/C
/RESET,
TE

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 4 of 14
3. Terminal Function (Input Terminal)
No.
Pin Name
I
/
O
Descriptions
1VSS P Power Supply GND (0V)
2
3VDD I Positive Power Supply (5.0V)
4
5 D/C I Register Select D/C=0, command
D/C=1, data or parameter
6 /CS I Chip Select signal
7 /RESET I Reset signal, /RESET=1, normal
/RESET=0, reset execute
8 D0 I/O 8bit Data bus: :
15 D7
16 TE O Tear Signal (*1)
17 /RD I Read Status signal
18 /WR I Write signal
19 NC -- No Connection: :
28 NC
Note.
*1. Tear signal may leave open when not use

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 5 of 14
4. Absolute Maximum Ratings
Items
Symbol
Min.
Max.
Unit
Condition
Power Supply voltage V
DD
-0.3 6.0 V
Backlight Supply voltage V
DD_BL
-0.3 6.0 V
Operating Temperature TOP -20 70 CNo Condensation
Storage Temperature TST -30 80 CNo Condensation
Note:
*1. This rating applies to all parts of the module. And should not be exceeded.
*2. The operating temperature only guarantees operation of the circuit. The contrast, response speed,
and the other specification related to electro-optical display quality is determined at the room temperature, TOP=25℃
*3. Ambient temperature when the backlight is lit (reference value)
*4. Any Stresses exceeding the Absolute Maximum Ratings may cause substantial damage to the device. Functional
operation of this device at other conditions beyond those listed in the specification is not implied and prolonged
exposure to extreme conditions may affect device reliability.
5. Electrical Characteristics
5.1 DC Characteristics VDD =5.0V,Top=25℃, VSS=0V
Items
Symbol
Min.
Typ.
Max.
Unit
Remark
Power Supply Voltage V
DD
4.8 5.0 5.5 V *2
Input logic high voltage V
IH
3.0 - V
DD
V *2, *3
Input logic low voltage V
IL
0 - 0.6 V *2, *3
Output logic high voltage V
O
H
3.0 - 3.6 V *2, *3
Output logic low voltage V
O
L
0 - 0.6 V *2, *3
Logic Supply Current
(VDD) IDD - 380.0 - mA Backlight (100%PWM)
- 250.0 - Backlight (66%PWM)
Note:
*1. Never Apply logic signal before the VDD supply.
*2. VDD setting should match the signals voltage
*3. For all the inputs signals
*4. PLL Clock Freq=200MHz

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 6 of 14
6. AC Characteristics
6.1 TFT Controller Timing Characteristics
8080 Mode Write Timing
8080 Mode Read Timing
VSS=0V, VDD=5.0V, TOP=25C
Item
Symbol
MIN.
TYP.
MAX.
Unit
System Clock Period
(
*
1)
t
MCLK
1/f
MCLK
-
-
n
s
Control Pulse High Width
Write tPWCSL 29 1.5*tMCLK - ns
Read
51
1.3
*
t
MCLK
-
n
s
Co
ntrol Pulse Low Width
Write (next write cycle) tPWCSH
29 1.5*tMCLK - ns
Write (next read cycle)
113
9*
t
MCLK
-
n
s
Read
113
9*t
MCLK
-
n
s
Address Setup Time
t
AS
7.8
-
-
ns
Address Hold Time
t
AH
9
-
-
ns
Write Data Setup Time
t
DSW
11.5
-
-
ns
Write
Data Hold Time
t
DHW
7.8
-
-
ns
Write Low Time
t
PWLW
28
-
-
ns
Read Data Hold Time
t
DHR
9.1
-
-
ns
Access Time
t
ACC
63.3
-
-
ns
Read Low Time
t
PWLR
58
-
-
ns
Rise Time
t
R
-
-
0.
4
ns
Fall Time
t
F
-
-
0.
4
ns
Chip select setup time
t
CS
9
-
-
ns
Chip s
elect hold time to read signal
t
CSH
9
-
-
ns
Note:
*1. tMCLK is the System Clock Period, which may config by internal PLL setting
*2. LMT056DIDFWD is driving by external 10MHz, and clock up by enabling the SSD1963 internal PLL
*3. Suggested PLL clock setting is 200MHz

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 7 of 14
6.2 TFT Controller Reset Timing
VSS=0V, VDD=5.0V, TOP=25C
Item
Symbol
MIN.
TYP.
MAX.
Unit
Reset setup time trs 2 - - ms
Reset pulse trst 0.2 - - ms
Reset hold time trh 2 - - ms

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 8 of 14
7. Optical Characteristics
Item Symbol Condition MIN. TYP. MAX. UNIT Note.
Viewing angle
(CR≥10)
θ
L9 o’clock 60 70 -
degree *2
θ
R3 o’clock 60 70 -
θ
T12 o’clock 40 50 -
θ
B6 o’clock 60 70 -
Response Time Tf
Normal
θ=0o
- 10 20 msec *3
Tr- 15 30 msec
Contrast ratio CR 400 500 - - *1
Color chromaticlty WX0.26 0.31 0.26 -
WY0.28 0.33 0.38 -
Luminance L - 350 - cd/m2*4
Luminance uniformity YU70 75 - % *4
Note:
*1. Definition of Contrast Ratio
The contrast ratio could be calculate by the following expression:
Contrast Ratio (CR) = Luminanc with all pixels white / Luminance with all pixels black
*2 Definition of Viewing Angle
*3 Definition of response time *4 Definition of Luminance Uniformity
Luminance uniformity (Lu)=
Min. Luminance form pt1~pt9 / Max Luminance form Pt1~pt9
*5. Measured with TFT and backlight only

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 9 of 14
8. Function Specifications
8.1 TFT Controller Functions
8.1.1 Display Memory Addressing
TFT module with 640x480 pixels, using SSD1963, address the display memory with a co-ordinate
system as follow.
Display Window
480 pixels 
(0,0)
(x1,y1)
Window Frame
(x2,y2)
(639,479)
640 pixels 
8.1.2 Command Packet
-Command Packet organizes with “Command Code”followed by “Parameter”
-Command Code and Parameters are 8bit only
-Number of Parameters is depends on Command type
some of the command followed with no parameter.
Se
q. D/C /RD /WR Lo byte (D7:D0)
1 0 1 ↑Command code
2 1 1 ↑Parameter 1
3 1 1 ↑Parameter 2
4 1 1 ↑Parameter 3
: : : : :
8.1.3 Data Format
-Display Data is in 24bit format (R:G:B=8:8:8)
-24bit data built one pixels
-Display Data could be continue write (depends on command and configuration)
D/C /RD /WR D7 D6 D5 D4 D3 D2 D1 D0
1 1 ↑R7 R6 R5 R4 R3 R2 R1 R0
1 1 ↑G7 G6 G5 G4 G3 G2 G1 G0
1 1 ↑B7 B6 B5 B4 B3 B2 B1 B0
1 1 ↑R7 R6 R5 R4 R3 R2 R1 R0
1 1 ↑G7 G6 G5 G4 G3 G2 G1 G0
1 1 ↑B7 B6 B5 B4 B3 B2 B1 B0
: : : : : : : : : : :

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 10 of 14
8.1.4 Command Table
Code
(hex)
Command
Description
0x00 nop No operation
0x01 soft_reset Software Reset
0x0A get_power_mode Get the current power mode
0x0B get_address_mode Get the frame buffer to the display panel read order
0x0C Reserved Reserved
0x0D get_display_mode The SSD1963 returns the Display Image Mode.
0x0E get_tear_effect_status Get the Tear Effect status
0x0F Reserved Reserved
0x10 enter_sleep_mode Turn off the panel. This command will pull low the GPIO0. If GPIO0 is
configured as normal GPIO or LCD miscellaneous signal with command
set_gpio_conf, this command will be ignored.
0x11 exit_sleep_mode Turn on the panel. This command will pull high the GPIO0. If GPIO0 is
configured as normal GPIO or LCD miscellaneous signal with command
set_gpio_conf, this command will be ignored.
0x12 enter_partial_mode Part of the display area is used for image display.
0x13 enter_normal_mode The whole display area is used for image display.
0x20 exit_invert_mode Displayed image colors are not inverted.
0x21 enter_invert_mode Displayed image colors are inverted.
0x26 set_gamma_curve Selects the gamma curve used by the display panel.
0x28 set_display_off Blanks the display panel
0x29 set_display_on Show the image on the display panel
0x2A set_column_address Set the column address
0x2B set_page_address Set the page address
0x2C write_memory_start Transfer image information from the host processor interface to the
SSD1963 starting at the location provided by set_column_address and
set_page_address
0x2E read_memory_start Transfer image data from the SSD1963 to the host processor interface
starting at the location provided by set_column_address and
set_page_address
0x30 set_partial_area Defines the partial display area on the display panel
0x33 set_scroll_area Defines the vertical scrolling and fixed area on display area
0x34 set_tear_off Synchronization information is not sent from the SSD1963 to the host
processor
0x35 set_tear_on Synchronization information is sent from the SSD1963 to the host
processor at the start of VFP
0x36 set_address_mode Set the read order from frame buffer to the display panel
0x37 set_scroll_start Defines the vertical scrolling starting point
0x38 exit_idle_mode Full color depth is used for the display panel
0x39 enter_idle_mode Reduce color depth is used on the display panel.
0x3A Reserved Reserved
0x3C write_memory_continue Transfer image information from the host processor interface to the
SSD1963 from the last written location
0x3E read_memory_continue Read image data from the SSD1963 continuing after the last
read_memory_continue or read_memory_start
Hex Code Command Description
0x44 set_tear_scanline Synchronization information is sent from the SSD1963 to the host
processor when the display panel refresh reaches the provided scanline
0x45 get_scanline Get the current scan line
0xA1 read_ddb Read the DDB from the provided location
0xA8 Reserved Reserved

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 11 of 14
8.1.5 Command Table(continue)
Code (hex)
Command
Description
0xB0 set_lcd_mode_ Set the LCD panel mode and resolution
0xB1 get_lcd_mode Get the current LCD panel mode, pad strength and resolution
0xB4 set_hori_period Set front porch
0xB5 get_hori_period Get current front porch settings
0xB6 set_vert_period Set the vertical blanking interval between last scan line and next LFRAME
pulse
0xB7 get_vert_period Set the vertical blanking interval between last scan line and next LFRAME
pulse
0xB8 set_gpio_conf Set the GPIO configuration. If the GPIO is not used for LCD, set the
direction. Otherwise, they are toggled with LCD signals.
0xB9 get_gpio_conf Get the current GPIO configuration
0xBA set_gpio_value Set GPIO value for GPIO configured as output
0xBB get_gpio_status Read current GPIO status. If the individual GPIO was configured as input,
the value is the status of the corresponding pin. Otherwise, it is the
programmed value.
0xBC set_post_proc Set the image post processor
0xBD get_post_proc Set the image post processor
0xBE set_pwm_conf Set the image post processor
0xBF get_pwm_conf Set the image post processor
0xC0 set_lcd_gen0 Set the rise, fall, period and toggling properties of LCD signal generator 0
0xC1 get_lcd_gen0 Get the current settings of LCD signal generator 0
0xC2 set_lcd_gen1 Set the rise, fall, period and toggling properties of LCD signal generator 1
0xC3 get_lcd_gen1 Get the current settings of LCD signal generator 1
0xC4 set_lcd_gen2 Set the rise, fall, period and toggling properties of LCD signal generator 2
0xC5 get_lcd_gen2 Get the current settings of LCD signal generator 2
0xC6 set_lcd_gen3 Set the rise, fall, period and toggling properties of LCD signal generator 3
0xC7 get_lcd_gen3 Get the current settings of LCD signal generator 3
0xC8 set_gpio0_rop Set the GPIO0 with respect to the LCD signal generators using ROP
operation. No effect if the GPIO0 is configured as general GPIO.
0xC9 get_gpio0_rop Get the GPIO0 properties with respect to the LCD signal generators.
0xCA set_gpio1_rop Set the GPIO1 with respect to the LCD signal generators using ROP
operation. No effect if the GPIO1 is configured as general GPIO.
0xCB get_gpio1_rop Get the GPIO1 properties with respect to the LCD signal generators.
0xCC set_gpio2_rop Set the GPIO2 with respect to the LCD signal generators using ROP
operation. No effect if the GPIO2 is configured as general GPIO.
Hex Code Command Description
0xCD get_gpio2_rop Get the GPIO2 properties with respect to the LCD signal generators.
0xCE set_gpio3_rop Set the GPIO3 with respect to the LCD signal generators using ROP
operation. No effect if the GPIO3 is configured as general GPIO.
0xCF get_gpio3_rop Get the GPIO3 properties with respect to the LCD signal generators.
0xD0 set_dbc_conf Set the dynamic back light configuration
0xD1 get_dbc_conf Get the current dynamic back light configuration
0xD4 set_dbc_th Set the threshold for each level of power saving
0xD5 get_dbc_th Get the threshold for each level of power saving
0xE0 set_pll Start the PLL. Before the start, the system was operated with the crystal
oscillator or clock input
0xE2 set_pll_mn Set the PLL
0xE3 get_pll_mn Get the PLL settings
0xE4 get_pll_status Get the current PLL status
0xE5 set_deep_sleep Set deep sleep mode
0xE6 set_lshift_freq Set the LSHIFT (pixel clock) frequency
0xE7 get_lshift_freq Get current LSHIFT (pixel clock) frequency setting
0xE8 Reserved Reserved
0xE9 Reserved Reserved
0xF0 set_pixel_data_interface Set the pixel data format of the parallel host processor interface
0xF1 get_pixel_data_interface Get the current pixel data format settings
0xFF Reserved Reserved
Note. Please Refer to SSD1963 datasheet for details.

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 12 of 14
8.1.6 Hardware Related Parameter
Booster and Power circuit
Internal DC-DC booster and Backlight driver are controlled by SSD1963 GPIO0 and GPIO1
respectively. It is necessary to enable them for normal operation via command
Backlight Brightness PWM control
It is suggested to config the backlight brightness control signal as 3kHz PWM signal for best
performance.
8.1.7 Startup Program (Example)
_RST=1; delayms(10); // wait for all power stable
_RST=0; delayms(1); // reset pulse
_RST=1; delayms(10); // wait till internal reset routine finish
SdCmd(0xe2); SdData(0x3B); SdData(0x02); SdData(0x04); delayms(10); // config PLL to 200MHz
SdCmd(0xe0); SdData(0x01); delayms(10); // enable PLL
SdCmd(0xe0); SdData(0x03); delayms(10); // switch to use PLL clock
SdCmd(0x11); // exit_sleep_mode
SdCmd(0x13); // enter_normal_mode (exit_partial_mode)
SdCmd(0x20); // exit_invert_mode
SdCmd(0x38); // exit_idle_mode (using full color)
SdCmd(0xB8); // set_gpio_conf
SdData(0x0f); // GPIO[0~3] controlled by host
SdData(0x01); // GPIO0 as normal GPIO
SdCmd(0xba); SdData(0x01); delayms(10); // GPIO[0~3]=0001, enable DC-CD booster
SdCmd(0xba); SdData(0x03); delayms(10); // GPIO[0~3]=0011, enable backlight booster
SdCmd(0xf0); SdData(0x00); // set_pixel_data_interface (MCU) 8bit
SdCmd(0xb0); // set_lcd_mode
SdData(0x24); // 24bit, disable FRC or dithering, DCLK=rising edge
SdData(0x20); // HSYNC=active lo, VSYNC=active low, default TFT m
SdData(0x02); SdData(0x7f); // panel size 640-1
SdData(0x01); SdData(0xdf); // panel size 480-1
SdCmd(0xb4); // set_hori_period
SdData(0x03); SdData(0x1f); // total pluse per line, HT=800-1
SdData(0x00); SdData(0x9f); // horizontal front porch, HPS=160-1
SdData(0x07); // HPW=0x07(default), not use
SdData(0x00); SdData(0x00); // LPS=0x0000(default), not use
SdData(0x00); // LPSPP=0x00(default), not use
SdCmd(0xb6); // set_vert_period
SdData(0x02); SdData(0x0c); // total line per frame, VT=525-1
SdData(0x00); SdData(0x2c); // vertical front porch, VPS=45-1
SdData(0x01); // VPW=0x01(default), not use
SdData(0x00); SdData(0x00); // FPS=0x0000(default), not use
SdCmd(0xe6); SdData(0x01); SdData(0xe0); SdData(0x00);// config PCLK=40ns(PLL@200MHz)
SdCmd(0x36); // set_address_mode
SdData(0x00); // top to bottom, left to right, RGB, normal
SdCmd(0xbe); // set_pwm_conf
SdData(0x00); // PWM clock set to 3kHz (PLL@200MHz)
SdData(150); // PWM width at about 60% (150/255)
SdData(0x01); // C[3]=0, non_DBC control; C[0]=1, enable PWM
SdData(0xf0); // DBC manual level at middle
SdData(0x00); // DBC minimum lever at middle
SdData(0x00); // disable the DBC response delay setting
SdCmd(0x29); // display on
SdCmd(0x2c); // write_memory_start
SdData(0xff); SdData(0xff); SdData(0xff); // write a white pixel
SdData(0xff); SdData(0x00); SdData(0x00); // write a red pixel
.......... // continue wirit display data
Note. Above example program may need modification to fit correspondent application.

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 13 of 14
9. Precautions of using LCD Modules
Mounting
-Mounting must use holes arranged in four corners or four sides.
-The mounting structure so provide even force on to LCD module. Uneven force (ex. Twisted stress)
should not applied to the module. And the case on which a module is mounted should have sufficient
strength so that external force is not transmitted directly to the module.
-It is suggested to attach a transparent protective plate to the surface in order to protect the polarizer.
It should have sufficient strength in order to the resist external force.
-The housing should adopt radiation structure to satisfy the temperature specification.
-Acetic acid type and chlorine type materials for the cover case are not desirable because the former
generates corrosive gas of attacking the polarizer at high temperature and the latter causes circuit
break by electro-chemical reaction.
-Do not touch, push or rub the exposed polarizers with glass, tweezers or anything harder than HB
pencil lead. Never rub with dust clothes with chemical treatment. Do not touch the surface of
polarizer for bare hand or greasy cloth.(Some cosmetics deteriorate the polarizer.)
-When the surface becomes dusty, please wipe gently with absorbent cotton or other soft materials
like chamois soaks with petroleum benzine. Normal-hexane is recommended for cleaning the
adhesives used to attach front / rear polarizers. Do not use acetone, toluene and alcohol because
they cause chemical damage to the polarizer.
-Wipe off saliva or water drops as soon as possible. Their long time contact with polarizer
Operating
-The spike noise causes the mis-operation of circuits. It should be within the ±200mV level (Over and
under shoot voltage)
-Response time depends on the temperature.(In lower temperature, it becomes longer.)
-Brightness depends on the temperature. (In lower temperature, it becomes lower.) And in lower
temperature, response time(required time that brightness is stable after turned on) becomes longer.
-Be careful for condensation at sudden temperature change. Condensation makes damage to
polarizer or electrical contacted parts. And after fading condensation, smear or spot will occur.
-When fixed patterns are displayed for a long time, remnant image is likely to occur.
-Module has high frequency circuits. Sufficient suppression to the electromagnetic interference shall
be done by system manufacturers. Grounding and shielding methods may be important to minimized
the interference
Electrostatic Discharge Control
Since a module is composed of electronic circuits, it is not strong to electrostatic discharge. Make certain
that treatment persons are connected to ground through wrist band etc. And don’t touch interface pin
directly.
Strong Light Exposure
Strong light exposure causes degradation of polarizer and color filter.
Storage
When storing modules as spares for a long time, the following precautions are necessary.
-Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep the
temperature between 5°C and 35°C at normal humidity.
-The polarizer surface should not come in contact with any other object. It is recommended that they
be stored in the container in which they were shipped.
Protection Film
-When the protection film is peeled off, static electricity is generated between the film and polarizer.
This should be peeled off slowly and carefully by people who are electrically grounded and with well
ion-blown equipment or in such a condition, etc.
-The protection film is attached to the polarizer with a small amount of glue. If some stress is applied
to rub the protection film against the polarizer during the time you peel off the film, the glue is apt
tore main on the polarizer. Please carefully peel off the protection film without rubbing it against the
polarizer.
-When the module with protection film attached is stored for a long time, sometimes there remains a
very small amount of glue still on the polarizer after the protection film is peeled off.
-You can remove the glue easily. When the glue remains on the polarizer surface or its vestige is
recognized, please wipe them off with absorbent cotton waste or other soft material like chamois
soaked with normal-hexane.
Transportation
The LCD modules should be no falling and violent shocking during transportation, and also should avoid
excessive press, water, damp and sunshine.

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX

TOPWAY
LCD Module User Manual LMT056DIDFWD-ABN
Document Name: LMT056DIDFWD-ABN-Manual-Rev0.2
Page: 14 of 14
10. Appendix <Inspection items and criteria for appearance defect>
Bright/Dark Dots:
Defect Type Specification Major Minor
Bright Dots N≤2●
Dark Dots N≤3●
Total Bright and Dark Dots N≤4●
Note: 1. The definition of dot: The size of a defective dot over 1/2 of whole dot is regarded as one defective dot.
2. Bright dot: Dots appear bright and unchanged in size in which LCD panel is displaying under black
pattern.
3. Dark dot: Dots appear dark and unchanged in size in which LCD panel is displaying under pure red,
green, blue pattern.

ZZZWRSZD\GLVSOD\VHX
LQIR#WRSZD\GLVSOD\VHX
