Toro 38657 User manual

FormNo.3360-759RevA
PowerMax®1128OXESnowthrower
ModelNo.38657—SerialNo.290000001andUp
Operator'sManual
Introduction
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoidinjury
andproductdamage.Youareresponsibleforoperating
theproductproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafetyalertsymbol
(Figure2),whichsignalsahazardthatmaycauseserious
injuryordeathifyoudonotfollowtherecommended
precautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
ReplacementEngineOwner’sManualsmaybe
orderedthroughtheenginemanufacturer.
©2008—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved

Safety
Before Operating
?
?
Read and understand the contents of this
manual before operating the snowthrower .
Become familiar with all controls and know
how to stop the engine quickly .
Operator 's
Position
The low-speed auger has a moving pinch
point close to the opening.
Caution: Improper use may result in
loss of fingers, hands, or feet.
There is a high-speed
impeller close to the
opening.
ThissnowthrowermeetsorexceedstheISO
standard8437ineffectatthetimeofproduction.
Readandunderstandthecontentsofthismanual
beforetheengineiseverstarted.
Thisisthesafetyalertsymbol.Itisusedtoalert
youtopotentialpersonalinjuryhazards.Obeyall
safetymessagesthatfollowthissymboltoavoid
possibleinjuryordeath.
Improperlyusingormaintainingthissnowthrower
couldresultininjuryordeath.Toreducethis
potential,complywiththefollowingsafety
instructions.
Training
•Readtheoperatingandserviceinstructionmanual
carefully.Bethoroughlyfamiliarwiththecontrols
andtheproperuseoftheequipment.Knowhowto
stoptheunitanddisengagethecontrolsquickly.
•Neverallowchildrentooperatetheequipment.
Neverallowadultstooperatetheequipmentwithout
properinstruction.
•Keeptheareaofoperationclearofallpersons,
particularlysmallchildren,andpets.
•Exercisecautiontoavoidslippingorfalling,
especiallywhenoperatinginreverse.
Preparation
•Thoroughlyinspecttheareawheretheequipmentis
tobeusedandremovealldoormats,sleds,boards,
wires,andotherforeignobjects.
•Disengageallclutchesandshiftintoneutralbefore
startingtheengine.
•Donotoperatetheequipmentwithoutwearing
adequatewintergarments.Wearfootwearwhichwill
improvefootingonslipperysurfaces.
•Handlefuelwithcare;itishighlyammable.
–Useanapprovedfuelcontainer.
–Neveraddfueltoarunningorhotengine.
–Fillfueltankoutdoorswithextremecare.Never
llfueltankindoors.
–Replacegasolinecapssecurelyandwipeup
spilledfuel.
•Adjustthecollectorhousingheighttocleargravel
orcrushedrocksurface.
•Neverattempttomakeanyadjustmentswhile
theengineisrunning(exceptwherespecically
recommendedbymanufacturer).
•Letengineandmachineadjusttooutdoor
temperaturesbeforestartingtoclearsnow .
•Theoperationofanypoweredmachinecanresultin
foreignobjectsbeingthrownintotheeyes.Always
2

wearsafetyglassesoreyeshieldsduringoperationor
whileperforminganadjustmentorrepair.
Operation
•Donotputhandsorfeetnearorunderrotatingparts.
Keepclearofthedischargeopeningatalltimes.
•Exerciseextremecautionwhenoperatingonor
crossinggraveldrives,walks,orroads.Stayalertfor
hiddenhazardsortrafc.
•Afterstrikingaforeignobject,stoptheengine,
removethewirefromthespark-plug,thoroughly
inspectthesnowthrowerforanydamage,andrepair
thedamagebeforerestartingandoperatingthesnow
thrower.
•Iftheunitshouldstarttovibrateabnormally,stop
theengineandcheckimmediatelyforthecause.
Vibrationisgenerallyawarningoftrouble.
•Stoptheenginewheneveryouleavetheoperating
position,beforeuncloggingthecollector/impeller
housingordischargeguide,andwhenmakingany
repairs,adjustments,orinspections.
•Whencleaning,repairing,orinspecting,makecertain
thecollector/impellerandallmovingpartshave
stopped.Disconnectthespark-plugwire,andkeep
thewireawayfromtheplugtopreventaccidental
starting.
•Donotruntheengineindoors,exceptwhenstarting
itandformovingthesnowthrowerinoroutofthe
building.Opentheoutsidedoors;exhaustfumes
aredangerous.
•Donotclearsnowacrossthefaceofslopes.Exercise
extremecautionwhenchangingdirectiononslopes.
Donotattempttoclearsteepslopes.
•Neveroperatethesnowthrowerwithoutproper
guards,plates,orothersafetyprotectivedevicesin
place.
•Neveroperatethesnowthrowernearglass
enclosures,automobiles,windowwells,drop-offs,
etc.withoutproperadjustmentofthesnow
dischargeangle.Keepchildrenandpetsaway.
•Donotoverloadthemachinecapacitybyattempting
toclearsnowattoofastarate.
•Neveroperatethemachineathightransportspeeds
onslipperysurfaces.Usecarewhenreversing.
•Neverdirectdischargeatbystandersorallowanyone
infrontoftheunit.
•Disengagepowertothecollector/impellerwhen
snowthroweristransportedornotinuse.
•Useonlyattachmentsandaccessoriesapprovedby
themanufacturerofsnowthrower(suchaswheel
weights,counterweights,cabs,etc.).
•Neveroperatethesnowthrowerwithoutgood
visibilityorlight.Alwaysbesureofyourfooting,and
keeparmholdonthehandles.Walk;neverrun.
•Neveroperatethesnowthrowerwithoutgood
visibilityorlight.
•Takeallpossibleprecautionswhenleavingthe
machineunattended.Shiftintoneutral,setthe
parkingbrake,stoptheengineandremovethekey.
MaintenanceandStorage
•Checkallfastenersatfrequentintervalsforproper
tightnesstobesuretheequipmentisinsafeworking
condition.
•Neverstorethemachinewithfuelinthefueltank
insideabuildingwhereignitionsourcesarepresent
suchashotwaterandspaceheaters,clothesdryers,
etc.Allowtheenginetocoolbeforestoringinany
enclosure.
•Alwaysrefertoowner’sguideinstructionsfor
importantdetailsifthesnowthroweristobestored
foranextendedperiod.
•Maintainorreplacesafetyandinstructionslabels,
asnecessary.
•Runthemachineafewminutesafterthrowingsnow
topreventfreeze-upofthecollector/impeller.
ToroSnowthrowerSafety
Thefollowinglistcontainssafetyinformationspecic
toToroproductsorothersafetyinformationthatyou
mustknow.
•Rotatingrotorbladescaninjurengersor
hands.Staybehindthehandlesandawayfromthe
dischargeopeningwhileoperatingthesnowthrower.
Keepyourface,hands,feet,andanyotherpart
ofyourbodyorclothingawayfrommovingor
rotatingparts.
•Beforeadjusting,cleaning,repairing,andinspecting
thesnowthrower,andbeforeuncloggingthe
dischargechute,stoptheengine,removethekey,
andwaitforallmovingpartstostop.
•Usethesnowcleanouttool,notyourhands,to
removeobstructionsfromthedischargechute.
•Beforeleavingtheoperatingposition,stopthe
engine,removethekey,andwaitforallmovingparts
tostop.
3

•Donotwearloose-ttingclothingthatcouldget
caughtinmovingparts.
•Ifashield,safetydevice,ordecalisdamaged,
illegible,orlost,repairorreplaceitbeforebeginning
operation.Also,tightenanyloosefasteners.
•Donotsmokewhilehandlinggasoline.
•Donotusethesnowthroweronaroof.
•Donottouchtheenginewhileitisrunningorsoon
afterithasstoppedbecausetheenginemaybehot
enoughtocauseaburn.
•Performonlythosemaintenanceinstructions
describedinthismanual.Beforeperformingany
maintenance,service,oradjustment,stoptheengine,
removethekey,anddisconnectthewirefromthe
sparkplug.Ifmajorrepairsareeverneeded,contact
anAuthorizedServiceDealer.
•Donotchangethegovernorsettingsontheengine.
•Whenstoringthesnowthrowerformorethan30
days,drainthefuelfromthefueltanktoprevent
apotentialhazard.Storefuelinanapprovedfuel
container.Removethekeyfromtheignitionswitch
beforestoringthesnowthrower.
•PurchaseonlygenuineTororeplacementpartsand
accessories.
SoundPressure
Thisunithasamaximumsoundpressurelevelatthe
operator’searof90dBA,basedonmeasurementsof
identicalmachinesperEN11201.
SoundPower
Thisunithasaguaranteedsoundpowerlevelof105
dBA,basedonmeasurementsofidenticalmachinesper
EN3744.
Vibration
Thisunitdoesnotexceedahand/armvibrationlevelof
7.1m/s2,basedonmeasurementsofidenticalmachines
perEN1033.
SafetyandInstructionalDecals
Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamaged
decals.
106-4525
Reorderpartno.112-6633
1.Fast3.Slow
2.Forwardspeeds4.Reversespeeds
107-3040
1.Cuttingdismemberment,impellerandcutting
dismemberment,augerhazards—keepbystandersasafe
distancefromthesnowthrower.
4

112-6625
Reorderpartno.112-6629
1.Cutting/dismembermenthazard,impeller—donotplace
yourhandinthechute;stoptheenginebeforeleavingthe
operator’sposition,usethetooltoclearthechute.
112-6627
1.Leftturncontrol3.Warning—readthe
Operator’sManual.
5.Cutting/dismemberment
hazard,impeller—keep
awayfrommovingparts;
removetheignitionkeyand
readtheinstructionsbefore
servicingorperforming
maintenance.
7.Auger/impeller
drive—squeezetheleverto
engage;releasethelever
todisengage.
2.Tractiondrive—squeeze
thelevertoengage;release
thelevertodisengage.
4.Cutting/dismemberment
hazard,impeller—do
notplaceyourhand
inthechute;stopthe
enginebeforeleavingthe
operator’sposition,usethe
tooltoclearthechute.
6.Thrownobject
hazard—keepbystanders
asafedistancefromthe
snowthrower.
8.Rightturncontrol
BriggsPartNo.273676
1.Stop3.Fast
2.Slow
BriggsPartNo.274681
1.Fuel—On2.Fuel—Off
BriggsPartNo.276923
1.Primer4.Ignitionkeyin
(Engine—Run)
2.Chokeoff(Run)5.Ignitionkeyout
(Engine—Stop)
3.Chokeon(Choke)
5

BriggsPartNo.276925
1.Warning—readthe
Operator’sManual.
3.Warning—toxicgas
inhalationhazard.
2.Warning—rehazard.4.Warning—hot
surface/burnhazard.
BriggsPartNo.277566
1.Whenstartingacold
engine,closethechoke
andpresstheprimertwo
times.
2.Whenstartingawarm
engine,openthechoke
anddonotpressthe
primer.
Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
Handlebolts4
Curvedwashers4
1.Locknuts4
Installtheupperhandle.
2.Nopartsrequired–Installthewheelclutchcableends
3.Nopartsrequired–Installthetractioncontrollinkage.
Carriagebolts2
4.Locknuts2Installthechutecontrolrod.
5.Cabletie1Connectthewiretotheheadlight.
6.Nopartsrequired–Filltheenginewithoil.
7.Nopartsrequired–Checkthetirepressure.
8.Nopartsrequired–Checktheskids.
9.Nopartsrequired–Checktheoperationofthetractiondrive.
6

1.InstallingtheUpperHandle
4Handlebolts
4Curvedwashers
4Locknuts
Procedure
Note:Donotremovetherubberbandonthecables
untilyouhaveinstalledtheupperhandle.
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure3).
Important:Routethecablesattachedtothe
QuickStickinsidetheupperhandlelegsand
ensurethatthecablesandthewireforthe
headlightarenotpinchedbetweenthehandle
sections.
Figure3
1.Cables
2.Securetheupperhandlewith4handlebolts,
4curvedwashers,and4locknutsfromtheloose
partsbag(Figure4).
Figure4
2.InstallingtheWheelClutch
CableEnds
Procedure
1.Unwrapthecableendsfromthelowerhandle
(Figure5).
Figure5
2.Routeeithertheleftorrightcableendoverthelower
handleandinsertthecableendintotheholeinthe
correspondingwheelclutchlever(Figure6).
Figure6
1.Wheelclutchlever
3.Removethenutandwasherfromthehandle,attach
thecableclamponthecabletothehandle,install
thewasherandthenut,andhandtightenthenut
(Figure7).
Figure7
1.Cableclamp(2)
7

Important:Ensurethatthecurvedsideofthe
cableclampisagainstthehandleandthatthe
cableisroutedbelowtheclampbolt.Thecable
mustbeinastraightlinefromthecableclamp
tothepointwhereitattachestothewheelclutch
lever.
4.Pullthecablejacketdowngentlyuntilthewheel
clutchleverisdownandtheslackisoutofthecable,
thentightenthecableclampnutsecurely(Figure8).
Figure8
5.Squeezetheleverfully,thencheckthegapbetween
thebottomofthehandleandthewheelclutchlever
end(Figure9).
Figure9
Note:Thegapshouldbeapproximatelythe
thicknessofapencil(1/4inchor6mm).Ifitis
greater,loosenthecableclampnut,slidethecable
jacketupslightly,tightenthecableclampnut,and
checkthegapagain.
6.Repeatsteps2through5fortheothercable.
3.InstallingtheTraction
ControlLinkage
Procedure
1.Removethehairpincotterandwasherfromthe
lowerendofthespeedcontrolrodandinsertthe
lowerendoftherodintothelowerlinkarmsothat
thebentendofthespeedcontrolrodfacesrearward
(Figure10).
Figure10
2.Securethelowerendofthespeedcontrolrodwith
thewasherandhairpincotterthatyoupreviously
removed.
3.Removethehairpincotterandtheouterwasher
fromthetrunnionontheupperendofthespeed
controlrod(Figure11).
Figure11
1.Speedselectorlever3.Innerwasher
2.Trunnion4.Outerwasher
Note:Tomakeinstallationeasier,leavetheat
washeronthetrunnion(Figure11).
4.ShiftthespeedselectorleverintoPositionR2.
5.Rotatethelowerlinkarmfullyupward
(counterclockwise)(Figure12).
Figure12
8

6.Liftuponthespeedcontrolrodandinsertthe
trunnionintotheholeinthespeedselectorlever
(Figure11).
Note:Ifthetrunniondoesnottintothehole
whenyouliftuponthespeedcontrolrod,rotatethe
trunnionupwardordownwardonthespeedcontrol
roduntilitts.
7.Securethetrunnionandupperendofthespeed
controlrodwiththeouterwasherandahairpin
cotteryoupreviouslyremoved.
Note:Foreasierinstallation,lookdownthrough
theopeninginthespeedselector(Figure13).
Figure13
1.Speedselector
4.InstallingtheChuteControl
Rod
2Carriagebolts
2Locknuts
Procedure
1.UnwraptheQuickStickandrotateitsothatitis
uprightandinthecenter.
2.Holdthebluetriggercapdownandpullthelever
fullyrearward.
Note:Thedischargechuteanddeectorshould
faceforward.Iftheydonot,holdthebluetrigger
capdown(butdonotmovetheQuickStick)and
rotatethedischargechuteuntiltheydo.
3.Aligntheattenedbackendofthelongchute
controlrodwiththeattenedfrontendoftheshort
rodthatextendsfromthecontrolpanelsothatthey
nesttogether(Figure14).
Figure14
1.Shortrod2.Longchutecontrolrod
4.Insertthefrontendoftherodintotheopeningin
thebackofthechutegearcoveruntilitslidesinto
thechutegear(Figure15).
Figure15
5.Aligntheholesinthenestedendsoftherodsand
insert2carriagebolts(intheloosepartsbag)through
theshortrodfromtheleftsideofthesnowthrower
(fromtheoperatingposition).
6.Insertthecableclipthatsupportsthedeector
cableontotheforwardcarriagebolt,andsecurethe
carriageboltswithlocknutsfromtheloosepartsbag
(Figure16).
9

Figure16
1.Cableclip2.Deectorcable
7.HoldthebluetriggercapdownandrotatetheQuick
Stickinacircletoensurethatthechuteanddeector
operatesmoothly.
5.ConnectingtheWiretothe
Headlight
1Cabletie
Procedure
1.Insertthewireconnectoronthelooseendofthe
wirestraightintothebackoftheheadlightuntilitis
securelyinplace(Figure17).
Figure17
1.Plasticcliponwire
connector
3.Cabletie
2.U-bolt
Note:Ensurethattheplasticcliponthewire
connectorisonthebottom(Figure17).
2.Secureacabletie(fromtheloosepartsbag)around
thewireandthehandleaboutaninch(2.5cm)below
theU-bolt(Figure17).
6.FillingtheEnginewithOil
Procedure
Yoursnowthrowercomeswith28oz.ofoilinthe
enginecrankcase.
Note:Beforestartingtheengine,checktheoillevel
andaddoilifnecessary.
Max.ll:28oz.(0.83l),type:automotivedetergentoil
withanAPIserviceclassicationofSF,SG,SH,SJ,SL,
orhigher.UseSAE5W30orSAE10W30oil.Referto
yourengineowner’smanual.
1.Removethedipstickandslowlypouroilintothe
oillltubetoraisetheoilleveltotheFullmarkon
thedipstick.Donotoverll(Figure18).Referto
CheckingtheEngineOilLevelinMaintenance.
Figure18
2.Installthedipsticksecurely.
Note:Donotspilloilaroundtheoillltube;oil
couldleakontotractionpartsandcausethetraction
toslip.
7.CheckingtheTirePressure
Procedure
Thetiresareoverinatedatthefactoryforshipping.
Reducethepressureequallyinbothtirestobetween17
and20psi(116and137kPa).
8.CheckingtheSkids
Procedure
RefertoCheckingandAdjustingtheSkidsin
Maintenance.
10

9.CheckingtheTractionDrive
Operation
Procedure
Ifthetractiondriveisnotproperlyadjusted,
thesnowthrowermaymoveinthedirection
oppositeofwhatyouintended,causinginjury
and/orpropertydamage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Starttheengine;refertoStartingtheEngine.
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector.
3.Squeezethelefthand(traction)levertothehand-grip
(Figure19).
Figure19
Thesnowthrowershouldmoverearward.Ifthe
snowthrowerdoesnotmoveormovesforward,
completethefollowing:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure11).
C.Turnthetrunniondownward(clockwise)onthe
speedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
4.Releasethetractionlever.
5.MovethespeedselectortothePosition1;referto
OperatingtheSpeedSelector.
6.Squeezethelefthand(traction)levertothehand-grip
(Figure19).
Thesnowthrowershouldmoveforward.Ifthe
snowthrowerdoesnotmoveormovesrearward,
completethefollowing:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure11).
C.Turnthetrunnionupward(counterclockwise)on
thespeedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.
Important:Ifthesnowthrowermoveswhenthe
tractionleverisinthereleasedposition,checkthe
tractioncable(refertoCheckingandAdjusting
theTractionCable)ortakethesnowthrowertoan
AuthorizedServiceDealerforservice.
ProductOverview
Figure20
1.Hand-grip(2)10.Scraper
2.Auger/impellerlever11.Auger
3.Speedselectorlever12.Skid(2)
4.QuickStick™discharge
chutecontrol
13.Electricstarterbutton
5.Tractionlever14.Electricstarterplug
6.Fueltankcap15.Snowcleanouttool
7.Engineoillltube/dipstick16.Headlight
8.Chutedeector17.Wheelclutchlever(2)
9.Dischargechute
11

Figure21
1.Choke5.Recoilstarter
2.Ignitionswitch6.Oildrainplug
3.Fuelshutoffvalve7.Primer
4.Throttle
Figure22
1.Snowcleanouttool(attachedtothehandle)
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
FillingtheFuelTank
Gasolineisextremelyammableandexplosive.
Areorexplosionfromgasolinecanburnyou
andothers.
•Topreventastaticchargefromigniting
thegasoline,placethecontainerand/or
snowthroweronthegroundbeforelling,
notinavehicleoronanobject.
•Fillthetankoutdoorswhentheengineis
cold.Wipeupspills.
•Donothandlegasolinewhensmokingor
aroundanopenameorsparks.
•Storegasolineinanapprovedfuelcontainer,
outofthereachofchildren.
Fillthefueltankwithfreshunleadedregulargasoline
fromamajorname-brandservicestation(Figure23).
Important:Toreducestartingproblems,add
fuelstabilizertothefuelallseason,mixingitwith
gasolinelessthan30daysold.
Do not add oil to
the gasoline.
Figure23
1.1-1/2inch(3.8cm)
StartingtheEngine
1.Checktheengineoillevel.RefertoCheckingthe
EngineOilLevelinMaintenance.
2.Turnthefuelshutoffvalve1/4turncounterclockwise
toopenit(Figure24).
Figure24
3.Inserttheignitionkey(Figure25).
12

Figure25
1.Ignitionkey
4.Firmlypushintheprimerwithyourthumb2times
(15°For-9°Corabove)or4times(below15°For
-9°C),holdingtheprimerinforasecondbefore
releasingiteachtime(Figure26).
Figure26
5.RotatethechoketotheChokeposition(Figure27).
Figure27
6.MovethethrottletotheFastposition(Figure28).
Figure28
7.Startthesnowthrowerpullingtherecoilstarteror
pressingtheelectric-starterbutton(Figure29).
Figure29
1.Electric-starterbutton3.Recoilstarter
2.Electricstarterplug
Note:Tousetheelectricstarter,connectapower
cordtotheelectricstarterplugrstandthentoa
poweroutlet.
Important:Topreventdamagingtheelectric
starter,runitinshortcycles(5seconds
maximum,thenwaitoneminutebeforetryingto
13

startitagain).Iftheenginestilldoesnotstart,
takethesnowthrowertoanAuthorizedService
Dealerforservice.
8.Disconnectthepowercordfromthepoweroutlet
rstandthenfromthesnowthrower(electricstart
only).
9.Allowtheenginetowarmupforseveralminutes,
movethechoketowardtheRunposition.Wait
fortheenginetorunsmoothlybeforeeachchoke
adjustment.
Ifyouleavethesnowthrowerpluggedintoa
poweroutlet,someonecaninadvertentlystart
thesnowthrowerandinjurepeopleordamage
property.
Unplugthepowercordwheneveryouarenot
startingthesnowthrower.
StoppingtheEngine
1.MovethethrottletotheSlowposition,andthento
theStopposition(Figure30).
Figure30
2.Waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheignitionkey.
4.Closethefuelshutoffvalvebyrotatingitclockwise
(Figure31).
Figure31
5.Pulltherecoilstarter3or4times.Thishelpsprevent
therecoilstarterfromfreezingup.
OperatingtheTractionDrive
Ifthetractiondriveisnotproperlyadjusted,
thesnowthrowermaymoveinthedirection
oppositeofwhatyouintended,causinginjury
and/orpropertydamage.
Carefullycheckthetractiondriveandadjust
itproperly,ifnecessary;refertoCheckingthe
TractionDriveOperationinSetupformore
information.
Important:Ifthesnowthrowermoveswhenthe
tractionleverisinthereleasedposition,checkthe
tractioncable(refertoCheckingandAdjusting
theTractionCable)ortakethesnowthrowertoan
AuthorizedServiceDealerforservice.
1.Toengagethetractiondrive,squeezethelefthand
(traction)levertothehand-grip(Figure32).
Figure32
2.Tostopthetractiondrive,releasethetractionlever.
14

UsingtheWheelClutchLevers
Thewheelclutchleversallowyoutomomentarily
disengagethedrivetooneorbothwheelswiththe
tractiondriveleverstillengaged.Thisenablesyouto
turnandmaneuverthesnowthrowereasily.
Note:Holdingdownthetractionleveragainstthe
handleengagesthetractiondrivetobothwheels.
Toturnthesnowthrowertotheright,liftuponthe
rightwheelclutchleverandsqueezeittowardthehandle
(Figure33).
Figure33
Note:Thisdisengagesthedrivetotherightwheelwhile
theleftwheelcontinuesdriving,andthesnowthrower
turnstotheright.
Note:Similarly,squeezingtheleftwheelclutchlever
turnsthesnowthrowertotheleft.
Whenyoucompletetheturn,releasethewheelclutch
lever,andthedrivere-engagesbothwheels(Figure34).
Figure34
Momentarilysqueezingandreleasingtheleftorright
wheelclutchleveralsoallowsforsteeringadjustmentsto
keepthesnowthrowergoinginastraightline,especially
indeepsnow .
Squeezingbothwheelclutchleverssimultaneously
disengagesthedrivetobothwheels.Thisenablesyou
tomanuallymovethesnowthrowerbackwardwithout
stoppingtoshiftitintoareversegear.Italsoallowsyou
tomaneuverandtransportthesnowthrowermoreeasily
whentheengineisnotrunning.
OperatingtheSpeedSelector
Thespeedselectorhas6forwardand2reversegears.
Tochangespeeds,releasethetractionleverandshiftthe
speedselectorlevertothedesiredposition(Figure35).
Theleverlocksinanotchateachspeedselection.
Figure35
OperatingtheAuger/Impeller
Drive
1.Toengagetheauger/impellerdrive,squeezethe
righthand(auger/impeller)levertothehandgrip
(Figure36).
Figure36
2.Tostoptheaugerandimpeller,releasetheright
handlever.
Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,the
tractionleverlockstheauger/impellerlever
down,freeingyourrighthand.Toreleaseboth
levers,simplyreleasethelefthand(traction)
lever.
3.Iftheaugerandimpellercontinuetorotatewhen
youreleasetheauger/impellerlever,donotoperate
thesnowthrower.Checktheauger/impellercable
(refertoCheckingandAdjustingtheAuger/Impeller
Cable)andadjustitifnecessary.Otherwise,takethe
snowthrowertoanAuthorizedDealerforservice.
15

Iftheaugerandimpellercontinuetorotate
whenyoureleasetheauger/impellerlever,you
couldseriouslyinjureyourselforothers.
Donotoperatethesnowthrower.Takeittoan
AuthorizedServiceDealerforservice.
OperatingtheQuickStick®
HoldthebluetriggercapdowntousetheQuickStick
tomovethedischargechuteandthechutedeector.
Releasethetriggercaptolockthedischargechuteand
chutedeectorintoposition(Figure37).
Figure37
MovingtheDischargeChute
HoldthebluetriggercapdownandmovetheQuick
Sticktothelefttomovethedischargechutetotheleft;
movetheQuickSticktotherighttomovethedischarge
chutetotheright(Figure38).
Figure38
•Ifthechutedoesnotmove,refertoAdjustingthe
DischargeChuteLatch.
•Ifthechutedoesnotturnasfartotheleftasitdoes
totheright,ensurethatthecableisroutedtothe
insideofthehandles.RefertoInstallingtheUpper
Handle.
•Ifthechutedoesnotlockintoplacewhenyourelease
thetriggercap,refertoAdjustingtheDischarge
ChuteLatch.
MovingtheChuteDeector
HoldthebluetriggercapdownandmovetheQuick
Stickforwardtolowerthechutedeector;moveit
rearwardtoraisethechutedeector(Figure39).
Figure39
UncloggingtheDischarge
Chute
Iftheauger/impellerisrunningbutthereisnosnow
comingoutofthedischargechute,thedischargechute
maybeclogged.
•Tounclogthedischargechute,stayintheoperating
positionandreleasethelefthand(traction)lever.
Whilerunningtheauger/impeller,pushdownon
thehandlestoraisethefrontofthesnowthrower
afewinches(centimeters)offthepavement.Then
liftthehandlesquicklytobumpthefrontofthe
snowthroweronthepavement.Repeatifnecessary
untilastreamofsnowcomesoutthedischargechute.
•Ifyoucannotunclogthedischargechutebybumping
thefrontofthesnowthrower,stoptheengine,
waitforallmovingpartstostop,anduseastick;
neveruseyourhand.
Important:Uncloggingthedischargechuteby
bumpingthefrontofthesnowthroweronthe
pavementmaycausetheskidstomove.Adjust
theskidsandtightentheskidboltssecurely.
16

PreventingFreeze-up
•Insnowyandcoldconditions,somecontrolsand
movingpartsmayfreeze.Donotuseexcessive
forcewhentryingtooperatefrozencontrols.If
youhavedifcultyoperatinganycontrolorpart,
starttheengineandletitrunforafewminutes.
•Afterusingthesnowthrower,lettheenginerunfora
fewminutestopreventmovingpartsfromfreezing.
Engagetheauger/impellertoclearanyremaining
snowfrominsidethehousing.RotatetheQuick
Sticktopreventitfromfreezing.Stoptheengine,
waitforallmovingpartstostop,andremoveallice
andsnowfromthesnowthrower.
•Withtheengineoff,pulltherecoilstarterhandle
severaltimesandpushtheelectric-starterbutton
oncetopreventtherecoilandelectricstartersfrom
freezingup.
OperatingTips
Whenthesnowthrowerisinoperation,the
impellerandaugercanrotateandcutoffor
injurehandsandfeet.
•Beforeadjusting,cleaning,inspecting,
troubleshooting,orrepairingthe
snowthrower,stoptheengineandwaitfor
allmovingpartstostop.Disconnectthe
wirefromthesparkplugandkeepitaway
fromtheplugtopreventsomeonefrom
accidentallystartingtheengine.
•Removeanobstructionfromthedischarge
chute;refertoUncloggingtheDischarge
Chute.Ifnecessary,useastick,notyour
hands,toremoveanobstructionfromthe
dischargechute.
•Staybehindthehandlesandawayfrom
thedischargeopeningwhileoperatingthe
snowthrower.
•Keepface,hands,feet,andanyotherpartof
yourbodyorclothingawayfromconcealed,
moving,orrotatingparts.
Therotorbladescanthrowstones,toys,and
otherforeignobjectsandcauseseriouspersonal
injurytotheoperatorortobystanders.
•Keeptheareatobeclearedfreeofallobjects
thattherotorbladescouldpickupand
throw.
•Keepallchildrenandpetsawayfromthe
areaofoperation.
•AlwayssetthethrottletotheFastpositionwhen
throwingsnow .
•Iftheengineslowsdownunderaloadorthewheels
slip,shiftthesnowthrowerintoalowergear.
•Ifthefrontofthesnowthrowerridesup,shiftthe
snowthrowerintoalowergear.Ifthefrontcontinues
torideup,liftuponthehandles.
•Thepivotingscraperonthesnowthrowerisnot
recommendedforuseongravelsurfaces.Butif
youmustusethesnowthroweronagravelsurface,
adjusttheskidsfurtherdowntopreventthepivoting
scraperfrompickinguprocks.
17

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst2hours•Inspectthetractioncableandadjustitifnecessary.
•Inspecttheauger/impellercableandadjustitifnecessary.
Aftertherst5hours•Changetheengineoil.
Beforeeachuseordaily•Checktheengineoillevelandaddoilifnecessary.
Every50hours•Changetheengineoil.Changetheengineoilevery25operatinghourswhen
operatingtheengineunderaheavyload.
Every100hours•Replacethesparkplug.
Yearly
•Checktheskidsandadjustthemifnecessary.
•Inspectthetractioncableandadjustorreplaceitifnecessary.
•Inspecttheauger/impellercableandadjustorreplaceitifnecessary.
•Checktheaugergearboxoilandaddoilifnecessary.
•Lubricatethehexshaft.
Yearlyorbeforestorage
•Checktheairpressureinthetiresandinatethemto17–20psi(116–137kPa).
•Drainthegasolineandruntheenginetodryoutthefueltankandthecarburetorat
theendoftheseason.
•HaveanAuthorizedServiceDealerinspectandreplacethetractiondrivebeltand/or
theauger/impellerdrivebelt,ifnecessary.
Important:Youcanndmoreinformationaboutmaintainingandservicingyoursnowthrowerat
www.Toro.com.
Important:Refertoyourengineoperator’smanualforadditionalmaintenanceprocedures.Forengine
adjustments,repairs,orwarrantyservicenotcoveredinthismanual,contactanAuthorizedBriggs
&StrattonServicingDealer.
PreparingforMaintenance
1.Movethesnowthrowertoalevelsurface.
2.Stoptheengineandwaitforallmovingpartstostop.
3.Disconnectthesparkplugwire.RefertoReplacing
theSparkPlug.
18

CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily—Check
theengineoillevelandaddoilif
necessary.
1.Removethedipstick,wipeitclean,thenfullyinstall
thedipstick.
2.Removethedipstickandchecktheoillevel
(Figure40).IftheoillevelisbelowtheAddmark
onthedipstick,addoil.RefertoFillingtheEngine
withOil.
Figure40
CheckingandAdjustingthe
Skids
ServiceInterval:Yearly—Checktheskidsandadjust
themifnecessary.
Checktheskidstoensurethattheaugerdoesnot
contactthepavedorgravelsurface.Adjusttheskidsas
neededtocompensateforwear.
1.Checkthetirepressure.RefertoCheckingtheTire
Pressure.
2.Movethesnowthrowertoalevelsurface.
3.Loosenthenutsthatsecurebothskidstothe
augersidesuntiltheskidsslideupanddowneasily
(Figure41).
Figure41
1.Skid
4.Pushdownonthehandlestoallowthepivoting
scrapertomovefullyforward,thensetthefrontof
thesnowthrowerdownsothatthefrontedgeofthe
pivotingscrapercontactstheground(Figure42).
Figure42
1.Pivotingscraper
5.Movetheskidsdownuntiltheyareevenwiththe
ground.
Note:Forasmoothsurface,youcansettheskids
slightlyhighertoincreasethescrapingaction,but
settheskidsfarenoughdowntopreventtheauger
bladesfromcontactingtheground.
Note:Thepivotingscraperonthesnowthrower
isnotrecommendedforuseongravelsurfaces.
Butifyoumustusethesnowthroweronagravel
surface,adjusttheskidsfurtherdowntopreventthe
pivotingscraperfrompickinguprocks.
6.Firmlytightenthenutsthatsecurebothskidstothe
augersides.
Note:Iftheskidsbecomeexcessivelyworn,you
canturnthemoverandsettheunusedsidetoward
thepavement.
19

CheckingandAdjustingthe
TractionCable
ServiceInterval:Aftertherst2hours—Inspect
thetractioncableandadjustitif
necessary.
Yearly—Inspectthetractioncable
andadjustorreplaceitifnecessary.
Ifthesnowthrowerdoesnotdriveintheforwardor
reversespeedsoritdriveswhenyoureleasethetraction
lever,adjustthetractioncable.
Withthetractionleverdisengaged,checkthepininthe
elongatedslotintheleftsideofthesnowthrowerabove
thetire.Thereshouldbeagapof1/32to1/16inch(1
to1.5mm)fromthefrontoftheslottothefrontedge
ofthepin(Figure43).
Figure43
1.Pin
Ifthelefthand(traction)cableisnotproperlyadjusted,
dothefollowingsteps:
1.Loosenthejamnut.
2.Loosenortightentheturnbuckletoadjustthepin
untilitisthepropergapfromthefrontedgeofthe
slot.
3.Tightenthejamnut(Figure44).
Figure44
1.Jamnut2.Turnbuckle
CheckingandAdjustingthe
Auger/ImpellerCable
ServiceInterval:Aftertherst2hours—Inspectthe
auger/impellercableandadjustitif
necessary.
Yearly—Inspecttheauger/impeller
cableandadjustorreplaceitif
necessary.
1.Removethe2screwsfromtherightsideofthebelt
coverasshown.
2.Liftuptherightsideofthebeltcover(Figure45).
Figure45
3.Withtheauger/impellerleverdisengaged,ensure
thatthegapbetweentheaugerclutchassemblyand
thetabis1/16inch(1.5mm)(Figure46).
Figure46
1.Tab
4.Iftheauger/impellercableisnotproperlyadjusted,
dothefollowingsteps:
5.Loosenthejamnut(Figure47).
20
