SERVICE MANUAL
LCD Color Television
37HLX95
FILE NO. 020-200519
Published in Japan, Sep. 2005 (YC)
TOSHIBA CORPORATION 2005
DOCUMENT CREATED IN JAPAN, Sept., 2005

- 2 -
TABLE OF CONTENTS
SERVICE SAFETY PRECAUTIONS .................................................................................................................................... 3
HANDLING THE LCD MODULE .......................................................................................................................................... 5
SERVICE MODE .................................................................................................................................................................. 7
LAYOUT OF MAJOR BOARDS .......................................................................................................................................... 12
MECHANICAL DISASSEMBLY .......................................................................................................................................... 13
EXPLODED VIEW .............................................................................................................................................................. 15
PACKING DISASSEMBLY ................................................................................................................................................. 17
CHASSIS AND CABINET REPLACEMENT PARTS LIST ................................................................................................. 18
PC BOARDS TOP & BOTTOM VIEW ................................................................................................................................ 27
CIRCUIT BLOCK DIAGRAM .............................................................................................................................................. 51
APPENDIX:
SCHEMATIC DIAGRAM

- 3 -
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICE SAFETY PRECAUTIONS
• The caution items shown here describe major safety issues and should always be observed.
• The meanings of the various indications are as follows.
WARNING
CAUTION
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users due to a product defect after the service operation is completed, could possibly be in
danger of injury or even death in the event of operational error.
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users after the service operation is completed, could possibly be in danger of injury, or
where there could be physical damage in the event of operational error.
* Physical damage means major damage to a home, furnishings and other possessions.
Examples of marks
SHOCK HAZARD
PROHIBIT DISASSEM-
BLING
UNPULUG
The " indicates caution (including danger and warning).
The actual meaning of this caution is indicated inside the
" or nearby illustrations or text.
The example shown to the left indicates the danger of "electrical shock".
The indicates a forbidden action.
The actual meaning of this caution is indicated inside the or nearby illustrations or text.
The example shown to the left indicates that disassembly is forbidden.
The
- indicates a forced action (an action that must be performed).
The actual meaning of this forced action is indicated by
- or nearby illustrations or text.
The example shown to the left indicates that the power plug must be disconnected.

- 4 -
WARNING
KEEP CHILDREN
AWAY
UNPULUG
SHOCK HAZARD
USE SPECIFIED
PARTS
CAUTION FOR
WIRING
CAUTION FOR
ASSEMBLING /
WIRING
CHECK INSULATION
RESISTANCE
PROHIBIT
REMODELING
• Always advise users to keep children away.
There is danger of injury to children from tools, disassembled products, etc.
• Always disconnect the power plug before starting work whenever power is not required.
Failure to disconnect the power plug before starting work can result in electrical shock.
• Depending on the model, use an insulation transformer or wear gloves when servicing with the
power on, and disconnect the power plug to avoid electrical shock when replacing parts.
In some cases, alternating current is also impressed in the chassis, so electrical shock is pos-
sible if the chassis is contacted with the power on.
• Always use the replacement parts specified for the particular model when making repairs.
The parts used in products have the necessary safety characteristics such as inflammability,
voltage resistance, etc.; therefore, use only replacement parts that have these same character-
istics.
Use only the specified parts when the mark is included in a circuit diagram or parts list.
• Parts mounting and routing of the wiring should be the same as that used originally.
For safety purposes, insulating materials such as tubing or tape is sometimes used and printed
circuit boards are sometimes mounted floating.
Also make sure that wiring is routed and clamped to avoid parts that generate heat and which
use high voltage. Always follow the original scheme.
• After a repair has been completed, reassemble all disassembled parts, and route and recon-
nect the wiring, in accordance with the original scheme.
Do not allow internal wiring to be pinched by cabinets, panels, etc.
Any error in reassembly or wiring can result in electrical leakage, flame, etc., and may be
hazardous.
• After completing the work, disconnect the power plug from the outlet, remove the antenna, turn
on the power switch. Then, use a 500V insulation resistance meter to check the insulation
resistance of the antenna terminal, other metallic parts and between the prongs of the power
plug to make sure that the insulation resistance is 1M 1or more.
The set will require inspection and repair if the insulation resistance is below this value.
• Never remodel the product in any way.
Remodeling can result in improper operation, malfunction, or electrical leakage and flame,
which may be hazardous

- 5 -
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
HANDLING THE LCD MODULE
Safety Precautions
In the event that the screen is damaged or the liquid crystal
(fluid) leaks, do not breathe in or drink this fluid. Also, never
touch this fluid.
Such actions could cause toxicity or skin irritation. If this fluid
should enter the mouth, rinse the mouth thoroughly with wa-
ter. If the fluid should contact the skin or clothing, wipe off
with alcohol, etc., and rinse thoroughly with water. If the fluid
should enter the eyes, immediately rinse the eyes thoroughly
with running water.
Precautions for Handling the LCD Module
The LCD module can easily be damaged during disassembly
or reassembly; therefore, always observe the following pre-
cautions when handling the module.
1. When attaching the LCD module to the LCD cover, posi-
tion it appropriately and fasten at the position where the
display can be viewed most conveniently.
2. Carefully align the holes at all four corners of the LCD
module with the corresponding holes in the LCD cover
and fasten with screws. Do not strongly push on the mod-
ule because any impact can adversely affect the perform-
ance. Also use caution when handling the polarized screen
because it can easily be damaged.
CAUTION The metal edges of the LCD module
are sharp, so use caution to avoid in-
jury.
3. If the panel surface becomes soiled, wipe with cotton or a
soft cloth. If this does not remove the soiling, breathe on
the surface and then wipe again.
If the panel surface is extremely solied, use a CRT cleaner
as a cleaner.Wipe off the panel surface by drop the cleaner
on the cloth. Do not drop the cleaner on the panel. Pay
attention not to scratch the panel surface.
4. Leaving water or other fluids on the panel screen for an
extended period of time can result in discoloration or
stripes. Immediately remove any type of fluid from the
screen.
5. Glass is used in the panel, so do not drop or strike with
hard objects. Such actions can damage the panel.
6. CMOS-LSI circuitry is used in the LCD module, so avoid
damage due to static electricity. When handling the mod-
ule, use a wrist ground or anchor ground.

- 6 -
7. Do not expose the LCD module to direct sunlight or strong
ultraviolet rays for an extended period of time.
8. Do not store the LCD module below the temperature con-
ditions described in the specifications. Failure to do so
could result in freezing of the liquid crystal due to cold air
or loss of resilience or other damage.
9. Do not disassemble the LCD module. Such actions could
result in improper operation.
10. When transporting the LCD module, do not use packing
containing epoxy resin (amine) or silicon resin (alcohol or
oxim). The gas generated by these materials can cause
loss of polarity.
Safety Precautions for Laser Beam (DVD Player)
Do not look into the opening of the disc slot or ventilation
opening of the product to see the source of the laser beam.
It may cause sight damage.

- 7 -
CAUTION : Never try to perform initialization unless you have changed the memory IC.
SERVICE MODE
1. ENTERING SERVICE MODE
1) Press MUTE button twice on 2) Press MUTE button again and 3) While pressing the MUTE button,
Remote Control. keep pressing. press MENU button on TV set.
(Service mode display)
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on Remote Control.
Service mode Adjustment mode
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
Press
Press
MUTE
Test signal selection : TV/VIDEO button (on Remote)
Selection of the adjustment items : Channel / (on TV or Remote)
Change of the data value : Volume W/ X(on TV) or / (on Remote)
Adjustment menu mode ON/OFF : MENU button (on Remote)
Initialization of the memory : CALL + Channel button on TV ( )
Reset the count of operating protect circuit to “00” : CALL + Channel button on TV ( )
“RCUT” selection : 1 button
“GCUT” selection : 2 button
“BCUT” selection : 3 button
“CNTX” selection : 4 button
“COLC” selection : 5 button
“UVTT” selection : 6button
Automatic A/D Adjustment(PC, Component) : 7 button
Self diagnostic display ON/OFF : 9 button
----- Color thickness correction
note: Displayed differently as shown below, depending
on the setting of the receiving color system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)

- 8 -
Signals Picture
• Red raster
• Green raster
• Blue raster
• All Black
• All White
R
All BlackAll White
BSignal off G
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL button in the service mode changes the adjustment items in the order of table-2.
(button for reverse order)
5. ADJUSTING THE DATA
1) Pressing of VOLUME W/ X, / button will change the value of data in the range from 00H to FFH. The
variable range depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
INITIALIZATION OF MEMORY DATA
After replacing EEPROM IC, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL button on the TV. The initialization of
EEPROM IC has been completed.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto tune” on the owner’s manual.
CAUTION: Never attempt to initialize the data unless EEPROM IC has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of TV/VIDEO button on the Remote Control changes the built-in test patterns on screen as described
below in SERVICE MODE.

- 9 -
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s is executed properly.
2) During diagnosis, the following displays are shown.
000000
HLV95_1489
OK
M
N
O
P
Q
MFirmware :
Version information of microprocessor
In case of file name : HLV95 and Version : 1489 indicates[HLV95_1489].
NTime : Total hour of turn the TV on. (Unit : H)
OBus line : --"OK" is normal
"SCL-GND"(Red indication) : SCL-GND short circuit
"SDA-GND"(Red indication) : SDA-GND short circuit
"SCL-SDA"(Red indication) : SCL-SDA short circuit
PBus cont : --- "OK" is normal.
NG is abnormal(Red indication).
When type name of semiconductor indicates.
QBlock
UV : TV reception mode
V1 : VIDEO 1 input mode
V2 : VIDEO 2 input mode
V3 : ColorStream HD1
V4 : ColorStream HD2
V5 : Buit-in DVD
V6: HDMI IN
PC : Personal Computer (PC)

- 10 -
9. VERSION CHECK MODE
1) Press “9” button twice on Remote Control during display of adjustment menu in the service mode. The version of main
MPU will begin to check.
2) During Version Check, the following displays are shown.
HLV95_1489 (U15)
FF
2A
1A
74 00 01 25 00 00
00000155
SHP-37
M
N
O
P
Q
S
MMAIN MPU :
Version information of microprocessor
In case of file name : HLV95, Version 1489 for Code Program Version
and (U15) for OSD Version indicates [HLV95_1489(U15)]
NEEPROM :
Version information of EEPROM : Display 1 byte data.
OSUB MPU :
Version information of SUB MPU : Display 1 byte data.
POPTION :
Option information : Display six numbers of 1 byte data.
QHDMI ID :
HDMI ID information : Display 4 byte data.
RDVD :
DVD information : Display 1 byte data.
SLCD Panel Vender information display
The following Panel Vender and screen size are displayed.
Example : SHP-37 indicates that vender is SHP and Screen Size is 37 inch.
R
Panel Vender Screen Size(Inch)
CMO -27
SHP -32
-37

- 11 -
10. STATUS CHECK MODE
1) Press “9” button thrice on Remote Control during display of adjustment menu in the service mode. The status of this
model will begin to check.
2) During Status Check, the following displays are shown.
MMAIN :
Main source information :
Display RF position number (0 - 99) on the main screen, or Input Source (ANT1/2/HDMI etc.)
NMAIN FORMAT :
Display Video and PC format information
OMAIN PLL :
Main PLL information : Display five numbers of 2 byte data.
PSCREEN SIZE :
Display the screen size as follows.
ANT1 CABLE 12
480i
NATURAL
06OF B0 CE 02
0000 0000 0000
M
N
P
Q
O
QOTHER STATUS :
Other status information : Display three numbers of 2 byte data.
Theater Wide 1
Theater Wide 2
Theater Wide 3
FULL
NATURAL

- 12 -
LAYOUT OF MAJOR BOARDS
U104A
TN/AV-AOUT BOARD
U101
SIGNAL DVD-LCD BOARD
U104B
FRONT AV BOARD
U104D
KEY-SW BOARD
U104C
LED-RMT BOARD
U801
POWER BOARD
U104F
DVD-KEY BOARD
U104E
PC-IN BOARD
U103
D-TUNER BOARD
U102
SEINE FOR FPD BOARD U802
AC-IN BOARD
U803
LOWB BOARD

- 13 -
BITTB4×16SBN ×10
PP3×8+SW+W SBN
×6
PP5×16
SW+W SBN
×5
A450
A401
A445
A420
MECHANICAL DISASSEMBLY
1. Removethe stand (foot) and back cover.
2. Removethe boards (FRONT AV, KEY-SW, PC-IN, DVD-KEY) and piece key ass'y.
BITTB3×8 SBN
×5
BITTB3×8
SBN
BITTB3×8 SBN
×2
BITTB3×8
SBN ×2
PP3×8+SW+W
SBN ×3
PP3×8
+SW+W
ECO ×2
PP3×8+SW+W SBN
×6
PP3×8
+SW+W
ECO
PP3×8
+SW+W SBN
×2
PP3×8+SW+W
SBN
PP3×8
+SW+W
SBN
A340
PP08
A320 U104D
U104E
U104B
4-40UNC
JFS-4S L=13
H003C
BITTB3×8
SBN ×2
BITTB3×8
SBN
PP3×8
+SW+W ECO
×4
PP3×8
+SW+W ECO
×4
PP4×20
+SW+W SBN
×2
PP3×8
+SW+W
ECO ×4
PP3×8+SW+W
SBN ×3
PP08
BD01
A545
UF01
A541
U104F
P801
PP3×8+SW+W
ECO
BITTB4×16
SBN ×3
A315

- 14 -
PP3×8+SW+W
ECO ×4
PP3×8
+SW+W
ECO ×4
PP3×8+SW+W ECO
×6
PP3×8
+SW+W
ECO ×3
PP3×8
+SW+W ECO
×3PP3×8+SW+W ECO
×7
PP3×8+SW+W ECO
×4PP3×8+SW+W ECO
×6
PP4×20
+SW+W
SBN ×2PP12
UF03
PP12
U104A
U101
H001
U102
U103
U801
U803
PP3×8
+SW+W ECO
×4
W661
W661
BITTB3×8SBN
×3
BITTB3×8
×2
BITTB3×8
×2
U104C
U802
PP08
PP12
PP08
3. Removethe boards (SIGNAL DVD-LCD, SEINE FOR FPD, D-TUNER, TN/AV-AOUT, LED-RMT,
POWER, AC-IN, LOWB) and speaker.
4. Removethe display.
BITTB4×16SBN
×12
BITTB4×16SBN
×4
B001
A201

- 15 -
EXPLODED VIEWS
1. Chassis Block
BITTB4×16SBN ×10
BITTB3×8 SBN
×5
BITTB3×8 SBN
BITTB3×8
SBN ×2
BITTB3×8
SBN ×2
BITTB3×8 SBN
×2
BITTB3×8 SBN
PP3×8+SW+W SBN
×6
PP3×8
+SW+W SBN
×3
PP5×16
SW+W SBN
×5
PP3×8
+SW+W
ECO ×2
PP3×8
+SW+W
SBN ×6
PP3×8
+SW+W
ECO
PP3×8
+SW+W ECO
×4
PP3×8+SW+W ECO
×4
PP4×20
+SW+W SBN
×2
PP3×8
+SW+W
ECO ×4
PP3×8+SW+W
SBN ×3
PP3×8
+SW+W SBN
×2
PP3×8+SW+W
SBN
PP3×8
+SW+W
SBN
A450
A401
A445
A340
PP08
A320
U104D
U104E
U104B
A420
4-40UNC
JFS-4S L=13
H003C
PP08
BD01
A545
UF01
A541
U104F

- 16 -
P801
BITTB4×16SBN
×12
PP3×8
+SW+W ECO
BITTB4×16SBN
×3
PP3×8+SW+W
ECO ×3
PP3×8+SW+W
ECO ×4
PP3×8+SW+W ECO
×6
PP3×8
+SW+W
ECO ×3
PP3×8
+SW+W ECO
×3
BITTB4×16
SBN×4
PP3×8
+SW+W ECO
×4
PP3×8+SW+W ECO
×7
PP3×8+SW+W ECO
×4
PP3×8+SW+W ECO
×6
PP4×20+SW+W SBN
×2
B001
W661
W661
A201
PP12
UF03
PP12
PP12
PP08
A315
BITTB3×8SBN
×3
BITTB3×8
×2
BITTB3×8
×2
U104A
U104C
U101
H001
U102
U103
U801
U803
U802
PP08
2. Main Block

- 17 -
PACKING DISASSEMBLY
A702B
A702B
A702A
A702A
K902Y170 Y101
A709
A701A
A705
A705
A701B

- 18 -
Location Parts No.Description
No.
Location Parts No.Description
No.
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “SERVICE SAFETY PRECAUTIONS” ON PAGE 3 OF THIS
MANUAL.
CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which
have special characteristics important for safety and should be replaced only with types identical to those in the original
circuit or specified in the parts list. The mounting position of replacements is to be identical with originals. Before replacing
any of these components, read carefully the SERVICE SAFETY PRECAUTIONS. Do not degrade the safety of the receiver
through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with ∗ mark is no longer available after the end of the production.
CHASSIS AND CABINET REPLACEMENT PARTS LIST
Model : 37HLX95
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CAPACITORS
C102 76073019 ELECTROLYTIC, 10V 470UF M 3A
C103 76109102 CERAMIC CHIP, 50V B 1000PF K
C104 76619143 ELECTROLYTIC CHIP, 50V 4.7UF M
C105 76073019 ELECTROLYTIC, 10V 470UF M 3A
C150 76073041 ELECTROLYTIC, 16V 470UF M 3A
C151 76109102 CERAMIC CHIP, 50V B 1000PF K
C152 76109102 CERAMIC CHIP, 50V B 1000PF K
C16176109102 CERAMIC CHIP, 50V B 1000PF K
C16276105101 CERAMIC CHIP, 50V CH 100PF J
C16476092730 CERAMIC CHIP, 16V B 0.1UF K
C16876109103 CERAMIC CHIP, 50V B 0.01UF K
C16976109103 CERAMIC CHIP, 50V B 0.01UF K
C605 76109102 CERAMIC CHIP, 50V B 1000PF K
C60676109102 CERAMIC CHIP, 50V B 1000PF K
C66076669479 ELECTROLYTIC, 50V 4.7UF M
C66176669479 ELECTROLYTIC, 50V 4.7UF M
C66276109681 CERAMIC CHIP, 50V B 680PF K
C66376109681 CERAMIC CHIP, 50V B 680PF K
C66876109102 CERAMIC CHIP, 50V B 1000PF K
C66976109102 CERAMIC CHIP, 50V B 1000PF K
C670 76669100 ELECTROLYTIC, 50V 10UF M
C671 76669100 ELECTROLYTIC, 50V 10UF M
C673 76619102 ELECTROLYTIC CHIP, 16V 47UF M
C674 76092731 CERAMIC CHIP, 16V B 1UF K
C677 76092731 CERAMIC CHIP, 16V B 1UF K
C678 76285104 CERAMIC CHIP, 50V B 0.1UF K
C679 76285104 CERAMIC CHIP, 50V B 0.1UF K
C680 76073073 ELECTROLYTIC, 35V 2200UF M 3A
C681 76073073 ELECTROLYTIC, 35V 2200UF M 3A
C682 76073073 ELECTROLYTIC, 35V 2200UF M 3A
C684 76109103 CERAMIC CHIP, 50V B 0.01UF K
C685 76092538 CERAMIC CHIP, 10V F 1UF Z
C690 76664102 ELECTROLYTIC, 6.3V 1000UF M 3A
C691 76092463 CERAMIC CHIP, 16V B 0.22UF K
C692 76092463 CERAMIC CHIP, 16V B 0.22UF K
C801 76168007 MT PLA AC275V 1UF M
C802 76503508 MT PLA PCX2 337 11474
C80676092555 CERAMIC DISC, AC250V E 1000PF M
C807 76092555 CERAMIC DISC, AC250V E 1000PF M
C808 76092553 CERAMIC DISC, AC250V B 470PF K
C809 76092553 CERAMIC DISC, AC250V B 470PF K
C812 76109102 CERAMIC CHIP, 50V B 1000PF K
C814 76109102 CERAMIC CHIP, 50V B 1000PF K
C815 76073037 ELECTROLYTIC, 16V 47UF M 3A
C81676109102 CERAMIC CHIP, 50V B 1000PF K
C817 76109102 CERAMIC CHIP, 50V B 1000PF K
C818 76669010 ELECTROLYTIC, 50V 1UF M
C819 76539684 PLASTIC FILM, 50V 0.68UF J
C820 76125010 ELECTROLYTIC CE69R 450V 270UF M 3H
C821 76125011 ELECTROLYTIC CE04R 450V 82UF M 4A
C822 76214103 CERAMIC DISC, 500V B 0.01UF K
C824 76168008 MT PLA 450V 1UF K
C825 76168008 MT PLA 450V 1UF K
C82676092339 CERAMIC DISC, 2KV 330PF K
C827 76092339 CERAMIC DISC, 2KV 330PF K
C840 76125009 ELECTROLYTIC 450V 47UF M
C843 76166001 CERAMIC DISK CC45 SL 3.15KV 47PF J
C844 76669479 ELECTROLYTIC, 50V 4.7UF M
C845 76073196ELECTROLYTIC, 50V 22UF M 3A
C84676073140 ELECTROLYTIC CE04P 10V 680UF M 3A
C847 76665471 ELECTROLYTIC, 10V 470UF M
C848 76214471 CERAMIC DISC, 500V B 470PF K
C86076214103 CERAMIC DISC, 500V B 0.01UF K
C86176503053 PLASTIC FILM, 63V 1UF J
C86276669229 ELECTROLYTIC, 50V 2.2UF M
C86376503049 PLASTIC FILM, 63V 0.47UF J
C86476567224 PLASTIC FILM, 50V 0.22UF J
C86576567224 PLASTIC FILM, 50V 0.22UF J
C866 76092341 CERAMIC DISC, 2KV R 470PF K
C86876435221 CERAMIC DISC, 500V SL 220PF J
C86976435221 CERAMIC DISC, 500V SL 220PF J
C870 76503425 PLASTIC FILM CQ92 3D2J473J-K5
C872 76073189 ELECTROLYTIC, 35V 1000UF M
C873 76073189 ELECTROLYTIC, 35V 1000UF M
C87676073204 ELECTROLYTIC CE04P 50V 330UF M 3A
C877 76669229 ELECTROLYTIC, 50V 2.2UF M
C878 76503041 PLASTIC FILM , 63V 0.1UF J
C880 76503229 PLASTIC FILM, 1250VH 1000PF H
C881 76092337 CERAMIC DISC, 2KV 220PF K
C882 76567334 PLASTIC FILM, 50V 0.33UF J
C883 76212221 CERAMIC DISC, 50V B 220PF K

Location Parts No.Description
No.
Location Parts No.Description
No.
- 19 -
C884 76073196ELECTROLYTIC, 50V 22UF M 3A
C885 76214471 CERAMIC DISC, 500V B 470PF K
C88676212152 CERAMIC DISC, 50V B 1500PF K
C887 76214471 CERAMIC DISC, 500V B 470PF K
C888 76073189 ELECTROLYTIC, 35V 1000UF M
C889 76073189 ELECTROLYTIC, 35V 1000UF M
C890 76796102 ELECTROLYTIC, 35V 1000UF M
C891 76214471 CERAMIC DISC, 500V B 470PF K
C892 76676100 ELECTROLYTIC, 100V 10UF M 3A
C893 76747220 ELECTROLYTIC, 50V 22UF M 7L 3A
C894 76214471 CERAMIC DISC, 500V B 470PF K
C895 76073188 ELECTROLYTIC, 35V 680UF M
C89676073188 ELECTROLYTIC, 35V 680UF M
C897 76796102 ELECTROLYTIC, 35V 1000UF M
C898 76669010 ELECTROLYTIC, 50V 1UF M
C1801 76285104 CERAMIC CHIP, 50V B 0.1UF K
C1802 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1803 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1804 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1805 76109103 CERAMIC CHIP, 50V B 0.01UF K
C180676109103 CERAMIC CHIP, 50V B 0.01UF K
C1807 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1808 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1809 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1810 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1811 76109103 CERAMIC CHIP, 50V B 0.01UF K
C8171 76092730 CERAMIC CHIP, 16V B 0.1UF K
C8191 76092730 CERAMIC CHIP, 16V B 0.1UF K
C8210 76105331 CERAMIC CHIP, 50V CH 330PF J
C8211 76815473 CERAMIC CHIP, 50V B 0.047UF K
C8212 76092178 CERAMIC CHIP, 25V B 0.1UF K
C8213 76109102 CERAMIC CHIP, 50V B 1000PF K
C8241 76073196ELECTROLYTIC, 50V 22UF M 3A
C8250 76092341 CERAMIC DISC, 2KV R 470PF K
C8251 76434100 CERAMIC DISC, 500V SL 10PF D
C8390 76109102 CERAMIC CHIP, 50V B 1000PF K
C8401 76092733 CERAMIC CHIP, 50V B 0.022UF K
C8402 76092733 CERAMIC CHIP, 50V B 0.022UF K
C8403 76669470 ELECTROLYTIC, 50V 47UF M
C8490 76669010 ELECTROLYTIC, 50V 1UF M
C8601 76591682 PLASTIC FILM, 50V 6800PF J
C8602 76212101 CERAMIC DISC, 50V B 100PF K
C8605 76285104 CERAMIC CHIP, 50V B 0.1UF K
C8701 76567224 PLASTIC FILM, 50V 0.22UF J
C8702 76287224 CHIP CER 50V F 224Z GRM319F11H224ZA01D
C8703 76109102 CERAMIC CHIP, 50V B 1000PF K
C8801 76092730 CERAMIC CHIP, 16V B 0.1UF K
C8802 76092883 CERAMIC CHIP, 50V B 0.1UF K
C8891 76503049 PLASTIC FILM, 63V 0.47UF J
CB01 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB02 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB03 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB04 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB05 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB38 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CC11 76109102 CERAMIC CHIP, 50V B 1000PF K
CC12 76109102 CERAMIC CHIP, 50V B 1000PF K
CC1676109102 CERAMIC CHIP, 50V B 1000PF K
CC17 76109102 CERAMIC CHIP, 50V B 1000PF K
CD41 76105330 CERAMIC CHIP, 50V CH 33PF J
CD42 76105330 CERAMIC CHIP, 50V CH 33PF J
CD43 76105330 CERAMIC CHIP, 50V CH 33PF J
CD45 76105330 CERAMIC CHIP, 50V CH 33PF J
CD4676105330 CERAMIC CHIP, 50V CH 33PF J
CD47 76105330 CERAMIC CHIP, 50V CH 33PF J
CD48 76105330 CERAMIC CHIP, 50V CH 33PF J
CD6176105330 CERAMIC CHIP, 50V CH 33PF J
CD6276105330 CERAMIC CHIP, 50V CH 33PF J
CD6376105330 CERAMIC CHIP, 50V CH 33PF J
CD6476105330 CERAMIC CHIP, 50V CH 33PF J
CD6576105330 CERAMIC CHIP, 50V CH 33PF J
CD66 76105330 CERAMIC CHIP, 50V CH 33PF J
CD6776105330 CERAMIC CHIP, 50V CH 33PF J
CD81 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD82 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD83 76109102 CERAMIC CHIP, 50V B 1000PF K
CD84 76109102 CERAMIC CHIP, 50V B 1000PF K
CD85 76105221 CERAMIC CHIP, 50V CH 220PF J
CD87 76092731 CERAMIC CHIP, 16V B 1UF K
CD88 76105221 CERAMIC CHIP, 50V CH 220PF J
CD89 76105221 CERAMIC CHIP, 50V CH 220PF J
CD90 76105221 CERAMIC CHIP, 50V CH 220PF J
CD91 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD92 76109102 CERAMIC CHIP, 50V B 1000PF K
CD93 76105101 CERAMIC CHIP, 50V CH 100PF J
CD94 76109102 CERAMIC CHIP, 50V B 1000PF K
CD95 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD9676619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CE05 76073090 ELECTROLYTIC, 50V 100UF M 3A
CE08 76073090 ELECTROLYTIC, 50V 100UF M 3A
CE10 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE11 76539474 PLASTIC FILM, 50V 0.47UF J
CE12 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE25 76668470 ELECTROLYTIC, 35V 47UF M 3A
CE40 76073186ELECTROLYTIC, 35V 470UF M
CE41 76617028 ELECTROLYTIC, 16V 1200UF M
CE42 76073020 ELECTROLYTIC, 10V 1000UF M 3A
CE43 76539104 PLASTIC FILM, 50V 0.1UF J
CE44 76539104 PLASTIC FILM, 50V 0.1UF J
CE45 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE4676539474 PLASTIC FILM, 50V 0.47UF J
CE47 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE6076073186ELECTROLYTIC, 35V 470UF M
CE6176617028 ELECTROLYTIC, 16V 1200UF M
CE6276073020 ELECTROLYTIC, 10V 1000UF M 3A
CE6376539104 PLASTIC FILM, 50V 0.1UF J
CE6476539104 PLASTIC FILM, 50V 0.1UF J
CE6576666470 ELECTORLYTIC, 16V 47UF M 3A
CE66 76539474 PLASTIC FILM, 50V 0.47UF J
CE6776666470 ELECTORLYTIC, 16V 47UF M 3A
CE70 76073189 ELECTROLYTIC, 35V 1000UF M
CE71 76073186ELECTROLYTIC, 35V 470UF M
CE72 76073128 ELECTROLYTIC, 6.3V 1000UF M
CE85 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE90 76073186ELECTROLYTIC, 35V 470UF M
CE91 76617028 ELECTROLYTIC, 16V 1200UF M
CE92 76666471 ELECTROLYTIC, 16V 470UF M 3A
CE93 76539104 PLASTIC FILM, 50V 0.1UF J
CE94 76539104 PLASTIC FILM, 50V 0.1UF J
CE95 76668101 ELECTROLYTIC, 35V 100UF M 3A
CS10 76092628 CERAMIC CHIP, 6.3V B 10UF K
CS11 76092628 CERAMIC CHIP, 6.3V B 10UF K
CS12 76109473 CERAMIC CHIP, 25V B 0.047UF K
CS15 76092628 CERAMIC CHIP, 6.3V B 10UF K
CS1676092628 CERAMIC CHIP, 6.3V B 10UF K
CS40 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS41 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS42 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS43 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS44 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS45 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4676092611 CERAMIC CHIP, 6.3V B 2.2UF K

Location Parts No.Description
No.
Location Parts No.Description
No.
- 20 -
CS47 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS48 76092538 CERAMIC CHIP, 10V F 1UF Z
CS49 76092538 CERAMIC CHIP, 10V F 1UF Z
CS50 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS51 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS52 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS53 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS54 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS55 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5676092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS57 76619102 ELECTROLYTIC CHIP, 16V 47UF M
CS6476619101 ELECTROLYTIC CHIP, 16V 22UF M
CS82 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS85 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS8676092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS501 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CS502 76092726CERAMIC CHIP, 10V B 2.2UF K
CS503 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CS504 76105470 CERAMIC CHIP, 50V CH 47PF J
CS505 76105470 CERAMIC CHIP, 50V CH 47PF J
CV10 76109102 CERAMIC CHIP, 50V B 1000PF K
CV59 76105220 CERAMIC CHIP, 50V CH 22PF J
CV6176105270 CERAMIC CHIP, 50V CH 27PF J
CV6276105330 CERAMIC CHIP, 50V CH 33PF J
CV6376092730 CERAMIC CHIP, 16V B 0.1UF K
CV6876092621 CERAMIC CHIP, 10V B 1UF K
CV6976092621 CERAMIC CHIP, 10V B 1UF K
CV72 76794471 ELECTROLYTIC, 16V 470UF M
CV74 76666101 ELECTROLYTIC, 16V 100UF M 3A
CV7676100104 CERAMIC CHIP, 25V F 0.1UF Z
CV122 76105101 CERAMIC CHIP, 50V CH 100PF J
CV26776619100 ELECTROLYTIC CHIP, 16V 10UF M
CV270 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV273 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV282 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV28676109103 CERAMIC CHIP, 50V B 0.01UF K
CV287 76619102 ELECTROLYTIC CHIP, 16V 47UF M
CV289 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV291 76109103 CERAMIC CHIP, 50V B 0.01UF K
CV292 76109103 CERAMIC CHIP, 50V B 0.01UF K
CV293 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV294 76109103 CERAMIC CHIP, 50V B 0.01UF K
RESISTORS
R103 76011101 CHIP, 1/20W 100 OHM J
R104 76011103 CHIP, 1/20W 10K OHM J
R105 76011273 CHIP, 1/20W 27K OHM J
R107 76000445 CHIP JUMPER, 1608TYPE
R108 76000445 CHIP JUMPER, 1608TYPE
R110 76011682 CHIP, 1/20W 6.8K OHM J
R114 76000445 CHIP JUMPER, 1608TYPE
R16176011102 CHIP, 1/20W 1K OHM J
R16576011392 CHIP, 1/20W 3.9K OHM J
R166 76011472 CHIP, 1/20W 4.7K OHM J
R16776011101 CHIP, 1/20W 100 OHM J
R16876011101 CHIP, 1/20W 100 OHM J
R66476011104 CHIP, 1/20W 100K OHM J
R66576011104 CHIP, 1/20W 100K OHM J
R670 76011472 CHIP, 1/20W 4.7K OHM J
R671 76011472 CHIP, 1/20W 4.7K OHM J
R672 76011182 CHIP, 1/20W 1.8K OHM J
R673 76011182 CHIP, 1/20W 1.8K OHM J
R678 76871229 CHIP, 1/8W 2.2 OHM J
R679 76871229 CHIP, 1/8W 2.2 OHM J
R680 76011473 CHIP, 1/20W 47K OHM J
R681 76011473 CHIP, 1/20W 47K OHM J
R683 76011103 CHIP, 1/20W 10K OHM J
R684 76011104 CHIP, 1/20W 100K OHM J
R685 76011222 CHIP, 1/20W 2.2K OHM J
R68676011102 CHIP, 1/20W 1K OHM J
R687 76871102 CHIP, 1/8W 1K OHM J
R688 76871102 CHIP, 1/8W 1K OHM J
R689 76871102 CHIP, 1/8W 1K OHM J
R690 76011473 CHIP, 1/20W 47K OHM J
R691 76011103 CHIP, 1/20W 10K OHM J
R692 76011223 CHIP, 1/20W 22K OHM J
R695 76871102 CHIP, 1/8W 1K OHM J
R69676871102 CHIP, 1/8W 1K OHM J
R697 76871102 CHIP, 1/8W 1K OHM J
R801 76017004 METAL GLAZE 1/2W 510K J
R809 76004718 METAL GLAZE, 1/2W 8.2M OHM J
R812 76011473 CHIP, 1/20W 47K OHM J
R820 76019461 METAL PLATE, 2W 0.15 OHM J
R821 76019461 METAL PLATE, 2W 0.15 OHM J
R82676004714 METAL GLAZE, 1/2W 1.2M OHM J
R830 76007061 CERAMIC COVERED, 2W 1.8 OHM K
R831 76120003 CERAMIC COVERED G 5W 4.7 J
R840 76382823 OXIDE FILM 1W 82K J
R841 76322339 METAL FILM 1W 3R3 J
R842 76310479 OXIDE METAL FILM, 1/2W 4.7 OHM J
R86076552271 OXIDE METAL FILM, 1/2W 270 OHM J
R86276552681 OXIDE METAL FILM, 1/2W 680 OHM J
R86376011272 CHIP, 1/20W 2.7K OHM J
R86476552101 OXIDE METAL FILM, 1/2W 100 OHM J
R86576552100 OXIDE METAL FILM, 1/2W 10 OHM J
R86776552330 OXIDE METAL FILM, 1/2W 33 OHM J
R880 76553683 OXIDE METAL FILM, 1W 68K OHM J
R881 76553683 OXIDE METAL FILM, 1W 68K OHM J
R882 76323569 METAL FILM 2W 5R6J
R883 76079010 METAL RES 2W R47 J
R884 76321339 OXIDE METAL FILM, 1/2W 3.3 OHM J
R885 76553101 OXIDE METAL FILM, 1W 100 OHM J
R88676554432 OXIDE FILM 2W 4.3K J
R4100 76011102 CHIP, 1/20W 1K OHM J
R4101 76011681 CHIP, 1/20W 680 OHM J
R4102 76011471 CHIP, 1/20W 470 OHM J
R4103 76011102 CHIP, 1/20W 1K OHM J
R4104 76011152 CHIP, 1/20W 1.5K OHM J
R4105 76011102 CHIP, 1/20W 1K OHM J
R410676011681 CHIP, 1/20W 680 OHM J
R4107 76011471 CHIP, 1/20W 470 OHM J
R4108 76011102 CHIP, 1/20W 1K OHM J
R4109 76011152 CHIP, 1/20W 1.5K OHM J
R4120 76000445 CHIP JUMPER, 1608TYPE
R4122 76000445 CHIP JUMPER, 1608TYPE
R6601 76011223 CHIP, 1/20W 22K OHM J
R6602 76011472 CHIP, 1/20W 4.7K OHM J
R6603 76011223 CHIP, 1/20W 22K OHM J
R6604 76011102 CHIP, 1/20W 1K OHM J
R6605 76011103 CHIP, 1/20W 10K OHM J
R660676011104 CHIP, 1/20W 100K OHM J
R8110 76000250 METAL FILM, 1/4W 56K OHM F
R8111 76000250 METAL FILM, 1/4W 56K OHM F
R8112 76000250 METAL FILM, 1/4W 56K OHM F
R8113 76000250 METAL FILM, 1/4W 56K OHM F
R8114 76000527 METAL FILM, 1/4W 5.6K OHM F
R8115 76000639 METAL FILM, 1/4W 22K OHM F
R811676000554 CHIP, 1/16W 510 F
R8117 76000574 METAL FILM CHIP 1/16W 2.7K F
R8118 76000574 METAL FILM CHIP 1/16W 2.7K F
R8130 76871182 CHIP, 1/8W 1.8K OHM J
R8131 76871182 CHIP, 1/8W 1.8K OHM J
