Tripp Lite AWC-002 User manual

1
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
All trademarks are the sole property of their respective owners.
Owner’s Manual
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR®surge protector in our monthly drawing!
tripplite.com/warranty
USB 2.0 Desktop/Laptop
1080p Webcam with Internal
Microphone, LEDs and Lens Cover
Model: AWC-002
Este manual está disponible en español en la página
de Tripp Lite:tripplite.com
Ce manuel est disponible en français sur le site Web
de Tripp Lite : tripplite.com
Русскоязычная версия настоящего руководства
представлена на веб-сайте компании Tripp Lite по
адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der
Tripp Lite-Website verfügbar: tripplite.com

2
• AWC-002 USB 2.0 Webcam
• USB-A to USB-C Adapter
• Owner’s Manual
• Captures high-definition (HD) 1080p video at 30 fps
(frames per second) and 2 MP (megapixel) images
for livestreaming or conference calls
• 70° wide-angle lens reduces dead angles
• Advanced H.264 video compression ensures high-
quality transmission
• Rotatable clip makes it easy to mount onto laptops
or monitor screens
• Tripod threads allow mounting on a tripod for extra
stability
• Built-in noise reduction microphone captures audio
within 20 ft. to ensure clear communication and
sound quality
• LEDs indicate webcam’s on/off/active status to
prevent accidental video feeds
• Movable lens cover provides extra privacy when
needed
• USB-A to USB-C adapter included for versatility in
port connection
Package Contents
Product Features

3
Product Features
System Requirements
• Compatible with Windows and macOS operating
systems, as well as Skype, Zoom and YouTube
software
• Plug-and-play operation with no software required
for easy, immediate installation
• USB-A or USB-C port
• Windows 7, 8, 10 or later
• macOS 10.10 or later
• Android 5.0 or above
• Chrome OS

4
1) Open the clip base.
2) Mount the webcam to your monitor or laptop.
Note: Make sure the foot on the clip base is flush
with the back of your monitor or laptop screen.
3) Rotate the camera to the desired angle.
Note: Tripod threads at the bottom of the clip base allow you
to mount the webcam on a tripod.
Mounting Instructions
1 2 3
1.9 in.
(49.5 mm)
1.8 in.
(48 mm)
1.8 in.
(48 mm)
1.4 in.
(35.5 mm)
3.1 in.
(80 mm)
1.2 in.
(30 mm)

5
Plug the webcam into a USB-A or USB-C interface
on your PC, laptop or TV STB. The webcam will install
automatically in about 60 seconds.
Note: A USB-A to USB-C adapter is included for connecting
the built-in USB-A cable to the USB-C port on your laptop or
computer.
To take advantage of livestreaming or video calling,
both you and the recipient must install video-calling
applications (such as Skype or Zoom) and webcam
hardware.
Connection/Installation
Video Calling
USB

6
Q: How do I know if my camera is recognized by
the operating system?
A: Connect the webcam to a USB port and wait
about one minute for it to install. To check if your
computer’s OS is recognizing the webcam, go to:
Control Panel > System and Security > System >
Device Manager
Q: How do I know if my video calling application is
using my webcam?
A: All video applications include an option setting to
review the audio and video device. While using
the video application, review the following:
• The audio selection to ensure the webcam
microphone is selected. If not, change the
selection to AWC-002 webcam.
• The video selection to ensure the webcam is
selected. If not, change the selection to
AWC-002 webcam.
Q: How do I determine if the webcam is properly
installed on my computer?
A: Windows: Go to: Computer Management > Device
Manager > Cameras
A: macOS: Click the Finder icon on the Dock. From
the Finder window sidebar, click Applications and
open the Photo Booth app. Click the Camera
dropdown from the Photo Booth toolbar. “USB 2.0
Camera” should be listed as the default webcam.
FAQ

7
FAQ
Q: Why is my webcam not working with Skype or
Facebook?
A: Software like Skype and Facebook often use the
integrated webcam by default. To use the AWC-
002 webcam, go to the software’s video settings
and select the AWC-002 webcam as the video
source. For example, with Skype, go to Setting >
Audio & Video to select the video source.
Q: What do the LEDs on my webcam indicate?
A: The red LED indicates the webcam is powered on.
The green LED indicates the camera is active.
Specifications
Pixel Size 2.8 µm x 2.8 µm
Operating Temperature Range -4° to 140°F (-20° to 60°C)
Storage Temperature Range -4° to 140°F (-20° to 60°C)
Relative Humidity 0% to 20% RH,
Non-Condensing
Image Resolution 2 MP
Pixel Range 320 x 240, 640 x 480,
1280 x 720, 1920 x 1080
Frame Rate 30 fps
Lens Size 1/2.7 in.
Interface/
USB Specification
USB 2.0 (backwards
compatible with USB 1.1)
Data Format YUY2/MJPEG
Viewing Angle 70°
DC Voltage 5V
Current 200mA
Cable Length 4.8 ft. (1.45 m)

8
Warranty and Product Registration
3-Year Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions, to be free from
original defects in material and workmanship for a period of three (3) years from the date of initial
purchase. If the product should prove defective in material or workmanship within that period,
Seller will repair or replace the product, at its sole discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM
ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER
THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY
OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND
THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES.
(Some states do not allow limitations on how long an implied warranty lasts, and some states
do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and
you may have other rights which vary from jurisdiction to jurisdiction.)
WARNING: The individual user should take care to determine prior to use whether this device is
suitable, adequate or safe for the use intended. Since individual applications are subject to great
variation, the manufacturer makes no representation or warranty as to the suitability or fitness of
these devices for any specific application.
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically
entered into a drawing for a chance to win a FREE Tripp Lite product!*
*No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Use of this equipment in life support applications where failure of this equipment can reasonably
be expected to cause the failure of the life support equipment or to significantly affect its safety or
effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Photos and illustrations may differ slightly from actual products.
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
21-06-203 • 93-3F0B_RevA
