COLOR TELEVISION RECEIVER

Chassis : KS1B(P)

Model : CS21K9MLDC/DWP

COLOR TELEVISION RECEIVER CONTENTS

Precautions

Specifications and IC Data

Disassembly and Reassembly

Alignment and Adjustment

Troubleshooting

Exploded View and Parts List

Electrical Parts List

Block Diagram

Wiring Diagram

Schematic Diagrams

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

Alignment and Adjustments

Samsung Electronics 4-1

4. Alignment and Adjustments

4-1 Preadjustment

4-1-1 Factory Mode

1. Do not attempt these adjustments in the Video

Mode.

2. The Factory Mode adjustments are necessary

when either the EEPROM (IC202) or the CRT

is replaced.

3. Do not tamper with the “Adjustment” screen

of the Factory Mode menu. This screen is

intended only for factory use.

4-1-2 When EEPROM (IC202) Is Replaced

1. When IC202 is replaced all adjustment data

revert to initial values. It is necessary to

re-program this data.

2. After IC202 is replaced, warm up the TV for

10 seconds.

4-1-3 When CRT Is Replaced

1. Make the following adjustments AFTER set-

ting up after setting up purity and conver-

gence :

White Balance

Sub-Brightness

Vertical Center

Vertical Size

Horizontal Size

Fail Safe (This adjustment must be the last

step).

2. If the EEPROM or CRT is replaced and set SC

as 30(factory mode).

4-2 Factory/Service Mode

4-2-1 Procedure for the “Adjustment” Mode

1. This mode uses the standard remote control.

The Service Mode is activated by entering the

following remote-control sequence :

(1) DISPLAY → FACTORY.

(2) STAND-BY → MUTE →1 →8 →2

→POWER ON.

2. The “SERVICE (FACTORY)” message will be

displayed. The Service Mode has four compo-

nents: ADJUST, OPTION , G2-ADJUST and

RESET.

3. Access the Adjustment Mode by pressing the

“VOLUME” keys ( Up or Down). The adjust-

ment parameters are listed in the accompany-

ing table, and selected by pressing the CHAN-

NEL keys ( , ).

4. Selection sequences for the all system:

DOWN or UP key:

SCT>SBT>BLR>BLB>RG>GG>BG>VSL>VS>

VA>HS>SC>CDL>STT>AKB>PDL>NDL>

PSR>NSR>SCBT>VOL>CAP>MVOL>RP00>

RP01>FMWS>AGC1>OMD>SCL>PWL>

MUS>AGC

5. The VOLUME keys increase or decrease the

adjustment values (stored in the

non-volatile memory) when Adjustment Mode

is cancelled.

6. Cancel the Adjustment Mode by re-pressing

the “FACTORY” or “Power OFF” keys.

4-2-2 Main Adjustment Parameter

Alignment and Adjustments

4-2 Samsung Electronics

SCT Sub Cont ras t 0 ~ 23

0~23

SBT Sub Bright ness

BLR

Black Level offset Blue

BLB

Black Level offset Red

RG Red Gain 0 ~ 63

GG Green Gain 0 ~ 63

0~63

BG Blue Gai n 0 ~ 63

VSL Vert ical Slope 0 ~ 63

VS Ver t ical Shif t 0 ~ 63

VA Vert ical Ampli tud e 0 ~ 63

HS Horizontal Shif t 0 ~ 63

SC S- Cor r ec t i on 0 ~ 63

CDL Cat hode Drive Level 0 ~ 15

STT Sub Tint 0 ~ 7

AKB AKB On / off 0 ~ 1

0~1

0~3

PDL P AL Del ay 0 ~ 1 5

0~15

0~50

NDL NTSC Delay 0 ~ 15

PSR PAL Sub color 0 ~ 23

NSR NTSC Sub color 0 ~ 23

SCBT Screen Brighrtness 0 ~ 63

VOL Volume pre set t i ng 0 ~ 63

0~63

CAP Caption Position

Melody Sound Volume

Ratio Pre / overshoot

Window Selection Sound PLL

IF AGC Speed

Offset IF Demodulator

Soft Clipping Level

Peak White Limitting

Matrix USA

Automatic Gain Control

MVOL

RP00

RP01

FMWS

AGC1

OMD

SCL

PWL

MUS

AGC

15

8

35

32

40

25

42

30

31

25

32

30

9

3

0

2

0

20

7

40

10

12

7

1

0

1

32

3

15

0

27

(12)

(3)

(37)

(33)

(38)

25

(39)

(32)

31

(25)

(33)

30

9

3

0

2

0

20

7

40

10

12

7

1

0

1

32

3

15

0

(27)

FIX

FIX (Mono)

FIX (Nomal)

FIX

FIX (Off)

FIX (100%)

FIX (Mono)

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

ONO S D F U N CT I ON R A N G E I N I T I A L D AT A SETTING RE M ARK

Alignment and Adjustments

Samsung Electronics 4-3

4-2-3 Option Bytes

In the Service Mode, various can be selected via the Option Table. Example:

1

2

3

4

5

6

7

8

9

10

11

Option Table : xx xx

OSD

VIDEO MUTE

AUDIO

E/W

ZOOM

AUTO POWER

AUDIO MUTE

LANGUAGE

HOTEL MODE

BULE SCREEN

2'nd SIF

V-CHIP

SETTING

OFF

STEREO

OFF

NOR/ZOOM

OFF

ON

ENGLISH

OFF

INTERNAL

ON

- Video Mute On/Off changing the channel

- Audio Option (Mono / Steeo)

- E/W Option

- Picture Size Option

- Master S/w Option

- Audio Mute On/ Off without signal

- Inital Language agter Factory Reset

- Hotel mode On/ Off

- Bule Screen On/ Off without signal

- SIF Option at Mono sound

- V-CHIP On/Off

REMARK

Alignment and Adjustments

4-4 Samsung Electronics

4-3 Other Adjustments

4-3-1 General

1. Usually, a color TV needs only slight touch-

up adjustment upon installation. Check the

basic characteristics such as height, horizontal

and vertical sync and focus.

2. The picture should have good black and white

details. There should be no objectionable

color shading; if color shading is present, per-

form the purity and convergence adjustments

described below.

3. Use the specified test equipment or its equiva-

lent.

4. Correct impedance matching is essential.

5. Avoid overload. Excessive signal from a sweep

generator might overload the front-end of the

TV. When inserting signal markers, do not

allow the marker generator to distort test

results.

6. Connect the TV only to an AC power source

with voltage and frequency as specified on the

backcover nameplate.

7. Do not attempt to connect or disconnect any

wires while the TV is turned on. Make sure

that the power cord is disconnected before

replacing any parts.

8. To protect against shock hazard, use an isola-

tion transformer.

4-3-2 Automatic Degaussing

A degaussing coil is mounted around the pic-

ture tube, so that external degaussing after

moving the TV should be unnecessary. But

the receiver must be properly degaussed upon

installation.

The degaussing coil operates for about 1 sec-

ond after the power is switched ON. If the set

has been moved or turned in a different direc-

tion, disconnect its AC power for at least 30

minutes.

If the chassis or parts of the cabinet become

magnetized, poor color purity will result. If

this happens, use an external degaussing coil.

Slowly move the degaussing coil around the

faceplate of the picture tube and the sides and

front of the receiver. Slowly withdraw the coil

to a distance of about 6 feet before removing

power.

4-2-4 RESET

The Reset Mode is used during factory inspection.

Function Reset:

1. Picture Mode Custom

2. Sound Mode Custom

3. Auto Volume Off

4. Melody On

5. Surround Off

6. Turbo Sound Off

7. MTS Stereo

8. Language English

9. Caption Off

10. Timer Off

Alignment and Adjustments

Samsung Electronics 4-5

4-3-3 High Voltage Check

CAUTION: There is no high voltage adjustment on this chassis.

The B+ power supply must be set to +125 volts (Full color bar input

and normal picture level).

1. Connect a digital voltmeter to the second

anode of the picture tube.

2. Turn on the TV. Set the Brightness and

Contrast controls to minimum (zero beam cur-

rent).

3. The high voltage should not exceed 30KV.

4. Adjust the Brightness and contrast controls to

both extremes. Ensure that the high voltage

does not exceed 30KV under any conditions.

4-3-4 FOCUS Adjustment

1. Input a black and white signal.

2. Adjust the tuning control for the clearest pic-

ture.

3. Adjust the FOCUS control for well defined

scanning lines in the center area of the screen.

4-3-5 Cathode Voltage Adjustment

(Screen Adjustment)

1. Connect CRT socket pin GK to an oscilloscope

probe.

2. Input a gray scale pattern. (Use a pattern gen-

erator, PM5518)

3. Use the P mode key (on the remote control)

for the STANDARD picture.

4. Adjust the Screen VR (on the FBT) so that the

voltage on the oscilloscope becomes 125+2.5V

(See Fig. 4-1).

4-3-6 Purity Adjustment

1. Warm up the receiver for at least 20 minutes.

2. Plug in the CRT deflection yoke and tighten

the clamp screw.

3. Plug the convergence yoke into the CRT and

set in as shown in Fig. 4-2.

4. Input a black and white signal.

5. Fully demagnetize the receiver by applying an

external degaussing coil.

6. Turn the CONTRAST and BRIGHTNESS con-

trols to maximum.

7. Loosen the clamp screw holding the yoke.

Slide the yoke backward or forward to pro-

vide vertical green belt. (Fig. 4-3).

8. Tighten the convergence yoke.

9. Slowly move the deflection yoke forward,

and adjust for the best overall green screen.

10. Temporarily tighten the deflection yoke.

11. Produce blue and red rasters by adjusting the

low-light controls. Check for good purity in

each field.

12. Tighten the deflection yoke.

Fig. 4-1

125 2.5V

+

_

GND

_

Alignment and Adjustments

4-6 Samsung Electronics

4-3-7 White Balance Adjustment

Fig. 4-2 Convergence Magnet Assembly

4 Pole Magnet

6 Pole Magnet 2 Pole Magnet

Clamper

Screw

2 POLE

PURITY

YOKE

CLAMP

SCREW

6 POLE

CONVERGENCE

4 POLE

CONVERGENCE

ADJUST THE ANGLE

(VERTICAL LINES)

Fig. 4-3 Center Convergence Adjustment

31m/m

Vertical Green Belt

Fig. 4-4

1

2

(a) Set up

1. Warm up the TV for at least 30 minutes in the

Aging Mode (OSD White). This mode is dis-

played by entering the following sequence:

DISPLAY →FACTORY →FACTORY

2. Input a Toshiba pattern.

(b) Low-Light Adjustment

1. Set SBT to 1.0 fL in the Factory Service

Mode with using CA100. See Fig. 4-4.

2. Adjust RG,BG so that the levels are suitable to

each local area.

(c) High-Light Adjustment

1. Set SCT to 35 FL in the Factory Service Mode

with using CA100.

See Fig. 4-4 .

Alignment and Adjustments

Samsung Electronics 4-7

4-3-8 Center Convergence Adjustment

1. Warm up the receiver for at least 20 minutes.

2. Adjust the two tabs of the 4 pole magnets to

change the angle between them. Superimpose

the red and blue vertical lines in the center

area of the screen.

3. Adjust the Brightness and Contrast controls

for a well defined picture.

4. Adjust the two-tab pairs of the 4 pole mag-

nets, and change the angle between them.

Superimpose the red and the blue vertical

lines in the center area of the screen.

5. Turn the both tabs at the same time, keeping

the angle constant, and superimpose the red

and blue horizontal line in the center of the

screen.

6. Adjust the two-tab pairs of the 6-pole magnets

to superimpose the red and blue line onto the

green. (Changing the angle affects the vertical

lines, and rotating both magnets affects the

horizontal lines.)

7. Repeat adjustments 2~6, if necessary.

8. Since the 4-pole magnets and 6-pole magnets

interact, the dot movement is complex

(Fig. 4-5).

Fig. 4-5 Center Convergence Adjustment

RED

BLUE

RED

4-Pole Magnet Movement

GREEN

RED/BLUE

GREEN

6-Pole Magnet Movement

4-3-9 RF AGC Adjustment

Set the AGC data to 27 (Factory Mode).

4-3-10 Sub-Color Adjustment

Set data to (Factory Mode).

4-3-11 Geometry Adjustment

SC →VS→VA→VSL→HS

1. Input a lion head pattern.

2. Set the SC (S-Correction) as 30 and VS(Vertical

Shift) 31 so that the lion head circle becomes

oval.

3. Adjust with VA (Vertical Amplitude) so that

the top margin of the picture is 4.

Fig. 4-7

4. Adjust with VSL (Vertical-Slope) so that the

bottom margin of the picture is 4.

Fig. 4-8

5. Adjust with HS (Horizontal Shift) so that the

lion-head pattern and CRT centers are aligned.

Fig. 4-9

6. Adjust HS (Horizontal Shift) so that the left

and right margins of the picture are 5.

Alignment and Adjustments

4-8 Samsung Electronics

4

55

4

PSR

NSR 20

7

Samsung Electronics

Troubleshooting

5-1

5. Troubleshooting

5-1 No Power

LED Off

LED On

Abnormal

Normal

Abnormal

Counect

the Power code

Check

the

Power LED

Check the

X-tal,SDA,SCL port

of IC201S

Check the

(33)Pin (H-Drive)

of IC201S

Check the

130V- A Line

Check the

3.3V-A,8V-A Line

of IC201S

Check/Replace

IC802

Replace

IC201 S

Check the

FBT,D808

Check the

12.5V-A Line

Check the

FD802S, IC801S

or AC-Fuse

Check / Replace

Q401

5-2 Samsung Electronics

5-2 No Video (Sound OK)

Troubleshooting

Nornal

Abnormal

Check RK,GK,BK

Signal

Check R,G,B

Signal into CRT

PCB

Check the

resistance of R512

Check IC201S

Pin 49(V-GUARD)

Pin50(IK)

Check IC501

B+(180V-B)

Check the

Voltage of heater

Check

CRT and FBT

Check/Replace

D407,FBT

Re-Adjust

Screen Voltage

Replace

R512

Check

CRT and FBT

Check/Replace

IC201S

Check/Replace

R418,R513,D503

Check IC201S

Pin 51,52,53

(R.G.B)

5-3 No Sound (Video OK)

Troubleshooting

Samsung Electronics 5-3

Normal

Checkthe signal

Output from CN602

CN603

Check

Speaker and Wire

Check/Replace

IC601

Check

B+ Line

5V-B, 8V-B

Check

IC101,TUNER

Check/Replace

IC201S

See

No Power

Check

IC101,TUNER

Replace

IC602

Replace

IC610,R611

Replace

FD801S,D805

Check IC602

Pin8,9

Check IC601

Pin47(SIF)

Check IC601

B+

Check IC201S

Pin32(SIF)

Check IC602

B+

Check

R610,R611

Check FD801S

D805

Abnormal

* MONO

* STEREO

5-4 Samsung Electronics

Troubleshooting

5-4 Horizontal Lines Appear or Screen

Normal

Abnormal

Check

R413,R414

D405,D406

Check

IC201S

Check IC201S

Pin 21,22

(VDN,VDP)

Check IC301 B+

16V-C,-13.5V-C

Check / Replace

IC301

TP01

TP02

TP03

TP04 TP05

TP06

TP12

TP11

TP10

TP08

TP09

TP07

Schematic Diagrams

10-1Samsung Electronics

10. Schematic Diagrams

10-1 MAIN(1/3)

: Power Line

: Signal Line

TP01 TP02

TP04

TP05

TP07 TP08

TP10

TP11

TP03

TP06

TP09

TP12

Schematic Diagrams

10-2 Samsung Electronics

10-2 MAIN(2/3)

TP02

TP01

TP05

TP04

TP03

TP01

TP02

: Power Line

: Signal Line

TP03

TP04

TP05

Schematic Diagrams

10-3Samsung Electronics

10-3 MAIN(3/3)

TP02

TP01

TP02

: Power Line

: Signal Line

Schematic Diagrams

10-4 Samsung Electronics

10-4 CRT

Electrical Parts List

Samsung Electronics 7-1

ASSY PARTS

1 AA98-01902C ASSY PARTS;CS21K9MLDC/DWP

..2 T0089 AA27-00113A COIL DEGAUSSING;-,-,4.8mH,-,48T,9ohm,-,2

..2 T0074 AA59-00231C REMOCON;,TM59,DREAM,29,G6671B,S/S,GAME,E

..2 AA91-02193E ASSY MISC-POWER CORD;,KS1ACP2/NO(4.0),H/ S.N.A

...3 T0077 AA39-10006X CBF POWER CORD;-,KKP419C,KLCE-2F,2.286MT

...3 AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 S.N.A

..2 AA91-06460A ASSY SPEAKER;,8OHM,3001-001037,AA39-2050

...3 T0082 3001-001037 SPEAKER;5W,8OHM,89DB,180HZ

...3 T0076 AA39-20505N LEAD CONNECTOR-ASSY; ,4P,350,550MM,YSH02

..2 AA98-00128A ASSY TBC WIRE(P);DP,21INCH,AA98-00125A,2 S.N.A

..2 AA98-00293A ASSY K/D-CRT;A51QDX992X001(NF),+380MG,21 S.N.A

...3 T0063 AA03-00302A CRT COLOR;A51QDX992X001(NF),+380MG,1.85M

..2 AA98-00336E ASSY K/D-SUB MATERIAL;,S15A,PAKISTAN S.N.A

...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A

..2 AA98-01176A ASSY K/D-P/MATERIAL;CKD ALL MODEL S.N.A

...3 AA60-40006A PIN-STAPLE;AUTO,33X17.8X2.4,H18,33X17.8X S.N.A

...3 AA63-10007C BAND-PP;W18,CLEA,1G S.N.A

...3 WOODEN AA63-10007C BAND-PP;W18,CLEA,1G S.N.A

...3 6902-000022 BAG PE;LDPE,T0.08,L250,W90,TRP,,,PE MARK S.N.A

...3 AA69-90001A CHEMICALS-SILICAGEL;-,-,-,-,-,M2,5GR,-,- S.N.A

..2 AA98-01445A ASSY K/D-ACCESSORY;CS21K3SDC/DWP,PAKISTA

...3 T0080 AA26-90001C TRANS MATCHING;-,300ohm/75ohm,PAL,40-890

...3 T0075 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,-

...3 6902-000009 BAG PE;HDPE,T0.03,L400,W240,TRP,8,2,PE M S.N.A

...3 CIS AA68-02022A MANUAL USERS;,ENG,W/P100G,ALL1,B5,KS1A,3

...3 6801-001063 CARD-REGISTRATION;-,SAMSUNG,ENG+ARAB,MOJ S.N.A

..2 T0073 AA98-01910E ASSY K/D-PCB MAIN(COM);,KS1B CKD

...3 D208 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

...3 D301 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

...3 D804 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

...3 D206 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

...3 D103 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

...3 D102 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

...3 D803 0401-000006 DIODE-SWITCHING;BAV21,250V,250mA,DO-35,T

...3 T0083 0402-000010 DIODE-RECTIFIER;RGP15G,400V,1.5A,DO-204A

...3 T0083 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP

...3 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP

...3 T0083 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L

...3 T0083 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T

...3 T0083 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP

...3 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T

...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,

...3 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20

...3 T0083 0402-001160 DIODE-BRIDGE;D5SB60,600V,6A,SIP-4,-

...3 T0083 0402-001230 DIODE-RECTIFIER;FMG-G2CS,1000V,3A,TO-220

...3 T0083 0402-001296 DIODE-RECTIFIER;FMP-3FU,1.5KV,5A,TO-3PF,

...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500

...3 DZ016 0403-000510 DIODE-ZENER;MTZJ6.2B,6.2V,5.96-6.27V,500

...3 DZ016 0403-000699 DIODE-ZENER;TZP27B,27V,27-30.8V,1W,DO-41

...3 DZ016 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T

...3 DZ016 0403-000716 DIODE-ZENER;MTZJ4.7B,4.7V,4.55-4.8V,500m

...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500

...3 DZ016 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D

...3 DZ016 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D

...3 DZ016 0403-001317 DIODE-ZENER;MTZJ3.0B,3.01-3.22V,500mW,DO

...3 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500mW,DO

...3 DZ016 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO

...3 DZ016 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D

...3 DZ016 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D

...3 DZ016 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D

...3 Q301 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T

...3 Q211 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T

...3 Q209 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T

...3 Q206 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T

...3 Q205 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T

...3 Q208 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 Q210 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 Q601 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 Q602 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 Q102 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 Q106 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 Q207 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

...3 T0090 0502-000242 TR-POWER;KSA614,PNP,25W,TO-220,TP,40-24

...3 T0090 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6

...3 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST

...3 IC112 1103-001213 IC-EEPROM;M24C16-WBN6,2048x8Bit,SDIP,8P,

...3 IC604 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL

...3 IC012 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL

...3 IC101 1204-001583 IC-IF CIRCUIT;U4468B,DIP,16P,-,PLASTIC,5

...3 IC601 1204-001713 IC-SOUND PROCESSOR;MSP3465G-B8-V3,DIP,52

...3 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T

...3 P803T 1404-001156 THERMISTOR-PTC;9OHM,+30%/-20%,220VRMS,27

...3 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP

...3 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm

...3 R125 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R306 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM

...3 R806 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M

...3 R624 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M

7-1 CS21K9MLDC/DWP

Level Loc. No. Code No. Description ; Specification Remark

7. Electrical Parts List

Level Loc. No. Code No. Description ; Specification Remark

You can search for the updated part code through ITSELF web site.

URL : http://itself.sec.samsung.co.kr

...3 R623 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M

...3 R405 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M

...3 R809 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4

...3 R125 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R125 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM

...3 R514 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4

...3 R402 2001-001077 R-CARBON(S);150OHM,5%,1/2W,AA,TP,2.4X6.4

...3 R812 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4

...3 R404 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA,TP,2.4X6.4

...3 R825 2001-001131 R-CARBON(S);33KOHM,5%,1/2W,AA,TP,2.4X6.4

...3 R804 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.

...3 R803 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.

...3 R807 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4

...3 R808 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4

...3 R810 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AA,TP,2.4X6.4

...3 R403 2001-001199 R-CARBON(S);91OHM,5%,1/2W,AA,TP,2.4X6.4M

...3 R511 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7

...3 R502H 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7

...3 R501H 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7

...3 RX801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x

...3 RY801S 2002-001012 R-COMPOSITION;8.2Mohm,5%,1/2W,AA,TP,3.7x

...3 R408 2003-000540 R-METAL OXIDE(S);1Kohm,5%,2W,AF,TP,4x12m

...3 R831 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12

...3 R830 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12

...3 R802 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12

...3 R801 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12

...3 R818 2003-000998 R-METAL OXIDE;300ohm,5%,2W,AF,TP,3.9x10m

...3 R310 2003-000998 R-METAL OXIDE;300ohm,5%,2W,AF,TP,3.9x10m

...3 R309 2003-000998 R-METAL OXIDE;300ohm,5%,2W,AF,TP,3.9x10m

...3 R832 2003-001035 R-METAL OXIDE(S);27ohm,5%,2W,AF,TP,3.9x1

...3 R420 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x

...3 R419 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x

...3 R423 2003-002007 R-METAL OXIDE(S);4.7Kohm,5%,2W,AF,TP,3.9

...3 R407 2003-002008 R-METAL OXIDE(S);18Kohm,5%,2W,AF,TP,3.9x

...3 R821 2003-002064 R-METAL OXIDE;7.5ohm,5%,2W,AF,TP,10x3.9m

...3 R820 2003-002064 R-METAL OXIDE;7.5ohm,5%,2W,AF,TP,10x3.9m

...3 R819 2003-002064 R-METAL OXIDE;7.5ohm,5%,2W,AF,TP,10x3.9m

...3 R312 2003-002070 R-METAL OXIDE;1ohm,5%,2W,AF,TP,3.9x10mm

...3 R024 2004-001371 R-METAL(S);1.5Kohm,1%,1/2W,AA,TP,2.4x6.4

...3 R024 2004-001377 R-METAL(S);120Kohm,1%,1/2W,AA,TP,2.4x6.4

...3 R024 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm

...3 R024 2004-001402 R-METAL(S);6.8Kohm,1%,1/2W,AA,TP,2.4x6.4

...3 R024 2004-001405 R-METAL(S);79Kohm,1%,1/2W,AA,TP,2.4x6.4m

...3 R280 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm

...3 R024 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6.

...3 R513 2008-000292 R-FUSIBLE(S);3.3ohm,5%,2W,AF,TP,3.9x10mm

...3 R815 2008-000294 R-FUSIBLE(S);33ohm,5%,2W,AF,TP,3.9x10mm

...3 R512 2008-000299 R-FUSIBLE(S);47ohm,5%,2W,AF,TP,3.9x10mm

...3 R816 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10

...3 R414 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10

...3 R413 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10

...3 R610 2008-001088 R-FUSIBLE(S);1ohm,5%,2W,AG,TP,3.9x12mm

...3 R611 2008-001116 R-FUSIBLE(S);0.68ohm,10%,2W,AG,TP,3.9x12

Electrical Parts List

7-2 Samsung Electronics

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

Electrical Parts List

Samsung Electronics 7-3

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

...3 C598 2201-000132 C-CERAMIC,DISC;0.1NF,10%,500V,Y5P,TP,6.5

...3 C598 2201-000262 C-CERAMIC,DISC;0.18NF,10%,50V,Y5P,TP,4X3

...3 C598 2201-000304 C-CERAMIC,DISC;0.001NF,0.25PF,50V,C0G,TP

...3 C598 2201-000332 C-CERAMIC,DISC;2.2NF,20%,250V,Y5U,TP,9X4

...3 C598 2201-000374 C-CERAMIC,DISC;0.22NF,5%,50V,C0G,TP,10.5

...3 C598 2201-000446 C-CERAMIC,DISC;3.3NF,20%,400V,Y5U,TP,15X

...3 C598 2201-000467 C-CERAMIC,DISC;0.33NF,10%,2KV,Y5P,TP,6.3

...3 C598 2201-000556 C-CERAMIC,DISC;0.47NF,10%,500V,Y5P,TP,5.

...3 C598 2201-000573 C-CERAMIC,DISC;0.047NF,5%,50V,C0G,TP,5X3

...3 C598 2201-000599 C-CERAMIC,DISC;0.56NF,10%,500V,Y5P,TP,5.

...3 C598 2201-000639 C-CERAMIC,DISC;0.68NF,10%,2KV,Y5P,TP,9X5

...3 C598 2201-000723 C-CERAMIC,DISC;4.7NF,20%,3KV,Y5U,TP,16X5

...3 C598 2201-000991 C-CERAMIC,DISC;0.56NF,10%,2KV,Y5P,TP,7.5

...3 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP

...3 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V

...3 C689 2202-000210 C-CERAMIC,MLC-AXIAL;270pF,10%,50V,Y5P,TP

...3 C689 2202-000286 C-CERAMIC,MLC-AXIAL;56pF,5%,50V,SL,TP,1.

...3 C689 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP

...3 C689 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3

...3 C689 2202-000829 C-CERAMIC,MLC-AXIAL;0.82NF,10%,50V,Y5P,T

...3 C689 2202-000849 C-CERAMIC,MLC-AXIAL;0.018NF,5%,50V,C0G,T

...3 C613 2301-000108 C-FILM,PEF;1.5nF,5%,50V,TP,6.5x3.0x5.5mm

...3 C618 2301-000108 C-FILM,PEF;1.5nF,5%,50V,TP,6.5x3.0x5.5mm

...3 C623 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm

...3 C622 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm

...3 C824 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5

...3 C805 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5

...3 C245 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5

...3 C806 2301-000235 C-FILM,PEF;3.9nF,5%,50V,TP,6.5x3.0x5.5mm

...3 C301 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm,

...3 C235 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,

...3 C213 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,

...3 C621 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm

...3 C401 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm

...3 C102 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm

...3 C633 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm

...3 C632 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm

...3 C249 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm

...3 C246 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm

...3 C237 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm

...3 C414 2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7.

...3 CR404S 2301-001067 C-FILM,MPPF;82nF,5%,400V,TP,19x15.5x7,7.

...3 C504 2301-001259 C-FILM,MPPF;100nF,5%,400V,TP,19x8x16,7.5

...3 C808 2301-001435 C-FILM,PPF;1.5nF,5%,1.2kV,TP,15x8x12.5mm

...3 CR403S 2301-001468 C-FILM,PPF;3.3NF,3%,1.6KV,BK,29X13.5X8MM

...3 CR402S 2301-001468 C-FILM,PPF;3.3NF,3%,1.6KV,BK,29X13.5X8MM

...3 C306 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5

...3 C305 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15

...3 C631 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

...3 C629 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

...3 C628 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

...3 C627 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

...3 C225 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

...3 C231 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

...3 C236 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

...3 C404 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm

...3 C218 2305-000411 C-FILM,MPEF;470nF,5%,50V,TP,7.3x4.8x5.5m

...3 C204 2305-000411 C-FILM,MPEF;470nF,5%,50V,TP,7.3x4.8x5.5m

...3 C116 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm

...3 C626 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C611 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C606 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C240 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C638 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C639 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C807 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C812 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C105 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C115 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C206 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C209 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C232 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C229 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C222 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 C219 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

...3 CX802S 2306-000318 C-FILM,MPPF;220NF,20%,250V,BK,-,22.5

...3 CX801S 2306-000318 C-FILM,MPPF;220NF,20%,250V,BK,-,22.5

...3 CR406S 2306-000350 C-FILM,MPPF;270NF,5%,400V,BK,26X18.5X10M

...3 C244 2301-001664 C-FILM,MPE-PPF;100nF,3%,50V,TP,20x16x8.5

...3 C701 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5

...3 C701 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5

...3 C701 2401-000326 C-AL;100uF,20%,35V,GP,TP,8x11.5,5

...3 C701 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5

...3 C701 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m

...3 C701 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5

...3 C701 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm

...3 C701 2401-000603 C-AL;1UF,20%,50V,GP,TP,5X11,2

...3 C701 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5

...3 C701 2401-000703 C-AL;2200uF,20%,25V,GP,-,12.5x25mm,

...3 C701 2401-000758 C-AL;0.22UF,20%,50V,GP,TP,5X11,5

...3 C701 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5

...3 C701 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5

...3 C701 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5

...3 C701 2401-001192 C-AL;33uF,20%,50V,GP,TP,6.3x11,5

...3 C701 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5

...3 C701 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5

...3 C701 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5

...3 C701 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5

...3 C701 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm

...3 C701 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5

...3 C701 2401-002268 C-AL;2.2uF,20%,250V,LZ,TP,8X11,5

...3 C701 2401-002300 C-AL;47uF,20%,50V,GP,TP,6.3x11,5

...3 C701 2401-002594 C-AL;220uF,20%,16V,GP,TP,8x11.5,5

...3 C701 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5

Samsung CS21K9MLDC/DWP User manual

Popular TV manuals by other brands
