TP-Link Archer-C20 User manual

www.pars-ecotech.com
1
Instruction Manual for installing
TP-link Archer-C20 WIFI Router
to FUN4FOUR Game Table

www.pars-ecotech.com
2
1-Installing:
Turn off the table with disconnecting the electricity cable from plug
and open the main computer door with yellow key.
First put the white 2 Outlet Adapter Plug to the black plug inside. Put
again the plug in one outlet. Then put the adapter of router in
another one.

www.pars-ecotech.com
3
Then put router at the left side of main computer.
Same as picture:

www.pars-ecotech.com
4
Then connect the LAN cable in to the one of 4 LAN ports of the
router and other head to the LAN port of Computer.
Turn on the router with power button. Shift up the computer. Be
careful about cables. Put them in a right place.

www.pars-ecotech.com
5
2- Connecting:
Turn on the table. Wait until complete boot. Then push the test
button.
In the main menu tap on the ChampionsNet.

www.pars-ecotech.com
6

www.pars-ecotech.com
7

www.pars-ecotech.com
8
Choose Router:
Username: admin
Password: admin

www.pars-ecotech.com
9
Username: admin
Password: admin

www.pars-ecotech.com
10
Go to quick setup:
Next

www.pars-ecotech.com
11
Very Important!!!!!
Choose Operation Mode: Range Extender
And then Next

www.pars-ecotech.com
12
Find the WIFI name (SSID) of the bar/restaurant
Tap “Connect” in front of the wifi name and then next

www.pars-ecotech.com
13
Now, write the WIFI password of the bar/restaurant
And then next

www.pars-ecotech.com
14
Just check LAN settings, they should be same as picture:
And then next

www.pars-ecotech.com
15
Now the device needs to reboot to work. Tap the finish button.
Wait for finish rebooting the router.

www.pars-ecotech.com
16
Very Important!!!!!!
Now, after setup the router, for entering inside of menu, you need
to write this address in the address bar on the top of display:
tplinkwifi.net
And then press ENTER on the keyboard

www.pars-ecotech.com
17
Username: admin
Password: admin
Now on the main page you can see all settings. Check that
operation mode should be range extender and wireless radio
should be enabled. You can see the WIFI name also.

www.pars-ecotech.com
18

www.pars-ecotech.com
19
Go to “NETWORK” and Select “Wireless 2.4 Ghz”
Clear the box of: “Enable SSID Broadcast”
And then “SAVE”

www.pars-ecotech.com
20
