Transition Networks CVIDF20xx-15x User manual
User’s Guide
CVIDF20xx-15x Analog CCT Video Copper-to-
Fiber Video Receiver
Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .4
Cable Specification . . . . . . . . . . .5
Technical Specifications . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . .6
Contact Us . . . . . . . . . . . . . . . . . .7
Compliance Information . . . . . . . .8
Single and dual channel video receiver card features:
• Plug-and-play design for easy installation
• CCTV video equipment compatible
• One-way signal transmission through the system
• AM Video
• NTSC, PAL, SECAM compatible
• Automatic Gain Control (AGC)
• Real time full color video
• Link Pass Through
• Single or dual video channel configuration
• Automatic gain control (contrast and brightness)
The CVIDF20xx-15x video receiver, when paired with
Transition’s camera-mounted transmitter J/VD-Tx-01,
enables the transport of analog CCTV video over a fiber
infrastructure for extended reach video surveillance or
security installations. In extended fiber receiver mode, the
RX sensitivity can be adjusted to accommodate greater
distances.
The chassis card is available in a single video channel or a
dual video channel configuration. All video conversion is
performed in real time. The automatic Gain Control (AGC)
feature automatically adjusts the video contrast and
brightness to maintain the quality and integrity of the
original video stream.
Dual
Single
2
CVIDF20xx-15x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Model Optic Fiber Distance
CVIDF2011-150
Video Receiver (Single)
ST, multimode, 850 nm 1km (0.6miles) standard
2km (1.2miles) extended
CVIDF2011-155
Video Receiver (Dual)
(2)ST, multimode, 850 nm 1km (0.6miles) standard
2km (1.2miles) extended
CVIDF2013-150
Video Receiver (Single)
SC, multimode, 850 nm 1km (0.6miles) standard
2km (1.2miles) extended
CVIDF2013-155
Video Receiver (Dual)
(2)SC, multimode, 850 nm 1km (0.6miles) standard
2km (1.2miles) extended
CVIDF2012-150
Video Receiver (Single)
ST, single mode, 1310 nm 10km (6.2miles) standard
20km (12.4miles) extended
CVIDF2012-155
Video Receiver (Dual)
(2)ST, single mode, 1310 nm 10km (6.2miles) standard
20km (12.4miles) extended
Connector Type Quantity Distance
75-Ohm BNC 2 75-Ohm coax cable, 228m (750ft)
Fiber 2 Model dependent (see below)
The video receiver system has the following types of connectors.
The various fiber connections are available on separate models. Single mode and
multimode receivers come in the following configurations.
Installation
Card handling
1. Keep the CVIDF20xx-15x card in its anti-static bag until ready to install.
2. Wear a grounding strap when removing the card from its anti-static bag.
Distance configuration shunt
The CVIDF20xx-15x card come with a shunt installed in the “S” position on connector
J1 (single channel) and J1/J5 (dual channel) as shown below.
CVIDF20xx-15x
Installation -- continued
J1 and J5 are distance configuration connectors. Position “S” is for standard distances
and “X” is for extended distances. The distances are model dependent.
Installing video card in a Point System chassis
To insert the video card, do the following:
1. Wearing a ground strap, slide the card into an available slot in the Point System
chassis. See photo below.
2. Push the card all the way into the slot (should snap in).
3. Push in and turn the screw clockwise to secure the card to the chassis frame.
3
Setting up the video system
Equipment needed:
• J/VD-TX-01 fiber transmitter (single or multimode)
• CVIDF20xx-15x video card (single or multimode)
• Video camera
• Monitor
• Coax cable
• Fiber cable
Note: The video transmitter and receiver must be matched: single mode TX/RX or
multimode TX/RX. If installed as a mixed pair, the system will not function.
Caution: Use 75 ohm BNC connectors on 75 ohm cable only. Failure to observe this
caution will result in signal degradation.
Note: See J/VD-TX-01 fiber transmitter manual (#33349) available on the web @
transition.com for specifics.
4
CVIDF20xx-15x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Setting up video system -- continued
To install the video transmitter and receiver system cables, see installation diagram
below.
Point System
Chassis
with
CVIDF20xx-15x
Receiver Card
Fiber
Fiber
Dual Channel Video System
75-Ohm BNC Coax Cable
75-Ohm BNC Coax Cable
Directly Mounted Camera
Monitor Monitor
J/VD-TX-01
Transmitter
Coax*
Camera
Camera
J/VD-TX-01
Transmitter
*75-Ohm BNC Coax Cable
Operation
LEDs
The following shows LED locations and an explanation of each follows:
RX 2 R X1 P WR
1
2
3
CVIDF20xx-15x
Operation -- continued
LED Description
1RX2 (Receive) ON solid green = fiber cable connect/receiving data
Off = No power or cable disconnected
2RX1 (Receive) ON solid green = fiber cable connect/receiving data
Off = No power or cable disconnected
3PWR (Power) ON Green Powered
OFF No Power
• Make sure that power is supplied to the transmitter, receiver, and camera,
with the monitor turned ON.
• The system is operational when the camera feed appears on the monitor.
Cable specifications
Coax cable
RG Type: RG-59, RG-6
Gauge: 18–25, single conductor
Impedance: 75 ohms
Distance: 228 M (750 ft) Max
Fiber
Single Mode 9/125μ
Multimode 62.5/125μ
Multimode
Wavelength: 850 nm
Link Budget: 6.0 db or 11.0 db
Single Mode
Wavelength: 1310 nm
Link Budget: 10.0 db or 15.0 db
Technical Specifications
Use 75-ohm BNC connectors on 75-ohm cable only.
Transition Networks models CVIDF20xx-15x video receiver specifications for
all six models.
Video formats: NTSC, PAL, SECAM
Video spec
Input Video: 0.5 to 2-volt pk-pk (75 ohms)
Bandwidth: 5 Hz - 10 MHz
Differential gain: < 5 %
Differential phase: < 5°
Tilt: < 1%
Signal/Noise Ratio: 60dB
6
CVIDF20xx-15x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1--952-941-7600
Technical Specifications -- continued
Power consumption: Single card 2 watts; dual card 3 watts
Power supply: 12 V – chassis AC
Operating temperature: 0°C to 60°C (32°F to 140°F)
Storage temperature: -25°C to 85°C (13°F to 185°F )
Humidity: 5% to 95%, non-condensing
Altitude: 0 to 10,000 feet
Dimensions: 0.86”W x 5.0”D x 3.4”H (22 mm x 127 mm x 86 mm)
Warranty: Lifetime
The information in this user’s guide is subject to change. For the most up-to-date
information on the CVIDF20xx-15x video receiver, view the user’s guide on-line at:
www.transition.com.
Troubleshooting
If there are problems with the system setup or a system failure occurs, isolate and
correct the problem by determining the answers to the following questions and then
taking the indicated action:
1. Is the power LEDs ON on the receiver?
NO
• Is the power to the chassis ON?
• Is the card fully inserted ?
• Is the power on LED lit?
• Contact Technical Support: US/Canada: 1-800-260-1312, International: 00-1-
952-941-7600.
YES
• Proceed to step 2.
2. Are the RX LED lit on the receiver?
NO
• Check that the fiber cable SM/MM matches the transmitter and receiver set
SM/MM.
• Check the fiber-cable connections and condition of the fiber cable.
• Check for video signal at the transmitter coax port.
• Check the coax cable connection.
• Contact Technical Support: US/Canada: 1-800-260-1312, International: 00-1-
952-941-7600.
YES
• Contact Technical Support: US/Canada: 1-800-260-1312, International: 00-1-
952-941-7600.
