TotalSeat A50 User manual

OPERATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
A50 FULL BODY AIR-MASSAGE CHAIR

01
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
02
04
05
16
19
Safety and maintenance
Name and function of components
Function & Efficacy
Method of usage
Product specification
CONTENTS

0302
Safety And Maintenance Safety And Maintenance
Dont allow children to touch moveable part of this product.
Please use well-grounding power supply suited to this product.
Please pull out the plug after use or before cleaning to avoid injury or
Damage to the product.
Please operate this product according to this manual instruction.
Dont use accessories which are not recommended.
Dont use this product outdoors.
Please read this manual instruction carefully before operation.
Any other usage that is not listed in this manual instruction is forbidden.
20 minutes of usage each time is recommended.
Please dont use it if the leather is broken or damaged.
Please dont use it if the cover or leather is damaged.
Please dont use it if the radiator hole is covered or blocked.
Please dont drop anything into this product.
Please dont fall asleep while using this product.
Please dont use it if drunk or feel unwell.
Please dont use it within one hour after having meal.
Please dont make the massage function too strong for avoiding Injury.
2. Environment for usage.
Please dont use it under high temperature and moist environment such as
bathroom.
Please dont use it immediately while the environmental temperature
changes sharply.
Please dont use it under heavy-dusty or caustic environment.
Please dont use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
People who are suffering from osteoporosis are not suitable to use this product.
People who are suffering from heart disease or carrying electronic medical equipment
such as heart pacemaker are not suitable to use this product.
People who are suffering from fever are not suitable to use this product.
Pregnant women or women that are in menses period are not suitable to use this
product.
People who got injured or skin disease are not suitable to use this product.
Children under 14-year old or people mentally unbalanced without being
Supervised are not allowed to use this machine.
People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product.
People whose bodies are wet are forbidden to use this product.
The appliance has a heated surface.persons insensitive to Heat must be careful
when using the appliance.
4. Safety.
Check the voltage if it is suitable to the specification of this product.
Dont use wet hand to pull the plug.
Dont make water go inside this product to avoid electric shock or cause damage to
this product.
Dont damage the wires or change the circuit of this product.
Dont use wet cloth to clean the electric parts such as switch and plug.
Be away from this product under power cut state to avoid injury if the power comeback
suddenly.
Stop using this product while it works abnormal, and please consult local agent
immediately.
Stop using this product if you feel unwell, and please consult health care doctor.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its Service
agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
This product should be maintained by certain appointed agents, users are prohibited
to disassemble or maintain by themselves.
Please dont forget to cut the power after usage.
Dont use this product if the socket looses.
If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
Dont reserve this product under high temperature or near fire and avoid longtime
direct sunshine.
If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
Hazard.
Please clean this product by dry cloth. Dont use thinner, benzene or alcohol.
The mechanical components of this product are specially designed and made, it is
not necessary to be specially maintained.
Dont use edged res to thrust this product.
Dont roll or pull this product above uneven ground, it should be lifted before moving.
Please use it intermittently; dont make this product work continuously for long.
6. Solution of ordinary malfunctions.
It is nature movement voice if the motor sounds while in usage.
1.IMPORTANT SAFETY WARNING.

04 05
1
2
4
3
5
7
11
10
12
8
6
14
13
16
15
17 18
ON/OF F FUSE
19
Functions
This product is designed with a set of smart 3D mechanical hands, which can move
up and down, stretching back and forth, four-wheel driven with muted design
The shoulder part is designed with automatic detection and micro adjustment
function; body curve and massage points automatic detection, it can automatically
adjust the distance of massage hands' moving back and forth according to the
detected body curve and massage points, to make the massage more humanistic
and scientific.
Comfort, ease, ache relieve, full air pressure, waist twist, waist stretch and other
specific massage functions.
Set with three kinds memo massage functions
Manually select the upper body massage; three massage position options of overall,
partial and fixed position; six massage methods of shoulder grasping, kneading,
tapping, shiatsu, kneading &flapping and 3 D; five massage speed levels available;
under tapping and shiatsu massage status, the width of the massage hand can be
adjusted in five levels.
Arm air massage function (built-in 26 airbags), upper arm air massage function
(built-in 4 airbags), with 3 intensity adjustments
Lower body air pressure massage function: back air pressure massage function
(built in 4 airbags), buttock air pressure massage (built in 5 airbags) legs air
pressure massage function (built-in 40 airbags), with 3 intensity adjustments.
Cell phone MP3 player function, upper arm built in 3 D digital audio
Back heating function, use carbon fiber as infrared heating source
Knee heating function, use carbon fiber as infrared heating source
The footrest can be extended to suit various heights
Footrest lifting, backrest lift and laying and lie-down models adjustment
Auto-sitting function, massage hands can automatically return to original position
after turning off.
VFD display
LED colorful mood light on armrest
Efficacy
Relieve fatigue
Promote blood circulation
Alleviate muscle fatigue
9
Name And Function Of Components Function & Efficacy
Enlarge figure
1.Pillow pad
2.3 D digital audio
3.Controller
4.Arm air bags assembly
5.Seat cushion
6.Cell phone pocket
7.Legs frame
8.Foot frame
9.Upper arm air bags assembly
10.Back cushion
11.Armrest
12.LED colorful mood light
13.Back cover
14.Controller holder
15.Base caster
16.Power line and power plug
17.Power socket
18.Power switch
19.Fuse box

0706
ON/ OFF F US E
ABC
Method Of UsageMethod Of Usage Method Of UsageMethod Of Usage
NOTE: this is for reference only, please take practicality as standard
1.Switch power supply on
Diagram of the switch position of power supply
Diagram of plug in
Shoulder
adjust
High shoulder position
suitable shoulder position
Low shoulder position
2.Start to massage
Press the red power button to start massage, the massage chair lie down 
automatically
Automatically detecting shoulder position and massage points, please wait till 
detection finished.
It sounds [di di di...] after detection finished. Now, please adjust the shoulder 
position by pressing up or down button. It will run automatic massage if there is no
adjustment on shoulder position within 10 seconds.
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
Shoulder position
adjustment (Upper button)
Shoulder position
adjustment (lower button)
Choose massage methods
Memory massage
When you are massaging, you can use A, B, C memory button at any time, press
one of the button, then will back to the stored massage models to massage.
CUSTOMIZATION MODES STORE
ABC
TIME FINE RELAX
STIFFNESS
AIR
PRESSURE
WAIST
STRETCH
ADJUSTING SHOU LDER
+
- BACK
INTENSITY
KNEAD&FLAP
KNEAD
SHOULDER
3D
FLAP SHIATSU
SPEED WIDTH
ARM INTENSITY
LOWER BODY
INTENSITY
HEATER
SOLE ROLLER
ARTHROSIS
TRACTION

0908
Manual functions
Air pressure massage
3D
(H1)
(H1)
(H1)
(H1-H2)
(H1-H2)
3D (H1-H4)
F1 Auto
F2 Auto
F3 Auto
F4 Auto
F5 Auto
Back
buttoc k s
Feet
Method Of Usage Method Of Usage
Buttons description
FINE
RELAX
STIFFNESS
AIR
PRESSURE
WAIST
STRETCH
Comfort: relax muscles and bones
Ease: promote blood circulation
Ache : make deep massage to relax the ache position relieve
Whole-body air pressure massage: waist, buttock, arms, legs
air pressure massage work at the same time.
Waist stretch: When the calf airbags work and squeeze calf part,
the backrest lays down and calf rest pulls down to stretch the
waist part, then return to original position and repeat above
actions. Meantime the seat airbags and massage mechanism
works.
Buttons description display
SHOULDER
KNEAD&TAP
TAPPING
SHIATSU
SPEED
WIDTH
Grasp: built in 1 massage method, speed and strength
adjustable
Kneading & taping: built in 1 massage method, speed
and strength adjustable
Kneading: built in 1 massage method, speed and
strength adjustable
Taping: built in 2 massage methods, speed, width and
strength adjustable
Shiatsu: built in 2 massage methods, speed width and
strength adjustable
3 D: built in 4 massage methods, speed and strength
adjustable
Speed: with 5 levels available
Width: 5 levels available (in taping and kneading
massage mode)
Buttons description display
BACK STRETCH
BACK STRETCH
BACK STRETCH
LOWER ADJUST
UPPER ADJUST
Fixed position (fixed point) massage
Small area (partial) massage back and forth
Upper body (overall) back and forth
Massage position adjust ( can adjust
the massage position in fixed
position, partial mode)
Mechanical hands move downward
Mechanical hands move upward
Note: back stretch ( except shoulder grasp, other manual modes are effective)
ARM
INTENSITY
INTENSITY
Buttons description display
Arms: press this button, the arm air pressure and upper arm air
pressure massage function on
Strength: arm air pressure strength has 3 levels adjustable
Automatically massage
TIME
LOWER BODY
ARTHROSIS TRACTION
Timing set
Rated time is 20 minutes. Max working time is 40 minutes. Every time press on
timing set button add to 5 more minutes. Working time up to 40 minutes, press
on timing set button return to 5 minutes. Follow by cycle.
Lower body: press this button and choose lower body air
pressure massage function (including lower body, back and
waist, calf)
Intensity: air pressure massage intensity of lower body, back
and waist, calf. Three intensity available.
The function of calf stretch will be enabled automatically under the mode of
lower body air pressure massage and calf air pressure massage.
KNEAD

11
10
Press red power button during massage to stop all massage functions immediately,
the backrest and footrest will return to original position automatically.After rated
working time, all massage functions will be finished but backrest and footrest won't
return to original position.
After rated working time or switch off, the handle controller displayed "Memory Set On"
and glitter, and remind the users whether need to store the massage mode before turn
off, you can choose the memo function buttons A, B, C as your requirement, store the
massage mode. Press the red button again, the machine turn off, and the massage
hands will restore to the original position, or wait for 10 seconds, the machine turn off
automatically, and the massage restore to the original position.
ON/ OFF F US E
Memory set on
Auto
01 ~ 03
-
+
Method Of Usage Method Of Usage
Other manual function
Buttons description display
BACK
WEAKEN BUTTON
BACK
STRENGTHEN BUTTON
Back weaken button: press this button, weaken the
strength of upper body massage
Back strengthen button: press this button, strengthen
the strength of upper body massage
SOLE ROLLER
HEATER
Warm therapy: back heating and knee heating switch,
has warm feeling when it start to work 3 minutes later.
3.The angle of back rest and calf rest
Buttons description display
Auto lay down mode: with 3 auto lay down modes, when
press the button, turn into one mode.
Calf rest lifting button: press this button, calf rest lifting slowly, stop
when release it.
Calf rest decline button: press this button, calf rest decline slowly, stop
when release it.
Back rest lifting button: press this button, back rest lifting slowly, stop
when release it.
Back rest decline button: press this button, back rest decline slowly,
stop when release it.
Linkage upward: press this button, the back rest lifting slowly, and the
calf rest decline slowly at the same time, stop when release it.
Linkage downward: press this button, the back rest decline slowly, and
the calf rest lifting slowly at the same time, stop when release it.
music when massaging.
With a 3 D digit audio equipment on each side of the upper arm of armrest,connect
with cell phone music, and played through the 3 D digit audio equipment, you will
enjoy music and massage when relaxing
Colorful light on armrest: with colorful light on each side, red, green, blue, blue-
4. Other function
Cell phone music: set cell phone pocket in left arm rest, audio equipment built in,
make the music and massage working at same time, share the rhythm of the
Cell phone
pocket (audio interface)
3 D digit audio LED colorful mood light
5.Shut off power and finish massage
Switch power off
Figure (Cut off the power of the machine)
Power switch position
method of cut off power 
Sole roller: sole roller switch, with 3 speed levels available

1312
Method Of Usage Method Of Usage
6.Am rest installation
Find out the plug respond to the arm rest on the bottom of the seat frame, and
through out from the square hole which on the fixed steel board.(figure 1)
When the plug out from the square hole on the steel board, respond to every 
connecting plug( figure 2)
( Figure 1) ( Figure 2)
Draw out the plug on the bottom of the seat frame and connect with the arm rest
joint, air pipe responded to the right place (figure 3)
After connect the responded connector, insert it gently through the square hole on
the bottom of the seat frame, be careful to avoid to fold the air pipe (figure 4)
( Figure 3) ( Figure 4)
As figure, the pin on the arm rest respond to the box on the fix board, the steel
board respond to the groove of arm rest.(figure 5)
Hold the arm rest with your hands, pin respond to box on the front part of the steel
board, and pin respond to box on the behind of the armrest,( check the connect
wire whether it is insert in to the bottom of the armrest frame, avoid to get stuck),
( Figure 5) ( Figure 6)
Note: the connect wire must be
insert in the right place, avoid to get stuck
Arm rest covered on the fixed steel board, then press the armrest make sure the pin
into the box on the fixed steel board, and pull it with your hand to check it is fasten
tightly.(figure 7)
Find out the install hole on the front part of the fixed steel board, screw the screws
with hex wrench. £Figure 8£
Find out the install hole on the behind part of the fixed steel board, screw the screws
with hex wrench, finish the installnation, the same installnation of the two armrest.
( Figure 7)
( Figure 8)
( Figure 9)
PRESS IT
DOWNWARD GENTLY
Armrest
Seat cushion
Calf rest
Figure: hex head screw
fixed in front part of armrest
Armrest
back cover
Figure: hex head screw
fixed in behind part of armrest
Pull
INSERT INTO THE
BOTTOM OF
THE SEAT FRAME
7. Upper armrest installation
( Figure 1)
( Figure 2)
 Air pipe and trumpet line in backrest cross upper armrest and pipe hole. Two
guide pillars of upper armrest insert relevant hole on backrest cover(Figure 1).
Upper armrest pressed tightly by hand. Fixed the upper armrest on armrest 
cover by two cross recessed pan head screws(Figure 2)

8.Handle controller frame installation
Handle controller tray
Screw
Frame
Handle controller
frame assembly
Method Of Usage Method Of Usage
Ready for the handle controller tray, steel pole, take out the fixed screws on the handle
controller tray. (Figure 1)
Insert the ball joint of the steel pole to the concave spherical of the handle controller
tray.(figure 2)
( Figure 1) ( Figure 2)
Screw the screws in to the hole which got in step 1 and tighten it, take care the
direction, should be screw it from right to left. (Figure 3)
Prepare the cylindrical fixed pipe.(Figure 4)
( Figure 3) ( Figure 4)
1514
( Figure 3)
( Figure 4)
( Figure 5) ( Figure 6
Joint the upper armrest, trumpet line in backrest and the air pipe. Make sure the
connection is well and without air leak(Figure 3).
After the connected air pipe and trumpet line, please surround the cable within 
upper armrest. Do not fold any pipe or cable(Figure 4).
Surround
Air Pipe
Installation of decoration bar. Insert it into upper armrest cover slot. Lightly press
inward rim make it fit. Be careful of damage rim during installation(Figure 5).
Tighten decoration bar with supplied cross recessed pan head screws(Figure 6)
Insert
Lightly
press inward

1716
Method Of Usage Method Of Usage
Prepare the handle controller frame assembly in step 3.(figure 7)
Insert the handle controller frame assembly in to the cylindrical fixed pipe, be carefully
( Figure 7) ( Figure 8)
Prepare two screws which tighten on two sides (figure 9)
( Figure 9) ( Figure 10)
9.Controller installation and usage
Insert the handle controller in to the frame (figure 1), the frame can turn left and rig ht
freely. (Figure 2) and the handle controller can swing freely in horizontal direction.
( Figure 1)
( Figure 2) ( Figure 3)
ENLARGE
FIGURE
Put the cylindrical fixed pipe in to the hole on the right armrest, take care that the
sthere hole on the fixed pipe should be one to one corresponded with the hole on
the arm rest of the flange plate. (figure 5)
Screw three screws to tighten it ( figure 6)
( Figure 5) ( Figure 6)
Note: the gap should be
face down and vertical to the earth
£1£ £2£
10.The disassemble and using of pillow pad and back cushion
You can weaken the kneading strength of the neck and shoulder by pillow pad, you
can use it according to your requirement (Advise you use it). Back cushion connect
with back by zipper (1), pillow pad connect with the back cushion by fastener (2)
Zipper
Fastener

18 19
11.Floor Protection
Put the heavy massage chairs on the wood floor for a longtime may damage the
floor, so please place a carpet or other object to avoid this damage.
Caution: Do not move the chairs with its wheels on wood floor, rough ground or in a
narrow space. Two people are required to lift the chair.
12.Method Of Movement
Make sure that all wires are far above the ground, tilt the backrest backward to a
certain degree (with the gravity center resting on the wheels), push the chair forward
or backward with your hands and finally resume the chair to the normal position in a
slow and gentle manner.
Method Of Usage
Material introduction: PVC, PA, steel parts and electric &ele
-ctron parts
MATERIAL PU LEATHER CLOTH WOOD
Model: A50
Description: Full Body Air-massage Chair
Rated Voltage: 110-120V~ 60Hz
220-240V~ 50Hz60Hz
Rated Power Input: 200W
Rated Working Time: 20Minutes
Safety Design: Class
Product Specification
