Traeger Ironwood Series User manual

ATTACH SIDE SHELF AND GRILL HANDLE
PLACE GRILL GRATES AND CONNECT CORD CONNECT TO WIFI
PRIME YOUR GRILL
PLACE HEAT SHIELD AND DRIP TRAY
5 6
6
3
4
This will require TWO people.
2
1
1
You are ready to season your grill and get Traeger’ing!
Once you’re up and running, make sure to smoke it forward by posting photos of
your cooks using #TraegerGrills.
In this step: 8In this step: 9
1
3
2
2
Ex 4 Gx 4 Hx 2 Ix 2
In this step: 12 13 14 In this step: 7
In this step: 10 In this step: 11
ASSEMBLY
GUIDE
A MAJOR CAUSE OF FIRES IS FAILURE
TO MAINTAIN REQUIRED CLEARANCES
(AIR SPACES) TO COMBUSTIBLE
MATERIALS. IT IS OF UTMOST
IMPORTANCE THAT THIS PRODUCT
BE INSTALLED ONLY IN ACCORDANCE
WITH THESE INSTRUCTIONS.
Wood Fired Grills – Ironwood
Please read this entire manual before installation and use of this pellet
fuel-burning appliance. Failure to follow these instructions could result in property
damage, bodily injury, or even death. Contact your local building or re ofcials
about restrictions and installation inspection requirements in your area.
For English-only assistance
with assembly, installation, parts,
and customer service, contact
Traeger's VIP-365 Customer Service.
Phone: 1-800-TRAEGER
Email: [email protected]
Mail: Traeger Pellet Grills LLC
1215 E. Wilmington Ave.
Salt Lake City, UT 84106
traegergrills.com
WARNING!
Many parts of the grill will become very hot during
operation. Care must be taken to avoid burns, both during
operation and afterwards while the grill is still hot.
• Never leave the grill unattended when young children
are present.
• Never move the grill when it is operating.
• Let the grill cool thoroughly before moving or attempting
to transport.
• Grill is very heavy. Always lift grill with TWO people.
IMPORTANT, RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY
TFB89SLC
Refer to the Quick Start Guide
to connect your grill to WiFi.
NOTE: The Ironwood grill
utilizes a hot rod with a
deeper contact point. It should
extend approximately 1.5"
(3.8 cm) into the repot.
Ensure the cutout is placed
toward the back of the grill.
See the Owner's Manual for
instructions on how to prime
and season your grill.
TFB89SLC Ironwood US Assembly Final.indd 1 12/19/17 3:01 PM

2INSTALL LEGS AND BRACES
GRILL IS HEAVY. USE TWO PEOPLE TO LIFT.
NOTE: When fastening legs to grill body, fasteners assemble in
this order: ABLeg BCD
4 5
1 2
1
6
Traeger’ing is more fun with friends! (No, really, you will need two people to lift the grill.)
NOTE: You should assemble grill on a clean, at
surface, as you will need to lay it on its back at
times during assembly.
In this step: 2In this step: 3
In this step: 5
In this step: 4
Ax 2 Bx 4 Cx 2 Dx 2 Ax 2 Bx 4 Cx 2 Dx 2
Ax 2 Bx 4 Cx 2 Dx 2
Ax 2 Bx 4 Cx 2 Dx 2
READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE GRILL
PARTS LIST BLISTERPACK PARTS NEEDED
Hex Key (1 pc)
Wrench (2 pcs)
BWasher: 5/16" (16 pcs)
HBolt: 1/4-20x1.25 (2 pcs)
ABolt: 5/16-18 socket head (8 pcs)
GStainless Steel Washer:
5/16" (4 pcs)
GWasher: 1/4" (2 pcs)
FSocket-Head Stainless Steel Screw:
1/4-20x0.50 (4 pcs)
DHex Nut: 5/16-18 (8 pcs)
11
2
5
12
10
14
15
4
3
8
7
1
13
40.00" 12.00"
12.00"
WARNING!
• When operating this grill under overhead combustibles,
a MINIMUM of 40 inches is required.
• When operating this grill, maintain a MINIMUM distance
of 12 inches from the Grill to combustibles.
IMPORTANT!
• The grill is very heavy. Always lift the grill with TWO people.
3
REMOVE GRILL PARTS AND PACKAGING
3
EBolt: 1/4-20x0.5 (8 pcs)
CSpring Washer: 5/16" (8 pcs)
12
GRAB THE 6-PACK, GET THE TOOLS, CUE THE RADIO —
IT’S ALMOST TRAEGER’ING TIME.
Screwdriver (1 pc)
This will require TWO people.
NOTE: We recommend you use the
foam packing to prop up the grill to
make attaching the legs easier.
In this step: 6+ Ex 4 In this step: 6+ Ex 4
6
6
9
In this step: 1
Utility Knife
OTHER TOOLS NEEDED
(NOT INCLUDED)
