Dear Customer,
Thank you for purchasing this Toshiba LCD TV. This manual will
help you use the many exciting features of your new LCD TV. Before
operating your LCD TV, please read this manual completely, and
keep it nearby for future reference.
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat
Panel Display
www.CE.org/safety
'~CEA
1_ (,""", .. ,"~b",'"A"o<.tion
CongratUlations on your purchase! As you enjoy your
new product, please keep these safety tips in mind:
The Issue !
• The home theater entertainment experience is ag rowing trend II
and larger flat panel displays are popular purchases However,
flat panel displays are not always supported on the proper stands I
or installed according to the manufacturer's recommendations. I
• Flat panel displays that are
inappropriately situated on dressers,
bookcases, shelves, desks,
speakers, chests or carts may fall
over and cause injury.
TOSHIBA Cares!
1 • The consumer electronics industry
is committed to making home
entertainment enjoyable and safe.
Tune Into Safety
• One size does NOT fit all. Follow the manufacturer's recommendations
for the safe installation and use of your flat panel display.
• Carefully read and understand all enclosed instructions for
proper use of this product.
• Don't allow children to climb on or play with furniture and
television sets.
• Don't place flat panel displays on
furniture that can easily be used as
steps, such as a chest of drawers.
• Remember that children can
become excited while watching a
program, especially on a "larger
than life" flat panel display. Care
should be taken to place or install
the display where it cannot be
pushed, pulled over, or knocked down.
• Care should be taken to route all cords and
cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
Wall Mounting: If you decide to wall mount your
flat panel display, always:
• Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory (such
as UL, CSA, ETL).
• Follow all instructions supplied by the display and wall mount
manufacturers.
• If you have any doubts about your ability to safely install your
flat panel display, contact your retailer about professional
installation.
• Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction. If you
are unsure, contact a professional
installer.
• A minimum of two people are
L
required for installation. Flat panel
displays can be heavy.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: If you decide to wall mount this television, always
use a UL Listed wall bracket appropriate for the size and weight of
this television. For more detail about UL Listed wall bracket, contact
a Toshiba Authorized Service Center.The use of any wall bracket
other than a UL Listed wall bracket appropriate for the size and
weight of this television for wall mounting this television could result
in serious bodily injury and/or property damage. See "Removing the
Pedestal Stand" (lrl\ page 5).
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER·SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
NOTE TO CATV INSTALLERS
This is a reminder to call the CATV system installer's attention to
Article 820-40 of the US. NEC, which provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the
point of cable entry as practical. For additional antenna grounding
information, see items 26 and 27 on page 4.
2

~
:JYG;.' ~--::
( . 0'\ ~
-......:
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
---------------------_._----_._------------
5) Do not use this apparatus near water.
-----_. __ .. _---_._------,-_._,--~---,'"-----'--~.-._.- ... _-----~.-_ ... _'._-,-~ .. ,,~._'.'-_._. __ ._--
6) Clean only with dry cloth.
._------_._-_._-_._---.-_...._-_.--_ .. _-_._------_._------_.~------_._---
7) Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
prod uce heat.
9) Do not defeat the safety purpose of Grounding prong
the polarized or grounding type plug. A
polarized plug has two blades with one wider~~ ~
than the other. A grounding type plug has ~ ~
two blades and a third grounding prong. The ~ :.=-:::;
wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
-----
10) Protect the power cord from being walked on
or pinched, particularly at plugs, convenience ~
,"
receptacles, and the point where they exit from ~
the apparatus. '.'
---------------~._._-._- ---------------
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, Cl)
or table specified by the manufacturer, or ~
sold with the apparatus. When a cart is used, • ~
use caution when moving the cart/apparatus ,.1
combination to avoid injury from tip-over. ~ ~~~
,.,-
----
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
-----------~-_._--------
14) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Additional Safety Precautions
14a) CAUTION: If the TV is dropped and the cabinet or enclosure
surface has been damaged or the TV does not operate normally,
take the following precautions:
• ALWAYS turn off the TV and unplug the power cord to avoid
possible electric shock or fire.
• NEVER allow your body to come in contact with any broken
glass or liquid from the damaged television. The LCD panel
inside the TV contains glass and a toxic liquid. If the liquid
comes in contact with your mouth or eyes, or your skin is
cut by broken glass, rinse the affected area thoroughly with
water and consult your doctor.
• ALWAYS contact a service technician to inspect the TV any
time it has been damaged or dropped.
15) CAUTION:
• To reduce the risk of electric shock, do not use the polarized
plug with an extension cord, receptacle, or other outlet
unless the blades can be inserted completely to prevent
blade exposure.
• To prevent electric shock, match wide blade of plug to wide
slot; fully insert.
16) WARNING:
To prevent the spread of fire, keep candles or other open flames
away from this product at all times.
Installation, Care, and Service
Installation
Follow these recommendations and precautions and heed all warnings
when installing your TV:
17) Never modify this equipment. Changes or modifications may
void: a) the warranty, and b) the user's authority to operate
this equipment under the rules of the Federal Communications
Commission.
18) ~ DANGER: RISK OF SERIOUS PERSONAL INJURY,
I DEATH, OR EQUIPMENT Cl)
• DAMAGE!
Never place the TV on an unstable • ~
cart, stand, or table. The TV may fall,
causing serious personal injury, death, or I
serious damage to the TV. ~
19) To avoid damage to this product, never place or store the TV in
direct sunlight; hot, humid areas; or areas subject to excessive
dust or vibration.
20) The apparatus shall not be exposed to dripping or splashing and
that no objects filled with liquids, such as vases, shall be placed
on the apparatus.
21) Never block or cover the slots or openings in the TV cabinet
back, bottom, and sides. Never place
the TV:
• on a bed, sofa, rug, or similar
surface;
• too close to drapes, curtains, or
walls; or
• in a confined space such as a
bookcase, built-in cabinet, or any other place with poor
ventilation.
The slots and openings are provided to protect the TV from
overheating and to help maintain reliable operation of the TV. Leave
a space of at least 4 (four) inches around the TV.
22) Always place the back of the television at least four (4) inches
away from any vertical surface (such as a wall) to allow proper
ventilation.
23) Never allow anything to rest on or roll over the power cord, and
never place the TV where the power cord is subject to wear or
abuse.
24) Never overload wall outlets and extension cords.
25) Always operate this equipment from a 120 VAC, 60 Hz power
source only. (continued).
3

26) Always make sure the antenna system is properly grounded to
provide adequate protection against voltage surges and built-up
static charges (see Section 810 of the National Electric Code).
r::
G
"""" :""
Electric service equipment
Ground clamps
/ Antenna lead-in wire
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
_____ Power service grounding electrode
system (NEC Art 250 Part-H)
34) ~DANGER: RISK OF SERIOUS
I PERSONAL INJURY OR
• DEATH!
Never strike the screen with a sharp or
heavy object.
_._---~._--,-- - -~-----
35) • The LCD screen of this product can be damaged by
ultraviolet radiation from the sun. When selecting a location
for the television, avoid locations where the screen may be
exposed to direct sunlight, such as in front of a window.
• Never touch, press, or place anything on the LCD screen.
These actions will damage the LCD screen. If you need to
clean the LCD screen, follow the instructions in item 29 on
this page.
Never attempt to service the TV yourself. Opening and removing
the covers may expose you to dangerous voltage or other
hazards. Failure to follow this WARNING may result in death or
serious injury. Refer all servicing not specified in this manual to
a Toshiba Authorized Service Center.
37) If you have the TV serviced:
• Ask the service technician to use only replacement parts
specified by the manufacturer.
• Upon completion of service, ask the service technician to
perform routine safety checks to determine that the TV is in
safe operating condition.
_._----._--_._--------- -- ._----
38) The cold cathode fluorescent lamp in the LCD panel contains a
small amount of mercury.
When the TV reaches the end of its useful life, dispose of
the used TV by the approved method for your area, or ask a
qualified service technician to properly dispose of the TV.
LL
Note: The lamp(s) inside this product contain
mercury. Disposal may be regulated due to
•environmental considerations. For disposal or
recycling information, contact yourlocal authorities or the
Electronics Industries Alliance (www.eiae.org).
27) t DANGER: RISK OF SERIOUS PERSONAL
~ INJURY OR DEATH!
• Use extreme care to make sure you are never in a position
where your body (or any item you are in contact with, such
as a ladder or screwdriver) can accidentally touch overhead
power lines. Never locate the antenna near overhead power
lines or other electrical circuits.
• Never attempt to install any of the following during lightning
activity: a) an antenna system; or b) cables, wires, or any
home theater component connected to an antenna or phone
system.
Care
For better performance and safer operation of your TOSHIBA TV,
follow these recommendations and precautions:
28) If you use the TV in a room whose temperature is 32 of (0 °C)
or below, the picture brightness may vary until the LCD warms
up. This is not a sign of malfunction.
------------_._---- -----~-- -- ------------
29) Always unplug the TV before cleaning. Gently wipe the display
panel surface (the TV screen) using \.
a
dry, soft cloth only (cotton, flannel,
etc.). A hard cloth may damage the 19L.[:b}'
surface of the panel. Avoid contact </do.. ~
with alcohol, thinner, benzene, acidic "-- /' ~
or alkaline solvent cleaners, abrasive
cleaners, or chemical cloths, which
may damage the surface. Never spray volatile compounds such
as insecticide on the cabinet. Such products may damage or
discolor the cabinet.
--_ .. - ---_.-----------
30) ~ WARNING: t
~ RISK OF ELECTRIC SHOCK! ~
Never spill liquids or push objects of any kind into the TV
cabinet slots.
31) While it is thundering, do not touch the connecting cables or
apparatus.
-.---- ----------~--~----~-,-- - -------_.- ---.
32) For added protection of your TV from lightning and power
surges, always unplug the power cord and disconnect the
antenna from the TV if you leave the TV unattended or unused
for long periods of time.
----- -- --- ._-~--- -----._------_.
33) During normal use, the TV may make occasional snapping
or popping sounds. This is normal, especially when the unit
is being turned on or off. If these sounds become frequent
or continuous, unplug the power cord and contact a Toshiba
Authorized Service Center.
4
Service
36) Lh
WARNING:
RISK OF ELECTRIC SHOCK!

Choosing a location for your LCD TV
To Display your LCD TV on the included Pedestal
Stand:
Observe the following safety precautions:
I) Read and Follow the pedestal assembly instructions.
CAUTION: Before beginning pedestal assembly, carefully lay the
front
of the LCD Panel face down on aflat, cushioned surface
such as aquilt or blanket. Leave the bottom
of the unit protruding
over the edge
of the surface and assemble the pedestal as indicated
below.
Note: Extreme care should always
be used when attaching
the pedestal stand
to avoid damage to the LCD panel
2) Place the TV on asturdy, level surface that can support the
weight
of the TV.
To Display your LCD TV using a Wall Bracket:
If you decide to wall mount your LCD TV, always use a UL-listed wall
bracket appropriate for the size and weight of the LCD TV (lIE page 2) :
I) CAUTION: Two people are required for installation.
2) Unplug and remove any cables and/or other component
connectors from the rear of the TV.
3) Follow the instructions provided with your wall bracket.
Before proceeding, make sure the appropriate bracket(s) are
attached to the wall and the back
of the TV as described in the
instructions provided with the wall bracket.
4) After attaching the appropriate bracket(s) to the wall and the
back
of the TV, remove the pedestal stand from the TV as.
described below.
5) VESA Mounting Pattern
22" TV
VESA Mounting Pattern
.r=f====;;;nJ
'1rlr
c::::5'~===':::l
Five screws
TV Size
22"
Hole Patlern(VxH)
100xlOO mm
Screw Size
M4
(unit in mm)
Removing the Pedestal Stand
I) Carefully lay the front of the unit face down on aflat,
cushioned surface such as aquilt
or blanket. Leave the stand
protruding over the edge
of the surface.
Note: Extreme care should always
be used when removing
the pedestal stand
to avoid damage to the LCD panel.
2) Remove the screws shown in the right diagram below. This
will allow removal
of the pedestal stand.
3) Once you have removed all screws holding the pedestal stand
in place, remove the pedestal stand from the TV.
5

ENERGY STA/l® User Information
Important notes about your LCD
TV
ENERGY STAR User Information Statement: the factory default
settings
of this television meet ENERGY STAR requirements.
Changing Picture Settings may increase energy consumption,
possibly beyond the limits required for
ENERGY STAR
qualification.
To ensure your television
is operating at optimal energy
efficiency, select [Home] mode during initial activation. To
return to [Home] mode settings, select [Standard] picture mode.
[Standard] mode
is recommended for normal home use.
The following symptoms are technical limitations of LCD
Display technology and are not an indication of malfunction;
therefore, Toshiba is not responsible for perceived issues
resulting from these symptoms.
I) An afterimage (ghost) may appear on the screen if afixed,
nonmoving image
is displayed for along period of time. The
afterimage is not permanent and will disappear in ashort
period
of time.
2) The LCD panel contained
in this TV is manufactured using
an extremely high level
of precision technology; however,
there may be an occasional pixel (dot
of light) that does not
operate properly (does not light, remains constantly lit, etc.).
This
is astructural property of LCD technology, is not a
sign
of malfunction, and is not covered under your warranty.
Such pixels are not visible when the picture
is viewed from a
normal viewing distance.
Note: Interactive video games that involve shooting a"gun"
type
of joystick at an on-screen target may not work with this
TV.
ENERGY STAR® qualified TV. Products that
earn the ENERGY STAR prevent green house
gas emissions by meeting strict guidelines set
by the U.S. Environmental Protection Agency.
ENERGY STAR and the ENERGY STAR mark
are registered U.S. marks.
II
i§fl3ijetJi4
iD
Note: This equipment has been tested and found to comply
with the limits for aClass Bdigital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference
in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in aparticular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
removing and applying power to the equipment, the user is
encouraged
to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the
receiver.
•Connect the equipment into an outlet on acircuit different
from that to which the receiver
is connected.
•Consult the dealer
or an experienced radiolTV technician for
help.
Caution: Changes or modifications to this equipment not
expressly approved
by Toshiba could void the user's authority
to operate this equipment.
The Toshiba 22AV500U Televisions comply with Part 15 of the
FCC rules.
Operation
is subject to the following two conditions: (I) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
The party responsible for compliance to these rules is:
Toshiba America
Consumer Products, L.L.c.
82 Totowa Rd. Wayne, NJ 07470.
Ph: 1-800-631-381 I
FCC Declaration of Conformity
Compliance Statement
(Part 15):
Trademark Information
•Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
•HDMI, the HDMIIogo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
6

Contents
Important Safety Instructions 3
Installation, Care, and Service 3
Chapter 1: Introduction 8
Features of your new TV 8
Overview
of steps for installing, setting up,
and using
your new TV 9
TV front and side panel controls and connections 10
Chapter 2: Connecting your TV 12
Overview of cable types 12
About the connection illustrations 12
Connecting a VCR and antenna or Cable TV
(no
Cable box) 13
Connecting aVCR with S-video and acable box 14
Connecting a DVD player with ColorStream® (component
video), aVCR, and asatellite receiver 15
Connecting a camcorder 16
Connecting an HDMJTM or DVI device to the HDMI input.. 17
Connecting adigital audio system 18
Connecting apersonal computer (PC) 19
Chapter 3: Using the remote control 20
Preparing the remote control for use 20
Installing the remote control batteries 20
Remote control effective range 20
Learning about the remote controL 21
Using the remote control to control your other devices 22
Remote Control functional key chart... 23
Programming the remote control to control your
other devices 24
Remote control codes 25
Chapter 4: Menu layout and navigation 27
Main menu layout 27
SetuplInstallation menu layout 28
Navigating the
menu system 28
Chapter 5: Setting up your TV 29
Selecting the menu language 29
Configuring the
antenna input source for the
ANT/CABLE terminal 29
Programming channels into the TV's channel memory 30
Programming channels automatically 30
Manually adding and deleting channels
in the channel memory 30
Labeling channels 31
Setting the HDMJTM audio mode 32
Viewing the digital signal meter 33
Setting the time
zone 33
Viewing the system status 33
Chapter 6: Using the TV's features 34
Selecting the video input source to view 34
Labeling the video input sources 34
Tuning channels 35
Tuning channels using the Channel Browser™ 35
Setting the Channel Tuning
Mode 37
Tuning to the next
programmed channel 37
Tuning to aspecific channel
(programmed or
unprogrammed) 37
Switching between two channels using
Channel Return 37
Switching between two channels using SurfLock™ 38
Selecting the picture size 38
Scrolling the TheaterWide® picture
(TheaterWide 2and 3only)
40
Using the auto aspect ratio feature .40
Selecting the cinema mode (480i and 1080i signals) .40
Using the FREEZE feature .40
Adjusting the picture .41
Selecting the picture mode
4l
Adjusting the picture quality 41
Using the closed caption mode .42
Base closed captions .42
Digital CC Settings 42
CC Selector 42
Adjusting the audio 43
Muting the sound
.43
Using the digital audio selector. 43
Selecting stereo/SAP broadcasts 43
Adjusting the audio quality
44
Selecting the optical audio output format 44
Using the Dolby® Digital Dynamic Range
Control feature 44
Using the Locks menu .45
Entering the PIN code 45
If you cannot remember your PIN code 45
Changing your PIN code 45
Blocking TV programs and movies by rating (V-Chip) .. 45
Downloading an additional rating system for
blocking
TV programs and movies 46
Blocking channels 47
Unlocking programs temporarily 47
Using the input lock feature 47
Using the GameTimer® 48
Using the control panel lock feature
.48
Using the PC settings feature .49
Setting the PC Audio 49
Setting the sleep timer 49
Displaying TV status information 50
Understanding the auto power off feature 50
Understanding the last mode memory feature 50
Chapter 7: Using the TV's advanced features 51
Using the advanced picture settings features 51
Using dynamic contrasl.. 51
Using the static gamma feature 51
Selecting the color temperature 51
Using CableClear® digital noise reduction 52
Using
MPEG noise reduction 52
Using the
Game Mode feature 52
Chapter 8: Troubleshooting 53
General troubleshooting 53
Chapter 9: Appendix 55
Specifications 55
Acceptable signal formats for PC IN
and HDMIterminals .. 56
Limited United States Warranty for LCD Televisions
(23" and smaller) Depot Repair Warranty 57
Limited Canadian Warranty
for Toshiba Brand Flat Panel Televisions 58
7

Chafji8r 1: IntriJiiiCiiiJn
Features of your new TV
The following are just afew of the many exciting features of
.your new Toshiba widescreen, integrated HD, LCD TV:
•
Integrated digital tuning (8VSB ATSC and QAM)
eliminates the need for aseparate digital converter set-top
box (in most cases).
•Two HDMITM digital, high-definition multimedia
interfaces I080i input support
(1& page 17).
•
HDMI new capabiJity
Lip-Sync Latency activates an audio/video display timing
adjustment function that allows HDMl source devices
to
accurately perform synchronization automatically.
•
One set of ColorStream® HD high-resolution component
video inputs (1& page 15).
•Digital
Audio Out optical audio connection with Dolby®
Digital optical output format (1& page 44).
•CableClear® digital picture noise reduction
(1& page 52).
•
PC IN (Analog RGB) computer terminal (1& page 19).
• Channel Labeling allows you to put the Call Letters (e.g.
ABC, HBO, etc.) on the screen along with the station
numbers, so you always know what you're watching
(1& page 31).
8

Chapter 1: Introduction
Overview of steps for installing,
setting up, and using your new TV
Follow these steps to set up your TV and begin using its many
exciting features.
1Carefully read the important safety, installation, care,
and service information. Keep this manual for future
reference.
2Observe the following when choosing alocation for the
TV:
•Read "Important notes about your LCD TV"
(~page 6).
•Place the TV on the floor or asturdy, level, stable
surface that can support the weight
of the unit. Secure
the TV
to awall, pillar, or other immovable structure
(~page 3).
•Place the TV
in alocation where light does not reflect
on the screen.
•Place the TV far enough from walls and other objects
to allow proper ventilation. Inadequate ventilation may
cause overheating, which will damage the
TV THIS
TYPE
OF DAMAGE IS NOT COVERED UNDER
THE TOSHIBA WARRANTY.
3Do not plug in any power cords until AFTER you have
connected all cables and devices
to your TV
4BEFORE connecting cables or devices to the TV, learn
the functions
of the TV's connections and controls
(~ pages 10-11).
5Connect your other electronic device(s) to the TV
(~pages 12-19).
6Install the batteries in the remote control (~ page 20).
7See "Learning about the remote control" (~ page 21) for
an overview
of the buttons on the remote control.
8Program the remote control to operate your other
device(s)
(~ pages 22-26).
9AFTER connecting all cables and devices, plug in the
power cords for your TV and other devices. Then press
POWER on the TV control panel or remote control to turn
on the
TV If the TV stops responding to the controls on
the remote control orTV control panel and you cannot
turn the TV off or on, please unplug the power cords few
seconds then re-plug to try again.
10 See "Menu layout and navigation" for aquick overview
of navigating the TV's menu system (~page 27).
11 Program channels into the TV's channel memory
(~page 30).
12 For details on using the TV's features, see Chapters 6
and
7.
13 For help, refer to the Troubleshooting Guide, Chapter 8.
14 For technical specifications and warranty information,
see Chapter
9.
15 Enjoy your new TV!
9

Chapter 1: Introduction
TV front and side panel controls and connections
Model 22AV500U is used in this manual for illustration purposes.
Top panel
TV front
Right side panel
Control panel
1 Green LED
Power LED (Green) =Power indicator
2 Remote sensor -Point the remote control toward this
remote sensor (1&
"Remote control effective range" on
page 20).
3 POWER -Press to turn the TV on and off.
If the TV stops responding to the controls on the remote
control or TV control panel and you cannot turn
off the
TV, press and hold the
POWER button on the TV control
panel for 5or more seconds to reset the
TV.
4 ARROWS .. T .... ~ -When amenu is on-screen, these
buttons function as up/down/leftJright menu navigation
buttons.
5 MENU (ENTER) -Press to access the menu system (1&
pages 27-28). When amenu is on-screen, the MENU
button on the TV's control panel functions as the ENTER
button.
6 EXIT -Press to instantly close an on-screen menu.
7 CHANNEL .. T-When no menu is on-screen, these
buttons change the channel (programmed channels only;
1& page 30).
8 VOLUME .... ~ -These buttons adjust the volume level.
9 INPUT -'--- Repeatedly press to change the source you are
viewing
(ANT/CABLE, VIDEO, Color StreamHD, HDMI1,
HDMI2, PC).

~~"""''1'''!l'''''I!'i''_,~,~:~.", '~"'",''"'''''''''''''''''''''''''''''''>-''--~;7' ~!!""""--':''''''''~"",!",~'''''''1~~~~''''''':~~~~''1!\!~':'''\'1f'f'!!'t"~~~~m'''''''II,!~
Chapter 1: Introduction
TV back panel connections
For an explanation of cable types and connections, see pages 12-19.
TV back
0
-
II
u
.~
=::,
--=
Power cord
~
HomlJ ~ d ~ @ @u;@o @~o
~ y P8 PR A S-VIOEO
~ ~1 ~ ~ @ @@ @ ~
2 AUDIO RGB
HOM I IN S6II'l:£ PC IN COLOR STIlEAM HD IN VIDEO IN
®A
DIGITAL
ANT/CABlE AUDOOUT
IT
2 3
~
4T
T'
6 7 9
8T 9
1 HDMJTM IN -High-Definition Multimedia Interface input
receives digital audio and uncompressed digital video
from an HDMI device
or uncompressed digital video
from aDVI device. Also see item 3.
HDMI connection is
necessary to receive I080i signals.
2 Service port -For service use only. Used for updating
the television's firmware.
3 PC/HDMI-1 (AUDIO) IN -PC audio input terminals are
shared with
HDMI -I analog audio input terminals, and
their use can be configured
in the Audio Setup menu (lIE
page 51).
4 PC IN -For use when connecting apersonal computer.
5 ColorStream® HD - The ColorStream® high-definition
component video inputs (with standard stereo audio
inputs) for connecting devices with component video
output, such as aToshiba DVD player with ColorStream®.
7 ANT/CABLE -Antenna input that supports analog
(NTSC) and digital (ATSC) off-air antenna signals and
analog and digital Cable
TV (QAM) signals.
8 Digital Audio OUT -Optical audio output in Dolby
Digital or PCM (pulse-code modulation) format for
connecting an external Dolby Digital decoder, amplifier,
AN receiver, or home theater system with optical audio
input.
HDMI, the HOMIlogo and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
Note: Component video cables carry only video
information; separate audio cables are required for a
complete connection.
6 VIDEO IN -Standard (composite) video and standard
audio inputs plus optional S-video inputs for connecting
devices with composite video or S-video output.
Note: Standard (composite) video and S-video cables
carry only video information; separate audio cables are
required for acomplete connection.
11 I

Chapter 2: Connecting your TV
Overview of cable types
Cables can be purchased from most stores that sell audio/
video devices. Before purchasing any cables, be sure
of
connector types required by your devices and the length of
each cable.
Coaxial (F-type) cable
G {tf)-------
Coaxial (F-type) cable is used for connecting your antenna,
cable TV service, and/or cable converter box to the
ANTI
CABLE input on your TV.
Standard AN cables (red/white/yellow)
~:E7
~ -~-----
~
Standard AN cables (composite video) usually come in sets
of three, and are for use with video devices with analog audio
and composite video output. These cables (and the related
inputs on your
TV) are typically color-coded according to
use: yellow for video, red for stereo right audio, and white for
stereo left (or mono) audio.
S-video cable
OdJIIIDm-----
S-video cable is for use with video devices with S-video
output. Separate audio cables are required for acomplete
connection.
Note: An S-video cable provides better picture performance
than acomposite video cable. Ifyou connect an S-video
cable, be sure to disconnect the standard (composite) video
cable
or the picture performance will be unacceptable.
Component video cables (red/green/blue)
~3:7 ~ -~-----
~
Component video cables come in sets of three and are for
use with video devices with component video output.
(ColorStream®
is Toshiba's brand of component video.) These
cables are typically color-coded red, green, and blue. Separate
audio cables are required for acomplete connection.
Note: Component video cables provide better picture
performance than astandard (composite) video
or S-video
cable.
1
12
HDMITM cable (with HDMI Logo "Hi:Jml")
HDMI (High-Definition Multimedia Interface) cable is for
use with devices with an HDMI output. An HDMI cable
delivers digital audio and video
in its native format. This
cable carries both video and audio information; therefore,
separate audio cables are not required for acomplete HDMI
device connection (1& page
17 and page 19).
Note: HOMI cable provides betterpicture performance than
astandard (composite) video or S-video cable.
Optical audio cable
[Q]~...---
Optical audio cable is for connecting receivers with Dolby
Digital
or PCM (pulse-code modulation) optical audio input
to the
TV's DIGITAL AUDIO OUT terminal (1& page 18).
Analog RGB (15-pin) computer cable
Analog RGB (15-pin) computer cable is for connecting aPC
to the
TV's PC IN terminal (1& page 19).
About the connection illustrations
You can connect different types and brands of devices to
your TV
in several different configurations. The connection
illustrations in this manual are representative
of typical
device connections only. The input/output terminals on your
devices may differ from those illustrated herein. For details
on connecting and using your specific devices, refer.to each
device's owner's manual.

'Challtei2: Connecting your TV
Connecting a VCR and antenna or Cable TV (no Cable box)
From Cable TV or antenna
TV back panel
LIMONO VI DEO
@ @
__ fVIDI ~
ff ~
DIGITAL
ANT !CABLE AUDIO OUT
You will need:
•coaxial cables
•standard
AN cables
-For betterpicture performance, ifyour VCR has S-video,
use an S-video cable (plus the audio cables) instead
of
the standard video cable, 00 not connect both types of
video cable to VIDEO IN at the same time or the picture
performance will be unacceptable,
-Ifyou have amono
VCR, connect UMONO on the TV
to your VCR's audio out terminal using the white audio
cable only
To view the antenna or Cable signal:
Select the ANT/CABLE video input source on the TV. *
To view the VCR:
Turn ON the VCR. Select the VIDEO video input source on
the TV.*
* To select the video input source, press INPUT on the remote control
(1& page 21), To program the TV remote control to operate other
devices, see Chapter
3,
The unauthorized recording, use, distribution, or revision of television
programs, videotapes, DVDs, and other materials is prohibited under the
Copyright Laws of the United States and other countries, and may subject
you to civil and criminal liability,
13

Chapter 2: Connecting your TV
Connecting a VCR with S-video and a cable box
An S-video connection will provide better picture performance than astandard (composite) video cable.
From Cable TV
TV back panel
I~ ~~
~
@ 0 ~ ~
tt
DIGITAL
__ ~ -=A=NT;:/C=AB;::LE==A::;::UD=IO:::;OUT=
LtJ =
You will need:
•coaxial cables
•S-video cable
- 00 not connect both types of video cable to VIDEO IN
at the same time or the picture performance will be
unacceptable.
•standard audio cables
-Ifyou have amono VCR, connect UMONO on the TV
to your VCR's audio out terminal using the white audio
cable only
Note:
When you use aCable box, you may not be able to use
the remote control
to program or access certain features on
the
TV
I 14
Stereo VCR
To view basic and premium Cable channels:
Turn OFF the VCR. Select the ANT/CABLE video input
source on the
TV. *Tune the TV to channel 3or 4(whichever
channel the Cable box output
is set to). Use the Cable box
controls to change channels.
To view the VCR:
Turn ON the VCR. Select the VIDEO video input source on
the TV.*
* To select the video input source, press INPUT on the remote control
(1& page 21). To program the TV remote control to operate other
devices,
see Chapter 3.
The unauthorized recording, use, distribution, or revision of television
programs, videotapes, DVDs, and other materials is prohibited under the
Copyright Laws of the United States and other countries, and may subject
you to civil and criminal liability.

Chapter 2: Connecting your TV
Connecting a DVD player with ColorStream® (component video), a VCR,
and a satellite receiver
Your TV has one set of ColorStream® (component video) inputs.
From satellite dish
Satellite receiver with component video
You will need:
•coaxial cables
•standard NV cables
-For better picture performance, if your VCR has S-video,
use an S-video cable (plus the audio cables) instead
of
the standard video cable. 00 not connect both types of
video cable to VIDEO IN at the same time or the picture
performance will
be unacceptable.
-
If you have amono VCR, connect UMONO on the TV
to your VCR's audio out terminal using the white audio
cable only
•standard audio cables
•component video cables
- You can connect the component video cables (plus
audio cables) from the
OVO player or satellite receiver to
ColorStream HD terminals on the TV The ColorStream
HD terminals can be used with Progressive (4BDp, 72Dp)
and Interlaced (4BDi, 1OBDi) scan systems. A 1DBDi
signal will provide the best picture performance (1OBDp
is not supported).
-
If your OVO player or satellite receiver does not have
component video,
connect astandard A/V cable to
VIDEO IN. If your OVO player has HoMI video, see page
17.
To view antenna or Cable channels:
Select the ANT/CABLE video input source on the TV*
To view the DVD player:
Turn ON the DVD player. Select the ColorStream HD video
input source on the TV *
To view satellite programs using the component
video connections:
Turn on the satellite receiver. Select the ColorStream HD video
input source on the TV *
To view the VCR or view and record antenna
channels:
Turn ON the VCR. Tune the VCR to the channel you want to
watch. Select the VIDEO video input source on the TV. *
To record aTV program while watching aDVD:
Turn ON the VCR. Tune the VCR to the channel to record.
Select the ColorStream HD video input source on the TV* to
view the DVD.
* To select the video input source, press INPUT on the remote control
(I&' page 21). To program the TV remote control to operate other
devices, see Chapter
3.
The unauthorized recording, use, distribution, or revision of television
programs, videotapes, DVDs, and other materials is prohibited under the
Copyright Laws of the United States and other countries, and may subject
you to civil and criminal liability.

Connecting a camcorder
You will need:
•standard A/V cables
-For better picture performance, ifyour camcorder has
S-video, connect an S-video cable (plus the audio cables)
to VIDEO IN on the TV back panel.
Camcorder
VIDEO AUDIO
OUT
~L0
"0
VIDEO inputs on TV back panel
To view the camcorder video:
Select the VIDEO IN video input source on the TV. *
* To select the video input source, press INPUT on the remote control
(1& page 21). To program the TV remote control to operate other
devices, see Chapter 3.

Chapter 2: Connecting your TV
Connecting an HOMITM or OVI
device to the HOMI input
The HDMI input on your TV receives digital audio and
uncompressed digital video from
an HDMI source device,
or uncompressed digital video from aDVI (Digital Visual
Interface) source device.
This input
is designed to accept HDCP (High-Bandwidth
Digital-Content Protection) program material
in digital form
from EIA/CEA-861-D--compliant
fll
consumer electronic
devices (such
as aset-top box or DVD player with HOM] or
DVI output).
The HDMI input can accept and display VGA, 480i (60Hz),
480p (60Hz),
nop (60Hz), and 1080i (60Hz) signal formats.
For detailed signal specifications, see page 60.
Supported Audio format: Linear PCM, sampling rate 32/44.1/
48 kHz
Note: To connect aPC to the HOMI input, see page 19.
To connect an HOMI device, you will need:
•one HDMI cable (type Aconnector) per HDMI device
-For proper operation, it is recommended that you use an
HOMI
cable with the HOMI Logo (HLlm.).
- To display an 1080i/60Hz signal format, you will need a
Category 2cable. Conventional HOM I/O VI cable may
not work properly
-HOMI cable transfers both video
and audio. Separate
analog audio cables are
not required (see illustration).
-See "Setting the
HOMITM audio mode" (1rF page 32).
TV back panel
~
7 H~m~J. ~ d·;w.,
fh=?t 2 1 AUDIO AGB
HDMIIN SER'IICE PC IN
HOM I device
VIDEO I AUO~
[O~ ~~~
[O~ ~i+
L R
To view the HOMI device video:
Select the HDMI I, or HDMI 2video input source on the
TV.*
* To select the video input source, press INPUT on the remote control
(1rF page 21). To program the TV remote control to operate other
devices, see Chapter
3.
To connect aOVI device, you will need:
•one HDMI-to-DVI adapter cable (HDMI type Aconnector)
per DVI device
-For proper operation, the length of an HOMI-to-OVI
adapter cable should not exceed 9.8 ft (3m). The
recommended length is 6.6 ft (2m).
•one pair of standard analog audio cables per DVI device
-An HOMI-to-OVI adapter cable transfers video only
Separate analog audio cables are required (see
illustration).
-See "Setting the
HOMITM audio mode" (1rF page 32).
TV back panel
~
Hi:JmIJ ~ d
~ ~ !le:;b
fkiJt 2 fkiJt 1 AUDIO ~-
HOMIIN SEJI'fCE PC IN
=
OVI device
Note: To ensure that the HOMI or OVI device is reset properly,
it is recommended that you follow these procedures:
•When turning on your electronic components,
turn on the
TV first, and then the HOMI or OVI device.
•When turning
off your electronic components, turn off the
HDMI or DVI device first, and then the TV.
[1] EINCEA-861-D compliance covers the transmission of
Iuncompressed digital video with high-bandwidth digital content
protection, which
is being standardized for reception of high-
definition video signals. Because this is
an evolving technology, it
is possible that some devices may not operate properly with the
TV
HDMI, the HDMIIogo and High-Definition Multimedia Interface are
Itrademarks or registered trademarks of HOMILicensing LLC.

Compressed
Connecting a digital audio system
The TV's DIGITAL AUDIO OUT terminal outputs a Dolby®*
DigitallDD~!.,"; or 2-channel down-mixed peM (pulse-code
modulation) signal for use with an external
Dolby® Digital
decoder or other external audio system with optical audio
input.
You will need:
4In the Optical Output Format field, select either Dolby
Digital or PCM, depending on your device (~"Selecting
the optical audio output format" on page 45).
Audio Setup
PC Audio No
HDMI 1Audio Aula
MTS Stereo
Language English
, ( .•. <>,.,. p. tiCal.9. utputl:Ol1lia. t".· .••. "'ll.w. •• al· ;E~~~{:i1
. . ..... _ . _ . ;,-~ <_.~~m;,wl, ..... ~
Dolby Digital
Dynamic Range Control
•optical audio cable (Use an optical audio cable that has
the larger "TosLink" connector and not the smaller "mini-
optical" connector.)
Reset Done
*Manufactured under license from Dolby Laboratories. Dolby and
the double-D symbol are trademarks
of Dolby Laboratories.
Note:
•Some audio systems may not be compatible with Dolby
Digital bitstream signals. Older audio systems that are
not compatible with standard optical out signals may
not work properly, creating ahigh noise level that may
damage speakers or headphones. THIS DAMAGE IS NOT
COVERED BY YOUR WARRANTY
•
The DIGITAL AUDIO OUT terminal may not output some
digital audio sources
because of copy restrictions.
Dolby Digital decoder or
other digital audio system
00
0I
tINEI~ II
O,I,ca' I0
~~
AU~:
"'-cF1
TV back panel
~
~
DIG"Al
ANTICABLE
AUDIO OUT
-----u-=c
cF1
To control the audio:
•Menu item
of Speakers can turn to OFF to mute the TV's
built in speakers.
Digital Audio Selector
~~:f~
Audio Setup
1Turn on the TV and the digital audio device.
2Press M~U on the TV's remote control and open the Audio
menu.
3Highlight Audio Setup and press e.
Audio Settings
Bass
Treble
Balance
·s.Peaj(~.,·,
10
10
Reset Done

Connecting a personal computer
(PC)
With either the PC IN or HOMI connection, you can watch
your computer's display on the TV and hear the sound from
the
TV's speakers.
To connect a PC to the PC IN terminal on the TV:
When connecting aPC to the PC IN terminal on the TV,
use an analog RGB (IS-pin) computer cable and aPC audio
cable.
TV back panel
b
Ho::Jm,J ~ d
~J ~J ~ /@gj,
I ~ 2I 41 1 ~ r-=f'
AUDIO AGB
HDMIIN SEJMCE PC IN
may be skipped or you may not be able to pause during
multi-angle scenes.
•Signal names for mini O-sub IS-pin connector
Pin No.
Signal
Pin No.
Signal
Pin No.
Signal
name name
name
IR 6 Ground
11 Reserved
2G 7 Ground
12 SOA
3 B 8Ground
13 H-sync
4Reserved 95V
14 V-sync
5Reserved
10 Ground 15
SCL
To connect a PC to the HDMI terminal on the TV:
When connecting aPC to the HOMIterminal on the TV, use
an HOMI-to OVI adapter cable and analog audio cables.
If connecting aPC with an HOMI terminal, use an HOMI
cable (type Aconnector). Separate analog cables are not
necessary
(~ page 17).
Conversion adapter (if necessary)
PC audio cable
LJ LJ LL:JJ
=
TV back panel
b
Ho::Jm,J ~ d
~J ~J ~ /§g,
I ...--r 2 I 41 1 ~ II'
AUDIO RGB
HDMIIN SERVICE PC IN
Note:
• The edges of the images may be hidden.
•
If receiving a 72Dp, or 108Di signal program, Native mode
scales the video to display the entire picture within the
borders
of the screen (i.e. no overscanning).
The HOMI input can accept and display VGA, 480i (60Hz),
480p (60Hz),
nop (60Hz), and I080i (60Hz) signal formats.
For detailed signal specifications, see page 56.
lL]
tt
PC audio cable
PC audio output
• To use aPC, set the monitor output resolution on the PC
before connecting it to the
TV. The PC IN terminal can
accept and display VGA, SVGA, XGA, and WXGA signal
formats. For detailed signal specifications
(~ page 56).
Other formats or non-standard signals will not be displayed
correctly.
•
To display the optimum picture, use the PC setting feature
(~ "Using the PC settings feature" on page 49).
Note:
• The PC audio input terminals on the TV are shared with the
HDMI-1 analog audio input terminals
(1& page 49).
•Some PC models cannot be connected
to this TV
• An adapter is not needed for computers with acompatible
mini D-sub15-pin terminal.
•Depending on the DVD's title
and the specifications of the
PC on which you are playing the DVD-Video, some scenes

Chapter 3: Using the remote control
Preparing the remote control for
use
Your TV remote control can operate your TV and many other
devices such as cable converter boxes, satellite receivers,
VCRs, DVD players, and HTIBs (home theater
in abox),
even if they are different brands.
If you have aToshiba device:
Your TV remote control is preprogrammed to operate most
Toshiba devices (I&' page 24).
If you have anon-Toshiba device or aToshiba device
that the remote control is not preprogrammed to
operate:
You can program the TV remote control so it will operate the
other device
(1& pages 22-26).
Installing the remote control
batteries
1Remove the battery cover from the back of the remote
control.
Squeeze tab
and lift cover.
2Install two "AAA" size batteries, making sure to match
the +and -signs on the batteries
to the signs on the
battery compartment.
3Reinsert the battery cover in the remote control until the
tab snaps.
Caution: Batteries must not be exposed to excessive heat
such as sunshine, fire
or the like.
Note:
•Be sure to use AAA size batteries.
•Dispose
of batteries in adesignated disposal area.
•Batteries should always be disposed
of with the
environment
in mind. Always dispose of batteries in
accordance with applicable laws and regulations.
•If the remote control does not operate correctly,
or if the
operating range becomes reduced, replace batteries with
new ones.
I 20
• When necessary to replace batteries in the remote control,
always replace both batteries with new ones. Never mix
battery types or use new
and used batteries in combination
•.Always remove batteries from the remote control if they
are
dead or if the remote control is not to be used for an
extended period
of time. This will prevent battery acid from
leaking into the battery compartment.
Remote control effective range
For optimum performance, aim the remote control directly
at the TV and make sure there
is no obstruction between the
remote control and the
TV.
Point remote control
toward remote sensor on
front of
TV.
I
~
16.4 ft (5m)
1
00
:00:
~
