Toro 30635 User manual

FormNo.3403-554RevA
Groundsmaster®4010Rotary
Mower
ModelNo.30635—SerialNo.316000501andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3403-554*A

ThisproductcomplieswithallrelevantEuropeandirectives;
fordetails,pleaseseetheseparateproductspecicDeclaration
ofConformity(DOC)sheet.
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Dieselengineexhaustandsomeofits
constituentsareknowntotheStateof
Californiatocausecancer,birthdefects,
andotherreproductiveharm.
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineonany
forest-covered,brush-covered,orgrass-coveredlandunless
theengineisequippedwithasparkarrester,asdenedin
Section4442,maintainedineffectiveworkingorderorthe
engineisconstructed,equipped,andmaintainedforthe
preventionofre.
Introduction
Thismachineisaride-on,rotary-bladelawnmowerintended
tobeusedbyprofessional,hiredoperatorsincommercial
applications.Itisprimarilydesignedforcuttinggrass
onwell-maintainedlawnsinparks,sportselds,andon
commercialgrounds.Itisnotdesignedforcuttingbrush,
mowinggrassandothergrowthalongsidehighways,orfor
agriculturaluses.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.comforproduct
safetyandoperationtrainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.Writethenumbers
inthespaceprovided.
g028455
1
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafety-alertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Contents
Safety...........................................................................4
GeneralSafety.........................................................4
SoundPowerLevel..................................................4
SoundPressureLevel...............................................4
VibrationLevel......................................................4
EngineEmissionCertication...................................4
SafetyandInstructionalDecals.................................5
Setup...........................................................................14
1GreasingtheMachine...........................................14
2ReplacingtheWarningDecal.................................14
3CheckingtheTirePressure....................................14
4CheckingtheFluidLevels.....................................15
ProductOverview.........................................................15
Controls...............................................................15
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

CabControls......................................................17
Specications........................................................21
Attachments/Accessories........................................21
BeforeOperation......................................................22
BeforeOperationSafety..........................................22
CheckingtheEngine-OilLevel.................................23
CheckingtheCoolingSystem...................................23
CheckingtheHydraulicSystem................................23
FillingtheFuelTank...............................................23
CheckingtheTirePressure......................................24
CheckingtheTorqueoftheWheel-Lug
Nuts.................................................................24
AdjustingtheHeightofCut.....................................25
AdjustingtheSkids.................................................27
AdjustingtheMower-DeckRollers...........................28
CorrectingaMismatchBetweenMower
Decks................................................................28
CheckingtheSafety-InterlockSwitches......................29
AdjustingtheMirrors..............................................30
AimingtheHeadlights............................................30
DuringOperation.....................................................30
DuringOperationSafety.........................................30
StartingandStoppingtheEngine..............................31
UnderstandingSmartPower™Traction....................32
ReversingFanOperation.........................................32
UnderstandingAutoIdle.........................................32
UsingCruiseControl..............................................32
UsingtheEngine-SpeedSwitch................................32
AdjustingtheMowingSpeed....................................32
AdjustingtheTransportSpeed.................................32
UnderstandingtheOperatingCharacteristicsofthe
Machine............................................................33
OperatingTips......................................................33
AfterOperation........................................................34
AfterOperationSafety............................................34
PushingorTowingtheMachine................................34
LocatingtheJackingPoints......................................35
HaulingtheMachine...............................................35
LocatingtheTie-DownPoints..................................35
Maintenance.................................................................36
RecommendedMaintenanceSchedule(s)......................36
DailyMaintenanceChecklist....................................37
ServiceIntervalChart.............................................39
PremaintenanceProcedures........................................39
Pre-MaintenanceSafety...........................................39
PreparingtheMachineforMaintenance.....................40
RemovingtheHood...............................................40
Lubrication...............................................................40
GreasingtheBearingsandBushings..........................40
EngineMaintenance..................................................43
EngineSafety.........................................................43
ServicingtheAirCleaner.........................................43
CheckingtheEngine-OilLevel.................................44
ChangingtheEngineOilandFilter...........................45
FuelSystemMaintenance...........................................45
ServicingtheFuelSystem........................................45
ServicingtheWaterSeparator...................................46
ElectricalSystemMaintenance....................................46
ElectricalSystemSafety...........................................46
ServicingtheBattery...............................................47
LocatingtheFuses..................................................48
DriveSystemMaintenance.........................................49
AdjustingtheTraction-PedalAngle...........................49
CheckingthePlanetary-Gear-DriveOil.....................49
ChangingthePlanetary-Gear-DriveOil.....................49
CheckingtheRear-AxleLubricant.............................50
CheckingtheRear-Axle-GearboxLubricant...............50
ChangingtheRear-AxleLubricant............................50
CheckingtheRearWheelToe-In..............................51
CoolingSystemMaintenance......................................52
CoolingSystemSafety.............................................52
CheckingtheCoolingSystem...................................52
ServicingtheEngine-CoolingSystem........................52
BrakeMaintenance....................................................53
AdjustingtheServiceBrakes....................................53
BeltMaintenance......................................................54
ServicingtheAlternatorBelt....................................54
ServicingtheCompressorBelt.................................54
TensioningtheBlade-DriveBelts..............................54
ReplacingtheBlade-DriveBelt.................................54
HydraulicSystemMaintenance....................................55
HydraulicSystemSafety..........................................55
CheckingtheHydraulicFluid...................................55
ChangingtheHydraulicFluid...................................57
ReplacingtheHydraulicFilters.................................57
CheckingtheHydraulicLinesandHoses....................57
AdjustingtheCounterbalancePressure......................58
MowerMaintenance...................................................58
Pivoting(Tilting)theFrontMowerDecktothe
UprightPosition.................................................58
PivotingtheFrontMowerDeckDown......................58
AdjustingtheMower-DeckPitch..............................59
ServicingtheCaster-ArmBushings...........................59
ServicingtheCasterWheelsandBearings...................60
BladeMaintenance.....................................................61
BladeSafety...........................................................61
CheckingforaBentBlade........................................61
RemovingandInstallingtheMowerBlade(s)..............61
InspectingandSharpeningtheMower
Blade(s).............................................................61
CorrectingaMower-DeckMismatch.........................62
CabMaintenance.......................................................63
CleaningtheCab....................................................63
CleaningtheCabAirFilters.....................................63
CleaningtheAir-ConditioningAssembly
........................................................................64
Storage........................................................................65
PreparingforSeasonalStorage.................................65
3

Safety
ThismachinehasbeendesignedinaccordancewithENISO
5395:2013andANSIB71.4-2012.
Improperuseormaintenancebytheoperatororownercan
resultininjury.Toreducethepotentialforinjury,comply
withthesesafetyinstructionsandalwayspayattentionto
thesafetyalertsymbol,whichmeansCaution,Warning,or
Danger—personalsafetyinstruction.Failuretocomplywith
theinstructionmayresultinpersonalinjuryordeath.
GeneralSafety
Thisproductiscapableofamputatinghandsandfeetand
ofthrowingobjects.Alwaysfollowallsafetyinstructionsto
avoidseriouspersonalinjury.
Usingthisproductforpurposesotherthanitsintendeduse
couldprovedangeroustoyouandbystanders.
•ReadandunderstandthecontentsofthisOperator’sManual
beforeyoustarttheengine.Ensurethateveryoneusing
thisproductknowshowtouseitandunderstandsthe
warnings.
•Donotputyourhandsorfeetnearmovingcomponents
ofthemachine.
•Donotoperatethemachinewithoutallguardsandother
safetyprotectivedevicesinplaceandworkingonthe
machine.
•Keepclearofanydischargeopening.Keepbystandersa
safedistancefromthemachine.
•Keepchildrenoutoftheoperatingarea.Neverallow
childrentooperatethemachine.
•Stopthemachineandshutofftheenginebeforeservicing,
fueling,oruncloggingthemachine.
Improperlyusingormaintainingthemachinecanresult
ininjury.Toreducethepotentialforinjury,complywith
thesesafetyinstructionsandalwayspayattentiontothe
safety-alertsymbol,whichmeansCaution,Warning,or
Danger—personalsafetyinstruction.Failuretocomplywith
theseinstructionsmayresultinpersonalinjuryordeath.
Youcanndadditionalitemsofsafetyinformationintheir
respectivesectionsthroughoutthismanual.
SoundPowerLevel
Thisunithasaguaranteedsoundpowerlevelof104dBA,
whichincludesanUncertaintyValue(K)of1dBA.
Soundpowerlevelwasdeterminedaccordingtothe
proceduresoutlinedinISO11094.
SoundPressureLevel
Thisunithasasoundpressurelevelattheoperator’searof
85dBA,whichincludesanUncertaintyValue(K)of1dBA.
Soundpressurelevelwasdeterminedaccordingtothe
proceduresoutlinedinENISO5395:2013.
VibrationLevel
Hand-Arm
Measuredvibrationlevelforrighthand=0.58m/s2
Measuredvibrationlevelforlefthand=0.63m/s2
UncertaintyValue(K)=0.32m/s2
Measuredvaluesweredeterminedaccordingtotheprocedures
outlinedinENISO5395:2013.
WholeBody
Measuredvibrationlevel=0.26m/s2
UncertaintyValue(K)=0.13m/s2
Measuredvaluesweredeterminedaccordingtotheprocedures
outlinedinENISO5395:2013.
EngineEmissionCertication
TheengineinthismachineisEUStage3acompliant.
4

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotential
danger.Replaceanydecalthatisdamagedorlost.
93-7272
1.Cutting/dismembermenthazard;fan—stayawayfrom
movingparts.
93-7275
1.ReadtheOperator'sManual.
2.Donotusestartingaids.
93-7818
1.Warning—readtheOperator'sManualforinstructionson
torquingthebladebolt/nutto115to149N∙m(85to110
ft-lb).
100-5622
1.Height-of-cutadjustment
100-5623
1.Lowheight-of-cut
adjustment
2.Highheight-of-cut
adjustment
100-5624
1.Height-of-cutadjustment
100-5693
1.Height-of-cutadjustment
5

100-5694
1.Height-of-cutadjustment
100-6578
1.Entanglementhazard,belt—donotoperatethemachine
withtheshieldsorguardsremoved;alwayskeeptheshields
andguardsinplace;stayawayfrommovingparts.
104-3578
1.Height-of-cutadjustment
104-3579
1.Lowheight-of-cut
adjustment
2.Highheight-of-cut
adjustment
106-6754
1.Warning—donottouchthehotsurface.
2.Cutting/dismembermenthazard,fanandentanglement
hazard,belt—stayawayfrommovingparts.
106-6755
1.Enginecoolantunder
pressure.
3.Warning—donottouchthe
hotsurface.
2.Explosionhazard—read
theOperator'sManual.
4.Warning—readthe
Operator'sManual.
114-0845
1.Steering-wheeltiltlever2.Horn
6

114-0846
1.ReadtheOperator’s
Manualforinformationon
startingtheengine—1)Set
toneutral;2)Engagethe
brake;3)Settheengine
speedtoslow;4)Turnthe
ignitionkeytopreheat;5)
Turntheignitionkeyto
enginestart.
4.Pulltheknoboutto
engagethePTO.
2.ReadtheOperator’s
Manualforinformationon
stoppingtheengine—1)
Settheenginespeedto
slow;2)Disengagethe
deck;3)Locktheparking
brake;4)Wait5minutes;
5)Turntheignitionkeyto
enginestop;6)Remove
thekeyfromtheignition.
5.Pushtheknobinto
disengagethePTO.
3.ReadtheOperator’s
Manual.
6.RaisethedeckstogotoH
range.
114-0849
1.Warning—1)Disengage
thePTO;2)Raisethe
deck.
4.Forwarddirection
2.Donotplaceyourfoot
here.
5.Reversedirection
3.Directionpedal
120-4129
1.Beacon3.Left-turnsignal
2.Hazardlight4.Right-turnsignal
7

120-4130
1.ReadtheOperator’s
Manual.
3.Parkingbrake
2.Toengagetheparking
brake—1)Lockthepedals
together;2)Pushdownon
thebrake;3)Pulloutthe
parkingbrakeknob.
4.Todisengagetheparking
brake,pushdownonthe
brakepedal.
120-4159
1.Off8.High
2.Lights9.Tractiondrive
3.On10.Low
4.Light-switchlocation11.Powertakeoff(PTO)
5.Fast12.Lower,leftdeck
6.Variable-speedadjustment13.Lower,centerdeck
7.Slow14.Lower,rightdeck
120-6604
1.Thrownobjecthazard—keepbystandersawayfromthe
machine.
2.Cutting/dismembermenthazardofhand,mower
blade—stayawayfrommovingparts,keepallguardsand
shieldsinplace.
3.Cutting/dismembermenthazardoffoot,mowerblade—stay
awayfrommovingparts,keepallguardsandshieldsin
place.
8

121-1599
1.ReadtheOperator’sManualforinformationonfuses.
121-3884
1.Engine—stop3.Engine—start
2.Engine—preheat
121-3887
1.ReadtheOperator’sManual.
125-9688
1.Windshieldwipers—off3.Windshieldwipers—on
2.Windshieldwipers4.Spraywindshieldwasher
uid
127-3700
1.Raisetheleftdeck4.Locktheenginespeed
2.Raisethecenterdeck5.Unlocktheenginespeed
3.Raisetherightdeck
9

130-0594
1.Warning—readtheOperator’sManual;whensittinginthe
cab,alwayswearaseatbelt;wearhearingprotection.
130-0611
1.1)Removethepin.2)Raisethedoors.3)Exitthecab.
130-5355
1.Closetherearwindow.2.Raisethehood.
130-5356
1.Usethefootpedaltomoveforwardorinreverse.
132-3600
1.ReadtheOperator's
Manualformore
informationonfuses.
5.Workinglight—20A
2.Headlight—25A6.Auxiliarypower—15A
3.CondenserfanandA/C
clutch—30A
7.Cablight—15A
4.Fan—25A8.Windshieldwipers—15A
BatterySymbols
Someorallofthesesymbolsareonyourbattery.
1.Explosionhazard6.Keepbystandersasafe
distancefromthebattery.
2.Nore,opename,or
smoking.
7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.
3.Causticliquid/chemical
burnhazard
8.Batteryacidcancause
blindnessorsevereburns.
4.Weareyeprotection.9.Flusheyesimmediately
withwaterandgetmedical
helpfast.
5.ReadtheOperator's
Manual.
10.Containslead;donot
discard.
10

117-2754
1.Warning—readtheOperator'sManual.
2.Warning—donotoperatethismachineunlessyouaretrained.
3.Warning—weartheseatbeltwhenseatedintheoperator'sposition.
4.Warning—wearhearingprotection.
5.Thrownobjecthazard—keepbystandersasafedistancefromthemachine.
6.Cuttinghazardofhandorfoot—stayawayfrommovingparts;keepallguardsinplace.
7.Tippinghazard—lowerthecuttingunitwhendrivingdownslopes;slowmachinebeforeturning,donotturnathighspeeds
8.Warning—locktheparkingbrake,stoptheengineandremovetheignitionkeybeforeleavingthemachine.
117-2766
(AfxoverPartNo.117-2754forCE*)
*ThissafetydecalincludesaslopewarningrequiredonthemachineforcompliancetotheEuropeanLawnMowerSafetyStandardEN836:1997.Theconservativemaximum
slopeanglesindicatedforoperationofthismachineareprescribedbyandrequiredbythisstandard.
1.Warning—readtheOperator'sManual.
2.Warning—donotoperatethismachineunlessyouaretrained.
3.Warning—weartheseatbeltwhenseatedintheoperator'sposition.
4.Warning—wearhearingprotection.
5.Thrownobjecthazard—keepbystandersasafedistancefromthemachine.
6.Cuttinghazardofhandorfoot—stayawayfrommovingparts;keepallguardsinplace.
7.Tippinghazard—lowerthecuttingunitwhendrivingdownslopes;donotoperatemachineonslopesgreaterthan15degrees.
8.Warning—locktheparkingbrake,stoptheengineandremovetheignitionkeybeforeleavingthemachine.
11

121-8378
1.Fan—off3.Coldair5.Externalair7.Airconditioner—off(If
equipped)
2.Fan—onfull4.Hotair6.Internalair8.Airconditioner—on(If
equipped)
12

130-6046
1.ReadtheOperator’sManual.
13

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Greasethemachine.
2Warningdecal1Replacethewarningdecal.
3Nopartsrequired–Checkthetirepressure.
4Nopartsrequired–Checktheuidlevels.
MediaandAdditionalParts
DescriptionQty.Use
Operator'sManual1Reviewbeforeoperatingmachine
Engineowner'sManual1Usetoreferenceengineinformation
PartsCatalog1Usetoreferencepartnumbers
Operatortrainingmaterials1Reviewbeforeoperatingmachine
DeclarationofConformity1
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
1
GreasingtheMachine
NoPartsRequired
Procedure
Beforeoperatingthemachine,greaseittoensureproper
lubricatingcharacteristics;refertoLubrication(page40).
Important:Failuretoproperlygreasethemachinewill
resultinprematurefailureofcriticalparts.
2
ReplacingtheWarningDecal
ForCEModelsOnly
Partsneededforthisprocedure:
1Warningdecal
Procedure
OnmachinesrequiringEuropeanCEcompliance,replace
thewarningdecalPartNo.117-2754withthewarningdecal
PartNo.117-2766.
14

3
CheckingtheTirePressure
NoPartsRequired
Procedure
Checkthetirepressure;refertoCheckingtheTirePressure
(page24).
4
CheckingtheFluidLevels
NoPartsRequired
Procedure
1.Checktheengine-oillevel;refertoCheckingthe
Engine-OilLevel(page44).
2.Checkthehydraulicuidlevel;refertoCheckingthe
HydraulicFluid(page55).
3.Checkthecoolingsystem;refertoCheckingthe
CoolingSystem(page23).
4.Checktheplanetary-gear-driveoil;refertoChecking
thePlanetary-Gear-DriveOil(page49).
5.Checktherear-axlelubricant;refertoCheckingthe
Rear-AxleLubricant(page50).
6.Checktherear-axle-gearboxlubricant;referto
CheckingtheRear-Axle-GearboxLubricant(page50).
ProductOverview
Controls
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
9
10 g020756
Figure3
1.Brakepedals6.Hazard-lightswitch
(optional)
2.Pedal-lockinglatch7.Turn-signalswitch
(optional)
3.Parking-brakelatch8.Hornbutton(optional)
4.Spaceforoptional
accessory
9.Tractionpedal
5.Beaconswitch(optional)10.Tilt-steeringlever
TractionPedal
Tostop,reduceyourfootpressureonthetractionpedaland
allowittoreturntothecenterposition(Figure3).
BrakePedals
Thereare2footpedalsthatoperateindividualwheelbrakes
forturningassistance,parking,andtoaidinbetterside-hill
traction.Alatchconnectsthepedalsforparking-brake
operationandtransport(Figure3).
Pedal-LockingLatch
Thepedal-lockinglatchconnectsthepedalstogetherto
engagetheparkingbrake(Figure3).
Tilt-SteeringLever
Pressthetilt-steeringleverdowntotiltthesteeringwheel
tothedesiredposition,thenreleasethelevertolockthe
adjustment(Figure3).
15

Parking-BrakeLatch
Aknobontheleftsideoftheconsoleactuatesthe
parking-brakelock(Figure3).
Toengagetheparkingbrake,connectthepedalswiththe
lockinglatch,pushdownonbothpedals,andpullthe
parking-brakelatchout.Toreleasetheparkingbrake,press
bothpedalsuntiltheparking-brakelatchretracts.
Hazard-LightSwitch(Optional)
Pressthehazard-lightswitchtoactivatethehazardlights
(Figure3).
Turn-SignalSwitch(Optional)
Presstheleftsideoftheturn-signalswitchtoactivatethe
left-turnsignalandtherightsideoftheswitchtoactivatethe
right-turnsignal(Figure3).
KeySwitch
Thekeyswitch(Figure4)has3positions:OFF,
ON/PREHEAT,andSTART.
g028453
1
2
3
4
5
6
7
Figure4
1.Liftswitches5.High-Lowspeedcontrol
2.PTOswitch6.Engine-speedswitch
3.Keyswitch7.Lightswitch(optional)
4.InfoCenter
Engine-SpeedSwitch
Theengine-speedswitchhas2modestochangetheengine
speed(Figure4).
Bymomentarilytappingtheswitch,youcanincreaseor
decreasetheenginespeedin100-rpmincrements.Whenyou
holdtheswitchdown,theengineautomaticallymovesto
HIGHorLOWIDLE,dependingonwhichsideoftheswitch
youpress.
PTOSwitch
ThePTOswitchhas2positions:OUT(START)andIN(STOP).
PullthePTObuttonouttoengagethemower-deckblades.
Pushthebuttonintodisengagethemower-deckblades
(Figure4).
High-LowSpeed-ControlSwitch
TheHigh-Lowspeed-controlswitchallowsthespeedrange
toincreasefortransportofthemachine(Figure4).
Mowerdecksdonotoperateinhighrange.Toswitchbetween
theHIGHandLOWrange,raisethedecks,disengagethePTO,
disengagethecruisecontrol,movethetractionpedalinthe
NEUTRALposition,andmovethemachineataslowspeed.
LiftSwitches
Theliftswitchesraiseandlowerthemowerdecks(Figure
4).Presstheswitchesforwardtolowerthemowerdecks
andrearwardtoraisethemowerdecks.Whenstartingthe
machine,withthemowerdecksinthedownposition,press
theliftswitchdowntoallowthemowerdeckstooatand
mow .
Note:ThedecksdonotlowerwhileintheHigh-speedrange
andtheydonotraiseorloweriftheoperatorisoutoftheseat
whentheengineisrunning.Also,thedeckslowerwiththe
keyintheONpositionandtheoperatorintheseat.
Cruise-ControlSwitch
Thecruise-controlswitchlocksinthepedalpositionto
maintainthedesiredgroundspeed(Figure5).Pressingthe
rearoftheswitchturnsoffthecruisecontrol,themiddle
positionoftheswitchenablesthecruise-controlfunction,
andthefrontoftheswitchsetsthedesiredgroundspeed.
Note:Pressingeitherbrakepedalormovingthetraction
pedalintotheREVERSEposition,for1second,also
disengagesthecruisecontrol.
g028454
12
Figure5
1.Power-pointport2.Cruise-controlswitch
16

Power-PointPort
Thepower-pointportisusedtopoweroptionalelectrical
accessories(Figure5).
AdjustingtheSeat
Seat-AdjustmentLever
Movetheseat-adjustmentleveronthesideoftheseat
outward,slidetheseattothedesiredposition,andreleasethe
levertolocktheseatintoposition(Figure6).
Figure6
1.Weightgauge4.Seat-backadjustment
lever
2.Weight-adjustmentlever5.Armrest-adjustmentknob
(notshown;locatedunder
armrest)
3.Seat-adjustmentlever
Armrest-AdjustmentKnob
Rotatetheknobtoadjustthearmrestangle(Figure6).
Seat-Back-AdjustmentLever
Movethelevertoadjusttheseat-backangle(Figure6).
WeightGauge
Theweightgaugeindicateswhentheseatisadjustedto
theweightoftheoperator(Figure6).Adjusttheheightby
positioningthesuspensionwithintherangeofthegreen
region.
Weight-AdjustmentLever
Usethislevertoadjusttotheproperweightoftheoperator
(Figure6).Pullupthelevertoincreasetheairpressure
andpushdowntodecreasetheairpressure.Theproper
adjustmentiscorrectwhentheweightgaugeisinthegreen
region.
CabControls
Figure7
1.Air-conditioningswitch4.Temperaturecontrol
2.Air-recirculationcontrol5.Windshield-wiperswitch
3.Fancontrol6.Blankswitchesforoptional
kits
Air-RecirculationControl
Theair-recirculationcontrolsetsthecabtoeitherrecirculate
theairinthecabinortodrawairintothecabinfromoutside
(Figure7).
•Setittorecirculatetheairwhenusingtheair-conditioning.
•Setittodrawairinwhenusingtheheaterorfan.
FanControl
Rotatethefancontrolknobtoregulatethespeedofthefan
(Figure7).
TemperatureControl
Rotatethetemperaturecontrolknobtoregulatetheair
temperatureinthecab(Figure7).
Windshield-WiperSwitch
Usethisswitchtoturnthewindshieldwipersonoroff
(Figure7).
17

AirConditioningSwitch
Usethisswitchtoturntheairconditioningonoroff(Figure
7).
WindshieldLatch
Liftupthelatchestoopenthewindshield(Figure8).Pressin
thelatchtolockthewindshieldopen.Pulloutanddownon
thelatchtocloseandsecurewindshield.
Figure8
1.Windshieldlatch
RearWindowLatch
Liftupthelatchestoopentherearwindow .Pressinthelatch
tolockthewindowopen.Pulloutanddownonthelatchto
closeandsecurethewindow(Figure8).
Important:Youmustclosetherearwindowbeforeyou
openthehood;otherwise,damagemayoccur.
UsingtheInfoCenterControl
TheInfoCenterLCDdisplayshowsinformationaboutyour
machinesuchastheoperatingstatus,variousdiagnostics
andotherinformationaboutthemachine(Figure9).There
isasplashscreenandmaininformationscreeninthe
InfoCenter.Youcanswitchbetweenthesplashscreenand
maininformationscreenatanytimebypressinganyof
theInfoCenterbuttonsandthenselectingtheappropriate
directionalarrow.
1
g020650
2
3
4
TORO
Figure9
1.Indicatorlight3.Middlebutton
2.Rightbutton4.Leftbutton
•LeftButton,MenuAccess/BackButton—pressthis
buttontoaccesstheInfoCentermenus.Youcanuseitto
exitanymenuthatyouarecurrentlyusing.
•MiddleButton—usethisbuttontoscrolldownmenus.
•RightButton—usethisbuttontoopenamenuwherea
rightarrowindicatesadditionalcontent.
•Beeper—activatedwhenloweringthedecksorfor
advisoriesandfaults.
Note:Thefunctionofeachbuttonmaychangedepending
onwhatisrequiredatthetime.Eachbuttonislabeledwith
anicondisplayingitscurrentfunction.
InfoCenterIconDescription
SERVICEDUEIndicateswhenscheduledservice
shouldbeperformed
Enginerpm/status—indicatesthe
enginerpm
Hourmeter
Infoicon
Setsthemaximumtractionspeed
Fast
Slow
FanReversal—indicateswhenthe
fanisreversed
18

InfoCenterIconDescription(cont'd.)
Fuellevel
Stationaryregenerationrequired
Airintakeheaterisactive
Raisetheleftdeck
Raisethecenterdeck
Raisetherightdeck
Operatormustsitinseat
ParkingBrakeIndicator—indicates
whentheparkingbrakeison
IdentiestherangeasHigh
Neutral
IdentiestherangeasLow
CoolantT emperature-indicatesthe
enginecoolanttemperatureineither
°Cor°F
Temperature(hot)
TractionorTractionPedal
Deniedornotallowed
EngineStart
PTO—indicatesthatthePTOison
Stoporshutdown
Engine
Keyswitch
Indicateswhenthemowerdecksare
beinglowered
Indicateswhenthemowerdecksare
beingraised
PINpasscode
InfoCenterIconDescription(cont'd.)
Hydraulic-OilTemperature—indicates
thehydraulic-oiltemperature
CANbus
InfoCenter
Badorfailed
Center
Right
Left
Bulb
OutputofTECcontrollerorcontrol
wireinharness
High:over-allowedrange
Low:under-allowedrange
/
Outofrange
Switch
Operatormustreleasetheswitch
Operatorshouldchangetothe
indicatedstate
Symbolsareoften
combinedtoform
sentences.Some
examplesareshown
below
Operatorshouldputthemachinein
neutral
Enginestartdenied
Engineshutdown
Enginecoolantistoohot
Hydraulicuidistoohot
or
Sitdownorsettheparkingbrake
19

UsingtheMenus
ToaccesstheInfoCentermenusystem,pressthemenuaccess
buttonwhileatthemainscreen.Thiswillbringyoutothe
mainmenu.Refertothefollowingtablesforasynopsisof
theoptionsavailablefromthemenus:
MainMenu
MenuItemDescription
FaultsTheFaultsmenucontains
alistoftherecentmachine
faults.RefertotheService
ManualoryourAuthorized
ToroDistributorformore
informationontheFaults
menuandtheinformation
containedthere.
ServiceTheServicemenucontains
informationonthemachine
suchashoursofuseandother
similarnumbers.
DiagnosticsTheDiagnosticsmenu
displaysthestateofeach
machineswitch,sensorand
controloutput.Youcanuse
thistotroubleshootcertain
issuesasitwillquicklytellyou
whichmachinecontrolsareon
andwhichareoff.
SettingsTheSettingsmenuallows
youtocustomizeandmodify
congurationvariablesonthe
InfoCenterdisplay.
AboutTheAboutmenuliststhe
modelnumber,serialnumber,
andsoftwareversionofyour
machine.
Service
MenuItemDescription
HoursListsthetotalnumberofhours
thatthemachine,engineand
fanhavebeenon,aswellas
thenumberofhoursthatthe
machinehasbeentransported
andoverheated
CountsListsthenumberofpreheats
andstartsthatthemachine
hasexperienced
Diagnostics
MenuItemDescription
EngineRunRefertotheService
ManualoryourAuthorized
ToroDistributorformore
informationontheEngine
Runmenuandtheinformation
containedthere.
GlowplugsIndicatesifthefollowingitems
areactive:Keystart,timeout
limited,andglowplugs
FanIndicatesifthefanisactive
inthefollowinginstances:
Enginehightemp,oilhigh
temp,engineorhydraulichigh
temp,andfanon
Settings
MenuItemDescription
UnitsControlstheunitsusedonthe
InfoCenter;themenuchoices
areEnglishorMetric
LanguageControlsthelanguageused
ontheInfoCenter*
LCDBacklightControlsthebrightnessofthe
LCDdisplay
LCDContrastControlsthecontrastofthe
LCDdisplay
ProtectedMenusAllowsthedistributor/engineer
toaccessprotectedmenusby
inputtingapasscode
AutoIdleControlstheamountoftime
allowedbeforeidlingthe
enginewhenthemachineis
notinuse
MowSpeedControlsthemaximumspeed
whileinmow(lowrange)
TransSpeedControlsthemaximumspeed
whileintransport(highrange)
SmartPowerSmartPowerprevents
boggingdowninheavyturfby
automaticallycontrollingthe
machinespeedandoptimizing
cuttingperformance.
*Only"operator-faced"textistranslated.Faults,Service,and
Diagnosticsscreensare"service-faced."Titleswillbeinthe
selectedlanguage,butmenuitemsareinEnglish.
About
MenuItemDescription
ModelListsthemodelnumberofthe
machine
SNListstheserialnumberofthe
machine
MachineControllerRevisionListsthesoftwarerevisionof
themastercontroller
InfoCenterRevisionListsthesoftwarerevisionof
theInfoCenter
CANBusListsthemachine
communicationbusstatus
20
