SERVICE MANUAL

Projection Television

65H14

FILE NO. 023-200411

65H14 is the same as 51H84 except for the parts tabled on this manual.

Use this service manual together with the service manual of 46H84/51H84/57H84

(File No. 020-200404).

-

SUMMARY

-

SUPPLEMENT

CAPACITORS

C490 24073037 CAPACITOR, ELECTROLYTIC, 16V 47UF M 3A

C601 24109681 CAPACITOR, CERAMIC CHIP, 50V B 680PF K

C602 24109681 CAPACITOR, CERAMIC CHIP, 50V B 680PF K

C7110 24666470 CAPACITOR, ELECTORLYTIC, 16V 47UF M 3A

C7111 24666470 CAPACITOR, ELECTORLYTIC, 16V 47UF M 3A

RESISTORS

R174 24011273 RESISTOR, CHIP, 1/20W 27K OHM J

R349 24011392 RESISTOR, CHIP, 1/20W 3.9K OHM J

R367 24011392 RESISTOR, CHIP, 1/20W 3.9K OHM J

R610 24011273 RESISTOR, CHIP, 1/20W 27K OHM J

R900 24000961 RESISTOR, FUSIBLE, 2W 2.2 OHM J

R925 24872330 RESISTOR, CHIP, 1/16W 33 OHM J

R7701 24011392 RESISTOR, CHIP, 1/20W 3.9K OHM J

COIL & TRANSFORMERS

L490 23280019 COIL, PEAKING, TRF4330AZ

L840 23289843 COIL, PEAKING, TRF4330AT

MISCELLANEOUS

V901R 23078363 OTHER, COUPLING R

V903B 23078364 OTHER, COUPLING B

ZV60 23103778 FERRITE CORE, TFE1008

PC BOARD ASSEMBLIES

E031Z 23762337 PC BOARD ASSY, CRT/SVM/R PU PD1733C1

E032Z 23762338 PC BOARD ASSY, CRT/SVM/G PU PD1733C2

E033Z 23762339 PC BOARD ASSY, CRT/SVM/B PU PD1733C3

E034Z 23762340 PC BOARD ASSY, SVM/DIV PU PD1733C4

U401 23762552

PCBOARDASSY,DEFPOWER65H14 PUPD1730M

ACCESSORIES

A701 23067798 CARTON,CARTON65H14

A703 23946500 PACKING, TOP

A708 23946499 PACKING, BOTTOM

Y101 23566380 OWNERS MANUAL, ENGLISH/FRENCH 65H14

CABINET PARTS

A001 23429125 CABINET, WOOD CABINET SHIP

A102 23527359 GRILLE, SPEAKER GRILLE ASSEY 65H14

A201 23530796 COVER, BEZEL

A268 23530770 COVER, FRONT COVER

A331 23929899 PIECE, POLE BOTTOM LEFT

A332 23929900 PIECE, POLE BOTTOM RIGHT

K501 23311011 SCREEN, 65KNH LENTICULAR SHEET

K502 23311010 SCREEN, 65KN FRESNEL SHEET

K503 23311861 SCREEN, PROTECTOR 65RL

K601 23405415 MIRROR, 65WL

Location Parts No. Description

No.

CHASSIS AND CABINET REPLACEMENT PARTS LIST

TOSHIBA CORPORATION

1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-8001, JAPAN
