Triteka EoC-500 Series User manual

v1.0.4
Ethernet over Coax
Network System
Model: EoC-500 Series

i
About This Guide
While reading through the User Guide you may see
various icons that call attention to specific items. Below
is a description of these icons:
NOTE: This check mark indicates that there is
a note of interest and is something that you
should pay special attention to while using the
product
WARNING: This exclamation point indicates
that there is a caution or warning and it is
something that could damage your property
or product.
WEB: This globe icon indicates a noteworthy
website address or e-mail address.
This Manual is intended for people who want to
configure the EoC Ethernet Adapter using the EoC-
500 Series (EoC-500, EoC-500AP, EoC-500-4L, EoC-
500-WL.Triteka's Nexus Utility version 6.1.0. You
should have your basic Internet access or Local Area
Network already setup.
Quick Start Guide
The Quick Start Guide is designed to help
you get up and running right away. It contains
information on making your hardware
connections.
Support CD
Refer to the included CD for support
documents
Triteka Website
Please refer to www.triteka.com for additional
support documentation and product
certifications.
Computer with:
Operating system support TCP/IP installed
Pentium III and above
Ethernet LAN card support TCP/IP protocol
64MB of RAM or more
50MB of Free disk space or more
The contents of this publication may not be reproduced in
any part of as a whole, stored, transcribed in an information
retrieval system, translated into any language, or
transmitted in any form or by any means, mechanical,
magnetic, electronic, optical, photocopying, manual, or
otherwise, without prior written permission.
All product, company, and brand names are trademarks or
registered trademarks of their respective companies. They
are used for identification purpose only. Specifications are
subject to be changed without prior notice.
This equipment has been tested and found to comply with
the limits for a ClassB digital device pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against radio interference in a
commercial environment. This equipment can generate,
use and radiate radio frequency energy and, if not installed
and used in accordance with the instructions in this
manual, it may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause interference, in which
case the user, at his own expense, will be required to take
whatever measure are necessary to correct the
interference.
Before installing the EoC Network System, verify that you
have the items listed under “Package Contents”. Also be
sure that you have the necessary cabling. If any of the
items are missing or damaged, contact your local Triteka
distributor.
• One (1) EoC Ethernet Adapter
• One (1) Power cord
• One (1) 3 ft (1 meter) Ethernet cable
• Support CD - Documentation & Utility Software
• Quick Start Guide
If possible, please retain the carton and original packing
materials in case there is a need to return the product.
Help us help you. Send all User Guide-related comments,
questions or suggestions for improvement to the following
email. Thank you!
E-mail: [email protected]

ii
