tri-art audio B Series User manual

dc linear
tube buffered
power supply
B-Series
User Manual
24 Volt – Product #21677
12 Volt – Product #21680*Read the user manual
before operating.

safety
information
Before you start...
Warning of a hazard for the user, the unit or possible misuse. Important notice.
Thank you for buying a Tri-Art Audio product. Please read through this manual to understand and
operate this product correctly. Please keep this manual in a safe place so that you may refer to it
whenever necessary. Please ensure the product you are using is rated for your country’s electrical
system, or it will not be covered under our warrenty.
Warning:
To prevent re or shock hazard, do not expose this product to rain or moisture.
Important Notice:
The serial number for this equipment is located on the bottom of this component. Please write this
serial number on the enclosed warrenty card and follow the instructions to register your product for
our three (3) year limited warrenty.
This equipment is designed for consumer use, such as home audio systems. It is not designed to
operate in a business environment or a mobile application. Mobile, professional, or commerical
businesses such as resturants will not be covered under warrenty.
caution:To reduce the risk of electric shock, do not remove cover (or back).
No user serviceable parts inside. Refer servicing to qualied service personnel.

safety
information
Safety Instructions
Read Instructions:
All the safety and operating instructions should be read before operating this equipment.
Retain Instructions:
The safety and operating instructions should be retained for future reference.
Heed All Warnings:
All warnings, set up procedures, and operating instructions should be strictly adhered to.
Follow all instructions carefully.
Water and Moisture:
Under no circumstances should this audio component be used near water.
It is not to be used in a bathroom, water closet, shower, kitchen, wet basement,
pool/spa/suana area, or outdoors.

safety
information
Safety Instructions
Ventilation:
Please ensure that the location of this equipment is such that in no way does it prevent adequate
ventilation. Do not enclose this unit in fabric or enclose in a cabinet where there is inadequate
ventilation. In no instance should the product be located where the ow of air is impeded or cannot
allow proper vanilation.
NOS GE 5670 tube Please ensure to provide adequate ventilation around the tube. Similar to a
light bulb it can get warm to the touch. Please ensure its location is free of any cables or household
materials that might come in contact with the tube. Never install or remove the tube with the AC
power connected. Avoid touching the tube with your bare hands (use a glove) and never touch it
when it is in operation
Heat:
This product should be located well away from all the heat sources such as but not limited to
heaters, forced air heat, radiators, stoves, and replaces.
Power Sources:
The Tri-Art component should be connected to a power supply as listed on the actual component
and manual.
Cleaning:
Your Tri-Art product was soaked in hemp oil and sealed with beeswax. Only use the Tri-Art
Beeswax and Hemp Oil in moderate amounts as per the instructions to freshen up the appearance
from time to time as needed. Do not use lacquers or aerosol wax products with this product. Do not
pour water on the surface at any time.
Heavy Objects:
Do not place heavy objects on this component.

included
in the box
• Power Supply
• AC Power Cord
• DC Barrel to Barrel Cable

2
supply top:
1
1
l
o
w
m
i
d
h
i
g
h
NOS GE 5670 tube
3 Position Tube Gain Selector
2
Figure: 1

supply front:
supply back:
3
5
4
6
Tube Toggle Switch
LED Light
Vdc Power Output
Vac Power Input
5 6
On / Of f
Tube
Vdc
24Vdc
120/220Vdc
Power Supply
3
4
Figure: 2
Figure: 3
NOS GE 5670 tube
NOS GE 5670 tube
12 or 24 Vdc
12 or 24 Vdc

supply specs
Power Supply: 12 or 24 Volt DC 5 Amps, Linear Tube Buffered
Tube: One (1) NOS GE 5670 (or one of the listed equivalent) [1]
Gain: Three Position Gain Selector Switch for optimal Tube Loading
Interior: Dampened with Natural Sheep’s Wool
Cabinet: Bamboo Cabinet Features Acoustic Wafing
to Break Up Sound Waves
Crafted with bamboo and natural sheep’s wool.
Learn more at triartaudio.com
use & guidelines
The power supply is active as soon as it is connected to the
AC power.The power supply operates with or without the tube
buffering.
title
Subtitle
subtitle 2
Body
1. Remove the Power Supply, and assorted cables from the box.
Conrm you have all components as specied under included in the box (page 5)
2. Please ensure that you have the correct power supply for the voltage of your country.
3. While wearing gloves [so that the oils from your hand do not get on the tube] gently install the
tube into its tube socket located in the top of the unit. Do not twist.
4. Connect the Barrel plug to the Vdc Power output. (see Figure 3)
5. Connect the opposite side of the barrel plug to the component.
6. Insert the AC power cord into the receptacle Vac power input (see Figure 3) on the back
panel of the power supply.
7. Connect the ac power cord to the AC wall receptacle.
Setting up the power supply

How it Works:
The tube buffer uses one (1) NOS GE 5670 tube. It’s anticipated life span under normal operation,
[the tube] should not need to be replaced. However, tubes are consumable devices like lightbulbs
and the lament may fail any any time. Tube rolling is the listener’s choice, our designers have
spent many hours listening to different tubes before selecting the one they felt was the best sound
for a reasonable investment. Our warranty is only valid for the factory supplied tube. The tube is not
covered under this warranty.
The tube draws on the DC current presenting a stable load. By turning the switch to one of three
preset loadings you add or decrease the amount of tube power draw you add to the load. The
brightness of the tube visually increases with higher loading settings. Note: The switch does not
add volume gain, it just increases the vacuum tube loading on the AC current.
[1] Tube Buffered Power Tap (NOS GE 5670 Tube)
Or equivalent such as:
2C51 6CC42 6N3P-DR 6N3P-EV 6N3P-I
Using your new dc linear tube buffered
power supply
1. Locate the Three position Gain selector switch for the tube loadingt settings and set it to low.
2. Locate the tube output toggle switch and switch it on. (move it to the left)
3. Using the three position gain select the low, mid or high setting.
4. This setting allows for nding the optimal tube loading for the attached equipment.
5. In most cases the mid setting is the most desirable.
6. It is recommended to disengage the tube (switch it off when not in use) to avoid using the tube
when not listening. This will also extend tube life. Switching the tube on and off rapidly will also
shorten tube life expectancy.

warranty
information
For Your Protection:
Completely and immediately mail the product registration card so that we may contact you directly
in the event a safety notication is issued in accordance with the 1972 Consumer Safety Act, or for
other reasons Tri-Art Audio may deem necessary.
Technical Support
Our technical department will gladly answer any questions you may have about our products.
Using the Contact Us feature on our web site (www.triartaudio.com) is the ideal method for
obtaining a prompt reply. We can also be contacted via telephone [phone] (Monday
through Thursday, 9AM to 5PM, Friday 9:00AM to 3PM EST. Please note questions posted on
social media do not automatically forward to technical staff so we highly recommend the contact us
on our website for a prompt response.
Manufacturer’s Limited Three Year Warranty:
Tri-Art Audio warrants this unit to be free from defective material or workmanship and will repair or
replace this unit or any part thereof if it proves defective in normal use or service within three (3)
years from the date of original purchase.
Tube manufacturers warranty on all tube products is 6 months after date of shipment.
This warranty will be considered void if the unit has been tampered with, improperly serviced,
subjected to abuse or misuse or if installed in a commercial vehicle. This warranty does not cover
accidental damage.
For all warranty information please see Tri-Art Audio’s warranty
information card included with your new equipment.

thank you for
your purchase!
TM

triartaudio.com
Designed. Fabricated. Assembled.
In Canada
