TorTech A300 Operator's manual

European step down Transformer Voltage Converter
User Instruction Manual
Thank-you for Purchasing a Tortech step down transformer
Tortech Transformers maintain their power rating 24/7
Thermal cut-out and safety fuse included for your Protection.
The Economy European Step Down transformer is designed to operate your
European or Asian 220/230 Volts rated appliance in Australia on the
Australian 240 Volts power mains supply..
Operating Instructions - Please read this manual:
Plug this transformer into your mains power outlet. Connect your
appliance to the outlet sockets. Switch on the transformer and you are
ready to go! When not in use turn off transformer switch (if included).
Please ensure the required wattage of your appliance is less than the
transformers rated capacity.
If your transformer has multiple outlets (or using with power board )
please ensure the simultaneous power use of all connected devices
not exceed the power rating of the transformer.
The Step-Down Unit will work on our 50Hz Frequency power supply,
but will not change it
Please check your product will work with 50Hz if it is a 60Hz unit. In
most cases this will not be an issue
The unit can even be used to help with Over-Voltage Problems in
areas with High Mains Power
It can accept Inputs of 250-260V, and bring it down to 230-240V (i.e. a
reduction of 20Volts)
220V –230V is found in Europe and some Asian countries
Please Note: If using with European equipment, you may need a
European adapter to plug your European device into our transformer.
We unfortunately do not currently stock this item, and must be
purchased separately.
European step down Transformers:
300W, 1200W, 2400W
Models:
A300/240/220E
AE-1200-220T
AE-2400-220T
Converts voltage down from 240V to 220V
European/Asian
Will power most small devices/electronic
chargers e.g. mobile phones, laptops,
printers (ink jet type) and pre-amps.
Fully enclosed unit with a white powder
coated finish
Input: 240V 50Hz Fused, comes with
AUSTRALIAN Style 3-Pin Power Cord
1.8m Long. (Normal Power Cord)
Safety fuse protection (300W and above)
Auto transformer construction
Will allow you to run Overseas Equipment
here in Australia on our 240V AC Power.
This Unit is designed with an Auto-
Transformer style (non-isolating) for light
weight and low cost.
Support Email:
[email protected]
Tel: [phone]

Storage and use:
Note: Transformer is designed for INSIDE use only NOT outdoors.
Please ensure the transformer is placed in a dry and well ventilated area
at all times with 10 cm of space around ventilation grills.
Do not cover ventilation grills on the side or top of unit.
Do not expose to direct sunlight or direct high heat
Keep out of reach of children
Keep away from water, moisture, liquids or oils or flammable substances.
Warranty:
All Tortech transformers come with a 1 year warranty. Please keep your
invoice with date of purchase as proof of warranty. No serviceable parts
inside the unit. Opening or misuse will void warranty. Return for authorised
servicing.
Overloading: Fuses in the transformer will “blow” if you draw more current
than what the transformer can provide. They are part of the inbuilt safety
protection of our transformers. If you keep blowing a fuse repeatedly after first
purchase you may have the wrong transformer, please call us to check your
device and transformer rating.
Fuse replacements:
All our stepdown transformers come with 2 spare fuses in the original
package. Please put the fuses aside when you first open box.
How do I know fuse is blown?
If your transformer has a Led Light on the switch and if this light does not
come on when transformer is turned on this is an indication the fuse has
blown.
HOW TO REPLACE THE FUSE:
Video: http://www.tortech.com.au/fuses/
1) Turn off the power at the 240v power point and unplug the lead from the
power point.
2) Unscrew the fuse Holder
3) Turn it anti-clockwise until the fuse "pops out"
4) Remove the fuse holder plus the fuse
5) Check if that the fuse is intact : Look at the removed fuse in the light and if
the inside filament is broken or the glass is browned out then the fuse is
blown.
6) Put a new fuse in the holder
7) Push back into the fuse main body
8) Turn the fuse holder clockwise until its locked in
9) Plug in the lead into the power point.
10) Turn the power on at the 240v outlet
Replacement fuses
Fuses are selected based on your model and rating.
Fuses can be be purchased from Tortech.
Model
Fuse required
A300/240/220E
1A
AE-1200-220T
6.3A
AE-2400-220T
10A
Safety Compliance Approvals:
RCM tick of approval demonstrates Tortech Pty Ltd’s commitment to
mandatory Australian Electrical Safety EESS Legislation
Tortech Pty Ltd
Support Email: [email protected]
Tel: [phone]
