TOSHIBA CORPORATION
1-1, SHIBAURA 1- CHOME, MINATO-KU, TOKYO 105-8001, JAPAN
FILE NO. 030-200206
SERVICE MANUAL
COLOUR TELEVISION
ZD26 Chassis
32ZD26P
PUBLISHED IN JAPAN Mar. 2002 So

– 2 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
TABLE OF CONTENTS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS ........................................................................................................................................ 3
SET-UP ADJUSTMENT ............................................................................................................................................ 4
SERVICE MODE ...................................................................................................................................................... 6
DESIGN MODE ........................................................................................................................................................ 9
ELECTRICAL ADJUSTMENTS .............................................................................................................................. 10
CIRCUIT CHECK .................................................................................................................................................... 12
CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA .............................................................................................................................. 13
LOCATION OF CONTROLS ................................................................................................................................... 14
CHASSIS AND CABINET REPLACEMENT PARTS LIST ......................................................................................16
PC BOARDS BOTTOM VIEW ................................................................................................................................. 29
TERMINAL VIEW OF TRANSISTORS ................................................................................................................... 37
CIRCUIT BLOCK DIAGRAM .................................................................................................................................. 40
SPECIFICATIONS .............................................................................................................................................. END
APPENDIX:
CIRCUIT DIAGRAM

–3 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”INSTRUCTIONS BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazard-
ous X-RAY RADIATION. To avoid such hazards, the high
voltage must not be above the specified limit. The nominal
value of the high voltage of this receiver is (A) kV at zero
beam current (minimum brightness) under a (C) V AC power
source.The high voltage must not, under any circumstances,
exceed (B) kV.
Refer to table-1 for high voltage (A), (B) & AC voltage (C).
(See SETTING & ADJUSTING DATA on page 13)
Each time a receiver requires servicing, the high voltage
should be checked following the HIGH VOLTAGE CHECK
procedure in this manual. It is recommended that the read-
ing of the high voltage be recorded as a part of the service
record. It is important to use an accurate and reliable high
voltage meter.
2. The only source of X-RAY RADIATION in this TV receiver
is the picture tube. For continued X-RAY RADIATION pro-
tection, the replacement tube must be exactly the same
type tube as specified in the parts list.
3. Some part in this receiver have special safety-related char-
acteristics for X-RAY RADIATION protection. For contin-
ued safety, parts replacement should be undertaken only
after referring to the PRODUCT SAFETY NOTICE below.
SAFETY PRECAUTION
WARNING : Service should not be attempted by anyone unfamiliar with the necessary precautions on this receiver.The following
are the necessary precautions to be observed before servicing this chassis.
1. An isolation transformer should be connected in the power line between the receiver and the AC line before any service is
performed on the receiver.
2. Always discharge the picture tube anode to the CRT conductive coating before handling the picture tube. The picture tube
is highly evacuated and if broken, glass fragments will be violently expelled. Use shatter proof goggles and keep picture tube
away from the unprotected body while handling.
3. When replacing a chassis in the cabinet, always be certain that all the protective devices are put back in place, such as; non-
metallic control knobs, insulating covers, shields, isolation resistor-capacitor network etc.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety char-
acteristics are identified in this manual and its supplements; electrical components having such features are identified by
the international hazard symbols on the schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement
parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray
radiation or other hazards.

–4 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”ON PAGE 3 OF THIS MANUAL.
SET-UP ADJUSTMENT
■The following adjustments should be made when a complete realignment is required or a new picture tube is installed.
Perform the adjustments in order as follows :
1. Color Purity
2. Convergence
3. White Balance
Note: The PURITY/CONVERGENCE MAGNET assembly and rubber wedges need mechanical positioning.
Refer to figure 1.
Mounting position of the purity magnet assembly should fit to same position as old one because slightly difference to
the position depend on a kind of tube.
*There are no adjustment of purity and convergence in some picture tube (Unified with purity magnet)
GLASS CLOTH
TAPES
DEFLECTION
YOKE
TEMPORARY
MOUNTING
RUBBER WEDGE
ADHESIVE
DEFLECTION
YOKE
PURITY/
CONVERGENCE
MAGNET ASS'Y
29.1mm(28", 29")
25mm(25")
19mm(19", 20", 21")
14mm(13", 14")
Figure 1.
COLOR PURITY ADJUSTMENT
NOTE : Before attempting any purity adjustments, the receiver
should be operated for at least fifteen minutes.
1. Demagnetize the picture tube and cabinet using a degauss-
ing coil.
2. Set the brightness and contrast to maximum.
3. Use a green raster from among the built-in test signals.
4. Loosen the clamp screw holding the yoke and slide the
yoke backward or forward to provide vertical green belt
(zone) in the picture screen.
5. Remove the Rubber Wedges.
6. Rotate and spread the tabs of the purity magnet (See fig-
ure 2.) around the neck of the picture tube until the green
belt is in the center of the screen. At the same time, enter
the raster vertically.
7. Slowly move the yoke forward or backward until a uniform
green screen is obtained. Tighten the clamp screw of the
yoke temporarily.
8. Check the purity of the red and blue raster.

–5 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
CONVERGENCE ADJUSTMENTS
NOTE: Before attempting any convergence adjustments, the
receiver should be operated for at least fifteen min-
utes.
■CENTER CONVERGENCE ADJUSTMENT
1. Use the cross-dot pattern from among the built-in test sig-
nals.
2. Set the brightness and contrast for well defined pattern.
3. Adjust two tabs of the 4-Pole Magnets to change the an-
gle between them (See figure 2.) and superimpose red
and blue vertical lines in the center area of the picture
screen.
4. Turn the both tabs at the same time keeping the angle
constant to superimpose red and blue horizontal lines at
the center of the screen.
5. Adjust two tabs of 6-Pole Magnets to superimpose red/
blue line and green one. Adjusting the angle affects the
vertical lines and rotating both magnets affects the hori-
zontal lines.
6. Repeat adjustments 3, 4, 5 keeping in mind red, green
and blue movement, because 4-Pole Magnets and 6-Pole
Magnets have mutual interaction and make dot movement
complex.
■CIRCUMFERENCE CONVERGENCE ADJUSTMENT
1. Loosen the clamping screw of deflection yoke slightly to
allow the yoke to tilt.
2. Temporarily put a wedge as shown in figure 1. (Do not
remove cover paper on adhesive part of the wedge.)
3. Tilt front of the deflection yoke up or down to obtain better
convergence in circumference. (See figure 3.) Push the
mounted wedge into the space between picture tube and
the yoke to fix the yoke temporarily.
4. Put other wedge into bottom space and remove the cover
paper to stick.
5. Tilt front of the yoke right or left to obtain better conver-
gence in circumference. (See figure 3.)
6. Keep the yoke position and put another wedge in either
upper space. Remove cover paper and stick the wedge
on picture tube to fix the yoke.
7. Detach the temporarily mounted wedge and put it in an-
other upper space. Stick it on picture tube to fix the yoke.
8. After fixing three wedges, recheck overall convergence.
Tighten the screw firmly to fix the yoke and check the yoke
is firm.
9. Stick three adhesive tapes on wedges as shown in figure
1.
Figure 2.
BLU RED
BLU
RED
RED/BLU GRN
RED/BLU
GRN
B
G
R
R
G
B
BGR
RGB
BGR
RGB
R
G
B
B
G
R
4-POLE MAGNETS MOVEMENT
INCLINE THE YOKE UP (OR DOWN)
6-POLE MAGNETS MOVEMENT
Center Convergence by Convergence Magnets
Circumference Convergence by DEF Yoke
INCLINE THE YOKE RIGHT (OR LEFT)
Figure 3. Dot Movement Pattern
4-POLE
MAGNETS
PURITY
MAGNETS
6-POLE
MAGNETS
ADJUST THE ANGLE
(VERTICAL LINES) FIXED
ROTATE TWO TABS
AT THE SAME TIME
(HORIZONTAL LINES)
CONVERGENCE MAGNET ASSEMBLY ADJUSTMENT OF MAGNETS

–6 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICE MODE
1. ENTERING TO SERVICE MODE
S
(Service mode display)
Item
Data
Mute or
3) While pressing the obutton,
press MENU button on TV set.
2) Press obutton again to
keep pressing.
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on TV.
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
A single horizontal line ON/OFF: INFO button (on Remote) or abutton (on TV)
Test signal selection : abutton (on Remote)
Selection of the adjustment items : Channel s/t(on TV or Remote)
Change of the data value : Volume ;+/–(on TV or Remote)
Adjustment menu mode ON/OFF : MENU button (on TV)
Initialization of the memory (QA02) : CALL + Channel button on TV (s)
Reset the count of operating protect
circuit to “00”: CALL + Channel button on TV (t)
“RCUT”selection : 1 button
“GCUT”selection : 2 button
“BCUT”selection : 3 button
“CNTX”(or “SCNT”) selection : 4 button
“COLC”selection : 5 button
“TNTC”selection : 6 button
Self diagnostic display ON/OFF : 9 button
1) Press obutton once on
Remote Control.
Adjustment mode
Item
Data
Service mode
S
Press
Press
ITEM
DATA
Color thickness correction
note: Displayed differently as shown below, de-
pending on the setting of the receiving color
system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)
CAUTION : Never try to perform initialization unless you have changed the memory IC.

–7 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL sbutton in the service mode changes the adjustment items in the order of table-2.
(tbutton for reverse order)
Refer to table-2 for preset data of adjustment mode.
(See SETTING & ADJUSTING DATA on page 13)
5. ADJUSTING THE DATA
1) Pressing of VOLUME ;+/–button will change the value of data in the range from 00H to FFH. The variable
range depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■INITIALIZATION OF MEMORY DATA OF QA02
After replacing QA02, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL sbutton on the TV.The initialization of QA02 has
been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto search Memory”on the owner’s manual.
CAUTION: Never attempt to initialize the data unless QA02 has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of abutton on the Remote Control changes the built-in test patterns on screen as described below
in SERVICE MODE.
Signals Picture
•Red raster
•Green raster
•Blue raster
•All White
•Black cross-hatch
* The signals marked with are not usable to display in the Test signal for some model.
Signal off NTSC signals (5 patterns)
PAL signals (5 patterns)

–8 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
8. SELF DIAGNOSTIC FUNCTION
1) Press “9”button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s are executed properly.
2) During diagnosis, the following displays are shown.
23******
POWER : 00
BUS LINE : OK
BUS CONT : OK
BLOCK :
UV V1 V2 V3
QV01
<SELF CHECK>
Part number of microcomputer (QA01)
Operation number of protecting circuit ----“00”is nor-
mal.
When indication is other than “00”, overcurrent apts to
flow, and circuit parts may possibly be damaged.
BUS LINE CHECK ----“OK”is normal.
“SDA1-GND”------------- SDA-GND short circuit.
“SCL1-GND”-------------- SCL-GND short circuit.
“SCL1-SDA1”------------- SCL-SDA short circuit.
BUS CONT ----“OK”is normal.
When indication shows “Q uuu NG”, the device with
the number may possibly be damaged.
BLOCK
UV : TV reception mode
V1 : VIDEO 1 input mode (a1)
V2 : VIDEO 2 input mode (a2)
V3 : VIDEO 3 input mode (a3)
Indicated color of mode now selected : Green and Red
Indicated color of other modes : White
Green : Normal
Red : The microcomputer operates to provide judgement
of no video signal. The red color is still indicated
though the signal is input, failure may exist in input
signal line including QV01.
QV01 : In case of indication green ---Normal
In case of indication red with input signal----
Failure may exist in output line including QV01.
NOTE: Component which controls character display on
screen is ICF01 (TELETEXT IC.). If this display
function fails to operate due to damage in ICF01,
self diagnosis procedure is as follows.
(1) In case that power indicator is blinking with
interval of 0.5 seconds; it means protecting
circuit (Current limiter) is operating, and cir-
cuit components may possibly be damaged.
Check related components.
(2) In case that power indicator is blinking with
interval of 1 second; Protecting circuit does
not operate, but a part of Bus line does not
operate normally. Check Bus line.





* The items marked with are not usable to display in the SELF DIAGNOSTIC FUCTION for some model.

–9 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
DESIGN MODE
1. ENTERING TO DESIGN MODE
ITEM
DATA
S D Press
(Design mode) (Adjustment mode)
Press
3) Press MENU button on TV.
2) While pressing oor CALL button on
Remote and press MENU button on TV.
1) Select the Service mode.
2. SELECTING THE ADJUSTING ITEMS
Every pressing of CHANNEL tbutton in the design mode changes the adjustment items in the order of table-3.
(sbutton for reverse order)
Refer to table-3 for data of design mode.
(See SETTING & ADJUSTING DATA on page 13)
3. ADJUSTING THE DATA
Pressing of VOLUME sor tbutton will change the value of data.
When QA02 is initialized, items “OPT0”and “OPT1”of DESIGN MODE are set to the data of the representative model of this
chassis family.
Therefore, because ON-SCREEN specification remains in the state of the representative of model. This model is required to
reset the data of items “OPT0”and “OPT1”.

–10 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
ELECTRICAL ADJUSTMENTS
1. Enter the service mode, then select any register item.
2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern ap-
pears on the screen.
3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture
screen.
FOCUS VR ADJ
SUB-BRIGHTNESS
(BRTC)
Note: Constrict the picture height
until the vertical retrace line
appears adjusting the item
HIT (HEIGHT).
1. Set CONTRAST to minimum, and
BRIGHTNESS to center by adjusting
user controls.
2. Set the TV in service mode to get white
cross-bar of inside pattern.
3. Select BRTC (brightness correction),
and adjust the ;–/+ button to reduce
the value so that white portion of inside
pattern slightly light.
4. Adjust ;–/+ button to increase the
data value of BRTC, and set it just
before the difference between the belt of
vertical retrace and the border of black
portion of inside pattern is visible.
After that, return vertical height and
contrast.
ITEM ADJUSTMENT PROCEDURE
Belt of vertical retrace
HORIZONTAL POSITION
ADJUSTMENT (HPOS)
VERTICAL POSITION
ADJUSTMENT (VPOS)
1. Set the TV in service mode, and get
black or white cross-bar signal with
VIDEO button on remote hand unit.
2. Select either HPOS (Horizontal
picture phase) or VPOS (Vertical
picture phase) with CHANNEL s, t
buttons, and adjust horizontal or
vertical picture position in the center
of screen with VOLUME ;–/+
buttons.
VERTICAL AMPLITUDE
ADJUSTMENT (HIT)
1. Set the TV in service mode, and get
black or white cross-hatch signal
with VIDEO button on remote hand
unit.
2. Select HIT (Vertical amplitude) with
CHANNEL s, tbuttons, and adjust
vertical amplitude with VOLUME
;–/+ buttons so that vertical am-
plitude lacks a little.
3. Adjust vertical amplitude with VOL-
UME ;–/+ buttons so that the first
bar on cross-hatch signal touches
edge of screen.
The first

–11 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
ITEM ADJUSTMENT PROCEDURE
WHITE BALANCE
ADJUSTMENT
•CUTOFF ADJUSTMENT
(RCUT)
(GCUT)
(BCUT)
•DRIVE ADJUSTMENT
(GDRV)
(BDRV)
1. Set Contrast to 40, and brightness to +20 by picture control.
2. Set the TV in service mode, and get the inside W/B adjusting signal with VIDEO
button.
3. Select RCUT, GCUT and BCUT with CHANNEL s, tbuttons, to set individual
values to Initial reference data, and to set GDRV and BDRV to Initial reference
data with VOLUME ;–/+ buttons.
4. Press -/- - button on the remote control and rotate Screen VR to get one slight
horizontal line on screen.
Note: Every pressing of -/- - button provides Horizontal line picture and Normal
picture alternately.
5. Press -/- - button to release horizontal line picture, and select the two other colors
which did not light in the above step with CHANNEL s, tbuttons. Then tap VOL-
UME ;–/+ buttons so that three colors slightly light in the same level.
XTo correct white balance in light area,
select GDRV and BDRV with CHANNEL
s, tbuttons to adjust.
XTo correct white balance in dark area,
perform fine adjustment of RCUT, GCUT
and BCUT.
Light area check
(to show white)
Dark area check
(to show black)

–12 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
CIRCUIT CHECK
HIGH VOLTAGE CHECK
CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on this chassis. Checking should be done following the steps
below.
1. Connect an accurate high voltage meter to the second anode of the picture tube.
2. Turn on the receiver. Set the BRIGHTNESS and CONTRAST controls to minimum (zero beam current).
3. High voltage must be measured below (B) kV.
Refer to table-1 for high voltage (B).
(See SETTING & ADJUSTING DATA on page 13)
4. Vary the BRIGHTNESS control to both extremes to be sure the high voltage does not exceed the limit under any conditions.

–13 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
DESIGN MODE
ADJUSTING ITEMS AND DATAS IN THE DESIGN MODE:
Item Name of adjustment Preset Data Data Remarks
Table-3
SETTING & ADJUSTING DATA
32”
HIGH VOLTAGE AT ZERO BEAM: (A) 33.4 kV
MAX HIGH VOLTAGE: (B) 34.0 kV
AV VOLTAGE (C) 220~240 V
CHAPTER 2 SPECIFIC INFORMATIONS
SAFETY INSTRUCTIONS
Table-1
SERVICE MODE
ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE:
Table-2
RCUT
GCUT
BCUT
GDRV
BDRV
CNTX
BRTC
COLC
TNTC
COLP
COLS
COLD
SCNT
SRY
SBY
R CUTOFF (B/W)
G CUTOFF (B/W)
B CUTOFF (B/W)
R DRIVE
B DRIVE
SUB CONTRAST MAX
SUB BRIGHT CEN
SUB COLOR CEN NTSC
SUB TINT CEN
SUB COLOR CEN PAL
SUB COLOR CEN SECAM
SUB COLOR CEN DTV
SUB CONTRAST
SECAM R-Y
SECAM B-Y
Item Adjustment
Reference data
40H
40H
40H
35H
35H
7FH
80H
02H
1EH
05H
08H
41H
08H
07H
04H
Item Adjustment
Reference data
HPOS
VPOS
HIT
VLIN
VSC
VPS2
WID
PARA
CNR
TRAP
CPAR
HSC
VPSI
CSAW
50Hz H-POSITION
V-POSITION
HEIGHT
V-LINEARITY
V-S CORRECTION
V-SHIFT
PICTURE WIDTH
E-W PARABOLA
E-W CORNER
TRAPEZIUM
WIDE CENT PARA
WIDE EW S CORR
WIDE V-POS
WIDE CENT SAW
34H
00H
2BH
10H
2AH
40H
25H
0FH
0EH
40H
06H
10H
7AH
08H
OPT0
OPT1
OPT2
OPT3
OPTION 0
OPTION 1
OPTION 2
OPTION 3
80H
46H
20H
00H
←
←
←
←

–14 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
LOCATION OF CONTROLS
MENU
VOLUME DOWN
VOLUME UP
POSITION DOWN
POSITION UP
VIDEO-3
(S-VIDEO TERMINAL)
VIDEO-3
HEAD PHONE
ON-TIMER INDICATOR (GREEN) POWER INDICATOR (RED)
MAIN SWITCH
AERIAL TERMINAL
VIDEO-1 (21PIN S-VIDEO/AV)
VIDEO-2 (21PIN S-VIDEO/AV)
VIDEO-3 (21PIN S-VIDEO/AV) AUDIO OUT (FIXED)
Front
Rear terminals
VIDEO-4 (AUDIO IN)
VIDEO-4 (COMPONENT VIDEO)

–15 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Remote Controller
CALL
456
7
MENU
TV
VCR
DVD
R
GY
C
DVD
MENU
EXIT
89
0
123
1. TEXT Sub Function
<HOLD, REVEAL, F-T-B, TIME/TXCL, SUB PAGE>
v?^yX Y
---------------- Only TV mode operation
2. VCR & DVD Common
<Power, Play, Stop, Pause, Eject,
fSRJc
FF, REV, Skip - FWD, Skip - REV>
3. Key Name (by special characters)
f--------------- Power ON - Stanby
i-------------- TEXT INDEX
----------- TEXT / TV
a-------------- VIDEO INPUT
V----------- SELECTABLE PICTURE
o-------------- MUTE
+;- ------------ VOLUME +, –
8P9------------- POSITION(CH.) Up/Down
-------------- Size
-------------- STILL PICTURE
?--------------- Sub Woofer
N--------------- SURROUND
mI/II ----------- Stereo Bilingual
--------------- Previous Ch.
i---------------- INFO.
Switched
TV Mode
VCR Mode
DVD Mode
MENU
&
Cursor:
TV, DVD
Power Key: TV, VCR, DVD

SPECIFIC INFORMATIONS
LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
– 16 –
SPECIFIC INFORMATIONS
CAPACITORS
C102 24793221 ELECTROLYTIC, 10 220UF M
C105 24109102 CERAMIC CHIP, 50 B 1000PF K
C106 24797100 ELECTROLYTIC, 50 10UF M
C108 24793221 ELECTROLYTIC, 10 220UF M
C109 24109103 CERAMIC CHIP, 50 B 10000PF K
C115 24109103 CERAMIC CHIP, 50 B 10000PF K
C160 24503045 PLASTIC FILM, 63 0.22UF J
C205 24797229 ELECTROLYTIC, 50 2.2UF M
C206 24794100 ELECTROLYTIC, 16 10UF M
C302 24214471 CERAMIC DISC, 500 B 470PF K
C303 24214471 CERAMIC DISC, 500 B 470PF K
C305 24795222 ELECTROLYTIC, 25 2200UF M
C308 24797221 ELECTROLYTIC, 50 220UF M
C309 24591102 PLASTIC FILM, 50 1000PF J
C310 24795222 ELECTROLYTIC, 25 2200UF M
C313 24082057 PLASTIC FILM, 100 220000PF J
C316 24795471 ELECTROLYTIC, 25 470UF M
C317 24214102 CERAMIC DISC, 500 B 1000PF K
C318 24794471 ELECTROLYTIC, 16 470UF M
C320 24795471 ELECTROLYTIC, 25 470UF M
C321 24503051 MT PLA CAP 63 0.68UF J
C322 24617915 ELECTROLYTIC, 50 1UF K 3A LI
C323 24503049 PLASTIC FILM, 63 0.47UF J
C325 24590223 PLASTIC FILM, 50 0.022MF J
C326 24797010 ELECTROLYTIC, 50 1UF M
C327 24794471 ELECTROLYTIC, 16 470UF M
C329 24503045 PLASTIC FILM, 63 0.22UF J
C331 24503038 MT PLA CAP 63 0.056UF J
C332 24212102 CERAMIC DISC, 50 B 1000PF K
C361 24590223 PLASTIC FILM, 50 0.022MF J
C366 24082052 PLA CAP M-L 100 823J
C370 24794100 ELECTROLYTIC, 16 10UF M
C372 24797470 ELECTROLYTIC, 50 47UF M
C373 24797470 ELECTROLYTIC, 50 47UF M
C410 24092341 CERAMIC DISC, 2K R 470PF K
C413 24214392 CERAMIC DISK CK45 B 500 3900PF K
C416 24676330 ELECTROLYTIC, 100 33UF M 3A
C417 24214391 CERAMIC DISC, 500 B 390PF K
C419 24212102 CERAMIC DISC, 50 B 1000PF K
C420 24794101 ELECTROLYTIC, 16 100UF M
C421 24232103 CERAMIC DISC, 50 F 10000PF Z
C421 24503041 PLASTIC FILM , 63 0.1UF J
* C423 24503124 PLASTIC CAP T 400 683J
C430 24829203 PLASTIC FILM, 400 20000PF J
C431 24232103 CERAMIC DISC, 50 F 10000PF Z
C441 24082636 MT PLA CAP T 400 624J
* C444 24503195 MT PLA CAP T 1800 H 512H
C445 24828473 PLASTIC FILM, 200 47000PF J
C446 24679330 ELECTROLYTIC, 250 33UF M 3A
C447 24829363 PLASTIC FILM, 400 36000PF J
C448 24640908 ELECTROLYTIC, 160 33UF M 3A LI
* C461 24503196 MT PLA CAP T 1800 H 562H
C462 24073044 ELECTROLYTIC, 16 3300UF M 3A
* C464 24503149 PLASTIC FILM, 250 3.3UF
C466 24503231 MT PLA CAP T 1250 H 122H
* C466 24503261 MT PLA CAP T 1250 H 682H
* C467 24503253 MT PLA CAP T 1250 H 103H
* C468 24503253 MT PLA CAP T 1250 H 103H
C470 24794470 ELECTORLYTIC, 16 47UF M
C471 24503046 MT PLA CAP M 63 274J
C472 24503049 PLASTIC FILM, 63 0.47UF J
C473 24669010 ELECTROLYTIC, 50 1.0UF M 3A
C475 24820822 PLASTIC FILM, 630 8200PF J
C476 24794220 ELECTROLYTIC, 16 22UF M
C478 24591563 PLASTIC FILM, 50 0.056MF J
C481 24085988 ELECTROLYTIC, NONPOLAR, 50
1.0UF M 7L
C482 24212152 CERAMIC DISC, 50 B 1500PF K
C491 24082637 PLASTIC FILM, 400 R1UF J
C492 24082637 PLASTIC FILM, 400 R1UF J
C494 24503041 PLASTIC FILM , 63 0.1UF J
C495 24092343 CERAMIC DISC, 2K 680PF K
C496 24092343 CERAMIC DISC, 2K 680PF K
C498 24591392 PLASTIC FILM, 50 3900PF J
C499 24212101 CERAMIC DISC, 50 B 100PF K
C501 24100104 CERAMIC CHIP, 25 F 100000PF Z
C502 24100104 CERAMIC CHIP, 25 F 100000PF Z
C503 24794470 ELECTORLYTIC, 16 47UF M
C504 24109103 CERAMIC CHIP, 50 B 10000PF K
C505 24794470 ELECTORLYTIC, 16 47UF M
C506 24109103 CERAMIC CHIP, 50 B 10000PF K
C507 24100104 CERAMIC CHIP, 25 F 100000PF Z
C508 24100104 CERAMIC CHIP, 25 F 100000PF Z
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate com-
ponents which have special characteristics important for safety and should be replaced only with types identical to
those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with
originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not
degrade the safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with *mark is no longer available after the end of the production.
Models : 32ZD26P
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CHASSIS AND CABINET REPLACEMENT PARTS LIST

LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No. LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
–17 –
SPECIFIC INFORMATIONS
C509 24100104 CERAMIC CHIP, 25 F 100000PF Z
C511 24100104 CERAMIC CHIP, 25 F 100000PF Z
C512 24100104 CERAMIC CHIP, 25 F 100000PF Z
C513 24109103 CERAMIC CHIP, 50 B 10000PF K
C514 24793221 ELECTROLYTIC, 10 220UF M
C516 24105100 CERAMIC CHIP, 50 CH 10PF D
C517 24206478 ELECTROLYTIC, 50 0.47UF M 7L 3A
C519 24797479 ELECTROLYTIC, 50 4.7UF M
C520 24503047 PLASTIC FILM, 63 0.33UF J
C521 24092733 CERAMIC CHIP, 50 B 22000PF K
C522 24109103 CERAMIC CHIP, 50 B 10000PF K
C523 24100104 CERAMIC CHIP, 25 F 100000PF Z
C524 24109103 CERAMIC CHIP, 50 B 10000PF K
C525 24503041 PLASTIC FILM , 63 0.1UF J
C526 24109103 CERAMIC CHIP, 50 B 10000PF K
C527 24797229 ELECTROLYTIC, 50 2.2UF M
C530 24206010 ELECTROLYTIC, 50 1.0UF M 7L 3A
C531 24100104 CERAMIC CHIP, 25 F 100000PF Z
C532 24100104 CERAMIC CHIP, 25 F 100000PF Z
C533 24100104 CERAMIC CHIP, 25 F 100000PF Z
C534 24100104 CERAMIC CHIP, 25 F 100000PF Z
C536 24100104 CERAMIC CHIP, 25 F 100000PF Z
C537 24100104 CERAMIC CHIP, 25 F 100000PF Z
C540 24100104 CERAMIC CHIP, 25 F 100000PF Z
C541 24100104 CERAMIC CHIP, 25 F 100000PF Z
C542 24100104 CERAMIC CHIP, 25 F 100000PF Z
C543 24100104 CERAMIC CHIP, 25 F 100000PF Z
C544 24100104 CERAMIC CHIP, 25 F 100000PF Z
C545 24100104 CERAMIC CHIP, 25 F 100000PF Z
C547 24109103 CERAMIC CHIP, 50 B 10000PF K
C548 24763101 ELECTROLYTIC, 16 100UF M
C563 24206010 ELECTROLYTIC, 50 1.0UF M 7L 3A
C564 24797479 ELECTROLYTIC, 50 4.7UF M
C571 24100104 CERAMIC CHIP, 25 F 100000PF Z
C575 24092538 CERAMIC CHIP, 10 F 1UF Z
C613 24666471 ELECTROLYTIC, 16 470UF M 3A
C639 24794101 ELECTROLYTIC, 16 100UF M
C661 24797478 ELECTROLYTIC, 50 0.47UF M
C664 24797100 ELECTROLYTIC, 50 10UF M
C665 24797010 ELECTROLYTIC, 50 1UF M
C666 24797010 ELECTROLYTIC, 50 1UF M
C667 24212102 CERAMIC DISC, 50 B 1000PF K
C668 24212102 CERAMIC DISC, 50 B 1000PF K
C669 24797330 ELECTROLYTIC, 50 33UF M
C670 24797330 ELECTROLYTIC, 50 33UF M
C671 24669100 ELECTROLYTIC, 50 10UF M 3A
C672 24667470 ELECTROLYTIC, 25 47UF M 3A
C673 24667470 ELECTROLYTIC, 25 47UF M 3A
C674 24669100 ELECTROLYTIC, 50 10UF M 3A
C675 24667470 ELECTROLYTIC, 25 47UF M 3A
C677 24590102 PLASTIC FILM, 50 1000PF J
C678 24590102 PLASTIC FILM, 50 1000PF J
C680 24668102 ELECTROLYTIC, 35 1000UF M 3A
C681 24668102 ELECTROLYTIC, 35 1000UF M 3A
C682 24668102 ELECTROLYTIC, 35 1000UF M 3A
C685 24503042 PLASTIC FILM, 63 0.12UF J
C687 24232103 CERAMIC DISC, 50 F 10000PF Z
C688 24666220 ELECTROLYTIC, 16 22UF M 3A
C689 24503042 PLASTIC FILM, 63 0.12UF J
C704 24591822 PLASTIC FILM, 50 8200PF J
C705 24797229 ELECTROLYTIC, 50 2.2UF M
C707 24794470 ELECTORLYTIC, 16 47UF M
C712 24794470 ELECTORLYTIC, 16 47UF M
C713 24790100 ELECTROLYTIC CE04G 160 10UF M
C715 24214472 CERAMIC DISK CK45 B 500 4700PF K
C717 24214472 CERAMIC DISK CK45 B 500 4700PF K
C718 24794470 ELECTORLYTIC, 16 47UF M
C719 24435151 PCERA CAP SL 500 151J
C720 24790100 ELECTROLYTIC CE04G 160 10UF M
C721 24794470 ELECTORLYTIC, 16 47UF M
* C801 24503056 PLASTIC FILM, AC275 0.1UF M
* C802 24503056 PLASTIC FILM, AC275 0.1UF M
C805 24092281 CERAMIC DISC, AC250 E 4700PF
C806 24092281 CERAMIC DISC, AC250 E 4700PF
C808 24668101 ELECTROLYTIC, 35 100UF M 3A
C809 24503049 PLASTIC FILM, 63 0.47UF J
C810 24086873 440 330M30F 400 330UF M30F
* C813 24092555 CERAMIC DISC, AC250 E 1000PF M
* C814 24092555 CERAMIC DISC, AC250 E 1000PF M
C816 24794470 ELECTORLYTIC, 16 47UF M
C817 24092339 CERAMIC DISC, 2K 330PF K
C818 24095931 PLASTIC FILM CF92T 1250 H 2200PF J
C821 24214471 CERAMIC DISC, 500 B 470PF K
C822 24503049 PLASTIC FILM, 63 0.47UF J
C823 24214471 CERAMIC DISC, 500 B 470PF K
C829 24212221 CERAMIC DISC, 50 B 220PF K
C832 24794470 ELECTORLYTIC, 16 47UF M
C836 24794470 ELECTORLYTIC, 16 47UF M
C840 24667102 ELECTROLYTIC, 25 1000UF M 3A
C841 24669100 ELECTROLYTIC, 50 10UF M 3A
C842 24669100 ELECTROLYTIC, 50 10UF M 3A
C843 24503041 PLASTIC FILM , 63 0.1UF J
C872 24669221 ELECTROLYTIC, 50 220UF M 3A
C884 24086953 ELECTROLYTIC, 160 220UF M 3A
C885 24214471 CERAMIC DISC, 500 B 470PF K
C889 24669222 ELECTROLYTIC, 50 2200UF M 3A
C890 24667222 ELECTROLYTIC, 25 2200UF M 3A
C893 24092337 CERAMIC DISC, 2K 220PF K
C896 24214471 CERAMIC DISC, 500 B 470PF K
C897 24667332 ELECTROLYTIC, 25 3300UF M 3A
C898 24503045 PLASTIC FILM, 63 0.22UF J
C899 24214471 CERAMIC DISC, 500 B 470PF K
C902 24092353 CERAMIC DISC, 2K 4700PF K
C904 24436471 CERAMIC DISC, 50 SL 470PF J
C905 24436471 CERAMIC DISC, 50 SL 470PF J
C907 24436391 CERAMIC DISC, 50 SL 390PF J
C909 24679330 ELECTROLYTIC, 250 33UF M 3A
C910 24797478 ELECTROLYTIC, 50 0.47UF M
C911 24203100 ELECTORLYTIC, 16 10UF M 7L 3A
C912 24794102 ELECTROLYTIC, 16 1000UF M
C913 24794101 ELECTROLYTIC, 16 100UF M
C914 24212103 CERAMIC DISC, 50 B 10000PF K
C915 24092398 CERAMIC DISC, 25 0.1UF Z, 24092398A
NI TOOITSU
C930 24214101 CERAMIC DISC, 500 B 100PF K
C931 24214101 CERAMIC DISC, 500 B 100PF K
C2110 24100104 CERAMIC CHIP, 25 F 100000PF Z
C4000 24591102 PLASTIC FILM, 50 1000PF J
C4222 24092538 CERAMIC CHIP, 10 F 1UF Z
C4401 24763221 ELECTROLYTIC, 16 220UF M
C4402 24109103 CERAMIC CHIP, 50 B 10000PF K
C4403 24797010 ELECTROLYTIC, 50 1UF M
C4404 24109103 CERAMIC CHIP, 50 B 10000PF K
C4405 24100104 CERAMIC CHIP, 25 F 100000PF Z
C4406 24109103 CERAMIC CHIP, 50 B 10000PF K
C4407 24109103 CERAMIC CHIP, 50 B 10000PF K
C4408 24092538 CERAMIC CHIP, 10 F 1UF Z
C4409 24794331 ELECTROLYTIC, 16 330UF M
C4410 24109103 CERAMIC CHIP, 50 B 10000PF K
C4411 24100104 CERAMIC CHIP, 25 F 100000PF Z
* C4490 24503280 MT PLA CAP T 400 244J
* C4491 24503280 MT PLA CAP T 400 244J
C5020 24109103 CERAMIC CHIP, 50 B 10000PF K
C5030 24763101 ELECTROLYTIC, 16 100UF M

–18 –
LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No. LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
SPECIFIC INFORMATIONS
C5080 24206010 ELECTROLYTIC, 50 1.0UF M 7L 3A
C5090 24763101 ELECTROLYTIC, 16 100UF M
CA03 24105180 CERAMIC CHIP, 50 CH 18PF J
CA04 24105180 CERAMIC CHIP, 50 CH 18PF J
CA09 24105101 CERAMIC CHIP, 50 CH 100PF J
CA10 24105101 CERAMIC CHIP, 50 CH 100PF J
CA12 24105101 CERAMIC CHIP, 50 CH 100PF J
CA15 24105101 CERAMIC CHIP, 50 CH 100PF J
CA16 24105101 CERAMIC CHIP, 50 CH 100PF J
CA17 24105101 CERAMIC CHIP, 50 CH 100PF J
CA33 24100103 CERAMIC CHIP, 50 F 10000PF Z
CA42 24794101 ELECTROLYTIC, 16 100UF M
CA43 24109103 CERAMIC CHIP, 50 B 10000PF K
CA44 24109103 CERAMIC CHIP, 50 B 10000PF K
CA45 24109103 CERAMIC CHIP, 50 B 10000PF K
CA67 24100103 CERAMIC CHIP, 50 F 10000PF Z
CA68 24794100 ELECTROLYTIC, 16 10UF M
CA69 24100103 CERAMIC CHIP, 50 F 10000PF Z
CA70 24794100 ELECTROLYTIC, 16 10UF M
CB04 24092538 CERAMIC CHIP, 10 F 1UF Z
CB05 24109222 CERAMIC CHIP, 50 B 2200PF K
CB06 24105561 CERAMIC CHIP, 50 CH 560PF J
CB07 24109332 CERAMIC CHIP, 50 B 3300PF K
CB21 24503041 PLASTIC FILM , 63 0.1UF J
CB22 24203470 ELECTROLYTIC, 16 47UF M 7L 3A
CB40 24092538 CERAMIC CHIP, 10 F 1UF Z
CB41 24109222 CERAMIC CHIP, 50 B 2200PF K
CB42 24105561 CERAMIC CHIP, 50 CH 560PF J
CB43 24109332 CERAMIC CHIP, 50 B 3300PF K
CB90 24100103 CERAMIC CHIP, 50 F 10000PF Z
CC04 24105220 CERAMIC CHIP, 50 CH 22PF J
CC15 24100104 CERAMIC CHIP, 25 F 100000PF Z
CC15 24232103 CERAMIC DISC, 50 F 10000PF Z
CC16 24109103 CERAMIC CHIP, 50 B 10000PF K
CC16 24590103 PLASTIC FILM, 50 0.01MF J
CC26 24109103 CERAMIC CHIP, 50 B 10000PF K
CC27 24109103 CERAMIC CHIP, 50 B 10000PF K
CC31 24109102 CERAMIC CHIP, 50 B 1000PF K
CC60 24109223 CERAMIC CHIP, 25 B 22000PF K
CC61 24109223 CERAMIC CHIP, 25 B 22000PF K
CC62 24109102 CERAMIC CHIP, 50 B 1000PF K
CC63 24109102 CERAMIC CHIP, 50 B 1000PF K
CC64 24109223 CERAMIC CHIP, 25 B 22000PF K
CC65 24109223 CERAMIC CHIP, 25 B 22000PF K
CC66 24109102 CERAMIC CHIP, 50 B 1000PF K
CC67 24109102 CERAMIC CHIP, 50 B 1000PF K
CC68 24109102 CERAMIC CHIP, 50 B 1000PF K
CC69 24109102 CERAMIC CHIP, 50 B 1000PF K
CC70 24109102 CERAMIC CHIP, 50 B 1000PF K
CC71 24109102 CERAMIC CHIP, 50 B 1000PF K
CC72 24109102 CERAMIC CHIP, 50 B 1000PF K
CC73 24109102 CERAMIC CHIP, 50 B 1000PF K
CC74 24109102 CERAMIC CHIP, 50 B 1000PF K
CC75 24109102 CERAMIC CHIP, 50 B 1000PF K
CC77 24109102 CERAMIC CHIP, 50 B 1000PF K
CC78 24109102 CERAMIC CHIP, 50 B 1000PF K
CC80 24436470 CERAMIC DISC, 50 SL 47PF J
CR01 24206010 ELECTROLYTIC, 50 1.0UF M 7L 3A
CR02 24100103 CERAMIC CHIP, 50 F 10000PF Z
CR07 24100104 CERAMIC CHIP, 25 F 100000PF Z
CR08 24100104 CERAMIC CHIP, 25 F 100000PF Z
CR09 24100104 CERAMIC CHIP, 25 F 100000PF Z
CR10 24100104 CERAMIC CHIP, 25 F 100000PF Z
CR11 24105470 CERAMIC CHIP, 50 CH 47PF J
CR12 24100104 CERAMIC CHIP, 25 F 100000PF Z
CR13 24100104 CERAMIC CHIP, 25 F 100000PF Z
CR14 24100104 CERAMIC CHIP, 25 F 100000PF Z
CR15 24794470 ELECTORLYTIC, 16 47UF M
CR16 24100104 CERAMIC CHIP, 25 F 100000PF Z
CS01 24797229 ELECTROLYTIC, 50 2.2UF M
CS02 24797229 ELECTROLYTIC, 50 2.2UF M
CS03 24797229 ELECTROLYTIC, 50 2.2UF M
CS04 24797229 ELECTROLYTIC, 50 2.2UF M
CS05 24797229 ELECTROLYTIC, 50 2.2UF M
CS06 24797229 ELECTROLYTIC, 50 2.2UF M
CS07 24797229 ELECTROLYTIC, 50 2.2UF M
CS08 24797229 ELECTROLYTIC, 50 2.2UF M
CS09 24797229 ELECTROLYTIC, 50 2.2UF M
CS10 24797229 ELECTROLYTIC, 50 2.2UF M
CS11 24794100 ELECTROLYTIC, 16 10UF M
CS12 24794100 ELECTROLYTIC, 16 10UF M
CS13 24794100 ELECTROLYTIC, 16 10UF M
CS14 24794100 ELECTROLYTIC, 16 10UF M
CS18 24794100 ELECTROLYTIC, 16 10UF M
CS19 24794100 ELECTROLYTIC, 16 10UF M
CS20 24797478 ELECTROLYTIC, 50 0.47UF M
CS23 24797478 ELECTROLYTIC, 50 0.47UF M
CT01 24792221 ELECTROLYTIC CE04G 6.3 220UF M
CT02 24109103 CERAMIC CHIP, 50 B 10000PF K
CT03 24109103 CERAMIC CHIP, 50 B 10000PF K
CT04 24793101 ELECTROLYTIC, 10 100UF M
CT05 24100104 CERAMIC CHIP, 25 F 100000PF Z
CT06 24793470 ELECTROLYTIC CE04G 10 47UF M
CT07 24092538 CERAMIC CHIP, 10 F 1UF Z
CT08 24105560 CERAMIC CHIP, 50 CH 56PF J
CT09 24105560 CERAMIC CHIP, 50 CH 56PF J
CT10 24793470 ELECTROLYTIC CE04G 10 47UF M
CT11 24100104 CERAMIC CHIP, 25 F 100000PF Z
CT12 24793470 ELECTROLYTIC CE04G 10 47UF M
CT13 24100104 CERAMIC CHIP, 25 F 100000PF Z
CT14 24100104 CERAMIC CHIP, 25 F 100000PF Z
CT17 24100104 CERAMIC CHIP, 25 F 100000PF Z
CT19 24794100 ELECTROLYTIC, 16 10UF M
CT20 24109103 CERAMIC CHIP, 50 B 10000PF K
CT23 24100104 CERAMIC CHIP, 25 F 100000PF Z
CT99 24763102 ELECTROLYTIC, 16 1000UF M
C 02 24092743 CERAMIC CHIP, 10 F 470NF Z
C 03 24092538 CERAMIC CHIP, 10 F 1UF Z
C 04 24092538 CERAMIC CHIP, 10 F 1UF Z
C 05 24100104 CERAMIC CHIP, 25 F 100000PF Z
C 06 24092538 CERAMIC CHIP, 10 F 1UF Z
C 07 24100104 CERAMIC CHIP, 25 F 100000PF Z
C 08 24203101 ELECTROLYTIC, 16 100UF M 7L 3A
C 09 24092743 CERAMIC CHIP, 10 F 470NF Z
C 10 24794100 ELECTROLYTIC, 16 10UF M
C 12 24100104 CERAMIC CHIP, 25 F 100000PF Z
C 13 24794100 ELECTROLYTIC, 16 10UF M
C 14 24100104 CERAMIC CHIP, 25 F 100000PF Z
C 23 24203101 ELECTROLYTIC, 16 100UF M 7L 3A
C 24 24100104 CERAMIC CHIP, 25 F 100000PF Z
C 25 24794470 ELECTORLYTIC, 16 47UF M
C 35 24100104 CERAMIC CHIP, 25 F 100000PF Z
C 39 24794101 ELECTROLYTIC, 16 100UF M
C 40 24100104 CERAMIC CHIP, 25 F 100000PF Z
C 42 24092743 CERAMIC CHIP, 10 F 470NF Z
C 44 24092743 CERAMIC CHIP, 10 F 470NF Z
C 46 24212332 CERAMIC DISC, 50 B 3300PF K
C 47 24212332 CERAMIC DISC, 50 B 3300PF K
C 62 24794470 ELECTORLYTIC, 16 47UF M
C 65 24203101 ELECTROLYTIC, 16 100UF M 7L 3A
C 66 24203101 ELECTROLYTIC, 16 100UF M 7L 3A
CZ01 24100104 CERAMIC CHIP, 25 F 100000PF Z
CZ02 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ03 24092743 CERAMIC CHIP, 10 F 470NF Z

–19 –
LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No. LocationLocation
LocationLocation
Location Parts No.Parts No.
Parts No.Parts No.
Parts No. DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
SPECIFIC INFORMATIONS
CZ04 24100104 CERAMIC CHIP, 25 F 100000PF Z
CZ05 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ06 24100104 CERAMIC CHIP, 25 F 100000PF Z
CZ07 24100104 CERAMIC CHIP, 25 F 100000PF Z
CZ08 24100104 CERAMIC CHIP, 25 F 100000PF Z
CZ09 24105220 CERAMIC CHIP, 50 CH 22PF J
CZ10 24105100 CERAMIC CHIP, 50 CH 10PF D
CZ11 24105220 CERAMIC CHIP, 50 CH 22PF J
CZ12 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ13 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ14 24794100 ELECTROLYTIC, 16 10UF M
CZ15 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ16 24100104 CERAMIC CHIP, 25 F 100000PF Z
CZ17 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ19 24105681 CERAMIC CHIP, 50 680PF J
CZ20 24092730 CERAMIC CHIP, 16 B 0.1UF K
CZ21 24105102 CERAMIC CHIP, 25 CH 1000PF J
CZ22 24794100 ELECTROLYTIC, 16 10UF M
CZ23 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ24 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ25 24794100 ELECTROLYTIC, 16 10UF M
CZ26 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ28 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ29 24109103 CERAMIC CHIP, 50 B 10000PF K
CZ30 24794100 ELECTROLYTIC, 16 10UF M
CZ31 24100104 CERAMIC CHIP, 25 F 100000PF Z
CZ32 24105101 CERAMIC CHIP, 50 CH 100PF J
CZ33 24105270 CERAMIC CHIP, 50 CH 27PF J
CZ34 24105101 CERAMIC CHIP, 50 CH 100PF J
CZ35 24105270 CERAMIC CHIP, 50 CH 27PF J
CZ36 24105470 CERAMIC CHIP, 50 CH 47PF J
RESISTORS
R101 24553223 OXIDE METAL FILM, 1W 22K OHM J
R208 24366103 CARBON FILM, 1/6W 10K OHM J
R209 24366103 CARBON FILM, 1/6W 10K OHM J
R211 24366563 CARBON FILM, 1/6W 56K OHM J
R217 24366392 CARBON FILM, 1/6W 3.9K OHM J
R219 24366473 CARBON FILM, 1/6W 47K OHM J
R227 24366273 CARBON FILM, 1/6W 27K OHM J
R245 24011104 CHIP, METAL FILM, 1/20W 100K OHM J
R271 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R272 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R303 24321109 OXIDE METAL FILM, 1/2W 1 OHM J
R305 24322109 OXIDE METAL FILM, 1W 1 OHM J
R307 24366101 CARBON FILM, 1/6W 100 OHM J
R312 24366103 CARBON FILM, 1/6W 10K OHM J
R314 24366102 CARBON FILM, 1/6W 1K OHM J
R315 24366332 CARBON FILM, 1/6W 3.3K OHM J
R316 24366394 CARBON FILM, 1/6W 390K OHM J
R318 24366101 CARBON FILM, 1/6W 100 OHM J
R319 24366101 CARBON FILM, 1/6W 100 OHM J
R320 24366155 CARBON FILM, 1/6W 1.5M OHM J
R322 24366102 CARBON FILM, 1/6W 1K OHM J
R323 24366103 CARBON FILM, 1/6W 10K OHM J
R326 24338109 OXIDE METAL FILM, 1W 1 OHM J
R327 24338109 OXIDE METAL FILM, 1W 1 OHM J
R329 24366102 CARBON FILM, 1/6W 1K OHM J
R330 24552103 OXIDE METAL FILM, 1/2W 10K OHM J
R331 24366104 CARBON FILM, 1/6W 100K OHM J
R333 24552103 OXIDE METAL FILM, 1/2W 10K OHM J
R335 24366153 CARBON FILM, 1/6W 15K OHM J
R336 24383471 OXIDE METAL FILM, 2W 470 OHM J
R340 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R341 24366182 CARBON FILM, 1/6W 1.8K OHM J
R342 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R343 24366103 CARBON FILM, 1/6W 10K OHM J
R370 24366822 CARBON FILM, 1/6W 8.2K OHM J
R371 24366103 CARBON FILM, 1/6W 10K OHM J
R372 24366220 CARBON FILM, 1/6W 22 OHM J
R375 24552150 OXIDE METAL FILM, 1/2W 15 OHM J
R400 24946561 CARBON COMPOSITION, 1/2W 560 OHM K
R405 24553682 OXIDE METAL FILM, 1W 6.8K OHM J
R411 24366180 CARBON FILM, 1/6W 18 OHM J
R412 24323228 OXIDE METAL FILM, 2W 0.22 OHM J
R415 24383271 OXIDE METAL FILM, 2W 270 OHM J
R416 24381563 OXIDE METAL FILM, 1/2W 56K OHM J
R417 24383680 OXIDE METAL FILM, 2W 68 OHM J
R424 24366751 CARBON FILM, 1/6W 750 OHM J
R425 24552182 OXIDE METAL FILM, 1/2W 1.8K OHM J
R426 24366751 CARBON FILM, 1/6W 750 OHM J
R427 24366392 CARBON FILM, 1/6W 3.9K OHM J
R428 24366561 CARBON FILM, 1/6W 560 OHM J
R429 24553100 OXIDE FILM 1W 10 J
R433 24366681 CARBON FILM, 1/6W 680 OHM J
R434 24366472 CARBON FILM, 1/6W 4.7K OHM J
R435 24366184 CARBON FILM, 1/6W 18OK OHM J
R441 24383561 OXIDE METAL FILM, 2W 560 OHM J
R442 24553153 OXIDE METAL FILM, 1W 15K OHM J
R445 24321129 OXIDE METAL FILM, 1/2W 1.2 OHM J
R460 24366103 CARBON FILM, 1/6W 10K OHM J
R462 24366822 CARBON FILM, 1/6W 8.2K OHM J
R464 24366103 CARBON FILM, 1/6W 10K OHM J
R466 24366103 CARBON FILM, 1/6W 10K OHM J
R467 24327224 METAL FILM, 1/4W 220K OHM F
R470 24339568 METAL FILM 2W R56 J
R471 24531271 FUSIBLE, 1/2W 270 OHM J
R472 24366101 CARBON FILM, 1/6W 100 OHM J
R473 24366183 CARBON FILM, 1/6W 18K OHM J
R474 24376393 CARBON FILM, 1/2W 39K OHM J
R476 24366471 CARBON FILM, 1/6W 470 OHM J
R477 24366102 CARBON FILM, 1/6W 1K OHM J
R478 24381333 OXIDE METAL FILM, 1/2W 33K OHM J
R479 24531680 FUSIBLE, 1/2W 68 OHM J
R481 24366223 CARBON FILM, 1/6W 22K OHM J
R482 24366183 CARBON FILM, 1/6W 18K OHM J
R483 24366223 CARBON FILM, 1/6W 22K OHM J
R487 24366474 CARBON FILM, 1/6W 470K OHM J
R488 24366154 CARBON FILM, 1/6W 150K OHM J
R489 24366563 CARBON FILM, 1/6W 56K OHM J
R490 24366101 CARBON FILM, 1/6W 100 OHM J
R491 24366101 CARBON FILM, 1/6W 100 OHM J
R492 24366472 CARBON FILM, 1/6W 4.7K OHM J
R493 24366104 CARBON FILM, 1/6W 100K OHM J
R494 24366104 CARBON FILM, 1/6W 100K OHM J
R497 24366105 CARBON FILM, 1/6W 1M OHM J
R498 24366104 CARBON FILM, 1/6W 100K OHM J
R501 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J
R502 24011272 CHIP, METAL FILM, 1/20W 2.7K OHM J
R504 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R505 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R506 24011273 CHIP, METAL FILM, 1/20W 27K OHM J
R507 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J
R508 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J
R511 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R512 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R513 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R514 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R515 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R516 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R517 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R519 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J
R520 24366681 CARBON FILM, 1/6W 680 OHM J
R543 24011681 CHIP, METAL FILM, 1/20W 680 OHM J
