Traeger RANGER TFT18KLD User manual

ASSEMBLY
GUIDE
A MAJOR CAUSE OF FIRES IS FAILURE
TO MAINTAIN REQUIRED CLEARANCES
(AIR SPACES) BETWEEN COMBUSTIBLE
MATERIALS. IT IS OF UTMOST
IMPORTANCE THAT THIS PRODUCT
BE INSTALLED ONLY IN ACCORDANCE
WITH THESE INSTRUCTIONS.
Wood Fired Grills – Ranger
Please read this entire manual before installation and use of this pellet fuel-burning appliance.
Failure to follow these instructions could result in property damage, bodily injury, or even death.
Contact your local building or fire ocials about restrictions and installation inspection requirements
in your area.
For English-only assistance
with assembly, installation, parts,
and customer service, contact
Traeger's VIP-365 Customer Service.
Phone: 1-800-TRAEGER
Email: [email protected]
Mail: Traeger Pellet Grills LLC
1215 E. Wilmington Ave.
Salt Lake City, UT 84106
traegergrills.com
WARNING!
Many parts of the grill will become very hot during operation. Care
must be taken to avoid burns, both during operation and afterwards,
while the grill is still hot.
• Never leave the grill unattended when young children are present.
• Never move the grill when it is operating.
• Let the grill cool completely before moving or attempting to
transport.
• Grill is very heavy. Always lift grill with TWO people.
IMPORTANT, RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY
TFT18KLD
08/2018
Traeger Pellet Grills LLC
1215 E. Wilmington Ave
Salt Lake City, UT 84106
traegergrills.com
4928 Ranger Assemblyv05.indd 1 8/22/18 3:36 PM

READ ALL INSTRUCTIONS BEFORE INSTALLING
AND USING THE APPLIANCE
PARTS LIST
5
6
7
8
1
2
4
BLISTER PACK PARTS
NEEDED
C
D
B
A
PART DESCRIPTION
1Grill Lid
2Grill Body
3Feet with Caps
4Lid Handle
5Cast-Iron Griddle
6Grill Grate
7Grease Drip Tray
8Grease Bucket
PART DESCRIPTION
ABolts: 1/4-20 x 3⁄8" (2 pcs.)
BWashers: 1/4" (2 pcs.)
CLock Washers: 1/4" (2 pcs.)
DWrench
EPhillips Head Screws (4 pcs.)
FFeet (4 pcs.)
GCaps (4 pcs.)
2
In this step: 4
Ax 2 Bx 2 Cx 2 D
ATTACH LID HANDLE
1
In this step: 3
Ex 4 Fx 4 Gx 4
INSTALL FEET
E
F
G
3
3
4
In this step: 7
8
In this step: 6
PLACE GREASE DRIP TRAY AND BUCKET
INSTALL GRILL GRATE
NOTE: Be sure the grease drain spout on the grease drip
tray extends through the opening in the back of the grill.
IMPORTANT: Always be sure to position the grease drain
bucket under the spout during use!
Traeger’ing is more fun with friends! (No, really, you will need two people to lif the grill.)
NOTE: You should assemble grill on a clean, flat
surface, as you will need to lay it on its back during
assembly.
You are ready to season your grill and get Traeger’ing!
Refer to your Owner’s Manual for operation instructions.
4928 Ranger Assemblyv05.indd 2 8/22/18 3:36 PM
