Totai 16/DK1010RG User manual

Flameware
This appliance complies with SANS1539 LPGSASA Permit No: 1051-XXX/1-RSA-17-A
Fig. 1
Instructions for use
Model Nos: 16/DK1010RG, 16/DK1010B, 16/DK1010C and 16/DK0101S
Totai Roll about 3 Panel Gas Heater
Do not modify the appliance in any way as this may make it unsafe
and will invalidate the manufacturer’s warranty.
Important: Read these instructions carefully so as to familiarise
yourself with the appliance before connecting it to its gas
container. Keep these instructions for future reference
Do not use this appliance in areas where there is not sufficient
ventilation. This appliance consumes oxygen and it is dangerous
to use this appliance in areas where there is insufficient
ventilation as this may cause oxygen depletion and could
endanger the life of the occupants of the area. Do not use the
heater in a bedroom whilst sleeping.
Fig. 3
B
A
Fig. 2
High
Medium
Off
Off
Start & Low
Ignition Button D
Control Knob C
1
2
Distributed by: D.K.Gas Appliances. PO Box 34191 Erasmia 0023
website: www.totai.co.za email: [email protected] Issue 1-2018

Gas type: LPG Jet size 0,62 mm
·Do not use the appliance unless the chromed wire safety guard is in place.
·Keep young children away from the appliance when it is in use. Keep the appliance away from flammable materials
e.g. Clothes, curtains or upholstery. A minimum safety distance of 500 mm is recommended.
2. Safety information
·This appliance is designed to be used only with 9 kg LPG cylinder fitted with a G 5/8 horizontal valve outlet. A
2,8kPa LPG Regulator that complies with SANS 1237 must be used with this appliance.
·Do not move the appliance when lit or when in use. Be aware that even after use it will remain hot for a several
minutes. Do not use this appliance if is it leaking gas (see notes below on how to check for a gas leak).
·Always change the gas cylinder outdoors and away from any sources of ignition.
·In the event of burn back, (where the flame burns back to the jet) immediately turn off the gas supply at the cylinder
control valve. After ensuring that the flame is extinguished, re-light the appliance as described below. Should the
appliance again burn back, close the valve and return the appliance to the supplier for examination. .
Operating Pressure: 2,8 kPa Gas usage: 300 grams per hour
1. Appliance details
·Note that it is not possible to adjust the heat output by making adjustments to the cylinder valve opening position.
·Check the connection between the cylinder and the regulator for leaks as described in section 2.
·If there are no leaks, fit the cylinder into the rear of the heater body making sure that the cylinder is placed in such a
manner that the hose is not trapped, kinked or touching the metal panel behind the burners. Do not use the heater
unless the cylinder is in position in the back of the heater. It is dangerous to use the heater with the cylinder
positioned outside of the heater body.
·Refit the heater rear panel to the body by engaging the clips as shown in Fig 1.
·Open the cylinder valve 1½ turns. Push the control knob C (Fig 2) to the Low position and hold it down. Whilst
holding the control knob down push the ignition button D down ( Fig 2). The pilot flame A should ignite (Fig 3). If it
doesn’t ignite, release the button and push it down again. Once the pilot flame has ignited, release the ignition
button but continue to hold down the control knob for approximately 15 seconds before releasing it. The pilot flame
should remain alight and should automatically ignite the centre infra red heater panel B.
·To completely turn off the heater turn the control knob to the Off position (see Fig 2). When the heater panel and
pilot light are extinguished, close the cylinder valve making sure it is properly closed by turning it in a clockwise
direction as far as it will go. Never leave the heater whilst not in use with the cylinder valve open.
3. Preparing The Heater For Use
·To reduce the heat output, push the control knob down and turning it to the next lower position (Fig 2). This will
automatically turn off the deselected panel. It is not necessary to hold the control knob down once it has been set
to the new position.
5. Shutting down the heater
·To increase the heat output by using two panels, push the control knob C down and turn it to the medium position
(Fig 2). This will automatically ignite the first of the two of the side panels. It is not necessary to hold the control
knob down once it has been set to the medium position.
·Do not check for gas leaks with a flame as this is extremely dangerous.
·To check for a gas leak, with the appliance control valve in the Off position, open the control valve on the cylinder
and use a brush dipped in a soapy water solution (e.g. water with dish washing liquid added) and apply the brush to
the suspect areas such as the cylinder valve spindle or where the regulator screws into the cylinder. Also check the
joints between the hose and regulator and between the hose and appliance. If there is a leak then bubbles will form.
Should this happen, turn off the gas supply at the cylinder valve. Inspect the condition of the seal fitted on the
regulator and ensure that it is in good condition. Refit the cylinder to the heater and re-test using the soapy water
solution. If the leak persists then return the heater and the cylinder to the supplier for inspection and/or repair.
·Unpacking the heater and unclip the cylinder retaining panel from the heater body. Take the heater outside. Place a
filled 9kg LPG cylinder beside the rear of the heater with the valve outlet facing to the rear of the heater. Check that
the cylinder valve outlet is clean and free of any obstructions or foreign matter and that the rubber seal on the
regulator connection is in place and in good condition. Connect the regulator to the outlet valve of the cylinder. Be
aware that the thread on the regulator connection is a left hand thread. To fit the regulator and tighten the thread
turn the handwheel nut on the regulator in an anti-clockwise direction. Ensure that the handwheel nut is fully
tightened by hand only . Do not use a spanner to tighten the handwheel nut.
·If there is an apparent gas leak on the appliance e.g. a smell of gas, close the valve on the cylinder. Take the
complete assembly outside into a flame free environment and test for the suspected leak as described below.
4. Lighting the Heater
·To increase the heat output to the maximum level push the control knob down and turning it to the High position (Fig
2). This will automatically ignite the other side panel. It is not necessary to hold the control knob down once it has
been set to the maximum position.
6. Changing the cylinder
·Take the heater outside and remove the rear panel (Fig 1). Lift out the cylinder and place it on the ground next to the
heater. Unscrew the regulator handwheel nut in a clockwise direction.
·Make sure that there is gas in the cylinder and that the cylinder valve is open. Check that the regulator is
connected correctly and that you have followed the lighting instructions.
8. Trouble shooting- before calling for further assistance
·Refit the heater rear panel to the body by engaging the clips as shown in Fig 1.
7. Maintenance procedures
·If there are no leaks, fit the cylinder into the rear of the heater body making sure that the cylinder is placed in such a
manner that the hose is not trapped or kinked in any way.
·Always check that the hose is in good condition before use and that it is securely clamped to the appliance and the
Regulator.
·It is recommended that the hose be replaced every two years whether it has been used or not. When replacing the
hose make sure it is a proper hose for use with LPG. These are available from a gas dealer. When replacing the
hose always replace the hose clamps at the same time.
·It is advisable to have the heater checked by a gas dealer before using every winter.
·The heater does not light
·When not in use for extended periods disconnect the Cylinder and store it outside away from buildings but covered
up to keep it clean. Store the appliance in a dry place and covered up to protect it from dust.
·To clean the appliance wipe the enamelled exterior with a damp cloth. Do not use abrasive cleaners. Never
immerse the appliance in water or use water to clean the infra red elements. If the elements appear dusty then
clean them using a soft brush or very carefully with a vacuum cleaner
·If this happens with a new or exchanged cylinder being used for the first time
·With the exception of the hose and Regulator there are no user fitted parts available for this heater. Should the
heater not function properly have it checked by a gas dealer and should replacement parts be required he will
ensure the correct parts are supplied and fitted in the proper manner.
·Before connecting the refilled cylinder, check that the bullnose seal on the regulator is undamaged and in good
condition. If in doubt take the Regulator to a gas dealer to be checked.
·Connect the refilled cylinder and check for any gas leaks as described in section 2.
·Check that the cylinder is free of air or nitrogen. To do this move the heater and cylinder to the outside in an
area where there are no sources of ignition i.e open flames or electrical switches with 5 m. Hold the control
valve down for 30 secs before pressing the ignition button. If the pilot light and centre panel are lit, move the
control knob to the high setting and let it run for 1 minute. This will ensure any trapped air or nitrogen is
released. Shut down the heater as described in section 5. Move the heater to its normal position and restart it
as described in section 4
·If the heater is excessively cold, allow the cylinder to reach room temperature and then restart the heater.
·There is very little maintenance required on this appliance. Points to note are:
·Always check that the Regulator seal is undamaged when changing a Cylinder.
·If this happens, immediately turn off the heater. The most probable cause is that the cylinder is overfilled and
must not be used as it is dangerous to use an overfilled cylinder. This is another reason to only purchase gas
from a reputable dealer. The overfilled cylinder must be returned to the supplier.
·The heater flares up and the flames burn outside of the heater panels.
·If the heater still won’t start then try a normal start up with a different cylinder - if that fails then a call service
technician to examine the heater - do not use the heater until the service technician has declared that it is safe
to do so.
·This may be due to the gas not being of the correct standard or quality. If this happens, then try another
cylinder. If this solves the problem then the gas in the original cylinder is definitely faulty and the cylinder
should be returned to the supplier. For your own safety and to ensure the efficient operation of the heater
always purchase your gas from a reputable dealer. If you are using an exchange cylinder, when purchasing,
check that the gas cylinder valve is protected by a branded shrink wrapped seal that matches the brand on the
cylinder.
·If this happens while the heater has been working continually for a period then either the gas has been used up
and the cylinder is empty, or there is insufficient ventilation in the room and the heater has shut down
automatically for safety reasons. If there is gas in the cylinder and the heater shuts down unexpectedly, open
a window to let fresh air in the room and restart the heater after waiting several minutes. Note that sufficient
ventilation is vital for the safe operation of the heater.
·The heater turns off by itself
·The heater smells or produces soot on the burners or on surrounding walls or furnishings
