SERVICE MANUAL
COLOR TELEVISION/
DVD VIDEO PLAYER
FILE NO. 140-200106
MD20FL3

CAUTION
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READTHIS SERVICE MANUAL CARE-
FULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE,
CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE.
VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT
STARE INTO BEAM.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS,
21 CFR SUBCHAPTER J.

SERVICING NOTICES ON CHECKING
6. AVOID AN X-RAY1. KEEP THE NOTICES
As for the places which need special attentions,
they are indicated with the labels or seals on the
cabinet, chassis and parts. Make sure to keep the
indications and notices in the operation manual.
3. USE THE DESIGNATED PARTS
5. TAKE CARE TO DEAL WITH THE
CATHODE-RAY TUBE
In the condition that an explosion-proof cathode-
ray tube is set in this equipment, safety is
secured against implosion. However, when
removing it or serving from backward, it is
dangerous to give a shock. Take enough care to
deal with it.
Safety is secured against an X-ray by consider-
ing about the cathode-ray tube and the high
voltage peripheral circuit, etc.
Therefore, when repairing the high voltage pe-
ripheral circuit, use the designated parts and
make sure not modify the circuit.
Repairing except indicates causes rising of high
voltage, and it emits an X-ray from the cathode-
ray tube.
Please include the following informations when you order parts. (Particularly the VERSION LETTER.)
1. MODEL NUMBER and VERSION LETTER
The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be
found at the end of the SERIAL NUMBER.
2. PART NO. and DESCRIPTION
You can find it in your SERVICE MANUAL.
HOW TO ORDER PARTS
PERFORM A SAFETY CHECK AFTER
SERVICING
7.
Confirm that the screws, parts and wiring which
were removed in order to service are put in the
original positions, or whether there are the
portions which are deteriorated around the
serviced places serviced or not. Check the
insulation between the antenna terminal or
external metal and the AC cord plug blades.
And be sure the safety of that.
(INSULATION CHECK PROCEDURE)
1.
2.
3.
4.
Unplug the plug from the AC outlet.
Remove the antenna terminal on TV and turn
on the TV.
Insulation resistance between the cord plug
terminals and the eternal exposure metal
[Note 2] should be more than 1M ohm by
using the 500V insulation resistance meter
[Note 1].
If the insulation resistance is less than 1M
ohm, the inspection repair should be
required.
[Note 1]
If you have not the 500V insulation
resistance meter, use a Tester.
[Note 2]
External exposure metal: Antenna terminal
Earphone jack
2. AVOID AN ELECTRIC SHOCK
There is a high voltage part inside. Avoid an
electric shock while the electric current is
flowing.
The parts in this equipment have the specific
characters of incombustibility and withstand
voltage for safety. Therefore, the part which is
replaced should be used the part which has
the same character.
Especially as to the important parts for safety
which is indicated in the circuit diagram or the
table of parts as a mark, the designated
parts must be used.
4. PUT PARTS AND WIRES IN THE
ORIGINAL POSITION AFTER
ASSEMBLING OR WIRING
There are parts which use the insulation
material such as a tube or tape for safety, or
which are assembled in the condition that
these do not contact with the printed board.
The inside wiring is designed not to get closer
to the pyrogenic parts and high voltage parts.
Therefore, put these parts in the original
positions.

IMPORTANT SAFEGUARDS
1.
2.
3.
4.
5.
6.
7.
8.
8A.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
ATTACHMENTS
Do not use attachments not recommended by the unit’s manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a
swimming pool.
ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall,
causing serious injury, and serious damage to the unit. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance and cart combination to overturn.
VENTILATION
Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure reliable operation of the unit, and
to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing
the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat source. This
unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufac-
turer’s instructions have been adhered to.
POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the type of
power supply to your home, consult your appliance dealer or local power company. For units intended to operate from battery
power, or other sources, refer to the operating instructions.
GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit
into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug. If your unit is equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin, this plug will only fit
into a grounding-type power outlet. This too, is a safety feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges.
POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or
where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits, as contact with them might be fatal.
OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could
result in fire or electric shock. Never spill or spray any type of liquid into the unit.
OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide
some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A

IMPORTANT SAFEGUARDS (CONTINUED)
DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions:
REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or
those that have the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric shock or other hazards.
SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit
is in proper operating condition.
WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
DISC TRAY
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure
to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and
follow the instructions when making any connections.
SOUND VOLUME
Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause
hearing or speaker damage.
SOUND DISTORTION
Do not allow the product output distorted sound for a longtime. It may cause speaker overheating and fire.
HEADPHONES
When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume
sound, it may cause hearing damage.
LEASER BEAM
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser beam. It may cause
sight damage.
DISC
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and
product malfunction.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as
close to the point of cable entry as practical.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
a.
b.
c.
d.
e.
f.
When the power-supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen into the unit.
If the unit has been exposed to rain or water.
If the unit does not operate normally by following the operating instructions. Adjust only those controls that are covered by
the operating instructions, as an improper adjustment of other controls may result in damage and will often require extensive
work by a qualified technician to restore the unit to its normal operation.
If the unit has been dropped or the cabinet has been damaged.
When the unit exhibits a distinct change in performance, this indicates a need for service.
EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A

GENERAL SPECIFICATIONS
G-1 TV CRT CRT Size / Visual Size 20 Inch / 508.0 mmV
System CRT Type FLAT
Deflection 90 degree
Magnetic Field BV/BH +0.45G/0.18G
Color System NTSC
Speaker 2 Speaker
Position Front
Size 3 Inch
Impedance 8 Ohm
Sound Output Max 2.5x2.5 W
10%(Typical) 2.0x2.0 W
G-2 DVD System Color System NTSC
Disc DVD, CD-DA
Disc Diameter 120 mm , 80 mm
Deck Disc Loading System Front Loading
Motor 3 Motors
Pick up 1-Lens 2-Beams System
Playback time(Max) DVD 1-Layer 135min (4.7GB)
DVD 2-Layer 245min (8.5GB)
CD 74min
VIDEO CD --min
Search speed Fwd 2-20 times
Actual 2-45 times
Rev 2-20 times
Actual 2-45 times
Slow speed Fwd 1/7-1/2 times
Actual --
Rev 1/7 -1/2 times
Actual 1-2 times
G-3 Tuning Broadcasting System US System M
System Tuner and System 1Tuner
Receive CH Channel Tuner Others
Tuning System F-Synth
Input Impedance VHF/UHF 75 Ohm
CH Coverage 2~69, 4A, A-5~A-1, A~I, J~W,
W+1~W+
8
4
Intermediate Picture(FP) 45.75MHz
Frequency Sound(FS) 41.25MHz
FP-FS 4.50MHz
Preset CH --
Stereo/Dual TV Sound Yes
NTSC Playback (PAL60) No
G-4 Power Power Source AC 120V, 60Hz
DC --
Power Consumption at AC 120W at 120V 60Hz
at DC --
Stand by (at AC) 8 W at 120V 60Hz
Per Year -- kWh/Year
Power Supply Cord UL
Protector Power Fuse Yes
G-5 Signal Video Signal Input Level 1 V p-p/75 ohm
Output Level 1 V p-p/75 ohm
S/N Ratio (Weighted) 65dB
Horizontal Resolution at DVD Mode 400 Lines (TV Monitor)
500 Lines ( Video Out)
RGB Signal Output Level -- V p-p/75 ohm
Audio Signal Input Level RCA -8.0dB/50Kohm
Output Level RCA -8.0dB/1Kohm
S/N Ratio at DVD (Weighted) 90 dB
Harmonic Distortion 0.01% (1KHz)
Frequency Response : at DVD 4Hz - 22KHz
at VIDEO CD --
at CD 4Hz - 20KHz
Digital Audio Signal Output Level 0.5 V p-p/75 ohm

GENERAL SPECIFICATIONS
G-6 Interface Switch Front Power (Tact) Yes
Channel Up Yes
Channel Down Yes
Volume Up Yes
Volume Down Yes
Play Yes
Open/Close Yes
Skip(>>) Yes
Skip(<<) Yes
Still/Pause No
Stop Yes
Main Power SW No
Rear AC/DC No
Color On/Off (SECAM Only) No
Degauss No
Main Power SW No
Indicator Power Red
Stand-by No
On Timer No
Terminals Front Video Input Yes
Audio Input Yes (Stereo)
Other Terminal Head Phone
Rear Video Input(Rear1) Yes
Video Input(Rear2) No
Audio Input(Rear1) Yes (Stereo)
Audio Input(Rear2) No
Video Output Yes
Audio Output Yes (Stereo)
Euro Scart No
Digital Audio Output Coaxial
Optical Audio Output No
Color Stream No
Diversity No
Ext Speaker No
DC Jack 12V(Center +) No
VHF/UHF Antenna Input F Type
AC Outlet No
G-7 Set Size Approx. W x D x H (mm) 574x483x514.5
G-8 Weight Net (Approx.) 25.5kg
Gross (Approx.) 29.0kg
G-9 Regulation Safety UL
Radiation FCC
X-Radiation DHHS
G-10 Temperature Operation 5oC ~ 40oC
Storage -20oC ~ 60oC
G-11 Operating Humidity Less than 80% RH

GENERAL SPECIFICATIONS
G-12 On Screen Menu(TV) Yes
Display Menu Type Icon
Picture Yes
Contrast Yes
Brightness Yes
Color Yes
Tint Yes
Sharpness Yes
Sound Yes
Bass Yes
Treble Yes
Balance Yes
CH Yes
Auto CH Memory Yes
ADD/DELETE Yes
TV/CATV Yes
Option Yes
Language Yes
V-Chip Yes
Clock No
Clock Set No
On/Off Timer No
Sleep Timer Yes
CH/AV/DVD Yes
Stereo, Audio Output, Bilingual No
Stereo, Mono, SAP(Stereo Only) Yes
Stereo, Audio Output No
Sound 1/2 No
SAP (Stereo Only) Yes
NICAM Auto Off No
Closed Caption Yes
System Select No
Area Code No
Pin Code Registration No
Pin Code No
DVD RGB /Composite No
Game Yes
Hotel Lock No
Volume Yes
Sound Mute No
On Screen Menu(DVD) Yes
Display Menu Type Character
Rating Level Yes
Audio Yes
Sub Title Yes
TV Screen Size Yes
OSD Display On/Off Yes
Menu Language Yes
Audio Output No
Set Up Language Yes
Password Lock/Unlock Yes
Open Yes
Close Yes
No disc Yes
Reading Yes
Play Yes
Still/Pause Yes
Stop Yes
Prohibit Mark Yes
Step Yes
Next Yes
Back Yes
Random Yes(CD Only)
Repeat Yes
Slow+ ## Yes
Slow- ## Yes
Search+ ## Yes
Search- ## Yes
Jump Yes
Resume Yes
Title No. Yes
Chapter No. Yes
Track No. Yes
Time Yes
Sub Title On/Off No
Angle No. Yes
Vocal On/Off Yes
Audio No. Yes
Audio Stereo L/R No
Zoom Yes
Marker No. Yes
Program Play Back Yes(CD Only)

GENERAL SPECIFICATIONS
G-13 OSD Language (TV) Eng, Fre, Spa
(DVD) Eng, Fre, Spa
G-14 Remote Unit RC-EF
Control Glow in Dark Remocon No
Format NEC
Custom Code 71-8E h
Power Source Voltage(D.C) 3V
UM size x pcs UM-4 x 2 pcs
Keys Total 45 Key
Power Yes
1 Yes
2 Yes
3 Yes
4 Yes
5 Yes
6 Yes
7 Yes
8 Yes
9 Yes
0 Yes
Open/Close No
Play Yes
Stop Yes
Search+ Yes
Search- Yes
Skip+ Yes
Skip- Yes
Slow+ Yes
Slow- Yes
Still/Pause Yes
Display/Call Yes
TV/DVD Yes
Clear/Reset Yes
Audio/Audio Sel. Yes
Angle Yes
Subtitle Yes
Subtitle On/Off No
Title Yes
Set up/TV Menu <TV MENU> Yes
Return Yes
Menu DVD <SET UP> Yes
Up/ Set+/ CH Up Yes
Down/ Set-/ CH Down Yes
Left/Select- Yes
Right/Select+ Yes
Select/Enter Yes
Play Mode Yes
Closed Caption Yes
Input Yes
Volume+ Yes
Volume- Yes
Repeat A-B Yes
Zoom/ Quick View Yes
Mute No
Sleep Yes
Jump Yes
Text/Mix/TV No
Game Yes

GENERAL SPECIFICATIONS
G-15 Features Auto Degauss Yes
Auto Shut Off Yes
Auto Power On, Auto Play No
Canal+ No
CATV Yes
Anti-theft No
Rental No
Memory(Last CH) Yes
Memory(Last Volume) Yes
V-Chip Yes
Type --
BBE No
Fast Text No
UniText No
Top Text No
Auto Search No
CH Allocation No
SAP Yes
Channel Lock No
Just Clock Function No
Game Position Yes
CH Label No
VM Circuit No
Area Code No
FM Transmitter No
Energy Star No
TV Monitor No
Closed Caption Yes
Full OSD Yes
Premiere No
Comb Filter Yes
2 Lines
Parental Lock (DVD Only) Yes
Auto CH Memory Yes
Hotel Lock No
Stable Sound No
Favorite CH No
Digital Out (Dolby Digital) Yes
(PCM) Yes
(DTS) Yes
Down Mix Out (Dolby Digital) Yes
Self Diagnostic No
MP3 Playback No
G-16 Accessories Owner's Manual Language Eng
w/Guarantee Card Yes
Guarantee Card No
Registration Card(NDL Card) No
Registration Card Yes
Warranty Card No
Information Sheet No
ESP Card Yes
Toll Free Insert Sheet No
Warning Sheet No
Survice Information Sheet No
Quick Set-up Sheet No
Euro Warranty Information Sheet No
Dew/AHC Caution Sheet No
PTB Sheet No
Circuit Diagram No
Service Facility List No
Service Station List No
Inportant Safeguard No
Remote Control Unit Yes
Rod Antenna No
Poles No
Terminal --
Loop Antenna No
Terminal --
75 Ohm Coaxial Cable No
--
21pin Cable No
U/V Mixer No
Channel Film No
Battery Yes
UM size x pcs UM-4 x 2 pcs
OEM Brand No
DC Car Cord (Center+) No
AC Cord No
AV Cord (2Pin-1Pin) No
AC Plug Adaptor No
Safety Tip No
Anntena Change Plug No
300 ohm to 75 ohm Antenna Adapter Yes

GENERAL SPECIFICATIONS
G-17 Carton Master Carton No
Content --- Sets
Material --- / ---
Dimensions W x D x H(mm) ---
Description of Origin ---
Gift Box Yes
Material Double/White
W/Color Phote Label No
Dimensions W x D x H(mm) 647x620x625
Design As Per Buyer 's
Description of Origin Yes
Drop Test Natural Dropping At 1
C
orner
/
3 Edges
/
6
Su
rf
aces
Height (cm) 31
Container Stuffing 171 Sets/40' container
G-18 Cabinet Material Cabinet Front PS, 94V0
Cabinet Rear PS, 94V0

DISASSEMBLY INSTRUCTIONS
1. REMOVAL OF MECHANICAL PARTS
AND P.C. BOARDS
1-1: BACK CABINET (Refer to Fig. 1-1)
1.
2.
3.
4.
Remove the 6 screws 1.
Remove the 2 screws 2which are used for holding the
Back Cabinet.
Remove the AC cord from the AC cord hook 3.
Remove the Back Cabinet in the direction of arrow.
1-3: TV/DVD BLOCK (Refer to Fig. 1-3)
1.
2.
3.
Remove the 2 screws 1.
Disconnect the following connectors:
(CP102, CP303, CP401 and CP502).
Remove the TV/DVD Block in the direction of arrow.
Fig. 1-3
TV/DVD Block
1
1
1-4: MAIN PCB (Refer to Fig. 1-4)
1.
2.
3.
4.
Remove the 2 screws 1.
Remove the 3 screws 2.
Disconnect the following connectors:
(CP403, CP810B, CP820B and CP811).
Remove the Main PCB in the direction of arrow.
Fig. 1-4
1
1
Main PCB
DVD Block
1-2: CRT PCB (Refer to Fig. 1-2)
CAUTION: BEFORE REMOVING THE ANODE CAP,
DISCHARGE ELECTRICITY BECAUSE IT
CONTAINS HIGH VOLTAGE.
BEFORE ATTEMPTING TO REMOVE OR
REPAIR ANY PCB, UNPLUG THE POWER
CORD FROM THE AC SOURCE.
1.
2.
3.
Remove the Anode Cap.
(Refer to REMOVAL OF ANODE CAP)
Disconnect the following connectors:
(CP801 and CP850B).
Remove the CRT PCB in the direction of arrow.
CRT PCB
Front Cabinet
Fig. 1-1
Front Cabinet
1
1
2
2
1
1Back Cabinet
1
1
3
Fig. 1-2
Front Cabinet
2
2
2

DISASSEMBLY INSTRUCTIONS
1-5: FRONT TRAY PLATE/TOP SHIELD
(Refer to Fig. 1-5)
1.
2.
3.
Remove the Front Tray Plate in the direction of arrow (A).
Remove the 9 screws 1.
Remove the Top Shield in the direction of arrow (B).
Front Tray Plate
1
1
1
11
1
1
1
1
Top Shield
DVD Block Fig. 1-5
1-6: AV PCB/SYSCON PCB/CD DECK (Refer to Fig. 1-6)
1.
2.
3.
4.
5.
6.
7.
8.
9.
Remove the 3 screws 1.
Remove the AV PCB in the direction of arrow (A).
Remove the 4 screws 2.
Remove the Angle Deck in the direction of arrow (B).
Disconnect the following connectors:
(CP4001 and CP4002).
Remove the 4 screws 3.
Remove the CD Deck in the direction of arrow (C).
Remove the 4 screws 4.
Remove the Syscon PCB in the direction of arrow (D).
Fig. 1-5
1
1
1
Bottom Plate
22
2
2
Angle Deck
AV PCB
(A)
(B)
4
4
4
Syscon PCB
4
(D)
3
(C)
(B)
(A)
3
3
CD Deck
3

2. REMOVAL OF ANODE CAP
Read the following NOTED items before starting work.
After turning the power off there might still be a potential
voltage that is very dangerous. When removing the
Anode Cap, make sure to discharge the Anode Cap's
potential voltage.
Do not use pliers to loosen or tighten the Anode Cap
terminal, this may cause the spring to be damaged.
*
*
REMOVAL
1. Follow the steps as follows to discharge the Anode Cap.
(Refer to Fig. 2-1.)
Connect one end of an Alligator Clip to the metal part of a
flat-blade screwdriver and the other end to ground.
While holding the plastic part of the insulated Screwdriver,
touch the support of the Anode with the tip of the
Screwdriver.
A cracking noise will be heard as the voltage is discharged.
Flip up the sides of the Rubber Cap in the direction of
the arrow and remove one side of the support.
(Refer to Fig. 2-2.)
2.
GND on the CRT
Screwdriver
Alligator Clip
Support CRT
GND on the CRT
Rubber Cap
CRT Support
Fig. 2-1
Fig. 2-2
3. After one side is removed, pull in the opposite direction
to remove the other.
NOTE
DISASSEMBLY INSTRUCTIONS
INSTALLATION
1. Clean the spot where the cap was located with a small
amount of alcohol. (Refer to Fig. 2-3.)
NOTE
Confirm that there is no dirt, dust, etc. at the spot where
the cap was located.
2.
3.
Arrange the wire of the Anode Cap and make sure the
wire is not twisted.
Turn over the Rubber Cap. (Refer to Fig. 2-4.)
Fig. 2-4
4. Insert one end of the Anode Support into the anode
button, then the other as shown in Fig. 2-5.
CRT Support Fig. 2-5
5.
6. Confirm that the Support is securely connected. Put on the Rubber Cap without moving any parts.
Location of Anode Cap
Fig. 2-3
Take care not to damage the Rubber Cap.

SERVICE MODE LIST
This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily.
To enter the Service Mode, press both set key and remote control key.
Press both the VOL. key and remocon keys simultaneously for more than 1 second.
Press both the STOP key and remocon keys simultaneously for more than 3 seconds.
Set Key Remocon Key Operations
Initialization of the factory on TV.
NOTE: No operation at DVD mode.
Do not use this for the normal servicing.
Initialization of the factory on DVD.
NOTE: The operation will work only with STOP mode at DVD mode.
Do not use this for the normal servicing.
VOL. (-) MIN 1
POWER ON total hours are displayed on the screen.
Refer to the "CONFIRMATION OF USING HOURS".
NOTE: No operation at DVD mode.
Can be checked of the INITIAL DATA of MEMORY IC on TV.
Refer to the "NOTE FOR THE REPLACING OF MEMORY IC".
NOTE: No operation at DVD mode.
VOL. (-) MIN 3
VOL. (-) MIN 6
VOL. (-) MIN 0Releasing of V-CHIP PASSWORD.
Writing of EEPROM initial data on TV.
NOTE: No operation at DVD mode.
Do not use this for the normal servicing.
VOL. (-) MIN 9 Display of the Adjustment MENU on the screen.
Refer to the "ELECTRICAL ADJUSTMENT" (On-Screen Display Adjustment).
STOP 7 Releasing of PARENTAL LOCK.
NOTE: The operation will work only with STOP mode at DVD mode.
VOL. (-) MIN 8
CONFIRMATION OF USING HOURS
POWER ON total hours can be checked on the screen. Total hours are displayed in 16 system of notation.
1.
2.
3.
Set the VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel
button (6) on the remote control for more than 1 second.
After the confirmation of using hours, turn off the power.
INIT 00 83
0010
CRT ON
ADDRESS DATA
FIG. 1
Initial setting content of MEMORY IC.
POWER ON total hours.
= (16 x 16 x 16 x thousands digit value)
+ (16 x 16 x hundreds digit value)
+ (16 x tens digit value)
+ (ones digit value)

If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to
ensure correct data settings while making reference to TABLE 1.
No need the setting for the INI 4E~6A.
NOTE FOR THE REPLACING OF MEMORY IC
F9 43 25 01 F1 23 27 F7 81 CD
+0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +A +B +C +D +E +FINI
64 67 69 2A 6B 6C 6D 6E 6F
54 74 55 75 75 56 56 76 76 57
78 59 59 79 79 5A 5A 7A 7A 5B
7C 5D 7D 7D 5E 5E 7E 7E 5F
D9 3F 3F 40 61 6300
10 26 70 71 52 72 53 73
20 57 77 77 58 58 78
30 5B 7B 7B 5C 5C 7C
40 5D 5F 5F 7F 7F --- ---
--- --- --- --- --- --- --- --- ---
--- --- --- --- --- --- --- --- --- ---
50 --- --- --- --- --- --- ---
60 --- --- --- --- ---
INIT 00 83
0010
CRT ON
ADDRESS DATA
3.
4.
5.
6.
7.
8.
The unit will now have the correct DATA for the new MEMORY IC.
Table 1
1.
2.
Fig. 1
Enter DATA SET mode by setting VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 1 second.
ADDRESS and DATA should appear as FIG 1.
ADDRESS is now selected and should "blink". Using the VOL. UP/DOWN button on the remote, step through the
ADDRESS until required ADDRESS to be changed is reached.
Press ENTER to select DATA. When DATA is selected, it will "blink".
Again, step through the DATA using VOL. UP/DOWN button until required DATA value has been selected.
Pressing ENTER will take you back to ADDRESS for further selection if necessary.
Repeat steps 3 to 6 until all data has been checked.
When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input.
10

ELECTRICAL ADJUSTMENTS
1.
Read and perform these adjustments when repairing the
circuits or replacing electrical parts or PCB assemblies.
CAUTION
•
•
•
•
Use an isolation transformer when performing any
service on this chassis.
Before removing the anode cap, discharge electricity
because it contains high voltage.
When removing a PCB or related component, after
unfastening or changing a wire, be sure to put the wire
back in its original position.
Inferior silicon grease can damage IC's and transistors.
When replacing IC's and transistors, use only specified
silicon grease.
Remove all old silicon before applying new silicon.
Prepare the following measurement tools for electrical
adjustments.
BEFORE MAKING ELECTRICAL
ADJUSTMENTS
1. Oscilloscope
2. Digital Voltmeter
3. AC Voltmeter
4. Pattern Generator
2. BASIC ADJUSTMENTS
2-1: CONSTANT VOLTAGE
1.
2.
3.
4.
Set condition is AV MODE without signal.
Using the remote control, set the brightness and contrast
to normal position.
Connect the digital voltmeter to TP401.
Adjust the VR502 until the digital voltmeter is 111 ±0.5V.
Fig. 1-2
NO.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
FUNCTION
BRI. AV(CENT.)
BRI. AV(MAX)
BRI. AV(MIN)
COL. AV(CENT.)
COL. AV(MAX)
COL. AV(MIN)
TINT AV
SUB CONTRAST AV
CONT. AV(CENT.)
CONT. AV(MAX)
CONT. AV(MIN)
SHARPNESS AV
BRI. DVD(CENT.)
BRI. DVD(MAX)
BRI. DVD(MIN)
COL. DVD(CENT.)
COL. DVD(MAX)
COL. DVD(MIN)
TINT DVD
SUB CONTRAST DVD
CONT. DVD(CENT.)
CONT. DVD(MAX)
CONT. DVD(MIN)
SHARPNESS DVD
BRI. GAME(CENT.)
BRI. GAME(MAX)
BRI. GAME(MIN)
CONT. GAME(CENT.)
CONT. GAME(MAX)
CONT. GAME(MIN)
TUNING V MUTE
POWER ON V MUTE
INPUT LEVEL
SEPARATION L
SEPARATION H
CUT OFF
NO.
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
FUNCTION
R CUT OFF
G CUT OFF
B CUT OFF
G DRIVE
B DRIVE
BRIGHTNESS(CENT.)
BRIGHTNESS(MAX)
BRIGHTNESS(MIN)
COLOR(CENT.)
COLOR(MAX)
COLOR(MIN)
TINT
SUB CONTRAST
CONTRAST(CENT.)
CONTRAST(MAX)
CONTRAST(MIN)
SHARPNESS
RGB CONTRAST
H POSITION
V POSITION
V SIZE
V LINEARITY
V S CORRECTION
EW PARABOLA CORR.
EW TRAPEZIUM CORR.
H SIZE
V EHT
H EHT
RF AGC
V CENTERING
CORNER CORR. TOP
CORNER CORR. BTM
OSD H
FM LEVEL
TEST PWM
TEST TONE CONTROL
2-2: RF AGC
1.
2.
3.
4.
5.
Receive the VHF HIGH (63dB).
Place the set with Aging Test for more than 15 minutes.
Connect the digital voltmeter between the pin 5 of
CP101 and the pin 1 of CP101.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (29) on the remote control to
select "AGC".
Press the RIGHT/LEFT button on the remote control
until the digital voltmeter is 2.7 ±0.05V.
2-3: CUT OFF
1.
2.
3.
4.
5.
6.
Adjust the unit to the following settings.
G DRIVE=3F, B DRIVE=3F, R CUT OFF=7F, G CUT
OFF=7F, B CUT OFF=7F
Place the set with Aging Test for more than 15 minutes.
Set condition is AV MODE without signal.
Using the remote control, set the brightness and contrast
to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (72) on the remote control to
select "CUT OFF".
Adjust the Screen Volume until a dim raster is obtained.
On-Screen Display Adjustment
In the condition of NO indication on the screen.
Press the VOL. DOWN button on the set and the
Channel button (9) on the remote control for more than
1 second to appear the adjustment mode on the screen
as shown in Fig. 1-1.
1.
Fig. 1-1
Use the Channel UP/DOWN button or Channel button
(1-0) on the remote control to select the options shown
in Fig. 1-2.
Press the MENU button on the remote control to end
the adjustments.
2.
3.
01 RCUT
3E
Function
Step No.

ELECTRICAL ADJUSTMENTS
2-4: WHITE BALANCE
NOTE: Adjust after performing CUT OFF adjustment.
1.
2.
3.
4.
5.
6.
7.
8.
Place the set with Aging Test for more than 15 minutes.
Receive the white 100% signal from the Pattern
Generator.
Using the adjustment control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (01) on the remote control to
select "RCUT".
Using the RIGHT/LEFT button on the remote control,
adjust the RCUT.
Press the CH. UP/DOWN button on the remote control to
select the "GDRV", "BDRV", "GCUT" or "BCUT".
Using the RIGHT/LEFT button on the remote control,
adjust the GDRV, BDRV, GCUT or BCUT.
Perform the above adjustments 6 and 7 until the white
color is looked like a white.
2-5: FOCUS
1.
2.
3.
Receive the monoscope pattern.
Turn the Focus Volume fully counterclockwise once.
Adjust the Focus Volume until picture is distinct.
2-6: HORIZONTAL POSITION
1.
2.
3.
4.
Receive the center cross signal from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (19) on the remote control to
select "HPOSI".
Press the RIGHT/LEFT button on the remote control
until the right and left screen size of the vertical line
becomes the same.
2-7: HORIZONTAL SIZE
NOTE: Adjust after performing adjustments in section 2-6.
1.
2.
3.
4.
Receive the monoscope pattern.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (26) on the remote control to
select "WIDS".
Press the RIGHT/LEFT button on the remote control
until the SHIFT quantity of the OVER SCAN on right
and left becomes 10 ±2%.
2-8: VERTICAL LINEALITY
NOTE: Adjust after performing adjustments in section 2-7.
1.
2.
3.
4.
Receive the center cross signal from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (22) on the remote control to
select "VLIN".
Press the RIGHT/LEFT button on the remote control
until the upside and downside screen size of the
horizontal line becomes the same.
2-9: VERTICAL SHIFT
NOTE: Adjust after performing adjustments in section 2-8.
2-10: VERTICAL SIZE
NOTE: Adjust after performing adjustments in section 2-9.
1.
2.
3.
4.
Receive the center cross signal from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (20) on the remote control to
select "VPOSI".
Press the RIGHT/LEFT button on the remote control
until the horizontal line becomes fit to the notch of the
shadow mask.
1.
2.
3.
4.
5.
Receive the crosshatch signal from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (21) on the remote control to
select "VSIZE".
Press the RIGHT/LEFT button on the remote control
until the rectangle on the center of the screen becomes
square.
Receive a broadcast and check if the picture is normal.
2-11: PARABOLA CORR
1.
2.
3.
4.
Receive the rainbow pattern from the Pattern Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (24) on the remote control to
select "DPCS".
Press the RIGHT/LEFT button on the remote control
until the right and left vertical lines are straight.
1.
2.
3.
4.
2-12: TRAPEZIUM
Receive the rainbow pattern from the Pattern Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (25) on the remote control to
select "KEYS".
Press the RIGHT/LEFT button on the remote control
until the both vertical lines of the screen become
parallel.
2-13: CORNER CORR TOP
1.
2.
3.
4.
Receive the rainbow pattern from the Pattern Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (31) on the remote control to
select "CNRT".
Press the RIGHT/LEFT button on the remote control
until the upper section of the both ends vertical lines are
straight.

ELECTRICAL ADJUSTMENTS
1.
2.
3.
4.
2-14: CORNER CORR BOTTOM
Receive the rainbow pattern from the Pattern Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (32) on the remote control to
select "CNRB".
Press the RIGHT/LEFT button on the remote control
until the bottom section of the both ends vertical lines
are straight.
2-18: SUB BRIGHT CENTER
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Receive the monoscope pattern. (RF Input)
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (06) on the remote control to
select "BRTC".
Press the RIGHT/LEFT button on the remote control
until the white 15% is starting to be visible
Receive the monoscope pattern. (Audio Video Input)
Press the INPUT SELECT button on the remote control
to set to the AV mode.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (37) on the remote control to
select "BRTCA".
Press the RIGHT/LEFT button on the remote control
until the white 15% is starting to be visible
Press the TV/DVD button on the remote control to set to
the DVD mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (49) on the remote control to
select "BRTCD".
Press the RIGHT/LEFT button on the remote control to
set the same step numbers as the AV.
Press the GAME button on the remote control to set to
the GAME mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (61) on the remote control to
select "BRTCG".
Press the RIGHT/LEFT button on the remote control to
decrease the step numbers by 16 steps to the AV.
2-19: SUB CONTRAST MAX
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (15) on the remote control to
select "CNTX".
Press the RIGHT/LEFT button on the remote control
until the contrast step No. becomes "5E"
Press the INPUT SELECT button on the remote
control to set to the AV mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (46) on the remote control to
select "CNTXA".
Press the RIGHT/LEFT button on the remote control
until the contrast step No. becomes "61"
Press the TV/DVD button on the remote control to set
to the DVD mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (58) on the remote control to
select "CNTXD".
Press the RIGHT/LEFT button on the remote control
until the contrast step No. becomes "61"
Press the GAME button on the remote control to set to
the GAME mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (65) on the remote control to
select "CNTXG".
Press the RIGHT/LEFT button on the remote control
until the contrast step No. becomes "61"
2-15: OSD HORIZONTAL
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (33) on the remote control to
select "OSD".
Press the RIGHT/LEFT button on the remote control
until the difference of A and B becomes minimum.
(Refer to Fig. 2-1)
1.
2.
BA Fig. 2-1
33 OSD
15
1.
2.
3.
4.
Receive the VHF HIGH (70dB).
Connect the AC voltmeter to TP901.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (69) on the remote control to
select "LVL".
Press the RIGHT/LEFT button on the remote control
until the AC voltmeter is 75 ±2mV.
2-16: LEVEL
1.
2.
3.
4.
5.
6.
7.
8.
9.
2-17: SEPARATION L/H
Receive the stereo signal (L=2KHz, R=400Hz).
Connect the AC voltmeter to AUDIO OUT JACK though
stereo filter (L=400Hz, R=2KHz).
Press the AUDIO button on the remote control to set to
the STEREO mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (70) on the remote control to
select "SEPAL".
Press the RIGHT/LEFT button on the remote control until
the output of L-CH and R-CH become minimum.
Press the CH UP button once the set to "SEPAH" mode.
Press the RIGHT/LEFT button on the remote control until
the output of L-CH and R-CH become minimum.
Press the CH DOWN button once the set to "SEPAL"
mode.
Repeat step 5 to step 8 several times.
The output difference of the between with Filter and
without Filter should be more than 20dB for both L and R.

ELECTRICAL ADJUSTMENTS
2-20: SUB TINT CENTER
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Receive the color bar pattern. (RF Input)
Using the remote control, set the brightness, contrast,
color and tint to normal position.
Connect the oscilloscope to TP803.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (12) on the remote control to
select "TNTC".
Press the RIGHT/LEFT button on the remote control
until the waveform becomes as shown in Fig. 2-2.
Receive the color bar pattern. (Audio Video Input)
Press the INPUT SELECT button on the remote
control to set to the AV mode.
Using the remote control, set the brightness, contrast,
color and tint to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (43) on the remote control to
select "TNTCA".
Press the RIGHT/LEFT button on the remote control
until the waveform becomes as shown in Fig. 2-2.
Press the TV/DVD button on the remote control to set
to the DVD mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (55) on the remote control to
select "TNTCD".
Press the RIGHT/LEFT button on the remote control
until the waveform becomes as shown in Fig. 2-3.
Fig. 2-2
Fig. 2-3
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
2-21: SUB COLOR CENTER
Receive the color bar pattern. (RF Input)
Using the remote control, set the brightness, contrast,
color and tint to normal position.
Connect the oscilloscop to TP801.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (09) on the remote control to
select "COLC".
Adjust the VOLTS RANGE VARIABLE knob of the
oscilloscope until the range between white 100% and
0% is set to 4 scales on the screen of the oscilloscope.
Press the RIGHT/LEFT button on the remote control
until the red color level is adjusted to 120 ±5% of the
white level. (Refer to Fig. 2-4)
Receive the color bar pattern. (Audio Video Input)
Press the INPUT SELECT button on the remote control
to set to the AV mode.
Using the remote control, set the brightness, contrast,
color and tint to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (40) on the remote control to
select "COLCA".
Adjust the VOLTS RANGE VARIABLE knob of the
oscilloscope until the range between white 100% and
0% is set to 4 scales on the screen of the oscilloscope.
Press the RIGHT/LEFT button on the remote control
until the red color level is adjusted to 120 ±5% of the
white level. (Refer to Fig. 2-4)
Press the TV/DVD button on the remote control to set
to the DVD mode.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (52) on the remote control to
select "COLCD".
Press the RIGHT/LEFT button on the remote control to
increase the step numbers by 3 steps to the AV.
0%
Fig. 2-4
White 0%
White 100%
100%
Red Level
