SDSTX3110-121S-LRT
Industrial Serial Device Server
User Guide
33745 Rev. A

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 2of 109
Trademark Notice
All trademarks and registered trademarks are the property of their respective owners. All other products or service names
used in this publication are for identification purposes only, and may be trademarks or registered trademarks of their
respective companies. All other trademarks or registered trademarks mentioned herein are the property of their respective
holders.
Copyright Restrictions
© 2018 Transition Networks, Inc. All rights reserved. No part of this work may be reproduced or used in any form or by any
means (graphic, electronic, or mechanical) without written permission from Transition Networks.
SDSTX3110-121S-LRT Industrial Serial Device Server User Guide, 33745 Rev. A
Contact Information
Transition Networks
10900 Red Circle Drive
Minnetonka, MN 55343 USA
Tel: [phone] or 1-800-526-9267
Fax: [phone]
Record of Revisions
Rev
Date
Description of Changes
A 3/30/18 Initial release for SDSTX3110-121S-LRT, SDS-Manager v1.5c, and FW v 1.1.
Address comments on this product or manual to: Transition Networks Inc. * 10900 Red Circle Drive *
Tel: [phone] / Toll Free: 800-526-9267 / Fax: [phone] * E-Mail: [e-mail]

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 3of 109
Table of Contents
Record of Revisions..................................................................................................................................2
1. Introduction ............................................................................................................................................5
1.1 Product Numbers...............................................................................................................................5
1.2 Features .............................................................................................................................................6
1.2.1 Hardware Features ...................................................................................................................... 6
1.2.2 Software Features ...................................................................................................................... 6
1.3 Applications........................................................................................................................................7
1.4 Dimensions.........................................................................................................................................8
1.4.1 SDSTX3110-121S-LRT Dimensions............................................................................................... 8
1.5 Pin Definitions....................................................................................................................................9
1.5.1 DB9 Connector ............................................................................................................................ 9
1.5.2 DB9 Console Port Wiring............................................................................................................. 9
1.5.3 10/100 Base-T(X) MDI/MDI-X Pin Assignments ........................................................................ 10
1.6 Package Contents............................................................................................................................. 11
1.7 Optional Accessories........................................................................................................................ 11
2. Hardware Overview ..............................................................................................................................12
2.1 Front Panel .......................................................................................................................................12
2.1.1 Ports and Connectors ................................................................................................................ 12
2.1.4 LED Descriptions....................................................................................................................... 12
2.1.6 DIP Switch for RS 422/485 Termination .................................................................................... 13
2.2 Top Panel..........................................................................................................................................14
2.3 Back Panel ........................................................................................................................................14
3. Hardware Installation ...........................................................................................................................15
3.1 DIN-Rail Installation .........................................................................................................................15
3.2 Wall Mounting .................................................................................................................................16
3.3 Rack Mounting .................................................................................................................................17
3.4 Wiring...............................................................................................................................................18
3.4.1 Grounding.................................................................................................................................. 18
3.4.2 Redundant Power Inputs........................................................................................................... 18
3.5 Connection.......................................................................................................................................19
3.5.1 10/100BASE-T(X) Pin Assignments........................................................................................... 19
3.5.2 Cable Types and Specifications................................................................................................. 19
4. Management.........................................................................................................................................20
4.1 SDS-Manager....................................................................................................................................20
4.1.1 Install the SDS-Manager ............................................................................................................ 20
4.1.2 SDS-Manager Overview............................................................................................................. 22
4.1.3 Using SDS-Manager................................................................................................................... 23
File ...................................................................................................................................................... 23
Device Configuration .......................................................................................................................... 24
COM Configuration............................................................................................................................. 24
Options............................................................................................................................................... 24
Help .................................................................................................................................................... 24
Search for and Discover Serial Device Servers ................................................................................... 25
4.1.4 Configure Device Servers........................................................................................................... 26
4.1.5 Configure Serial Port ................................................................................................................. 35

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 4of 109
4.2 Service Mode ...................................................................................................................................39
4.2.1 Virtual COM Mode .................................................................................................................... 39
4.2.2 TCP Server Mode....................................................................................................................... 41
4.2.3 TCP Client Mode........................................................................................................................ 43
4.2.4 UDP Mode ................................................................................................................................. 44
4.2.5 VCOM List.................................................................................................................................. 45
4.2.6 Setup Wizard ............................................................................................................................. 46
4.2.8 IP Collection............................................................................................................................... 46
4.2.9 System Log................................................................................................................................. 46
4.3 Web Management ...........................................................................................................................47
4.3.1 Management via Web Browser................................................................................................. 47
4.3.2 System ....................................................................................................................................... 48
4.3.3 Port Serial Setting...................................................................................................................... 52
4.4.1 TCP Server Mode....................................................................................................................... 57
4.4.2 TCP Client Mode........................................................................................................................ 58
4.4.3 UDP Mode ................................................................................................................................. 59
4.4.4 Management............................................................................................................................. 60
4.4.5 Factory Default / Restore Config / Upgrade Firmware / Reboot............................................... 65
4.5 Configuration by SSH Console..........................................................................................................74
4.5.1 Connect to SSH Console ............................................................................................................ 74
4.6 Uninstall SDS Manager.....................................................................................................................87
5. Technical Specifications ........................................................................................................................89
SDSTX3110-121S-LRT Regulatory Approvals..........................................................................................90
Power Supply Specifications ..................................................................................................................91
xxxxx GlobTek Power Supply .............................................................................................................. 91
25130 Features and Specifications..................................................................................................... 94
25135 Features and Specifications..................................................................................................... 96
6. Troubleshooting ....................................................................................................................................98
6.1 FAQs .................................................................................................................................................98
6.2 Procedure.........................................................................................................................................99
6.3 Record Model and System Information .........................................................................................100
6.4 Package and Device Labeling .........................................................................................................101
7. Service, Warranty and Tech Support .................................................................................................102
7.1 Contact Us......................................................................................................................................102
7.2 Warranty ........................................................................................................................................102
7.3 Compliance Information ................................................................................................................104
7.4 Safety Warnings and Cautions .......................................................................................................105
7.5 Electrical Safety Warnings..............................................................................................................106
7.6 Encryption Registration Number ...................................................................................................106
A. DB-9 to RJ-45 Adapter for RS-485 Connection (-PA Build Only)........................................................107
1. Adapter PN 29069............................................................................................................................107

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 5of 109
1. Introduction
Transition Networks hardened serial device server provides the ability to communicate secured serial data across
an Ethernet network.
The SDSTX3110-121S-LRT contains two 10/100 Fast Ethernet ports that can be configured to communicate to
one or multiple redundant servers. Security of the data transmission is assured through HTTPS, SSH, and SSL data
encryption.
The SDSTX3110-121S-LRT comes with COM port redirector software enabling communication of serial data to a
virtual COM port on a server, or can be used in pairs to provide serial tunneling across the Ethernet network.
The SDSTX3110-121S-LRT is a hardened device designed to operate in the harshest environments. It has a slim
IP-30 enclosure that can fit into space-constraining cabinets. The device accepts 12-48VDC power input and it is
also certified to operate in temperatures of -40°C to +70°C.
1.1 Product Numbers
The SDS models are described below.
Product #
Description
SDSTX3110-121S-LRT
Slim size Industrial 1 secure serial port to Ethernet device server with one (1)
RS232/422/485 DB9 ports and two (2) 10/100Base-TX RJ-45 ports with a
reduced footprint. It has (2) 10/100Base-TX ports and 1 RS-232/422/485 port.
SDSTX3110-121S-LRT-PA
Slim size Industrial 1 secure serial port to Ethernet device server with one (1)
RS232/422/485 DB9 ports and two (2) 10/100Base-TX RJ-45 ports with a
reduced footprint. It has (2) 10/100Base-TX ports and 1 RS-232/422/485 port.
Includes Adapter #29069 .
Optional Accessories
(sold separately)
25130
Industrial DIN Rail Mounted Power Supply; Input: 85-264 VAC, 120-370 VDC.
Output: 48VDC, 0.83A, 39.8 Watts.
25135
Industrial DIN Rail Mounted Power Supply; Input: 85-264 VAC, 120-370 VDC.
Output: 24VDC, 0.42A, 10 Watts.
xxxxx
GlobTek Power Supply GT-41080-1817.9-5.9:
Input: 120-240VAC~. 50-60Hz. 0.6A.
Output: 12VDC 1.5A

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 6of 109
1.2 Features
•Operating Modes: Virtual Com, Serial Tunnel, TCP Server, TCP Client, UDP
•Redundant multiple host devices:
o5 host devices: Virtual COM, TCP Server, TCP Client mode;
o4 IP ranges in UDP mode
•Security: SSL data encryption; secured management by HTTPS and SSH: IP Access: IP White List
•Event Warning via Syslog, Email, SNMP trap
•Configurable by Web interface, Windows utility (SDS-Manager), or SSH Console.
•SDS-Manager-x64 for Windows Server 2003 and 2008, Windows XP, Windows 7, Windows 8
•SDS-Manager 32-bit version for Windows Server 2003 and 2008, Windows XP, Windows 7, Windows 8
•Windows OS support: Windows NT/2000/ XP/ 2003/VISTA (32/64bit)/Windows 7(32/64bit) /Windows 8
1.2.1 Hardware Features
•DIN-rail and wall-mount enabled
•Redundant DC power inputs
•IP Casing: IP-30
•Extended operating temperature (-40°C to 70°C)
1.2.2 Software Features
•Supports five host devices including Virtual COM, TCP Server, TCP Client modes and four IP ranges
•Supports application-based QoS management
•NAT-pass through support for users to manage SDS through NAT router
•Ensure high levels of security with SSL data encryption, HTTPS/SSH, IP access control and IP white list
•Event warning by Syslog, Email, and SNMP trap
•Configurable by Web Interface, SSH console, and Windows utility
•Operating Modes: Virtual Com, Serial Tunnel, TCP Server, TCP Client, UDP
•Security: SSL data encryption; secured management by HTTPS and SSH IP Access: IP White List
•Event Warning by SYSLOG, Email, SNMP trap

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 7of 109
1.3 Applications
The figure below shows typical SDS configurations (e.g., Multiple Host PCs, SSL Data Encryption, TCP
Client/Server Modes, and NAT Router Pass-through).

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 8of 109
1.4 Dimensions
1.4.1 SDSTX3110-121S-LRT Dimensions
The SDSTX3110-121S-LRT cabinet dimensions are provided below:

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 9of 109
1.5 Pin Definitions
1.5.1 DB9 Connector
The SDSTX3110-121S-LRT serial port can be connected using a DB9 cable. The DB9 connector supports RS232 /
RS422 / RS485 operation modes. The table below provides the DB9 connector pin assignments.
Pin #
RS-232
RS-422
RS-485 (4 wire)
RS-485 (2 wire)
1
DCD
TX-
TX-
DATA-
2
RXD
TX+
TX+
DATA+
3
TXD
RX+
RX+
4
DTR
RX-
RX-
5
GND
GND
GND
6
DSR
7
RTS
8
CTS
9
RI
DB-9 Serial Port
1.5.2 DB9 Console Port Wiring
The serial ports can be connected using a DB9 cable. The DB9 connector supports RS232 / RS422 / RS485
operation modes. Please refer to the following table for the pin assignments of the DB9 connector.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 10 of 109
1.5.3 10/100 Base-T(X) MDI/MDI-X Pin Assignments
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
Pin Number
MDI port
MDI-X port
1
TD+(transmit)
RD+(receive)
2
TD-(transmit)
RD-(receive)
3
RD+(receive)
TD+(transmit)
4
Not used
Not used
5
Not used
Not used
6
RD-(receive)
TD-(transmit)
7
Not used
Not used
8
Not used
Not used
9

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 11 of 109
1.6 Package Contents
Carefully unpack the items near the final location. Save the packing materials for possible future use.
Verify that you received the items below. Contact your sales representative if you have not received all of the
following items:
□One SDSTX3110-121S-LRT
□Two Wall-Mount Brackets
□One DC Jack to 1 pair Cable, Black, Female, D2C-2001
□One TN Postcard and one printed Quick Start Guide
□One Plastic Bag with a 4-Pin Terminal Block, two I/O Dust Covers, and eight Screws.
□One optional power supply
1.7 Optional Accessories
These optional accessories can be ordered separately:
□25130 Industrial DIN Rail Mount Power Supply
□25135 Industrial DIN Rail Mount Power Supply
See the Power Supply Specifications on page 85 for power supply details.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 12 of 109
2. Hardware Overview
2.1 Front Panel
SDSTX3110-121S-LRT Front Panel
2.1.1 Ports and Connectors
The Ethernet ports on the device use RJ45 connectors.
Port
Description
ETH1 and ETH2
Two 10/100 Base-T(X) ports (ETH 10/100M).
Serial Port
One DB9 Serial Port.
Reset button
To restore the device configurations back to the factory defaults, click the front panel
Reset button for a few seconds. Once the power LED starts to flash, release the button.
The device will then reboot and return to factory defaults.
2.1.4 LED Descriptions
With the device installed and cabled, the green power LED should light. The LEDs are described below.
LED
Color
State
Description
P1 / P2
Green
On
Power is on and functioning normally.
ETH1 / ETH2
Green
On
Port is connected
ETH1 / ETH2
Green
Blinking
Data Transmitted.
Rx
Amber
On
Receiving Serial data.
Tx
Green
On
Transmitting Serial data.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 13 of 109
2.1.6 DIP Switch for RS 422/485 Termination
Termination is used to match the impedance of a transmission line to the hardware impedance of the interface it
is connected to. There is more than one way to add termination to an RS485/422 serial connection. The most
commonly used is DC Termination, accomplished by attaching a resistor between the signal lines on the extreme
ends of the transmission line.
Set DIP switch # 3 to ON (enabled) for long distance (>=100m) transmission to improve the quality of data
transmission. The default is Off.
SW No.
Description
1
150K / 1K Ohm Pull High/Low Resistor
2
3
Enable / Disable Terminal Resistor
DIP Switch
SW No.
Setting Description
1
Off
150K / 1K Ohm Pull High/Low Resistor
2
ON
150K / 1K Ohm Pull High/Low Resistor
3 Off
ON
Disable Terminal Resistor (default)
Enable Terminal Resistor for data transmission distance >=100m
to improve the data transmission quality.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 14 of 109
2.2 Top Panel
The top panel components are shown and described below:
1 Terminal block: V1-, V1+, V2- and V2+ for power connections.
2 Grounding screw (see section 3.4.1 Grounding on page 18).
3 Reset button.
SDSTX3110-121S-LRT Top Panel
2.3 Back Panel
Below are the back panel components with the DIN-rail kit removed and with the DIN-rail kit installed:

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 15 of 109
3. Hardware Installation
3.1 DIN-Rail Installation
A DIN-Rail kit is pre-installed to let you fasten the device to a DIN rail. The dimensions are provided below.
SDSTX3110-121S-LRT Dimensions (in mm)
1. Slant the device and screw the DIN-Rail Kit onto the back of the device, right in the middle of the back panel.
2. Slide the device onto a DIN-rail from the DIN-Rail kit and make sure the device clicks into the rail firmly.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 16 of 109
3.2 Wall Mounting
The SDS can be fixed to the wall via the wall mount kit included in the package. The wall mount kit dimensions
are provided below.
To install the device on a panel or wall:
1. Remove the Din-Rail clip by removing the three screws.
2. Use the screws included in the package to install the wall mount bracket.
3. Screw the two pieces of wall-mount kits to the top and bottom panels of the device. A total of eight screws
are required, as shown below.
4. Use the device, with wall mount plates attached, as a guide to mark the correct locations of the four screws.
5. Insert a screw head through middle of the keyhole-shaped aperture on the plate, and then slide the device
downwards. Tighten the screw head for added stability.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 17 of 109
3.3 Rack Mounting
The SDS can be rack mounted using the procedure below.
1. Install the provided L-shaped mounting brackets to the left and right sides of the device as shown below.
2. With the front brackets oriented in the front of the rack, mount the device in the rack with the four rack-
mounting screws.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 18 of 109
3.4 Wiring
Warning: Do not disconnect modules or wires unless power has been switched off or the area is known
to be non-hazardous. The devices may only be connected to the supply voltage shown on the type plate.
Attention:
1. Be sure to disconnect the power cord before installing and/or wiring your devices.
2. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes
dictating the maximum current allowable for each wire size.
3. If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your
equipment.
4. Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must
cross, make sure the wires are perpendicular at the intersection point.
5. Do not run signal or communications wiring and power wiring through the same wire conduit. To avoid
interference, wires with different signal characteristics should be routed separately.
6. You can use the type of signal transmitted through the wire to determine which wires should be kept
separate. The rule of thumb is that wiring sharing similar electrical characteristics can be bundled together.
7. You should separate input wiring from output wiring.
8. It is advised to label the wiring to all devices in the system.
3.4.1 Grounding
Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the
ground connection from the ground pin on the power module to the grounding surface prior to connecting
devices.
3.4.2 Redundant Power Inputs
The device has two sets of DC power inputs on the 4-pin terminal block located on top of the device. Follow the
steps below to wire the power input on the terminal block.
1. Insert the Terminal Block connector into the keyed receptacle on the SDS.
2. Insert the negative/positive wires into the V- and V+ terminals, respectively.
3. To keep the wires from pulling loose, use a small flat-blade screwdriver to tighten the wire-clamp screws on
the front of the terminal block connector.

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 19 of 109
3.5 Connection
3.5.1 10/100BASE-T(X) Pin Assignments
Depending on the link type, the device can use CAT 3, 4, 5, or 5e UTP cables to connect to any other network
devices (PCs, servers, switches, routers, or hubs). See the table below for cable specifications.
With 10/100BASE-T(X) cables, pins 1 and 2 are used for transmitting data, and pins 3 and 6 are used for receiving
data. Note that the + and -signs represent the polarity of the wires that make up each pair.
Pin Number
Assignment
1
TD+
2
TD-
3
RD+
4
Not used
5
Not used
6
RD-
7
Not used
8
Not used
3.5.2 Cable Types and Specifications
Cable
Type
Max. Length
Connector
10BASE-T
CAT 3, 4, 5 100-ohm
UTP 100 m (328 ft.)
RJ-45
100BASE-TX
CAT 5 100-ohm UTP
UTP 100 m (328 ft.)
RJ-45

Transition Networks SDSTX3110-121S-LRT User Guide
33745 Rev. A https://www.transition.com Page 20 of 109
4. Management
Management / configuration methods include:
1. Web interface
2. Windows utility (SDS-Manager)
a) SDS-Manager-x64 for Windows Server 2003 & 2008, Windows XP, Windows 7, Windows 8.
b) SDS-Manager 32 bit version for Windows Server 2003 & 2008, Windows XP, Windows 7, Windows 8.
3. SSH Console connect to SDS Commander
4.1 SDS-Manager
SDS-Manager is a powerful Windows utility for SDS devices. SDS-Manager supports device discovery, device
configuration, group setup, group firmware update, and monitoring. SDS-Manager lets you easily install and
configure devices on the network. SDS-Manager requires 8881 Kb of disk space.
Two versions of SDS Manager are available; one each to support to support 32-bit and 64-bit Windows systems.
1. Determine which version you require.
2. Download it from the Transition Networks website: SDS Management Software zip file (e.g., filename
SDS-Manager_x64_v1.5a_20170413.zip).
3. Unzip the Zip file (e.g., SDS-Manager_x64_v1.5a_20170413.exe).
4. Note the name and location of the .EXE file. Firmware file names have the format SDSTX3110-121S-
LRT_2016221_1.1_uImage. SDS-Manager file names are SDS-Manager_x64_v1.5a.exe and SDS-
Manager_v1.5c_201701207.exe.
4.1.1 Install the SDS-Manager
Follow the steps below to install the SDS Manager.
1. Select the folder for the SDS-Manager and click Start to run the setup program. The Destination Directory
screen displays.
2. Click the Start button to install in the default directory (C:\Program Files (x86)\SDS-Manager), or browse to
and select a different location and then click the Start button. When done the message Installation was
completed successfully displays.
3. Click the OK button. A dialog displays indicating The installation of SDS-Manager is finished.
