RAGE COMPACT CLASS AB/D AMPLIFIER
Owners Manual
Please read through this manual to familiarize yourself with your new amplifier. Should your TORO
AUDIO mobile amplifie r ever require service, you will need to have the original dated receipt.

Thank you and Congratulations
Thank you for your decision to purchase a TORO AUDIO Rage amplifier! Our Rage amplifiers are the
result of extensive engineering, testing, and bullet proof construction. Their versatility enables
compatibility with optional signal and audio processors. These high quality MOSFET amplifiers may be
configured to allow maximum flexibility in designing different speaker and subwoofer options.
COMPACT RAGE AMPLIFIERS
Models RX2,RX4,RX4S are Class AB multi channel amplifiers specifically designed for mid-range
or mid-bass speakers and sound quality subwoofer systems.
Models R2,R3,R4,R5,R6 are designed specifically for low frequencies and are intended only to
power subwoofers.
Model R4F is full range digital amplifier specifically for full range speakers and subwoofers.
It is important that you closely follow the wiring instructions contained in this Owners Manual so
that you get the most from your TORO AUDIO Rage amplifier.
T
E
O
C
R
H
O
T
Caution
High powered audio systems in a vehicle are capable of generating higher than "Live concert"
levels of sound pressure. Continued exposure to excessively high volume sound levels will cause
hearing loss or damage. Also, operation of a motor vehicle while listening to audio equipment at
high volume levels may impair your ability to hear external sounds such as horns, warning signals,
or emergency vehicles-thus creating a potential traffic hazard. In the interest of safety, TORO AUDIO
highly recommends listening at lower volume levels when driving.

TECHNICAL FEATURES
Installation of TORO AUDIO mobile amplifiers require detailed knowledge of electronic wiring and proper
speaker impedance. We strongly recommend installation by an authorized TORO AUDIO dealer or certified
MECP installer. This Owners Manual only provides general installation and operation instructions. If you
have any reservations about your installation skills, please contact your local TORO AUDIO dealer for
assistance. IMPORTANT: This amplifier is designed for operation in vehicles with 12-Volt negative
ground electrical systems only.
NOTE: The tools listed below may be required for basic installation
Sound Quality Class-A/B Design (R2, RX2, RX4, RX4S)
High Efficiency Class-D Design for Subwoofers (R3, R4, R5, R6)
Full Range Digital Design for full Range Speakers and Subwoofer (R4F)
Built-In Auto Sensing Turn-On Function (Hi-Inputs)
MOSFET Power Supplies for High Power Output and Best Stability into Low Impedance Loads
Soft Delay Remote Turn On/Off Circuit Eliminates Pops and Clicks
Variable Low Pass Electronic Crossover
Selectable Bass Boost EQ
Self-Diagnostic Protection Circuit with LED Status Indicator for; Impedance Over-load, Speaker Short
Circuit, Thermal Overheating, and DC Output
0.5-OHM Stable Operation with Extensive Output Power Increase (R6)
2-OHM Stable Operation with Extensive Output Power Increase (R2)
1-OHM Stable Operation with Extensive Output Power Increase (R3, R4, R5, R4F)
Variable Gain Control
Remote Level Control Port (for optional controller)
An electric drill with bits
Phillips head and standard screwdrivers
Wire strippers
Crimping tool
VOM (electronic volt ohm meter)
Heat shrink tubing and heat gun
Soldering iron
Electronic (Rosen Core not Acid Core) Solder

Fig.1 Mounting Amplifier
Turn off all stereo and other electrical devices before you begin
Disconnect the negative (-) lead from your vehicle’s battery
Locate all fuel lines, brake lines, oil lines, and electrical cables when planning the install
Make sure there is at least 2-inches (5 cm) around the air vents on the amplifier.
When connecting ground points, make sure all paint is carefully scrapped away from the vehicle's
chassis and contact is make with bare metal
Use a utility knife to trim away fabric from hole locations before drilling or cutting
When running power cables through sheet metal, be sure to use grommets to properly insulate the
metal edges from the wire insulation
If possible, use tubing through grommets
NOTE: Proceed only if you are a qualified installer, otherwise; see your Authorized TORO AUDIO
Dealer or MECP Certified Installer to professionally install this amplifier. Always wear protective
eyewear when using tools.
Due to the high-power output of the TORO AUDIO RAGE amplifiers, considerable heat may be produced
when the unit is in operation. For this reason, the amplifier should be mounted in a location which will allow
air to circulate freely. A clearance of at least 2-inches (5 cm) to all sides of the amplifier is necessary not
only for proper cooling, but also for gaining access to the inputs and other variable controls. Be sure that
the power and signal cable connections can enter and leave the amplifier in a straight line to avoid the risk
of kinked wires causing malfunction.

Find a clear and well-ventilated area to mount your amplifier that is unobstructed by any objects that will
cause harm or block ventilation. Despite the fact that this amplifier is compact, it still needs air to cool the
heat-sink fins. Do not mount under a carpet or an area with dead or stagnant air. Without proper air flow
the amplifier may overheat and go into protection where the thermal overload circuitry will shut down the
amplifier.
You may use the amplifier as a template and mark the four screw locations with a felt tip pen. Set the
amplifier aside before drilling. Use caution to make sure there are no objects behind the installation surface
that may become damaged during drilling.
The amplifier should be protected from exposure to moisture and direct sunlight. The best places to mount
your amplifier are: The floor of the trunk, under the driver's seat, or on the back of the rear seat. For
alternate installation locations, please consult your authorized TORO AUDIO Dealer.
NOTE: Do not use a drill with driver bit to mount the amplifier. Excessive force could cause the
plastic mounting feet to crack.
Upside down mounting will compromise heat dissipation through the heat-sink and
could engage the thermal protection circuit.
Try to avoid mounting the amplifier on a subwoofer enclosure, as extended exposure
to vibration may cause malfunction of the amplifier.
Don't mount the amplifier so that the wire connections are unprotected or are subject
to pinching or damage from nearby objects.
The DC power wire must be fused at the battery positive (+) terminal connection
before making or breaking power connections at the amplifier power terminals,
disconnect the DC power wire at the battery end.
The battery of the car audio system must be disconnected until the entire wiring and
installation is completed.
Do not use a power drill to tighten the power, ground, remote or speaker output
terminals on the amplifier to avoid stripping the terminal screws. It is best to hand
tighten these connections.
The use of Ring and Spade terminals (not included) provide the best electrical
connection for use with the clamp style connections on this amplifier.

FUSE
DESIGNED & ENGINEERED IN U.S.A.
2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
R2
R2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
BASS
BOOST
12dB
10V 0.2
Q
CONTROL
WIDE NARROW
R3/R4/R5/R6
R3/R4/R5/R6
FIG2 . MONO AMPLIFIER PANEL LAYOUT
R4F
R4F

RX4S
RX4S
FUSE
SPE AKERS
bridged
1 2
3 4
1 2
3 4
4
DESIGNED & ENGINEERED IN U.S.A.
X4S
PWR/PRO
X-OVER
HP
Full 3KHz 3KHz80
Full
/HiPass
Low/
BandPass
LP
REAR
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2 10V 0.2
FUSE
DESIGNED & ENGINEERED IN U.S.A.
12
4BRIDGED
X2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
HPF
RX2
RX2
FIG3 . 4-CH AMPLIFIER PANEL LAYOUT
FIG4. 2-CH AMPLIFIER PANEL LAYOUT
1. SPEAKERS
CONNECT SPEAKERS/SUBWOOFERS TO THESE TERMINALS. BE SURE TO CHECK WIRE FOR PROPER POLARITY.
NEVER CONNECT THE SPEAKER CABLES TO CHASSIS GROUND.
2.+12VOLT POWER
CONNECT THIS TERMINAL THROUGH A FUSE CIRCUIT BREAKER TO THE POSITIVE TERMINAL OF THE VEHICLE
BATTERY OR THE POSITIVE TERMINAL OF AN ISOLATED AUDIO SYSTEM BATTERY.
AMPLIFIER FUNCTIONS
3. AUTO SENSING TURN ON FUNCTION / REM OUT(HI-INPUTS)
WHEN USE HI-INPUT, THE AMP CAN DETECT THE DC OFFSET FROM THE HIGH-LEVEL INPUT SIGNAL TO AUTO
TURN ON/OFF. WHEN THE AMP TURNS ON, THE REM TERMINAL WILL OUTPUT+1 2V DC TO CONTROL THE OTHER
DEVICE TURN ON/OFF.
REM IN: WHEN USE LOW LEVEL INPUT, THE AMP REM IN SHOULD BE CONNECTED TO THE REMOTE OUT OF THE
SOURCE UNIT. THE HEAD UNIT CONTROLS THE AMP TURN ON/OFF.

4.GND
CONNECT THIS CABLE DIRECTLY TO THE FRAME OF THE VEHICLE. MAKE SURE THE METAL FRAME HAS BEEN
STRIPPED OF ALL PAINT DOWN TO THE BARE METAL. USE THE SHORTEST DISTANCE POSSIBLE. IT IS ALWAYS A GOOD
IDEA TO REPLACE THE FACTORY GROUND AT THIS TIME WITH A LARGER CABLE EQUAL TO THE NEW DIRECTLY TO THE
VEHICLE BATTERY GROUND TERMINAL OR ANY OTHER FACTORY GROUND POINTS.
5.RCA INPUT/AUTO HI-LOW LINE CONVERTOR
THESE RCA INPUT JACKS CONNECT WITH YOUR SOURCE UNITRCA LOW L EVEL OUTPUTS OR VIA OPTIONAL
ADAPTER WITH YOUR SOURCE UNIT SPEAKER HIGH LEVEL OUTPUTS. THE USE OF HIGH QUALITY TWISTED PAIR
CAR AUDIO CABLES IS RECOMMENDED TO MIND POSSIBILITY OF DISTURBANCE THE AUDIO SIGNAL.
6. REMOTE(MONO BLOCKS)
CONNECT THE REMOTE CONTROLLER TO CONTROL THE SUBWOOFER AMPLIFIER VOLUME FROM THE DRIVER
SEAT LOCATION, FOR EASE OF ADJUSTMENT DURING PLAYING.
7. GAIN CONTROLLER
GAIN CONTROL WILL MATCH THE AMPLIFIERS SENSITIVITY TO THE SOURCE UNITS SIGNAL VOLTAGE. THE
OPERATING RANGE IS 10V TO 200MV. THIS IS NOT A VOLUME CONTROL!
8.LOW PASS FILTER CONTROL (MONO BLOCK)
THIS CONTROL IS USED TO SELECT THE DESIRED LOW PASS X-OVER FREQUENCY. THE FREQUENCY CAN BE
ADJUSTED FROM 60HZ TO 220HZ FOR ALL BASS MONO MODELS.
9. SUBSONIC FILTER CONTROL (MONO BLOCK)
10.BASS BOOST LEVEL KNOB (MONO BLOCK)
THIS CONTROL ADJUSTS THE BOOST LEVEL OF THE BASS BOOST CENTER FREQUENCY. IT CAN BE ADJUSTED
FROM 0 TO 12DB. COMBINING WITH BASS BOOST FREQUENCY, YOU CAN ACCURATELY MATCH THE AMPLIFIER
PERFORMANCE TO WOOFER RESPONSE.
11.BASS BOOST FREQ KNOB (MONO BLOCK)
THIS CONTROLS THE BOOSTED CENTER FREQUENCY. THE FREQUENCY CAN BE ADJUSTED FROM 30HZ TO 120HZ
ACCORDING TO YOUR CAR AUDIO SYSTEM PERFORMANCE. (I.E. WHEN YOU ADJUST THIS KNOB TO 50HZ, THE
AMPLIFIER WILL BOOST THE FREQUENCY AROUND 50HZ.) THIS FUNCTION SHOULD BE ADJUSTED COMBINING WITH
BASS BOOST LEVEL TUNING.
12. X-OVER MODE (FULL RANGE)
TO ADJUST THE OPERATING FREQUENCY RANGE OF THE AMP. WHEN SWITCHED TO LPF OR HPF, THE
CORRESPONDING FILTER CAN ADJUST THE OPERATING FREQUENCY RANGE. WHEN PUSHING THE SUBWOOFER,
SWITCH TO LPF MODE. WHEN PUSHING SMALL CALIBER FULL FREQUENCY SPEAKERS OR MIDDLE AND HIGH
FREQUENCY LOUDSPEAKERS, SWITCH TO HPF MODE. WHEN PUSHING LARGE CALIBER FULL FREQUENCY SPEAKERS,
SWITCH TO FULL MODE. WHEN SWITCHED TO FULL MODE THE FILTERS WILL NOT FUNCTION.
13. FREQUENCY CONTROL (RX4/RX4S)
TO ADJUST FRONT FREQUENCY FROM FULL / HI PASS TO 3KHZ.
14.POWER PROTECTION INDICATOR
THIS LED WILL LIGHT UP WHEN AMPLIFIER WORKS PROPERLY.
THIS RED LED WILL LIGHT UP AND WILL BE FLASHING IF THERE IS A FAULT PRESENTED TO THE AMPLIFIER.
PLEASE DISCONNECT THE AMPLIFIER AND RESOLVE THE FAULT BEFORE RECONNECTING THE AMPLIFIER.
LED INDICATOR IS TO SHOW SIGNAL CLIPPING, IF THE INPUT SIGNAL WAVE IS BEYOND THE RANGE.
BY LOWERING THE GAIN, THE CLIPPED PORTION WILL GO BACK WITHIN THE INPUT RANGE AND THE LED
INDICATOR WILL TURN OFF.
OCCASIONAL LED “ON” ( OCCASIONAL FLICKERING) OF LED WOULD BE PERMISSIBLE IN SOME INSTALLS, BASED
ON PERSONAL PREFERENCE.
15. CLIP
16.CROSSOVER
THIS CROSSOVER SWITCH SELECTS (LPF) LOW PASS FREQUENCIES. THE OFF POSITION IS FOR FULL RANGE.
THE CROSSOVER FREQUENCY RANGE TO SELECT THE LOW PASS FREQUENCY (LPF) IS BASED ON YOUR SPEAKERS
AND SYSTEM SETUP REQUIREMENTS
THIS CONTROL CAN FILTER OUT UNWANTED LOW FREQUENCY FROM 0HZ (OFF) TO 60HZ. THIS FUNCTION WILL
INCREASE THE POWER HANDLING OF YOUR WOOFERS.

FUSE
DESIGNED & ENGINEERED IN U.S.A.
12
4BRIDGED
TORO AUDIO Rage Mono Block amplifiers will draw large levels of current, so use the largest gauge power /
ground cable possible. Using too small of a power cable can result in unnecessary over-heating of the amplifier,
distortion at high volume levels and might even cause the thermal protection circuitry to shut-off the amplifier.
Remember, bigger wire and pure copper is better! For the best results we recommend a 100% Pure Copper
amplifier install kit available at your local TORO AUDIO dealer
Use rubber grommets when running cables through any metal or sharp plastic, to prevent accidental
shorting or shearing. Make sure the cables do not interfere with the normal operation of the vehicle
The audio signal cables (RCA Cables) should be kept far away from any potential sources of
electrical interference such as electronic vehicle management systems, relays, engine computers
wiring harnesses, fuel pumps etc.
FIG5. Power Input Connection
This amplifier is designed to work within a 9 to 16 volt DC range. Before any wires are connected, the vehicles
electrical system should be checked for correct voltage supply with the help of a voltmeter.
First, check the voltage at the battery with the ignition in the OFF position. The voltmeter should read no less than
12V. If your vehicles electrical system is not up to these specifications, we recommend having it checked by an auto
electrician before any further installation. Once the vehicle is checked, make certain the correct cable gauge is used.
We recommend using as large a gauge cable as possible, use the Power Cable Selection Chart to calculate the
correct power wire size for your application. Remember Bigger is Better!
18. HIGH PASS FILTER
SWITCH THE (HP) HIGH PASS FREQUENCY SWITCH FOR HIGH PASS FREQUENCY SET UP FROM FULL RANGE UP TO
3 KHZ BASED ON YOUR SPEAKERS AND SYSTEM SETUP REQUIREMENTS. SWITCH TO LOW/BAND PASS FOR A
VERSATILE BANDPASS SET UP FROM 20HZ TO 3KHZ OR SIMPLY A LOW PASS SET UP FOR SUBWOOFERS WITH SUB
SONIC CONTROL.
Remote 12V Output
USED TO CONTROL THE FREQUENCY BAND WIDTH (I.E.) WIDE WILL EFFECT MORE FREQUENCIES AND NARROW
EFFECTS LESS FREQUENCIES.
17. Q CONTROL (WIDE AND NARROW) FOR R4, R5, R6
19. DIFFERENTIAL INPUT SWITCH
SWITCH THE DIFFERENTIAL INPUT SWITCH IN CASE OF THE NOISE FROM INSTALLTION

GND(Ground)
12V(Power)
This amplifier should be wired directly to the vehicle battery using the appropriate size cable. Start
at the vehicle battery and run the power cable through to the amplifier. Avoid running the power cable
over engine components and near heater cores. The use of an in-line fuse or circuit breaker is a
must; this will prevent the risk of a potential fire caused by a short in your power cable Connect the
fuse holder or circuit breaker as close to the battery positive (+) terminal as possible (no farther then
18" from that battery). This fuse or circuit breaker should be no greater than the sum of the fuses found
on the chassis of your amplifier (also see specifications chart). You may now connect the cable to the
battery, but remember to leave the fuse out or circuit breaker "off" until all other cable connections
are made.
When grounding your amplifier, locate a metal area close to the amplifier that is good source of
ground (preferably the floor pan). Once again, investigate the area you wish to use for electrical
wires,vacuum lines, and brake or fuel lines. Use either a wire brush or sandpaper to eliminate
unwanted paint for better contact of the ground.
Now it's time to connect the power and ground cables to the amplifier. Cut both cables to length.
Use a Phillips screwdriver to loosen the BATT+ and the GND connections on the amplifier. Insert the
ground first, and then the +12V and please make sure that you place them into the correctly marked
terminals. Then tighten the screws down securely.

REM (Remote Trigger)
FUSE REQUIREMENTS
While the panel on your TORO AUDIO amplifier incorporates one or more fuses, these do nothing
to protect the vehicle from a dangerous short circuit. It is absolutely vital that the main power lead to
the amplifier(s)in the system be fused within 18-inches(45cm) of the connection to the vehicle battery.
The value of this fuse (or circuit breaker) should be no greater than the sum of the fuses found on all
of the equipment being connected to that power wire.
This terminal must be connected to a switched +12V source. Typically, remote turn-on leads are
provided at the source unit that will turn on and off the amplifier in correspondence with the source.
If the source unit does not have a remote turn-on lead, then a switched +12V supply must be used,
like the ACC,+12V.
Run a minimum of 18-gauge wire from the amplifier location to the source of the switched +12V lead.
If possible, route this wire on the same side of the vehicle as your power cable. Connect the source
remote output to the wire. Go back to the amplifier and cut the wire to length. Loosen the screw
terminal marked REM on the amplifier

FUSE
DESIGNED & ENGINEERED IN U.S.A.
12
4BRIDGED
X2
PWR/PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
HPF
2-4 OHM 2-4 OHM
11
FIG6. Low Level Input using RCA
Choose the correct length and style of RCA interconnects for your needs. Always use high quality
RCA audio cables (not supplied) for signal connections--those with multiple layers of shielding or a
twisted pair variety provides better noise rejection.
Be extra careful when routing your RCA audio interconnect cables. Car environments are notorious
for poorly insulated wires. This means that hiss, engine noise, and fan noise can easily be picked up
through RCA cables if run incorrectly.
Make sure that the cables for power and audio signal are not on the same side of the vehicle and
that they do no cross each other; this will help reduce any noise that may radiate from the power
cable and the signal cable. If an audio cable is too close to a power cable, it may pick up the
magnetic field generated by the power cable, which could lead to a loss of quality in your signal.

FUSE
DESIGNED & ENGINEERED IN U.S.A.
2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
R2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
BASS
BOOST
12dB
10V 0.2
Q
CONTROL
WIDE NARROW
R3/R4/R5/R6
R3/R4/R5/R6
R2
12
FIG7. MONO AMPLIFIER WIRING (SINGLE WOOFER LOAD)
WIRING DIAGRAM
2 OH M MI N IM UM
R4F
2 OH M MI N IM UM
R4F

PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
BASS
BOOST
12dB
10V 0.2
Q
CONTROL
WIDE NARROW
R3/R4/R5/R6
R3/R4/R5/R6
FIG8. MONO AMPLIFIER WIRING (MULTI-WOOFER LOAD)
4 OH M
4 OH M
*EQUIVALENT PARALLEL WOOFER LOADS CANNOT BE LESS THAN THE MINIMUM STABLE LOAD RATED IN THIS
MANUAL. THE TWO NEGATIVE AND TWO POSITIVE SPEAKER TERMINALS ARE WIRED INTERNALLY INSIDE EACH
AMPLIFIER.
ONLY ONE NEGATIVE AND ONE POSITIVE ARE NEEDED WHEN WIRING TO THE AMPLIFIER.
THESE ARE MONO-BLOCK AMPLIFIERS AND NOT MULTI-CHANNEL AMPLIFIERS.
THE MINIMUM LOAD FOR ALL “MONO RAGE” (MONOBLOCK) AMPLIFIERS ARE 1-OHM, EXCEPT "R2"
(2-OHM MINIMUM).
Tw o DUAL 4 -Oh m SU B

FUSE
DESIGNED & ENGINEERED IN U.S.A.
12
4BRIDGED
X2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
HPF
FIG9. (1-CHANNEL MODE)RX2 AMPLIFIER WIRING
FUSE
DESIGNED & ENGINEERED IN U.S.A.
12
4BRIDGED
X2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
HPF
FIG10. (2-CHANNEL MODE)RX2 AMPLIFIER WIRING
MINI M U M I M P E D A N C E FOR
BRI D G E D I N S TA LLATI O N I S 4 - O H M
MINI M U M I M P E D A N C E FOR
STER E O I N S TA L LATIO N I S 2 - O H M

15
FUSE
SPEAKERS
bridged
1 2
3 4
1 2
3 4
4
DESIGNED & ENGINEERED IN U.S.A.
X4S
PWR/PRO
X-OVER
HP
Full 3KHz 3KHz80
Full
/HiPass
Low/
BandPass
LP
REAR
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2 10V 0.2
FIG11. (3-CHANNEL MODE)RX4/RX4S AMPLIFIER WIRING

16
FUSE
SPEAKERS
bridged
1 2
3 4
1 2
3 4
4
DESIGNED & ENGINEERED IN U.S.A.
X4S
PWR/PRO
X-OVER
HP
Full 3KHz 3KHz80
Full
/HiPass
Low/
BandPass
LP
REAR
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2 10V 0.2
FIG12. (4-CHANNEL MODE)RX4/RX4S AMPLIFIER WIRING

17
TROUBLE SHOOTING
NOTE: If the Status LED is activated and glows RED with no speakers connected to the
amplifier, and all the power connections are correct, this would indicate an internal problem
with the amplifier. Contact TORO AUDIO USA or your local dealer.

18
RAGE AMPLIFIER SPECIFICATION CHART
25A 50A 60A 50A 60A 100A 120A 200A
195mm 295mm 319mm 295mm 195mm 275mm 355mm 531mm
7.68” 11.61” 12.56” 11.61” 7.68” 10.83” 13.98” 20.9”
MODEL RX2 RX4 RX4S R2 R3 R4 R5 R6
Description 2ch 4ch 4ch 1ch 1ch 1ch 1ch 1ch
4 Ohm RMS Power (Watt) 2x 75 4x75 4x100 1x270 1x280 1x400 1x600 1x1300
2 Ohm RMS Power (Watt) 2x120 4x120 4x150 1x500 1x480 1x800 1x1200 1x2000
1 Ohm RMS Power (Watt) N/A N/A N/A N/A 1x 750 1x1250 1x2000 1x3200
0.5 Ohm RMS Power (Watt) N/A N/A N/A N/A N/A N/A N/A 1x4000
4 Ohm Bridged Power (Watt) 1x300 2x300 2x360 N/A N/A N/A N/A N/A
Peak Music Power (Watt) 2x250 4x250 4x300 1x1000 1x1500 1x2500 1x4000 1x8000
THD @ RMS Power ＜0.05% ＜0.05% ＜0.05% ＜0.5% ＜0.8% ＜1% ＜1% ＜1%
Frequency Response 12Hz-40kHz 14Hz-50kHz 14Hz-50kHz 12Hz-50kHz 13Hz-220Hz 13Hz-220Hz 13Hz-220Hz 13Hz-220Hz
S/N Ratio (EIA Rated) >105dB >105dB >105dB >100dB >100dB >100dB >100dB >100dB
Input Sensitivity 200mV-10V 200mV-10V 200mV-10V 200mV-10V 200mV-10V 200mV-10V 200mV-10V 200mV-10V
Crossover Slope
LPF/HPF 50Hz-260Hz/ FULL-
3KHz
80Hz-3KHz/ FULL-
3KHz
80Hz-3KHz/ FULL-
3KHz 50Hz-750Hz
SUBSONIC FILTER N/A N/A N/A N/A
Bass EQ (on/off) OFF-6DB -12DB OFF-6DB -12DB OFF-6DB -12DB OFF-6DB -12DB
Subwoofer EQ Freq. N/A N/A N/A N/A
Fuses/ ATC Style
Dimensions (2.0” H x 7.1” W)
Dimensions (54mm H x 171mm W)
0-60Hz
0 -12DB
30Hz-120Hz
Power output @ 14.4VDC Input
12dB (REAR CHANNEL) 12dB
60Hz-220Hz
90A
148mm
5.82”
R4F
1ch
1x400 1x800
1x1250
N/A N/A
1x2500
＜0.3%
25Hz-18KHz
>90dB
400mV-10V
25Hz-18KHz
25Hz-9.1KHz

19
TORO AUDIO WARRANTY POLICY
This warranty covers only the original purchaser of TORO AUDIO products. In order to receive service, the
purchaser must provide TORO AUDIO with the receipt stating the consumer name, dealer, product and
date of purchase.
Products found to be defective during the warranty period will be repaired or replaced (with a product
deemed to be equivalent) at TORO AUDIO's discretion and will not be liable for incidental or consequential
damages. TORO AUDIO will not warranty this product under the following situations:
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to
the period of the express warranty set forth above. Some states do not allow limitations on the length of an
implied warranty, so this limitation may not apply. No person is authorized to TORO AUDIO any other
liability in connection with the sale of this product.
Residents of HI, AK and US territories will be charged for return shipping. All inquiries regarding service
and warranty should be sent to the above address or via email at [e-mail].
TORO AUDIO Amplifiers are to be free of defects in material and workmanship for a period of 90 days,
from the date of purchase, if purchased over the counter from an authorized TORO AUDIO retailer. The
Warranty will increase to 1 (one) year if installed by a TORO AUDIO Authorized Installer.
TORO TECH LLC.
TORO TECH LLC offers limited warranty on TORO AUDIO products under normal use on the following terms:
TORO AUDIO Amplifiers are to be free of defects in material and workmanship for a period of
one(1)year.
• Amplifiers received with apparent rust or corrosion
• Any evidence of liquid damage or exposure to excessive heat
• Attempted repairs or alterations of any nature
• Product that has not been installed according to this owner’s manual
• Products that are used beyond normal operating conditions
• Products that have blown circuitry due to misuse
