FormNo.3385-226RevA
PowerMax724/826OESnowthrower
ModelNo.37772—SerialNo.315000001andUp
ModelNo.37775—SerialNo.315000001andUp
Operator'sManual
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Introduction
Thismachineisintendedtobeusedbyresidential
homeownersorprofessional,hiredoperators.Itis
designedforremovingsnowfrompavedsurfaces,such
asdrivewaysandsidewalks,andothersurfacesfor
trafconresidentialorcommercialproperties.Itisnot
designedforremovingmaterialsotherthansnow,noris
amodelwithapivotingscraperdesignedforclearingoff
gravelsurfaces.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourmachineproperlyandtoavoidinjuryand
machinedamage.Youareresponsibleforoperatingthe
machineproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comformachine
andaccessoryinformation,helpndingadealer,ortoregister
yourmachine.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourmachineready.Figure1identiesthelocationofthe
modelandserialnumbersonthemachine.Writethenumbers
inthespaceprovided.
g018884
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Contents
Introduction..................................................................1
Safety...........................................................................2
Training.................................................................3
Preparation.............................................................3
Operation...............................................................3
ClearingaCloggedDischargeChute..........................4
MaintenanceandStorage..........................................4
ToroSnowthrowerSafety.........................................4
SafetyandInstructionalDecals.................................5
©2014—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3385-226*A

Setup............................................................................7
1InstallingtheUpperHandle....................................7
2InstallingtheTractionControlLinkage....................8
3InstallingtheChute...............................................9
4InstallingtheChuteControlRod............................10
5CheckingtheEngineOilLevel...............................10
6CheckingtheTirePressure....................................11
7CheckingtheSkidsandScraper..............................11
8CheckingtheTractionDriveOperation...................11
ProductOverview.........................................................12
Operation....................................................................13
FreewheelingorUsingtheSelf-propelDrive...............13
FillingtheFuelTank...............................................13
StartingtheEngine.................................................14
StoppingtheEngine...............................................16
OperatingtheTractionDrive...................................16
OperatingtheSpeedSelector...................................16
OperatingtheAuger/ImpellerDrive.........................17
OperatingtheQuickStick™....................................17
UncloggingtheDischargeChute..............................18
PreventingFreeze-up..............................................18
OperatingTips......................................................18
Maintenance.................................................................19
RecommendedMaintenanceSchedule(s)......................19
............................................................................19
PreparingforMaintenance.......................................19
CheckingtheEngineOilLevel.................................19
CheckingandAdjustingtheSkidsand
Scraper..............................................................20
CheckingandAdjustingtheTractionCable................20
CheckingandAdjustingtheAuger/Impeller
Cable................................................................21
CheckingtheAugerGearboxOilLevel......................21
ChangingtheEngineOil.........................................22
LubricatingtheHexShaft........................................22
ReplacingtheSparkPlug.........................................23
AdjustingtheDischargeChuteLatch........................24
ReplacingtheDriveBelts.........................................24
Storage........................................................................24
PreparingtheMachineforStorage............................24
RemovingtheMachinefromStorage.........................24
Troubleshooting...........................................................25
Safety
Before Operating
?
?
Read and understand the contents of this
manual before operating the snowthrower .
Become familiar with all controls and know
how to stop the engine quickly .
Operator 's
Position
The low-speed auger has a moving pinch
point close to the opening.
Caution: Improper use may result in
loss of fingers, hands, or feet.
There is a high-speed
impeller close to the
opening.
ThismachinemeetsorexceedstheB71.3specications
oftheAmericanNationalStandardsInstituteineffect
atthetimeofproduction.
Readandunderstandthecontentsofthismanualbefore
theengineiseverstarted.
Thisisthesafetyalertsymbol.Itisusedtoalertyou
topotentialpersonalinjuryhazards.Obeyallsafety
messagesthatfollowthissymboltoavoidpossibleinjury
ordeath.
Improperlyusingormaintainingthismachinecould
resultininjuryordeath.Toreducethispotential,
complywiththefollowingsafetyinstructions.
2

Training
•Read,understandandfollowallinstructionsonthe
machineandinthemanual(s)beforeoperatingthis
machine.Bethoroughlyfamiliarwiththecontrolsand
theproperuseofthemachine.Knowhowtostopthe
machineanddisengagethecontrolsquickly.
•Neverallowchildrentooperatethemachine.Neverallow
adultstooperatethemachinewithoutproperinstruction.
•Keeptheareaofoperationclearofallpersons,particularly
smallchildren.
•Exercisecautiontoavoidslippingorfalling,especially
whenoperatingthemachineinreverse.
Preparation
•Thoroughlyinspecttheareawherethemachineistobe
usedandremovealldoormats,sleds,boards,wires,and
otherforeignobjects.
•Disengageallclutchesandshiftintoneutralbefore
startingtheengine.
•Donotoperatethemachinewithoutwearingadequate
wintergarments.Avoidloosettingclothingthatcanget
caughtinmovingparts.Wearfootwearthatwillimprove
footingonslipperysurfaces.
•Handlefuelwithcare;itishighlyammable.
–Useanapprovedfuelcontainer.
–Neveraddfueltoarunningengineorhotengine.
–Fillfueltankoutdoorswithextremecare.Neverll
fueltankindoors.
–Neverllcontainersinsideavehicleoronatruckor
trailerbedwithaplasticliner.Alwaysplacecontainers
ontheground,awayfromyourvehicle,beforelling.
–Whenpractical,removegas-poweredmachineryfrom
thetruckortrailerandrefuelitontheground.If
thisisnotpossible,thenrefuelsuchmachineryona
trailerwithaportablecontainer,ratherthanfroma
gasolinedispensernozzle.
–Keepthenozzleincontactwiththerimofthefuel
tankorcontaineropeningatalltimes,untilrefueling
iscomplete.Donotuseanozzlelock-opendevice.
–Replacegasolinecapsecurelyandwipeupspilledfuel.
–Iffuelisspilledonclothing,changeclothing
immediately.
•Useextensioncordsandreceptaclesasspeciedby
themanufacturerforallmachineswithelectricstarting
motors.
•Adjustthecollectorhousingtocleargravelorcrushed
rocksurface.
•Neverattempttomakeanyadjustmentswhiletheengine
isrunning(exceptwhenspecicallyrecommendedby
manufacturer).
•Alwayswearsafetyglassesoreyeshieldsduringoperation
orwhileperforminganadjustmentorrepairtoprotect
eyesfromforeignobjectsthatmaybethrownfromthe
machine.
Operation
•Donotputhandsorfeetnearorunderrotatingparts.
Keepclearofthedischargeopeningatalltimes.
•Exerciseextremecautionwhenoperatingonorcrossing
graveldrives,walks,orroads.Stayalertforhidden
hazardsortrafc.
•Afterstrikingaforeignobject,stoptheengine,remove
theignitionkey,thoroughlyinspectthemachineforany
damage,andrepairthedamagebeforerestartingand
operatingthemachine.
•Ifthemachineshouldstarttovibrateabnormally,stopthe
engineandcheckimmediatelyforthecause.Vibrationis
generallyawarningoftrouble.
•Stoptheenginewheneveryouleavetheoperating
position,beforeuncloggingtheauger/impellerhousing
ordischargechute,andwhenmakinganyrepairs,
adjustmentsorinspections.
•Whencleaning,repairingorinspectingthemachine,stop
theengineandmakecertaintheauger/impellerandall
movingpartshavestopped.Disconnectthesparkplug
wireandkeepthewireawayfromtheplugtoprevent
someonefromaccidentallystartingtheengine.
•Donotruntheengineindoors,exceptwhenstarting
theengineandfortransportingthemachineinorout
ofthebuilding.Opentheoutsidedoors;exhaustfumes
aredangerous.
•Exerciseextremecautionwhenoperatingonslopes.
•Neveroperatethemachinewithoutproperguards,and
othersafetyprotectivedevicesinplaceandworking.
•Neverdirectthedischargetowardpeopleorareaswhere
propertydamagecanoccur.Keepchildrenandothers
away.
•Donotoverloadthemachinecapacitybyattemptingto
clearsnowattoofastarate.
•Neveroperatethemachineathightransportspeeds
onslipperysurfaces.Lookbehindandusecarewhen
operatinginreverse.
•Disengagepowertotheauger/impellerwhenmachineis
transportedornotinuse.
•Useonlyattachmentsandaccessoriesapprovedbythe
manufacturerofthemachine(suchaswheelweights,
counterweights,orcabs).
•Neveroperatethemachinewithoutgoodvisibilityor
light.Alwaysbesureofyourfooting,andkeeparm
holdonthehandles.Walk;neverrun.
•Nevertouchahotengineormufer.
3

ClearingaCloggedDischarge
Chute
WARNING
Handcontactwiththerotatingrotorbladesinside
thedischargechuteisthemostcommoncauseof
injuryassociatedwithmachines.Neveruseyour
handtocleanoutthedischargechute.
Toclearthechute:
•Shuttheengineoff!
•Wait10secondstobesuretherotorbladeshavestopped
rotating.
•Alwaysusethecleanouttoolmountedonthe
snowthrower,notyourhands.
MaintenanceandStorage
•Checkallfastenersatfrequentintervalsforproper
tightnesstobesurethemachineisinsafeworking
condition.
•Neverstorethemachinewithfuelinthefueltankinsidea
buildingwhereignitionsourcesarepresentsuchashot
waterheaters,spaceheaters,orclothesdryers.Allowthe
enginetocoolbeforestoringinanyenclosure.
•AlwaysrefertotheOperator’sManualforimportantdetails
ifthemachineistobestoredforanextendedperiod.
•Maintainorreplacesafetyandinstructionlabels,as
necessary.
•Runthemachineafewminutesafterthrowingsnowto
preventfreeze-upoftherotorblades.
ToroSnowthrowerSafety
ThefollowinglistcontainssafetyinformationspecictoToro
machinesorothersafetyinformationthatyoumustknow.
•Rotatingauger/impellercanamputateorinjure
ngersorhands.Staybehindthehandlesandawayfrom
thedischargeopeningwhileoperatingthemachine.Keep
yourface,hands,feet,andanyotherpartofyour
bodyorclothingawayfrommovingorrotatingparts.
•Beforeadjusting,cleaning,inspecting,troubleshooting,or
repairingthemachine,stoptheengine,removethekey,
andwaitforallmovingpartstostop.Disconnect
thewirefromthesparkplugandkeepitawayfrom
thesparkplugtopreventsomeonefromaccidentally
startingtheengine.
•Beforeleavingtheoperatingposition,stoptheengine,
removethekey,andwaitforallmovingpartstostop.
•Tounclogthedischargechute,stayintheoperating
positionandreleasethelefthand(traction)lever.While
runningtheauger/impeller,pushdownonthehandlesto
raisethefrontofthemachineafewinches(centimeters)
offthepavement.Thenliftthehandlesquicklytobump
thefrontofthemachineonthepavement.Repeatif
necessaryuntilastreamofsnowcomesoutthedischarge
chute.
•Ifyoucannotunclogthedischargechutebybumping
thefrontofthemachine,stoptheengine,waitfor
allmovingpartstostop,andusethecleanouttool;
neveruseyourhand.
•Ifashield,safetydevice,ordecalisdamaged,illegible,or
lost,repairorreplaceitbeforebeginningoperation.
•Donotsmokewhilehandlinggasoline.
•Donotusethemachineonaroof.
•Donottouchtheenginewhileitisrunningorsoonafter
ithasstoppedbecausetheenginemaybehotenoughto
causeaburn.
•Performonlythosemaintenanceinstructionsdescribedin
thismanual.Beforeperforminganymaintenance,service,
oradjustment,stoptheengine,removethekey,and
disconnectthewirefromthesparkplug.Ifmajorrepairs
areeverneeded,contactyourAuthorizedServiceDealer.
•Donotchangethegovernorsettingsontheengine.
•Whenstoringthemachineformorethan30days,drain
thefuelfromthefueltanktopreventapotentialhazard.
Storefuelinanapprovedfuelcontainer.Removethekey
fromtheignitionswitchbeforestoringthemachine.
•PurchaseonlygenuineTororeplacementpartsand
accessories.
4

SafetyandInstructional
Decals
Important:Safetyandinstructiondecalsarelocated
nearareasofpotentialdanger.Replacedamageddecals.
121–6823
1.Fast3.Slow
2.Forwardspeeds4.Reversespeeds
121–6817
1.Cuttingdismemberment,impellerandcutting
dismemberment,augerhazards—keepbystandersasafe
distancefromthesnowthrower.
121–1239
Reorderpartno.121–1215
121–1240
Reorderpartno.120–7194
1.Tractiondrive—squeezethelevertoengage;releasethe
levertodisengage.
4.Cuttingdismembermenthazard,impeller—keepaway
frommovingparts;removetheignitionkeyandreadthe
instructionsbeforeservicingorperformingmaintenance.
2.Warning—readtheOperator’sManual.5.Thrownobjecthazard—keepbystandersasafedistancefrom
thesnowthrower.
3.Cutting/dismembermenthazard,impeller—donotplace
yourhandinthechute;stoptheenginebeforeleavingthe
operatingposition,usethetooltoclearthechute.
6.Auger/impellerdrive—squeezethelevertoengage;release
thelevertodisengage.
5

Briggs&StrattonPartNo.273676
1.Stop3.Fast
2.Slow
Briggs&StrattonPartNo.275949
1.Chokeon(Choke)2.Chokeoff(Run)
Briggs&StrattonPartNo.276925
1.Warning—readthe
Operator'sManual.
3.Warning—toxicgas
inhalationhazard.
2.Warning—rehazard.4.Warning—hot
surface/burnhazard.
Briggs&StrattonPartNo.277566
1.Whenstartingacold
engine,closethechoke
andpresstheprimertwo
times.
2.Whenstartingawarm
engine,openthechoke
anddonotpressthe
primer.
Briggs&StrattonPartNo.277588
1.Primer3.Ignitionkeyout
(Engine—Stop)
2.Ignitionkeyin
(Engine—Run)
Briggs&StrattonPartNo.278866
1.Fuel—On2.Fuel—Off
6

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
Handlebolts2
Curvedwashers2
1Locknuts2
Installtheupperhandle.
Hairpincotter2
2Flatwasher3Installthetractioncontrollinkage.
Nut2
Carriagebolt2
3Flatwasher2
Installthechute.
Carriagebolts2
4Locknuts2Installthechutecontrolrod.
5Nopartsrequired–Checktheengineoillevel.
6Nopartsrequired–Checkthetirepressure.
7Nopartsrequired–Checktheskidsandscraper.
8Nopartsrequired–Checktheoperationofthetractiondrive.
1
InstallingtheUpperHandle
Partsneededforthisprocedure:
2Handlebolts
2Curvedwashers
2Locknuts
Procedure
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure3).
2.Install2handlebolts,2curvedwashers,and2locknuts
inthelowerhandleholes(Figure3).
g019003
Figure3
7

2
InstallingtheTractionControl
Linkage
Partsneededforthisprocedure:
2Hairpincotter
3Flatwasher
Procedure
1.Insertthelowerendoftherodintothelowerlinkarm
sothatthebentendofthespeedcontrolrodfaces
rearward(Figure4).
g019004
Figure4
2.Securethelowerendofthespeedcontrolrodwitha
atwasherandahairpincotter(Figure4).
3.Placeaatwasheronthetrunnion(Figure5).
Figure5
1.Speedselectorlever3.Innerwasher
2.Trunnion4.Outerwasher
4.ShiftthespeedselectorleverintoPositionR2.
5.Rotatethelowerlinkarmfullyupward
(counterclockwise)(Figure6).
g019378
Figure6
6.Pulluponthespeedcontrolrodandinsertthetrunnion
intotheholeinthespeedselectorlever(Figure5).
Note:Ifthetrunniondoesnottintothehole
whenyouliftuponthespeedcontrolrod,rotatethe
trunnionupwardordownwardonthespeedcontrol
roduntilitts.
7.Securethetrunnionandupperendofthespeedcontrol
rodwithawasherandahairpincotter.
Note:Foreasierinstallation,lookdownthroughthe
openinginthespeedselector(Figure7).
Figure7
1.Speedselector
8

3
InstallingtheChute
Partsneededforthisprocedure:
2Nut
2Carriagebolt
2Flatwasher
Procedure
1.Placethechuteontheframeandthealignthedischarge
chutemounttothechutesupport.
3
1
2
g019379
Figure8
1.Carriagebolt3.Nut
2.Flatwasher
2.Securethedischargechutemountusing2bolts,2nuts,
and2atwashers.
9

4
InstallingtheChuteControl
Rod
Partsneededforthisprocedure:
2Carriagebolts
2Locknuts
Procedure
1.UnwraptheQuickStickandrotateitsothatitis
uprightandinthecenter.
2.Holdthebluetriggercapdownandpulltheleverfully
rearward.
Note:Thedischargechuteanddeectorshouldface
forward.Iftheydonot,holdthebluetriggercap
down(butdonotmovetheQuickStick)androtatethe
dischargechuteuntiltheydo.
3.Aligntheattenedbackendofthelongchutecontrol
rodwiththeattenedfrontendoftheshortrod
thatextendsfromthecontrolpanelsothattheynest
together(Figure9).
Figure9
1.Shortrod2.Longchutecontrolrod
4.Insertthefrontendoftherodintotheopeningin
thebackofthechutegearcoveruntilitslidesintothe
chutegear(Figure10).
g018885
Figure10
5.Aligntheholesinthenestedendsoftherodsand
insert2carriagebolts(intheloosepartsbag)through
theshortrodfromtheleftsideofthemachine(from
theoperatingposition).
6.Insertthecableclipthatsupportsthedeectorcable
ontotheforwardcarriagebolt,andsecurethecarriage
boltswithlocknutsfromtheloosepartsbag(Figure
11).
Figure11
1.Cableclip2.Deectorcable
7.HoldthebluetriggercapdownandrotatetheQuick
Stickinacircletoensurethatthechuteanddeector
operatesmoothly.
5
CheckingtheEngineOilLevel
NoPartsRequired
Procedure
Yourmachinecomeswithoilintheenginecrankcase.
10

Note:Beforestartingtheengine,checktheoilleveland
addoilifnecessary.
UseautomotivedetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.Refertoyourengineowner's
manual.
UseFigure12belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:
g019049
Figure12
EngineOilCapacities
ModelEngineOilCapacity
37771
37772
18to20oz.(0.53to0.59l)
1.Removethedipstickandslowlypouroilintotheoil
lltubetoraisetheoilleveltotheFullmarkonthe
dipstick.Donotoverll.(Figure13).
g018886
Figure13
2.Installthedipsticksecurely.
Note:Donotspilloilaroundtheoillltube;oilcould
leakontotractionpartsandcausethetractiontoslip.
6
CheckingtheTirePressure
NoPartsRequired
Procedure
Thetiresareoverinatedatthefactoryforshipping.Reduce
thepressureequallyinbothtirestobetween17and20psi
(116and137kPa).
7
CheckingtheSkidsand
Scraper
NoPartsRequired
Procedure
RefertoCheckingandAdjustingtheSkidsandScraperin
Maintenance.
8
CheckingtheTractionDrive
Operation
NoPartsRequired
Procedure
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
Note:Tocheckthetractiondriveoperation,theself-propel
featuremustbeengagedbyensuringthewheelsarepinned
intheaxle.Referto(page).
1.Starttheengine;refertoStartingtheEngine.
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector.
11

3.Squeezethelefthand(traction)levertothehand-grip
(Figure14).
Figure14
Themachineshouldmoverearward.Ifthemachine
doesnotmoveormovesforward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure5).
C.Turnthetrunniondownward(clockwise)onthe
speedcontrolrod(Figure5).
D.Connectthetrunniontothespeedselectorlever
(Figure5).
4.Releasethetractionlever.
5.MovethespeedselectortothePosition1;referto
OperatingtheSpeedSelector.
6.Squeezethelefthand(traction)levertothehand-grip
(Figure14).
Themachineshouldmoveforward.Ifthemachine
doesnotmoveormovesrearward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure5).
C.Turnthetrunnionupward(counterclockwise)on
thespeedcontrolrod(Figure5).
D.Connectthetrunniontothespeedselectorlever
(Figure5).
7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable)or
takethemachinetoanAuthorizedServiceDealerfor
service.
ProductOverview
g018887
Figure15
1.Hand-grip(2)9.Dischargechute
2.Auger/impellerlever10.Scraper
3.Speedselectorlever11.Auger
4.QuickStick™discharge
chutecontrol
12.Skid(2)
5.Tractionlever13.Electricstarterbutton
6.Fueltankcap14.Electricstarterplug-in
7.Engineoillltube/dipstick15.Snowcleanouttool
8.Chutedeector
g018888
Figure16
1.Choke5.Recoilstarter
2.Ignitionswitch6.Oildrainplug
3.Fuelshutoffvalve7.Primer
4.Throttle
12

Figure17
1.Snowcleanouttool(attachedtothehandle)
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
FreewheelingorUsingthe
Self-propelDrive
Youcanoperatethesnowthrowerwiththeself-propelfeature
engagedordisengaged(freewheeling).
Tofreewheel,slidethewheelsinwardandinserttheaxle
pinsthroughtheaxleholes,butnotthroughthewheelhubs
(Figure18).
g019015
Figure18
Toself-propel,axlepinthroughtheholesinthewheelhubs
andtheinneraxleholes(Figure19).
g019014
Figure19
FillingtheFuelTank
DANGER
Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.
•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
onthegroundbeforelling,notinavehicleor
onanobject.
•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.
•Donothandlegasolinewhensmokingoraround
anopenameorsparks.
•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.
•Forbestresults,useonlyclean,fresh,unleadedgasoline
withanoctaneratingof87orhigher((R+M)/2rating
method).
•Oxygenatedfuelwithupto10%ethanolor15%MTBE
byvolumeisacceptable.
•DoNotuseethanolblendsofgasoline(suchasE15
orE85)withmorethan10%ethanolbyvolume.
Performanceproblemsand/orenginedamagemayresult
whichmaynotbecoveredunderwarranty.
•DoNotusegasolinecontainingmethanol.
•DoNotstorefueleitherinthefueltankorfuelcontainers
overthewinterunlessafuelstabilizerisused.
•DoNotaddoiltogasoline.
Important:Toreducestartingproblems,addfuel
stabilizertothefuelallseason,mixingitwithgasoline
lessthan30daysold.
Do not add oil to the gasoline.
13

4.Firmlypushintheprimerwithyourthumb2times
(15°For-9°Corabove)or4times(below15°For
-9°C),holdingtheprimerinforasecondbefore
releasingiteachtime(Figure23).
g018891
Figure23
5.RotatethechoketotheChokeposition(Figure24).
g018892
Figure24
6.MovethethrottletotheFastposition(Figure25).
Figure25
7.Startthemachinepullingtherecoilstarterorpressing
theelectric-starterbutton(Figure26).
g018893
Figure26
1.Electric-starterbutton3.Recoilstarter
2.Electricstarterplug-in
Note:Tousetheelectricstarter,connectapower
cordtotheelectricstarterplug-inrstandthentoa
poweroutlet.UseonlyaUL-listed,16-gaugeextension
cordrecommendedforoutdoorusethatisnotlonger
than50feet(15m).
WARNING
Theelectricalcordcanbecomedamaged,
causingashockorre.
Thoroughlyinspecttheelectricalcordbefore
usingthemachine.Ifthecordisdamaged,
donotoperatethemachine.Replaceorrepair
thedamagedcordimmediately.Contactan
AuthorizedServiceDealerforassistance.
Important:Topreventdamagingtheelectric
starter,runitinshortcycles(5secondsmaximum,
thenwaitoneminutebeforetryingtostartit
again).Iftheenginestilldoesnotstart,take
themachinetoanAuthorizedServiceDealerfor
service.
8.Disconnectthepowercordfromthepoweroutletrst
andthenfromthemachine(electricstartonly).
9.Allowtheenginetowarmupforseveralminutes,move
thechoketowardtheRunposition.Waitfortheengine
torunsmoothlybeforeeachchokeadjustment.
15

CAUTION
Ifyouleavethemachinepluggedintoa
poweroutlet,someonecaninadvertentlystart
themachineandinjurepeopleordamage
property.
Unplugthepowercordwheneveryouarenot
startingthemachine.
StoppingtheEngine
1.MovethethrottletotheSlowposition,andthentothe
Stopposition(Figure27).
Figure27
2.Waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheignitionkey.
4.Closethefuelshutoffvalvebyrotatingitclockwise
(Figure28).
Figure28
5.Pulltherecoilstarter3or4times.Thishelpsprevent
therecoilstarterfromfreezingup.
OperatingtheTractionDrive
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary;refertoCheckingtheTraction
DriveOperationinSetupformoreinformation.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable)or
takethemachinetoanAuthorizedServiceDealerfor
service.
Important:Tooperatethetractiondrive,youmust
operatethemachinewiththeself-propelfeature
engaged.RefertoFreewheelingorUsingtheSelf-propel
Drive.
1.Toengagethetractiondrive,squeezethelefthand
(traction)levertothehandgrip(Figure29).
Figure29
2.Tostopthetractiondrive,releasethetractionlever.
OperatingtheSpeedSelector
Thespeedselectorhas6forwardand2reversegears.To
changespeeds,releasethetractionleverandshiftthespeed
selectorlevertothedesiredposition(Figure30).Thelever
locksinanotchateachspeedselection.
Figure30
16

OperatingtheAuger/Impeller
Drive
1.Toengagetheauger/impellerdrive,squeezetheright
hand(auger/impeller)levertothehandgrip(Figure
31).
Figure31
2.Tostoptheaugerandimpeller,releasetherighthand
lever.
Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,the
tractionleverlockstheauger/impellerleverdown,
freeingyourrighthand.Toreleasebothlevers,
simplyreleasethelefthand(traction)lever.
3.Iftheaugerandimpellercontinuetorotatewhenyou
releasetheauger/impellerlever,donotoperatethe
machine.Checktheauger/impellercable(referto
CheckingandAdjustingtheAuger/ImpellerCable)
andadjustitifnecessary.Otherwise,takethemachine
toanAuthorizedDealerforservice.
WARNING
Iftheaugerandimpellercontinuetorotate
whenyoureleasetheauger/impellerlever,
donotoperatethemachine,asyoucould
seriouslyinjureyourselforothers.
TakeittoanAuthorizedServiceDealerfor
service.
OperatingtheQuickStick™
HoldthebluetriggercapdowntousetheQuickStickto
movethedischargechuteandthechutedeector.Releasethe
triggercaptolockthedischargechuteandchutedeector
intoposition(Figure32).
Figure32
MovingtheDischargeChute
HoldthebluetriggercapdownandmovetheQuickStick
tothelefttomovethedischargechutetotheleft;movethe
QuickSticktotherighttomovethedischargechutetothe
right(Figure33).
g018894
Figure33
•Ifthechutedoesnotmove,refertoAdjustingthe
DischargeChuteLatch.
•Ifthechutedoesnotturnasfartotheleftasitdoesto
theright,ensurethatthecableisroutedtotheinsideof
thehandles.RefertoInstallingtheUpperHandle.
•Ifthechutedoesnotlockintoplacewhenyoureleasethe
triggercap,refertoAdjustingtheDischargeChuteLatch.
MovingtheChuteDeector
HoldthebluetriggercapdownandmovetheQuickStick
forwardtolowerthechutedeector;moveitrearwardtoraise
thechutedeector(Figure34).
17

Figure34
UncloggingtheDischarge
Chute
WARNING
Iftheauger/impellerisrunningbutthereisno
snowcomingoutofthedischargechute,the
dischargechutemaybeclogged.
Neveruseyourhandstoclearacloggeddischarge
chute.Thiscouldresultinpersonalinjury.
•Tounclogthedischargechute,stayintheoperating
positionandreleasethelefthand(traction)lever.While
runningtheauger/impeller,pushdownonthehandlesto
raisethefrontofthemachineafewinches(centimeters)
offthepavement.Thenliftthehandlesquicklytobump
thefrontofthemachineonthepavement.Repeatif
necessaryuntilastreamofsnowcomesoutthedischarge
chute.
•Ifyoucannotunclogthedischargechutebybumping
thefrontofthemachine,stoptheengine,waitforall
movingpartstostop,andusethesnowcleanouttool;
neveruseyourhand.
Important:Uncloggingthedischargechuteby
bumpingthefrontofthemachineonthepavement
maycausetheskidstomove.Adjusttheskidsand
tightentheskidboltssecurely.
PreventingFreeze-up
•Insnowyandcoldconditions,somecontrolsandmoving
partsmayfreeze.Donotuseexcessiveforcewhen
tryingtooperatefrozencontrols.Ifyouhavedifculty
operatinganycontrolorpart,starttheengineandletit
runforafewminutes.
•Afterusingthemachine,lettheenginerunforafew
minutestopreventmovingpartsfromfreezing.Engage
theauger/impellertoclearanyremainingsnowfrom
insidethehousing.RotatetheQuickSticktopreventit
fromfreezing.Stoptheengine,waitforallmovingparts
tostop,andremovealliceandsnowfromthemachine.
•Withtheengineoff,pulltherecoilstarterhandleseveral
timesandpushtheelectric-starterbuttononcetoprevent
therecoilandelectricstartersfromfreezingup.
OperatingTips
DANGER
Whenthemachineisinoperation,theimpellerand
augerrotateandcaninjureoramputatehandsor
feet.
•Beforeadjusting,cleaning,inspecting,
troubleshooting,orrepairingthemachine,stop
theengineandwaitforallmovingpartstostop.
Disconnectthewirefromthesparkplugand
keepitawayfromtheplugtopreventsomeone
fromaccidentallystartingtheengine.
•Removeanobstructionfromthedischarge
chute;refertoUncloggingtheDischargeChute.
Ifnecessary,usethesnowcleanouttool,not
yourhands,toremoveanobstructionfromthe
dischargechute.
•Staybehindthehandlesandawayfromthe
dischargeopeningwhileoperatingthemachine.
•Keepface,hands,feet,andanyotherpartof
yourbodyorclothingawayfromconcealed,
moving,orrotatingparts.
WARNING
Theimpellercanthrowstones,toys,andother
foreignobjectsandcauseseriouspersonalinjuryto
theoperatorortobystanders.
•Keeptheareatobeclearedfreeofallobjects
thattheaugercouldpickupandthrow.
•Keepallchildrenandpetsawayfromthearea
ofoperation.
•AlwayssetthethrottletotheFastpositionwhenthrowing
snow .
•Iftheengineslowsdownunderaloadorthewheelsslip,
shiftthemachineintoalowergear.
•Ifthefrontofthemachineridesup,shiftthemachine
intoalowergear.Ifthefrontcontinuestorideup,liftup
onthehandles.
18

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst2hours•Inspectthetractioncableandadjustitifnecessary.
•Inspecttheauger/impellercableandadjustitifnecessary.
Aftertherst5hours•Changetheengineoil.
Beforeeachuseordaily•
•Checktheengineoillevelandaddoilifnecessary.
Yearly
•Checktheskidsandthescraperandadjustthemifnecessary.
•Inspectthetractioncableandadjustorreplaceitifnecessary.
•Inspecttheauger/impellercableandadjustorreplaceitifnecessary.
•Checktheaugergearboxoilandaddoilifnecessary.
•Changetheengineoil.
•Lubricatethehexshaft.
•Replacethesparkplug.
Yearlyorbeforestorage
•Checktheairpressureinthetiresandinatethemto17–20psi(116–137kPa).
•Drainthegasolineandruntheenginetodryoutthefueltankandthecarburetorat
theendoftheseason.
•HaveanAuthorizedServiceDealerinspectandreplacethetractiondrivebeltand/or
theauger/impellerdrivebelt,ifnecessary.
Important:Youcanndmoreinformationaboutmaintainingandservicingyourmachineatwww.Toro.com.
Important:Refertoyourengineoperator'smanualforadditionalmaintenanceprocedures.Forengineadjustments,
repairs,orwarrantyservicenotcoveredinthismanual,contactanAuthorizedBriggs&StrattonServicingDealer.
ServiceInterval:Beforeeachuseordaily
PreparingforMaintenance
1.Movethemachinetoalevelsurface.
2.Stoptheengineandwaitforallmovingpartstostop.
3.Disconnectthesparkplugwire.RefertoReplacing
theSparkPlug.
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily—Checktheengine
oillevelandaddoilifnecessary.
1.Removethedipstick,wipeitclean,thenfullyinstall
thedipstick.
2.Removethedipstickandchecktheoillevel(Figure35).
IftheoillevelisbelowtheAddmarkonthedipstick,
addoil.RefertoFillingtheEnginewithOil.
g018886
Figure35
19

CheckingandAdjustingthe
SkidsandScraper
ServiceInterval:Yearly—Checktheskidsandthescraper
andadjustthemifnecessary.
Checktheskidsandthescrapertoensurethattheaugerdoes
notcontactthepavedorgravelsurface.Adjusttheskidsand
thescraperasneededtocompensateforwear.
1.Checkthetirepressure.RefertoCheckingtheTire
Pressure.
2.Loosenthenutsthatsecurebothskidstotheauger
sidesuntiltheskidsslideupanddowneasily.
g019046
1
Figure36
1.1/8inch(3mm)
Important:Theaugerbladesmustbesupported
abovethegroundbytheskids.
3.Ensurethatthescraperis1/8inch(3mm)aboveand
paralleltoalevelsurface.
Note:Ifthepavementiscracked,rough,oruneven,
adjusttheskidstoraisethescraper.Forgravelsurfaces,
adjusttheskidsfurtherdowntopreventthemachine
frompickinguprocks.
4.Movetheskidsdownuntiltheyareevenwiththe
ground.
5.Firmlytightenthenutsthatsecurebothskidstothe
augersides.
Note:Toquicklyadjusttheskidsiftheyloosen,
supportthescraper1/8inch(3mm)offthepavement,
thenadjusttheskidsdowntothepavement.
Note:Iftheskidsbecomeexcessivelyworn,youcan
turnthemoverandsettheunusedsidetowardthe
pavement.
CheckingandAdjustingthe
TractionCable
ServiceInterval:Aftertherst2hours—Inspectthe
tractioncableandadjustitifnecessary.
Yearly—Inspectthetractioncableandadjustor
replaceitifnecessary.
Ifthemachinedoesnotdriveintheforwardorreversespeeds
oritdriveswhenyoureleasethetractionlever,adjustthe
tractioncable.
Ifthelefthand(traction)cableisnotproperlyadjusted,do
thefollowingsteps:
1.Loosenthejamnut.
2.Engagethetractionleverandholditinplace(Figure
37).
Figure37
3.Loosenortightentheturnbuckletoadjustspring
lengthto2.18inches(5.5cm)(Figure38).
3
g019048
4
Figure38
1.Jamnut3.Spring
2.Turnbuckle4.2.18inches(5.5cm)
4.Tightenthejamnut(Figure38),ensuringthereisslight
tensiononthecable.
5.Ifthetractioncableisproperlyadjustedbutaproblem
remains,contactanAuthorizedServiceDealer.
20
This manual suits for next models
1
Table of contents
Other Toro Snow Thrower manuals
