Toyota Land Cruiser 2016 User manual

For your safety and comfort,
read carefully and keep in the vehicle.
Quick index
•If a service reminder indicator or warning buzzer comes on.......................... 93
•If your vehicle will not start............................................................................. 194
•If your engine stalls while driving ................................................................... 197
•If your vehicle overheats................................................................................ 198
•If you have a flat tire....................................................................................... 200
•If your vehicle needs to be towed................................................................... 212
•Tips for driving during break–in period........................................................... 165
•How to start the engine.................................................................................. 180
•Pre–trip safety check...................................................................................... 181
•Complete index.............................................................................................. 269
Gas station information
Fuel type:
Diesel fuel with cetane number 50 (cetane index 45) or higher
See page 166 for detailed information.
Fuel tank capacity: See page 166.
Engine oil:
ACEA C2
See page 236 for detailed information.
Tire information: See pages 240 through 244.
Tire inflation pressure: See page 265.
Publication No. OM60N74E
Part No. 01999-60N74
Printed in Japan 01–1608–00
ランドクルーザー (豪州E)I
ミQ–1
DIC87 Black L/C70_60N74E
Not for Reproduction

L/C70_AE
i
Foreword
Welcome to the growing group of value−conscious people who drive Toyotas. We
are proud of the advanced engineering and quality construction of each vehicle we
build.
This Owner’s Manual explains the operation of your new Toyota. Please read
it thoroughly and have all the occupants follow the instructions carefully.
Doing so will help you enjoy many years of safe and trouble−free motoring.
For important information about this manual and your Toyota, read the follow-
ing pages carefully.
When it comes to service, remember that your Toyota dealer knows your vehicle
very well and is interested in your complete satisfaction. Your Toyota dealer will
provide quality maintenance and any other assistance you may require.
Please leave this Owner’s Manual in this vehicle at the time of resale. The next
owner will need this information also.
All information and specifications in this manual are current at the time of printing.
However, because of Toyota’s policy of continual product improvement, we reserve
the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
ã2016 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in
part, without the written permission of Toyota Motor Corporation.
Not for Reproduction

L/C70_AE
ii
Important information about this manual
Safety and vehicle damage warnings
Throughout this manual, you will see safety and vehicle dam-
age warnings. You must follow these warnings carefully to
avoid possible injury or damage.
The types of warnings, what they look like, and how they are
used in this manual are explained as follows:
CAUTION
This is a warning against anything which may cause
injury to people if the warning is ignored. You are
informed about what you must or must not do in
order to reduce the risk of injury to yourself and
others.
NOTICE
This is a warning against anything which may cause
damage to the vehicle or its equipment if the warning
is ignored. You are informed about what you must or
must not do in order to avoid or reduce the risk of
damage to your vehicle and its equipment.
Safety symbol
When you see the safety symbol
shown above, it means: “Do not...”;
“Do not do this”; or “Do not let this
happen”.
Not for Reproduction

L/C70_AE
iii
Important information about your Toyota
Accessories, spare parts and
modification of your Toyota
A wide variety of non−genuine spare parts and accessories
for Toyota vehicles are currently available in the market.
Using these spare parts and accessories which are not
genuine Toyota products may adversely affect the safety of
your vehicle, even though these parts may be approved by
certain authorities in your country. Toyota therefore cannot
accept any liability or guarantee spare parts and accesso-
ries which are not Toyota products, nor for replacement or
installation involving such parts.
This vehicle should not be modified with non−genuine
Toyota products. Modification with non−genuine Toyota
products could affect its performance, safety or durability,
and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the
modification may not be covered under warranty.
Installation of an
RF−transmitter system
As the installation of an RF−transmitter system in your ve-
hicle could affect electronic systems such as electronically
controlled fuel injection pump system, electronic engine
control system, cruise control system, anti−lock brake sys-
tem, SRS airbag system and seat belt pretensioner sys-
tem, be sure to check with your Toyota dealer for precau-
tionary measures or special instructions regarding installa-
tion of an RF−transmitter system.
Further information regarding frequency bands, power lev-
els, antenna positions and installation provisions for the
installation of RF−transmitters, is available on request at
your Toyota dealer.
Maintenance schedule
Please refer to the separate “Warranty and Service
Booklet”.
Not for Reproduction

L/C70_AE
iv
On−pavement and off−road
driving tips
This vehicle belongs to the utility vehicle class. Utility
vehicles have a significantly higher rollover rate than other
types of vehicles. This vehicle will handle and maneuver
differently from an ordinary passenger car because it is
designed for off−road use also. In addition, this vehicle
has a higher ground clearance and center of gravity than
that of an ordinary passenger car. This vehicle design
feature causes this type of vehicle to be more likely to
rollover. Failure to operate this vehicle correctly may result
in loss of control, accidents or vehicle rollover causing
death or serious injury. Be sure to read “Off−road vehicle
precautions” in Section 2 and “Off−road driving
precautions” in Section 3.
Event data recorder
This vehicle is equipped with an event data recorder
(EDR). The main purpose of an EDR is to record, in
certain crash or near crash−like situations, such as an
airbag deployment or hitting a road obstacle, data that will
assist in understanding how a vehicle’s systems
performed. The EDR is designed to record data related to
vehicle dynamics and safety systems for a short period of
time, typically 30 seconds or less. However, data may not
be recorded depending on the severity and type of a
crash.
The EDR in this vehicle is designed to record such data
as:
SHow various systems in your vehicle were operating;
SHow far (if at all) the driver was depressing the
accelerator and/or brake pedal; and,
SHow fast the vehicle was traveling.
These data can help provide a better understanding of the
circumstances in which crashes and injuries occur.
Not for Reproduction

L/C70_AE
v
NOTE: EDR data are recorded by your vehicle only if a
non−trivial crash situation occurs; no data are recorded by
the EDR under normal driving conditions and no personal
data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law
enforcement, could combine the EDR data with the type of
personally identifying data routinely acquired during a
crash investigation.
To read data recorded by an EDR, special equipment is
required, and access to the vehicle or the EDR is needed.
In addition to the vehicle manufacturer, other parties, such
as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or
the EDR.
DDisclosure of the EDR data
Toyota will not disclose the data recorded in an EDR to a
third party except when:
SAn agreement from the vehicle’s owner (or the lessee for
a leased vehicle) is obtained
SIn response to an official request by the police, a court of
law or a government agency
SFor use by Toyota in a lawsuit
However, if necessary, Toyota may:
SUse the data for research on vehicle safety performance
SDisclose the data to a third party for research purposes
without disclosing information about the specific vehicle
or vehicle owner
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your
Toyota contain explosive chemicals. If the vehicle is
scrapped with the airbags and seat belt pretensioners left
as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt
pretensioner removed and disposed of by a qualified ser-
vice shop or by your Toyota dealer before you scrap your
vehicle.
Not for Reproduction

L/C70_AE
vi
Not for Reproduction

L/C70_AE
vii
1 OPERATION OF INSTRUMENTS AND CONTROLS Page
1 Overview of instruments and controls 1............................
2 Keys and Doors 9.............................................
3 Seats, Seat belts, Steering wheel and Mirrors 31.....................
4 Lights and Wipers 79..........................................
5 Gauges, Meters and Service reminder indicators 87..................
6 Engine (ignition) switch, Transmission and Parking brake 101...........
7 Audio system 119.............................................
8 Air conditioning system 145....................................
9 Other equipment 155..........................................
2 INFORMATION BEFORE DRIVING YOUR TOYOTA 163...........
3 STARTING AND DRIVING 179...................................
4 IN CASE OF AN EMERGENCY 193..............................
5 CORROSION PREVENTION AND APPEARANCE CARE 217......
6 MAINTENANCE REQUIREMENTS 225...........................
7DO−IT−YOURSELF MAINTENANCE
1 Introduction 229...............................................
2 Engine and Chassis 235........................................
3 Electrical components 245......................................
8 SPECIFICATIONS 259..........................................
9 INDEX 269.....................................................
Table of contents
Not for Reproduction

L/C70_AE
viii
Model code
Check the model code to see what type of model your vehicle is.
The model code appears on the manufacturer’s label with the heading “MODEL”.
See “Your Toyota’s identification” in Section 2 for the manufacturer’s label location.
VDJ76 −R
Body type
R: Van
D: Pick−up (Double−Cab)
T: P i c k −up (Single−Cab)
Wheel base
76: Semi long wheelbase
78: Long wheelbase
79: Super long wheelbase
Not for Reproduction

L/C70_AE
1
OPERATION OF INSTRUMENTS AND
CONTROLS
Overview of instruments and controls
Instrument panel overview 2....................................
Instrument cluster overview 5...................................
Indicator symbols on the instrument panel 6......................
Finish
SECTION 1−1
Not for Reproduction

L/C70_AE
2
1. Sun visors*
2. Center vents
3. Instrument cluster
4. Side vents
5. Side defroster outlets
6. Power door lock switch
7. Power window switches
8. Window lock switch
9. Hood lock release lever
10. Fuel filler door opener
*: NEVER use a rearward facing child re-
straint on a seat protected by an ACTIVE
AIRBAG in front of it, DEATH or SE-
RIOUS INJURY to the CHILD can occur.
(See “Child restraint” in Section 1−3.)
Finish
Instrument panel overview
Not for Reproduction

L/C70_AE
3
11. Lower vent
12. Four−wheel drive control lever
13. Parking brake lever
14. Rear console box
15. Front console box
16. Manual transmission gear shift lever
17. Glove box
Finish
Not for Reproduction

L/C70_AE
4
1. Air conditioning controls
2. Emergency flasher switch
3. Audio system
4. Clock
5. Wiper and washer switches
6. Engine switch
7. Headlight and turn signal switches
8. Idle up switch
9. Power door lock switch
10. DPF (Diesel Particulate Filter) system
switch
11. Cruise control switch
12. Tilt and telescopic steering lock release
lever
13. Front and rear differential lock switch
14. Rear window defogger switch
15. VSC OFF switch
16. Sub fuel tank switch
17. Power antenna switch
18. Cigarette lighter
19. Ashtray
Finish
Not for Reproduction

L/C70_AE
5
1. Tachometer
2. Service reminder indicators and
indicator lights
3. Oil pressure gauge or sub fuel gauge
4. Fuel gauge
5. Speedometer
6. Odometer, two trip meters and meter
light control knob
7. Odometer, two trip meters, DPF system
display and meter light control display
8. Voltmeter
9. Engine coolant temperature gauge
Finish
Instrument cluster overview
Not for Reproduction

L/C70_AE
6
Brake system warning light*1
Charging system warning light*1
Low engine oil level warning light*1
Low fuel level warning light*1
Fuel system warning light*1
DPF (Diesel Particulate Filter) system warning
light*1
Headlight high beam indicator light
Turn signal indicator lights
Malfunction indicator lamp*1
Low engine oil pressure warning light*1
Sub fuel tank indicator light*2 Open door warning light*1
Front fog light indicator light
Seat belt reminder light*1
SRS warning light*1
Engine immobilizer system indicator light
Anti−lock brake system warning light*1
Go to service warning light*1
Finish
Indicator symbols on the instrument panel
Not for Reproduction

L/C70_AE
7
Engine preheating indicator light
Front differential lock indicator light
*1: For details, see “Service reminder indicators and warning
buzzers” in Section 1−5.
*2: If this light flashes, see “Fuel gauge” in Section 1−5.
*3: If this light comes on in yellow, see ”Cruise control” in Sec-
tion 1−7.
Rear differential lock indicator light
Four−wheel drive indicator light
Parking brake indicator light
Slip indicator light
VSC OFF indicator light
“TRC OFF” indicator light
Cruise control indicator light*3
Cruise control “SET” indicator
Finish
Not for Reproduction

L/C70_AE
8
Finish
Not for Reproduction

L/C70_AE
9
OPERATION OF INSTRUMENTS AND
CONTROLS
Keys and Doors
Keys 10.......................................................
Engine immobilizer system 12...................................
Wireless remote control 13.....................................
Side doors 17..................................................
Power windows 19.............................................
Door vent windows 23..........................................
Side windows 23...............................................
Rear window 24................................................
Back door 24..................................................
Hood 26.......................................................
Fuel tank cap 27...............................................
Finish
SECTION 1−2
Not for Reproduction

L/C70_AE
10
Your vehicle is supplied with two kinds
of keys.
1. Master keys (black)—These keys work
in every lock. Your Toyota dealer will
need one of them to make a new key
with a built−in transponder chip.
Since the side doors and back door
can be locked without a key, you
should always carry a spare master
key in case you accidentally lock your
keys inside the vehicle.
2. Sub key (gray)—This key will not work
in the glove box.
To protect things locked in the glove
box when you have your vehicle
parked, leave the sub key with the at-
tendant.
A transponder chip for engine immobilizer
system has been placed in the head of
the master and sub keys. These chips are
needed to enable the system to function
correctly, so be careful not to lose these
keys. If you make your own duplicate key,
you will not be able to cancel the system
or start the engine.
NOTICE
When using a key containing a trans-
ponder chip, observe the following
precautions:
zWhen starting the engine, do not
use the key with a key ring resting
on the key grip and do not press
the key ring against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts.
Finish
Keys
Not for Reproduction

L/C70_AE
11
zWhen starting the engine, do not
use the key with other transponder
keys around (including keys of oth-
er vehicles) and do not press other
key plates against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts. If
this happens, remove the key once
and then insert it again after remov-
ing other transponder keys (includ-
ing keys of other vehicles) from the
ring or while gripping or covering
them with your hand to start the
engine.
zDo not bend the key grip.
zDo not cover the key grip with any
material that cuts off electromagnet-
ic waves.
zDo not knock the key hard against
other objects.
zDo not leave the key exposed to
high temperatures for a long period,
such as on the dashboard and hood
under direct sunlight.
zDo not put the key in water or
wash it in an ultrasonic washer.
zDo not use the key with electromag-
netic materials.
Finish
Not for Reproduction
