Toro TimeCutter SW3200 User manual

FormNo.3416-953RevA
TimeCutter®SW3200Riding
Mower
ModelNo.74780—SerialNo.401100000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3416-953*A

WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemical
orchemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
GrossorNetTorque
Thegrossornettorqueofthisenginewaslaboratory
ratedbytheenginemanufacturerinaccordancewith
theSocietyofAutomotiveEngineers(SAE)J1940
orJ2723.Asconguredtomeetsafety,emission,
andoperatingrequirements,theactualenginetorque
onthisclassofmowerwillbesignicantlylower.
Pleaserefertotheenginemanufacturer’sinformation
includedwiththemachine.
WARNING
Removingstandardoriginalequipmentparts
andaccessoriesmayalterthewarranty,
traction,andsafetyofthemachine.Failureto
useoriginalToropartscouldcauseserious
injuryordeath.Makingunauthorizedchanges
totheengine,fuel,orventingsystem,may
violateregulations.
Replaceallpartsincluding,butnotlimited
to,tires,belts,blades,andfuelsystem
componentswithoriginalToroparts.
Important:IfyouareusingamachinewithaToro
engineabove1500m(5,000ft)foracontinuous
period,ensurethattheHighAltitudeKithasbeen
installedsothattheenginemeetsCARB/EPA
emissionregulations.TheHighAltitudeKit
increasesengineperformancewhilepreventing
spark-plugfouling,hardstarting,andincreased
emissions.Onceyouhaveinstalledthekit,attach
thehigh-altitudelabelnexttotheserialdecalon
themachine.ContactanyAuthorizedToroService
DealertoobtaintheproperHighAltitudeKitand
high-altitudelabelforyourmachine.Tolocate
adealerconvenienttoyou,accessourwebsite
atwww.Toro.comorcontactourToroCustomer
CareDepartmentatthenumber(s)listedinyour
EmissionControlWarrantyStatement.
Removethekitfromtheengineandrestorethe
enginetoitsoriginalfactorycongurationwhen
runningtheengineunder1500m(5,000ft).Do
notoperateanenginethathasbeenconverted
forhigh-altitudeuseatloweraltitudes;otherwise,
youcouldoverheatanddamagetheengine.
Ifyouareunsurewhetherornotyourmachine
hasbeenconvertedforhigh-altitudeuse,lookfor
thefollowinglabel.
decal127-9363
Gotowww.Toro.comtoviewspecicationsonyour
model.
Introduction
Thisrotary-blade,ridinglawnmowerisintendedtobe
usedbyhomeownersinresidentialapplications.Itis
designedprimarilyforcuttinggrassonwell-maintained
lawns.Itisnotdesignedforcuttingbrush,mowing
grassandothergrowthalongsidehighways,orfor
agriculturaluses.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.
FortheOperator’sManual,thecompletewarranty
details,ortoregisteryourproduct,usetheQR
codeorvisitwww.Toro.com.Youmayalsocallus
at1-888-384-9939torequestawrittencopyofthe
productwarranty.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

g230912
Figure1
1.Modelandserialnumberplate
Writetheproductmodelandserialnumbersinthe
spacebelow:
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................4
GeneralSafety...................................................4
SlopeIndicator...................................................5
SafetyandInstructionalDecals..........................6
ProductOverview....................................................11
Controls............................................................11
BeforeOperation.................................................13
BeforeOperationSafety...................................13
AddingFuel......................................................13
PerformingDailyMaintenance..........................14
BreakinginaNewMachine..............................14
UsingtheSafety-InterlockSystem....................15
PositioningtheSeat..........................................16
PositioningtheSteeringWheel.........................16
DuringOperation.................................................17
DuringOperationSafety...................................17
OperatingtheSmartPark™Parking
Brake............................................................19
EngagingtheBlade-ControlSwitch
(PTO)............................................................19
DisengagingtheBlade-ControlSwitch
(PTO)............................................................19
OperatingtheThrottle.......................................19
StartingtheEngine...........................................20
ShuttingOfftheEngine.....................................20
DrivingtheMachine..........................................20
MowinginReverse...........................................21
UsingtheSideDischarge.................................21
AdjustingtheHeightofCut...............................22
OperatingTips.................................................22
AfterOperation....................................................23
AfterOperationSafety......................................23
PushingtheMachinebyHand..........................23
TransportingtheMachine.................................24
Maintenance...........................................................26
RecommendedMaintenanceSchedule(s)...........26
Pre-MaintenanceProcedures..............................27
MaintenanceSafety..........................................27
RaisingtheSeat...............................................27
RaisingtheFrontoftheMachine.......................27
Lubrication..........................................................28
GreasingtheBearings......................................28
EngineMaintenance...........................................28
EngineSafety...................................................28
ServicingtheAirCleaner..................................28
ServicingtheEngineOil....................................29
ServicingtheSparkPlug...................................32
CleaningtheBlowerHousing............................32
FuelSystemMaintenance...................................33
ReplacingtheIn-LineFuelFilter.......................33
ElectricalSystemMaintenance...........................34
ElectricalSystemSafety...................................34
ServicingtheBattery.........................................34
ServicingtheFuses..........................................35
DriveSystemMaintenance..................................36
CheckingtheTirePressure...............................36
3

ReleasingtheElectricBrake.............................36
BeltMaintenance................................................37
InspectingtheBelts..........................................37
ReplacingtheMowerBelt.................................37
MowerMaintenance.............................................38
ServicingtheCuttingBlades.............................38
LevelingtheMowerDeck..................................40
RemovingtheMowerDeck...............................42
InstallingtheMowerDeck.................................43
ReplacingtheGrassDeector..........................43
Cleaning..............................................................44
CleaningundertheFrontoftheMachine...........44
WashingtheUndersideoftheMower
Deck..............................................................44
DisposingofWaste...........................................44
Storage...................................................................45
StorageSafety..................................................45
CleaningandStorage.......................................45
StoringtheBattery............................................46
Troubleshooting......................................................47
Schematics.............................................................49
Safety
ThefollowinginstructionsarefromANSIstandard
B71.4-2012.
GeneralSafety
Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury.
Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.
•Donotoperatethemachineneardrop-offs,
ditches,embankments,water,orotherhazards,or
onslopesgreaterthan15degrees.
•Readandunderstandthecontentsofthis
Operator’sManualbeforestartingtheengine.
•Donotputyourhandsorfeetnearmoving
componentsofthemachine.
•Donotoperatethemachinewithoutallguards
andothersafetyprotectivedevicesinplaceand
workingonthemachine.
•Keepchildrenandbystandersoutoftheoperating
area.Neverallowchildrentooperatethemachine.
•Stopthemachineandshutofftheenginebefore
servicing,fueling,oruncloggingthemachine.
Improperlyusingormaintainingthismachinecan
resultininjury.T oreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
Youcanndadditionalsafetyinformationwhere
neededthroughoutthismanual.
4

SlopeIndicator
g011841
Figure4
Thispagemaybecopiedforpersonaluse.
1.Themaximumslopeyoucanoperatethemachineonis15degrees.Usetheslopecharttodeterminethedegreeofslopeof
hillsbeforeoperating.Donotoperatethismachineonaslopegreaterthan15degrees.Foldalongtheappropriateline
tomatchtherecommendedslope.
2.Alignthisedgewithaverticalsurface,atree,building,fencepole,etc.
3.Exampleofhowtocompareslopewithfoldededge
5

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decalbatterysymbols
BatterySymbols
Someorallofthesesymbolsareonyourbattery.
1.Explosionhazard6.Keepbystandersasafe
distanceawayfromthe
battery.
2.Nore,opename,or
smoking
7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.
3.Causticliquid/chemical
burnhazard
8.Batteryacidcancause
blindnessorsevereburns.
4.Weareyeprotection.9.Flusheyesimmediately
withwaterandgetmedical
helpfast.
5.ReadtheOperator's
Manual.
10.Containslead;donot
discard
decaloemmarkt
Manufacturer'sMark
1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.
decal93-7009
93-7009
1.Warning—donotoperatethemowerwiththedeectorup
orremoved;keepthedeectorinplace.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.
decal106-8717
106-8717
1.Readtheinstructionsbeforeservicingorperforming
maintenance.
2.Checktirepressureevery25operatinghours.
3.Greaseevery25operatinghours.
4.Engine
decal119-8871
119-8871
1.Heightofcut5.3inches
2.4-1/2inches6.2-1/2inches
3.4inches7.2inches
4.3-1/2inches8.1-1/2inches
6

decal121-0771
121-0771
1.Choke4.SLOWposition
2.FASTposition5.Powertakeoff(PTO),blade-controlswitch
3.Continuous-variablesetting
decal121-2989b
121-2989
1.Bypassleverpositionfor
pushingthemachine
2.Bypassleverpositionfor
operatingthemachine
decal131-3620
131-3620
1.Pedalposition—forward3.Pedalposition—reverse
2.Pedalposition—neutral
7

decal131-3621b
131-3621
1.Crushing/dismembermenthazardofbystanders—keep
bystandersawayfromthemachine;donotstartthe
machinewithbystandersnearby.
decal131-3665
131-3665
1.Bladespinning3.ReadtheOperator's
Manual.
2.Reverse
decal131-3955
131-3955
1.On2.Off
8

decal132-0870
132-0870
Note:Thismachinecomplieswiththeindustrystandardstabilitytestinthestaticlateralandlongitudinaltestswiththemaximum
recommendedslopeindicatedonthedecal.ReviewtheinstructionsforoperatingthemachineonslopesintheOperator’sManualas
wellastheconditionsinwhichyouwouldoperatethemachinetodeterminewhetheryoucanoperatethemachineinthoseconditions
onthatdayandatthatsite.Changesintheterraincanresultinachangeinslopeoperationforthemachine.Ifpossible,keepthe
cuttingunitsloweredtothegroundwhileoperatingthemachineonslopes.Raisingthecuttingunitswhileoperatingonslopescan
causethemachinetobecomeunstable.
1.Warning—readtheOperator'sManual.3.Bodilyharmhazard—noriders;look
behindyouwhenmowinginreverse.
5.Ramptippinghazard—whenloading
ontoatrailer,donotusedualramps;
onlyuseasinglerampwideenough
forthemachineandthathasanincline
lessthan15degrees;backupthe
ramp(inreverse)anddriveforwardoff
theramp.
2.Cuttinghazardofhand,mowerblade;
pinchinghazardofhand,belt—keep
handsandfeetawayfrommoving
parts;keepallguardsandshieldsin
place.
4.Thrownobjecthazard—keep
bystandersawayfromthemachine;
removedebrisfromtheareabefore
mowing;keepthedeectorshield
down.
6.Tippinghazardonslopes—donot
makesharp,quickturns;donotuse
slopesgreaterthan15degrees.
9

decal132-0872
132-0872
1.Thrownobject
hazard—keepbystanders
awayfromthemachine.
3.Severinghazardofhand
orfoot—keepawayfrom
movingparts.
2.Thrownobjecthazard,
raisedbafe—donot
operatethemachinewith
anopendeck;usea
baggerorabafe.
4.Entanglement
hazard—keepaway
frommovingparts;keep
allguardsandshieldsin
place.
decal132-6863
132-6863
decal138-2456
138-2456
1.ReadtheOperator’s
Manual.
3.Donotoverllthefuel
tank.
2.Parkthemachineona
levelsurfacewhenlling
thefueltank.
10

ProductOverview
g027912
Figure5
1.Traction-controlpedal4.Steeringwheel7.Engine10.KeyChoice®control
2.Height-of-cutlever5.Controlpanel8.Fuel-tankcap11.Mowerdeck
3.SmartPark™switch6.Operatorseat9.Reardrivewheel12.Frontcasterwheels
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g027892
Figure6
1.SmartPark™switch5.Parkingbrake—On
2.Throttle/Chokecontrol6.Parkingbrakeindicator
light
3.Keyswitch7.Parkingbrake—Off
4.Blade-controlswitch
(powertake-off)
g028251
Figure7
1.Operating–in–Reverse
warninglight
3.Fuel-presencewindow
2.KeyChoicekey(bluein
color)
11

KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page20).
Throttle/ChokeControl
Thethrottleandchokecontrolsarecombinedinto1
controllever.Thethrottlecontrolstheenginespeed
andhasacontinuous-variablesettingfromSLOWto
FAST(Figure6).
Blade-ControlSwitch(Power
Takeoff)
Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure6).
Fuel-PresenceWindow
Youcanusethefuelwindow,locatedontheleftside
ofthemachine,toverifythepresenceoffuelinthe
tank(Figure7).
Height-of-CutLever
Usetheheight-of-cutlevertolowerandraisethedeck
fromtheseatedposition.Movingtheleverup(toward
you)raisesthedeckfromthegroundandmovingthe
leverdown(awayfromyou)lowersthedecktoward
theground.Adjusttheheight-of-cutonlywhilethe
machineisnotmoving(Figure19).
KeyChoice®Switch
Thisswitchallowsyoutomowinreversewhenit
isactivated.T oactivateit,turntheswitchtotheON
positionandreleaseitafterthePTOisengaged.T o
deactivateit,disengagethepowertakeoff(PTO)
(Figure7).
Operating-in-ReverseWarning
Light
TheOperating-in-Reversewarninglightilluminates
wheneveryouusetheKeyChoicekeytodeactivate
theoperating-in-reverseinterlock.Itisareminderthat
theinterlocksystemisdeactivated.Thelightgoes
outwheneveryoudisengagethePTOorshutoffthe
engine.Whenthelightison,lookbehindyouanduse
extracautionwhenbackingup.
SmartPark™Switch
Theparkingbrakeisactivatedelectronically.
Engagetheparkingbrakeby1ofthefollowingactions:
•PressingtheSmartPark™switchtotheONposition
(Figure6).
•Theparkingbrakeengagesautomaticallywhen
youleavetheseatandthetractioncontrolpedalis
intheNEUTRALposition.
•Theparkingbrakeautomaticallyengages5to6
secondsaftertheignitionswitchisturnedtothe
OFFposition(ifitisnotalreadyengaged).
Todisengagetheparkingbrake,presstheSmartPark
switchtotheOFFpositionwiththekeyintheRUN
position.
Attachments/Accessories
AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.T oro.comforalistofallapprovedattachments
andaccessories.
Tobestprotectyourinvestmentandmaintainoptimal
performanceofyourT oroequipment,countonToro
genuineparts.Whenitcomestoreliability,T oro
deliversreplacementpartsdesignedtotheexact
engineeringspecicationofourequipment.Forpeace
ofmind,insistonT orogenuineparts.
12

Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
BeforeOperation
BeforeOperationSafety
GeneralSafety
•Neverallowchildrenoruntrainedpeopleto
operateorservicethemachine.Localregulations
mayrestricttheageoftheoperator.Theowner
isresponsiblefortrainingalloperatorsand
mechanics.
•Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetysigns.
•Knowhowtostopthemachineandshutoffthe
enginequickly.
•Checkthatoperator-presencecontrols,safety
switches,andshieldsareattachedandfunctioning
properly.Donotoperatethemachineunlessthey
arefunctioningproperly.
•Beforemowing,alwaysinspectthemachineto
ensurethattheblades,bladebolts,andcutting
assembliesareingoodworkingcondition.
Replacewornordamagedbladesandboltsinsets
topreservebalance.
•Inspecttheareawhereyouwillusethemachine
andremoveallobjectsthatthemachinecould
throw.
•Evaluatetheterraintodeterminetheappropriate
equipmentandanyattachmentsoraccessories
requiredtooperatethemachineproperlyand
safely.
FuelSafety
•Toavoidpersonalinjuryorpropertydamage,use
extremecareinhandlingfuel.Fuelvaporsare
ammableandexplosive.
•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.
•Useonlyanapprovedfuelcontainer.
•Donotremovethefuelcaporaddfueltothefuel
tankwhiletheengineisrunningorwhilehot.
•Donotrefuelthemachineindoors.
•Donotstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.
•Donotllcontainersinsideavehicleoronatruck
ortrailerbedwithaplasticliner.Alwaysplace
containersontheground,awayfromyourvehicle
beforelling.
•Removetheequipmentfromthetruckortrailer
andrefuelitwhileitisontheground.Ifthisisnot
possible,thenrefuelfromaportablecontainer
ratherthanafuel-dispensernozzle.
•Donotoperatethemachinewithouttheentire
exhaustsysteminplaceandinproperworking
condition.
•Keepthefuel-dispensernozzleincontactwith
therimofthefueltankorcontaineropeningat
alltimesuntilfuelingiscomplete.Donotusea
nozzlelock-opendevice.
•Ifyouspillfuelonyourclothing,changeyour
clothingimmediately.Wipeupanyfuelthatspills.
•Neveroverllthefueltank.Replacethefuelcap
andtightenitsecurely.
•Storefuelinanapprovedcontainerandkeepit
outofthereachofchildren.Neverbuymorethan
a30-daysupplyoffuel.
•Donotllthefueltankcompletelyfull.Addfuelto
thefueltankuntilthelevelis6to13mm(1/4to
1/2inch)belowthebottomofthellerneck.This
emptyspaceinthetankallowsfueltoexpand.
–Avoidprolongedbreathingofvapors.
–Keepyourfaceawayfromthenozzleandfuel
tankopening.
–Avoidcontactwithskin;washoffspillswith
soapandwater.
AddingFuel
RecommendedFuel
•Forbestresults,useonlyclean,fresh(lessthan
30daysold),unleadedgasolinewithanoctane
ratingof87orhigher((R+M)/2ratingmethod).
•Ethanol:Gasolinewithupto10%ethanol
(gasohol)or15%MTBE(methyltertiarybutyl
ether)byvolumeisacceptable.Ethanoland
MTBEarenotthesame.Gasolinewith15%
ethanol(E15)byvolumeisnotapprovedforuse.
Neverusegasolinethatcontainsmorethan
10%ethanolbyvolume,suchasE15(contains
15%ethanol),E20(contains20%ethanol),orE85
(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/or
enginedamagewhichmaynotbecoveredunder
warranty.
•Donotusegasolinecontainingmethanol.
13

•Donotstorefueleitherinthefueltankorfuel
containersoverthewinterunlessyouuseafuel
stabilizer.
•Donotaddoiltogasoline.
UsingStabilizer/Conditioner
Useafuelstabilizer/conditionerinthemachineto
providethefollowingbenets:
•Keepsfuelfreshduringstorageof90daysorless
(drainthefueltankwhenstoringthemachinefor
morethan90days)
•Cleanstheenginewhileitruns
•Eliminatesgum-likevarnishbuildupinthefuel
system,whichcauseshardstarting
Important:Donotusefueladditives
containingmethanolorethanol.
Addthecorrectamountoffuelstabilizer/conditioner
tothefuel.
Note:Afuelstabilizer/conditionerismost
effectivewhenmixedwithfreshfuel.T ominimize
thechanceofvarnishdepositsinthefuelsystem,
usefuelstabilizeratalltimes.
FillingtheFuelTank
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Shutofftheengineandremovethekey.
4.Cleanaroundthefuel-tankcap.
5.Fillthefueltanktothebottomofthellerneck
(Figure8).
Note:Donotllthefueltankcompletelyfull.
Theemptyspaceinthetankallowsthefuelto
expand.
g027243
Figure8
PerformingDaily
Maintenance
Beforestartingthemachineeachday,performthe
EachUse/DailyprocedureslistedinMaintenance
(page26).
BreakinginaNewMachine
Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
new,placingadditionalloadontheengine.Allow
40to50hoursofbreak-intimefornewmachinesto
developfullpowerandbestperformance.
14

UsingtheSafety-Interlock
System
WARNING
Ifthesafety-interlockswitchesare
disconnectedordamaged,themachinecould
operateunexpectedly,causingpersonal
injury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthemachine.
Understandingthe
Safety-InterlockSystem
Thesafety-interlocksystemisdesignedforthe
following:
•Topreventtheenginefromstartingunlessthe
tractionpedalisintheNEUTRALposition.
•Toautomaticallyensurethattheparkingbrake
isengagedandthePTOisoffwhenstartingthe
machine.
•Toshutofftheenginewheneverthetractionpedal
isnotintheNEUTRALpositionandyourisefrom
theseat.
•Toautomaticallyengagetheparkingbrakeand
disengagethePTO,whenyouriseoutoftheseat
withthetractionpedalintheNEUTRALposition.
•Toshutofftheenginewhenevertheparkingbrake
isnotengagedandyourisefromtheseat.
TestingtheSafety-Interlock
System
1.Sitintheseatwiththeengineoffandensure
thatthePTOswitchisintheOFFposition.
2.TurnthekeyswitchtotheSTARTposition;the
startershouldcrank.Donotstartorshutoffthe
enginepriortostep3.
3.TurnthekeyswitchtotheONpositionandpush
theSmartParkswitchtotheOFFposition.The
brakeshoulddisengageandthebrakelight
shouldturnoff.
4.Withthebrakedisengagedandtractionpedal
intheNEUTRALposition,turnthekeytothe
STARTposition.Thebrakeshouldautomatically
engage,theengineshouldcrank,andthebrake
lightshouldturnon.
5.WiththeengineoffandthekeyintheON
position,engagethePTObypullingupthe
blade-controlswitch;youshouldheartheclutch
engage.
6.Ensurethatthetractionpedalisinneutraland
turnthekeytotheSTARTposition.ThePTO
shoulddisengageandtheengineshouldcrank
andstartwithoutthebladesmoving.
7.Withtheenginerunning,risefromtheseat.The
engineshouldremainrunningandthebrake
lightshouldbeon.
8.Returntotheseatanddisengagetheparking
brakebypushingtheSmartParkswitchtothe
OFFposition.Theengineshouldcontinuetorun.
9.Risefromtheseatagain.Thebrakeshould
automaticallyengageandtheengineshould
continuetorun.
10.Returntotheseatandengagethebladesby
pullinguptheblade-controlswitch.
11.Risefromtheseat.Thebladesshould
disengageandtheengineshouldcontinueto
run.
12.Returntotheseatandpulluptheblade-control
switch.Thebladesshouldengage.Disengage
thebladesbypushingdowntheblade-control
switch.
13.Pulluptheblade-controlswitchtoengagethe
blades.MovethetractionpedaltotheREVERSE
position.Thebladesshoulddisengage.Move
thetractionpedaltotheNEUTRALposition.
14.Pulluptheblade-controlswitchtoengagethe
blades.TurntheKeyChoiceswitchtotheON
positionandreleaseit.Theoperating-in-reverse
lightshouldilluminate.
15.MovethetractionpedaltotheREVERSEposition.
Thebladesshouldremainengaged.Pushthe
blade-controlswitchintodisengagetheblades.
Theoperating-in-reverselightshouldturnoff.
MovethetractionpedaltotheNEUTRALposition.
16.Ifnotengaged,pushtheSmarkParkswitchto
theONpositionandlightlytapthetractionpedal
intheeithertheFORWARDorREVERSEposition.
Thebrakeshoulddisengageandthebrakelight
shouldturnoff.
Note:Tapthepedal,donotfullyengagethe
pedalasthatcausesthebrakesystemtobind
andnotrelease.
17.Withthebrakereleased,engagethetraction
pedalslightlyandrisefromtheseat.Theengine
shouldshutoff.
18.ReturntotheseatandturnthekeytotheOFF
position.Afterseveralseconds,thebrake
systemshouldengage.
Note:WiththekeyintheOFFposition,the
brakelightdoesnotilluminate.
15

PositioningtheSeat
Theseatcanmoveforwardandbackward.Position
theseatwhereyouhavethebestcontrolofthe
machineandaremostcomfortable(Figure9).
g027249
Figure9
PositioningtheSteering
Wheel
Thesteeringwheelhas3positionsforoperationand
1full-upposition.Usethefull-uppositionforstepping
onandoffthemachineandgettingoutoftheseat.
Whenoperatingthemachine,positionthesteering
wheelwhereyouhavethebestcontrolofthemachine
andaremostcomfortable.
1.Pressyourfootontothesteering-columnrelease
lever.
2.Positionthesteeringwheeltothedesired
position(Figure10).
g027751
Figure10
16

DuringOperation
DuringOperationSafety
GeneralSafety
•Theowner/operatorcanpreventandisresponsible
foraccidentsthatmaycausepersonalinjuryor
propertydamage.
•Wearappropriateclothing,includingeye
protection;longpants;slip-resistant,substantial
footwear;andhearingprotection.Tiebacklong
hairanddonotwearjewelry.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Nevercarrypassengersonthemachineandkeep
bystandersandpetsawayfromthemachine
duringoperation.
•Operatethemachineonlyingoodvisibilitytoavoid
holesorhiddenhazards.
•Avoidmowingonwetgrass.Reducedtraction
couldcausethemachinetoslide.
•Ensurethatalldrivesareinneutral,theparking
brakeisengaged,andyouareintheoperating
positionbeforeyoustarttheengine.
•Keepyourhandsandfeetawayfromthecutting
units.Keepclearofthedischargeopeningatall
times.
•Lookbehindanddownbeforebackinguptobe
sureofaclearpath.
•Usecarewhenapproachingblindcorners,shrubs,
trees,orotherobjectsthatmayobscureyour
vision.
•Donotmowneardrop-offs,ditches,or
embankments.Themachinecouldsuddenlyroll
overifawheelgoesovertheedgeoriftheedge
givesway.
•Stopthebladeswheneveryouarenotmowing.
•Stopthemachineandinspectthebladesafter
strikinganobjectorifthereisanabnormal
vibrationinthemachine.Makeallnecessary
repairsbeforeresumingoperation.
•Slowdownandusecautionwhenmakingturns
andcrossingroadsandsidewalkswiththe
machine.Alwaysyieldtheright-of-way.
•Disengagethedrivetothecuttingunitandshut
offtheenginebeforeadjustingtheheightof
cut(unlessyoucanadjustitfromtheoperating
position).
•Neverrunanengineinanareawhereexhaust
gasesareenclosed.
•Neverleavearunningmachineunattended.
•Beforeleavingtheoperatingposition(including
toemptythecatchersortounclogthechute),do
thefollowing:
–Stopthemachineonlevelground.
–Disengagethepowertake-offandlowerthe
attachments.
–Engagetheparkingbrake.
–Shutofftheengineandremovethekey.
–Waitforallmovingpartstostop.
•Donotoperatethemachinewhenthereistherisk
oflightning.
•Donotusethemachineasatowingvehicleunless
ithasahitchinstalled.
•Donotchangethegovernorspeedoroverspeed
theengine.
•Useonlyaccessoriesandattachmentsapproved
byToro.
•Thismachineproducessoundlevelsinexcess
of85dBAattheoperator’searandcancause
hearinglossthroughextendedperiodsof
exposure.
g229846
Figure11
1.Wearhearingprotection.
SlopeSafety
•Slopesareamajorfactorrelatedtolossofcontrol
androlloveraccidents,whichcanresultinsevere
injuryordeath.Theoperatorisresponsiblefor
safeslopeoperation.Operatingthemachineon
anysloperequiresextracaution.Beforeusingthe
machineonaslope,dothefollowing:
–Reviewandunderstandtheslopeinstructions
inthemanualandonthemachine.
–Useanangleindicatortodeterminethe
approximateslopeangleofthearea.
–Neveroperateonslopesgreaterthan15
degrees.
–Evaluatethesiteconditionsofthedayto
determineiftheslopeissafeformachine
operation.Usecommonsenseandgood
judgmentwhenperformingthisevaluation.
Changesintheterrain,suchasmoisture,can
quicklyaffecttheoperationofthemachineon
aslope.
17

•Identifyhazardsatthebaseoftheslope.Do
notoperatethemachineneardrop-offs,ditches,
embankments,water,orotherhazards.The
machinecouldsuddenlyrolloverifawheelgoes
overtheedgeortheedgecollapses.Keepasafe
distance(twicethewidthofthemachine)between
themachineandanyhazard.Useawalk-behind
machineorahandtrimmertomowthegrassin
theseareas.
•Avoidstarting,stopping,orturningthemachineon
slopes.Avoidmakingsuddenchangesinspeedor
direction;turnslowlyandgradually.
•Donotoperateamachineunderanyconditions
wheretraction,steering,orstabilityisinquestion.
Beawarethatoperatingthemachineonwet
grass,acrossslopes,ordownhillmaycausethe
machinetolosetraction.Lossoftractiontothe
drivewheelsmayresultinslidingandalossof
brakingandsteering.Themachinecanslideeven
ifthedrivewheelsarestopped.
•Removeormarkobstaclessuchasditches,holes,
ruts,bumps,rocks,orotherhiddenhazards.Tall
grasscanhideobstacles.Uneventerraincould
overturnthemachine.
•Useextracarewhileoperatingwithaccessoriesor
attachments,suchasgrass-collectionsystems.
Thesecanchangethestabilityofthemachine
andcausealossofcontrol.Followdirectionsfor
counterweights.
•Ifpossible,keepthedeckloweredtotheground
whileoperatingonslopes.Raisingthedeckwhile
operatingonslopescancausethemachineto
becomeunstable.
g231393
Figure12
1.SafeZone—usethe
machinehereonslopes
lessthan15degreesor
atareas.
4.W=widthofthemachine
2.DangerZone—usea
walk-behindmowerand/or
ahandtrimmeronslopes
greaterthan15degrees
andneardrop-offsor
water.
5.Keepasafedistance
(twicethewidthofthe
machine)betweenthe
machineandanyhazard.
3.Water
TowingSafety
•Donotattachtowedequipmentexceptatthehitch
point.
•Followtheattachmentmanufacturer's
recommendationforweightlimitsfortowed
equipmentandtowingonslopes.T owedweight
mustnotexceedtheweightofthemachine,
operator,andballast.Usecounterweightsor
wheelweightsasdescribedintheattachment,or
intowingthemachineOperator’sManual.
•Neverallowchildrenorothersinoronthetowed
equipment.
•Onslopes,theweightofthetowedequipmentmay
causelossoftraction,increasedriskofrollover,
andlossofcontrol.Reducethetowedweightand
slowdown.
•Thestoppingdistanceincreaseswiththeweight
ofatowedload.Travelslowlyandallowextra
distancetostop.
•Makewideturnstokeeptheattachmentclearof
themachine.
18

OperatingtheSmartPark™
ParkingBrake
Theparkingbrakeisactivatedelectronically.
Engagetheparkingbrakeby1ofthefollowingactions:
•PressingtheSmartPark™switchtotheONposition
(Figure6).
•Theparkingbrakeengagesautomaticallywhen
theoperatorleavestheseatandthetraction
controlpedalisintheNEUTRALposition.
•Theparkingbrakeautomaticallyengages5to6
secondsaftertheignitionswitchisturnedtothe
OFFposition(ifitisnotalreadyengaged).
Disengagetheparkingbrakeby1ofthefollowing
actions:
•Tapthetraction-controlpedalforwardorreverse.
•PressingthebrakeswitchtotheOFFposition
(Figure6).
EngagingtheBlade-Control
Switch(PTO)
g008945
Figure13
Note:Alwaysengagethebladeswiththethrottlein
theFASTposition(Figure14).
g186693
Figure14
Disengagingthe
Blade-ControlSwitch
(PTO)
g009174
Figure15
OperatingtheThrottle
YoucanmovethethrottlecontrolbetweenFASTand
SLOWpositions(Figure16).
AlwaysusetheFASTpositionwhenengagingthePTO.
g187361
Figure16
19

StartingtheEngine
Important:Donotengagethestarterformore
than5secondsatatime.Engagingthestarter
motorformorethan5secondscandamagethe
startermotor.Iftheenginefailstostart,wait10
secondsbeforeoperatingtheenginestarteragain.
Note:Itmaybenecessarytoholdtheleveragainst
thestop,inthechokeposition,whiletryingtostartthe
engine(Figure17).
g027899
Figure17
ShuttingOfftheEngine
1.Disengagethebladesbymovingthe
blade-controlswitchtotheOFFposition(Figure
17).
2.Engagetheparkingbrake;refertoOperating
theSmartPark™ParkingBrake(page19).
3.MovethethrottlecontroltotheFASTposition.
4.TurnthekeytotheOFFpositionandremove
thekey.
CAUTION
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethemachinewhile
itisunattended.
Alwaysremovethekeyandengagethe
parkingbrakewhenleavingthemachine
unattended.
DrivingtheMachine
Thismachinehasthecharacteristicsofbothagarden
tractorandazero-turnmachine.Likeagarden
tractor,themachinehasafootpedalthatcontrolsthe
forwardandreversemotionalongwiththespeed,
andithasasteeringwheelthatcontrolsthedirection
andtheturningradius.Likeazero-turnmachine,
thereardrivewheelsoperateindependentlyofeach
other,enablingyoutomakesharpturnsandtoturn
indifferentdirectionsquickly.Thesecharacteristics
vastlyimprovethemaneuverabilityofthemachine,
buttheymayalsorequireyoutopracticedrivingifyou
areunfamiliarwiththistypeofmachine.
WARNING
Themachinecanspinveryrapidly.You
maylosecontrolofthemachineandcause
personalinjuryordamagetothemachine.
•Usecautionwhenmakingturns.
•Slowthemachinedownbeforemaking
sharpturns.
Thethrottlecontrolregulatestheenginespeedas
measuredinrpm(revolutionsperminute).Placing
thethrottlecontrolintheFASTpositioncanbebestfor
performance.Formostapplications,operatinginthe
FULL-THROTTLEpositionisdesirable.
DrivingForwardorBackward
1.MovethethrottletotheFASTposition.
2.Releasetheparkingbrake.
3.Placeyourfootontothetraction-controlpedal
andslowlypressthetopofthepedaltogo
forward,orpressonthebottomofthepedalto
movebackward(Figure18).
Note:Thefartheryoumovethepedalineither
direction,thefasterthemachinemovesinthat
direction.
20
