PWAY PW-SC5110C User manual

HDMI to SD/HD/3G-SDI Converter
USER MANUAL

一、 Description
HDMI to SD/HD / 3 G - SDI broadcast converter is a dedicated to dual high-definition
multimedia connect HDMI signal is converted to HD component serial interface SDI signal
equipment.The equipment integrated SDI emitter and HDMI demodulator, can easily change the
HDMI signal into SDI signal, at the same time will HDMI with embedded into audio signal separation
after converting in SDI signal, in order to realize the sound and image synchronous transmission.
二、 Features
Support HDMI input formats: 480i, 576i, 720p50Hz/60 Hz, 1080p24/25/30/ , 1080i 25/30Hz,
1080p 50 Hz / 60 Hz
Support SMPTE 425 m (class A and class B), SMPTE424M, SMPTE292M, SMPTE259M - C
With two-way SDI signal output
Automatically detect HDMI EDID information
Support all formats asymmetric transformation
The HDMI signal automatically audio signal embedded in SDI

三、 Specifications
Parameter
Description
Video
input interface
HDMI-A
Standards
HDMI 1.3; HDCP 1.2
Maximum pixel clock
225MHz
Support the input
formats
480i,576i,720p@50/60,1080i@50/60,
1080p@24/25/30, 1080p50/60
Output interface
BNC
output signal types
SD-SDI(270Mbps), HD-SDI(1.485Gbps),
3G-SDI(2.97Gbps)
SDI signal amplitude
0.8Vp-p
SDI impedance
75Ω
SDI coupling type
ACcoupling
SDI signal jitter
(typical)
SD-SDI≤0.1UI HD-SDI≤0.2UI 3G-SDI≤0.4 UI
Other
maximum cable
length
Belden 1694A: SD-SDI 300m ，HD-SDI 200m ，
3G-SDI 120m
Note: the above transmission distance for different
specifications of the cable, test results will be
different
Power supply
power adapter: DC 5-12V
Power dissipation
MAX 2.5W
Temperature
Working temperature：-5℃~ +70℃
Humidity
Working humidity：5% ~ 90%
Dimension
94X71X26mm
The warranty
1 年免费保修
四、 Panel
HDMI to SDI Equipment

Port name
Description
INPUT
HDMI signal input
SDI OUT
SDI signal output
DC5-12V
power input
LED indicator
Description
STATUS
Video signal lamp
POWER
Power light

五、 Package list
HDMI to SDI Equipment 1pcs
Power adapter 1pcs
User manual 1pcs
六、 Installation
1、Will the HDMI source access converter HDMI port
2、Connect the SDI OUT interface to display device,
3、Will the sender and the receiver connected to the power supply, when the lamp lights up
normally, normal operation of system.
七、 Diagram
