Toshiba MCU FLASH WRITER User manual

TOSHIBA MCU FLASH WRITER INSTRUCTION MANUAL
T.S ELECTRONICS
TOSHIBA MCU FLASH WRITER
INSTRUCTION MANUAL
Jan 2008
T.S ELECTRONICS
Copyright ⓒ 2006 TS ELECTONICS CO., LTD
All Right Reserved

TOSHIBA MCU FLASH WRITER INSTRUCTION MANUAL
T.S ELECTRONICS
1. Package Contents
1) TOSHIBA FLASH WRITER 2) USB-to-USB CABLE
4) INSTRUCTION MANUAL 5) INSTALL CD-ROM
The TOSHIBA MCU FLASH WRITER contains the following items
●TOSHIBA MCU FLASH WRITER
●USB-to-USB CABLE
●TOSHIBA FLASH WRITER INSTRUCTION MANUAL (Short Form)
●INSTALL CD-ROM
●On-Board CABLE
2. Software Setup
The following files are included on the CD-ROM
●TOSHIBA Flash Programmer (sw00fn5-zccuvxxx_en.exe)
●Driver installation utility (CP210x_ Drivers.exe)
●TOSHIBA Flash Programmer Manual (Kor,Eng)
2-1. Install Windows Virtual COM Port Driver
To install the Windows Virtual COM Port Driver, run CP210x_Drivers.exe on the CD-ROM
COM Port properties for the device can be selected in the device manager
(COM Port Number, Baud Rate etc.)
USB CONNECTOR
RESET SWITCH
POWER SWITCH
YAMAICHI SOCKET
CONNECTOR
For On-Bo ard Writing
Do not p ull out the U SB Cable whe n TOSHIB A Flash Pr ogrammer is runni ng.
2. Makea connection between FlashW riterand PC with USB Cable.
3. Turn on F lash Writ er and Exec ute TOSHIBA FlashProgrammer.
4. If youwant to make a reconnectionbetween two devices,
ClickRECONN ECT Icon onFlash Programmer and Push the RESET SWITCH on Fla sh Writer.
TOSHIBA FLASH WRITE R
OFF-BOARD WRITING
ON-BOARD WRITING
TargetB oard
Do not p ull out the U SB Cable whe n TOSHIB A Flash Pr ogrammer is runni ng.
2. Make a co nnection am ong Target Board and Flash W riter and PC w ith USB Cab le.
3. Turn on F lash Writ er and Exec ute TOSHIBA FlashProgrammer.
4. If youwant to make a reconnectionamong three devices,
ClickRECONN ECT Icon onFlash Programmer and Push the RESET SWITCH on Fla sh Writer.
1. Install CP210x_Drivers.exeincluded on the CD-ROM
1. Install CP210x_Drivers.exeincluded on the CD-ROM
TOSHIBA Flash Writer Simple Manual
TS ELECTRONICS CO., LTD.
2-2. Install TOSHIBA Flash Programmer
To install the TOSHIBA Flash Programmer, run sw00fn5-zccuvxxx_en.exe on the CD-ROM
If you want to know further information about the TOSHIBA Flash Programmer,
Please refer to the TOSHIBA Flash Programmer Manual on the CD-ROM
3) On-Board CABLE
●TOSHIBA MCU FLASH WRITER Instruction Manual

TOSHIBA MCU FLASH WRITER INSTRUCTION MANUAL
T.S ELECTRONICS
OFF-BOARD WRITING
ON-BOARD WRITING
3. Hardware Setup
The TOSHIBA MCU FLASH WRITER is connected to a PC as shown in Figure 1 and Figure2
1. Connect one end of the USB cable to a USB Port on the PC
2. Connect the other end of the USB cable to the USB connector on the TOSHIBA MCU FLASH WRITER
1. Connect one end of the USB cable to a USB Port on the PC
2. Connect the other end of the USB cable to the USB connector on the TOSHIBA MCU FLASH WRITER
3. Connect one end of the cable to the connector on the TOSHIBA MCU FLASH WRITER
4. Connect the other end of the cable to the connector on the TARGET BOARD
Figure 1. Hardware SETUP1
Figure 2. Hardware SETUP2
Target Board

TOSHIBA MCU FLASH WRITER INSTRUCTION MANUAL
T.S ELECTRONICS
4. Target Board
Refer to Figure 3 for the detail information about the TOSHIBA MCU FLASH WRITER
4-1. Universal Serial Bus (USB) Interface (T1)
A USB Connector is provided to facilitate connections to the USB interface on the FLASH WRITER
See Table 1 for the USB pin definitions.
Pin# Description
1VBUS
2D-
3D+
4GND
Figure 3. TOSHIBA MCU FLASH WRITER
Table1. USB Connector Pin Descriptions
USB CONNECTOR
RESET SWITCH
POWER SWITCH
YAMAICHI SOCKET
On-Board
Connector

TOSHIBA MCU FLASH WRITER INSTRUCTION MANUAL
T.S ELECTRONICS
4-2. On-Board Connector (T2)
A On-Board Connector is provided to connections to the Target Board for On-Board Writing
See Table 2 for the On-Board Connector pin definitions.
Pin# Signal Description
1VDD
2 TEST Test pin for serial mode
3 TX TxD output
4 RX RxD input
5 RST RESET signal input
6GND 0V
7GND 0V
8GND 0V
+5V
Table2. On-Board Connector Pin Descriptions
4-3. Actual Image
