Toro TimeCutter SW 5000 User manual

FormNo.3412-402RevA
TimeCutter®SW5000Riding
Mower
ModelNo.74790—SerialNo.400000000andUp
ModelNo.74795—SerialNo.400000000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3412-402*A

WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
ThissparkignitionsystemcomplieswithCanadianICES-002
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineonany
forest-covered,brush-covered,orgrass-coveredlandunless
theengineisequippedwithasparkarrester,asdenedin
Section4442,maintainedineffectiveworkingorderorthe
engineisconstructed,equipped,andmaintainedforthe
preventionofre.
GrossHorsepower
Thegrossornethorsepowerofthisenginewaslaboratory
ratedbytheenginemanufacturerinaccordancewiththe
SocietyofAutomotiveEngineers(SAE)J1940.Ascongured
tomeetsafety,emission,andoperatingrequirements,
theactualenginetorqueonthisclassofmowerwillbe
signicantlylower.
Gotowww.Toro.comtoviewspecicationsonyourmower
model.
Important:IfyouareusingamachinewithaToro
engineabove1500m(5,000ft)foracontinuousperiod,
ensurethattheHighAltitudeKithasbeeninstalledso
thattheenginemeetsCARB/EPAemissionregulations.
TheHighAltitudeKitincreasesengineperformance
whilepreventingspark-plugfouling,hardstarting,and
increasedemissions.Onceyouhaveinstalledthekit,
attachthehigh-altitudelabelnexttotheserialdecal
onthemachine.ContactanyAuthorizedToroService
DealertoobtaintheproperHighAltitudeKitand
high-altitudelabelforyourmachine.Tolocateadealer
convenienttoyou,accessourwebsiteatwww.Toro.com
orcontactourToroCustomerCareDepartmentatthe
number(s)listedinyourEmissionControlWarranty
Statement.
Removethekitfromtheengineandrestoretheengine
toitsoriginalfactorycongurationwhenrunningthe
engineunder1500m(5,000ft).Donotoperateanengine
thathasbeenconvertedforhigh-altitudeuseatlower
altitudes;otherwise,youcouldoverheatanddamage
theengine.
Ifyouareunsurewhetherornotyourmachinehasbeen
convertedforhigh-altitudeuse,lookforthefollowing
label.
decal127-9363
Introduction
Thismachineisaride-on,rotary-bladelawnmowerintended
tobeusedbyhomeownersinresidentialapplications.Itis
primarilydesignedforcuttinggrassonwell-maintainedlawns.
Itisnotdesignedforcuttingbrush,mowinggrassandother
growthalongsidehighways,orforagriculturaluses.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.comforproduct
safetyandoperationtrainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.Writethenumbers
inthespaceprovided.
g188142
Figure1
Undertheseat
1.Modelandserialnumberplate
Writetheproductmodelandserialnumbersinthespace
below:
©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafety-alertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
g000502
Figure2
1.Safety-alertsymbol.
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Contents
Safety...........................................................................4
GeneralSafety.........................................................4
SlopeIndicator.......................................................5
SafetyandInstructionalDecals.................................6
ProductOverview.........................................................11
Controls...............................................................11
BeforeOperation......................................................12
BeforeOperationSafety..........................................12
RecommendedFuel................................................13
UsingStabilizer/Conditioner...................................13
FillingtheFuelTank...............................................13
CheckingtheEngine-OilLevel.................................13
BreakinginaNewMachine......................................13
ThinkSafetyFirst...................................................14
UsingtheSafety-InterlockSystem.............................14
PositioningtheSeat................................................15
PositioningtheSteeringWheel.................................16
DuringOperation.....................................................16
DuringOperationSafety.........................................16
OperatingtheSmartPark™ParkingBrake..................17
OperatingtheMowerBlade-ControlSwitch
(PTO)...............................................................17
OperatingtheThrottle............................................17
OperatingtheChoke...............................................18
OperatingtheIgnitionSwitch..................................18
StartingandShuttingOfftheEngine.........................18
DrivingtheMachine...............................................19
StoppingtheMachine.............................................19
MowinginReverse.................................................20
AdjustingtheHeightofCut.....................................20
AdjustingtheAnti-ScalpRollers...............................21
OperatingTips......................................................21
AfterOperation........................................................22
AfterOperationSafety............................................22
PushingtheMachinebyHand..................................22
TransportingtheMachine........................................23
LoadingtheMachine..............................................23
Maintenance.................................................................25
RecommendedMaintenanceSchedule(s)......................25
Pre-MaintenanceProcedures......................................26
MaintenanceandStorageSafety................................26
RaisingtheSeat......................................................26
RaisingtheFrontoftheMachine..............................26
Lubrication...............................................................27
GreasingtheBearings.............................................27
EngineMaintenance..................................................27
EngineSafety.........................................................27
ServicingtheAirCleaner.........................................27
ServicingtheEngineOil..........................................28
ServicingtheSparkPlug..........................................31
CleaningtheCoolingSystem....................................32
FuelSystemMaintenance...........................................32
ReplacingtheIn-LineFuelFilter...............................32
ElectricalSystemMaintenance....................................33
ElectricalSystemSafety...........................................33
ServicingtheBattery...............................................33
ServicingtheFuses.................................................35
DriveSystemMaintenance.........................................35
CheckingtheTirePressure......................................35
ReleasingtheElectricBrake.....................................36
MowerMaintenance...................................................36
ServicingtheCuttingBlades.....................................36
LevelingtheMowerDeck........................................38
RemovingtheMowerDeck.....................................40
InstallingtheMowerDeck.......................................41
ReplacingtheGrassDeector..................................41
MowerBeltMaintenance............................................43
InspectingtheBelts................................................43
ReplacingtheMower-DeckBelt...............................43
Cleaning...................................................................44
CleaningundertheFrontoftheMachine...................44
WashingtheUndersideoftheMower........................44
Storage........................................................................45
CleaningandStorage..............................................45
Troubleshooting...........................................................46
Schematics...................................................................48
3

Safety
ThismachinehasbeendesignedinaccordancewithANSI
B71.1-2012.
GeneralSafety
Thisproductiscapableofamputatinghandsandfeetand
ofthrowingobjects.Alwaysfollowallsafetyinstructionsto
avoidseriouspersonalinjury.
Usingthisproductforpurposesotherthanitsintendeduse
couldprovedangeroustoyouandbystanders.
•ReadandunderstandthecontentsofthisOperator’sManual
beforeyoustarttheengine.Ensurethateveryoneusing
thisproductknowshowtouseitandunderstandsthe
warnings.
•Donotputyourhandsorfeetnearmovingcomponents
ofthemachine.
•Donotoperatethemachinewithoutallguardsandother
safetyprotectivedevicesinplaceandworkingonthe
machine.
•Keepclearofanydischargeopening.Keepbystandersa
safedistanceawayfromthemachine.
•Keepchildrenoutoftheoperatingarea.Neverallow
childrentooperatethemachine.
•Stopthemachineandshutofftheenginebeforeservicing,
fueling,oruncloggingthemachine.
Improperlyusingormaintainingthismachinecanresult
ininjury.Toreducethepotentialforinjury,complywith
thesesafetyinstructionsandalwayspayattentiontothe
safety-alertsymbol,whichmeansCaution,Warning,or
Danger—personalsafetyinstruction.Failuretocomplywith
theseinstructionsmayresultinpersonalinjuryordeath.
Youcanndadditionalitemsofsafetyinformationintheir
respectivesectionsthroughoutthismanual.
4

SlopeIndicator
G01 1841
g011841
Figure4
Thispagemaybecopiedforpersonaluse.
1.Themaximumslopeyoucansafelyoperatethemachineonis15degrees.Usetheslopecharttodeterminethedegreeofslope
ofhillsbeforeoperating.Donotoperatethismachineonaslopegreaterthan15degrees.Foldalongtheappropriateline
tomatchtherecommendedslope.
2.Alignthisedgewithaverticalsurface,atree,building,fencepole,etc.
3.Exampleofhowtocompareslopewithfoldededge
5

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotential
danger.Replaceanydecalthatisdamagedormissing.
decal93-7009
93-7009
1.Warning—donotoperatethemowerwiththedeectorup
orremoved;keepthedeectorinplace.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.
decal99-3943
99-3943
1.Engine
decal106-8717
106-8717
1.Readtheinstructionsbeforeservicingorperforming
maintenance.
2.Checktirepressureevery25operatinghours.
3.Greaseevery25operatinghours.
4.Engine
decal112-9840
112-9840
1.ReadtheOperator's
Manual.
3.Removetheignitionkey
andreadtheinstructions
beforeservicingor
performingmaintenance.
2.Height-of-cut
decaloemmarkt
Manufacturer'sMark
1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.
6

decal119-8870
119-8870
1.Height-of-cut
decal121-2989b
121-2989
1.Bypassleverpositionfor
pushingthemachine
2.Bypassleverpositionfor
operatingthemachine
decalbatterysymbols
BatterySymbols
Someorallofthesesymbolsareonyourbattery.
1.Explosionhazard6.Keepbystandersasafe
distanceawayfromthe
battery.
2.Nore,opename,or
smoking
7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.
3.Causticliquid/chemical
burnhazard
8.Batteryacidcancause
blindnessorsevereburns.
4.Weareyeprotection.9.Flusheyesimmediately
withwaterandgetmedical
helpfast.
5.ReadtheOperator's
Manual.
10.Containslead;donot
discard.
decal131-1097
131-1097
1.Oildrain
7

decal131-3620
131-3620
1.Pedalposition—forward3.Pedalposition—reverse
2.Pedalposition—neutral
decal131-3621b
131-3621
1.Crushing/dismembermenthazardofbystanders—keep
bystandersawayfromthemachine;donotstartthe
machinewithbystandersnearby.
decal131-3664
131-3664
1.Bladespinning3.ReadtheOperator's
Manual.
2.Reverse
decal131-3954
131-3954
1.On2.Off
decal132-6863
132-6863
decal132-0872
132-0872
1.Thrownobject
hazard—keepbystanders
awayfromthemachine.
3.Severinghazardofhand
orfoot—keepawayfrom
movingparts.
2.Thrownobjecthazard,
raisedbafe—donot
operatethemachinewith
anopendeck;usea
baggerorabafe.
4.Entanglement
hazard—keepaway
frommovingparts;keep
allguardsandshieldsin
place.
8

decal132-0870
132-0870
1.Warning—readtheOperator'sManual.3.Bodilyharmhazard—noriders;look
behindyouwhenmowinginreverse.
5.Ramptippinghazard—whenloading
ontoatrailer,donotusedualramps;
onlyuseasinglerampwideenough
forthemachineandthathasanincline
lessthan15degrees;backupthe
ramp(inreverse)anddriveforwardoff
theramp.
2.Cuttinghazardofhand,mowerblade;
pinchinghazardofhand,belt—keep
handsandfeetawayfrommoving
parts;keepallguardsandshieldsin
place.
4.Thrownobjecthazard—keep
bystandersawayfromthemachine;
removedebrisfromtheareabefore
mowing;keepthedeectorshield
down.
6.Tippinghazardonslopes—donot
makesharp,quickturns;donotuse
slopesgreaterthan15degrees.
9

decal121-0773
121-0773
1.Fast4.Choke
2.Continuous-variablesetting5.Powertakeoff(PTO),blade-controlswitch
3.Slow
10

ProductOverview
g027935
1
2
4
5
67
8
9
11
12
10
3
g027935
Figure5
1.Traction-controlpedal7.Engine
2.Height-of-cutlever8.Fuel-tankcap
3.SmartPark™switch9.Reardrivewheel
4.Steeringwheel10.KeyChoice®control
5.Controlpanel11.Mowerdeck
6.Operatorseat12.Frontcasterwheels
Controls
BecomefamiliarwithallcontrolsinFigure6andFigure7
beforeyoustarttheengineandoperatethemachine.
g028250
Figure6
ControlPanel
1.SmartPark™Switch5.Blade-controlswitch
(powertakeoff)
2.Throttle6.Parkingbrake—On
3.Chokecontrol7.Parkingbrakeindicator
light
4.Ignitionswitch8.Parkingbrake—Off
g028251
Figure7
1.Operating–in–Reverse
warninglight
3.Fuel-presencewindow
2.KeyChoicekey(bluein
color)
IgnitionSwitch
Usethisswitchtostartthemowerengine.Ithas3positions:
START,RUN,andOFF.
ChokeControl
Usethechoketostartacoldengine.Pullthechokeknob
uptoengageit.Pushthechokeknobdowntodisengage
it(Figure6).
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFASTposition
(Figure6).
Blade-ControlSwitch(PowerTakeoff)
Theblade-controlswitch(PTO)engagesanddisengages
powertothemowerblades(Figure6).
Fuel-PresenceWindow
Thefuelwindow,locatedontheleftsideofthemachine,can
beusedtoverifythepresenceoffuelinthetank(Figure7).
Height-of-CutLever
Usetheheight-of-cutlevertolowerandraisethedeckfrom
theseatedposition.Movingtheleverup(towardyou)raises
thedeckfromthegroundandmovingtheleverdown(away
fromyou)lowersthedecktowardtheground.Adjustthe
height-of-cutonlywhilethemachineisnotmoving(Figure5).
11

KeyChoice®Switch
Thisswitchallowsyoutomowinreversewhenitisactivated.
Toactivateit,turntheswitchtotheONpositionandrelease
itafterthePTOisengaged.Todeactivateit,disengagethe
powertakeoff(PTO)(Figure7).
Operating-in-ReverseWarningLight
TheOperating-in-Reversewarninglightilluminates
wheneveryouusetheKeyChoicekeytodeactivatethe
operating-in-reverseinterlock.Itisareminderthatthe
interlocksystemisdeactivated.Thelightgoesoutwhenever
youdisengagethePTOorshutofftheengine.Whenthelight
ison,lookbehindyouanduseextracautionwhenbackingup.
SmartPark™Switch
Theparkingbrakeisactivatedelectronically.
Engagetheparkingbrakeby1ofthefollowingactions:
•PressingtheSmartPark™switchtotheONposition
(Figure6).
•Theparkingbrakeengagesautomaticallywhenyouleave
theseatandthetractioncontrolpedalisintheNEUTRAL
position.
•Theparkingbrakeautomaticallyengages5to6seconds
aftertheignitionswitchisturnedtotheOFFposition(if
itisnotalreadyengaged).
Todisengagetheparkingbrake,presstheSmartParkswitch
totheOFFpositionwiththekeyintheRUNposition.
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesis
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww.Toro.comforalistofallapproved
attachmentsandaccessories.
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
BeforeOperation
BeforeOperationSafety
GeneralSafety
•Neverallowchildrenoruntrainedpeopletooperateor
servicethemachine.Localregulationsmayrestrictthe
ageoftheoperator.Theownerisresponsiblefortraining
alloperatorsandmechanics.
•Becomefamiliarwiththesafeoperationoftheequipment,
operatorcontrols,andsafetysigns.
•Knowhowtostopthemachineandshutofftheengine
quickly.
•Checkthatoperator-presencecontrols,safetyswitches,
andshieldsareattachedandfunctioningproperly.Donot
operatethemachineunlesstheyarefunctioningproperly.
•Beforemowing,alwaysinspectthemachinetoensurethat
theblades,bladebolts,andcuttingassembliesareingood
workingcondition.Replacewornordamagedbladesand
boltsinsetstopreservebalance.
•Inspecttheareawhereyouwillusethemachineand
removeallobjectsthatthemachinecouldthrow .
•Evaluatetheterraintodeterminetheappropriate
equipmentandanyattachmentsoraccessoriesrequiredto
operatethemachineproperlyandsafely.
FuelSafety
•Toavoidpersonalinjuryorpropertydamage,useextreme
careinhandlingfuel.Fuelvaporsareammableand
explosive.
•Extinguishallcigarettes,cigars,pipes,andothersources
ofignition.
•Useonlyanapprovedfuelcontainer.
•Donotremovethefuelcaporaddfueltothefueltank
whiletheengineisrunningorwhilehot.
•Donotrefuelthemachineindoors.
•Donotstorethemachineorfuelcontainerwherethere
isanopename,spark,orpilotlight,suchasonawater
heateroronotherappliances.
•Donotllcontainersinsideavehicleoronatruckor
trailerbedwithaplasticliner.Alwaysplacecontainerson
theground,awayfromyourvehiclebeforelling.
•Removetheequipmentfromthetruckortrailerand
refuelitwhileitisontheground.Ifthisisnotpossible,
thenrefuelfromaportablecontainerratherthana
fuel-dispensernozzle.
12

•Donotoperatethemachinewithouttheentireexhaust
systeminplaceandinproperworkingcondition.
•Keepthefuel-dispensernozzleincontactwiththerimof
thefueltankorcontaineropeningatalltimesuntilfueling
iscomplete.Donotuseanozzlelock-opendevice.
•Ifyouspillfuelonyourclothing,changeyourclothing
immediately.Wipeupanyfuelthatspills.
•Neveroverllthefueltank.Replacethefuelcapand
tightenitsecurely.
•Storefuelinanapprovedcontainerandkeepitoutofthe
reachofchildren.Neverbuymorethana30-daysupply
offuel.
•Donotllthefueltankcompletelyfull.Addfueltothe
fueltankuntilthelevelis6to13mm(1/4to1/2inch)
belowthebottomofthellerneck.Thisemptyspacein
thetankallowsfueltoexpand.
–Avoidprolongedbreathingofvapors.
–Keepyourfaceawayfromthenozzleandfueltank
opening.
–Avoidcontactwithskin;washoffspillswithsoapand
water.
RecommendedFuel
•Forbestresults,useonlyclean,fresh(lessthan30days
old),unleadedgasolinewithanoctaneratingof87or
higher((R+M)/2ratingmethod).
•Ethanol:Gasolinewithupto10%ethanol(gasohol)
or15%MTBE(methyltertiarybutylether)byvolume
isacceptable.EthanolandMTBEarenotthesame.
Gasolinewith15%ethanol(E15)byvolumeisnot
approvedforuse.Neverusegasolinethatcontains
morethan10%ethanolbyvolume,suchasE15
(contains15%ethanol),E20(contains20%ethanol),or
E85(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/orengine
damage.Usingunapprovedgasolinewillnotbecovered
bytheproductwarranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorfuelcontainers
overthewinterunlessyouuseafuelstabilizer.
•Donotaddoiltogasoline.
UsingStabilizer/Conditioner
Useafuelstabilizer/conditionerinthemachinetoprovide
thefollowingbenets:
•Keepsfuelfreshduringstorageof90daysorless(drain
thefueltankwhenstoringthemachineformorethan
90days)
•Cleanstheenginewhileitruns
•Eliminatesgum-likevarnishbuildupinthefuelsystem,
whichcauseshardstarting
Important:Donotusefueladditivescontaining
methanolorethanol.
Addthecorrectamountoffuelstabilizer/conditioner
tothefuel.
Note:Afuelstabilizer/conditionerismosteffective
whenmixedwithfreshfuel.Tominimizethechanceof
varnishdepositsinthefuelsystem,usefuelstabilizerat
alltimes.
FillingtheFuelTank
1.Parkthemachineonlevelground.
2.Shutofftheengineandengagetheparkingbrake.
3.Cleanaroundthefuel-tankcap.
4.Fillthefueltanktothebottomofthellerneck(Figure
8).
Note:Donotllthefueltankcompletelyfull.The
emptyspaceinthetankallowsthefueltoexpand.
g027243
AB
E
D
C
g027243
Figure8
CheckingtheEngine-OilLevel
Beforeyoustarttheengineandusethemachine,check
theoillevelintheenginecrankcase;refertoCheckingthe
Engine-OilLevel(page28).
BreakinginaNewMachine
Newenginestaketimetodevelopfullpower.Mowerdecks
anddrivesystemshavehigherfrictionwhennew,placing
additionalloadontheengine.Allow40to50hoursof
13

break-intimefornewmachinestodevelopfullpowerand
bestperformance.
ThinkSafetyFirst
Pleasereadallsafetyinstructionsandsymbolsinthesafety
section.Knowingthisinformationcouldhelpyouor
bystandersavoidinjury.
DANGER
Operatingthemachineonwetgrassorsteepslopes
cancauseslidingandlossofcontrol.
•Donotoperateonslopesgreaterthan15degrees.
•Reducespeedanduseextremecautionon
slopes.
•Donotoperatethemachinenearwater.
DANGER
Wheelsdroppingoveredgescancauserollovers,
whichmayresultinseriousinjury,death,or
drowning.
Donotoperatethemachineneardrop-offs.
g027830
g027830
Figure9
1.SafeZone—usethe
machinehereonslopes
lessthan15degreesor
atareas.
3.Water
2.DangerZone—usea
walk-behindmowerand/or
ahandtrimmeronslopes
greaterthan15degrees,
neardrop-offsandwater.
CAUTION
Thismachineproducessoundlevelsinexcessof
85dBAattheoperator’searandcancausehearing
lossthroughextendedperiodsofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
Useprotectiveequipmentforyoureyes,ears,hands,feet,
andhead.
G009027
12
g009027
Figure10
1.Weareyeprotection.2.Wearhearingprotection.
UsingtheSafety-Interlock
System
WARNING
Ifsafety-interlockswitchesaredisconnectedor
damaged,themachinecouldoperateunexpectedly
causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
daily,andreplaceanydamagedswitchesbefore
operatingthemachine.
UnderstandingtheSafety-Interlock
System
Thesafety-interlocksystemisdesignedforthefollowing:
•Topreventtheenginefromstartingunlessthetraction
pedalisintheNEUTRALposition.
•Toautomaticallyensurethattheparkingbrakeisengaged
andthePTOisoffwhenstartingthemachine.
•Toshutofftheenginewheneverthetractionpedalisnot
intheNEUTRALpositionandyourisefromtheseat.
•Toautomaticallyengagetheparkingbrakeanddisengage
thePTO,whenyouriseoutoftheseatwiththetraction
pedalintheNEUTRALposition.
•Toshutofftheenginewhenevertheparkingbrakeisnot
engagedandyourisefromtheseat.
14

TestingtheSafety-InterlockSystem
1.Sitintheseatwiththeengineoffandensurethatthe
PTOswitchisintheOFFposition.
2.TurntheignitionkeytotheSTARTposition;thestarter
shouldcrank.Donotstartorshutofftheengineprior
tostep3.
3.TurnthekeytotheONpositionandpushtheSmart
ParkswitchtotheOFFposition.Thebrakeshould
disengageandthebrakelightshouldturnoff.
4.Withthebrakedisengagedandtractionpedalinthe
NEUTRALposition,turntheignitionswitchtothe
STARTposition.Thebrakeshouldautomatically
engage,theengineshouldcrank,andthebrakelight
shouldturnon.
5.WiththeengineoffandthekeyintheONposition,
engagethePTObypullinguptheblade-controlswitch;
youshouldheartheclutchengage.
6.Ensurethatthetractionpedalisinneutralandturn
theignitionswitchtotheSTARTposition.ThePTO
shoulddisengageandtheengineshouldcrankandstart
withoutthebladesmoving.
7.Withtheenginerunning,risefromtheseat.Theengine
shouldremainrunningandthebrakelightshouldbe
on.
8.Returntotheseatanddisengagetheparkingbrakeby
pushingtheSmartParkswitchtotheOFFposition.
Theengineshouldcontinuetorun.
9.Risefromtheseatagain.Thebrakeshould
automaticallyengageandtheengineshouldcontinue
torun.
10.Returntotheseatandengagethebladesbypullingup
theblade-controlswitch.
11.Risefromtheseat.Thebladesshoulddisengageand
theengineshouldcontinuetorun.
12.Returntotheseatandpulluptheblade-controlswitch.
Thebladesshouldengage.Disengagethebladesby
pushingdowntheblade-controlswitch.
13.Pulluptheblade-controlswitchtoengagetheblades.
MovethetractionpedaltotheREVERSEposition.The
bladesshoulddisengage.Movethetractionpedalto
theNEUTRALposition.
14.Pulluptheblade-controlswitchtoengagetheblades.
TurntheKeyChoiceswitchtotheONposition
andreleaseit.Theoperating-in-reverselightshould
illuminate.
15.MovethetractionpedaltotheREVERSEposition.
Thebladesshouldremainengaged.Pushthe
blade-controlswitchintodisengagetheblades.The
operating-in-reverselightshouldturnoff.Movethe
tractionpedaltotheNEUTRALposition.
16.Ifnotengaged,pushtheSmarkParkswitchtotheON
positionandlightlytapthetractionpedalintheeither
theFORWARDorREVERSEposition.Thebrakeshould
disengageandthebrakelightshouldturnoff.
Note:Tapthepedal,donotfullyengagethepedalas
thatcausesthebrakesystemtobindandnotrelease.
17.Withthebrakereleased,engagethetractionpedal
slightlyandrisefromtheseat.Theengineshouldshut
off.
18.Returntotheseatandturntheignitionkeytothe
OFFposition.Afterseveralseconds,thebrakesystem
shouldengage.
Note:WiththekeyintheOFFposition,thebrakelight
doesnotilluminate.
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable(Figure11).
g188217
Figure11
15

PositioningtheSteeringWheel
Thesteeringwheelhas3positionsforoperationand1full-up
position.Usethefull-uppositionforsteppingonandoff
themachineandgettingoutoftheseat.Whenoperatingthe
machine,positionthesteeringwheelwhereyouhavethebest
controlofthemachineandaremostcomfortable.
1.Pressyourfootontothesteering-columnreleaselever.
2.Positionthesteeringwheeltothedesiredposition
(Figure12).
g027751
B
A
g027751
Figure12
DuringOperation
DuringOperationSafety
GeneralSafety
•Theowner/operatorcanpreventandisresponsiblefor
accidentsthatmaycausepersonalinjuryorproperty
damage.
•Wearappropriateclothing,includingeyeprotection;
slip-resistant,substantialfootwear;andhearing
protection.Tiebacklonghairanddonotwearjewelry.
•Donotoperatethemachinewhileill,tired,orunderthe
inuenceofalcoholordrugs.
•Nevercarrypassengersonthemachineandkeep
bystandersandpetsawayfromthemachineduring
operation.
•Operatethemachineonlyingoodvisibilitytoavoidholes
orhiddenhazards.
•Avoidmowingonwetgrass.Reducedtractioncould
causethemachinetoslide.
•Ensurethatalldrivesareinneutral,theparkingbrake
isengaged,andyouareintheoperatingpositionbefore
youstarttheengine.
•Keepyourhandsandfeetawayfromthecuttingunits.
Keepclearofthedischargeopeningatalltimes.
•Lookbehindanddownbeforebackinguptobesureof
aclearpath.
•Usecarewhenapproachingblindcorners,shrubs,trees,
orotherobjectsthatmayobscureyourvision.
•Donotmowneardrop-offs,ditches,orembankments.
Themachinecouldsuddenlyrolloverifawheelgoes
overtheedgeoriftheedgegivesway.
•Stopthebladeswheneveryouarenotmowing.
•Stopthemachineandinspectthebladesafterstrikingan
objectorifthereisanabnormalvibrationinthemachine.
Makeallnecessaryrepairsbeforeresumingoperation.
•Slowdownandusecautionwhenmakingturnsand
crossingroadsandsidewalkswiththemachine.Always
yieldtheright-of-way.
•Disengagethedrivetothecuttingunitandshutoffthe
enginebeforeadjustingtheheightofcut(unlessyoucan
adjustitfromtheoperatingposition).
•Neverrunanengineinanareawhereexhaustgasesare
enclosed.
•Neverleavearunningmachineunattended.
•Beforeleavingtheoperatingposition(includingtoempty
thecatchersortounclogthechute),dothefollowing:
–Stopthemachineonlevelground.
–Disengagethepowertake-offandlowerthe
attachments.
–Engagetheparkingbrake.
–Shutofftheengineandremovethekey.
–Waitforallmovingpartstostop.
•Donotoperatethemachinewhenthereistheriskof
lightning.
•Donotusethemachineasatowingvehicle.
•Donotchangethegovernorspeedoroverspeedthe
engine.
•UseaccessoriesandattachmentsapprovedbyToroonly.
SlopeSafety
•Slowdownthemachineanduseextracareonhillsides.
Travelupanddownonhillsides.Turfconditionscan
affectthestabilityofthemachine.
•Avoidturningthemachineonslopes.Ifyoumustturnthe
machine,turnitslowlyandgraduallydownhill,ifpossible.
•Donotturnthemachinesharply.Usecarewhenreversing
themachine.
•Useextracarewhileoperatingthemachinewith
attachments;theycanaffectthestabilityofthemachine.
16

OperatingtheSmartPark™
ParkingBrake
Theparkingbrakeisactivatedelectronically.
Engagetheparkingbrakeby1ofthefollowingactions:
•PressingtheSmartPark™switchtotheONposition
(Figure6).
•Theparkingbrakeengagesautomaticallywhenthe
operatorleavestheseatandthetractioncontrolpedalis
intheNEUTRALposition.
•Theparkingbrakeautomaticallyengages5to6seconds
aftertheignitionswitchisturnedtotheOFFposition(if
itisnotalreadyengaged).
Disengagetheparkingbrakeby1ofthefollowingactions:
•Tapthetraction-controlpedalforwardorreverse.
•PressingthebrakeswitchtotheOFFposition(Figure6).
OperatingtheMower
Blade-ControlSwitch(PTO)
Theblade-controlswitch(PTO)startsandstopsthemower
bladesandanypoweredattachments.
EngagingtheBlade-ControlSwitch
(PTO)
G008945
g008945
Figure13
Note:AlwaysengagethebladeswiththethrottleintheFAST
position(Figure14).
g187516
Figure14
DisengagingtheBlade-ControlSwitch
(PTO)
1
g027538
g027538
Figure15
OperatingtheThrottle
YoucanmovethethrottlecontrolbetweentheFASTand
SLOWpositions(Figure16).
AlwaysusetheFASTpositionwhenturningonthemower
deckwiththeblade-controlswitch(PTO).
g187517
Figure16
17

OperatingtheChoke
Usethechoketostartacoldengine.
1.Iftheengineiscold,usethechoketostarttheengine.
2.Pullupthechokeknobtoengagethechokebefore
usingtheignitionswitch(Figure17).
Note:Ensurethatyoufullyengagethechoke.You
mayneedtoholdtheknobupwhenyouusethe
ignitionswitch.
3.Pushdownthechoketodisengagethechokeafterthe
enginehasstarted(Figure17).
G008959
1
2
g008959
Figure17
1.Onposition2.Offposition
OperatingtheIgnitionSwitch
1.TurntheignitionkeytotheSTARTposition(Figure18).
Note:Whentheenginesstarts,releasethekey.
Important:Donotengagestarterformorethan5
secondsatatime.Iftheenginefailstostartallow
a15-secondcool-downperiodbetweenattempts.
Failuretofollowtheseinstructionscanburnout
thestartermotor.
Note:Youmayneedmultipleattemptstostartthe
enginewhenyoustartitthersttimeafterthefuel
systemhasbeenwithoutfuelcompletely.
START
RUN
ST OP
G008947
g008947
Figure18
2.Turntheignitionkeytoshutofftheengine.
StartingandShuttingOffthe
Engine
StartingtheEngine
Important:Donotengagethestarterformorethan
5secondsatatime.Engagingthestartermotorfor
morethan5secondscandamagethestartermotor.If
theenginefailstostart,wait10secondsbeforeoperating
theenginestarteragain.
Sitdownontheseatandensurethattheparkingbrakeis
engaged(Figure19).
g027831
B
CD
E
A
F
g027831
Figure19
18

ShuttingOfftheEngine
1.Disengagethebladesbypushingtheblade-control
switchtotheOFFposition(Figure15).
2.MovethethrottlelevertotheFASTposition.
3.TurntheignitionkeytotheOFFpositionandremove
thekey.
DrivingtheMachine
Thismachinehasthecharacteristicsofbothagardentractor
andazero-turnmachine.Likeagardentractor,themachine
hasafootpedalthatcontrolstheforwardandreversemotion
alongwiththespeed,andithasasteeringwheelthatcontrols
thedirectionandtheturningradius.Likeazero-turnmachine,
thereardrivewheelsoperateindependentlyofeachother,
enablingyoutomakesharpturnsandtoturnindifferent
directionsquickly.Thesecharacteristicsvastlyimprovethe
maneuverabilityofthemachine,buttheymayalsorequire
youtopracticedrivingifyouareunfamiliarwiththistypeof
machine.
WARNING
Themachinecanspinveryrapidly.Youmaylose
controlofthemachineandcausepersonalinjuryor
damagetothemachine.
•Usecautionwhenmakingturns.
•Slowthemachinedownbeforemakingsharp
turns.
Thethrottlecontrolregulatestheenginespeedasmeasured
inrpm(revolutionsperminute).Placingthethrottlecontrol
intheFASTpositioncanbebestforperformance.Formost
applications,operatingintheFULL-THROTTLEpositionis
desirable.
DrivingForwardorBackward
1.MovethethrottletotheFASTposition.
2.Releasetheparkingbrake.
3.Placeyourfootontothetraction-controlpedaland
slowlypressthetopofthepedaltogoforward,or
pressonthebottomofthepedaltomovebackward
(Figure20).
Note:Thefartheryoumovethepedalineither
direction,thefasterthemachinemovesinthat
direction.
g027750
Figure20
1.Forward3.Backward
2.Traction-controlpedal
4.Toslowdown,releasethepressureonthe
traction-controlpedal.
StoppingtheMachine
Toshutoffthemachine,releasethetraction-controlpedal,
disengagetheblade-controlswitch,ensurethatthethrottle
isintheFASTposition,engagetheparkingbrake,andturn
theignitionkeytooff.
Note:Remembertoremovethekeyfromtheignitionswitch.
WARNING
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethemowerwhileitis
unattended.
AlwaysremoveboththeignitionandKeyChoice
keysandengagetheparkingbrakewhenleavingthe
machineunattended,evenifjustforafewminutes.
19

MowinginReverse
Themachinehasaninterlockfeaturethatpreventsthemower
deckfrommowingwhilethemachineistravelinginreverse.
IfyoushiftintoreversewiththePTOengaged,thePTO
stops.Ifyouneedtomowwhileinreversegear,youcan
temporarilydeactivatethisinterlock.
Note:Donotmowwhilebackingupunlessitisnecessary.
DANGER
Achildorbystandercouldbebackedoverbya
ridingmowerwithbladesengagedandcause
seriouspersonalinjuryordeath.
•Donotmowinreverseunlessabsolutely
necessary.
•Alwayslookbackwardanddownbeforebacking
up.
•UsetheKeyChoiceswitchonlyifyouarecertain
nochildrenorotherbystanderswillappearin
themowingarea.
•AlwaysremoveboththeignitionandKeyChoice
keysandputtheminasafeplaceoutofthe
reachofchildrenorunauthorizeduserswhen
leavingthemachineunattended.
Ifyouarecertainthatyoucansafelymoworoperatean
attachmentinreverse,completethefollowingprocedure:
1.InserttheKeyChoicekeyintotheKeyChoiceswitch
(Figure7).
2.EngagethePTO.
3.TurntheKeyChoicekeyclockwiseuntilitstopsand
releaseit.
Note:Aredlightilluminatingontheconsoleindicates
thattheinterlockhasbeendeactivated.
4.Performthemowing.
5.Whennishedmowing,removetheKeyChoicekey
(Figure7).
Note:Onceyoudeactivatetheinterlock,itstaysin
thismode—withyourmowerbladeorPTOpowered
attachmentoperatingwheneveryoubackup—andthe
consolelightstaysonuntilyoueitherdisengagethe
PTOorshutofftheengine.
AdjustingtheHeightofCut
Note:Thetransportpositionisthehighestheight-of-cut
positionorcuttingheightat115mm(4-1/2inches)asshown
inFigure21.
Heightofcutiscontrolledbytheleverlocatedtotherightof
theoperatingposition(Figure21).
g028025
Figure21
20
