Preface
I
Preface
Notebook Computer
D400P/D410P
Service Manual

Preface
II
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained
herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven-
dor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are
they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or
reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publica-
tion, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of
their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement
of that product or its manufacturer.
Version 1.0
February 2004
Trademarks
Intel®and Pentium®are registered trademarks of Intel Corporation.
Windows®is a registered trademark of Microsoft Corporation.
Other brand and product names are trademarks and./or registered trademarks of their respective companies.

Preface
III
Preface
About this Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and
inspection of personal computers.
It is organized to allow you to look up basic information for servicing and/or upgrading components of the D400P/D410P
series notebook PC.
The following information is included:
Chapter 1, Introduction, provides general information about the location of system elements and their specifications.
Chapter 2, Disassembly, provides step-by-step instructions for disassembling parts and subsystems and how to upgrade
elements of the system.
Appendix A, Part Lists
Appendix B, Schematic Diagrams

Preface
IV
Preface
Related Documents
You may also need to consult the following manual for additional information:
User’s Manual on CD
This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro-
gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

Preface
V
Preface
Contents
Introduction ..............................................1-1
Overview .........................................................................................1-1
System Specifications .....................................................................1-2
Processor .........................................................................................1-2
Core Logic .......................................................................................1-2
Structure ..........................................................................................1-2
Security ............................................................................................1-2
Memory ...........................................................................................1-2
BIOS ................................................................................................1-2
LCD Options ...................................................................................1-2
Display ............................................................................................1-2
Storage Devices ...............................................................................1-3
Audio ...............................................................................................1-3
Keyboard .........................................................................................1-3
Pointing Device ...............................................................................1-3
Interface ...........................................................................................1-3
PC Card ...........................................................................................1-3
Communication ...............................................................................1-3
Power Management .........................................................................1-4
Power ...............................................................................................1-4
Indicators .........................................................................................1-4
Environmental Spec ........................................................................1-4
Physical Dimensions .......................................................................1-4
Weight .............................................................................................1-4
Optional ...........................................................................................1-4
Design Differences ..........................................................................1-5
External Locator - Top View ..........................................................1-6
External Locator - Front & Left Side Views ...................................1-7
External Locator - Right Side & Rear Views ..................................1-8
External Locator - Bottom View .....................................................1-9
Mainboard Overview - Top (Key Parts) ....................................... 1-10
Mainboard Overview - Bottom (Key Parts) ................................. 1-11
Mainboard Overview - Top (Connectors) .................................... 1-12
Mainboard Overview - Bottom (Connectors) ............................... 1-13
Disassembly ...............................................2-1
Overview ......................................................................................... 2-1
Maintenance Tools .......................................................................... 2-2
Connections .................................................................................... 2-2
Maintenance Precautions ................................................................ 2-3
Cleaning .......................................................................................... 2-3
Disassembly Steps .......................................................................... 2-4
Removing the Battery ..................................................................... 2-8
Removing the Hard Disk Drive ...................................................... 2-9
Hard Disk Upgrade Process ............................................................ 2-9
Removing the System Memory (RAM) ....................................... 2-10
Memory Upgrade Process ............................................................. 2-10
Removing the CD Device ............................................................. 2-12
Removing the Bluetooth Module .................................................. 2-14
Removing the Wireless LAN Module .......................................... 2-15
Removing the Processor ............................................................... 2-16
Removing the Keyboard ............................................................... 2-18
Removing the Keyboard Shielding Plate ...................................... 2-19
Removing the LCD and Top Case ................................................ 2-20
Removing the TouchPad and Click Board ................................... 2-22
Removing the Switch Board ......................................................... 2-23
Removing the Modem .................................................................. 2-24
Removing the Speakers ................................................................ 2-25
Removing the Mainboard ............................................................. 2-26
Removing the Fan Unit ................................................................. 2-27
Removing the Floppy Disk Drive Assembly ................................ 2-28

Preface
VI
Preface
Removing the PC Card Assembly .................................................2-29
Removing the LCD Front Panel Module ......................................2-30
Removing the Inverter ...................................................................2-31
Removing the PC Video Camera Module .....................................2-32
Removing the LCD Module ..........................................................2-33
Part Lists ..................................................A-1
Part List Illustration Location ........................................................A-2
Top (400P) ...................................................................................... A-3
Bottom (400P) ................................................................................ A-4
LCD 14" (400P) ............................................................................. A-5
LCD 15" (400P) ............................................................................. A-6
CD-ROM Drive (400P) .................................................................. A-7
CD-RW Drive (400P) ..................................................................... A-8
Combo Drive (400P) ...................................................................... A-9
DVD-ROM Drive (400P) .............................................................A-10
Floppy Disk Drive (400P) ............................................................A-11
Hard Disk Drive (400P) ...............................................................A-12
Top (410P) .................................................................................... A-13
Bottom (410P) ..............................................................................A-14
LCD 14" (410P) ........................................................................... A-15
LCD 15" (410P) ........................................................................... A-16
CD-ROM Drive (410P) ................................................................A-17
CD-RW Drive (410P) ................................................................... A-18
Combo Drive (410P) ....................................................................A-19
DVD-ROM Drive (410P) .............................................................A-20
Floppy Disk Drive (410P) ............................................................A-21
Hard Disk Drive (410P) ...............................................................A-22
Schematic Diagrams................................. B-1
System Block Diagram ................................................................... B-2
Socket 478 1 of 2 ............................................................................ B-3
Socket 478 & ITP 2 of 2 ................................................................. B-4
Clock Generator ..............................................................................B-5
M650 (Host/AGP) 1 of 4 ................................................................B-6
M650 (Memory for DDR) 2 of 4 ....................................................B-7
M650 (& CRT Out) 3 of 4 ..............................................................B-8
M650 (Power) 4 of 4 .......................................................................B-9
DDR Memory DIMM ...................................................................B-10
DDR SSTL-2 Termination ...........................................................B-11
LVDS Interface (SiS302LV) ........................................................B-12
Panel Con & LED Indicator .........................................................B-13
962 (PCI/IDE/HyperZip) 1 of 4 ....................................................B-14
962 (Misc Signals) 2 of 4 ..............................................................B-15
962 (USB I/F) 3 of 4 .....................................................................B-16
962 (Power & RTC) 4 of 4 ...........................................................B-17
HDD/Combo Connector ...............................................................B-18
USB Port .......................................................................................B-19
PCMCIA ENE CB1410 ................................................................B-20
PCMCIA Power ............................................................................B-21
1394 PHY TSB41LV01 ................................................................B-22
LPC Super I/O ..............................................................................B-23
LPT/COM Port .............................................................................B-24
LPC H8 .........................................................................................B-25
LAN RTL8100BL ........................................................................B-26
Audio Codec ALC201A ...............................................................B-27
Audio Out & Off Board Connectors .............................................B-28
System Power Control ..................................................................B-29
Fan Control and SpeedStep ..........................................................B-30
VCORE .........................................................................................B-31
DDR Power ...................................................................................B-32
System ...........................................................................................B-33
Charger .........................................................................................B-34
SW Board and HotKey .................................................................B-35
TouchPad and Switch Board ........................................................B-36

Introduction
Overview 1 - 1
1.Introduction
1: Introduction
Overview
This manual covers the information you need to service or upgrade the D400P/D410P series notebook computer. Infor-
mation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information
about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.
Operating systems (e.g. DOS, Windows 9x, Windows NT 4.0, Windows 2000, Windows XP, OS/2 Warp, UNIX, etc.) have
their own manuals as do application software (e.g. word processing and database programs). If you have questions about
those programs, you should consult those manuals.
The D400P/D410P series notebook is designed to be upgradeable. See “Disassembly” on page 2 - 1 for a detailed de-
scription of the upgrade procedures for each specific component. Please note the warning and safety information indi-
cated by the “” symbol.
The balance of this chapter reviews the computer’s technical specifications and features.

Introduction
1 - 2 System Specifications
1.Introduction
System Specifications
Processor
• Intel Pentium 4 Processor - (478-pin) FC-PGA2 package
(µ0.13) 0.13 Micron Process Technology, 512KB L2
Cache & 400MHz FSB - 2.0/ 2.2/ 2.4/ 2.5/ 2.6 GHz
(µ0.13) 0.13 Micron Process Technology, 512KB L2
Cache & 533MHz FSB - 2.26/ 2.4/ 2.53/ 2.66/ 2.8/ 3.06*
GHz
* Only Pentium 4 processors of 3.06GHz support Hyper-
Threading Technology
• Intel Celeron Processor - (478-pin) FC-PGA2 package
(µ0.18) 0.18 Micron Process Technology, 128KB L2
Cache & 400MHz FSB - 1.7/ 1.8 GHz
(µ0.13) 0.13 Micron Process Technology, 128KB L2
Cache & 400MHz FSB - 2.0/ 2.1/ 2.2 GHz
• Mobile Intel Pentium 4 Processor (Portability) - (478-pin)
FC-PGA2 package
(µ0.13) 0.13 Micron Process Technology, 512KB L2
Cache & 533MHz FSB - 2.26/ 2.4/ 2.66/ 2.8/ 3.06 GHz
(µ0.13) 0.13 Micron Process Technology, 512KB L2
Cache & 533MHz FSB with Hyper-Threading Technol-
ogy - 2.66/ 2.8/ 3.06 GHz
Core Logic
• SIS M650 + 962
Structure
• PC99 compliant
Security
• Security (Kensington® Type) Lock
•BIOSPassword
Memory
• Two 200-pins DDR SODIMM sockets, supporting DDR
SDRAM SODIMM (2.5V)
- DDR 200/ DDR 266/ DDR 333 compliant
• Memory expandable up to 1024MB (128/256/512MB
SODIMM Modules)
BIOS
• One 512KB Flash ROM
•PhoenixBIOS
LCD Options
• 14.1" XGA TFT (1024*768)
• 15.0" XGA TFT (1024*768)
• 15.0" SXGA+ TFT(1400*1050)
Display
• High Performance 256-bit 3D engine
• Advanced HW accelerator for DVD playback
• Fully Direct X 8.0 compliant graphics engine
• Dual-View display monitor

Video Memory
The system allocates
or "shares" a portion of
system memory for
video use. "Shared"
memory is user-config-
urable via the SCU.
The default setting is
set to 32MB.

Introduction
System Specifications 1 - 3
1.Introduction
Storage Devices
•3.5"3-modeFloppy Disk Drive
• Easy changeable 2.5" 9.5 mm (h) Hard Disk Drive
Supporting Master mode IDE
Supports PIO mode 4
ATA-33/66/100/133
Ultra DMA
• 12.7mm(h) Device Bay for ONE of the following drive
configuration options:
•CD-ROM
•DVD-ROM
•CD-RW
• Combination CD-RW/DVD-ROM
Audio
• AC'97 2.1 compliant interface
• 3D stereo enhanced sound system
• Compatible with Sound-Blaster PRO™
• S/PDIF Digital output (5.1 CH) for DVD content and
stereo audio
• Microphone-in jack
• Headphone-out jack
• Built-in microphone
• 2 built-in speakers
Keyboard
• “Win Key” keyboard
Pointing Device
• Built-in TouchPad (scrolling key functionality integrated)
Interface
• Three USB 2.0/ 1.1 ports
• One Mini-IEEE 1394 port
• One S-Video Out port for TV output
• One serial port
• One parallel port (LPT1), supporting ECP / EPP
• One external CRT monitor port
• One external keyboard/mouse (through Y cable) PS/2 port
• One speaker-out/headphone-out jack
• One microphone-in jack
• One RJ-11 jack for modem
• One RJ-45 jack for 100M/10M LAN
• One S/PDIF Out port
• One DC-in jack
• Wireless module On/Off switch
• Built-in 3 instant keys: WWW, email, and application
PC Card
• One type II PCMCIA 3.3V/5V socket supporting CardBus
Communication
• 10/100Mb Ethernet LAN built-in
• 56K MDC modem V.90 & V.92 compliant
• 802.11b wireless LAN module (available as a factory
option)
• Bluetooth module (available as a factory option)
• PC Camera module (available as a factory option)

Introduction
1 - 4 System Specifications
1.Introduction
Power Management
• Supports ACPI v1.0b
• Supports suspend to RAM (S3)
• Supports suspend to disk (S4)
• Supports Battery low suspend
• Supports resume from modem ring
Power
• Full range AC adapter
• AC-Input 100~240V, 50~60Hz
• DC Output 20V, 6A
• Supports one removable Smart Li-Ion battery
Indicators
• LED indicators (HDD, Power On/ AC-In/ Suspend, Bat-
tery Charging/Battery Full, Num Lock, Caps Lock, Scroll
Lock, E-mail)
Environmental Spec
• Temperature
Operating: 5°C ~ 35°C (w/o packing)
Non-Operating: -20°C ~ 60°C (packing)
• Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Physical Dimensions
• 329 (w) x 275 (d) x 36.5 (h) mm
Weight
• Around 2.8 kg (depend on optional modules included)
without battery
Optional
• DVD-ROM Drive
•CD-RWDrive
• Combination Drive
•DVD-RWDrive
• Software DVD player
• Wireless LAN module
• Bluetooth module
•VideoCamera

Introduction
System Specifications 1 - 5
1.Introduction
Design Differences
This manual refers to the two notebook designs pictured below. The designs vary slightly in external design. Photographs
used throughout this manual are of Design I.
Figure 1
Design Differences
Design I Design II

Introduction
1 - 6 External Locator - Top View
1.Introduction
External Locator - Top View
Figure 2
Top View
1. Optional Built-in
USB Camera
2. LCD
3. Built-In
Microphone
4. LED Power &
Communication
Indicators
5. LED Status
Indicators
6. Hot-Key buttons
7. Close Cover
Switch
8. Power Button
9. Keyboard
10. TouchPad and
Buttons
2
6
4
5
7
1
8
3
9
10

Introduction
External Locator - Front & Left Side Views 1 - 7
1.Introduction
External Locator - Front & Left Side Views Figure 3
Front View
1. LCD Latches
2. Mini IEEE 1394
Port
3. S/PDIF Out Port
4. Microphone Jack
5. Headphone Jack
6. Infrared
Transceiver
7. Wireless Module
ON/OFF Switch
8. Built-In Speakers
4 5
6 7
1
2
1
3
8 8
Figure 4
Left Side View
1. CD-ROM Bezel or
CD-ROM Device
2. USB 2.0/1.1 Port
3. Floppy Disk Drive
4. PC Card/ PCMCIA
Slot
5. PC Card/PCMCIA
Slot Eject Buttons
3
4
1
5
2

Introduction
1 - 8 External Locator - Right Side & Rear Views
1.Introduction
External Locator - Right Side & Rear Views
1
Figure 5
Right Side View
1. Security Lock Slot
Figure 6
Rear View
1. Vent
2. DC-In Jack
3. 2 * USB Ports
4. External Monitor
(CRT) Port
5. Parallel Port
6. Serial Port
7. S-Video-Out Port
8. PS/2 Type Port
9. RJ-11 Phone Jack
10. RJ-45 LAN Jack
34 5 6 7 8 9 10
1
2

Introduction
External Locator - Bottom View 1 - 9
1.Introduction
External Locator - Bottom View
Figure 7
Bottom View
1. Vent/Fan Intake
2. Battery Cover
3. Hard Disk Cover
4. Bluetooth
Module Cover
5. CPU Heatsink
Cover
Note: The RAM and
optional Wireless
LAN module are lo-
cated under the CPU
Heatsink Cover
1
1
2
4
5
3

Introduction
1 - 10 Mainboard Overview - Top (Key Parts)
1.Introduction
Mainboard Overview - Top (Key Parts)
Figure 8
Mainboard Top
Key Parts
1. PC Card
Assembly
2. Northbridge - SiS
M650
3. Southbridge - SiS
962
4. Flash ROM BIOS
1
2
3
4

Introduction
Mainboard Overview - Bottom (Key Parts) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Key Parts)
Figure 9
Mainboard Bottom
Key Parts
1. CPU Socket (no
CPU installed)
2. Memory Sockets
(no memory
installed)
3. SiS 302LV TV-
Out Controller
4. LAN Controller
RTL8100BL
5. CardBus ENE
CB1410
6. ALC202 - Audio
Codec
7. 1394 PHY
TSB41AB1
8. Clock Generator
9. Keyboard
Controller - KBC
H8 H8S-2149 HM
10. LPC Super I/O
NS PC87393
1
2
3
4
5
6
7
8
910

Introduction
1 - 12 Mainboard Overview - Top (Connectors)
1.Introduction
Mainboard Overview - Top (Connectors)
Figure 10
Mainboard Top
Connectors
1. Modem Cable
Connector (CN1)
2. LCD and Inverter
Cable Connector
(JLCD1)
3. Video Camera
Module
Connector
(JCCD1)
4. Switch Board
Cable Connector
(JSW1)
5. Fan Cable
Connector
(JFAN1)
6. TouchPad Cable
Connector (JTP1)
7. Keyboard Cable
Connector (JKB1)
8. Modem Module
Connector
(JMDC1)
9. Speaker Cable
Connector
(JSPK1)
10. Floppy Disk
Cable Controller
(JFDD1)
11. Speaker Cable
Connector
(JSPK2)
5
7
8
4
6
123
9
10
11
