Introduction
Thismachineisaride-on,rotary-bladelawnmower
intendedtobeusedbyhomeownersinresidential
applications.Itisprimarilydesignedforcuttinggrass
onwell-maintainedlawns.Itisnotdesignedforcutting
brush,mowinggrassandothergrowthalongside
highways,orforagriculturaluses.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
YoumaycontactT orodirectlyatwww.T oro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorT oroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
g028111
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA.
AllRightsReserved

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafetyalertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
1.Safetyalertsymbol
Thismanualuses2otherwordstohighlight
information.Importantcallsattentiontospecial
mechanicalinformationandNoteemphasizesgeneral
informationworthyofspecialattention.
Contents
Safety.......................................................................4
SafeOperatingPractices....................................4
ToroRidingMowerSafety...................................6
SlopeIndicator...................................................7
SafetyandInstructionalDecals..........................8
ProductOverview...................................................13
Controls...........................................................14
Operation................................................................15
AddingFuel......................................................15
ThinkSafetyFirst..............................................17
TheSafetyInterlockSystem.............................17
UsingtheRolloverProtectionSystem
(ROPS).........................................................18
CheckingtheEngine-OilLevel..........................18
BreakinginaNewMachine..............................18
OperatingtheParkingBrake.............................19
OperatingtheThrottle.......................................19
OperatingtheChoke.........................................19
OperatingtheIgnitionSwitch............................19
StartingandStoppingtheEngine......................20
OperatingtheMowerBladeControlSwitch
(PTO)............................................................21
DrivingForwardorBackward............................22
StoppingtheMachine.......................................23
AdjustingtheHeight-of-Cut...............................23
AdjustingtheAnti-ScalpRollers........................24
PositioningtheSeat..........................................25
AdjustingtheMotionControlLevers..................25
PushingtheMachinebyHand..........................25
UsingtheSideDischarge.................................26
TransportingtheMachine.................................26
LoadingtheMachine........................................27
OperatingTips.................................................29
Maintenance...........................................................30
RecommendedMaintenanceSchedule(s)...........30
Pre-MaintenanceProcedures..............................31
RaisingtheSeat...............................................31
Lubrication..........................................................31
GreasingtheBearings......................................31
EngineMaintenance...........................................32
ServicingtheAirCleaner..................................32
ServicingtheEngineOil....................................33
ServicingtheSparkPlug...................................35
CleaningtheBlowerHousing............................36
FuelSystemMaintenance...................................37
ReplacingtheFuelFilter...................................37
ElectricalSystemMaintenance...........................38
ServicingtheBattery.........................................38
ServicingtheFuses..........................................39
DriveSystemMaintenance..................................40
CheckingtheTirePressure...............................40
HydraulicSystemMaintenance...........................41
CheckingtheHydraulicOilLevel......................41
ChangingtheHydraulicSystemFilterand
Oil.................................................................41
MowerDeckMaintenance....................................44
3

ServicingtheCuttingBlades.............................44
MowerDeckLeveling.......................................46
InspectingtheBelts..........................................48
ReplacingtheMowerBelt.................................48
RemovingtheMower........................................49
InstallingtheMowerDeck.................................50
ReplacingtheGrassDeector..........................51
Cleaning..............................................................52
WashingtheUndersideoftheMower................52
WasteDisposal.................................................53
Storage...................................................................53
CleaningandStorage.......................................53
Troubleshooting......................................................55
Schematics.............................................................57
Safety
Improperuseormaintenancebytheoperatororowner
canresultininjury.T oreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafetyalertsymbol,whichmeans
Caution,Warning,orDanger-"personalsafety
instruction."Failuretocomplywiththeinstructionmay
resultinpersonalinjuryordeath.
Thisproductiscapableofamputatinghandsand
feetandthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriousinjuryordeath.
Thisproductisdesignedforcuttingandrecycling
grassor,whenequippedwithagrassbagger,for
catchingcutgrass.Anyuseforpurposesotherthan
thesecouldprovedangeroustouserandbystanders.
SafeOperatingPractices
ThefollowinginstructionsareadaptedfromANSI
standardB71.4-2012.
Training
•ReadtheOperator'sManualandothertraining
material.Iftheoperator(s)ormechanic(s)can
notreadEnglishitistheowner'sresponsibilityto
explainthismaterialtothem.
•Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetysigns.
•Alloperatorsandmechanicsshouldbetrained.
Theownerisresponsiblefortrainingtheusers.
•Neverletchildrenoruntrainedpeopleoperateor
servicetheequipment.Localregulationsmay
restricttheageoftheoperator.
•Theowner/usercanpreventandisresponsible
foraccidentsorinjuriesoccurringtopeopleor
damagetoproperty.
Preparation
•Evaluatetheterraintodeterminewhataccessories
andattachmentsareneededtoproperlyand
safelyperformthejob.Onlyuseaccessoriesand
attachmentsapprovedbythemanufacturer.
•Wearappropriateclothingincludinghardhat,
safetyglassesandhearingprotection.Long
hair,looseclothingorjewelrymaygettangledin
movingparts.
•Inspecttheareawheretheequipmentistobe
usedandremoveallobjectssuchasrocks,toys
andwirewhichcanbethrownbythemachine.
•Checkthatoperator'spresencecontrols,safety
switchesandshieldsareattachedandfunctioning
4

properly.Donotoperateunlesstheyare
functioningproperly.
Operation
•Lightningcancausesevereinjuryordeath.If
lightningisseenorthunderisheardinthearea,do
notoperatethemachine;seekshelter.
•Neverrunanengineinanenclosedarea.
•Onlyoperateingoodlight,keepingawayfrom
holesandhiddenhazards.
•Besurealldrivesareinneutralandparkingbrake
isengagedbeforestartingengine.Onlystart
enginefromtheoperator'sposition.
•Slowdownanduseextracareonhillsides.Be
suretotravelsidetosideonhillsides.Turf
conditionscanaffectthemachine'sstability.Use
cautionwhileoperatingneardrop-offs.
•Slowdownandusecautionwhenmakingturns
andwhenchangingdirectionsonslopes.
•Neverraisedeckwiththebladesrunning.
•NeveroperatewiththePTOshield,orother
guardsnotsecurelyinplace.Besureallinterlocks
areattached,adjustedproperly,andfunctioning
properly.
•Neveroperatewiththedischargedeectorraised,
removedoraltered,unlessusingagrasscatcher.
•Donotchangetheenginegovernorsettingor
overspeedtheengine.
•Stoponlevelground,disengagedrives,engage
parkingbrake(ifprovided),shutoffenginebefore
leavingtheoperator'spositionforanyreason
includingemptyingthecatchersoruncloggingthe
chute.
•Stopequipmentandinspectbladesafterstriking
objectsorifanabnormalvibrationoccurs.Make
necessaryrepairsbeforeresumingoperations.
•Keephandsandfeetawayfromthecuttingunit.
•Lookbehindanddownbeforebackinguptobe
sureofaclearpath.
•Keeppetsandbystandersaway.
•Slowdownandusecautionwhenmakingturns
andcrossingroadsandsidewalks.Stopblades
ifnotmowing.
•Beawareofthemowerdischargedirectionand
donotpointitatanyone.
•Donotoperatethemowerundertheinuenceof
alcoholordrugs.
•Usecarewhenloadingorunloadingthemachine
intoorfromatrailerortruck.
•Usecarewhenapproachingblindcorners,shrubs,
trees,orotherobjectsthatmayobscurevision.
RolloverProtectionSystem
(ROPS)-UseandMaintenance
•DonotremovetheROPS.
•TheROPSisanintegralandeffectivesafety
device.KeeptheROPSonthemachineanduse
theseatbeltwhenoperatingthemachine.
•Becertainthattheseatbeltcanbereleased
quicklyintheeventofanemergency.
•Checktheareatobemowedwherethereare
slopes,dropoffsorwater.
•Checkcarefullyforoverheadclearances(i.e.
branches,doorways,electricalwires)before
drivingunderanyobjectsanddonotcontactthem.
•KeeptheROPSinsafeoperatingconditionby
periodicallythoroughlyinspectingfordamageand
keepingallmountingfastenerstight.
•ReplaceadamagedROPS.Donotrepairor
revise.
•AnyalterationstoaROPSmustbeapprovedby
themanufacturer.
Safehandlingoffuels
•Toavoidpersonalinjuryorpropertydamage,use
extremecareinhandlinggasoline.Gasolineis
extremelyammableandthevaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.
•Useonlyanapprovedfuelcontainer.
•Neverremovefuelcaporaddfuelwiththeengine
running.
•Allowenginetocoolbeforerefueling.
•Neverrefuelthemachineindoors.
•Neverstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlightsuchas
onawaterheateroronotherappliances.
•Neverllcontainersinsideavehicleoronatruck
ortrailerbedwithaplasticliner.Alwaysplace
containersonthegroundawayfromyourvehicle
beforelling.
•Removeequipmentfromthetruckortrailerand
refuelitontheground.Ifthisisnotpossible,then
refuelsuchequipmentwithaportablecontainer,
ratherthanfromafueldispensernozzle.
•Keepthenozzleincontactwiththerimofthefuel
tankorcontaineropeningatalltimesuntilfueling
iscomplete.Donotuseanozzlelockopendevice.
•Iffuelisspilledonclothing,changeclothing
immediately.
•Neveroverllfueltank.Replacefuelcapand
tightensecurely.
5

Maintenanceandstorage
•Disengagedrives,setparkingbrake,stopengine
andremovekeyordisconnectspark-plugwire.
Waitforallmovementtostopbeforeadjusting,
cleaningorrepairing.
•Cleangrassanddebrisfromcuttingunit,drives,
mufers,andenginetohelppreventres.Clean
upoilorfuelspillage.
•Letenginecoolbeforestoringanddonotstore
nearame.
•Shutofffuelwhilestoringortransporting.Donot
storefuelnearamesordrainindoors.
•Parkthemachineonlevelground.Settheparking
brake.Neverallowuntrainedpersonneltoservice
themachine.
•Usejackstandstosupportcomponentswhen
required.
•Carefullyreleasepressurefromcomponentswith
storedenergy.
•Disconnectthebatteryorremovespark-plug
wirebeforemakinganyrepairs.Disconnect
thenegativeterminalrstandthepositivelast.
Reconnectthepositiverstandnegativelast.
•Usecarewhencheckingblades.Wrapthe
blade(s)orwearthickly-paddedgloves,anduse
cautionwhenservicingthem.Onlyreplaceblades.
Neverstraightenorweldthem.
•Keephandsandfeetawayfrommovingparts.If
possible,donotmakeadjustmentswiththeengine
running.
•Keepallpartsingoodworkingconditionandall
hardwaretightened.Replaceallwornordamaged
decals.
Hauling
•Usecarewhenloadingorunloadingthemachine
intoatrailerortruck.
•Usefullwidthrampsforloadingmachineinto
trailerortruck.
•Tiethemachinedownsecurelyusingstraps,
chains,cable,orropes.Bothfrontandrearstraps
shouldbedirecteddownandoutwardfromthe
machine.
ToroRidingMowerSafety
Thefollowinglistcontainssafetyinformationspecic
toToroproductsorothersafetyinformationthatyou
mustknowthatmaynotbeincludedintheANSI
standards.
•UseonlyToroapprovedattachments.Warranty
maybevoidedifusedwithunapproved
attachments.
•Ifloadingthemachineontoatrailerortruck,use
asingle,full-widthramponly.Therampangle
shouldnotexceed15degrees.
TowingSafety
•Donotattachtowedequipmentexceptatthehitch
point.
•Followtheattachmentmanufacturer's
recommendationforweightlimitsfortowed
equipmentandtowingonslopes.Towedweight
mustnotexceedtheweightofthemachine,
operator,andballast.Usecounterweightsor
wheelweightsasdescribedintheattachment,or
inthepullingmachineOperator’sManual.
•Neverallowchildrenorothersinorontowed
equipment.
•Onslopes,theweightofthetowedequipmentmay
causelossoftraction,increasedriskofrollover,
andlossofcontrol.Reducethetowedweightand
slowdown.
•Stoppingdistanceincreaseswiththeweightofthe
towedload.Travelslowlyandallowextradistance
tostop.
•Makewideturnstokeeptheattachmentclearof
themachine.
6

SlopeIndicator
r:\g011841
Figure3
Thispagemaybecopiedforpersonaluse.
1.Themaximumslopeyoucansafelyoperatethemachineonis15degrees.Usetheslopecharttodeterminethedegreeofslope
ofhillsbeforeoperating.Donotoperatethismachineonaslopegreaterthan15degrees.Foldalongtheappropriateline
tomatchtherecommendedslope.
2.Alignthisedgewithaverticalsurface,atree,building,fencepole,etc.
3.Exampleofhowtocompareslopewithfoldededge.
7

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedorlost.
decal99-8936
99-8936
1.Machinespeed4.Neutral
2.Fast5.Reverse
3.Slow
decaloemmarkt
Manufacturer'sMark
1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.
decal114-1606
114-1606
1.Entanglementhazard,belt—keepallguardsinplace.
decal115-9625
115-9625
1.Parking
brake—disengaged
2.Parkingbrake—engaged
decal115-9632
115-9632
1.Powertake-off(PTO),
Bladecontrolswitchon
somemodels
5.Fast
2.Bladecontrolswitch—On6.Continuousvariable
setting
3.Bladecontrolswitch—Off7.Slow
4.Choke
8

decalbatterysymbols
BatterySymbols
Someorallofthesesymbolsareonyourbattery
1.Explosionhazard6.Keepbystandersasafe
distancefromthebattery.
2.Nore,opename,or
smoking.
7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries
3.Causticliquid/chemical
burnhazard
8.Batteryacidcancause
blindnessorsevereburns.
4.Weareyeprotection9.Flusheyesimmediately
withwaterandgetmedical
helpfast.
5.ReadtheOperator's
Manual.
10.Containslead;donot
discard.
decal117-1194
117-1194
1.Engine
decal130-0654
130-0654
1.Transport—lock3.Height-of-cut
2.Transport—unlock
decal130-0655
130-0655
1.Fueltank3.Half
2.Full4.Empty
9

decal130-0731
130-0731
1.Warning—thrownobject
hazard;keepthedeector
shieldinplace.
2.Cuttinghazardofhandor
foot,mowerblade—keep
awayfrommovingparts.
decal130-0765
130-0765
1.ReadtheOperator's
Manual.
3.Removethekeyfrom
theignitionandreadthe
Operator'sManualbefore
permorningmaintenance.
2.Height-of-cutselection
decal130-6922
130-6922
1.Bypassleverpositionfor
operatingthemachine.
2.Bypassleverpositionfor
pushingthemachine.
decal130-6927
130-6927
1.Warning—alwaysusetheROPSandweartheseatbelt
whenseatedintheoperator'sposition.
decal130-6928
130-6928
1.Thrownobject
hazard—keepbystanders
awayfromthemachine.
3.Cutting/dismembermentof
handorfoot—stayaway
frommovingparts.
2.Thrownobjecthazard,
mower—donotoperate
thewithoutdeector,
dischargecover,orgrass
collectionsysteminplace.
10

decal130-6996
130-6996
1.ReadtheOperator's
Manualforinformationon
maintenance.
4.Checkthehydraulicoil
every25hours
2.Checktheengineoilevery
8hours
5.Checkthecasterwheel
tirepressureevery25
hours
3.Checkthedrivewheeltire
pressureevery25hours
6.Lubricatethecasterwheel
every25hours
decal131-4036
131-4036
1.Themaximumdrawbar
pullis36kg(80lb).
2.ReadtheOperator's
Manual.
11

decal132-0871
132-0871
Note:Thismachinecomplieswiththeindustrystandardstabilitytestinthestaticlateralandlongitudinaltestswiththemaximum
recommendedslopeindicatedonthedecal.ReviewtheinstructionsforoperatingthemachineonslopesintheOperator’sManualas
wellastheconditionsinwhichyouwouldoperatethemachinetodeterminewhetheryoucanoperatethemachineinthoseconditions
onthatdayandatthatsite.Changesintheterraincanresultinachangeinslopeoperationforthemachine.Ifpossible,keepthe
cuttingunitsloweredtothegroundwhileoperatingthemachineonslopes.Raisingthecuttingunitswhileoperatingonslopescan
causethemachinetobecomeunstable.
1.Warning—readtheOperator’sManual;donotoperatethis
machineunlessyouaretrained;wearhearingprotection.
4.Ramphazard—whenloadingontoatrailer,donotusedual
ramps;onlyuseasingularrampwideenoughforthemachine
andthathasaninclinelessthan15°;backuptheramp(in
reverse)anddriveforwardofftheramp.
2.Cutting,dismembering,andentanglementhazard—keep
handsawayfrommovingparts;keepallguardsandshieldsin
place.
5.Bodilyharmhazard—donotcarrypassengers;lookbehind
youwhenmowinginreverse.
3.Thrownobjecthazard—keepbystandersaway.6.Tippinghazardonslopes—donotuseonslopesnearopen
water;donotuseonslopesgreaterthan15°.
12

ProductOverview
g028215
Figure4
1.Grassdeector4.Operatorseat7.Footrest10.Mower-deckliftpedal
2.Drivewheel5.Motioncontrollevers8.Frontcasterwheel11.Height-of-cuthandle
3.Rolloverprotectionsystem
(ROPS)
6.Parkingbrake9.Anti-scalproller
13

Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine(Figure5).
g017722
Figure5
1.Throttlecontrol4.Ignitionswitch
2.Choke5.Bladecontrolswitch(PTO)
3.Hourmeter
IgnitionSwitch
Theignitionswitchhasthreepositions:Start,Run
andOff.ThekeywillturntoStartandmovebackto
Runuponrelease.TurningthekeytotheOffposition
willstoptheengine;however,alwaysremovethekey
whenleavingthemachinetopreventtheenginefrom
accidentallystarting(Figure5).
ThrottleControl
ThethrottlecontrolisvariablebetweenFastand
Slow.Movingthrottleleverforwardwillincrease
enginespeedandmovingthrottlelevertotherearwill
decreaseenginespeed.Movingthethrottleforward
intothedetentisfullthrottle(Figure5).
Choke
Usethechoketostartacoldengine.Pullthechoke
knobuptoengageit.Pushdownonthechokeknob
todisengageit.
Blade-ControlSwitch(Power
Take-Off)
Thebladecontrolswitchengagesanddisengages
powertothemowerblades(Figure5).
HourMeter
Thehourmeterrecordsthenumberofhoursthe
bladeshaveoperated.Itoperateswhentheblade
controlswitch(PTO)isengaged.Usethesetimesfor
schedulingregularmaintenance(Figure5).
FuelGauge
Thefuelwindowlocatedbelowtheoperatorposition
canbeusedtoverifythelevelofgasolineinthetank
(Figure6).
MotionControlLevers
Themotioncontrolleversarespeedsensitivecontrols
ofindependentwheelmotors.Movingaleverforward
orbackwardturnsthewheelonthesamesideforward
orinreverse;wheelspeedisproportionaltothe
amounttheleverismoved.Movethecontrollevers
outwardfromthecentertotheneutrallockposition
andexitthemachine(Figure4).Alwayspositionthe
motioncontrolleversintotheneutrallockposition
whenyoustopthemachineorleaveitunattended.
ParkingBrakeLever
Theparkingbrakeleverislocatedonleftsideof
theconsole(Figure4).Thebrakeleverengagesa
parkingbrakeonthedrivewheels.Pulltheleverup
andrearwardtoengagethebrake.Pushthelever
forwardanddowntodisengagethebrake.
FootPedalDeckLiftSystem
Thefootpedaldeckliftsystemallowstheoperator
tolowerandraisethedeckfromtheseatedposition.
Theoperatorcanusethefootpedaltoliftthedeck
brieytoavoidobstaclesorlockthedeckinthe
highestheight-of-cutortransportposition(Figure4).
Height-of-CutLever
Theheight-of-cutleverworkswiththefootpedalto
lockthedeckinaspeciccuttingheight.Onlyadjust
theheightofcutwhilemachineisnotmoving(Figure
4).
Attachments/Accessories
AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.T oro.comforalistofallapprovedattachments
andaccessories.
14

Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
AddingFuel
•Forbestresults,useonlyclean,fresh(lessthan
30daysold),unleadedgasolinewithanoctane
ratingof87orhigher((R+M)/2ratingmethod).
•Ethanol:Gasolinewithupto10%ethanol
(gasohol)or15%MTBE(methyltertiarybutyl
ether)byvolumeisacceptable.Ethanoland
MTBEarenotthesame.Gasolinewith15%
ethanol(E15)byvolumeisnotapprovedforuse.
Neverusegasolinethatcontainsmorethan
10%ethanolbyvolume,suchasE15(contains
15%ethanol),E20(contains20%ethanol),orE85
(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/or
enginedamagewhichmaynotbecoveredunder
warranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorfuel
containersoverthewinterunlessafuelstabilizer
isused.
•Donotaddoiltogasoline.
DANGER
Incertainconditions,gasolineisextremely
ammableandhighlyexplosive.Areor
explosionfromgasolinecanburnyouand
othersandcandamageproperty.
•Fillthefueltankoutdoors,inanopenarea,
whentheengineiscold.Wipeupany
gasolinethatspills.
•Neverllthefueltankinsideanenclosed
trailer.
•Donotllthefueltankcompletelyfull.Add
gasolinetothefueltankuntilthelevelis6
to13mm(1/4to1/2inch)belowthebottom
ofthellerneck.Thisemptyspaceinthe
tankallowsgasolinetoexpand.
•Neversmokewhenhandlinggasoline,and
stayawayfromanopenameorwhere
gasolinefumesmaybeignitedbyaspark.
•Storegasolineinanapprovedcontainer
andkeepitoutofthereachofchildren.
Neverbuymorethana30-daysupplyof
gasoline.
•Donotoperatewithoutentireexhaust
systeminplaceandinproperworking
condition.
DANGER
Incertainconditionsduringfueling,static
electricitycanbereleasedcausingaspark
whichcanignitethegasolinevapors.Are
orexplosionfromgasolinecanburnyouand
othersandcandamageproperty.
•Alwaysplacegasolinecontainersonthe
groundawayfromyourvehiclebefore
lling.
•Donotllgasolinecontainersinsidea
vehicleoronatruckortrailerbedbecause
interiorcarpetsorplastictruckbedliners
mayinsulatethecontainerandslowthe
lossofanystaticcharge.
•Whenpractical,removegas-powered
equipmentfromthetruckortrailerand
refueltheequipmentwithitswheelsonthe
ground.
•Ifthisisnotpossible,thenrefuelsuch
equipmentonatruckortrailerfroma
portablecontainer,ratherthanfroma
gasolinedispensernozzle.
•Ifagasolinedispensernozzlemustbe
used,keepthenozzleincontactwiththe
rimofthefueltankorcontaineropeningat
alltimesuntilfuelingiscomplete.
WARNING
Gasolineisharmfulorfatalifswallowed.
Long-termexposuretovaporscancause
seriousinjuryandillness.
•Avoidprolongedbreathingofvapors.
•Keepfaceawayfromnozzleandgastank
orconditioneropening.
•Keepgasawayfromeyesandskin.
UsingStabilizer/Conditioner
Useafuelstabilizer/conditionerinthemachineto
providethefollowingbenets:
•Fuelstabilizer/conditionerkeepsgasolinefresh
duringstorageof90daysorless.Whenstoringthe
machineforlongerperiods,drainthefuelsystem.
•Itcleanstheenginewhileitruns
•Iteliminatesgum-likevarnishbuildupinthefuel
system,whichcauseshardstarting
Important:Donotusefueladditivescontaining
methanolorethanol.
15

Addthecorrectamountofgasstabilizer/conditioner
tothegas.
Note:Afuelstabilizer/conditionerismosteffective
whenmixedwithfreshgasoline.Tominimizethe
chanceofvarnishdepositsinthefuelsystem,usefuel
stabilizeratalltimes.
FuelGauge
Usethefuelwindowbelowtheoperatortoverifythe
levelofgasolinebeforellingthetank(Figure6).
g020318
Figure6
1.Fuelgaugewindow
FillingtheFuelTank
Makesuretheengineisshutoffandthemotion
controlsareintheparkposition.
Important:Donotoverllfueltank.Fillthefuel
tanktothebottomofthellerneck.Theempty
spaceinthetankallowsthefueltoexpand.
Overllingmayresultinfuelleakageordamageto
theengineoremissionsystem.
1.Cleanaroundthefueltankcapandremovethe
cap.
Note:Youcanusethefuelwindowbelow
theoperatingpositionverifythepresenceof
gasolinebeforellingthetank(Figure6).
2.Slowlyaddregular,unleadedgasolineuntilthe
fuelreachesthebaseofthellerneckFigure7.
g027637
Figure7
3.Installthefueltankcapsecurelyandtighten
untilit“clicks.”Wipeupanygasolinethatmay
havespilled.
16

ThinkSafetyFirst
Pleasecarefullyreadallofthesafetyinstructionsand
decalsinthesafetysection.Knowingthisinformation
couldhelpyou,yourfamily,petsorbystandersavoid
injury.
DANGER
Mowingonwetgrassorsteepslopescan
causeslidingandlossofcontrol.
Wheelsdroppingoveredgescancause
rollovers,whichmayresultinseriousinjury,
deathordrowning.
Alossoftractionisalossofsteeringcontrol.
Toavoidlossofcontrolandpossibilityof
rollover:
•Donotmowneardrop-offsornearwater.
•Donotmowslopesgreaterthan15degrees.
•Reducespeedanduseextremecautionon
slopes.
•Whenmowingslopes,graduallyworkfrom
lowertohigherareasontheincline.
•Avoidsuddenturnsorrapidspeed
changes.
•Turnup,intoaninclinewhenchanging
directionsonslopes.Turningdownthe
slopereducestraction.
•Attachmentschangethehandling
characteristicsofthemachine.Useextra
cautionwhenusingattachmentswiththe
machine.
g015033
Figure8
1.SafeZone-usethemachinehere
2.Usewalkbehindmowerand/orhandtrimmerneardrop-offs
andwater.
3.Water
CAUTION
Thismachineproducessoundlevelsin
excessof85dBAattheoperatorsearandcan
causehearinglossthroughextendedperiods
ofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
Theuseofprotectiveequipmentforeyes,ears,
hands,feet,andheadisrecommended.
g009027
Figure9
1.Wearsafetyglasses2.Wearhearingprotection
TheSafetyInterlockSystem
WARNING
Ifsafetyinterlockswitchesaredisconnected
ordamagedthemachinecouldoperate
unexpectedlycausingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthemachine.
UnderstandingtheSafetyInterlock
System
Thesafetyinterlocksystemisdesignedtopreventthe
enginefromstartingunless:
•Theparkingbrakeisengaged.
•Thebladesaredisengaged.
•Themotioncontrolleversareintheneutrallock
position.
Thesafetyinterlocksystemalsoisdesignedtostop
theenginewhenthecontrolleversareoutofthe
neutrallockpositionwiththeparkingbrakeonorif
yourisefromtheseatwhenthebladesareengaged.
TestingtheSafetyInterlock
System
Testthesafetyinterlocksystembeforeyouusethe
machineeachtime.Ifthesafetysystemdoesnot
17

operateasdescribedbelow,haveanAuthorized
ServiceDealerrepairthesafetysystemimmediately.
1.Whilesittingontheseat,engagetheparking
brakeandmovethebladecontrolswitchtoOn.
Trystartingtheengine;theengineshouldnot
crank.
2.Whilesittingontheseat,engagetheparking
brakeandmovethebladecontrolswitchtoOff.
Moveeithermotioncontrollever(forwardor
reverse).Trystartingtheengine;theengine
shouldnotcrank.Repeatwiththeothermotion
controllever.
3.Whilesittingontheseat,engagetheparking
brake,movethebladecontrolswitchtoOff,
andlockthemotioncontrolleversinneutral.
Starttheengine.Whiletheengineisrunning,
releasetheparkingbrake,engagetheblade
controlswitch,andriseslightlyfromtheseat;
theengineshouldstop.
4.Whilesittingontheseat,engagetheparking
brake,movethebladecontrolswitchtoOff,and
lockthemotioncontrolleversinneutral.Start
theengine.Whiletheengineisrunning,center
themotioncontrols;theengineshouldstop.
UsingtheRollover
ProtectionSystem(ROPS)
WARNING
Toavoidinjuryordeathfromrollover:keep
therollbarinstalledandusetheseatbelt.
WARNING
Thereisnorolloverprotectionwhentheroll
barisremoved.
•Driveslowlyandcarefully.
•Checkcarefullyforoverheadclearances
(i.e.branches,doorways,electricalwires)
beforedrivingunderanyobjectsanddo
notcontactthem.
CheckingtheEngine-Oil
Level
Beforeyoustarttheengineandusethemachine,
checktheoillevelintheenginecrankcase;referto
CheckingtheEngine-OilLevel(page33).
BreakinginaNewMachine
Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
new,placingadditionalloadontheengine.Allow
40to50hoursofbreak-intimefornewmachinesto
developfullpowerandbestperformance.
18

OperatingtheParking
Brake
Alwayssettheparkingbrakewhenyoustopthe
machineorleaveitunattended.
SettingtheParkingBrake
g027638
Figure10
ReleasingtheParkingBrake
g027639
Figure11
OperatingtheThrottle
ThethrottlecontrolcanbemovedbetweenFastand
Slowpositions(Figure12).
Alwaysusethefastpositionwhenturningonthe
mowerdeckwiththebladecontrolswitch(PTO).
g028222
Figure12
OperatingtheChoke
Usethechoketostartacoldengineasfollows:
1.Pulluponthechokeknobtoengagethechoke
beforeusingtheignitionswitch(Figure13).
2.Pushdownonthechoketodisengagethechoke
aftertheenginehasstarted(Figure13).
g008959
Figure13
1.On2.Off
OperatingtheIgnition
Switch
1.TurntheignitionkeytotheStartposition(Figure
14).Whentheenginesstarts,releasethekey.
Important:Donotengagestarterformore
than5secondsatatime.Iftheenginefails
tostartallowa15secondcool-downperiod
betweenattempts.Failuretofollowthese
instructionscanburnoutthestartermotor.
Note:Additionalstartingcyclesmaybe
requiredwhenstartingtheenginefortherst
timeafterthefuelsystemhasbeenwithoutfuel
completely.
19

g008947
Figure14
2.Tostoptheengine,turntheignitionkeytothe
stopposition.
StartingandStoppingthe
Engine
StartingtheEngine
Note:Awarmorhotenginemaynotrequirechoking
(Figure15).
Important:Donotengagestarterformorethan5
secondsatatime.Iftheenginefailstostartallow
a15secondcool-downperiodbetweenattempts.
Failuretofollowtheseinstructionscanburnout
thestartermotor.
Note:Ifthefuelsystemwasdepletedoffuel—add
fueltothemachineanduseadditionalstartingcycles
whenstartingtheengine.
g028223
Figure15
StoppingtheEngine
CAUTION
Injurycanoccurifchildrenorbystanders
moveorattempttooperatethemachinewhile
itisunattended.
Alwaysremovetheignitionkeyandsetthe
parkingbrakewhenleavingthemachine
unattended,evenifjustforafewminutes.
20
