SAFETY RULES & PRECAUTIONS
Proper safety precautions must be observed. Like all power
equipment this unit must be handled carefully. DO NOT EXPOSE
YOURSELF OR OTHERS TO DANGER. Follow these general rules. Do
not permit others to use this machine unless they are thoroughly
responsible and have read, and understand the machine manual and
are trained in its operation.
łAlways wear safety goggles for eye protection. Dress properly; do
not wear loose clothing or jewelry that could become caught in
moving parts of the unit. Safe, sturdy, nonskid footwear should
always be worn. Long hair should be tied back. It is recommended
that legs and feet be covered to protect from flying debris during
operation.
łInspect the entire machine for loose parts (nuts, bolts, screws, etc.)
and any damage. Repair or replace as necessary before using the
machine. DO NOT USE any attachment with this power head other
than the ones recommended by our company. Serious injury to the
operator or bystanders could result as well as damage to the machine.
łKeep the handles free from oil and fuel.
łAlways use proper handles and shoulder strap when cutting.
łDo not smoke while mixing fuel or filling tank.
łDo not mix fuel in an enclosed room or near open flames. Assure
adequate ventilation.
łAlways mix and store the fuel in a properly marked container that is
approved by local codes and ordinances for such usage.
łNever remove the fuel tank cap while the engine is running.
łNever start or run the engine inside a closed room or building.
Fumes from the exhaust contain dangerous carbon monoxide.
łNever attempt to make engine adjustments while the unit is running
and strapped to the operator. Always make engine adjustments with
the unit resting on a flat, clear surface.
łDo not use the unit if it is damaged or poorly adjusted. Never
remove the machine’s guard. Serious injury to the operator or
bystanders could result as well as damage to the machine.
łInspect the area to be cut and remove all debris that could become
entangled in the nylon cutting head. Also remove any objects that the
unit may throw during cutting.
łKeep children away. Onlookers should be kept at a safe distance
from the work area, at least 15 METER (50 FEET)
łNever leave the machine unattended.
łDo not use this unit for any job other than those for which it is
intended as described in this manual.

łDo not overreach. Keep proper footing and balance at all times. Do
not run the unit while standing on a ladder or on any other unstable
footing location.
łKeep hands and feet clear of the nylon cutting head while unit is in
use.
łDo not use this type of machine for sweeping away debris.
łDo not use the unit when you are tired, ill or under the influence of
medication, drugs or alcohol.
łUse nylon cutting head which is free of damage. If a stone or any
other obstacle is hit, stop the engine and check the nylon cutting head.
A broken or unbalanced nylon cutting head must never be used.
FOLLOW INSTRUCTION FOR CHANGING ACCESSORIES.
łDo not store in a closed area where fuel vapors can reach an open
flame from hot water heaters, furnaces, etc. Store in a locked, well
ventilated area only.
łEnsure safe and proper performance of your product. These part are
available from your dealer. The use of any other accessories or
attachments may cause a potential hazard or injury to the user,
damage to the machine and void this warranty.
łClean the machine completely, especially, the fuel tank, its
surroundings, and the air cleaner.
łWhen refueling, be sure to stop the engine and confirm that it is
cooled down. Never refuel when the engine is running or hot. When
gasoline spills, be sure to wipe it up completely dispose of those
materials before starting the engine.
łStay clear of other workers or bystanders by at least 15 meters/50
feet.
łWhen ever approaching an operator of the machine, carefully call
his attention and confirm that the operator stop the engine. Be careful
not to startle or distract the operator which can cause an unsafe
situation.
łNever touch the nylon cutting head when ever the engine is running.
If it is necessary to adjust the protector or nylon cutting head, be sure
to stop the engine and confirm that the nylon cutting head has
stopped running.
łThe engine should be turned off when the machine is moved
between work areas.
łBe careful not to hit the nylon cutting head against stones, or the
ground. Unreasonable rough operation will shorten the life of the
machine as well as create an unsafe environment for yourself and
those around you.
łPay attention to loosening and overheating of parts. If there is any
abnormality of the machine, stop operation immediately and check
the machine carefully. If necessary, have the machine serviced by a

authorized dealer. Never continue to operate a machine which may be
damaged.
łIn start-up or during operation of the engine, never touch hot parts
such as the muffler, the high voltage wire or the spark plug.
łAfter the engine has stopped, the muffler is still hot. Never place the
machine in any places where there are flammable materials (dry
grass, etc.), combustible gasses or combustible liquids.
łPay special attention to operation in the rain or just after the rain as
the ground may be slippery.
łIf you slip or fall to the ground or into a hole, release the throttle
lever immediately.
łBe careful not to drop the machine or hit it against obstacles.
łBefore proceeding to adjust or repair the machine, be sure to stop
the engine and detach the spark plug.
łWhen the machine is placed in storage for a long time, drain fuel
from the fuel tank and carburetor, clean the parts, move the machine
to a safe place and confirm that the engine is cooled down.
łMake periodic inspections to assure safe and efficient operation. For
a thorough inspection of your machine, please contact a dealer.
łKeep the machine away from fire or sparks.
łIt is believed that a condition called Reynaud’s phenomenon, which
affects the fingers of certain individuals may be brought about by
exposure to vibration and cold, loss of color and numbness in the
fingers. The following precautions are strongly recommended
because the minimum exposure which might trigger the ailment is
unknown. Keep your body warm, especially the head, neck, feet,
ankles, hands and wrists. Maintain good blood circulation by
performing vigorous arm exercises during frequent work breaks and
also by not smoking. Limit the hours of operation. Try to fill each day
with jobs where operating the brush cutter or other hand-held power
equipment is not required.
If you experience discomfort, redness and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
łAlways wear ear protection, loud noise for long time can make
hearing debase even lost hearing.
łTotal face and head protection must be wearing to prevent damage
from plummet or branch.
łWear no-slip heavy duty work gloves to improve your grip on the
brush cutter handle. Gloves also reduce the transmission of machine
vibration to your hands
łWARNING: The cutter area is still dangerous while the machine is
coasting to a stop.

WARNINGS
Because a trimmer/cutter is a high-speed, fast cutting power tool,
special safety precaution must be observed to reduce the risk of
personal injury. Read this manual carefully. Be familiar with the
controls and the proper use of the unit. Know how to shut it off, and
how to unhook a harnessed unit quickly.
This graphic accompanied by the words WARNING
and DANGER calls attention to an act of a condition
which can lead to SERIOUS INJURY.
READ & UNDERSTAND Operator’s Manual and
Safety Manual.
ALWAYS WEAR EYE PROTECTION, EAR
PROTECTION AND HEAD PROTECTION.
WEAR FOOT PROTECTION
WEAR GLOVES
BEWARE OF FOOT INJURY BY CUTTING
ATTACHMENT
BEWARE OF THROWN OBJECTS HIT BY CUTTING
ATTACHMENTS. NEVER USE WITHOUT PROPERLY
MOUNTED BLADE GUARD.
KEEP 15 METERS AWAY FROM ANY OTHER PERSON

Specification
MODEL TP425381
Remote type Direct Drive
Flexible shaft
Max. speed(rpm) 8140
Idle speed(rpm) 3000±150
Vibration values at
each handle(m/s2)15
Sound pressure
values[dB(A)] 102
Guaranteed Sound
power values [dB(A)] 111
Line cutting width 15ļ/380 mm
Nylon head rotation Clockwise(seen from the top)
Aluminum pole 2 pcs
Main
unit
Weight when dry(kg) 4.8
Engine type Air-cooled;2 cycle; vertical
Piston valve; gasoline engine
Displacement(mL) 25
Maximum
output(W/rpm) 750/7500
Carburetor Diaphragm-type
Ignition Non-contact electronic ignition
Method of starting Recoil type
Fuel used Gasoline mixed with lubricating
oil
(ratio of 40:1)
Engine
Fuel tank capacity(L) 0.5
Accessories included:
1set line spool
1pcs debris shield
1pcs oil bottle
1pcs auxiliary handle
1pcs carrying belt
1pcs wrench
2pcs hex keys

Before operation
SAFETY MANUAL included with unit. Read before operating and keep
for future reference to learn proper, safe operating techniques.
NYLON CUTTER HEAD Contains replaceable nylon trimming line that
advances when the trimmer head is tapped against the ground while
the head is turning at normal operating speed.
CUT-OFF KNIFE Trims nylon filament to the correct length-7,headto
end of line-when nylon trimming head is bumped on the ground
during operation, line advance. If trimmer is operated without a
cut-off knife the line becomes too long (more than7”) the engine, this
will overheat or damage the engine.
DEBRIS SHIELD Mounted just above the cutting attachment. Helps
protest operator by deflecting debris produced during debris produced
during the trimming operation. Do not operate unit without shield.
D-HANDLE this handle can be adjusted at you convenience for
comfort.
DRIVE SHAFT ASSEMBLY contains a specially designed liner flexible
drive shaft.
IGNITION SWITCH “slide switch” mounted on top of the Throttle
Trigger Housing. Move switch FORWARD to Run, BACK TO STOP.
SAFETY LEVER Before acceleration compresses it please.
THROTTLE TRIGGER Spring loaded to return to idle when released.
When accelerating, press trigger gradually for best operating
technique. Do not hold trigger while starting.
PURGE BULB Pushing purge bulb (7 to 10 times before starting),will
remove all air and sale fuel from fuel system and bring fresh fuel to
the carburetor.
FUEL TANK LID.
FUEL TANK Contains fuel and fuel filter.
AIR CLEANER COVER Contains replaceable felt element.

CHOKE the choke control is located on the top of the filter cover.
STARTER HSNDLE pull handle until engine starts, then return handle
slowly. DO NOT let handle snap back or damage to starter will occur.
ASSEMBLY INSTRUCTIONS
HANDLE ASSEMBLY
NOTE: The Delta Handle is attached to the shaft but has been
turned under for ease of packing.
Loosen adjustment knob and rotate handle to top of shaft
handle to top of shaft Position handle 6-1/2 to 8-1/2ļfrom
throttle (Fig.1)
Tighten adjustment knob securely.
DEBRIS SHIELD
Shield Fits snug on shaft. Some force may be
required.
Seat shield (B) onto shaft bracket (C).
Insert washers (D) onto bolt.
Insert bolt (E) and nut (F).tighten securely. Fig.1
Fig.2A Fig.2B
INSTALLING THE LOWER SHAFT
Pack the aluminum tube into the
connector inside, make the convex
ball aim at the hole on connector
Then turning the knob clockwise until it is tight

DANGER ZONE
NO PERSON EXCEPT OPERATOR ALLOWED 15 METERS RADIUS DANGER ZONE.
EYE, EAR, FACE, FOOT, LEG AND BODY PROTECTION MUST BE WORN BY
OPERATOR. PERSONS IN ZONE OR RISK BEYOND DANGER ZONE SHOULD WEAR
EYE PROTECTION AGAINST THROWN OBJECTS. RISK DIMINISHES WITH
DISTANCE FROM DANGER ZONE.
CUTTING WITH A NYLON HEAD
For nearly all cutting, it is good to
tilt the lineheadofthecirclewhere
the line is moving A W A Y you
and the debris shield.
WARNING
DANGER
LineheadrotatesinaCLOCKWISE
Tilting the head to the wrong side will
shoot the debris TOWARDS you. If
the line head is held flat to the
ground so that cutting occurs on the
whole line circle, debris will be
THROWN at you, drag will slow the
engine down, and you will use up a
lot of line.
direction. The CUT-OFF KNIFE will
be on the right side of the debris
shield.

WARNING
DANGER
CUTTING WITH A NYLON HEAD
TRIMMING:
This is feeding the trimmer carefully into
the material you wish to cut. Tilt the head
slowly to direct debris away from you. If
cutting up to a barrier such as fence, wall
or tree, approach from an angle where
any debris ricocheting off the barrier will
fly away from you, Move the line head
slowly until the grass is cut right up the
barrier, but do not jam (overfeed) the line
into the barrier. If trimming up to a wire
mesh or chain linked fence be careful to
feed only up to wire. If you go to far the
line will snap off around the wire.
Use only quality nylon monofilament
line of the diameter 2 mm. Never
use wire or wore-reinforced line in
place of nylon trimmer line. Load
your nylon line cutting head only
with ny n trimmer
lo
WARNING DANGER
Use extreme caution when operating
over bare spots and gravel, because
the line can throw small rock
particles at high speeds. Debris
shields on the unit cannot stop
objects which bounce or ricochet off
hard surfaces.
WARNING DANGER
The proper debris shield must be in
place on the unit when nylon
cutting line is used, The cutting line
can flap around if too much line is
exposed. Always use the plastic
debris shield with cut-off knife
when using nylon cutting heads.

Trimming can be done to cut through
weed stems one at a time. Place the
trimmer line head near the bottom of the
weed-never high up which could cause
the weed to chatter and catch the line.
Rather than cut the weed right through,
just use the very end of the line to wear
through the stem slowly.
WARNING DANGER
Don’ttouseasteelbladeforedgingorscalping.
SCALPING AND ENGING:
Both of these are done with the line head
tilted at a steep angle Scalping is removing
top growth leaving the earth bear.
Edging is trimming the grass back where it
has spread over a sidewalk or drive way.
During both edging and scalping, hold the
unit a steep angle and in a position
where the debris, and any dislodging dirt
and stones, will not come back towards
you even if it ricochets off the hard surface.
Although the picture shows how to edge and
scalp every operator must find for himself
the angles which suits his body size and
cutting situation.
WARNING DANGER
Do not trim in any area where there are
strands of fencing wire. Wear protective
safety protecting; Do not cut where you
cannot see what the cuttin
g
device is cuttin
g
.

FUEL & OIL MIXTURE
zNever fill the fuel tank to the very top.
zNever add fuel to the tank in a closed non-ventilated
area.
zDo not add fuel to this unit close to an open fire or
sparks.
zBe sure to wipe off spilled fuel before attempting to
start engine.
zDo not attempt to refuel a hot engine.
Fuel used for this model is a mixture of unleaded gasoline and
approved engine lubricant. When mixing gasoline with two-cycle
engine oil, use only gasoline which contains NO ETHANOL or
METHANOL(Types of Alcohol) Use Branded 89 octane or higher
Unleaded gasoline known to be of good quality. This will help to avoid
possible damage to engine fuel lines and other engine parts.
MIXTURE RATIO IS 40:1
GASOLINE-40PART OIL-1
PART
Fuelmixtureattherate other than
40:1may cause damage to the
engine, Ensure mixture ratio is
correct.
PREPARING FOR OPERATIONS
WHEN MIXING GASOLINE WITH TWO CYCLE ENGINE OIL, USE ONLY
GASOLINE WHICH CONTAINS NO ETHANOL OR METHANOL (TYPES OF
ALCOHOL). THIS WILL HELP TO AVOID POSSIBLE DAMAGE TO
ENGINE FUEL LINES AND OTHER ENGINE PARTS.DO NOT MIX
GASOLINE AND OIL DIRECTLY IN THE ENGINE FUEL TANK.
IMPORTANT: Failure to follow proper fuel mix instructions may cause
damage to the engine.
1. When preparing fuel mixture, mix only the amount needed for the
job you are to do. Do not use fuel that has been stored longer than

two months. Fuel mixture stored longer than this will cause hard
starting and poor performance. If fuel mix has been stored longer
than this time. It should be removed and filled with fresh mixture.
2. Never fill the fuel tank to the very top.
3. Never add fuel to the tank in a closed non-ventilated area.
4. Do not add fuel to this unit close to an open fire or sparks.
5. Be sure to wipe off spilled fuel before attempting to start engine
6. Do not attempt to refuel a hot engine
CHECK POINTS BEFORE OPERATION
1. Check for loose bolts. Nuts and fittings.
2. Check the air cleaner for dirt. Clean the air filter of all dirt. Etc.
before operation.
3. Check to be sure that protector is securely in place.
4. Check to be sure that is not leak.
WARNING DANGER
The engine exhaust from this product contains chemicals known to
cause cancer, birth defects, or other reproductive harm.
OPERATIONS
ENGINE STARTING AND
STOPPING PROCEDURES
STARTING COLD ENGINE
Move the stop switch to “START”
position.
1. Give a gentle push on the primer pump
repeatedly (7-10times) until fuel comes
into the primer pump.
2. Cold Starts: Pull lever up to close choke.
3. Pullstarterhandle untilengineflash fires.

4. Push choke lever inwards (excessive cranking with choke lever will
cause flooding engine making it difficult to start).
5. Pullstarterhandle untilenginestarts.
6. Allow engine to warm up for a few minutes before using.
STARTING WARM ENGINE
1. If fuel tank was not run dry, pull starter one to three times and
should start.
2. If fuel tank was run dry, after refilling repeat steps 3 thru 7 in.
STARTING COLD ENGINE.
STOPPING THE ENGINE
zMove switch to STOP position
MAINTENANCE & CARE
AIR FILTER
zAccumulated dust in the air filter will
reduce engine efficiency. Increase fuel
consumption and allow abrasive particles
to pass into the engine. Remove the air
filter as often as necessary to maintain in
a clean condition.
zLight surface dust can readily be removed
by tapping the filter. Heavy deposits
should be washed out in suitable solvent.
zRemove filter cover by loosening air
filter cover knob.
ADJUSTING CARBURETOR
NOTE
Do not adjust carburetor unless necessary.
If you have trouble with the Carburetor,
see your dealer. Improper adjustment
may cause engine damage.
FUEL FILTER
zFuel tank is fitted with a filter.
Filter is situated at the free end of fuel
pipe and can be picked out through fuel

port with a piece of hooked wire.
zCheck the fuel filter periodically. Do not
allow dust to enter into fuel tank. Clogged
filter will cause difficulty in starting
engine or abnormalities in starting engine
or abnormalities in engine performance.
zWhen filter is dirty, replace the filter.
zWhen the inside of the fuel tank is dirty,
it can be cleaned by rinsing the tank out
with gasoline.
CHECK SPARK PLUG
zDo not attempt to remove the plug
from a hot engine in order to avoid
possible damage to the threads.
TROUBLE SHOOTING
zClean or replace the plug if fouled with heavy oily deposits.
zReplace the plug if the center electrode is worn rounded at the
end.
zSpark gap 0.6-0.7mm (.023".028")
zFastening torque = 145-155kg.cm (125-135in.lb)
zThe engine should be turned off when the unit is moved between
work areas.
zAfter the engine has stopped, the muffler is still hot. Never touch
hot parts such as the muffler.
zConfirm that the fuel is not leaked from tank.
zInspect, clean and repair unit if necessary.
zRemove all fuel from tank.
zStart engine-This will consume all fuel in fuel line and carburetor.
zRemove spark plug and pour one tea spoon of clean motor oil into
spark plug hole of cylinder-replace spark plug.
zStore in clean, dry, dust free area.
FAILURES such as difficulty in starting engine, irregularity in functions
and abnormality in performance can normally be prevented if careful
attention is paid to all operating instructions and maintenance
procedures.
Should the engine not function properly, check the following:
zThat the fuel system is in good condition and fuel is flowing to the
engine.
zThe ignition system is in good condition and the spark plug, sparks

correctly;
zCompression of the engine is adequate.
zDispose of fuel in tank.
zInsure that fuel is fresh and clean.
zCheck fuel filter to make sure it is clean. (Replace filter if
necessary).
zMake sure air filter elements are clean.
zInstall new, properly gapped spark plug.
zWhen there is serious trouble with the unit, do not try to repair it
yourself but have your distributor or dealer do it for you.
TROUBLESHOOTING GUIDE
1. FAILURE TO START
symptom Probable cause Remedy
fuel
system
abnormality
these is no fuel in
tank
fuel filter obstruct
Add fuel in tank
Clean fuel filter
spark
plug
spark
normal fuel
system
normal fuel
fuel is too dirty
there is water in
fuel
there is too much
mixture ratio is
improper
instead fuel
instead fuel
tear down spark plug
and dry it
mixture peroration
high
voltage
wire
spark
normal
spark
plug
spark plug fouled
with oily
deposits
Spark plug
insulation
damage
Spark gap is too
large or small
clean the oil deposits
replace spark plug
adjust spark gap
0.6-0.7mm
cylin
der
comp
ress
press
ure
norm
al
fuel
system
normal high
voltage
spark
abnormality
high voltage wire
breach
or break off
coil looseness
replace or tighten
tighten

compress
press
is
shortage
piston ring attrite
piston ring is
broken
piston ring
cementation
spark plug
looseness
conjoint surface
of the
cylinder and
crank cast leak
replace a new
replace
eliminate
tighten
eliminate
fuel
syste
m
norm
al
Ignition
System
normal
Compress
normal
High voltage wire
and spark
Plug contact
badness
Stop switch
failure or short
circuit
tighten the spark plug
cap
repair or replace
2. LOW OUTPUT
symptom Probable cause Remedy
flameout when
speedup
the smoke is thin,
carburetor spout
backward
fuel filter obstruct,
fall short of fuel
muffler fouled with
oily deposits
clean fuel filterǃclean
fuel roadǃ
adjust carburetor
clean the oily deposits
compress press is
shortage pistonǃpiston ringǃ
cylinder attriteǃ
replace pistonǃpiston
ring
engine leak Conjoint surface of
the
Cylinder and crank
cast leak
repair
the end of two crank
shaft leak the seal is bad replace seal
engine overheats
burning room fouled
with
oily deposits
avoid use it for long
timeǃ
high speed and heavy
load
clean the oily deposits

3. ENGINE RUNNING UNSTABLE
symptom Probable cause Remedy
there are metal knock
sound pistonǃpiston ringǃ
cylinder attriteǃ
piston pin ǃpiston
attrite
bearing of crank shaft
attrite
replace pistonǃpiston
ring
replace piston pin ǃ
piston
replace bearing
there are metal knock
sound engine overheats
burning room fouled
with
oily deposits
gasoline branded is
unfit
avoid use it for long
timeǃ
high speed and heavy
load clean the oily
deposits
replace require
branded octane
engine ignition break
off there is water in fuel
spark gap is wrong
coil gap is wrong
instead fuel
adjust spark gap
0.6-0.7mm
adjust coil gap
0.3-0.4mm
4. THE ENGINE SUDDENLY STOPPED
Probable cause Remedy
fuel is use up
spark plug fouled with oily
deposits and short circuit
high voltage wire fall off
add fuel
clean the oily deposits
connect

TP425381 Spare Part List
NO. Part Description NO. Part Description
eldnahthgiR62.1rennapS1.1
1.2 Rope wheel covering 1.27 Hookup set of the shaft
1.3 Nylon rope(2X5mm) 1.28 Flexible shaft B
BebuT.ulA92.1taesepoR4.1 lednahtnorF03.1gnirpS5.1 39-497T/BG55X6MtloB13.1xob
epoR6.1 AeldnahhctiwS23.1rehsuB7.1 58-548BG51X5.3TStloB33.1tfahS8.1 58-818BG8X5MtloB43.1gniraeB9.1 revele
lttorhT53.1eveelsleetS1.1 AgnirpsrabnoisroT63.1rehsaW11.1 reggirtehtfoecnaerusnI73.1eveelsleetS21.1 Bgni
rpsrabnoisroT83.1tekcarB31.1 rekcolreggirT93.1BG7X4
tiviR41.1 hctiwS04.1repapdrauG51.1
1.16 Nut M5 GB889-86 1.41 Switch handle B
ebutcitsalP24.1ef
inK71.1 enilelttorhT34.1dleihsdrauG81.1
1.19 Bolt M6X50 GB5780-86 1.44 Shock attenuation tube
1.2 Nut M6 GB62-88A 1.45 Screw M4X16 GB818-85
1.21 Bolt module M5X12 GB70-85 1.46 Spring washer4 GB93-87
58-1.79BG4teksaG74.1Aebut.ulA22.1 )cc52(enignE84.1bonK32.1 ebu
tgnitacoL94.1rotcennoC42.1
1.25 Guard Ring Sleeve

TP425381 Exploding view
Table of contents
Other Total Trimmer manuals
