2004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Overview of instruments and controls
Instrument panel overview 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument cluster overview 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Indicator symbols on the instrument panel 7. . . . . . . . . . . . . . . . . . . . . . .
04 01.06
SECTION 1 - 1

WWW.MANUALS.WS
WWW.MANUALS.WS
22004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
Instrument panel overview
1. Side vents
2. Instrument cluster
3. Center vents
4. Rear view mirror remote control levers
5. Auxiliary box
6. Power door lock switches
(with power windows)
7. Power window switches
8. Glove box
9. Automatic transmission selector lever or
manual transmission gear shift lever
10. Parking brake lever
11. Power door lock switch
(without power windows)
12. Hood lock release lever
13. Window lock switch
04 01.06
SU11001a

WWW.MANUALS.WS
WWW.MANUALS.WS
3
2004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
1. Headlight and turn signal switches
2. Wiper and washer switches
3. Rear window defogger switch
4. Emergency flasher switch
5. Clock
6. Air conditioning controls
7. Security indicator light/Front passen-
ger’s seat belt reminder light
8. Car audio
9. Cigarette lighter/Power outlet
10. Ashtray/Coin box
11. Ignition switch
12. Tilt steering lock release lever
13. Power rear view mirror control switches
14. Instrument panel light control knob
04 01.06
SU11002a

WWW.MANUALS.WS
WWW.MANUALS.WS
42004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
SU11015
1. Service reminder indicators and
indicator lights
2. Speedometer
3. Fuel gauge
4. Odometer and two trip meters
5. Trip meter reset knob
04 01.06
Instrument cluster overview
Type A

WWW.MANUALS.WS
WWW.MANUALS.WS
5
2004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
SU11014
1. Service reminder indicators and
indicator lights
2. Speedometer
3. Fuel gauge
4. Odometer and two trip meters
5. Trip meter reset knob
04 01.06
Type B

WWW.MANUALS.WS
WWW.MANUALS.WS
62004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
SU11009a
1. Service reminder indicators and
indicator lights
2. Speedometer
3. Extinction canceling button
4. Odometer and two trip meters
5. Fuel gauge
6. Trip meter reset button
7. Tachometer
04 01.06
Type C

WWW.MANUALS.WS
WWW.MANUALS.WS
7
2004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
Indicator symbols on theinstrument panel
or Brake system warning light∗1
Driver’s seat belt reminder light∗1
Discharge warning light∗1
Malfunction indicator lamp∗1
Low engine oil pressure warning light∗1
Anti-lock brake system warning light∗1
SRS warning light∗1
Low windshield washer fluid level warning light∗1
Low fuel level warning light∗1(type A)
Turn signal indicator lights
Headlight high beam indicator light
Overdrive- off indicator light
Low engine coolant temperature indicator light
(in blue)∗2
High engine coolant temperature warning light
(in red)∗1
Front passenger’s seat belt reminder light∗1
Open door warning light∗1
or
Low fuel level indicator light∗1(type B)
∗1: For details, see “Service reminder indicators and warning
buzzers” on page 92 in Section 1-6.
∗2: For details, see “Engine coolant temperature indicator and
warning light” on page 89 in Section 1-6.
04 01.06

WWW.MANUALS.WS
WWW.MANUALS.WS
82004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
04 01.06

WWW.MANUALS.WS
WWW.MANUALS.WS
9
2004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Keys and Doors
Keys 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless remote control 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side doors 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power windows 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft deterrent system 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel tank cap 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
04 01.06
SECTION 1 - 2

WWW.MANUALS.WS
WWW.MANUALS.WS
10 2004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
Keys (type A)
SU12062
These keys work in every lock.
1. Master keys—These keys work in ev-
ery lock.
Since the doors and trunk lid can be
locked without a key, you should always
carry a spare key in case you accidentally
lock your keys inside the vehicle.
Keys (type B)
SU12063
Your vehicle is supplied with two kinds
of key.
1. Master keys—These keys work in ev-
ery lock.
2. Sub key—This key will not work in the
trunk.
To protect items locked in the trunk when
using valet parking, leave the sub key
with the attendant.
Since the doors and trunk lid can be
locked without a key, you should always
carry a spare master key in case you
accidentally lock your keys inside the ve-
hicle.
SU12002
KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend writing down the key num-
ber and storing it in a safe place.
04 01.06
