TrailBlazer Attachments TB-ONE Guide

Read and understand the manual. This manual provides information
and procedures to safely operate and maintain the Offset Mower.
OFFSET MOWER
OPERATION AND PARTS MANUAL
trailblazer
at ta chments


Offset Mowers 3 Trailblazer Attachments, LLC
423-405-5150 February 2019
Pre-Delivery Checklist
The Dealer should inform the Purchaser of this product of the Warranty terms, provisions, and procedures that
are applicable. The Dealer and Purchaser should review the contents of the Operator’s Manual including safety
equipment, safe operation and maintenance, review the Safety Signs on the implement (and tractor if necessary),
and the Purchaser’s responsibility to train their operators in safe operation procedures.
• IMPLEMENTS: I have explained that a Safety Shield should be installed and maintained in good repair. If the
shield is not installed the purchaser accepts responsibility for any personal injury due to not having the shield.
• HYDRAULICS: I have made certain that the hydraulic supply pump, hoses, and motor is in good repair and
fastened securely in place to prevent injuries.
• MOUNTED IMPLEMENTS: I have explained that it is not possible to guard against thrown objects when
the cutter is lifted off the ground or operated in a vertical conguration, and that operator is responsible for
watching out for persons in the work area.
PRE-DELIVERY SERVICE
CHECK AND ADJUST OR LUBRICATE AS REQUIRED
Refer to this Manual for Details
Inspection Performed - Warranty and Safety Procedures Explained - Installation Complete
MOWER
Make Sure The Pump MotorAnd Adapter Bolts Are
Properly Tightened
Make Sure The Blade Carrier Bolt Is Properly
Tightened And Cotter Pin Is In Place
Make Sure The Two Blade BoltsAre Tight
Make Sure The BladesAre Installed In Correct
Rotational Direction
Review Procedure To Congure The Mower In One
Of The Three Possible Congurations
Make Sure All Hardware Is Properly Tightened
Retighten the tapered roller bearing in the pivot arm
after 15 minutes of initial use and again at 30
minutes. Recheck again before the next use.
I have thoroughly instructed the buyer on the above-described equipment. This review included the Operation and
Parts Manual content, equipment care, adjustments, safe operation, and applicable warranty policy.
Date__________________ Dealer Rep. Signature_________________________________________
The above equipment and Operator’s Manual have been received by me (the purchaser), and I have been
thoroughly instructed as to care, adjustments, safe operation, and applicable warranty policy. As the purchaser
I have read, understand, and take responsibility for the use of this attachment. I understand
and accept responsibility for the proper use of this Offset Mower. I acknowledge this mower is
dangerous if not used correctly or if the safety information is not followed.
Date__________________ Owner’s Signature_________________________________________
LUBRICATION & HYDRAULICS
Make Sure All Grease Joints Are Lubricated.
Check All Hoses And Coupling For Damage Or
Leaks.
MOWER TO TRACTOR CONNECTIONS
Make Sure The Proper Hydraulic ConnectionsAre
Available On the Tractor
SAFETY ITEMS
Make Sure Safety Shield Is Properly Installed
Make Sure Safety Decals Are Installed
Review This Operator’s Manual
Review TheAEM Mower Safety Manual
(Supplied in Canister)
AEM Mower Safety Video Has Been Shown To
Purchaser
Cut Here to Remove Page or Make Copies of This Page


Offset Mowers 5 Trailblazer Attachments, LLC
423-405-5150 February 2019
Trailblazer Attachments, LLC Will Provide Upon Request
One (1) AEM Mower Safety Practices Video
Please Send Me: ____VHS Format – AEM/FEMA Mower Operator Safety Video
____DVD Format – AEM/FEMA Mower Operator Safety Video
____Operation and Parts Manual
____AEM Mower Operator’s Safety Manual
Requester Name:________________________________________Phone:__________________________
Requester Address:______________________________________________________________________
City:________________________________________ State:_______________________
Zip Code:____________________________
Cutter Model:_______________________________ Serial Number:_______________________________
Date Purchased:____________________________ Dealer Salesperson:___________________________
Dealership Name:___________________________ Dealership Location:___________________________
Return a copy of the Pre-Delivery Checklist along with this page to Trailblazer Attachments LLC.
Mail to:
Trailblazer Attachments LLC.
#7 Rocky Mount Road
Athens TN 37303
Or Fax to:
423-405-5904
Or Email to:
Sales@TrailBlazerAttachments.com
Cut Here to Remove Page or Make Copies of This Page


Offset Mowers 7 Trailblazer Attachments, LLC
423-405-5150 February 2019
1. Table of Contents
1. INTRODUCTION ........................8
1.1 Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Safe Operation .........................8
1.3 Intended Usage.........................8
1.4 Owner/Operator Manual Storage ...........9
1.5 Operator Orientation .....................9
1.6 Serial Number Location...................9
1.7 Product Improvements ...................9
1.8 Disposal of Equipment at End of Useful Life...9
1.9 Unanswered Questions...................9
2. SAFETY...............................10
2.1 General ..............................10
2.2 Safety Alert Symbols ....................10
2.3 Safety Icon Nomenclature................11
2.3.1 Personal Protection/Important
Information......................11
2.3.2 Prohibited Actions ................11
2.3.3 Hazard Avoidance ................11
2.4 General Safety Instruction................12
2.5 Training ..............................13
2.6 OSHA Training Requirements.............13
2.7 Federal Laws and Regulations ............14
2.8 Sign-Off Form .........................15
2.9 Operation Safety .......................16
2.10 Transporting Safety.....................16
2.11 Storage Safety.........................16
2.12 Maintenance Safety.....................16
3. SAFETY SIGNS AND INSTRUCTIONAL
LABELS ..............................17
3.1 General Information.....................17
3.2 How to Install Replacement Safety Signs ....17
3.3 Safety Signs ..........................18
4. OPERATION ...........................21
4.1 Operating Safety .......................21
4.2 Work Area Safety.......................21
4.3 Tractor Requirements ...................22
4.4 Attaching to Tractor ....................22
4.5 Horizontal Offset Mowing Conguration .....24
4.6 Vertical Mowing Conguration.............26
4.7 Detaching from Tractor ..................28
4.8 Mower Checklist .......................28
4.9 Operation Checklist.....................29
4.10 Right of Way (Roadway) Mowing ..........29
5. TRANSPORTING .......................30
5.1 Transporting Safety (Road)...............30
6. STORAGE .............................31
6.1 Storage Safety.........................31
6.2 Placing In Storage......................31
6.3 Removing From Storage ................31
7. SERVICE AND MAINTENANCE ...........32
7.1 Maintenance Safety.....................32
7.2 Mower Deck Pivot Arm Bearing............33
7.3 Greasing .............................33
7.4 Blade Servicing .......................33
7.4.1 Blade Removal...................33
7.4.2 Blade Installation .................33
7.4.3 Blade Sharpening ................33
7.5 Blade Carrier Removal ..................33
7.6 Blade Carrier Installation.................34
7.7 Service Record ........................34
7.8 Welding Repairs .......................34
8. PARTS ...............................35
9. WARRANTY ...........................36

Offset Mowers 8 Trailblazer Attachments, LLC
February 2019 423-405-5150
2. INTRODUCTION
2.1 Welcome
Standard Conguration of the Offset Mower
Congratulations on your choice of a Trailblazer
Attachments, LLC (Trailblazer) offset mower. This
equipment has been designed and manufactured to
meet the needs of discerning users.
The Trailblazer offset mower is designed to cut grass,
weeds, and light brush.
Many features incorporated into this offset mower are
the result of suggestions made by customers like you.
Read this manual carefully to learn how to operate
the offset mower safely and how to set it to provide
maximum cutting efciency.
The offset mowers are designed for light-duty
applications such as weed, grass, and light brush up to
3” diameter. The cutters can be used to mow under a
fence line or it can be turned vertically to mow the sides
of hedgerows and tree lines.
The mower uses a single spindle with two
free-swinging blades, which reduce the shock of impact
when a stationary object is contacted. A shear key in
the input shaft protects the motor from damage. A front
safety shield is optional but highly recommended.
WARNING
Operating the offset mower without the safety
shield can result in physical injury or death.
Make sure the shield is properly installed and
in working condition before operating the offset
mower.
By following the operating instructions in conjunction
with a good maintenance program, your Trailblazer
offset mower will provide many years of trouble-free
service.
2.2 Safe Operation
Safe, efcient, and trouble-free operation of your offset
mower requires that you, and anyone else who will be
using or maintaining the unit, read and understand the
information contained within the Owner’s Manual.
Use this manual for frequent reference and to pass on
to new operators or owners.
WARNING
Read And Understand Manual
To prevent personal injury or even death, be
sure you read and understand all of the
instructions in this manual and other related OEM
equipment manuals! The offset mower, if not used
and maintained properly, can be dangerous to users
unfamiliarwith its operation. Do notallow operating,
maintaining, adjusting, or cleaning of this offset
mower until the user has read this manual and has
developed a thorough understanding of the safety
precautions and functions of the unit.
This offset mower is designed for the specic purpose
of cutting grass, weeds, and light brush. DO NOT
modify or use this offset mower for any application
other than that for which it was designed.
Offset mowers maintained or operated improperly
or by untrained personnel can be dangerous;
exposing the user and/or bystanders to possible
serious injury or death.
2.3 Intended Usage
Do not use this offset mower for any other purpose than
its intended use; cutting grass, weeds, and light brush
and an in-line or offset application.

Offset Mowers 9 Trailblazer Attachments, LLC
423-405-5150 February 2019
The offset mower can also be used in a vertical
conguration for mowing along hedge rows and tree
lines.
This unit WILL NOT work on a skid steer
machine.
WARNING
Using the mower on a skid steer will void the
warranty and have the potential for serious injury to
the user or bystanders.
2.4 Owner/Operator Manual Storage
Always store the Owner/Operator manual and other
operating materials in the document storage tube.
2.5 Operator Orientation
The directions left, right, front, and rear, as mentioned
throughout this manual, are as seen from the tractor
operator’s seat and facing in the direction of travel.
2.6 Serial Number Location
The serial number decal is located on the left-hand,
back-side of the mower deck.
Model Number ______________________________
Serial Number ______________________________
2.7 Product Improvements
Because Trailblazer Attachments, LLC maintains an
ongoing program of product improvement, we reserve
the right to make improvements in design or changes in
specications without incurring any obligation to install
them on units previously sold.
2.8 Disposal of Equipment at End of Useful
Life
The Trailblazer Attachments, LLC offset mower has
been designed for the specic purpose of cutting grass,
weeds, and light brush. When this unit is no longer
capable of doing its designed purpose, it should be
dismantled and scrapped. Do not use any materials or
components from this unit for any other purpose.
2.9 Unanswered Questions
If you have any questions not answered in this manual
or require additional copies or the manual is damaged,
please contact your dealer or:
Trailblazer Attachments LLC.
#7 Rocky Mount Road
Athens TN 37303
Phone: (423) 405-5150
Fax: 423-405-5904
Email: Sales@TrailBlazerAttachments.com

Offset Mowers 10 Trailblazer Attachments, LLC
February 2019 423-405-5150
3. Safety
3.1 General
Safety of the operator and bystanders is one of the
main concerns in designing and developing a new
piece of equipment. Designers and manufacturers
build in as many safety features as possible. However,
every year many accidents occur which could have
been avoided by a few seconds of thought and a more
careful approach to handling the equipment.
Most work-related accidents are caused by failure to
observe basic safety rules or precautions. An accident
can often be avoided by recognizing potentially
hazardous situations before an accident occurs. As you
assemble, operate, or maintain the offset mower (unit),
you must be alert to potential hazards. You should also
have the necessary training, skills, and tools to perform
any assembly or maintenance procedures.
Improper operation and maintenance of this unit could
result in a dangerous situation that could cause injury
or death.
If you have any questions not answered in this manual
or require additional copies or the manual is damaged,
please contact your dealer or:
Trailblazer Attachments LLC.
#7 Rocky Mount Road
Athens TN 37303
Phone: 423-405-5150
Fax: 423-405-5904
Email: Sales@TrailBlazerAttachments.com
WARNING
Do not assemble, operate, or maintain the
unit until you read and understand the
information contained in this manual.
Safety precautions and warnings are provided
in this manual and on the unit. If these hazard
warnings are not heeded, bodily injury or
death could occur to you or to other persons.
Trailblazer Attachments, LLC cannot anticipate every
possible circumstance that might involve a potential
hazard. The warnings in this manual and on the
unit are, therefore, not all-inclusive. If a method of
assembly, operation, or maintenance not specically
recommended by us is used, you must satisfy yourself
that it is safe for you and for others. You should also
ensure that the unit will not be damaged or be made
unsafe by the methods that you choose.
The information, specications, and illustrations in this
manual are based on the information that was available
at the time this material was written and can change at
any time without notice.
3.2 Safety Alert Symbols
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
This manual contains DANGERS, SAFETY
INSTRUCTIONS, CAUTIONS, IMPORTANT NOTICES,
and NOTES which must be followed to prevent
the possibility of improper service, damage to the
equipment, personal injury, or death. The following
keywords call the readers’ attention to potential
hazards.
Hazards are identied by the “Safety Alert Symbol”
and followed by a signal word such as “DANGER”,
“WARNING”, or “CAUTION”.
DANGER
Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
This signal word is limited to the most extreme
situations.
WARNING
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
NOTICE
Indicates that equipment or property damage can result
if instructions are not followed.
SAFETY
INSTRUCTIONS
Safety instructions (or equivalent) signs indicate
specic safety-related instructions or procedures.
Note: Contains additional information important to a
procedure.

Offset Mowers 11 Trailblazer Attachments, LLC
423-405-5150 February 2019
3.3 Safety Icon Nomenclature
Pictorial icons signal a type of
hazard and warn of personal
protection issues, prohibited actions,
and hazard avoidance.
3.3.1 Personal Protection/
Important Information
Read the manual
Maintenance procedure
N
I
NG
AR
Damaged hazard label
Eye protection
Fire extinguisher
First aid kit
Hand protection
Head protection
Hearing protection
Inspect equipment
OEM
OEM parts only
Protective shoes
Remove key
Set parking brake
STOP Stop engine
THINK
SAFETY! Think safety
Transmission in park
Use proper support
Use proper tools
Use two people when
lifting heavy objects
Visibility
Rollover protection
Wear seat belt
Weight rating
Chemical flushing kit
3.3.2 Prohibited Actions
Do not alter or modify
Use proper tools
Do not weld
No alcohol
No drugs
No smoking
No young children
No riders
3.3.3 Hazard Avoidance
Crush hazard
Crush hazard (chock
wheels)
Crush hazard (foot)
Defective or broken part
Entanglement hazard
Explosive force hazard
Explosive separation
hazard
Fall hazard
Fire hazard
Cutter blade contact
hazard (hand)
Cutter blade contact
hazard (foot)
Lifting hazard
Cutting hazard
Pinch point hazard
Projectile hazard
Rollover protection
Safety alert symbol
Safety shields
Sharp object hazard
Slipping injury
0Tire pressure
Tripping injury

Offset Mowers 12 Trailblazer Attachments, LLC
February 2019 423-405-5150
3.4 General Safety Instruction
The owner/operator is responsible for the SAFE use
and maintenance of the offset mower. Make sure
anyone who is operating, maintaining, or working
around the offset mower is familiar with the operating
and maintenance procedures and related SAFETY
information contained in this manual. This manual will
take you step-by-step through your working day and
alerts you to all good safety practices that should be
used while using the offset mower.
In addition to the design features of the offset
mower, including safety signs, accident prevention is
dependent upon the awareness, concern, prudence,
and proper training of the people involved in the
operation, maintenance, and storage of the offset
mower.
In addition to this safety section, refer also to safety
messages and instructions in each of the appropriate
sections of the offset mower manual.
These general safety instructions apply to the overall
use and maintenance of the offset mower.
More specic instructions on safety are found in the
operation, maintenance, and storage sections of this
manual. Refer to these sections before performing any
of these tasks.
WARNING
Failure to comply with the following safety
instructions can and will result in serious injury and
possibly even death if they are not understood and
followed.
Read and Understand Manual
To prevent personal injury or even
death, be sure you read and understand
all of the instructions in this manual and other
related OEM equipment manuals! The Trailblazer
offset mower, if not used and maintained properly,
can be dangerous to users unfamiliar with its
operation. Do not allow operating, maintaining,
adjusting, or cleaning of this offset mower until the
user has read this manual and has developed a
thorough understanding of the safety precautions
and functions of the unit.
This offset mower is designed for the specic
purpose of cutting grass, weeds, and light brush.
DO NOT modify or use this offset mower for any
application other than that for which it was
designed.
Offset mowers maintained or operated improperly,
or by untrained personnel, can be dangerous;
exposing the user and/or bystanders to possible
serious injury or death.
WARNING
Provide User with Literature
Trailblazeroffset mower ownersmust provide
operator instructions to anyone using the
offset mower before use, and at least annually
thereafter. Refer to “3.6 OSHA Training
Requirements” on page 13.
Stay Clear
Clear the area of people, especially small
children, before using the offset mower.
Under no circumstances should young children be
allowed to work with or around the offset mower.
Impaired User Hazard
Do not attempt to assemble, operate, or
maintain this offset mower under the
inuence of drugs or alcohol. Consult your doctor
before using this offset mower while taking
prescription medications.
Crush Hazard
Do not allow anyone to ride on the
tractor or the offset mower. Falling or
crushing hazards can result in severe injuries or
death.
Falling Hazard
Do not allow riders on the hitch,
tractor, or offset mower at any time.
Falling can result in severe injuries or death.
No Unauthorized Modications
Do not modify the offset mower or
safety devices. Do not weld on the unit.
Unauthorized modications may impair its function
and safety. Personal injury or death can result from
unauthorized modications.
If the offset mower has been altered in any way from
the original design, Trailblazer does not accept any
liability for injury or warranty.
Damaged Parts Hazard
Do not use the offset mower if any parts are
damaged. If the offset mower has a defect,
immediately stop using it and remedy the problem
before continuing.
Thrown Objects Hazard
The offset mower can throw objects up to
300 feet. To avoid serious injury or death:
Keep all thrown object shielding in place.
Inspect area for potential thrown objects before
cutting.
Do not operate the offset mower with the deck
raised.

Offset Mowers 13 Trailblazer Attachments, LLC
423-405-5150 February 2019
CAUTION
The following safety instructions are provided to
help prevent potential injury. Not following these
instructions may lead to injury.
Personal Protection Equipment
When using this offset mower, wear appropriate
personal protective equipment. This list may
include, but is not limited to:
• Protective shoes with slip resistant soles
• Protective goggles, glasses, or face shield
• Protective clothing and gloves
• Safety vest (when operating near roads)
• Hearing protection
Ear Protection
Wearsuitableearprotectionduringprolonged
exposure to excessive noise.
Hearing Loss
Prolonged Exposure To Loud Noise May
Cause Permanent Hearing Loss!
Working environments with noise-producing
equipment can cause partial to permanent hearing
loss. We recommend using hearing protection any
time noise levels exceed 80 decibels (dB). Noise
levels over 85 dB, on a long-term basis, can cause
severe hearing loss. Noise levels over 90 dB over a
period of time can cause permanent and even total
hearing loss.
Hearing loss from loud noise is cumulative over a
lifetime without hope of natural recovery.
Crush Hazard
The tractor should be equipped with a
Roll Over Protective Structure (ROPS)
and a seat belt. A crushing hazard can occur if the
driver is ejected from the seat while the tractor is in
motion. Fasten the seat belt whenever the tractor is
moving.
SAFETY
INSTRUCTIONS
The following safety instructions are provided to
help prevent injury or limit equipment damage.
N
I
NG
AR Safety Signs
Replace any missing or hard-to-read safety
signs or instructional labels. Use care when
washing or cleaning the offset mower.
Replacementsafety signlocationsandpartnumbers
are provided in this manual and are available from
an authorized dealer parts department or the factory.
First Aid Kit
Have a rst aid kit available for use should
the need arise and know how to use it.
Fire Extinguisher
Have a re extinguisher available for use
should the need arise and know how to use it.
THINK
SAFETY! Think SAFETY!
Work SAFELY!
3.5 Training
Anyone who will be using and/or maintaining the offset
mower must read, clearly understand, and follow
ALL safety, operation, and maintenance information
presented in this manual, other related OEM manuals,
and the safety signs
If you do not understand any information in this
manual, see your dealer or contact Trailblazer
Attachments, LLC before proceeding.
Do not use or allow anyone else to use this offset
mower until all information has been reviewed.
Annually review this manual before the season start-
up.
Make periodic reviews of SAFETY and OPERATION
of the offset mower a standard practice.An untrained
operator is not qualied to use this offset mower.
3.6 OSHA Training Requirements
The following training requirements have been taken
from Title 29, Code of Federal Regulations Part
1928.57 (a) (6). www.osha.gov.
Operator instructions. At the time of initial assignment
and at least annually thereafter, the employer shall
instruct every employee who operates an agricultural
tractor and implements in the safe operating practices
and servicing of equipment with which they are or will
be involved, and of any other practices dictated by the
work environment.

Offset Mowers 14 Trailblazer Attachments, LLC
February 2019 423-405-5150
3.7 Federal Laws and Regulations
IMPORTANT FEDERAL LAWS AND REGULATIONS
CONCERNING EMPLOYERS, EMPLOYEES AND OPERATORS
This sections is intended to explain in broad terms the concept and effect of the following federal laws and
regulations. It is not intended as a legal interpretation of the laws and should not be considered as such.
U.S. PUBLIC LAW 91-596 (The Williams-Steiger Occupational Safety and Health Act of 1970) OSHA
This Act Seeks:
“ ... to assure so far as possible every working man and woman in the nation safe and healthful working conditions and to
preserve our human resources ... “ DUTIES
Sec. 5(a) Each Employer -
(1) shall furnish to each of its employees employment and a place of employment which are free from
recognized hazards that are causing or are likely to cause death or serious physical harm to its
employees.
(2) shall comply with occupational safety and health standards promulgated under this Act.
(b) Each employee shall comply with occupational safety and health standards
and all rules, regulations, and orders issued pursuant to this Act which are
applicable to his or her own actions and conduct.
OSHA Regulations
Current OSHA regulations state in part: “At the time of initial assignment and at least annually thereafter, the
employer shall instruct every employee in the safe operation and servicing of all equipment with which the
employee is, or will be involved.” These will include (but are not limited to) instructions to:
Keep all guards in place when the machine is in operation;
Permit no riders on equipment;
Stop engine, disconnect the power source, and wait for all machine movement to stop before servicing,
adjusting, cleaning, or unclogging the equipment, except where the machine must be running to be
properly serviced or maintained, in which case the employer shall instruct employees as to all steps and
procedures which are necessary to safely service or maintain equipment.
Make sure no one is within 300 feet of machinery before starting the engine, engaging power,
or operating the machine.
EMPLOYEE TRACTOR OPERATING INSTRUCTIONS:
1. Securely fasten your seat belt if the tractor has a ROPS.
2. Where possible, avoid operating the tractor near ditches, embankments, and holes.
3. Reduce speed when turning, crossing slopes, and on rough, slick, or muddy surfaces.
4. Stay off slopes too steep for safe operation.
5. Watch where you are going, especially at row ends, on roads, and around trees.
6. Do not permit others to ride.
7. Operate the tractor smoothly - no jerky turns, starts, or stops.
8. Hitch only to the drawbar and hitch points recommended by tractor manufacturers.
9. When tractor is stopped, set brakes securely and use park lock if available.
Child Labor Under 16 Years Old
Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to
know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard
Administration, Wage & Home Division, Child Labor Bulletin #102).

Offset Mowers 15 Trailblazer Attachments, LLC
423-405-5150 February 2019
3.8 Sign-Off Form
Trailblazer follows the general Safety Standards
specied by the Farm Equipment Manufacturers
Association (FEMA), and the American National
Standards Institute (ANSI). Anyone who will be
using and/or maintaining the offset mower must read
and clearly understand ALL safety, operation and
maintenance information presented in this manual.
Do not use or allow anyone else to use this offset
mower until all information has been reviewed.
Annually review this manual before the season start-
up.
Sign-Off Form
Date User’s Signature Owner’s Signature
Make periodic reviews of SAFETY and OPERATION
of the offset mower a standard practice.An untrained
operator is not qualied to use this offset mower.
This sign-off sheet is provided for your record keeping
to show that all personnel who will be working with the
equipment have read and understand the information in
this Operator’s Manual and Parts Book and have been
instructed in the operation of the equipment.

Offset Mowers 16 Trailblazer Attachments, LLC
February 2019 423-405-5150
3.9 Operation Safety
Refer to the Operation section for safety
recommendations related to using the offset mower. All
applicable safety recommendations in other sections
should also be followed.
Trailblazer strongly recommends installing the optional
safety shield, shown here, on all offset mowers.
The safety shield is designed to reduce the risk of
thrown objects; however the offset mower deck and
safety shield cannot prevent all objects from escaping
the blade enclosure in every mowing condition,
especially in the vertical conguration.
It is possible for objects to ricochet and escape,
traveling as much as 300 feet. Inspect safety shield
each day of operation and replace any broken or
missing chains, as required.
3.10 Transporting Safety
Refer to the Transporting section for safety
recommendations related to transporting the offset
mower. All applicable safety recommendations in other
sections should also be followed.
3.11 Storage Safety
Refer to the Storage section for safety
recommendations related to storing the offset mower.
All applicable safety recommendations in other
sections should also be followed.
3.12 Maintenance Safety
Refer to the Service and Maintenance section for
safety recommendations related to maintaining the
offset mower. All applicable safety recommendations in
other sections should also be followed.

Offset Mowers 17 Trailblazer Attachments, LLC
423-405-5150 February 2019
4. SAFETY SIGNS AND INSTRUCTIONAL LABELS
4.1 General Information
The types of safety signs (hazard labels) and
instructional labels, along with their locations on the
equipment, are shown in the following illustrations.
Good safety practices require that you familiarize
yourself with the various safety signs, the type of
warning, and the area or particular operation related to
that area that requires your SAFETYAWARENESS.
THINK
SAFETY!
Think SAFETY!
Work SAFELY!
Pay close attention to the safety signs and instructional
labels attached to the tractor and the offset mower.
Duplicate safety signs, which are attached to the offset
mower, can also be found in this section. If the offset
mower is missing a label or one is unreadable, replace
the label before using the offset mower.
SAFETY
INSTRUCTIONS
N
I
NG
AR Safety Signs and Instructional Labels
1. Keep safety signs or instructional labels clean
and legible at all times. Use a clean, damp cloth
to clean safety decals.
2. Replace any missing or hard-to-read safety signs
or instructional labels.
3. Usecarewhenwashingorcleaningtheequipment
not to remove or damage the labels. When using
a pressure washer to clean the offset mower,
avoid spraying too close to decals; high-pressure
water can enter through very small scratches or
under edges of decals causing them to peel or
come off.
4. Locations for the labels and replacement part
numbers are shown in this section.
5. Replacement parts must have replacement labels
attached during installation and/or before the
offset mower is used.
6. Labels are available from your authorized dealer
or from Trailblazer at no charge.
4.2 How to Install Replacement Safety Signs
1. Clean and dry the installation area.
Note: Do not install the signs if the temperature is
below 50°F (10°C).
2. Determine the exact position before you remove the
backing paper.
3. Remove the backing paper.
4. Align the sign over the specied area and carefully
press the sign to the part/frame.
Note: Small air pockets can be pierced with a pin and
smoothed out using the piece of backing paper.

Offset Mowers 18 Trailblazer Attachments, LLC
February 2019 423-405-5150
4.3 Safety Signs

Offset Mowers 19 Trailblazer Attachments, LLC
423-405-5150 February 2019
TI-00005
To prevent serious injury or death:
Read and understand Operator’s Manual before using.
Review annually.
Do not permit riders on the tractor or mower. Never
carry children on tractor seat.
Do not allow children to operate mower.
Operate only with guards installed and in good condition.
Keep away from moving parts.
Operate only with tractor equipped with ROPS and
seatbelts.
Before mowing, clear debris from mowing area.
Do not operate in the raised position.
Stop engine, set brake and wait for all moving parts to
stop before dismounting.
Support mower securely before working beneath unit.
Transport with clean reflectors, SMV and working lights
as required by federal, state, and local laws.
WARNING
•
•
•
•
•
•
•
•
•
•
•
TI-00006
THROWN OBJECT HAZARD
To prevent serious injury or death:
Do not operate unless all guards
are installed and in good condition.
Stop blade rotation if bystanders
come within several hundred feet.
•
•
DANGER
TI-00075
All rotary cutters have the ability to discharge objects at high
speeds, which could result in serious injury to bystanders or
passers-by.
Therefore, this cutter is not to be operated along highways or
in any area where people may be present unless all sides of the
unit are enclosed by permanent bands, safety chains, or other
factory approved safety shields that are in good repair.
WARNING

Offset Mowers 20 Trailblazer Attachments, LLC
February 2019 423-405-5150
TI-00007
DANGER
ROTATING BLADES-KEEP AWAY
To prevent serious injury or death when the engine is
running and the blades are rotating:
•
Never allow riders, especially children, on tractor
or mower.
•
Do not operate with bystanders in mowing area.
•
Do not operate with deflectors/guards removed.
•
Do not place hands or feet under deck.
TI-00074
WARNING
NO RIDERS
TI-00008
WITH U.S. & IMPORTED PARTS
MADE IN THE USA
Table of contents
