TP Toys Active Fun TP349 Quick guide

IMPORTANT
These instructions must be followed for safe assembly and use.
Please retain for future reference.
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36
MONTHS UNTIL FULLY ASSEMBLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE. ADULT SUPERVISION IS REQUIRED.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 18 MONTHS TO 6 YEARS.
MAXIMUM COMBINED USER WEIGHT 50KGS
WARNING!
INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE
PLEASE RETAIN FOR FUTURE REFERENCE.
TP349
TP Summer Lodge
Assembly
Build
It is essential that this
product has a
application of a suitable
child/environmentally
friendly wood treatment
before being assembled.
IMPORTANT
WARNING
Age
18 mths+ - 6 yrs
Single user weight - 30kgs
Maximum combined
user weight - 0kgs
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 1

GB
INSTRUCTIONS FOR ASSEMBLY, MAINTENANCE AND USE OF TP TOYS
Please read carefully and keep all enclosed information or future reference.
1. ASSEMBLY AND SAFETY INFORMATION
This TP product must be treated and assembled before use by an adult/adults.
This product is made from natural European pinewood that is untreated. Therefore, before you assemble the product, it
is essential to treat both sides of each part with an environmentally friendly/child friendly preservative. Please follow
the instructions provided by the manufacturer of the treatment you select.
Wood is a natural product so it will have knots splits and and imperfections. This is to be anticipated and does not indicate
the product is faulty. Wood will also change over time with changes in the weather and atmospheric conditions. Splits will
open up and close again. It may warp and twist slightly. Again this is to be expected and does not affect the performance of
the product.
The TP product must be erected exactly in accordance with the assembly instructions. Enlisting the aid of a helper will make
assembly easier. In order to ensure the correct tensions and to ease assembly it is important to assemble the product hand
tight to begin with. Only when complete should the fastenings be fully tightened and checked. This pack may contain small
parts and is not suitable for children under 36 months until fully assembled. We recommend that you place small parts on a
tray or something similar to prevent the frustration and disappointment of mislaying them. Please take care during
assembly as the manufacturing process can sometimes result in the occasional sharp edge and small pieces of waste
metalwork. Should there be any missing parts the toy must not be used until replacement parts have been fitted - contact
the TP Customer Services: Email: [email protected]
2. SITING
Under no circumstances should this TP product be positioned on hard surface such as concrete or asphalt unless the
ground under the toy plus the recommended freespace area is covered with a safety surface (please refer to diagram on
page 15). Examples of suitable surfaces are grass sand or a play surface intended for this use. TP toys should be sited on
level ground.
3. USAGE
The toy is designed and made for family outdoor domestic use only. Misuse can result in injury to the child or damage to the
product.
4. SUPERVISION
Children should always be supervised while they are playing on TP toys and should be instructed not to use the toy in an
inappropriate or hazardous manner. We recommend that they do not wear loose-fitting clothing or jewellery that may catch
or snag during play. Children should not wear cycle helmets while playing on TP toys.
. WEATHER CONDITIONS
Special care should be taken as weather conditions change. In particular outdoor toys can become slippery in wet weather
and tongues and lips can stick to metalwork at subzero temperatures. In warmer and sunnier weather parts can become
hot and the temperature should be regularly checked during play especially metal parts and slides. If there is any doubt
over safety then the toys should not be used. We recommend that you check the product in relationship to the orientation of
the activity toy (e.g. swings) in relation to its exposure to the sun. Product may become hot!
6. MAINTENANCE
With all toys it is vital that the equipment is checked regularly and often by an adult. The complete toy should be checked at
least once a month and particular attention should be paid to connections and fastenings. If any parts exhibit signs of wear
and tear they may need to be replaced. Check all nuts and bolts and screws for tightness and tighten when required.
Failure to do this may result in the product malfunctioning and causing injury. Children must not be allowed to use the toy
until properly installed and checked.
Please protect your product with a annual application of environmentally friendly/child friendly treatment or as
recommended in the manufacturer’s instructions.
7. FIRE RISKS AND DISPOSAL
Do not place this product near a fire. When it becomes necessary to dispose of your equipment remove all bolts/screws
and disassemble. Store out of the reach of children until it can be properly disposed of.
These instructions are issued in the interest of child safety and we do ask you to follow our advice.
2
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 2

Instruction Guide
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Read Instructions Before Starting Hidden Lines
Sort Fixings
Sort Parts
Need Help? Visit www.tptoys.com TP Customer Services: (English Speaking)
3
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 3

Contents - Please check
Screwdriver
Tools - You will need:
10 20 30 40 50 60 70 80 90 100 110 120 130mm
Pack 1
Subpack - SP4023
3.5 x 50mm Woodscrew x16
FA9705
3.5 x 40mm Woodscrew x44
FA4522
4 x 70mm Woodscrew x1
FA4503
Floor Panel x1
WP1007
Front Panel
inc Door x1
WP1011
Side Panel x2
WP1004
Back Panel x1
WP1003
Gable End x2
WP1002
Balcony Support
upright x2
MW1060
Ridge Support x1
MW2113
Paint Brush
Balcony Panel x1
WP1006
Door batton x2
MW2116
3.5 x 30mm Woodscrew x1
FA4513
Door Knob x1
DK2117
Front Balcony x1
WP1010
Roof Panel x2
WP1000 & WP1001
Ridge Strip x2
MW2114
PM1007 x1 MW2512
Chimney Block
x1
4
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 4

WARNING - All fixings
Do not use Power tools
Excessive force can
crack/split this product.
Hand tighten only
IMPORTANT - Assembly Tip
1
Stage
It is essential that this product has a application of a suitable
child/environmentally friendly wood treatment before being assembled.
Treat all panels - on all sides.
IMPORTANT WARNING
Wood Treatment
Not Supplied
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 5

2
Stage
WP1003
3.5 x 40mm
ASSEMBLY
TIP
3.5 x 40mm Woodscrew x2
FA4522
WARNING - All fixings
Do not use
Power tools
Excessive force can
crack/split
this product.
Hand tighten only
WP1007
Floor Panel x1
WP1007
Back Panel x1
WP1003
WP1007
WP1003
6
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 6

3
Stage
Side Panel x1
WP1004
3.5 x 40mm
3.5 x 40mm
ASSEMBLY
TIP
3.5 x 40mm Woodscrew x7
FA4522
WP1004
WARNING - All fixings
Do not use
Power tools
Excessive force can
crack/split
this product.
Hand tighten only
7
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 7

4
Stage
Side Panel x1
WP1004
ASSEMBLY
TIP
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm Woodscrew x7
FA4522
WP1004
WARNING - All fixings
Do not use
Power tools
Excessive force
can crack/split
this product
8
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 8

Stage
Door Baton x2
MW2116
3.5 x 30mm Woodscrew x6
FA4513
Front Panel inc Door x1
WP1011
3.5 x 30mm
3.5 x 30mm
9
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 9

6
Stage Front Panel inc Door x1
WP1011
ASSEMBLY TIP
Do not remove
back panel
3.5 x 40mm Woodscrew x10
FA4522
3.5 x 40mm
WP1011
WARNING - All fixings
Do not use
Power tools
Excessive force
can crack/split
this product
3.5 x 50mm Woodscrew x1
FA9705
Door Knob x1
DK2117
3.5 x 50mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
10
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 10

7
Stage
Gable End x2
WP1002
3.5 x 40mm Woodscrew x8
FA4522
3.5 x 40mm
3.5 x 40mm
WP1002
WP1002
40mm
40mm
40mm
x4
ASSEMBLY
TIP
11
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 11

8
Stage
Roof Panel x1
WP1000
3.5 x 40mm Woodscrew x4
FA4522
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
WP1000
12
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 12

3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
3.5 x 40mm
WP1001
3.5 x 40mm
9
Stage
Ridge Support x1
MW2113
3.5 x 40mm
3.5 x 40mm Woodscrew x1
FA4522
10
Stage
3.5 x 40mm
3.5 x 40mm
Roof Panel x1
WP1001
3.5 x 40mm Woodscrew x
FA4522
13
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:31 Page 13

4 x 70mm Woodscrew x1
FA4503
balcony Support Upright x2
MW1060
3.5 x 50mm
4 x 70mm
ASSEMBLY TIP
Screw from
inside house
into balcony
3.5 x 50mm
11
Stage
Balcony Panel x1
WP1006
3.5 x 50mm Woodscrew x2
FA9705
3.5 x 50mm
3.5 x 50mm
3.5 x 50mm Woodscrew x6
FA9705
3.5 x 50mm
3.5
x 50mm
14
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:32 Page 14

12
Stage
Ridge Strip x2
MW2114
3.5 x 30mm
Recommended Free Space:
The Safe Play Area refers to the zone extending 200cm
(2 metres) beyond the toy on all sides and 700cm
(7 metres) above the toy. The Safe Play Area must be
free from all structures landscaping trees and
branches rocks wires sprinkler heads and other
similar obstacles to safe play. Children can be seriously
injured running or colliding into such obstacles.
Freespace/Safe Play Diagram
2m
2m
2m
2m
13
Stage
3.5 x 30mm Woodscrew x9
FA4513
3.5 x 50mm
3.5 x 50mm
3.5 x 50mm
Front Balcony x1
WP1010
3.5 x 50mm Woodscrew x7
FA9705
PM1007 x1
MW2512
Chimney Block
x1
ASSEMBLY TIP
Mark
position of
hole to be
drilled 3.5 x 30mm
ASSEMBLY TIP
Enlist the
help of an
helper.
Screw from
inside house.
ASSEMBLY TIP
Drill 3mm
hole
through
roof.
1
TP Summer Lodge
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:32 Page 15

TP Part No: IN3338
Issue B 10 15
Designed in the UK by Robovision Ltd t/as TP Toys
Unit 11 Enterprise Way Flitwick Bedfordshire MK45 5BX.
www.tptoys.com
Your TP Guarantee Number/Product Batch No is
YOUR GUARANTEE
lThis product is guaranteed for 1 year provided it has been assembled and maintained in accordance with these
instructions has been used by children of the appropriate age and weight guidelines have been strictly adhered to.
If their requirements have not been adhered to the guarantee will be invalidated. Please refer to page 2 of this
instruction for full information in relation to this requirement.
lAll guarantees are conditional upon family domestic use of the product.
lAll guarantees apply to the original purchaser only; they are strictly not transferable.
lAll guarantees commence on the date of purchase.
lAll guarantees require the purchaser not to have modified the product.
lOnly fittings and accessories supplied by TP should be used with TP products or your guarantee may be invalidated.
lLiability is limited to the replacement of the affected part only which we will repair or replace at our discretion.
TP is not liable for any cost incurred by the customer to apply treatment to the product.
lGuarantees require the production of the original purchase receipt and of the batch number which appears on the
instruction provided with the product. This instruction sheet should be retained by the purchaser for this reason and
to provide important maintenance information (see above).
lIf a guarantee claim is valid and a replacement part is supplied the replacement part assumes the warranty period
of the original purchase. For example if a product is purchased on 4 January 2012 and has a 1 year guarantee but a
replacement part is supplied under warranty 9 months later in September 2012 the warranty of the product
including the replacement part supplied in September 2012 will expire 1 year from the original purchase ie 3
January 2013.
lVandalism abuse incorrect installation inappropriate usage minor settlement weather related damage and acts
of God are excluded from the guarantee.
lGuarantees apply to purchases made in the British Isles.
lPurchases of TP products outside the British Isles must be made from an approved TP retailer who will provide local
resolution of any qualifying warranty claims. All claims will require the production of a valid purchase receipt.
lTo enable us to manage your warranty claim as efficiently as possible please register your purchase
at www.tptoys.com/productregistration.
TP349 Summe Lodge IN3340 Issue B 10 15.qxp_TP349 Summe Lodge IN3340 Issue B 10 15 21/10/2015 12:32 Page 16
